车辆工程外文翻译
- 格式:pdf
- 大小:729.27 KB
- 文档页数:8
车辆工程专业英文翻译原文:The controllable suspension system can improve both ride comfort and handling safety, which has become one research focus in the field of vehicle engineering since1950s.The full-car generally consists of four quarter-car suspension systems(QC)withstrong coupling characteristics,which yield strong coupling effects on vertical,pitch androll movement suspension performances.So far,an effective coordinated control methodfor the full-car with multiple sub-suspension systems has not been proposed.The best ideais to decouple the full-car into four independent QCs1,such that the sophisticated active orsemi-active control scheme for QC suspension can be directly employed,and thus simplifythe complicated controller synthesis for the full-car suspension and improve the real-timeproperty of control system,which has important theoretical and engineering values forrealizing the practical application of controllable suspension.This thesis focuses on the structural decoupling control study of half-car suspension,which has vertical and pitch movements.Firstly,the passive half-car dynamic model isestablished and transferred into the model involving two similar standard QC dynamicmodels.It is found that a coupling damping force exists in the sprung mass,and it can becompensated through adding a damping force in the unsprung mass, in which the half-carsuspension could be decoupled into two independent QCs.Furthermore,a new QCsuspension design with double controllable dampers is proposed on basis of the definedcoupling damping force,in which the traditional passive damper is normally replaced bythe sprung controllable dampe.Another damper named the unsprung controllable damperis installed between the lower control arm and linkage of vehicle controlled by the pitchangular acceleration,which plays role in compensating the yielded coupling damping force.Thus the suspension structural decoupling of half-car can be conveniently achieved and effectiveness of the proposed structural decoupling method of half-car suspension is verified.Finally,three kinds of control manners i.e.,active versus active,semi-activeversus active and semi-active versus semi-active,are fully discussed for the sprung and unsprung controllable dampers,respectively.The proposed active and semi-active slidingmode control schemes for the sprung controllable damper in QC are applied for thedecouplinghalf-car suspension robust control due to the uncertainty of vehicle load,andhe semi-active control manner chooses the semi-active controllable magneto-rheologicaldamper.As a result, the proposed both active versus active and semi-active versus active control manners could achieve the ideal multi-objective suspension performances for thehalf-car,and the proposed structural decoupling control method can be further extended to realize coordinated control of full-vehicle suspension system with multiple sub-suspension.Engineering vehicles working condition is usually relatively poor,coupled with thelimitations of the performance of the vehicle suspension system.It makes these vehicles' driveralways in the vibration of the high strength,and influences the driver's work efficiency,seriously hurts to the driver's spine,and directly leads to the disease.In order to reducevibration to the driver,this thesis usually takes the seat suspension system to isolate vibration,and uses the appropriate control strategies for seat suspension.It can effectively attenuate thevibration caused by uneven ground,reduce the vibration energy passed on to the driver's body,and improve the drivers'ride comfort.Magneto-rheological fluid is a kind of intelligent material,which has good rheologicalproperties.It can be the first choice of the semi-active suspension shock absorber material.According to the characteristics of magneto-rheological fluid,it can be made a lot of productswhich are used in mechanical engineering,civil engineering,etc.The most prominent exampleis magneto-rheological damper for vibration control in cable suspension bridge vibration,high-rise isolation,etc.In addition,the magnetic fluid rheostat vibration application of suspensionsystem is an important domain,including vehicle suspension system and vehicle seatsuspension system.In the suspension of the magneto-rheological damper applications,it ismainly for dissipation produced by the road excitation of vehicle and driver's vibration energy,to improve the ride comfort.Due to its good controllability,wide dynamic range,fast response,low power requirement and comparatively simple structure,magnetorheological(MR)dampers has become one of the focus research projects in automotive semi-active suspension.Besides damping force and dynamic range,the dynamic response is another important parameter of MR dampers,which isa key part of automotive MR semi-active suspension system.The dynamic response is valuable because it is one of the critical factors that determine the practical effectiveness of automotive MR dampers,the applications range of MR dampers and the controlling period directly.In this thesis,the dynamic response of automotive MR dampers is investigated and the effects of various conditions are considered.The main contributions include the following:(1)The properties and applications of MR fluid is reviewed firstly,the importance of the study on MR dampers dynamic response is discussed,and the present situation and existing problems of the study are summarized.Based on the present problems of the study,the main work is put forward.(2)Based on the hydrodynamics theory and working modes of MR dampers,applying the constitutive equations of Newton and Bingham fluid respectively,the parallel plates and annular duct based rheological equations are derived,the calculation approach of damping force is gained,and the theoretical relation between applied current,piston velocity and damping force is determined,which establishes he theoretical basis for the research of MR dampers dynamic response,propose of test approach and design of test system.Based on theoretical analysis of damping force,the calculation model of MR dampers dynamic response is built by analyzing the unstable state of MR fluid between parallel plates.Furthermore, driving by current source,the effect of the connecting way(parallel or serial)of electromagnetic coils is analyzed theoretically.(3)According to the damping force function and practical condition of dampers,an experimental approach for finding the dynamic response of automotive MR dampers and corresponding data processing are offered,the corresponding test system is developed, including some important parts of the test system,such as current driver based on PWM method,and its output characteristic and dynamic response are investigated theoretically and experimentally.译文:可控悬架系统能够同时提高车辆驾乘舒适度与操控安全性,因而具有出色的综合悬架性能,从上世纪五十年代起,就是国际车辆工程领域的研究热点课题之一。
外文翻译英文:Daily car maintenance. Auto maintenance aspects should be paid attention to:(1) prevent the mixture too thick due to the high temperature, gas to flow, but also because of quantity pore expansion, gas flow rate increase, and gasoline easy to evaporation, lead to the mixture too thick. Therefore, should be the small hole, speed up adjustment device and throttle rocker connection position, reduced float chamber oil surface height, to reduce the flow of.(2) prevent air resistance the burning hot summer, the gasoline engine fuel system due to temperature happen "gas resistance" phenomenon, fuel supply shortage or even interrupted the oil supply. To prevent "gas resistance", usable asbestos gasket will gasoline pumps and exhaust pipe is separated, or with wet cloth will cover the gasoline pump cooling.(3) the evaporation under high temperature, oil and water evaporation will increase, the flap raises to cover tightly, oil pipe to prevent oil leakage; Always check the water level of water tank, the crankcase oil oil face, height, brake zongbeng inside the brake fluid liquid surface height and within the battery electrolyte density and liquid surface height, etc. Illegal, want to add and adjust in time.(4) prevent overheating to prevent engine overheating, maintenance, attention shall be paid to fan belt can't with oil, in case the sliding, the degree appropriate belt. Driving timely rest, when resting, try to choose the shade, and open the hood ventilation cooling. When the tyre pressure because of the heat and increase when, should stop cooling, not use put gas and the method of threw cold water to reduce the tyre pressure and temperature.