大豪电控操作手册(V1.1)

第1章 概 述欢迎您使用太原大豪益达电控有限公司生产的电脑刺绣机控制系统。

请您仔细阅读本操作手册，以确保正确的操作使用电脑刺绣机。

此外，请将本操作手册妥善保存在安全地点，以便随时查阅。

1.1 安全警告和注意事项使用本产品时，为了减少火灾、触电或人员伤亡的危险，应始终遵守下列基本的安全预防措施。

使用注意事项危险本产品在工作过程中，千万不要打开机箱盖板。

机箱内某些部位带有致命的高电压，并控制危险的旋转机件，极易引发意外人身伤害。

禁止禁止电气设备存储、工作在潮湿、粉尘、腐蚀性气体、易燃易爆气体的场所，否则可能会造成触电或火灾。

禁止请不要存储、工作在振动强烈的地方，否则可能发生故障。

注意请严格遵守本产品所标识的各种要求和警示，以确保人员和财产的安全。

注意液晶屏属于易碎物品，为了保证屏的使用寿命以及显示性能，不要使用锋利坚硬的物体点击。

注意U 盘在使用中应注意插入的方向，当插入方向不对时切勿用力，否则可能导致USB 口、U 盘的损坏。

在磁盘驱动器灯亮时，不要插入或拔出磁盘。

注意本操作手册的更改将以增加附页的形式进行。

新增加附页的内容若与手册原内容矛盾，以附页的内容为准。

运输、搬运注意事项注意搬运、运输时，请不要手持电缆线，否则设备易损坏或发生故障，人员易受伤。

注意请严格遵守本产品所标识的各种要求和警示，以确保人员和财产的安全。

强制超载产品时可能导致倒塌。

请按外包装箱上的标签载荷。

安装注意事项注意勿堵塞该设备的排气口，也不要把外物塞入装置中。

否则可能发生火灾或触电。

注意务必遵守安装方向。

否则机器可能发生故障。

注意绝不要把该部件安装于易潮、易腐蚀或易燃气体和易燃物之处。

否则易发生火灾。

接线、配线注意事项禁止禁止对控制器的输入输出回路进行绝缘测试。

否则将直接造成电气设备损坏。

禁止严禁在控制箱的电源插座或接线端子上驳接超负荷的用电器具。

注意各种连接线缆（信号线或电源线）都要确认绝缘良好，外皮无损伤。

注意信号线和电源线须分开走线，不能从机箱同一孔走线，不能绑扎在一起。

版本：V1.1DahaoⅢ型断线检测系统用户手册北京兴大豪科技开发有限公司目录第一章概述 (3)1.1系统的组成 (3)1.2功能及特点 (4)第二章选型说明 (5)2.1 纯机头控制板HCO4O2 (5)2.2 挑线簧式机头信号板HT154 (6)2.3 斩光轮式机头信号板 (7)2.4 机头灯开关板 (12)第三章安装指南 (16)3.1 电控的安装 (16)3.1.1 纯断检机头控制板的安装 (16)第四章调试指南 (17)4.1 接线 (17)4.2 纯断检机头控制板供电的测量 (17)第五章在线升级和写地址操作说明 (18)5.1 HC0402在线升级操作说明 (18)5.2 316机型主控在线升级操作说明 (18)5.3 328机型主控在线升级操作说明 (21)5.4 写板地址步骤 (23)5.5 检查板地址步骤 (23)5.6 查询机头信息步骤 (24)第六章组合绣操作说明 (25)附录一系统框图和线缆图 (48)附录二外围信号板安装尺寸图 (58)附录三簧式断检接线示意图 (60)第一章概述我公司为了适应市场需求，开发了纯断检机头控制系统。

该断线检测系统功能强大，进一步满足了厂家、用户和绣花机发展的需要。

1.1系统的组成III型断线检测系统包括三部分：(1)纯断检机头控制板HC0402；(2)斩光轮式机头信号板：用于配有轮式断检的机型，安装在夹线器后。

功能类似于Ⅰ型断检和Ⅱ型断检中的轮式光耦检测板（如Ⅰ型断检中的EF103X和Ⅱ型断检中的EF193X），但不能混用。

如HL624（6针，光耦间距和安装尺寸与EF109X相同）、HL924（9针，光耦间距和安装尺寸与EF103X相同）和HL921（9针，新跃专用）；(3)挑线簧式机头信号板：用于配有簧式断检的机型，板上有簧式断检接口、机头红绿灯和机头开关，安装在夹线器后。

