ACCESSORIES:HD & SD ENG/EFP PROFESSIONAL REAR CONTROL KITSA. B. C.D. E.F .G.H.I.*Specify camera type.*FMM-8 for use with S16x7.3 A.CFC-990Flex Cable B.FMM-6B/FMM-8*Focus Manual Module C.ZMM-6Zoom Manual Module D.SRD-92B Zoom Demand E.FSM-30B Focus Servo Module F .MCA-7Mounting Clamp G.FSD-11Focus Demand H.CZH-14Zoom Handle I.CFH-3Focus Handle ZMM-6FMM-6B CFC-12-990CFH-12-990CZH-14CFH-3MCA-78-PIN FocusManualModuleFMM-6B/FMM-8Flexible CableCFC-12-990Focus GripCFH-3Zoom Rate Demand Unit SRD-92B 3-PIN 8-PIN 6-PIN Focus Servo Module FSM-30B Focus ServoDemand UnitFSD-11Zoom Rate Demand Unit SRD-92BMM-01 Manual Focus/Manual Zoom Not available on S16x7.3MS-01 Manual Focus/Servo Zoom SS-01 Servo Focus/Servo Zoom Not available on S16x7.3Wide Attachment (WAT)Fish-Eye Attachment (F–AT)ACCESSORIES:HD & SD ENG/EFPPROFESSIONAL LENS CONVERTERS Converted M.O.D.Weight ModelType ø Size Converter Mag.Focal (m)(kg)Length (mm)A13x6.3TELE85 mm TCV-85C 1.6x 82.0→131.2 1.02 1.15RM/ERM WIDE85 mm WCV-85C 0.8x 6.3→5.00.26 1.09WIDE85 mm WAT-85C 0.7x 6.3→4.4–0.55A20x8.6TELE85 mm TCV-85C 1.6x 172.0→275.2 2.30 1.15RM/ERM WIDE85 mm WCV-85C/-L850.8x 8.6→6.90.58 1.09/.57WIDE85 mm WAT-85C 0.7x 8.6→6.0–0.55FISHEYE 85 mm F-AT85C Approx.0.55x ––0.62RATIO 82 mmRCV-82SC 0.82x 8.6→7.10.610.25S13x4.6TELE 85 mmTCV-85C 1.6x 60.0→96.0 1.02 1.03RM/ERM WIDE 85 mmWCV-85C 0.8x 4.6→3.70.26 1.09WIDE 85 mmWAT-85C 0.7x 4.6→3.2–0.55S17x6.6TELE 85 mmTCV-85C 1.6x 114→182.4 2.30 1.15RM WIDE 85 mmWCV-85C 0.8x 6.6→5.30.58 1.09WIDE 85 mmWAT-85C 0.7x 6.6→4.6–0.55FISHEYE 85 mm F-AT85C Approx.0.55x ––0.62S20x6.4TELE 85 mmTCV-85C 1.6x 128.0→204.8 2.30 1.15RM/ERM WIDE 85 mm WCV-85C/-L850.8x 6.4→5.10.58 1.09/.57WIDE 85 mm WAT-85C0.7x 6.4→4.5–0.55FISHEYE 85 mmF-AT85C Approx.0.55x ––0.62BROADCAST LENS CONVERTERSConverted M.O.D.Weight ModelTypeø Size Converter*Mag.Focal (m)(kg)Length (mm)A18x7.6TELE85 mm TCV-85C 1.6x 137.0→219.0 1.54 1.15ERM/ERD WIDE85 mm WCV-85C/-L850.8x 7.6→6.10.38 1.09/0.57WIDE85 mm WAT-85C 0.7x 7.6→5.3–0.55FISHEYE 85 mm F-AT85C Approx.0.55x ––0.62RATIO 82 mmRCV-82SC 0.82x 7.60→6.200.400.25A23x7.6TELE 100 mmTCV-10C 1.6x 175.0→280.0 2.05 1.06ERM/ERD WIDE 100 mmWCV-100D 0.8x 7.60→6.100.51 1.09WIDE 100 mm WAT-100C0.7x 7.60→5.300.390.00FISHEYE 100 mmF-ATH100C 0.55x 7.60→4.200.240.55*TCV/WCV are zoom thru type **ø 95mm P-1 screw on typeWide attachement and fisheye attachment can be used at WIDE END.Number of M.O.D.is at wide end.A20x8.6B / S20x6.4B RM/ERM*LENSA20x8.6B RM/ERM*S20x6.4B RM/ERM*Zoom Ratio / Format20X / 2/3"20X / 1/2"Focal Length8.6 to 172 mm 6.4 to 128 mm (2X) 17.2 to 344 mm (2X) 12.8 to 256 mm Maximum RelativeF1.8 (to 115 mm)F1.4 (to 90 mm)ApertureF2.7 (at 172 mm)F2.0 (at 128 mm)Angular Field8.6mm 54°11’x 41°59’ 6.4mm 53°08’x 41°07’of View172mm 2°56’x 2°12’128mm 2°52’x 2°09’(Hor.x Vert.in °)(2X) 17.2mm 28°42’x 21°43’(2X) 12.8mm 28°04’x 21°14’344mm 1°28’x 1°06’256mm 1°26’x 1°04’M.O.D.from Image Plane0.9 m 0.9 m Object Area (at Wide)8.6mm 866mm x 650mm 6.4mm 846mm x 635mm at M.O.D (at Tele)172mm 43mm x 33mm 128mm 42mm x 32mm (at Wide)(2X) 17.2mm 433mm x 325mm (2X) 12.8mm 423mm x 317mm (at Tele)344mm 21mm x 16mm 256mm 21mm x 16mm Filter Sizeø 82 mm P=0.75ø 82 mm P=0.75Weight RM1.4 kg 1.4 kg ERM1.5 kg 1.5 kg Features Inner Focus Inner Focus*ERM version with extenderExtender。
AG-HPX170 Memory Card Camera-RecorderLightest P2 HD Model Brings Even Greater M A Handheld Camcorder with 28mm Wide-Angle Lens, Superb Image Quality and The AG-HPX170 is the lightest member of the P2 Series of camcordersthat have revolutionized news gathering and video production. Thanksto an exclusive P2 card recording design, the AG-HPX170 weighs in atonly 4.2 pounds (1.9 kg), assuring exceptional mobility.The AG-HPX170 has a camera section that features a 28mmwide-angle zoom lens — widest in the class — plus a 1/3-inch 16:9progressive CCD that provides low-noise, low-smear performance.These high-end features combine with use of the DVCPRO HD codec,with its proven track record in broadcasting, to provide exceptional HDrecording quality.The AG-HPX170 offers a host of advanced features. Two P2 card slotsallow hot swapping for extended recording. Pre-rec and loop-recfunctions help ensure that you never miss an important shootingopportunity. There is also 20-step variable frame rate selection, HD-SDIoutput for uncompressed streaming output, and a waveform monitor/vector scope for outdoor recording convenience. With its superbrecording quality, impressive feature set and exceptional mobility,the AG-HPX170 is an agile, powerful solution to today’s broadcastingand image production needs.Compact, Lightweight and Perfectly Balanced• 28mm wide-angle zoom lens — widest in the class*• Progressive CCD with low noise and low smear• 20-step variable frame rate selection • Comes equipped for HD-SDI output• Waveform Monitoring, vector scope and histogram display*HD camcorders with integrated lens and 1/3-inch CCD, as of September 2009 (according to a Panasonic survey)At 4.2 pounds (1.9kg), the super-compact AG-HPX170 is the lightest member of the P2 family. It combines small size and light weightwith an ideal balance - the center of gravity is inthe hand grip – to bring exceptional comfort and maneuverability to handheld recording. The zoom lens further enhances shooting ease and convenience, letting the AG-HPX170 handle a wide range of applications without requiring a conversion lens.obility to Video production and News GatheringAdvanced FunctionsP2 Memory Card Recorder: Lower Operating Costs, Better for the EnvironmentP2 Reduces Total Cost of Ownership(1) Faster, easier editing because digitization is not necessary (2) Lower media costs because memory cards are reusable (3) Lower maintenance costs because there is no moving mechanismReducing editing, media and maintenance costs, P2 can help improve your bottom line. Users can also take advantage of a special five-year free-repair service program that Panasonic offers for P2 HD equipment.The P2 Card Helps Preserve the Environment:Repeated Reusability and Low Power ConsumptionAllowing repeated file copying andinitialization, a single P2 card can be used and re-used, again and again. Whencombined with an IT-based workflow that requires no dubbing, P2 cards can greatly reduce storage media expenses.ReuseInitializationRecordingP2 CardImage of an angle of view equivalent to 31.4 mm Image of an angle of view equivalent to 28 mmraises image quality. It combines aand better low-light performancethan previous models. Backed bya high-performance digital signalprocessor, the