(5) the "combustion", "explosive" summer air temperature is higher, daily maximum temperature above 35 ℃in often, this makes the car itself also greatly improve the failure rate. When the high temperature heat slowly, auto water tank temperature often because do not fall high in and the influence of engine power, and may even cause mixed "combustion", "explosive", make the engine can't work normally. High temperature also makes some parts inflation deformation, light person can accelerate part wear, the person that weigh will blow out the parts. Summer road surface temperature at 70 ℃more often. Car tires for heated, the tyres increased pressure in, once the long distance running, easy blowout. When the car, a momentarybreaks down, it can also cause traffic accident.(6) the bad lubrication oil easily heated goes lean, oxidation resistance becomes poor, easy metamorphism, even cause the tile burning failure holding shaft. Therefore, should the crankcase and gear box with the oil changed into summer, often check the number of oil, lubricating oil, and in time to change.(7) the car paint the car paint him as insolate of skin, to bright and clean and bright beautiful, just cute. Although it seems to have no life, but it is also afraid of sun, long-term exposure willFaJiu, corrugate.The summer will often clean the car, in order to prevent the rain to car lacquer cause acid corrosion, also had better not on the street and wash your car, the repeated use of water sediment will scratch the car paint secretly. Next summer and the car that do more decontamination processing, summer bus is easy to splash on the viscosity substances, air temperature is exorbitant, will also be full of asphalt splash body. In that case, to do as soon as possible beauty treatment, using special detergents remove dirt, serious, want to undertake polishing processing. Some dirt if not handled in a timely manner, with all kinds of methods to remove not to drop, can only local polishing paint, paint again.The summer will pay more attention to the engine work environment, made timely cleaning work, if the engine external pollution too thick, it will affect the machine heat dissipation, give all sorts of machine fault buried hidden trouble. Summer should also be to paint on certain preventive protection, such as wax, glazing. Auto accessories part of the nursing in the summer also more important, such as the wheel hub, electroplating parts to timely derusting, clean, bumper, tires and other rubber and plastic parts to do add black glazing, anti-aging treatment.Common beauty protection- -wash the car wax, although some effect, but not for good. Because any waxes contain silicon ingredients, and ultraviolet ray will rust the car paint, leaving little black patches. And the car wax grinding particles, will be in the light of the car paint leave way way fine marks. Car wax itself up less than increase hardness, resistance ultraviolet function, will soon loss due to the temperature too high. Therefore, When the car parking shall be in the shade.The six main engine maintenance1. Use proper quality level of the lubricating oilThe engine should be for gasoline into the exhaust system according to additional devices and the using conditions choose SD-SF petrol engine oil level; Thediesel engine according to the mechanical load selection CB-CD level diesel engine oil, choose standard to not under production factory regulations shall prevail.2. Change regularly oil and filterAny quality level of the lubricating oil in use process of oil will change. To a certain mileage after, performance deterioration would bring a variety of problems to the engine. In order to avoid of failure, should combine conditions of use regular oil, and that the amount of oil moderate (generally in oil rod cap of good). The oil from the pores through the filter when the solid particles and viscous oil content stored up in filter. Such as filter jams, oil, not through the filter, will burst filter or turn on the relief valve, from bypass valve through, still the dirt back to lubrication part, make the engine wear, the internal worsening pollution.3. Keep the crankcase ventilationNow most of the gasoline engine are equipped with PCV valves (the crankcase forced ventilation device) prompted the engine take a breath, but channeling the pollutant in gas will "deposition in the valve, PCV around the valve plug. If possible PCV valves jams then pollution reverse flow gas air filter, pollution people filter core, make filtering ability, reduce inhaled mixture of dirty, caused the pollution, more crankcase to increase fuel consumption, engine wear more, even engine damage. Therefore, must be maintained regularly PCV, PCV valves clear around the pollutants.4. Regular cleaning the crankcaseThe engine running process, the combustion chamber not burning gas, high pressure water and sulfur acid, and of nitrogen oxide piston and cylinder wall after the clearance between into the crankcase, with parts wear produced metal powder mix together, form sludge. Quantity in oil suspended for a little time, large amount of precipitation from oil, blocked filter and the oil hole, cause the engine lubrication difficulties, caused by wear. In addition, the oil in the high temperature oxidation film and generates carbon bond on the piston, make the engine oil consumption, increase power decrease, serious when the rings card died and pull cylinder. Therefore, regular cleaning the crankcase and maintain engine internal clean.5. Regular cleaning fuel systemFuel in through the oil for the process of burning to the combustion chamber, inevitably will form the colloid and carbon, in oil,, carburetor, nozzles and deposited in the combustion chamber, interfering with the fuel flow, disrupt the normal air-fuelratio make fuel atomization bad, cause the engine out of shaking, blasting vibration, the idle instability, poor acceleration performance problem. Regular cleaning fuel oil system, control the generation of carbon, can always be the best to make the engine.6. Maintenance regularly water tankEngine water tank rust, scale is the most common problems. The grunge and scale can limit the cooling fluid in the cooling system, the flow, reduce the cooling effect, cause the engine overheat, even cause the engine damage. The cooling liquid oxygen also forms acidity material, corrosion water tank the metal components, causing the water tank damage and leakage. Regularly use the water tank cleaner water tank, remove the rust and scale, can not only ensure normal engine work, and extend the life of the whole water tank and the engine.中文:日常汽车保养汽车日常保养方面应该注意:(1)防混合气过浓由于气温高,汽油容易流动,还因量孔膨胀,使汽油流量增加,且汽油容易蒸发,导致混合气过浓。
Downloaded from SAE International by Guangxi University of Tech, Sunday, March 01, 2015The New Approach to Automotive Vehicle Assembly Process 2015-26-0061Published 01/14/2015 Sanjay NibandheMahindra Mahindra, Ltd.CITATION: Nibandhe, S., "The New Approach to Automotive Vehicle Assembly Process," SAE Technical Paper 2015-26-0061, 2015,doi:10.4271/2015-26-0061.Copyright © 2015 SAE International and Copyright © SAEINDIAAbstractThe paper presents integrated approach to Automobile Assembly Process. The approach describes about “Production Process Simulations” for New Products under development. This leads towards design verification during early prototype assembly process establishment for newly developed automobile vehicles and its control plan which regulates to final production practice.In recent years the Indian automotive business is expanding and with growing needs of faster new product development, the cycle time reduction becomes very crucial for environmental and economic reasons. The Lean production assembly and robust engineering processes are optimized in this approach.It's an advanced mechanism to identify process failures during final production setup. The experimentation has resulted towards establishing micro level study and critical stages to be captured well in advance for better planning. The actual verification of design at early stage builds confidence in New Product Development.This approach covers of all types of vehicle manufacturing, product mix, and deliverables of vehicle quality. The key achievement is by ensuring of significant & critical design parameters, engineering specifications, quality targets and customer perceived quality. The robust planning and decision making results in easiness of final product assembly line.This paper is an approach to create an integrated vehicle assembly process for New Product Development (NPD), in comparison with existing production process of vehicle assembly.IntroductionAt present we have 11 manufacturing facilities in India & abroad. As our Product Development center & manufacturing plants at distant locations. It is not so easy to assemble vehicles at manufacturing plants without any preparation. Similarly manufacturing facilities & Product development center are not closed to each other's, therefore it becomes very difficult to establish new products at early stage. In view of this we proposed & established miniature pilot line on which all the experimentations can be carried out. The present practice needs to modify in a greater way for fast product developments with multiple projects & variants.One product - one production line is a conventional practice over the years. Following process flow chart describes about existing vehicle manufacturing process used by OEM's.Fig.1. Existing vehicle manufacturing process.To have an innovative approach in Product development center for vehicle assembly one has to simulate future production practices to be deployed.