ZSimpWin使用教程
@柯倚
1. 复制数据
只复制前三列：
Freq（频率）、Z′（实部）Z″（虚部）
2. 导入数据
3. 修剪端部乱点
左上延伸的数据是可以手动删除的按住鼠标左键拖动对图形进行放大
选中要删除的数据
单击右键对单个点进行删除
4. 拟合电路
选否即可
选择合适的电路图进行拟合
5. 拟合结果
此列数据都小于10，说明拟合较好
5. 拟合结果-修正若有数据大于10，说明拟合较差①，手动再次拟合，模式改为手动输入②，确定后得到③，接下来对③中参数进行修改：将①中大于10的参数前面Fixed 选中，Start 值改为大于或小于原数的值，本例中将1E -5改为1E -6④,点击确定。
这时，所有数都小于10，说明拟合较好⑤，若还有数值大于10，继续调整Start 值，直至最佳①②③
④
⑤
6. 导出数据
导出的数据包含拟合前后的数据，后两列为拟合后数据，
导出为tx t格式，方便导入Origin作图。