如HT154（尺寸和EF154X、EF120X 相同）；(4)机头灯开关扳：如果只使用轮式断检，则使用机头灯开关板。

开箱机电控部分调整操作说明
开箱机是一款比较专业化的包装机械，主要有电气操作部分等，主要功能就是操作我们的机器正常使用，之前小编介绍过开箱机有哪些部分组成的？今天麦格小编简单介绍一下电控部分的操作说明：
1）确定开箱机已送入电源和气源。

2）依序打开NFB、电源开关，及确定急停钮为非下压状态。

如图十所示：
图十
3）开机后屏幕显示如图十一所示：
图十一
4）主画面如图十二所示：
自动/手动：为手自动状态切换及显示，在手动状态下，按下启动键，则转换至手动画面。

连续开箱：在自动状态下按启动键，则连续执行开箱作业。

#箱/分钟：按数字按钮可设定3-16箱每分钟,按下箱/分钟可执行#箱/分钟作业
开一箱：值执行一次开箱作业。

计数：显示批次的及总和开箱数量，按RST可归零。

图十二
5）手动画面。

如图十三所示：
图十三
6）帮助画面。

如图十四所示：。

电控使用指南
《电控使用指南》
嘿，朋友们！今天来给大家讲讲电控咋用哈。

就说前几天我在家捣鼓那个新买的电控小玩意儿。

我呀，满心欢喜地打开包装，嘿，那一堆线和按钮就摆在我面前。

我当时就有点傻眼了，这咋整啊？不过咱可不能退缩不是。

我先研究了一下那个说明书，哎呀妈呀，密密麻麻的字，看了半天也没太懂。

然后我就开始瞎摆弄，按按这个按钮，转转那个旋钮。

突然，那个小屏幕亮了起来，还发出了“嘀嘀”的声音，给我吓一跳！我寻思这是咋回事啊，不会给弄坏了吧。

我就开始小心翼翼地试着各种操作，一会儿把这个调高，一会儿把那个调低，嘿，慢慢还真让我摸出点门道来了。

比如说那个温度控制的，我发现调高了就热乎，调低了就凉快点。

然后我又试着用它来控制家里的一个小电器，哇塞，真的能控制哎，我感觉自己像个魔法师一样，太有意思啦！
哎呀，这就是我使用电控的小经历啦，虽然一开始有点懵，但慢慢摸索就会发现其实也不难嘛。