[3] There is need to inject the advanced manufacturing quality aspects in it. The independent Pilot production facility for batch productions of prototype vehicles becomes vital. All experimentations need to try out before take up final process settings.Now a days “Product life cycle” span is reduced drastically and hence the Original Equipment Manufacturer (OEM) need to introduce new products quite often. The periodic new product introduction becomes necessity to be successful in the business. Now that different models and variants thereof are required in multiple numbers, to prove dynamic need of customer's perspective. The base platforms are common for these variants and hence, need to accommodate on same production line. i.e. Base model is ‘Swift’ & new variants ‘Swift Desire’, ‘Eartiga’ etc. are produced on one production line. This has created need for an appropriate product mix, multiple models manufactured on one production setup.[3]The type of vehicles like monocoque, semi monocoque and body-over chassis are familiar. All three types of construction needs to have different process setting & sequence while assembly. It needs to accommodate on same line separately or in combination with flexibility. For NPD cycle it needs to be tryout on pilot setup and then make arrangement for final production line. Thus pilot line and simulations becomes the foundation for successful implementation for New Product Development.The integrated process is focusing on lean production practice and cycle time reduction along with design verification, establishing manufacturing quality characteristics & production norms optimization.[1] The task performed across the various projects are almost similar and can be benefit from the proposed process. The focus will be towards optimizing usage of Fixtures, Gauges, Tools, and methods to be deployed for manufacturing with following are the key aspects to be established.1.Design Readiness: Design for Manufacturability (DFM)and Assembly (DFA).2.Design for Serviceability (DFS) and ensure easiness for servableitems.3.Digital mockup & Virtual simulation4.BOM confirmation and compliance5.Assembly Simulation: Process Control specifications6.SOP: Process Control Plan7.Design Verification, Torque Integrity.8.Front Loading for manufacturing quality aspects9.Product Quality mapping10.Production Norms optimization.This paper is a Review of above processes in order to prepare for faster establishment of NPD process and to incorporate for higher design and process level accuracy form the beginning of product launch preparation. Please refer appendix 1 for the innovative approach adopted.1. Design readiness, DFM & DFA: This process provides confirmation for planned sequence of operations, then proper clearances at each stages. It's made applicable for all components & aggregates used in vehicle assembly. In a process confirmation various alternatives are evaluated. Right selection with process sequence & tool can be defined at early stage. This facilitates procurement of the right tools and confirm suitability The new method of virtual simulation provides best norms for fast and easy working. i.e. Cross Car beam bolts fitment is blind area for visibility. This needs high skill & best judgment for operating person else you can't verify as it will be very difficult to verify afterwards. Such critical areas are identified to reduce the dependency of workmen skills to larger extent. [4]The design for manufacturability and design for assembly (DFM & DFA) is confirmed effectively. The micro level details are worked out and process for assembly is defined. i.e. Torque control right angle approach tool with extension will be suitable for narrow space for tightening approach.[6] This process becomes vital important for deciding the assembly practices. Most of the automotive companies are started using these practices. However the scope is quiet vast & unlimited. The entire engineering industry wherever assembly process is involved; will be using it in future. I.e. Computer industry, Watch industry, White goods industry etc.2. Design for Service: Similarly design for serviceability (DFS) is another requirement which needs to confirm at early stage. All serviceable parts from different systems & aggregates may require to remove & refit during service. The set of tools used are quite different than production tools. Hence it needs to confirm adequate clearances for approach of standard tool kit.In few cases standard tools may not be useful unless & until special tools are designed & tried out i.e. removal of lubrication filter due to low access & space available. In such cases special tools are manufactured & provided for large number of service destinations. The specific methods & recommended practice will be planned with DFS study. The virtual study confirms easiness of operations at every level. Adequate time planning can be done to make such tools available for service needs. This process is very important considering long term effects.3. Digital Mockup & Virtual Simulation: In Recent decade the automobile assembly process becomes highly progressive & innovative. The accuracy level required for vehicle assembly needs to be very high in terms of fit finish, overall quality & customer satisfaction. The productivity is also equally important with multiple models/variants of vehicles to produce, simultaneously on the same production line. The process setting at every stage becomes complex.Vehicle assembly process starts with the sequence of operations to follow on assembly conveyor. Every element of sequence relates with tool approach in predetermined way of working. The specifications which are drawn by design, needs to achieve with those tools. The fixtures & methods deployed for easiness of operations plays major role. The space available for component placing & tool accessibility for tightening needs to be considered very carefully.This needs to study in detail with CAD systems at very early stage. Accordingly the layouts, CAD models & proper packaging becomes prerequisite at design stage. Digital Mock up and Virtual simulation needs to plan with details of tools to be deployed. The way the components are placed in assembly sequence & the methods for tightening will be used in DMU. The virtual study will used for complete study of layouts, clearance and space management in packaged condition. In today's world virtual simulation is supported by digital mock-up process & software extensively used for study and decision making. The training needs can be identified and planned in advance. Adequate time planning can be done to make such tools available for service needs. I am sure Auto OEM most of them are using it however other engineering industry can also think over for its wide applications.4.Virtual BOM Verification: The verification of BOM, correct hardware is confirmed at early stage, Virtual BOM simulation is new methodology developed & helped for first time right BOM release before start of physical assembly.5.Assembly Simulation: Process Control Specifications: Physical verification of assembly process is necessary to confirm output of physical simulations. During first pilot batch or prototype stage mostof the parameters are verified. Inputs are given to design & process team about confidence and non-compliance areas. Accordingly design changes are carried out and reconfirm for easiness.The Pilot line is a setup to try out assembly of proto vehicle at miniature line, processes and tools tryout. At first stage of design, all process sequences and innovative concepts about new methods & tools gets verified. The norms are not seen as constrain and the flexibility helps in achieving targets. The optimization of equipment and process confirmation will be carried out well in advance stage. The production norms, gets tryout along with Design for Manufacturing (DFM), Design for Assembly (DFA) and Service Aspect in Manufacturability (SAM) are verified. i.e The new introduction of aggregates like Auto Transmission is to be adoptedin latest vehicles at the proto stage, all functional & fitment tryout, training and practicing can be done at Pilot stage. Afterwards it can be set with refined version at Production line.6. SOP & Process Control plans: Assembly standard operating process (SOP) is defined for consistency in sequence to follow by any operator for ease of operation in given time limit. e.g. door window glass fitment is quite complex for new designs. Hence CAD Virtual simulation are used to establish actual tryout in assembly. This helps to define process. Once actual try out is carried out successfully, it becomes confirmation for process to follow in predetermined sequence. Finally manufacturing team will be trained on this type ofPilot Line. Accordingly SOP & early training is importantfor manufacturing setup of production.