CCD brings higherquality to HD images to meet theHigh-Resolution Native Progressive 1080/60p Scan Wide, High-Quality Imageswith High Sensitivity fromAdvanced Optical System andHigh-Performance DSPAG-HPX170 Gamma ModesHD NORM: Suitable for HD recordingLOW:SD NORM: Normal setting for SDHIGH:B.PRESS:CINE-LIKE D:CINE-LIKE V:Advanced Image Adjustments Built-In• Matrix setting including a Cine-Like mode• Adjustable H detail level, V detail level, detail coring and skin detailpedestal• Knee point settings: Auto, Low, Mid and Highand shared with other cameras.Image with DRS OFF Image with DRS ONBlown highlights are suppressed.HD NORM Mode CINE-LIKE D ModeAdvanced P2HD Boosts Reliability andGets Your Finger to the Record Button FasterThe P2 cam records each recording as a clip (file) and automatically attaches a thumbnail image and file information to it. To preview a clip on the LCD monitor or to check clip data, simply choose the clip you want from the list of thumbnails. It also supports metadata input using a software keyboard.Hot-Swap Recording and Other Versatile Functions•Hot-swap recording: Thanks to the two card slots, you can hot-swap P2 cards for continuous non-stop recording. With multiple cards you can record for hours without interruption.•Pre-rec: While in standby mode, you can continuously store, and subsequently record, up to 3 seconds in HD (7 seconds in SD). This will help to get your shot every time.•Last clip delete: Only the most recently recorded clip is deleted with this one-touch function, adding practical convenience to everyday operation. It can be assigned as a User button function if desired.•Rec check: You can check the end of the most recently recorded clip with one-touch ease.Shot Marker and Text MemoA shot mark, which allows convenient OK and NG marking, can be added to each clip during or after recording. When a P2 card with marked clips is inserted in a PC,* it’s possible to have only the marked clips displayed. The AG-HPX170 also has a text memo function. When recording or previewing a clip, press the Text Memo button at any of up to 100 locations and a blank text memo label is registered.*This function requires P2 viewer or P2CMS software for Windows PC or Mac computers, which P2 users can download for free. Visit https://eww.pavc.panasonic.co.jp/pro-av/ and click “P2 Support and Download.”for consecutive overwriting, you can repeatedly re-record during a particular recurring time slot, always maintaining a recording of the most recent period. Unlike video tape, P2 cards need no rewinding. They minimize wasted time and allow seamless, continuous recording. This makes them especially useful for unattended monitoring.•One-shot rec: Convenient for producing animation, this mode records for a set time (from 1 frame to 1 second) each time you press the Start button.•Interval rec:Recording one frame at a time at set intervals (from2 frames to 10 min), this mode is useful for monitoring and special ultra-undercranking effects.•Time stamp: The date and time can be stamped onto recorded images. Commonly used for evidential images.4-Channel Uncompressed PCM AudioYou can record 4 channels of uncompressed, high-quality, 16-bit digital audio. In addition to the built-in stereo microphone, the AG-HPX170 is equipped with two XLR audio input terminals with 48-V phantom power for professional use. Both input 1 and input 2 can be switched between line and mic levels. A switch lets you select built-in mic, input 1, or input 2 for the audio input of both channel-1 and channel-2. Large dials make it easy to manually adjust the levels.SMPTE Time-Code Generator/ReaderThe built-in SMPTE time-code generator/reader lets you select the Drop Frame/Non-Drop Frame and Free Run/Rec Run modes, preset and regenerate, User bits are also provided.Time stamp•Higher-speed shooting (at over 25 fps*) produces slow-motion•Lower-speed shooting (at under 22 fps*) lets you attain a fast-720p Native ModeVariCam Style Expressionwith Expanded, 20-StepVariable Frame Rate Selection1080/480 24p Advance ModeThe 1080 and 480 progressive recording systems convertrecordings to 60i in 24p, 30p, or 24pA (Advance) mode. The 24p Advance mode uses 2:3:3:2 pulldown, which allows for an easy NLEs that are compatible.*This lets you maintain superior image quality throughout the production process.*For information on compatible nonlinear editing systems, visit<https://eww.pavc.panasonic.co.jp/pro-av/> and click "Nonlinear Compatibility Information." *24p = 23.98p, 30p = 29.97p, 60p = 59.94p and 60i = 59.94i16:9/4:3 Aspect Ratio ConversionThe 16:9/4:3 Conversion mode can be used with SD-recordedselect from three modes: side crop, letterbox, and squeeze.Slow, Synchro and High-Speed Shuttera blurring effect or crystal-clear stop motion sports action. The AG-HPX170 also features a synchro scan function that's suitable for capturing screen shots from a computer monitor.Framerate Effect of 24p standard Effect of 30p standard 12p 200% (Quick) 250% (Quick)15p 160% (Quick) 200% (Quick)18p 133% (Quick) 167% (Quick)20p 120% (Quick) 150% (Quick)21p 114% (Quick) 143% (Quick)22p 109% (Quick) 136% (Quick)24p 100% (Standard) 125% (Quick)25p 96% (Slow) 120% (Quick)26p 92% (Slow) 115% (Quick)27p 89% (Slow) 111% (Quick)28p 86% (Slow) 107% (Quick)30p80% (Slow)100% (Standard)32p 75% (Slow) 94% (Slow)34p 71% (Slow) 88% (Slow)36p 67% (Slow) 83% (Slow)40p 60% (Slow) 75% (Slow)44p 55% (Slow) 68% (Slow)48p 50% (Slow) 63% (Slow)54p 44% (Slow) 56% (Slow)60p40% (Slow)50%(Slow)Side cropLetter box SqueezeShown above is a sample of operation styles.the LCD monitor.Excellent Operation, Versatile Assist Functions, and System Functions forBroadcasting WorkWaveform Monitoring (WFM)VECTOR (Vector scope)Standard 13x optical zoom13x optical zoom x Focus BarFocus assist ON (BOTH Mode)Camera-1Camera-1Camera-3IEEE 1394The TC value of the camera-2 and 3 are matched to the camera-1Versatile Operating Styleworking inWindows PCor MacPortable HDDAG-HPX170USB 2.0 (DEVICE)USB 2.0 (HOST)P2 Viewer P2 CMSPortable HDDAG-HPG20P2 card (Recorded)P2 card (Blank)USB 2.0HD-SDIAG-HPX170AV-HS400ALive switcher HD-SDIHD-SDIHD-SDIHD-SDIAG-H 170AG-HPX500AJ-HD1400On-AirUSB 2.0Work station for archive (P2 CMS is Installed)AG-HPG20AJ-PCD35AJ-PCD20IEEE 1394bPCI ExpressNAS/SANRAIDBlu-ray Disk DriveLTONLE orHDD HDDAG-HPX170P2 card P2 cardP2 card1onto optical media.