所以大家遇到电控不要怕，大胆去尝试，说不定你也能发现很多好玩的地方呢！哈哈，这就是我给大家的电控使用指南啦，希望对你们有用哟！。

ContentsDescription Page 1.0 Setup ................................21.1 Before Installation .....................21.2 Installation ..........................21.2.1 DIN Rail Kits ......................21.3 Wiring ..............................21.3.1 Series Wiring Applications ...........31.3.2 Parallel Wiring Applications ..........31.3.3 Dry Contact Wiring .................31.3.4 Telephone Line Protection ...........31.4 Apply Power .........................3 1.5 Specifications ........................41.6 Warranty . (4)nstallation Instructions for EatonSurge Protective Device XXCFXXX30-RJ2Instruction Manual IM01005027E Rev. 4Effective October 2018Installation Instructions for EatonSurge Protective Device XXCFXXX30-RJEATON WARNINGHAZARDOUS VOLTAGES PRESENTIMPROPER INSTALLATION OR MISAPPLICATION OF THESE DEVICES MAY RESULT IN SERIOUS INJURY TO INSTALLER AND/OR DAMAGE TO ELECTRI-CAL SYSTEM OR RELATED EQUIPMENT. READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION. PROTECTIVE EYE-WEAR SHOULD BE WORN WHENEVER WORKING AROUND HAZARDOUS VOLTAGES.NOTICEALL INSTRUCTIONS AND MEASUREMENTS MUST BE COMPLETED BY A LICENSED/QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE U.S. NATIONAL ELECTRICAL CODE, STATE AND LOCAL CODES OR OTHER APPLI-CABLE COUNTRY CODES. THE U.S. NATIONAL ELECTRICAL CODE AND STATE AND LOCAL REQUIREMENTS (OR OTHER APPLICABLE COUNTRY CODES) SUPERSEDE THIS INSTRUCTION.Catalog NumberVoltage RangeModeVPRMCOVInSCCRPeak Surge CurrentXXCF12030-RJ 248 - 149 Vdc 1 100 -127 Vac L-N L-G N-G 5005005001501501505kA 10kA 80kAXXCF23030-RJ 2150 - 300 Vdc 1128 - 230 VacL-N, L-G, N-G8008008002752752753kA 10kA 80kA1 UL 1449 4rd Edition does not list SPD products rated less than 110 Vac or DC voltages.2UL 1449 4th Edition, UL 1283 7th Edition1.0 SetupVerify that system voltages do not exceed those listed in Section 1.5, Specifications. • All AC measurements should be completed with an RMS voltme-ter.• All DC measurements should be completed with a DC voltmeter.•DO NOT INSTALL FILTER IF MEASURED VOLTAGE EXCEEDSMAXIMUM OPERATING LIMITS.Choose location for filter installation so that maximum separation can be maintained between input leads, output leads and ground leads.1.1 Before InstallationREMOVE POWER FROM ELECTRICAL SYSTEM BEFORE MOUNTING FILTER.•Filter MUST be mounted within enclosure to assure personnel safety from exposed terminals.IMPORTANT:FILTER SHOULD BE LOCATED SO THAT THE SHORTEST POSSIBLE CONDUC-TOR LENGTH MAY BE USED.•Filter should be mounted to allow maximum separation between input and output wiring.•Filter contains no position-oriented components and can be mounted upside down or sideways.•Filter should be placed in electrical circuit so that it is the last device in the circuit before equipment to be protected.1.2 InstallationFILTER MUST BE CONNECTED TO ELECTRICAL SYSTEM WITH A CIRCUIT BREAKER:For AC Applications•1 – Single Pole / Single Throw 40A circuit breaker(s). The Interrupting Rating of the Circuit Breaker Shall Not Be LessThan the Available Fault Current. Circuit Breaker Ratings of 40A, 240V/415V, 10kA Min. AIC Rating.ote:N Pre-existing breaker(s) of the rated load size may be utilized if provi-sion for multi-conductor connections are made according to N.E.C. 110-14A.•If Neutral wire is to be utilized as L2/NEU then circuit breaker should be provided for that phase.For DC Applications•DC units to be installed after an overcurrent protective device that is rated not to exceed 100% of the current rating of the unit.•Form C contacts are rated at 0.5 Amps at 125 VAC or 1.0 Amps at 30 VDC. These connections are to be used for alarm hook up.T able 1. Relay state when energized.Catalog Part NumberNormally ClosedNormally OpenXXCFXXX30-RJ Open ClosedREMOVE POWER FROM ELECTRICAL SYSTEM BEFORE INSTALLING FILTER.Mechanically mount filter.