“Product specific process control plan” is another important milestone. The engineering team need to take decisions about methods, fixtures, tools & gauges (FTG) to be used during the assembly process. The plan for target production level is key element for design of FTG. Accordingly the process norms are defined & worked out for throughput time & TACT time of operations. The efforts required by operator need to be evaluated to minimize the fatigue for long stretched workouts. E.g. In case of multi utility vehicles the middle seats are heavy in comparison with other parts for operations like Pick, lift, place & fix are the activities which consumes time. Also multiple operators involved & repetitive job create fatigue after some time. Hence manipulators are designed to pick & place with orientation is quite important. If this set up is flexible then this fixtures need to suitable to multiple designs of seats holding and movement. Thus fixture design plays important role in control plan. Another example of flexible powertrain mounting (Engine & Transmission) should be having approach for all six directional movements which brings easiness for aligning, locating & proper positioning.This facilitates need to set to achieve desired production rate with comfortable practice. The arrangement at every stage of production conveyer line will be planned with flow for material feeding, hardware & tools. This will ensure effectiveness for working positions & easy approach at working stages predominantly. The norms are defined with respect to best achievable production rate.Torque Integrity: The next important element of process control is specified as “torque requirement”. The every joint is defined with typeof hardware & applicable torque. The torque value varies from material & hardware used for fixing position. The elasticity limit for plastic part is different than metal part. It depends on tightening surface and clamping location; also material & type of joint makes difference for torqueing values. Once the component is fixed with specified torque value, it need to be retained in a position for long duration to sustain the vibrations from various road conditions & forces exerted on the joints.The study need to carry out at early stage for integrity of torqueing & its life to retain over the period. This can be defined in terms of years or number of kilometers to cover till end of life situation i.e. hardware used for fixing internal trim parts & hardware used for fixing metal to metal parts at suspension joints will have difference in torque value with respect to vibrations & relative movements. Hence specifications becomes critical at every stage.Thereafter the torque retained capacity vary with respect to specifications due to loosening effect due to usage or Life cycle. The reason behind these changes needs to study for material property, number of clamps & its positions. One also needs to anticipate natural tendency of loosening or over tightening effect. The optimistic torque value for every component needs to be set in advance.Residual torque will be confirmed for each clamping/ tightening locations for withholding value. In case the residual torque value changes, it need to be reviewed for right process at early stage. Similarly, if specified values need to revised, the decisions can be taken in advance. E.g. Trim plastic components deformed at localized clamping area which tends to reduce torque against specification value. Similarly number of clamping positions also plays major role, for large components like sheet metal panels, plastic or jute material trim pads.7. Design Verification: The design verification process gets starts with right fitment of components, aggregates without any trouble where predetermined sequence of operations need to follow with specified tools & processes. This provides confirmation for compliance of process. In case of failures, the designs are reevaluated & iterated at early stage. The tolerance stacks & its combined effect on multiple part's fitment needs to be verified.[2] In certain cases human skills become important for fitment of components i.e. the door alignment & adjustment of hardware for gaps & flushness with level of door and body. [9]. It will also affect door locking & unlocking efforts. Predetermined value of door efforts are one of the key parameters for customer perseverance. Similarly pedal efforts are dependent on multiple component's fitment i.e. relates to clutch & brake systems. The components used in assembly, their positions & tolerance, will affect for pedals movements. The resultant is low or high pedal pressure which is another parameter for customer satisfaction. In this way design verification of systems & aggregates are determined for specific requirements.Additionally critical gaps & clearances are another parameter to verify at early design stage.[8] This requires to verify clearances in static conditions between nearest two parts to be measured after assembly. The CAD layout indicates designed gaps & the actual gap available on vehicle needs to compare. The variation in either conditions (i.e. low or high) will have consequential effects. In case of lesser clearance, it may hit to other components or transfer forces / load / heat to the other components which will effect functionality. Inother way; the excessive gap may create effect on opposite side components. The shift condition will be observed and may create effects to the other assembled parts.These situations at static conditions are different than dynamic conditions. The lesser gaps will make assembly critical & create some of the issues related to noise and vibrations, and in worst condition failures. The engine rock at idle RPM & due to rubber mounts characteristics; it will allow engine oscillations. Hence it requires to confirm for adequate clearance during working conditions. There should be safe gap to avoid hit & failure with other components. Similarly hoses & pipes need to retain in the position & have flexibility even in rocking conditions. Otherwise fuel pipe, brake Bundy tubes, air & water hoses may get cut & lead to huge failure during running situation of vehicle. Thus overall design verifications with respect to layouts & clearance is vital important.Bill of Material (BOM) is other design verification parameters. Weight comparison & analysis is with respect to CAD & actual is another design verification parameter. Similarly new features introduced on product needs to be verified for its functionality. Inthis way multiple verification factors need to confirm at early stage.8.Front Loading of Manufacturing Quality aspects: The assembly process is normally looked as completion of parts fitment in sequential manners and compliance of certain quality parameters. At every stage one need to confirm functionality i.e. switch should operate head lamp, tail lamp or any electrical function. To confirm the right fitment & functional aspects of component or aggregate. We need to make stage wise checking facility. The small gazettes are designed & introduced to check the functionality. E.g. window winding motor fitment on door panel need immediate check with electrical supply & confirm proper working of winding mechanism for full operating length. The check points are involved at every stage & ensured allocated time is adequate to confirm product functionality effectively. In few locations, high complexity involved e.g. Ignition& instrument cluster where checking of head lamps, side indicator lamps, AC blowers, Instrument panel indicators etc. are quite complex. Functional checks becomes very critical, this avoids the repair & rectification at later stage to achieve first time right. This also will helpfor the better product quality establishment for first time right assembly. Stage buy-offs are involved for quality target achievement & establish ownership of the team responsible for delivery. Usually these are static check points followed for product improvements. At this stage,software flashing, vehicle data entry & performance checking parameters through SCADA systems are well recognized practice in industry which need to be adopted at ProductDevelopment Centre. Similarly facilities like brake & roller tester, Suspension Rumbles are required to establish for basic braking & suspension setting. Without this suspension permanent set &bushes torqueing will lead towards failures.