*2AG-MC200GXLR microphone•Sensitivity: •40 •3.5 dB (0 dB=1V/Pa,1KHz) •Maximum Input level: 127 dB(1000Hz, Distortion within 1%) •S/N:More than 69 dBCGA-D54Battery Pack (5,400mAh)AG-B25AC adapter kitOptional Accessories(As of September 2009)AJ-PCD20Memory Card Drive“P2 drive”(Interface: USB 2.0 / IEEE 1394b)AJ-PCS060GPortable Hard Disk Unit“P2 Store”AG-HPG10Memory Card Portable Recorder“P2 Gear”HD/SD LCD MonitorsBT-LH80WU7.9” HD/SD LCD monitorBT-LH900A8.4” HD/SD LCD monitorBT-LH171017” HD/SD LCD monitorBT-LH176017” 100Hz/120HzHD/SD LCD monitorBT-LH255025.5” HD/SD LCD monitorSD/SDHC memory cardNEWAJ-P2E064XGAJ-P2E032XGAJ-P2E016XGMemory Card (P2 card E series*)* P2 card E series may require to update thesoftware of P2 equipment. please go to the P2support page from the Panasonic web pagehttps://eww.pavc.panasonic.co.jp/pro-av/NEWNEWNEWAJ-P2C064AGAJ-P2C032AGAJ-P2C016AGMemory Card (P2 card A series)AJ-PCD35Memory Card Drive“P2 drive”*(Interface: PCI-Express)* Before using P2 card E series, you must install thelatest version of the software in the AJ-PCD35.For the latest version information, please go to theP2 support page from the Panasonic web pagehttps://eww.pavc.panasonic.co.jp/pro-av/AG-HPG20Memory Card Portable Recorder“P2 Portable”AVC-Intra supported. SDI Inputavailable.AG-HMR10Memory Card Portable Recorder“AVCCAM”AVCHD recording and HD-SDI input/output.DetailsGENERALPower Supply: DC7.2V (with Battery)DC7.9V (with AC adaptor)Power Consumption: 10.9W (when LCD monitor is not used.)11.7W (when LCD monitor is used.)13.8W(MAX)Operating Temperature: 32˚F to +104˚F (0˚C to +40˚C)Operating Humidity: 10% to 85% (No condensation)Weight: Approx. 4.19 lbs (1.9kg) Camcorder onlyApprox. 4.96 lbs (2.25kg) Incl. two P2 cards and supplied battery Dimensions (W x H x D): 6-1/8 inch x 7-1/8 inch x 15-11/16 inch (154 × 179.5 × 397 mm) CAMERAPick-up Device: 3CCD(1/3-inch interline transfer type, and progressive modes supported) Lens: LEICA DICOMAR lens with optical image stabilizer,motorized/manual mode switching, 13× zoom,F1.6 - 3.0 (f=3.9mm to 51mm / 35mm equivalent: 28mm to 368mm) Optical Color Separation: Prism systemND Filter: 1/4, 1/16, 1/64Gain Selection: 60i/60p mode: 0/+3/+6/+9/+12/+18 dB,30p/30pN/24p/24pA/24pN mode: 0/+3/+6/+9/+12 dB,when using slow shutter (1/12 or 1/15), 0dB fixed.when using under 23 fps flame rate, 0dB fixed.Shutter Speed: 60i/60p mode:(Preset) 1/60 (off), 1/100, 1/120, 1/250, 1/500, 1/1000,1/2000 sec.30p/30pNmode:1/30, 1/50 (off), 1/60, 1/120, 1/250, 1/500, 1/1000 sec.24p/24pA/24pNmode:1/24, 1/50 (off), 1/60, 1/120, 1/250, 1/500, 1/1000 sec. Shutter Speed: 60i/60p mode: 1/60.0 sec. to 1/249.8 sec.(Synchro Scan) 30p/30pN mode: 1/30.0 sec. to 1/249.8 sec.24p/24pA/24pN mode: 1/24.0 sec. to 1/249.8 sec.Shutter Angle: 10° to 360° by 0.5° steps“FILM CAM” mode in scene file operation typeSlow Shutter Speed: 60i/60p mode: 1/15, 1/30 sec.30p/30pN mode: 1/15 sec.24p/24pN mode: 1/12 sec. (in 720p mode only)Frame Rate: Variable 12/15/18/20/21/22/24/25/26/27/28/30/32/34/36/40/44/48/54/60 fps (20steps)Minimum Luminance: 3lux (F1.6, +12dB gain and 1/24 sec. of shutter speed)Lens Hood: Wide-field large typeFilter Diameter: 72 mmVideo P2 General (DVCPRO HD, 1080i / 720p)Sampling Frequency: Y: 74.25 MHz, P B/P R: 37.125 MHzQuantizing: 8bitsVideo Compression System: C ompression ratio 1/6.7, DCT + variable length codeVideo Recording Bit Rate: 100MbpsAudio P2 General (DVCPRO HD, 1080i / 720p)Sampling Frequency: 48 kHzQuantizing: 16 bits / 4chFrequency characteristics: 20 Hz to 20kHz Memory CardRecording Format: DVCPRO HD:1080/60i (30p over 60i, 24p over 60i, 24pA over 60i)720/59.94p (30p over 60p, 24p over 60p)720/30PN(Native)720/24PN(Native)DVCPRO50/DVCPRO/DV:480/60i (30p over 60i, 24p over 60i, 24pA over 60i)Audio Recording Format: PCM digital recording 48 kHz / 16 bits4ch (DVCPRO HD / DVCPRO 50),2ch/4ch selectable (DVCPRO/DV)Recording/Playback Time*: Approx.64 minutes(Using one 64GB P2 card, DVCPRO HD, recording in 1080/60i)Approx.32minutes(Using one 32GB P2 card, DVCPRO HD, recording in 1080/60i)Approx.16minutes(Using one 16GB P2 card, DVCPRO HD, recording in 1080/60i) VIDEO connectorsSDI Out: BNC x 1, 0.8Vp-p, 75HD: SMPTE292M/296M/299M StandardSD: SMPTE259M-C/272M-A/ITU-R.BT656-4 StandardAnalog Component Output: Component Video Terminal x 1,Y: 1.0Vp-p, 75Ω, P B/P R: 0.7Vp-p, 75ΩAnalog Composite Output: Pin jack x 1, 1.0Vp-p, 75ΩAudio ConnectorsXLR Input: XLR (3-pin) ×2 (Input 1/Input 2)Input High-Impedance Line: 0dBu,MIC: -50/-60dBu (selectable in menu GUI)Line Output: Pin-jack × 2 (ch1,ch2) 316mV, 600 ΩBuilt-in Microphone: Stereo microphonePhones: Stereo mini jack (3.5mm diameter)Built-in Speaker: 20mm round shape x 1Other ConnectorsIEEE 1394: 6-pin Digital x 1 (Input/Output), based on IEEE 1394 standardUSB: Type mini B connector (USB ver.2.0)Camera Remote: 2.5mm diameter super mini jack for zoom and rec start/stop3.5mm diameter mini jack for focus and irisMonitor, AC Adapter, and Other packagesLCD Monitor: 3.5 inches, LCD color monitor, 210,000 pixelsViewfinder: 0.44 inches, LCD color viewfinder, 235,000 pixelsAC Adapter: Weight: 0.37 lbs (160 g)Dimensions: 2-13/16 (W) inch x 1-1/8 (H) inch x 4-5/8 (D) inch(70 x 44.5 x 116 mm)Supplied Accessories: AC adapter/charger, AC cord, DC cord, Eye cup,5400mAh battery pack,Wireless remote controller with button-type battery,Microphone holder, Shoulder strap, Ferrite core,Component video cable, Pin-BNC conversion plug,P2 card software driver install CD-ROM*Time shown above is when you record a series of 1 shot to P2 card.Depending on numbers of shots you record, time will get shorter than the number shown above.SpecificationsSP-HPX170P215K909ZM-1 Printed in JapanFor US Customer: /broadcastFor Outside US: https://eww.pavc.panasonic.co.jp/pro-av/index.htmlPlease refer to the latest Non-linear Compatibilty Information, P2 Support and Downlord and Service Information, etc. at panasonic web site.Notes Regarding the Handling of P2 Files Using a PCMounting and Transferring FilesDownload."Preview and Nonlinear EditingFor software download or other information, visit https://eww.pavc.panasonic.co.jp/pro-av/ and click "P2 Support and Download" or "Nonlinear Compatibility Information." For the operating requirements of other editing software, visit the website of the relevant software manufacturer.Direct X are registered trademarks of Microsoft corporation.PANASONIC BROADCAST & TELEVISION SYSTEMS COMPANY UNIT OF PANASONIC CORPORATION OF NORTH AMERICA /broadcastPanasonic Corporation Systems Business Group2-15 Matsuba-cho, Kadoma, Osaka, 571-8503 Japan Tel. 81 6 6901 1161 Fax. 81-6-6908-5969https://eww.pavc.panasonic.co.jp/pro-av/Panasonic Marketing SALES TAIWAN Co.,Ltd579, Yuan Shan Road, Chung-Ho, Taipei Hsien, Taiwan Tel. 886-2-2227-6214 Fax. 886-2-2227-6297Panasonic Korea Ltd.Seohyun B/D, 1718-9, Seocho-Dong, Seocho-Gu,Seoul, KoreaTel. 