•Mount filter using mounting flange holes or optional DIN bracket listed below.•Filter should be mounted to allow maximum separation between input and output wiring.•Filter contains no position oriented components and can be mount-ed upside down or sideways.•Filter should be placed in electrical circuit so that it is the last device in circuit before equipment to be protected.1.2.1 DIN Rail Kits Mounting bracket and foot adaptable to DIN Rail systems DIN EN 50022, DIN EN 50035 and DIN EN 50045 are available through Eaton Order Center and can be ordered separately.• Eaton Cat# DINRAILKIT-30ACF•Eaton Innovative Technology Cat# DINRAILKIT-30ITCF1.3 WiringNOTICEAN INSULATED GROUNDING CONDUCTOR THAT IS IDENTICAL IN SIZE AND INSULATION MATERIAL AND THICKNESS TO THE GROUNDED AND UNGROUNDED CIRCUIT SUPPLY CONDUCTORS, EXCEPT THAT IT IS GREEN WITH OR WITHOUT ONE OR MORE YELLOW STRIPES, IS TO BE INSTALLED AS PART OF THE CIRCUIT THAT SUPPLIES THE FILTER. SEE TABLE 250-122 OF THE NATIONAL ELECTRIC CODE (NEC) REGARDING THE APPROPRIATE SIZE OF THE GROUNDING CONDUCTOR.THE GROUNDING CONDUCTOR IS TO BE GROUNDED TO EARTH AT THE SERVICE EQUIPMENT OR OTHER ACCEPTABLE BUILDING EARTH GROUND SUCH AS THE BUILDING FRAME IN THE CASE OF HIGH-RISE STEEL FRAME STRUCTURE.ANY ATTACHMENT-PLUG RECEPTACLES IN THE VICINITY OF THE FILTER ARE TO BE GROUNDING TYPE, AND THE GROUNDING CONDUCTORS SERV-ING THESE RECEPTACLES ARE TO BE CONNECTED TO EARTH GROUND AT THE SERVICE EQUIPMENT OR OTHER ACCEPTABLE BUILDING EARTH GROUND SUCH AS THE BUILDING FRAME IN THE CASE OF HIGH-RISE STEEL FRAME STRUCTURE.PRESSURE TERMINAL OR PRESSURE SPLICING CONNECTORS AND SOL-DERING LUGS USED IN THE INSTALLATION OF THE FILTER SHALL BEIDENTIFIED AS BEING SUITABLE FOR THE MATERIAL OF THE CONDUCTORS. CONDUCTORS OF DISSIMILAR METALS SHALL NOT BE INTERMIXED IN A TERMINAL OR SPLICING CONNECTOR WHERE PHYSICAL CONTACT OCCURS BETWEEN DISSIMILAR CONDUCTORS UNLESS THE DEVICE IS IDENTIFIED FOR THE PURPOSE AND CONDITIONS OF USE.CONDUCTORS SHOULD BE TWISTED TOGETHER TO REDUCE IMPEDANCE FACTOR. EXCESSIVE WIRE LENGTH AND SHARP BENDS DEGRADE FILTER PERFORMANCE; THEREFORE, AVOID EXCESSIVE WIRE LENGTH AND SHARP BENDS.3Instruction Manual IM01005027E Rev. 4Effective October 2018Installation Instructions for EatonSurge Protective Device XXCFXXX30-RJEATON Table of Maximum Suggested Operating UnitsModel Number Power ProtectionData ProtectionLine to Neutral (MCOV)Line to Ground (MCOV)Neutral to Ground* (MCOV)Maximum All Modes (@60 Hz) Amps Pins Peak Voltage L-L, L-G Max. Continuous Operating Current (mA)Max. Data Rate (Mbps)XXCF12030-RJ 150150150401-4, 2-31341001XXCF23030-RJ27527527540*Note: If Neutral to Ground voltage is greater than 5 VAC then a problem may exist in electrical system. Filter may be installed; however, a qualified person should be consulted to correct problem.1.3.1 Series Wiring Applications•Connect incoming system GROUND wire to terminal labeledGND on unprotected end (labeled as LINE ).•Connect load side GROUND wire to terminal labeled GND on protected end (labeled as EQUIP ).For AC Applications•Connect incoming system NEUTRAL wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect load side NEUTRAL wire to terminal labeled as L2/NEU on protected end (labeled as EQUIP ).•Connect incoming system HOT wire to terminal labeled L1 on unprotected end (labeled as LINE ).•Connect load side HOT wire to terminal labeled as L1 on protected end (labeled as EQUIP ).For DC Applications•Connect incoming system NEGATIVE wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system POSITIVE wire to terminal labeled L1 on unprotected end (labeled as LINE ).1.3.2 Parallel Wiring ApplicationsIMPORTANT:FILTER SHOULD BE LOCATED SO THAT THE SHORTEST POSSIBLE CON-DUCTOR LENGTH MAY BE USED. CONDUCTORS SHOULD BE TWISTED TOGETHER TO REDUCE IMPEDANCE FACTOR. EXCESSIVE WIRE LENGTH AND SHARP BENDS DEGRADE FILTER PERFORMANCE; THEREFORE, AVOID EXCESSIVE WIRE LENGTH AND SHARP BENDS.