[1]9.Quality Parameters mapping: Every vehicle will have list of quality parameters to be checked & established right from the early stage. NPD also demands for validation of those functional aspects before it introduce in the production vehicles. After rolling down the vehicles from miniature line static checks, Dynamic checks & advanced checks will be carried out on new products & this establish the future quality targets for production vehicles. The early mapping is helping for decision making & establishing product quality well in advance stage.Static checks - Door closing effectiveness & sealing effect shall be checked with water spray test or smoke test in conformity with standards. The wind screen wiping effectiveness of wiper system are checked to ensure First Time Right.Next stage is dynamic checks, which evolves initial running of the vehicle after completion of prerequisites checks. In first cut feel, we will come to know about acceleration, drivability, suspension & steering responses & any abnormality. The couple of important parameters which provides customer delight are measured with special tools & processes e.g. Clutch & brake pedal efforts, door opening & closing efforts, Steering efforts, Seat tracking efforts, Seat recliner mechanism efforts, gear shift lever efforts, Key opening efforts, approach to various switches & knobs of lighting system, audio system & their functional efforts. Additionally few check points pertaining to mirror operating approach & efforts, all three mirrors visibility, legibility of instrument cluster with lights on/off condition during day & night time, HVAC/AC systems, air flow & temperature, comfort at different locations, seat belt comfort/ access.Certain points related to ergonomic checks also needs to confirm for designer's input & better quality of the product e.g. Ingress/Egress at all seat locations, access to luggage compartment & glove box etc.All the parameters are taken care to avoid subjective feel and make it objective with measurement.Advances Checks: these are the check points for which the experts need to be involved & provide training to team. The parameters like identify abnormal noises of engine, gearbox and gear lever etc. The effect of vibration & rattle, shake on various components like floor panel, pedals, door trims, seat vibrations etc. Similarly checking for engine start & stop noise, clutch operational noise, throttle operation & response noise are identified by experts. The quality ratings are given for the vehicle towards overall feel, noise and comfort of vehicle drive. Similarly seat comfort, in-cab noise & exterior noise are also identified & considered for quality rating. In this process standards for measurement system will be established to refer in Production.Based on the New Product Development process in terms of design verification parameters, Fit & Functional checks & Product Quality Parameters, we defined the index. This index is measured for every new vehicle & achieve the desired target level before introduction in production.10. Production Norms Optimization: Next important process for vehicle assembly will be productivity consideration and norms finalization. The production norms are generally planned with respect to target production and jobs per hour delivery (JPH). The JPH will be finalized with respect to material feeding schedules, the overall stages timing, distance to walk for pick & place, tools approach for clamping & tightening, filling of coolant, fuel, AC gas, brake oil, engine & transmission oil, axle oils as per desired quantity as planned & worked out. The flow rate, feeder rate are also considered for balancing of norms & TACT time. Accordingly the stages are managed & conveyor speeds are set with optimized level. This involves basic skills by workmen for the job completion. Thetrainings need to provide to working team & setting the stage layouts. On this basis, the lean production norms are determined. Accordingly trained manpower will be allotted for set production target. As per production demands, resources are assigned and output will be achieved. The study carried out for different vehicle models and variants & based on that effective production time utilization is worked out.All three types of vehicles i.e. monocoque, semi monocoque and body- over chassis will need different setting & sequence. Individual different production set ups are established separately.Case StudyThis integrated & innovative process was experimented for first time for proto stage of the new vehicle under development. This process knowledge is disseminated to concerned manufacturing plants which saved their valuable time in establishing the New Product Line and fast ramp up of production in line with market demand.Design team received inputs at early phase and the following arethe benefits derived out of this process:1.Cycle time reduction for NPD: Time required to complete Firstbatch of 54 prototype vehicles with conventional static buildprocess was 27 weeks (7 months), whereas with new process i.e.build on Proto pilot miniature line, it has reduced to 16 weeks (4 months) and the total time saved is 12 weeks (3 months).2.FIRST TIME RIGHT product development, number ofengineering design changes reduced by 33% from firstbuild phase to second build phase.3.It is observed that number of manufacturing related concernsreduced from 815 to 184 (Reduction by 77%) in the project& Open concerns reduced from 210 to 19 (Reduction by 90%)over a period of time of 5 months.4.Design team worked to correct engineering specifications atearly stage & as a result Engineering Specifications Test scoreimproved from 54% to 70% at first phase of Prototype build.5.The result of continuous monitoring of torque parametersand necessary changes in torque specifications consideringTorque Integrity inputs. Torque Integrity score improvedfrom 80% to 96%.6.The customer perceived audit rating, number of concernsreduced from 250 to 155 at prototype stage, further concernresolution was targeted with better quality of supply andfinal process at production line. Target of less than 20concerns achieved before SOP.7.Continuous monitoring of build assessment parameters resultedin improvement in Build Quality Index from 3 to 6 in firstphase of prototype build and finally reached to level of 9before handover to production.8.Percentage of Not OK DVP parameters reduced from 50% to1.83%.9.Simulation of Fixtures Tools & Gauges carried out at firstphase of prototype build, helped Manufacturing Engineeringteam for readiness with all necessary Fixtures Tools & Gaugesbefore start of second phase of Prototype build itself. Tool TryOut phase deleted from development cycle, resulted in cost &time saving by 2 months. 10.As a result of integrated process production ramp upduration reduced from 12-15 weeks to 07 Weeks.11.Cascading unique Mahindra Product Development System Gen-IV process across all new products and locations.Conclusion1.The existing vehicle assembly knowledge is extended for earlydevelopment of prototype to establish newly designed products.2.The miniature pilot line is essential for multi-locationproduct manufacturing process establishment.3.To establish new products for production, the system needto study in advance by digital mockup and virtual simulationprocess at Prototyping stage & gain the design confidence.4.Engineering specifications are required at early stage todefine and set acceptance limits. This will help to achievecustomer touch points at initial stage of prototyping.5.Assembly process simulation of new design is carried outduring first stage of prototype and design confidence is gainedwell in advance.6.The design verification is vital important process to improveon design and confirm easiness in fitment and functional aspect, provided confidence with outcome of FTG & SOP.7.The process control plan, Tools & Fixtures design are specificto norms.8.The Front loading is very crucial during manufacturing processfor first time right product development.9.The optimization of resources was the key ingredient forLean production with product mix and variants. The SOP isderived for deployment.10.Vehicle constructions of all platforms are tried out onunique dynamic Proto Pilot line.11.The successful implementation with very careful and microlevel plans are innovative approach to tryout at pilot stage.References1.Morgan James M; Liker Jeffery K, “The Toyota ProductDevelopment systems” Integrating People, Process, andTechnology, Productivity Press, New York, ISBN-10:1563272822, ISBN-13: 978-1563272820, 2006.2.Nicolas, C., Hugo, F., François, T., Pierre, B. et al., “ANew Approach for Best Fit Assembly Based on theBehaviour of Components,” SAE Technical Paper 2006-01-3174, 2006, doi:10.4271/2006-01-3174.3.Krammer, P., Neef, D., and Plapper, P., “AdvancedManufacturing Technologies for General Assem bly,” SAETechnical Paper 2011-01-1253, 2011, doi:10.4271/2011-01-1253.4.Koganti, R., Zaluzec, M., Chen, M., and Defersha, F., “Designfor Integrated Assembly and Disassembly of AutomotiveProducts,” SAE Technical Paper 2006-01-1423, 2006,doi:10.4271/2006-01-1423.5.da Silva, P., “Concept Car: Excellence in Preparing People forNew Car Releases,” SAE Technical Paper 2006-01-2847, 2006, doi:10.4271/2006-01-2847.。