82-2-2106-6641 FAX. 82-2-533-8766Broadcast and Communication Company of Asia, Inc.R-1902A Tektite Tower II Exchange Road Ortigas Center Posig City, PhilippinesTel. 63-2-633-6162 Fax. 63-2-631-1861Panasonic de Mexico, S.A. de C.V.Tel. 52-55-5488-1000 Fax. 52-55-5575-6763Panasonic Latin America S.A.( C aribe,Centro America, Venezuela, Colombia, Ecuador, Bolivia, Uruguay, Paraguay, Chile ) Tel. 507-229-2955 Fax. 507-229-2536Panasonic del Peru S.A.Tel. 51-1-614-0000 Fax. 51-1-452-9415Panasonic do Brasil LtdaTel. 55-11-3889-4035 Fax. 55-11-3889-4004Executive Office:One Panasonic Way, 4E-7, Secaucus, NJ 07094(201) 348-5300EASTERN ZONE: One Panasonic Way 4E-7, Secaucus, NJ 07094 (including Southeast) (201) 348-7196WESTERN ZONE: 3330 Cahuenga Blvd W., Los Angeles, CA 90068 (including Southwest) (323) 436-3608Government Sales: (201) 348-7587Panasonic Canada Inc.5770 Ambler Drive, Mississauga, Ontario L4W 2T3 (905) 624-5010www.panasonic.cae-mail:**********************Factories of Systems Business Group have received ISO14001:2004-the Environmental ManagementSystem certification. (Except for 3rd party's peripherals.)Free registration, no membership fees 5-year extended warranty repairsExclusive offer for P2HD !Maximum 5-year extended warranty repairs are applied for P2HD models after registration. Several other services are also provided to members.Latest news only for youIn the member’s web site, information is selected and presented for your models only. To be alerted to new firmware information and other releases, an email newsletter can be subscribed to.Document libraryYou can filter through and find various technical information (operation guides, technical descriptions, etc.) quickly from the library.Manage your equipmentYou can easily know the update status and past service history of each unit, and can leave comments in free text as memos about your equipment.Details and user registration: /sav/pass_e1st year 2nd year3rd year4th year5th yearBasic warranty*1Extended warranty repair*2Providing necessary information when you need itP2 Asset Support System The member’s service programP2 Asset Support System assists your P2HD use by providing extended warranty repairs & various technical information (update notices, operation guides, etc.) upon registration.* Not all models are eligible for extended warranty coverage.* Please note that this extended warranty is not available in some countries/region see website below for the details.*1: The basic warranty period may vary depending on the country/region see enclosed warranty card for warranty coverage.*2: Not all repair work is covered by this extended warranty see enclosed warranty card for warranty coverage. The maximum warranty period may be adjusted depending on the number of hours the device has been used.。
松下AG-HPX173MC 专业摄像机∙发货地：北京市海淀区∙想了解产品详情，请∙给我留言∙或∙查看联系方式收藏此信息∙详细信息∙批发说明∙运费说明∙联系方式AG-HPX173 新装上市，作为Panasonic P2 系列摄录机中格外轻盈的产品，带来了新闻采集与影像制作的新革命。
独家的P2 存储卡记录设计，使得新款摄录机的重量只有1.9kg，保证了其出色的机动性。
AG-HPX173 的摄像部分也引入了新的设计，配备了一只28mm 广角变焦镜头——同类中最宽广的镜头——以及一款新开发的1/3 英寸16：9 逐行CCD，提供低噪音低变形的画质表现。
这些高端特征加上DVCPRO 高清编解码器的使用，以及在广播级应用方面的优秀业绩，一定可以提供出色的高清录制质量。
AG-HPX173 提供了多个先进的功能。
两个P2 卡槽可以实现热插拔，适用于录制时间长的场合。
预录制及循环录制功能可以确保不会错过重要的拍摄机会。
另外，还配有20 级可变帧频选择，HD-SDI 输出，以输出未经压缩的数字信号在液晶显示器上配有示波器/ 矢量示波显示，以便于户外录制。
由于其出色的录制质量，令人难忘的特色，以及杰出的机动性，AG-HPX173 成为当今广播及影像制作需求的一个敏捷而有力的解决方案。
让影像制作与新闻采集更便捷外形紧凑、重量轻盈、体现完美平衡1.9kg 的重量，P2 家族中十分轻盈的产品,超级紧凑的AG-HPX173 新装上市。
体积小、理想的平衡点——重心位于把手的位置，为手持录制带来更多的舒适与灵活性。
而变焦镜头则增强了拍摄的便捷程度，使AG-HPX173 在不配备传统镜头的情况下，实现更宽广的应用。
生态益处——由于采用固态存储技术，广播也可以为环保做出贡献。
因为P2 卡可以重复使用，机械部件大幅减少，所以P2 高清是一项绿色技术。
使用无磨损、防跌落存储卡的录制系统后，便不再需要使用传统录像机的磁带。
存储卡的使用可以减少在磁头，磁带驱动装置等更换时产生的浪费。
不只更便携几年过去，由松下引领的技术变革已经扩展到整个行业，P2技术日渐普及，HVX200也已经成为一代经典机型，如今无论在纪录片制作中，还是奥运赛场之上，到处都有它的身影。
2008年9月，松下宣布推出全新的P2手持摄录一体机AG HPX173MC。
HVX200珠玉在前，HPX173MC到底有何种变化？国内首台样机在第一时间来到本刊编辑部，我们带你细看新机器的种种不同。
在了解技术变化的同时，也希望对你的选购有所帮助。
告别磁带更强大P2存储能力从表面上看来，HPX173MC最大的变化就是去掉了磁带录制单元，完全采用P2卡作为存储介质，如果说之前的双模式存储可以看作是过渡的话，如今磁带远去的路可以说更明显了，在大部分的节目制作领域中，磁带所代表的线性存储方式即将退出历史舞台。
一个好的信息是：在结束磁带服役的同时，松下推出了型号为AJ-P2C064的64GB存储卡，比目前32GB 提高了一倍，由于松下公司在P2存储技术上领先的突破，这块卡的价格并不会很高。
使用两块64GB的卡，可以拍摄128分钟1920×1080的全高清DVCPRO HD素材。
这是目前卡存储与1920×1080全高清结合的最长拍摄时间。
身形减小接口增加由于去掉了磁带存储单元，重量和体积都得以减小，相比HVX200的2.5公斤，HPX173MC重量减少约25%，仅为1.9公斤，当然这与新设计的镜头也有关系，我们后面再说它。
减少的机身体积和重量，让机身能有更多的空间容纳其他功能模块，在HPX173MC上，我们找到了6针火线接口和HD-SDI 接口。
HD-SDI接口大大扩展了这款机器的适用范围，很多现场转播类型的节目制作又多了一种选择。
成像核心：CCD与镜头HVX200发布一段时间之后，我们曾看到HVX203的推出，这其中的核心变化就在CCD的变化――HVX203的CCD拥有更好的低照度表现，更高的信噪比，以及更强的脱尾抑制能力。
Network camera exceeding the human eye featured by Super Dynamic III Key FeaturesStandard Accessories• CD-ROM*.......................................1 pc.• Installation Guide...........................1 pc.* The IP setup software, the viewer softwareand the network operating instructions(PDF) are included on the CD-ROM.The following are for installation.• Mount Bracket (w/safety wire)........ 1 pc.• Fixing Screw .................... 2 pcs. (incl. a spare screw)• Decorative Cover.......................... 1 pc.• DC 12 V Power Cord Plug............ 1 pc.• Code Label*.................................. 1 pc.* It will be needed for network management.A network administrator should keep this label.• Built-in MPEG-4 and JPEG digital signal output at VGA image size with up to 30 ips.• MPEG-4/JPEG dual stream output for simultaneous live monitoring and high resolution recording.• Progressive Output with motion adaptive interlace/progressive conversion allows every frame to be clear even when the object is moving.• Super Dynamic III technology delivers 128x wider dynamic range compared to conventional cameras.• High sensitivity: Color: 0.7 lux (Sens up OFF), B/W: 0.5 lux (Sens up OFF)• Simple Day-Night function (No IR cut filter moving)• Up to 32x automatic electronic sensitivity enhancement.• Video Motion Detector with 4 programmable detection areas and 3 sensitivity levels.• 22x zoom lens with 10x digital zoom enabling 220x zoom• Auto tracking: Pan and tilt automatically controlled to keep moving objects centered in screen.• PTZ control can be taken on the user friendly GUI with 16 speeds pan/tilt and new “Drag and Zoom” operation enabling finer control. 256 speeds available for system with WV-CU950 system controller. • Up to 64 preset positions• 360 map shot: 8 thumbnail images at 45 deg. intervals make it simple to direct the camera easily by clicking on a thumbnail.