•Connect incoming system GROUND wire to terminal labeled GND on unprotected end (labeled as LINE ).For AC Applications•Connect incoming system NEUTRAL wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system HOT wire to terminal labeled L1 on unprotected end (labeled as LINE ).For DC Applications•Connect incoming system NEGATIVE wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system POSITIVE wire to terminal labeled L1 on unprotected end (labeled as LINE ).ote:N For grounded or isolated control transformer secondary, DO NOT CONNECT Ground terminal on either LINE or EQUIP side.1.3.3 Dry Contact WiringConnect ALARM leads to Normally Open (N/O) or Normally Closed (N/C) terminals as required.1.3.4 Telephone Line ProtectionConnecting telephone line to protection.•Assemble RJ-14 modular plugs to LINE and EQUIP telephone cables.•Connect circuit as follows: Circuit 1 = Pins 2 and 3; Circuit 2 = Pins 1 and 4.• Insert modular plugs into LINE and EQUIP modular jacks.•Assure that telephone circuits are operational.ote:N For ungrounded or isolated control transformer secondary, DO NOT CONNECT Ground terminal on either LINE or EQUIP side.1.4 Apply PowerApply power to system. Indicator light(s) should glow and alarm contacts should move to normal state. If the light(s) does not glow, remove power and contact supplier.Instruction Manual IM01005027E Rev. 4 Effective October 2018Installation Instructions for Eaton Surge Protective Device XXCFXXX30-RJEatonElectrical Sector1000 Eaton Boulevard Cleveland, OH 44122United States877-ETN-CARE (877-386-2273) © 2018 EatonAll Rights ReservedPrinted in USAPublication No. IM01005027E / TBG000473 October 2018Eaton is a registered trademark.All other trademarks are property of their respective owners.Agency ApprovalsXXCFXXX30-RJ UL1449 4th Edition, UL1283 7th Edition Type 2 SPDTerminal Connections Wire clamping terminals, 10-18 AWG (UL), 10-22 AWG (CSA)Torque 12 in-lbOperating Temperature-40F(-40C) to +140F(+60C)System voltagesDC48 - 149 Vdc, 150 - 300 VdcAC100 - 127 Vac, 128 - 230 VacCircuit Breaker40A, 240V/415V, 10kA Min. AIC Rating(Eaton P/N:FAZ-C40/1-NA-SP)Amps*30Input Power Frequency50/60 HzWarranty 5 Years, 10 Years if registered on /spd RoHS Compliant Yes* Amp rating is for series connection only. Parallel connection is not current dependent.Purchaser’s right under the warranty shall consist solely of requiring Eaton to repair, or at Eaton’s sole discretion, replace, free of charge, F.O.B. factory, and defective items received at said factory or failure to give any advice or recommendations by Eaton shall not constitute any warranty by or impose any liability upon Eaton. The foregoing constitutes the sole and exclusive liability of Eaton AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESSED, IMPLIED OR STATUTORY AS TO THE MERCHANTABILITY, FITNESS FOR PURPOSE SOLD, DESCRIPTION, QUALITY, PRODUCTIVENESS OR ANY OTHER MATTER.In no event shall Eaton be liable for special or consequential dam-ages or for delay in performance of the warranty.This warranty does not apply if the prod1uct has been misused, abused, altered, tampered with, or used in applications other than specified on the nameplate. At the end of the warranty period, Eaton shall be under no further warranty obliga-tion expressed or implied.The product covered by this warranty certificate can only be repaired or replaced by the factory. For help on troubleshooting the Critical Protection Product, or for warranty information, call 1-800-809-2772, Option 4, sub-option 2. Repair or replacement units will be returned collect. If Eaton finds the return to be a manufacturer’s defect, the product will be returned prepaid.。