附录A外文翻译-原文部分How Car Suspensions WorkTable of Contents:› Introduction to How Car Suspensions Work› Vehicle Dynamics› The Chassis› Springs› Springs: Sprung and Unsprung Mass› Dampers: Shock Absorbers› Dampers: Struts and Anti-sway Bars› Suspension Types: Front› Suspension Types: Rear› Specialized Suspensions: T› Specialized Suspensions: Formula One Racers› Spec ialized Suspensions: Hot Rods› The Future of Car Suspensions› Lots More Information› Compare Prices for Car SuspensionsWhen people think of automobile performance, they normally think of horsepower, torque and zero-to-60 acceleration. But all of the power generated by a piston engine is useless if the driver can't control the car. That's why automobile engineers turned their attention to the suspension system almost as soon as they had mastered the four-stroke internal combustion engine.Photo courtesy Honda Motor Co., Ltd.Double-wishbone suspension on Honda Accord 2005CoupeThe job of a car suspension is to maximize the friction between the tires and the road surface, to provide steering stability with good handling and to ensure the comfort of the passengers. In this article, we'll explore how car suspensions work, how they've evolved over the years and where the design of suspensions is headed in the future.Vehicle DynamicsIf a road were perfectly flat, with no irregularities,suspensions wouldn't be necessary. But roads are far fromflat. Even freshly paved highways have subtle imperfectionsthat can interact with the wheels of a car. It's theseimperfections that apply forces to the wheels. According toNewton's laws of motion, all forces have both magnitude anddirection. A bump in the road causes the wheel to move upand down perpendicular to the road surface. The magnitude,of course, depends on whether the wheel is striking a giantbump or a tiny speck. Either way, the car wheel experiences avertical acceleration as it passes over an imperfection.Without an intervening structure, all of wheel's vertical energy is transferred to the frame, which moves in the same direction. In such a situation, the wheels can lose contact with the road completely. Then, under the downward force of gravity, the wheels can slam back into the road surface. What you need is a system that will absorb the energy of the vertically accelerated wheel, allowing the frame and body to ride undisturbed while the wheels follow bumps in the road.The study of the forces at work on a moving car is called vehicle dynamics, and you need to understand some of these concepts in order to appreciate why a suspension is necessary in the first place. Most automobile engineers consider the dynamics of a moving car from two perspectives:∙Ride - a car's ability to smooth out a bumpy road∙Handling - a car's ability to safely accelerate, brake and cornerThese two characteristics can be further described in three important principles - road isolation, road holding and cornering. The table below describes these principles and how engineers attempt to solve the challenges unique to each.A car's suspension, with its various components, provides all of the solutions described.Let's look at the parts of a typical suspension, working from the bigger picture of the chassis down to the individual components that make up the suspension proper.The ChassisThe suspension of a car is actually part of the chassis, which comprises all of the important systems located beneath the car's body.ChassisThese systems include:∙The frame - structural, load-carrying component that supports the car's engine and body, which are in turn supported by the suspension∙The suspension system - setup that supports weight, absorbs and dampens shock and helps maintain tire contact∙The steering system - mechanism that enables the driver to guide and direct the vehicle∙The tires and wheels - components that make vehicle motion possible by way of grip and/or friction with the roadSo the suspension is just one of the major systems in any vehicle.With this big-picture overview in mind, it's time to look at the three fundamental components of any suspension: springs, dampers and anti-sway bars.SpringsToday's springing systems are based on one of four basic designs:Coil springs - This is the most common type of spring and is, in essence, aheavy-duty torsion bar coiled around an axis. Coil springs compress and expand to absorb the motion of the wheels.∙Leaf springs - This type of spring consists of several layers of metal (called "leaves") bound together to act as a single unit. Leaf springs were first used on horse-drawn carriages and were found on most American automobiles until 1985. They are still used today on most trucks and heavy-duty vehicles.∙Torsion bars - Torsion bars use the twisting properties of a steel bar to provide coil-spring-like performance. This is how they work: One end of a bar is anchored to the vehicle frame. The other end is attached to a wishbone,which acts like a lever that moves perpendicular to the torsion bar. When the wheel hits a bump, vertical motion is transferred to the wishbone and then, through the levering action, to the torsion bar. The torsion bar then twistsalong its axis to provide the spring force. European carmakers used thissystem extensively, as did Packard and Chrysler in the United States, through the 1950s and 1960s.Photo courtesy HowStuffWorks ShopperTorsion bar∙Air springs - Air springs, which consist of a cylindrical chamber of air positioned between the wheel and the car's body, use the compressive qualities of air to absorb wheel vibrations. The concept is actually more than a century old and could be found on horse-drawn buggies. Air springs from this era were made from air-filled, leather diaphragms, much like a bellows; they werereplaced with molded-rubber air springs in the 1930s.Photo courtesy HSW ShopperAir springsBased on where springs are located on a car -- i.e., between the wheels and the frame -- engineers often find it convenient to talk about the sprung mass and the unsprung mass.Springs: Sprung and Unsprung MassThe sprung mass is the mass of the vehicle supported on the springs, while the unsprung mass is loosely defined as the mass between the road and the suspension springs. The stiffness of the springs affects how the sprung mass responds while the car is being driven. Loosely sprung cars, such as luxury cars (think Lincoln Town Car), can swallow bumps and provide a super-smooth ride; however, such a car is prone to dive and squat during braking and acceleration and tends to experience body sway or roll during cornering. Tightly sprung cars, such as sports cars (think Mazda Miata), are less forgiving on bumpy roads, but they minimize body motion well, which means they can be driven aggressively, even around corners.So, while springs by themselves seem like simple devices, designing and implementing them on a car to balance passenger comfort with handling is a complex task. And to make matters more complex, springs alone can't provide a perfectly smooth ride. Why? Because springs are great at absorbing energy, but not so good at dissipating it. Other structures, known as dampers, are required to do this.Dampers: Shock AbsorbersUnless a dampening structure is present, a car spring will extend and release the energy it absorbs from a bump at an uncontrolled rate. The spring will continue to bounce at its natural frequency until all of the energy originally put into it is used up.A suspension built on springs alone would make for an extremely bouncy ride and, depending on the terrain, an uncontrollable car.Enter the shock absorber, or snubber, a device that controls unwanted spring motion through a process known as dampening. Shock absorbers slow down and reduce the magnitude of vibratory motions by turning the kinetic energy of suspension movement into heat energy that can be dissipated through hydraulic