• Built-in network interface (10Base-T / 100Base-TX).• Power over Ethernet (PoE) IEEE 802.3af.• Multiscreen: Image from 16 cameras can be displayed in 4 different Quad screens or 16-screen (JPEG only)• FTP client function enables periodic image data transfer or transfer upon alarm • Alarm notification via E-mail.• Max. bit rate/client for MPEG-4 (64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbps) and Total bit rate control (64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbps / Unlimited) allowing flexible network management.• 2-way audio feature (G.726, 32 / 16 kbps)• Alarm log, Manual REC log, FTP error log saved in the SD card is displayed on the browser GUI and can be downloaded to the client PC. Playback or Image data download through the log is also available. • Multi-language GUI and setup menu: English, French, Italian, Spanish, German, Polish, Russian (PAL), English, French (NTSC), (Installation required except for English).• SD Memory card slot for Manual recording, Alarm recording and Backup upon network failure.• Alarm sources include Terminal 1 ~ 3, VMD and Panasonic alarm command. Selectable alarm actions include SD memory recording, FTP image transfer, E-mail notification, Alarm indication, Terminal output, Camera positioning, Auto track and Panasonic protocol output.• Scheduling function for Alarm / VMD / Access permission, Preset position call and Position refresh.• Industrial grade Pan/Tilt/Zoom mechanism for high reliability• One-touch Fitting Mechanism for easy installation• Desktop/Ceiling position choice and various optional brackets for versatile installationsSuper Dynamic IIIDome Network CameraWV-NS202A WV-NS202A (12V DC or PoE) (12V DC or PoE)Optional AccessoriesCeiling Mount BracketsWV-Q152C (Clear)WV-Q152S (Smoke)Inner Dome CoverWV-Q153Wall Mount BracketsWV-Q150C (Clear)WV-Q150S (Smoke)Direct Ceiling InstallationWV-Q105(Smoke Type)(Smoke Type)(Smoke Type)Embedded Ceiling Mount BracketsWV-Q151C (Clear)WV-Q151S(Smoke)Trademarks and registered trademarks– Microsoft, and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.– SD logo is a trademark. Important– Safety Precaution: carefully read the operating instructions and installation manual before using this product.– Panasonic can not be responsible for network performance and/or other manufacturer products that reside on the network.DISTRIBUTED BY:Panasonic is the brandname of Matsushita Electric.Printed in Japan(2A-003L)SpecificationsTV System NTSC PALCamera Image Sensor1/4-type interline transfer CCD, Effective pixeles: 768 (H) x 494 (V), Scanning Area: 3.59 (H) x 2.70 (V) mmScanning Mode 2:1 interlace scan (with motion adaptive interlace/progressive conversion)Minimum Illumination Color (30 IRE): 0.7 lux (Sen up: OFF), 0.02 lux (Sens up: 32x) at F1.6B/W (10 IRE): 0.5 lux (Sens up: OFF), 0.015 lux (Sens up: 32x) at F1.6White Balance AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K)Light Control Automatic integration of ALC/ELC AGC ON (LOW) / ON (MID) / ON (HIGH) / OFF Super Dynamic III ON or OFF (with BLC masking)Dynamic Range 52 dB typical (Super Dynamic III : ON, Shutter speed: OFF)Electronic Shutter OFF (1/60), AUTO, 1/100Electronic Sensitivity UP OFF / AUTO (2x, 4x, 6x, 10x, 16x, 32x)Digital Noise Reduction High / LowBlack and White Mode OFF / Auto (No IR moving)Video Motion Detector For preset position: 4 programable detection areas, Sensitivity: 6 stepsNon-preset position: Detects entire screen except clock area, Sensitivity: 6 stepsPrivacy Zone Up to 8 zones, Gray/Mosaic Up Side Down ON (desktop) / OFF (ceiling)Camera Title Up to 16 characters (alphanumeric characters, marks)Lens Type22x (3.79 mm ~ 83.4 mm) Zoom lens, 220x with 10x digital zoom. F: 1:1.6 (WIDE) ~ 3.0 (TELE)Angular Field of View H: 2.6° (TELE) ~ 51.7° (WIDE), V: 2.0° (TELE) ~ 39.9° (WIDE)Min. Object Distance 1.6 mPan and Panning Range 0° ~ 350°Tilt Panning SpeedManual: approx.1°/s ~ 100°/s, Up to 256 steps (depending on the controller) Preset: up to approx. 300°/sTilting Range –30° ~ 90° (upward-level-downward)Tilting angle limit: 0° / –5° / –10° / –15° / –20° / –25° / –30°Tilting SpeedMnual: approx. 1°/s ~ 100°/s, Up to 256 steps (depending on the controller) Preset: up to approx. 100°/sProportional Pan/Tilt Control Yes Number of Preset Positions 64Auto Mode OFF/ preset sequence / auto pan / auto track Image Hold ON / OFF PTZ Position Display ON / OFF Map Shot 360° map shot / preset map shotBrowser Camera Control Pan/Tilt (16 steps), Zoom, Focus, Click centering, Drag zoom, GUI Iris, Preset position call and program, Auto mode.Display ModeImage from 16 cameras can be displayed in 4 different Quad screens or 16-screen (JPEG only). 20 characters camera title available.SD Memory Data Download Images recorded in the SD memory card can be downloaded.Clock DisplayTime: 12H/24H, Date: 5 formats on the browser, Summer time (Manual)GU I /Setup English, French English, French, Italian, Spanish, German, Polish,Menu Language (Installation required for French)Russian (Installation required except for English.)System Log Alarm log, Manual REC log, FTP error log (SD memory required) Supported OS Microsoft Windows ® 2000 Professional SP4, Microsoft Windows ® XPProfessional/Home SP2 English, French, Italian, Spanish, GermanSupported Browser Internet Explorer 7.0 Internet Explorer 6.0 SP2 (Windows ® XP Home/Professional SP2)Internet Explorer 6.0 SP1 (Only Windows ® 2000 Professional SP4)Network Network IF 10Base-T / 100Base-TX, RJ45 connectorImage Resolution VGA (640 x 480) / QVGA (320 x 240)Image CompressionMPEG-4: Image quality: LOW/NORMAL/FINE, Transmission type: UNICAST/MULTICAST JPEG: Image quality: 10 steps, Transmission type: PULL/PUSH Image Refresh Rate0.1 / 0.2 / 0.33 / 0.5 / 1 / 2 / 3 / 5 / 6 / 10 / 15 / 30 ips (Max. rate will be 5 ips-VGA, (JPEG)10 ips-QVGA when transmitting JPEG and MPEG-4 simultaneously)Audio Compression G.726 (ADPCM) 32 kbps/16 kbps Audio Mode OFF / Mic input / Audio output / Interactive Total Bit Rate 64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbps / Unlimited Max. Bit Rate/Client (MPEG-4)64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbpsSupported ProtocolTCP/IP, UDP/IP, HTTP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, RTP FTP Client Alarm image transfer, Periodic image transfer No. of Simultaneous Users Up to 8 usersSD Memory Card (Option)Manual REC/Alarm REC/Backup upon network failure.Compatible SD card: Panasonic 64MB, 128MB, 256MB, 512MB, 1GB, 2GB model.SDHC standard card