大豪系统触摸屏说明书看操作说明书就可以啊。

其实你想要大豪电脑绣花机操作说明书,你一方面可以找大豪电脑的售后技术人员索取,另一方面你也可以在大豪电脑绣花机的网站上查询和下载说明书。

先看看花样大小的位置,进行低速空走,就是不要下针,在空走时如果绣框越线机台停止了,就按空走相反的方向左或右移框键。

电脑绣花打版也称打带，是指打出卡、带或碟或通过数化等处理来准备花样，指导或激发绣花机和绣框作设计所需的各种运动的过程。

这个过程的设计者就是打版师。

这个术语来源于机械式的绣花机上通过在纸带上打孔来记录针迹而得。

不管是机械式的还是电子式的绣花机，记录针迹的目的都是为了让绣花机能识别并且执行其动作，可能用一个与水平和垂直棒相连的针，用机械方式或鼠标或更现代化的方式来记录那些形成花样所需要的点。

方法：打版的基本方法没有改变，我们还需要通过画一个6倍于原尺寸的图来打版。

当使用计算机后，图样都小于正常尺寸的6倍，但这样也不会出现不准确的情况。

将图放在数化板上，方向与图样在机器上绣的方向一致，排直。

当在上面工作时，不要让它发生移动。

在打版中最重要的就是研究放样、计划起始点、规划放样的路径、安排换色数和换色次序和跳针等。

开始花些时间做好上面的工作，它可以使你不返工，也不至于破坏作品。

另外还要计划好花样所需针的密度。

总之要将花样的总的概念一直记在脑海里。

放大的图样应该是草图精确的复制品。

打版师负责将该图转换成特定机器的机器语言。

在整个生产中打版师的技术是最重要的。

他要表现出设计师的思想，确保绣品的质量和外观。

一个最基本的要求就是要用适当的针数将草图作适当的放大，并且用适当的张力，正确地将织物铺展在机器上。

在这点上，打版师的作用就类似于一个钻石切割匠。

因为依靠他的技术，决定了最终作品的命运：是失败？或是永放异彩？设计中出现的每一个新问题都应该先解决。

打版师不断出现的新的念头一定是基于他的经验，随着各种问题的提出和解决，打版师就逐渐把它们应用在刺绣上或完善机器的功能上。

DH-NMS绣花管理系统界面功能说明北京大豪科技股份有限公司(版权所有，翻版必究)目录1需求描述 (3)2系统拓扑图 (4)3界面功能 (5)3.1登陆 (5)3.2服务器 (6)3.3机器管理 (6)3.3.1机器信息 (6)3.3.2历史事件 (8)3.3.3工作记录 (9)3.3.4工作统计 (11)3.4花样管理 (13)3.4.1花样信息 (13)3.4.2花样→机器 (16)3.4.3机器花样 (18)3.5现场管理 (19)3.5.1现场监控 (19)3.5.2现场指令单 (21)3.6绣工管理 (22)3.6.1绣工资料 (22)3.6.2工资计算 (23)3.7系统设置 (25)3.7.1登陆管理 (25)3.7.2权限管理 (26)3.7.3修改密码 (26)4产品优势 (27)4.1系统使用简单，价格存在优势 (27)4.2支持电脑，手机，PAD，随时随地访问 (27)4.3实时监控工厂信息 (27)4.4实时计算工资 (27)4.5减少机器闲置时间 (28)4.6大数据下的监视 (28)4.7大豪科技金牌服务 (28)5问题解答 (29)如何使用账号登陆 (29)如果电脑显示实时监控状态不更新了，怎么办 (29)如果程序很卡，或者死机了怎么办 (29)如果有其他情况，请重启电脑 (29)实时显示界面调整 (29)1需求描述随着绣花厂生产规模的扩大，绣花厂对绣花机的管理、对绣花厂人员绩效的管理、对生产物料的管理、对生产成本的精确计算、对订单生产进度的管理需求日益突出，希望有相应的系统来提高其机器的生产效率、有效减少机器闲置、对订单进度进行有效控制、对生产物料成本进行清晰的核算、对职工能方便监控和方便考核绩效、对订单受理进行风险预测。

那么网络管理系统就是需要来解决这些绣花厂实际面临的问题而开发的。

2系统拓扑图图中以无线路由器为分隔点，可以将其分为绣花厂内网部分和互联网部分。

内网部分本身是一个完备的系统，接入互联网并不是必须的，厂内的绣花机可以通过交换机和厂内的服务器相连，通过浏览器对绣花机进行管理。

大豪伺服参数调整简易说明参数调整前请参考阅读《大豪伺服高速机调试操作手册》，以便于熟悉操作。

大豪伺服框架主要针对各个针长进行控制，因此驱动器中对应有相关参数，详见卜表。

许则升级成最新的主控程序和驱动器程序一、确认XY通讯地址（需重新上电才能生效）大豪伺服框架采用通信方式进行指令控制，因此务必把XY轴对应的驱动器地址设对（X 向驱动器参数PA01设为0001, Y向驱动器参数PA01设为0002）。

如果设置错误将会造成通信报错或者绣作花样变形走位。

二、设定电子齿轮比PA02、PA03（需重新上电才能生效）电子齿轮比设置规律为：A、框架轴套采用0.45对应移框0.1mm的机器，则电子齿轮比的设置为电子齿轮比分子（PA02）二级传动减速装置大轮半径电子齿轮比分母（PA03）. 二级传动减速装置小轮半径B、框架轴套采用0.36对应移框0.1mm的机器，则电子齿轮比的设置为电子齿轮比分子（PA02）二级传动减速装置大轮半径------------- ---- 10 -------------------------电子齿轮比分母（PA03）二级传动减速装置小轮半径注：如果是采用三洋伺服参数设置的机器，则可以根据上述的AB两条折算。

或者用大豪伺服电子齿轮比二1.25 X三洋伺服电子齿轮比来计算。

另设置好伺服驱动器电子齿轮比后，可以通过手动移框一段距离来反馈是否正确。

手动移框一小段距离（比如5mm）后，将XY位移泊零，在台板上做标记，接着移框100mm,停止移框后在台板上做标记，用尺子测量这两个标记之间的距离是否也是100mm。