fluid. To understand how this works, it's best to look inside a shock absorber to see its structure and function.A shock absorber is basically an oil pump placed between the frame of the car and the wheels. The upper mount of the shock connects to the frame (i.e., the sprung weight), while the lower mount connects to the axle, near the wheel (i.e., the unsprung weight). In a twin-tube design, one of the most common types of shock absorbers, the upper mount is connected to a piston rod, which in turn is connected to a piston, which in turn sits in a tube filled with hydraulic fluid. The inner tube is known as the pressure tube, and the outer tube is known as the reserve tube. The reserve tube stores excess hydraulic fluid.When the car wheel encounters a bump in the road and causes the spring to coil and uncoil, the energy of the spring is transferred to the shock absorber through the upper mount, down through the piston rod and into the piston. Orifices perforate the piston and allow fluid to leak through as the piston moves up and down in the pressure tube. Because the orifices are relatively tiny, only a small amount of fluid, under great pressure, passes through. This slows down the piston, which in turn slows down the spring.Shock absorbers work in two cycles -- the compression cycle and the extension cycle. The compression cycle occurs as the piston moves downward, compressing the hydraulic fluid in the chamber below the piston. The extension cycle occurs as the piston moves toward the top of the pressure tube, compressing the fluid in the chamber above the piston. A typical car or light truck will have more resistance during its extension cycle than its compression cycle. With that in mind, thecompression cycle controls the motion of the vehicle's unsprung weight, while extension controls the heavier, sprung weight.All modern shock absorbers are velocity-sensitive -- the faster the suspension moves, the more resistance the shock absorber provides. This enables shocks to adjust to road conditions and to control all of the unwanted motions that can occur in a moving vehicle, including bounce, sway, brake dive and acceleration squat.Dampers: Struts and Anti-sway BarsAnother common dampening structure is the strut -- basically a shock absorber mounted inside a coil spring. Struts perform two jobs: They provide a dampening function like shock absorbers, and they provide structural support for the vehicle suspension. That means struts deliver a bit more than shock absorbers, which don't support vehicle weight -- they only control the speed at which weight is transferred in a car, not the weight itself. Because shocks and struts have so much to do with the handling of a car, they can be considered critical safety features. Worn shocks and struts can allow excessive vehicle-weight transfer from side to side and front to back. This reduces the tire's ability to grip the road, as well as handling and braking performance.Anti-sway BarsAnti-sway bars (also known as anti-roll bars) are used along with shock absorbers or struts to give a moving automobile additional stability. An anti-sway bar is a metal rod that spans the entire axle and effectively joins each side of the suspension together.When the suspension at one wheel moves up and down, the anti-sway bar transfers movement to the other wheel. This creates a more level ride and reduces vehicle sway. In particular, it combats the roll of a car on its suspension as it corners. For thisreason, almost all cars today are fitted with anti-sway bars as standard equipment, although if they're not, kits make it easy to install the bars at any time.Suspension Types: FrontSo far, our discussions have focused on how springs and dampers function on any given wheel. But the four wheels of a car work together in two independent systems -- the two wheels connected by the front axle and the two wheels connected by the rear axle. That means that a car can and usually does have a different type of suspension on the front and back. Much is determined by whether a rigid axle binds the wheels or if the wheels are permitted to move independently. The former arrangement is known as a dependent system, while the latter arrangement is known as an independent system. In the following sections, we'll look at some of the common types of front and back suspensions typically used on mainstream cars.Front Suspension - Dependent SystemsDependent front suspensions have a rigid front axle that connects the front wheels. Basically, this looks like a solid bar under the front of the car, kept in place by leaf springs and shock absorbers. Common on trucks, dependent front suspensions haven't been used in mainstream cars for years.Front Suspension - Independent SystemsIn this setup, the front wheels are allowed to move independently. The MacPherson strut, developed by Earle S. MacPherson of General Motors in 1947, is the most widely used front suspension system, especially in cars of European origin.The MacPherson strut combines a shock absorber and a coil spring into a single unit. This provides a more compact and lighter suspension system that can be used for front-wheel drive vehicles.The double-wishbone suspension, also known as an A-arm suspension, is another common type of front independent suspension.Double-wishbone suspension on Honda Accord 2005CoupeWhile there are several different possible configurations, this design typically uses two wishbone-shaped arms to locate the wheel. Each wishbone, which has two mounting positions to the frame and one at the wheel, bears a shock absorber and a coil spring to absorb vibrations. Double-wishbone suspensions allow for more control over the camber angle of the wheel, which describes the degree to which the wheels tilt in and out. They also help minimize roll or sway and provide for a more consistent steering feel. Because of these characteristics, the double-wishbone suspension is common on the front wheels of larger cars.Now let's look at some common rear suspensions.Suspension Types: RearRear Suspension - Dependent SystemsIf a solid axle connects the rear wheels of a car, thenthe suspension is usually quite simple -- based eitheron a leaf spring or a coil spring. In the former design,the leaf springs clamp directly to the drive axle. Theends of the leaf springs attach directly to the frame,and the shock absorber is attached at the clamp thatholds the spring to the axle. For many years,American car manufacturers preferred this designbecause of its simplicity. The same basic design can be achieved with coil springs replacing the leaves. In this case, the spring and shock absorber can be mounted as a single unit or as separate components. When they're separate, the springs can be much smaller, which reduces the amount of space the suspension takes up.Rear Suspension - Independent SuspensionsIf both the front and back suspensions are independent, then all of the wheels are mounted and sprung individually, resulting in what car advertisements tout as"four-wheel independent suspension." Any suspension that can be used on the front of the car can be used on the rear, and versions of the front independent systemsdescribed in the previous section can be found on the rear axles. Of course, in the rear of the car, the steering rack -- the assembly that includes the pinion gear wheel and Photo courtesyHowStuffWorks Shopper Leaf springenables the wheels to turn from side to side -- is absent. This means that rear independent suspensions can be simplified versions of front ones, although the basic principles remain the same.Specialized Suspensions: The Baja BugFor the most part, this article has focused on the suspensions of mainstream front- and rear-wheel-drive cars -- cars that drive on normal roads in normal driving conditions. But what about the suspensions of specialty cars, such as hot rods, racers or extreme off-road vehicles? Although the suspensions of specialty autos obey the same basic principles, they do provide additional benefits unique to the driving conditions they must navigate. What follows is a brief overview of how suspensions are designed for three types of specialty cars -- Baja Bugs, Formula One racers and American-style hot rods.Baja BugsThe Volkswagen Beetle or Bug was destined to become a favorite among off-road enthusiasts. With a low center of gravity and engine placement over the rear axle, the two-wheel-drive Bug handles off-road conditions as well as some four-wheel-drive vehicles. Of course, the VW Bug isn't ready for off-road conditions with its factory equipment. Most Bugs require some modifications, or conversions, to get them ready for racing in harsh conditions like the deserts of Baja California.One of the most important modifications takes place in the