ＡＦＮ－ＦＨ１８消防电话ＡＦＮ－ＦＨ１８消防电话使用说明书（Ｖ１．０　２００８．４）一、概述ＡＦＮ－ＦＨ１８消防电话是一种总线式智能设备，内置微处理器，性能稳定，工作可靠。

采用一路智能通讯回路，一路语音总线回路，单机容量６０点。

消防电话用于消防工作区域之间通话用的通讯主机。

消防电话分机可安装于可能发生火灾的报警现场，主机则安装于集中控制室或值班室等地的控制柜上，可保证发生火灾的报警现场与集中控制室之间及时、准确地保持联系。

消防电话系统采用大屏幕点阵式液晶显示，具有时间、事件纪录功能，掉电不丢失，系统自带日历／时钟，掉电不丢失，检测线路短路、断路的功能。

可以采用自成一套控制器的方案，也可以通过４８５通讯的方式与ＦＳ５０５０进行联网。

ＡＦＮ－ＦＨ１８消防电话满足国家标准ＧＢ１６８０６－２００６《消防联动控制系统》的相关要求。

消防对讲电话型号中ＡＦＮ代表公司产品的标号，ＦＨ１８为公司产品代号。

二、技术参数１．主机编号：ＡＦＮ－ＦＨ１８２．检测型号：ＡＦＮ－ＦＨ１８３．结构型号：嵌入式４．环境温度：－１０℃～５０℃５．环境湿度：１０％～９５％（不结露）６．工作电源：ＡＣ２２０Ｖ　５０Ｈｚ７．备用电源：ＤＣ１２Ｖ￣７ＡＨ　铅酸蓄电池两节８．消耗功率：监视状态：１０Ｗ 满载状态：２０Ｗ９．外型尺寸：长：４８２．６ｍｍ　宽：１３２．５ｍｍ１０．通讯总线线路和语音总线：1.2km（线截面积≥1.5mm2），800m（线截面积≥1.0mm2）１１．中文白色背光液晶显示１２．ＲＳ４８５接口一个三、结构特征与工作原理１．消防对讲单元控制面板说明 如图３－１２．工作原理消防电话采用双总线进行通信和通话，通过对消防电话的操作，可以方便查询系统的各种信息，并能播放任意一段录音。

通过主机可以很方便的呼叫分机和电话插孔，并可以进行多方通话，同时电话分机和电话插孔也可以很方便的呼叫主机，由主机决定是否与正在呼叫的分机和插孔通话，只要双方开始正式通话，录音机将自动打开进行录音，录音时间长达３０分钟以上，同时系统还有线路的检测、保护功能。