如果测量结果是100mm,那说明驱动器的电子齿轮比设置是对的。

具体步骤如下：① 设置成低速移框；按电脑操作面板上的键，屏幕上显示为哪除”:手动高速移框；：手动低速移框②向X方向移框一段距离（比如5mm后，按电脑操作面板上的键，将位移清零，屏幕上X [ +0.0 ]显示Y E 4S。

],在台板上做标记X [ + 100, 0 ]③接着按这个方向继续移动100mm,屏幕上，显示丫"Q】或者X [ -100.0 ]Y [ +0.0 ）④停止移框，在台板上做标记⑤测量两标记之间的距离⑥如果测量结果符合 100mm那么证明电子齿轮比设置是对的三、机械回差补偿PA18根据机械情况一般设为10~20之间，即0.1mm~0.2mmc 此参数针对绣作调头动作时进行补偿，低速机(750rpm)的设置值一般为10,而高速机(1000rpm)的设置值一般为20.四、手动移框参数根据高低速手动移框的效果(震动和声音)来设定，机器框架行程比较大的机器，可以将参数设置的大些。

目录目录第一部分功能特点 (1)第二部分显示、键盘及开关 (5)2.1显示、键盘 (5)2.2拉杆开关及慢动按钮 (7)第三部分系统状态 (10)3.1刺绣状态与非刺绣状态，停车态与开车态 (10)3.2正常绣作、回退及补绣 (11)3.3正常绣作与低速空走、高速空走 (12)3.4自动换色、自动启动与手动换色、手动启动 (13)第四部分显示查询 (14)4.1系统主画面 (14)4.2开车态画面 (17)4.3贴布绣、另外起点及循环绣作的显示 (17)4.4跳针、换色、到位及终止显示 (18)4.5显示停车原因 (19)4.6显示错误类型 (19)第五部分刺绣确认、换色顺序与直控操作 (21)5.1刺绣确认与解除刺绣 (21)5.2设置换色顺序 (21)5.3手动移框 (22)5.4手动换色 (22)5.5高速空走、低速空走设置 (22)目录5.6定位高速空走操作 (22)5.7手动/自动换色，手动/自动启动设置 (24)5.8升、降速 (24)5.9返回原点 (25)5.10回停绣点 (25)5.11点动操作 (25)第六部分工作方式 (27)6.1工作方式一——设置内存绣作花样号 (27)6.2工作方式二——磁盘花样读入 (28)6.3工作方式三——内存花样输出到磁盘 (30)第七部分辅助方式 (31)7.1辅助方式一——内存管理 (32)7.2辅助方式二——旋转缩放 (34)7.3辅助方式三——花样周边 (35)7.4辅助方式四——反复参数 (37)7.5辅助方式五——另外起点 (38)7.6辅助方式六——贴布绣作 (39)7.7辅助方式七——刺绣参数 (43)7.8辅助方式八——针迹补偿 (49)7.9辅助方式九——批量绣作 (51)7.10辅助方式十——磁盘格式化 (53)7.11辅助方式十一——出厂设置 (53)7.12辅助方式十二——绣框保护 (55)附录 (57)第一部分功能特点第一部分功能特点该电脑刺绣机综合国内外各家所长，集十几年开发制造之经验而精心设计生产。