not supported.User Registration Up to 16 users User Level 3 Levels: Administrator, Camera control, Live onlySecurity MethodUser authentication (ID and Password), Host authentication (IP address)Alarm Alarm Source 3 x Terminal inputs, VMD, Command alarmAlarm ActionsSD memory recording, E-mail notification, Indication on browser, Camera positioning, FTP image transfer, Terminal output, Panasonic protocol output, Auto trackAlarm Log With SD memory card: 5,000 logs, Without SD memory card: 1,000 logs Schedule Alarm/VMD/Access permission, Preset position call, Position refreshInput/Monitor Output 1.0 V [p-p] / 75 Ω, 1.0 V [p-p] / 75 Ω,OutputNTSC composite, ø3.5 mm mini jack PAL composite, ø3.5 mm mini jack External I/O Terminals ALARM IN 1, ALARM IN 2/ALARM OUT, ALARM IN3/AUX OUT Microphone Input MIC IN (Applicable microphone; Plug-in power type)Supply voltage: 2.5 V ±0.5 V Input impedance: 3 K Ω ±10 %Audio OutputAUDIO OUT ø3.5 mm stereo mini jack (monaural output) Line level General Safety/EMC Standard UL 6500, C-UL (E60065),CE (EN55022 ClassB EN55024),FCC Part15 ClassA, ICES003 ClassA GOST (R 51558)Power Source/Consumption DC 12 V: approx. 1,000 mA, PoE: approx.12.0 W (IEEE802.3af compliant, Class 0 device)Ambient Operating –10 °C ~ +50 °C (14 °F ~ 122 °F), 90 % or less (without condensation)Temperature/HumidityDimensionsø115 mm x 154 mm (H) (ø4-17/32" x 6-1/16" (H)) (excluding the DC 12 V power cord plug)Weight Camera: approx. 850 g (1.87 lbs.)Accessories (Camera mounting bracket, decorative cover): approx. 200 g (0.44 lbs.)Major Operating Controls & Terminals• All TV pictures/menu are simulated.• Weights and dimensions are approximate.• Specifications are subject to change without notice.• These products may be subject to export control regulations. • Product pictures shown in this catalog are all NTSC models.。
警告：•请勿将本产品置于雨水、潮湿的环境中，以免发生火灾或触电。
•为防止造成伤害等事故，请务必按照安装说明将本产品牢固地固定在地面、墙壁或天花板上。
•安装应当遵照本产品所适用的所有安装规则。
•本产品没有电源开关。
如需切断电源，则关闭电源装置或拔下电源线。
•连接应当符合当地的电气规定。
注意：•标示有本产品机身编号等的标签贴附于本产品的表面。
请在下面空白处填上本产品的机身编号，并将此说明书妥善保存，以便万一遭窃时查核。
型号：SER.No.（机身编号）：2目录重要安全须知 (4)有限责任 (5)免责条款 (5)前言 (5)关于标记 (6)特点 (6)关于使用说明书 (7)对电脑的系统要求 (7)商标和注册商标 (8)关于著作权 (8)网络安全 (9)注意事项 (10)安装时的注意事项 (13)各部分的名称 (15)镜头安装 (17)插入和取出SD记忆卡*1 (仅WV-SP509H) (19)安装 (20)连接 (24)使用光盘 (28)配置网络设置 (31)故障排除 (33)规格 (34)附件 (38)选购件 (38)补充说明 (39)*1 SDXC/SDHC/SD记忆卡记载为SD记忆卡。
3不要损坏电源线不要损坏、加工电源线，不要使电源线靠近加热器，不要过分弯折、拧电源线，不要拉扯电源线，不要在电源线上放置很重的东西，不要绑扎电源线。
如果使用有损伤的电源线，可能会导致触电、短路或火灾。
如需修理，请委托经销商。
清洁时请切断电源否则可能导致受伤。
[使用时的注意事项]本产品仅限室内专用。
请勿在室外使用。
本产品没有电源开关切断电源时，需断开直流12 V电源或PoE设备的电源。
（同时使用直流12 V电源和PoE 设备作为电源时，两者均需断开。
）环境要求请勿长时间在高温、高湿的场所使用。
否则有可能会损坏本产品的部件从而缩短使用寿命。
请勿在靠近热源的地方（如加热器附近）使用本产品。
小心轻放本产品避免坠落、强烈冲击或振动，以免损坏产品而造成功能不良。
• 720p HD images up to 30 fps• Super high resolution at HD / 1,280 x 720 created by 2.4 Megapixel high sensitivity MOS image sensor• Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by “UniPhier ®”, Panasonic’s proprietary System LSI platform.• Full frame (Up to 30 fps) transmission at 1,280 x 960 image size • 45x HD extra optical zoom at 1,280 x 720 (30x optical zoom) 90x extra optical zoom at 640x360 resolution with 12x digital zoom enabling 1080x zoom.• Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared to conventional cameras.• Face Super Dynamic technology ensures clear face image.• High sensitivity with Day/Night (ICR*) function: 0.3 lx (Color), 0.04 lx (B/W) at F1.6 *ICR: IR Cut filter Removal• VIQS (Variable Image Quality on Specified area) technology allows the designated 2 areas to retain higher image quality while the excluded area will have a decreased image quality, which enables to use lower image file size and bit rate.VIQS can be set on preset position (1 to 8) and except preset.• Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions.• Progressive scan ensures clear images with less motion blur and no tearing even when the subject is moving.• Electronic sensitivity enhancement: Auto (Up to 16x) / OFF • Selectable light control modes:Outdoor scene / Indoor scene (50 Hz) / Indoor scene (60 Hz) / Fix shutter Indoor scene (50 Hz / 60 Hz): Flicker causedby fluorescent lightning will be automatically compensated.• 360 degrees endless Panning• Advanced auto tracking: The camera automatically pans and tilts to follow a moving subject and keep it in the center of the image.• PTZ control can be taken very smoothly on the user friendly GUI with 16 speeds pan/tilt and “Drag and Zoom” operation enabling finer control. 256 speeds available for system with WV-CU950 system controller.• Up to 256 preset positions• 360 map shot: 8 thumbnail images at 45 deg. intervals make it simple to direct the camera easily by clicking on a thumbnail.• Industrial grade Pan / Tilt / Zoom mechanism for high reliability• VMD (Video Motion Detection) with 4 programmable detection areas, 15 steps sensitivity level and 10 steps detection size• Privacy Zone can mask up to 32 private areas, such as house windows and entrances/exits.• Camera title display: Up to 20 alphanumeric characters on the browser• Alarm sources including 3 terminal input, VMD and Panasonic alarm command can trigger actions such as SDXC/SDHC/SD memory recording, FTP image transfer, E-mail notification, Indication on browser, Alarm terminal output, and Panasonic alarm protocol output.• Full duplex bi-directional audio allows interactive communication between camera site and monitoring site.• JPEG Image compression ratio can be changed by alarm so that higher quality image can be provided.• Prioritized stream control: One of the video streams can be prioritized when multiple recorders or client PCs are accessing the camera so that the recorder or the client PC can maintain the frame rate.• SDXC/SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure (H.264 / JPEG) • H.264 max. bit rate / client and Total bit rate control allows flexible network traffic management. Frame rate priority mode controls bit rate and compression ratio to provide the specified frame rate.• Internet mode: H.264 images can be transmitted over HTTP protocol.• Multi-language: English / Italian / French / German / Spanish / Portuguese / Russian / Chinese / Japanese • IPv4/IPv6 protocol supported• Supports SSL, DDNS (viewnetcam, RFC2136)• Still images (JPEG) can be viewed on mobile phones via Internet.• Onvif compliant model• IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard compliant.• Dehumidification device for use in various weather conditions • Rain wash coating dome cover• Ambient Operating Temperature : -50 °C to +55 °C ( -58 °F to 131 °F )• Fog compensation function equipped as standard.