Features• Low Power Consumption• Industry Standard Size• Industry Standard Pinout• Choice of Character Size7.6 mm (0.30 in), 10 mm (0.40in), 10.9 mm (0.43 in), 14.2mm (0.56 in), 20 mm (0.80 in)• Choice of ColorsAlGaAs Red, High EfficiencyRed (HER), Yellow, Green• Excellent AppearanceEvenly Lighted Segments±50° Viewing Angle• Design FlexibilityCommon Anode or CommonCathodeSingle and Dual DigitLeft and Right Hand DecimalPoints±1. Overflow Character• Categorized for LuminousIntensityYellow and Green Categorizedfor ColorUse of Like Categories Yields aUniform Display• Excellent for Long DigitString MultiplexingDescriptionThese low current seven segmentdisplays are designed for applica-tions requiring low powerconsumption. They are tested andselected for their excellent lowcurrent characteristics to ensurethat the segments are matched atlow currents. Drive currents aslow as 1 mA per segment areavailable.Pin for pin equivalent displaysare also available in a standardcurrent or high light ambientdesign. The standard currentdisplays are available in all colorsand are ideal for most applica-tions. The high light ambientdisplays are ideal for sunlightambients or long string lengths.For additional information seethe 7.6 mm Micro Bright SevenSegment Displays, 10 mm SevenSegment Displays, 7.6 mm/10.9mm Seven Segment Displays,14.2 mm Seven SegmentDisplays, 20 mm Seven SegmentDisplays, or High Light AmbientSeven Segment Displays datasheets.Low Current Seven SegmentDisplaysTechnical DataHDSP-335X SeriesHDSP-555X SeriesHDSP-751X SeriesHDSP-A10X SeriesHDSP-A80X SeriesHDSP-A90X SeriesHDSP-E10X SeriesHDSP-F10X SeriesHDSP-G10X SeriesHDSP-H10X SeriesHDSP-K12X, K70X Series

HDSP-N10X Series元器件交易网www.cecb2b.com2

Package DimensionsDevicesAlGaAsHERYellowGreenPackageHDSP-HDSP-HDSP-HDSP-DescriptionDrawingA1017511A801A9017.6 mm Common Anode Right Hand DecimalAA1037513A803A9037.6 mm Common Cathode Right Hand DecimalBA1077517A807A9077.6 mm Common Anode ±1. OverflowCA1087518A808A9087.6 mm Common Cathode ±1. OverflowDF10110 mm Common Anode Right Hand DecimalEF10310 mm Common Cathode Right Hand DecimalFF10710 mm Common Anode ±1. OverflowGF10810 mm Common Cathode ±1. OverflowHG10110 mm Two Digit Common Anode Right Hand DecimalXG10310 mm Two Digit Common Cathode Right Hand DecimalYE100335010.9 mm Common Anode Left Hand DecimalIE101335110.9 mm Common Anode Right Hand DecimalJE103335310.9 mm Common Cathode Right Hand DecimalKE106335610.9 mm Universal ±1. Overflow[1]LH101555114.2 mm Common Anode Right Hand DecimalMH103555314.2 mm Common Cathode Right Hand DecimalNH107555714.2 mm Common Anode ±1. OverflowOH108555814.2 mm Common Cathode ±1. OverflowPK121K70114.2 mm Two Digit Common Anode Right Hand DecimalRK123K70314.2 mm Two Digit Common Cathode Right Hand DecimalSN10020 mm Common Anode Left Hand DecimalQN10120 mm Common Anode Right Hand DecimalTN10320 mm Common Cathode Right Hand DecimalUN10520 mm Common Cathode Left Hand DecimalVN10620 mm Universal ±1. Overflow[1]WNote:1. Universal pinout brings the anode and cathode of each segment’s LED out to separate pins. See internal diagrams L or W.元器件交易网www.cecb2b.com3Package Dimensions (cont.)元器件交易网www.cecb2b.com4Package Dimensions (cont.)

*The Side View of package indicates Country of Origin.元器件交易网www.cecb2b.com5Package Dimensions (cont.)元器件交易网www.cecb2b.com6Package Dimensions (cont.)元器件交易网www.cecb2b.com7

Package Dimensions (cont.)元器件交易网www.cecb2b.com8Internal Circuit Diagram元器件交易网www.cecb2b.com9

Internal Circuit Diagram (cont.)

Absolute Maximum RatingsAlGaAs Red

HERHDSP-A10X/E10X/HDSP-751X/YellowGreenH10X/K12X/N10X/335X/555X/HDSP-A80XHDSP-A90XDescriptionF10X, G10X SeriesK70X SeriesSeriesSeriesUnitsAverage Power per Segment or DP375264mWPeak Forward Current per 45mASegment or DPDC Forward Current per15[1]15[2]mASegment or DPOperating Temperature Range-20 to +100-40 to +100°CStorage Temperature Range -55 to +100°CReverse Voltage per Segment 3.0Vor DPLead Solder Temperature for 3Seconds (1.60 mm [0.063 in.] below 260°Cseating plane)Notes:1. Derate above 91°C at 0.53 mA/°C.2. Derate HER/Yellow above 80°C at 0.38 mA/°C and Green above 71°C at 0.31 mA/°C.元器件交易网www.cecb2b.com10

Electrical/Optical Characteristics at TA = 25°CDeviceSeriesHDSP-ParameterSymbolMin.Typ.Max.UnitsTest Conditions315600IF = 1 mAA10X3600IF = 5 mA330650IF = 1 mAF10X, G10X3900IF = 5 mA390650IF = 1 mAE10XLuminous Intensity/Segment[1,2]IVµcd(Digit Average)3900IF = 5 mA400700IF = 1 mAH10X, K12X4200IF = 5 mA270590IF = 1 mAN10X3500IF = 5 mA1.6IF = 1 mAForward Voltage/Segment or DPVF1.7VIF = 5 mA1.82.2IF = 20 mA PkAll DevicesPeak WavelengthλPEAK645nmDominant Wavelength[3]λd637nmReverse Voltage/Segment or DP[4]VR3.015VIR = 100 mATemperature Coefficient of∆VF/°C-2 mVmV/°CVF/Segment or DPA10X255F10X, G10X320E10X340Thermal Resistance LEDRθJ-PIN°C/W/SegH10X, K12XJunction-to-Pin400N10X430AlGaAs Red元器件交易网www.cecb2b.com