During this period:Avoid full-throttle starts and rapid acceleration.We recommend gasolines containing detergent additives that help prevent fuel system and engine deposits.Avoid hard braking.New brakes need to be broken-in by moderate use for the first 200miles (300km).In Canada,some gasolines contain an octane-enhancing additive called MMT.If you use such gasolines,your emission control system performance may deteriorate and the Malfunction Indicator Lamp on your instrument panel may turn on.If this happens,contact yourauthorized Honda dealer for service.Help assure your car’s futurereliability and performance by paying extra attention to how you driveduring the first 600miles (1,000km).Using gasoline containing lead will damage your car’s emissions controls.This contributes to air pollution.You should follow these same re-commendations with an overhauled or exchanged engine,or when the brakes are relined.Do not change the oil until the recommended time or mileage interval shown in the maintenance schedule.Your Honda is designed to operate on unleaded gasoline with a pump octane number of 86or e of a lower octane gasoline can cause a persistent,heavy metallic rapping noise in the engine that can lead to mechanical damage.Break-in Period,GasolineBreak-in PeriodGasoline118Open the fuel fill door by pulling on the handle to the left of the driver’s seat.Remove the fuel fill cap slowly.You may hear a hissing sound as pressure inside the tank escapes.Stop filling the tank after the fuel nozzle automatically clicks off.Do not try to ‘‘top off’’the tank,leave some room for the fuel to expand with temperature changes.Your car has an on-board refueling vapor recovery system to help keep fuel vapors from going into the atmosphere.If the fuel nozzle keeps clicking off even though the tank is not full,there may be a problem with this system.Consult your dealer.Because the fuel fill cap is on the passenger’s side of the car,park with that side closest to the service station pumps.1.2. 3.4.CONTINUEDFilling the Fuel TankService Station Procedures119Screw the fuel fill cap back on,tighten it until it clicks several times.If you do not properly tighten the cap,the Malfunction Indicator Lamp may come on (see page ).Push the fuel fill door closed until it latches.Standing in front of the car,put your fingers under the front edge of the hood to the right of center.Slide your hand to the left until you feel the hood latch handle.Push this handle up until itreleases the hood.Lift the hood.2.5.6.231Service Station Procedures120If you can open the hood without lifting the hood latch handle,or the hood latch handle moves stiffly or does not spring back as before,the mechanism should be cleaned and lubricated (see page ).After closing the hood,make sure it is securely latched.184CONTINUEDService Station Procedures121Insert it all the way back in its tube.Remove the dipstick (orange handle).Check the engine oil level every time you fill the car with fuel.Wait a few minutes after turning the engine off before you check the oil. 3.1.Oil CheckService Station Procedures122Remove the dipstick again and check the level.It should be between the upper and lower marks.If it is near or below the lower mark,see on page .Refer to on page for information on checking other items in your Honda.4.165167Adding Oil Owner MaintenanceChecks Service Station Procedures123The condition of your car and your driving habits are the two mostimportant things that affect the fuel mileage you get.Always maintain your car according to the maintenance schedule.This will keep it in top operating condition.An important part of that mainte-nance is the (see page ).For example,an underinflated tire causes more ‘‘rolling resistance,’’which uses fuel.It also wears out faster,so check the tire pressure at least monthly.Engine oil also affects fuel economy.The fuel efficient,low-viscosity 0W-20oil recommended for your Insight is formulated to help the engine use less fuel.This oil is available at your Honda dealer.In winter,the build-up of snow on your car’s underside adds weight and rolling resistance.Frequent cleaning helps your fuel mileage and reduces the chance of corrosion.You can improve fuel economy by driving moderately.Rapid acceler-ation,abrupt cornering,and hard braking use more fuel.To get the best fuel mileage,drive in the highest gear that is practical for the speed you are driving,and always accelerate slowly.You may find that your Insight’sunique combination of an engine and an electric motor has drivingcharacteristics that are somewhat different from what you are used to.Shift Up and Shift Down indicators (5-speed manual transmission only)on the instrument panel show when to shift to a higher or lower gear.By shifting as soon as the indicator comes on,you will keep the engine operating in its most economical range.Wind resistance causes vehicles to use more fuel at higher speeds.Driving at moderate speeds on the highway reduces wind resistance and conserves fuel.Depending on traffic conditions,try to maintain a constant speed.Every time you slow down and speed up,your car uses extra fuel.165Fuel EconomyVehicle ConditionOwner Maintenance Checks Driving Habits124A cold engine uses more fuel than a warm engine.It is not necessary to ‘‘warm-up’’a cold engine by letting it idle for a long time.You can drive away in about a minute,no matter how cold it is outside.The engine will warm up faster,and you getbetter fuel economy.To cut down on the number of ‘‘cold starts,’’try to combine several short trips into one.The air conditioning puts an extra load on the engine which makes it use more fuel.Turn off the A/C to cut down on air conditioning e the flow-through ventilation when the outside air temperature is moderate.If air conditioning is needed,you can save some fuel by using the A/C in ‘‘ECON’’mode.When the outside temperature is above 41°F (5°C),this mode allows the Auto Idle Stop function to shut off the engine when the vehicle is stopped,resulting in fuel savings.You may notice that using the A/C causes a greater drop in fuel economy than you are used to in other vehicles.Although the amount of extra fuel used by the A/C load on the engine is no greater than other vehicles,it is more noticeablebecause of your Insight’s excellent fuel ing the A/C in hot weather may result in fuel economy that is lower than expected.Fuel Economy125。