• AEM (Auto Eyelid Mechanism) offers images that are more natural and easy to watch reducing doubled images when direction of the lens moved above the horizontal.HD / 1,280 x 720 H.264 Weather Proof Camera featuring 45x HD extra optical zoom and Super DynamicKey FeaturesSuper Dynamic Weather Resistant HD PTZ Dome Network CameraWV-SW397A(Rain Wash Coating Model)Trademarks and registered trademarks– Microsoft, and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.– iPad, iPhone and iPod touch are registered trademarks of Apple Inc.– Android is a trademark of Google Inc.– UniPhier is a registered trademark of Panasonic Corporation.– "MEGA Super Dynamic", "i-PRO SmartHD" logos are trademarks or registered trademarks of Panasonic Corporation.– ONVIF and the ONVIF logo are trademarks of ONVIF Inc.Important– Safety Precaution: Carefully read the Important Information, Installation Guide and operating instructions before using this product.– Panasonic cannot be responsible for the performance of the network and/or other manufacturers' products used on the network.• Masses and dimensions are approximate. • Specifications are subject to change without notice.SpecificationsSDXC/SDHC/SDMemory Card (Option)Cellular Phone Compatibility Mobile Terminal Compatibility Alarm Source Alarm ActionsAlarm LogScheduleH.264 recording (Audio recording is enable): Manual REC / Alarm REC (Pre/Post) /Schedule REC / Backup upon network failure JPEG recording: Manual REC / Alarm REC (Pre/Post) / Backup upon network failureCompatible SD (SDHC/SDXC) card: Panasonic2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64GB** model *SDHC card, ** SDXC card (except miniSD card and microSD card) JPEG image, panning/ tilting/ zoom/ focus control, AUX control (by access level)iPad, iPhone, iPod touch (iOS 4.2.1 or later) Android mobile terminals3 terminals input, VMD, Command alarm, Audio detection SDXC/SDHC/SD memory recording, E-mail notification,Indication on browser, FTP image transfer, Panasonic protocol output With SDXC / SDHC / SD memory card: 5,000 logs, without SDXC / SDHC / SD memory card: 1,000 logsAlarm / VMD / Access permission / H.264 recording / Audio detection Monitor Output (for adjustment) Microphone/Line InputAudio OutputExternal I/O Terminals Safety/EMC StandardPower Source and Power Consumption Ambient Operating TemperatureAmbient Operating Humidity Shock ResistanceWater and Dust Resistance DimensionsMass (approx.) FinishVBS : 1.0V[p-p] / 75Ω,NTSC / PAL composite, BNC JackMIC IN and Line IN are selectable. ø3.5 mm stereo mini jack (monaural input) (Applicable microphone: Plug-in power type) Supply voltage: 2.5 V ±0.5 V Input impedance: approx. 2 kΩ ø3.5 mm stereo mini jack (monaural output) Line levelALARM IN 1 (DAY/NIGHT IN), ALARM IN 2 (ALARM OUT), ALARM IN 3 (AUX OUT) AC24 V : 3.5 A, 55 WPoE+ DC54 V: 470 mA, 25 W (IEEE802.3at compliant)POE Injector (60 W) DC54 V : 1.0 A, 50 WAC24 V and Tested PoE Injector (60 W) : –50 °C to +55 °C (-58 °F to 131 °F) * with limitations POE+ : –30°C to +55°C (–22 °F to 131 °F) Less than 90 % (no condensation)Compliant with IK10 (IEC62262)Main body : IP66 (IEC60529) compliantø229 mm x 392 mm(H) {ø9-1/32 inches x 15-7/16 inches(H)} diameter of the dome 160 mm(6-5/16 inches) Approx. 5.0 kg { 11.02 lbs}Main body : Aluminum die cast, Natural silver Sunshields : ASA resin coating, Natural silverDome section : Clear polycarbonate resin (Rain wash coating)<Safety>UL (UL60950-1), C-UL (CAN/CSA C22.2 No.60950-1), CE, IEC60950-1<EMC>FCC Part15 Class A, ICES-003 Class A, EN55022 Class B, EN55024*1 Converted value*2 For further information about PC system requirements and precautions for when using Microsoft ® Windows ® 8.1,Microsoft ® Windows ® 8, Microsoft ® Windows ® 7, Microsoft ® Windows Vista ®, or Windows Internet Explorer, click“Manual” - “Open” from the supplied CD-ROM and refer to “Notes on Windows ® / Internet Explorer ® versions”.*3 AAC (Advanced Audio Coding) is only used when recording audio on an SD memory card.*4 Transmission for 2 streams can be individually set.NetworkAlarmInput/OutputGeneralImage Sensor Effective Pixels Scanning Mode Scanning AreaMinimum IlluminationWhite BalanceLight Control ModeShutter SpeedSuper DynamicFace Super Dynamic Adaptive Black Stretch Fog compensation Gain (AGC)Electronic Sensitivity UP Day & Night (ICR)Digital Noise Reduction Video Motion Detection Privacy Zone Image Stabilizer VIQSDouble Image Reduction Camera Title (OSD) Focus distance Focal Length Zoom RatioDigital (Electrical) Zoom Angular Field of ViewMaximum Aperture Ratio Focusing Range Aperture RangePanning RangePanning SpeedTilting RangeTilting SpeedProportional Pan/Tilt Control Number of Preset Positions Auto Mode Image HoldPTZ Position Display Self Return Map Shot4.3 mm - 129.0 mm {3/16 inches - 5-3/32 inches} 30x / 45x with HD extra optical zoom (at 1280 x 720)12x (Max. 1080x combined with extra optical zoom at 640 x 360) H: 2.6° (TELE) - 64.6° (WIDE), V: 1.6° (TELE) - 38.2° (WIDE) ([16:9] mode)*H: 1.4° (TELE) - 44.4° (WIDE), V: 1.1° (TELE) - 33.8° (WIDE) ([4:3]mode)1 : 1.6 (WIDE) - 4.7 (TELE) 2.0 m - ∞ F1.6 - Close 360° endlessManual: approx. 0.065°/s to 120°/s, Up to 256 steps (depending on the controller)Preset : up to approx. 300°/s–15° to 195° (upward-level-downward)Auto Eyelid Mechanism (Double image reduction)Selectable tilting angle: 0° / –5°/ –10° / –15Manual: approx. 0.065°/s to 120°/s, Preset: up to approx. 300°/s Yes 256Auto track/ Auto pan/ Preset sequence/ 360 map-shot/ Patrol On / Off On / Off10 s / 20 s / 30 s / 1 min / 2 min / 3 min / 5 min / 10 min / 20 min / 30 min / 60 min 360° map shot / Preset map shotCamera ControlDisplay ModeCamera Title Clock Display Alarm Control One Shot Capture AudioSD Memory Data Download GUI/Setup Menu LanguageSystem Log Supported OS *2Supported BrowserImage Resolution H.264 *4JPEGImage Capture Mode:16:9H.264 : 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps JPEG (MJPEG): 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps 10Base-T / 100Base-TX, RJ45 connectorH.264 : 1,280 x 960 / 800 x 600 / 640 x 480 / 320 x 240, up to 30 fps JPEG (MJPEG): 1,280 x 960 / 800 x 600 / 640 x 480 / 320 x 240, up to 30 fps Network IF Audio Compression Audio ModeAuthentication for Audio Total Bit RateSupported ProtocolFTP ClientMaximum concurrent access numberPan/Tilt (256 steps), Zoom, Focus, Click centering, Drag zoom, Iris,Preset position call and program, Auto modeSpot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available.Up to 20 alphanumeric charactersTime: 12H/24H, Date: 5 formats on the browser, Summer time (Manual)ResetA still picture will be displayed on a newly opened window.Mic (Line) Input: On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High Still or motion Images recorded in the SDXC/SDHC/SD memory card can be downloaded. English / Italian / French / German / Spanish / Portuguese / Russian / Chinese / Japanese Up to 100 (Internal)Up to 4,000 (SDXC/SDHC/SD memory when the recording format is set to JPEG.) error logs Microsoft ® Windows ® 8.1,Microsoft ® Windows ® 8, Microsoft ® Windows ® 7, Microsoft ® Windows Vista ®, Microsoft ® Windows ® XP SP3Windows ® Internet Explorer ® 11 (32 bit), Windows ® Internet Explorer ® 10 (32 bit), Windows ® Internet Explorer ® 9 (32 bit), Windows ® Internet Explorer ® 8(32 bit),Windows ® Internet Explorer ® 7 (32 bi t)Approx.1/3 type MOS image sensor Approx. 2.4 mega pixels Progressive scan5.38 mm (H ) x 3.02 mm (V ) {7/32 inches(H) x 1/8 inches(V)}Color: 0.3 lx, BW: 0.04 lx (F1.6, Auto slow shutter: Off (1/30s), Gain: On(High))Color: 0.019 lx, BW: 0.003 lx (F1.6, Auto slow shutter: Max. 16/30s, Gain: On(High)) *1AWC (2,000 - 10,000 K), ATW1 (2,700 - 6,000 K), ATW2 (2,000 - 6,000 K)Outdoor scene: Automatic integration of ALC and ELCIndoor scene [50 Hz]: Automatic integration of ALC and ELC (up to 1/100 s)Indoor scene [60 Hz]: Automatic integration of ALC and ELC (up to 1/120 s)Fix shutterFix shutter: 1/30, 3/100, 3/120, 2/100, 2/120, 1/100, 1/120, 1/250,1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 (only at Super Dynamic Off) On / OffOn / Off (Only when Super Dynamic: On) On / Off (Only when Super Dynamic: Off) On / OffOn (Low, Mid, High) / OffOFF / AUTO (Max. 2x (2/30 s), 4x (4/30 s), 6x (6/30 s), 10x (10/30 s), 16x (16/30 s)) Mode: AUTO1 / AUTO2 / AUTO3 / On / Off, Level: High / Low, with external control High / Low4 areas, Sensitivity: 15 steps, Detection size: 10 steps Up to 8 zones / Up to 32 zones, Gray / Mosaic On / OffUp to 2 zones at preset position 1-8 and except preset On / OffUp to 20 characters (alphanumeric characters, marks) Limited / UnlimitedImage Capture Mode:4:3Transmission Mode Frame Rate Bit Rate/ClientImage Quality Refresh Interval Transmission Type Image Quality Refresh Interval Transmission TypeConstant bitrate / Frame rate priority / Best effort /Advanced VBR 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 6,144 / 8,192 kbps Low / Normal / Fine0.2 / 0.25 / 0.33 / 0.5 / 1 / 2 / 3 / 4 / 5 s Unicast / Multicast 10 steps0.1 fps to 30 fps Pull / PushG.726 (ADPCM) 32 kbps / 16 kbps, G.711 64 kbps, AAC *3Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) Level 1 only / Level 2 higher / All users64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, ICMP, ARPIPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP Alarm image transmission, FTP periodic transmission (When the FTP transmission is failed, backup on an optional SDXC/SDHC/SD memory card is available. ) Up to 14 users (Depends on network conditions)CameraLensPan and Tilt Browser GUINetworkDISTRIBUTED BY:/PanasonicNetworkCamera(2A-146AL)。
P2 存储卡式录制带来了视频制作的IT 革命✔✔✔✔✔✔保养成本可靠性传输速度P2 卡硬 盘光 盘DV磁带P2高清摄录机•以标清摄录机的价格支持着所有高清/标清录制格式•先进的P2 技术提供了快而稳定的表现，并且跨越到了IT 领域•2/3 英寸可更换镜头•出色的可变帧频功能Professional HD Quality 着眼于成熟高清视频制作的逐行3C C D和2/3英寸可更换镜头系统2/3 英寸可更换镜头系统2/3 英寸卡口型装配方式允许使用来自很多公司的种类繁多的广播级镜头及专业级镜头※。
2/3 英寸调焦镜头使得AG-HPX500 更容易捕获专业级视频中常常使用的浅景深。
逐行3CCDAG-HPX500的2/3 英寸逐行3CCD※拥有较大的感光区域（从而得到较高的敏感度），并且在画质、敏感度与成本这三者之间达到了最佳的平衡。
摄像机CCD 的扫描频率为每秒完全1080/50（或1080/60）逐行帧。
这是初始捕获格式；它是AG-HPX500摄像机所有生成格式的基础。
尽管摄像机并没有录制1080P/50（或1080P/60）素材，但信号最初还是1080/60格式；只不过后来才被交叉变换或下变换为需要使用的格式。
色差补偿(CAC)AG-HPX500 装备了色差补偿(CAC, Chromatic Aberration Compensation)功能。
与相符镜头结合使用，将允许自动补偿镜头生成的细微色差、最小化边缘模糊。
14 bit 数字电路AG-HPX500 的特点之一是一种具有14 bit 模/数转换能力和19 bit 内部处理能力的高性能数字信号处理器(DSP,Digital SignalProcessor)。
这种DSP提供了一些伽马设置，对1080逐行扫描生成之初始画面的R/G/B各个颜色信号分量进行了其他调整，并且同时处理了所有的高清/标清格式变换处理（P/I 变换、线路变换、下变换）。
所有视频格式均会得到出众的画面质量。
松下AG-DVC系列摄录一体机简明教程一、前言大家好，很高兴能有这么一个机会和在座的各位共同学习松下摄像机的使用方法。
考虑到各位对摄像机，尤其是专业摄像机接触不多，金源有线电视台〔某某宜城〕编写了此简明教程，帮助大家对摄像机的使用有一个根本的了解。
教程全文共分两个局部：第一局部的学习主要是对金源电视台目前使用的AG-DVC33、AG-DVC63、AG-DVC180BMS摄像机进展简要介绍。
学习点包括摄像机的根本工作原理、组成局部、主要功能按键的介绍、使用的须知事项、维护和保养。
第一局部是我写的，水平有限，不尽之处还望见谅。
第二局部的学习主要以摄影摄像技术根底知识的讲解为主。
这局部的教材网上很多，讲的也很细。
我们此次学习的这局部内容，也是来自于网络教材。
学习中我会结合教材对各个章节进展介绍讲解。
在正式开始以前，有两点是需要说明：1、虽然课后我会将此教材拷贝给各位，但学习的过程中还是希望能做好笔记，便于你拿到教材后，对一些学习过程中不是很明白的地方对照笔记有针对性的加强学习。
2、因为有些地方的讲解需要前面讲解的知识做铺垫，所以对于学习过程中不懂得地方，可以随时提问，防止影响后面的学习。
第一局部：摄像机简介一、摄像机的根本原理很多没有接触过摄像机的人可能会有疑问，摄像机是如何将图像拍摄下来的？如果中学物理课你还有印象的话，那么小孔成像的实验你应该记得。
这个实验验证的就是光线投射成像的原理。
对一些技术难点进展隐藏后，摄像机的工作原理说起来其实也很简单，摄像机其实是一个光、电、磁转换存储设备。
通过镜头的光学作用将光线聚焦于感光元件〔阴极摄像管、CCD〕上，由感光元件将光信号转变为对应的电信号，再通过电路使电信号进一步转换为磁信号记录于磁带上即完成了整个摄像过程。
以我们使用的松下数码摄像机为例，光线通过镜头组件，投射到感光元件CCD上，CCD将光信号转变为电信号后通过摄像机磁鼓，以高速旋转扫描的方式将磁信号记录于DV数码带上。
松下AG-HPX173MC 专业摄像机∙发货地：北京市海淀区∙想了解产品详情，请∙给我留言∙或∙查看联系方式收藏此信息∙详细信息∙批发说明∙运费说明∙联系方式AG-HPX173 新装上市，作为Panasonic P2 系列摄录机中格外轻盈的产品，带来了新闻采集与影像制作的新革命。
独家的P2 存储卡记录设计，使得新款摄录机的重量只有1.9kg，保证了其出色的机动性。
AG-HPX173 的摄像部分也引入了新的设计，配备了一只28mm 广角变焦镜头——同类中最宽广的镜头——以及一款新开发的1/3 英寸16：9 逐行CCD，提供低噪音低变形的画质表现。
这些高端特征加上DVCPRO 高清编解码器的使用，以及在广播级应用方面的优秀业绩，一定可以提供出色的高清录制质量。
AG-HPX173 提供了多个先进的功能。
两个P2 卡槽可以实现热插拔，适用于录制时间长的场合。
预录制及循环录制功能可以确保不会错过重要的拍摄机会。
另外，还配有20 级可变帧频选择，HD-SDI 输出，以输出未经压缩的数字信号在液晶显示器上配有示波器/ 矢量示波显示，以便于户外录制。
由于其出色的录制质量，令人难忘的特色，以及杰出的机动性，AG-HPX173 成为当今广播及影像制作需求的一个敏捷而有力的解决方案。
让影像制作与新闻采集更便捷外形紧凑、重量轻盈、体现完美平衡1.9kg 的重量，P2 家族中十分轻盈的产品,超级紧凑的AG-HPX173 新装上市。
体积小、理想的平衡点——重心位于把手的位置，为手持录制带来更多的舒适与灵活性。
而变焦镜头则增强了拍摄的便捷程度，使AG-HPX173 在不配备传统镜头的情况下，实现更宽广的应用。
生态益处——由于采用固态存储技术，广播也可以为环保做出贡献。
因为P2 卡可以重复使用，机械部件大幅减少，所以P2 高清是一项绿色技术。
使用无磨损、防跌落存储卡的录制系统后，便不再需要使用传统录像机的磁带。
存储卡的使用可以减少在磁头，磁带驱动装置等更换时产生的浪费。
可靠性高、成本低、速度快的P2P2卡是作为专业用的A/V 媒体而开发的高可靠性、大容量、小型、高速运行的半导体存储卡。
即使在激烈的温度变化及振动冲击等十分苛刻的环境下使用也能够确保可靠性。
它通过了30,000次的插拔测试，能够长期反复地使用。
将P2卡用于媒体的存储卡记录器采用了只有半导体存储器才能做到的无机械结构，实现了高速启动、高耐久性、低耗电，而且减少了维护的工作量，为降低成本和环保做出了卓越的贡献。
此外收录文件与IT(PC)直接连接，不需要进行数字变换，能够进行非线性编辑和网络传输，从而缩短了制作时间。
P2 HD 多格式观看配置有2个P2卡插槽和LCD 监视器，能够以单机形式迅速地观看已收录的P2素材。
该机具有的多格式&多编码功能，能够满足AG-HVX200/HPX500可收录的全部P2素材格式，可切换显示、重放DVCPRO HD 的各种高清格式、DVCPRO50/DVCPRO/DV 多编码的标清格式及50Hz/60Hz 影像。
※有关重放格式的详情请参阅下表。
※不能以无缝方式重放不同记录格式的多个片段。
标准配置有SDI/模拟输出标准配置有SDI(满足HD/SD 、嵌入4CH 音频)输出、分量/复合视频输出及音频(CH1/CH2)输出。
重放图像可通过大型监视器观看。
在广播电视业务中，可实现来自异地的微波传送等。
片段复制/片段编辑功能在P2录像机中,收录数据作为各个独立的片段（文件）被记录下来，从缩略图（图像一览）显示中做出选择后可进行重放、删除、元数据的确认、拍摄标记的追加/删除等操作。
P2Gear 配置操作在收录现场能够更方便使用的功能。
●片段复制：使用2个插槽能够在存储卡之间进行片段复制处理。
通过复制好片段能够有效地使用P2卡。
●缩略图变更：缺省设定值是片段的第一帧画面,使用此功能后可变更为片段内的任意的文本提示位置的影像,从而更容易判别。
●片段元数据的编辑：片段元数据中记载有摄影者姓名、采访记者姓名、摄影场所等信息，P2 Gear 除了能确认这些数据外，还能编辑文本数据。