suspension. Thetorsion-bar suspension, standard equipment on the front and back of most Bugs between 1936 and 1977, can be raised to make room for heavy-duty, off-road wheels and tires. Longer shock absorbers replace the standard shocks to lift the body higher and to provide for maximum wheel travel. In some cases, Baja Bug converters remove the torsion bars entirely and replace them with multiple coil-over systems, an aftermarket item that combines both the spring and shock absorber in one adjustable unit. The result of these modifications is a vehicle that allows the wheels to travelvertically 20 inches (50 cm) or more at each end. Such a car can easily navigate rough terrain and often appears to "skip" over desert washboard like a stone over water.Specialized Suspensions: Formula One RacersThe Formula One racing car represents the pinnacle of automobile innovation and evolution. Lightweight, composite bodies, powerful V10 engines and advanced aerodynamics have led to faster, safer and more reliable cars.To elevate driver skill as the key differentiating factor in a race, stringent rules and requirements govern Formula One racecar design. For example, the rules regulating suspension design say that all Formula One racers must be conventionally sprung, but they don't allow computer-controlled, active suspensions. To accommodate this, the cars feature multi-link suspensions, which use a multi-rod mechanism equivalent to a double-wishbone system.Recall that a double-wishbone design uses two wishbone-shaped control arms to guide each wheel's up-and-down motion. Each arm has three mounting positions -- two at the frame and one at the wheel hub -- and each joint is hinged to guide the wheel's motion. In all cars, the primary benefit of a double-wishbone suspension is control. The geometry of the arms and the elasticity of the joints give engineers ultimate control over the angle of the wheel and other vehicle dynamics, such as lift, squat and dive. Unlike road cars, however, the shock absorbers and coil springs of a Formula One racecar don't mount directly to the control arms. Instead, they are oriented along the length of the car and are controlled remotely through a series of pushrods and bell cranks. In such an arrangement, the pushrods and bell cranks translate the up-and-down motions of the wheel to the back-and-forth movement of the spring-and-damper apparatus.Specialized Suspensions: Hot RodsThe classic American hot rod era lasted from 1945 to about 1965. Like Baja Bugs, classic hot rods required significant modification by their owners. Unlike Bugs, however, which are built on Volkswagen chassis, hot rods were built on a variety of old, often historical, car models: Cars manufactured before 1945 were considered ideal fodder for hot rod transformations because their bodies and frames were often in good shape, while their engines and transmissions needed to be replaced completely. For hot rod enthusiasts, this was exactly what they wanted, for it allowed them to install more reliable and powerful engines, such as the flathead Ford V8 or the Chevrolet V8.The Future of Car SuspensionsWhile there have been enhancements and improvements to both springs and shockabsorbers, the basic design of car suspensions has not undergone a significant evolution over the years. But all of that's about to change with the introduction of a brand-new suspension design conceived by Bose -- the same Bose known for its innovations in acoustic technologies. Some experts are going so far as to say that the Bose suspension is the biggest advance in automobile suspensions since the introduction of an all-independent design.How does it work? The Bose system uses a linear electromagnetic motor (LEM) at each wheel in lieu of a conventional shock-and-spring setup. Amplifiers provide electricity to the motors in such a way that their power is regenerated with each compression of the system. The main benefit of the motors is that they are not limited by the inertia inherent in conventional fluid-based dampers. As a result, an LEM can extend and compress at a much greater speed, virtually eliminating all vibrations in the passenger cabin. The wheel's motion can be so finely controlled that the body of the car remains level regardless of what's happening at the wheel. The LEM can also counteract the body motion of the car while accelerating, braking and cornering, giving the driver a greater sense of control.Unfortunately, this paradigm-shifting suspension won't be available until 2009, when it will be offered on one or more high-end luxury cars. Until then, drivers will have to rely on the tried-and-true suspension methods that have smoothed out bumpy rides for centuries.For more information on car suspensions and related topics, check out the links on the next page.附录B 外文翻译-译文部分汽车悬架如何工作目录列表:对汽车悬架如何工作的介绍车辆动力学底盘弹簧弹簧:簧载质量和非簧载质量减震器:震动吸收装置减震器:减震器支柱和横向稳定杆悬架形式:前悬架悬架形式:后悬架特种悬架:T型悬架特种悬架:一级方程式赛车悬架特种悬架:改装车悬架未来汽车悬架更多信息汽车悬架的价格比较当人们提到汽车的性能时,人们通常会想到功率、扭矩和0到60的加速时间。
Unit 1 Automobile Basicsspare wheel 备胎lubricate 润滑(名词是lubrication )gearbox 变速箱frame 车架transmission 变速器hood 发动机罩(=bonnet )→ decklid = trunklid 行李箱盖chassis chassis ['ʃæsi]['ʃæsi]底盘crankshaft 曲轴carburetor carburetor [,kɑːbjʊ'retə][,kɑːbjʊ'retə]化油器spark plug 火花塞clutch 离合器driveshaft 传动轴drive train 传动链petroleum petroleum [pə'trolɪəm][pə'trolɪəm]石油propane 丙烷gasohol 酒精混合燃料Unit 2 Bodies bracket 支架labyrinth labyrinth ['læbərɪnθ]['læbərɪnθ]迷宫cross-member 横梁interposition 干涉steering wheel 方向盘three-box car 三厢车hinge 铰链bumper 保险杠windshield 挡风玻璃windshield wiper 雨刮器interior trim 内饰instrument panel = dashboard 仪表盘safety belt 安全带unibody 承载式车身rubber bush 橡胶衬套vibration 振动ancillary 辅助的stress 应力fender 翼子板curb weight 整备质量intake duct 进气道fatigue 疲劳demist 除雾loudspeaker 扬声器Unit 3 Engines sprocket 链齿轮cylinder 汽缸connecting rod 连杆valve 气门camshaft 凸轮轴lifter 挺杆rocker arm 摇臂valve train 配气机构Unit 4 Fuel System clamp 夹具fuel rail 油轨intake manifold 进气歧管exhaust manifold 排气歧管throttle 节气门squirt 喷射hothouse 温室Unit 5 Electric System circuit 电路coil 线圈ignition 点火alternator 发电机ammeter 安培计voltage regulator 稳压器insulation 绝缘distributor 分电器transistor 晶体管fuse 保险relay 继电器headlights 大灯dome light 顶灯fog lamp 雾灯dash 仪表板halogen 卤素filament 灯丝LED(Light Emitting Diodes)发光二极管Unit 6 Cooling and Lubricating Systems wear 磨损contamination 污染coolant 冷却液radiator 散热器thermostat 节温器grill 格栅,进风口centrifugal force 离心力centripetal force 向心力boiling point 沸点overflow tube 溢流管wax 蜡oil filter 机油滤清器oil pan 油底壳oil galleries 油孔sealing 密封nozzle 喷嘴meshing gear 啮合齿轮bearing 轴承horsepower 马力Unit 7 Exhaust and Emission Control System header pipe 集气管three-way catalytic converter 三元催化转化器三元催化转化器catalyst 催化剂muffler 消音器hanger 挂钩heat shield 隔热板heavy-duty 耐用的,重负荷的fume 烟hydrocarbon 碳氢化合物evaporate 蒸发(名词后缀是-ion)additive 添加剂coupling 连接器gasket 垫圈odorless 无味的positive crankcase ventilation 曲轴箱强制通风曲轴箱强制通风grove 沟槽oil dipstick 油尺vacuum valve 真空阀charcoal canister 活性炭阀idle speed 怠速EGR(Exhaust Gas Recirculation)废气再循环platinum 铂palladium 钯rhodium 铑ceramic 陶瓷的honeycomb 蜂窝状Unit 8 Suspension System, Steering System and Brake System passenger cars/vehicles 乘用车commercial cars/vehicles 商用车bump 路面凸起alignment 校准steering knuckle 转向节swivel 旋转spring 弹簧(sprite 雪碧)ball joint 球型接头shock absorber = damper 减震器bounce 谈起bushing 衬套non-independent suspension 非独立悬架recirculating call steering systems 循环球式转向器rack-and-pinion steering systems 齿轮齿条式转向器齿轮齿条式转向器lorry 货车(也有卡车的意思)truck 卡车worm gear 涡轮蜗杆机构steering linkage 转向连杆steering column 柱pitman arm 转向摇臂track rod 转向横拉杆idler arm 随动臂sleeve 衬套master cylinder 制动主缸lever 杠杆brake booster 制动助力器engine compartment 发动机舱housing 外壳,壳体malfunction 故障,失灵cable 线缆caliper 卡钳brake pads 摩擦片hub 轮毂squeeze 压缩brake shoe 制动蹄Unit 9 Drive Trains and Axlesdrive axles 驱动桥MT(Manual Transmission)手动变速器AT(Automatic Transmission)自动变速器CVT(Continuously Variable Transmission)无级变速器stationary 静态的release bearing 分离轴承clutch fork 离合器拨叉pressure plate 压盘tension 张力hydraulic circuit 液压回路throw-out bearing = release bearing 分离轴承torque converter 液力变矩器friction 摩擦synchronizer 同步器shift linkage 换挡连杆机构turbine 涡轮stator 导轮planet gears 行星齿轮planet gear carrier 行星架行星架ring gear 齿圈slip yoke 滑动叉differential 差速器axle housing 桥壳unsprung weight 簧下质量sprung weight 簧上质量Unit 10 Safety, Security and Navigation Systems occupant = passenger乘员buckle 安全带插扣impact 碰撞regulatory 法规nylon 尼龙stiffness 刚度abrasion 磨损kinetic 运动学的inertia 惯性trigger 触发器resister 电阻GPS(Global Positioning System)全球定位系统补充:assembly line装配线stabilizer bar横向稳定杆cylinder block 气缸体cast iron/aluminium 铸铁/铝turbocharge 涡轮增压supercharge 机械增压exhaust pipe 排气管displacement排量compression ratio压缩比valve overlap 气门重叠thrust washer 止推垫圈ductile iron 球墨铸铁constant velocity joint 等速万向节等速万向节SUV (Sport Utility Vehicle )运动型多功能车)运动型多功能车常见品牌:Toyota 丰田Honda 本田Nissan 日产Mazda 马自达Lexus 雷克萨斯Suzuki 铃木Mitsubishi 三菱General Motors 通用Cadillac 凯迪拉克Lincoln 林肯Ford 福特Chrysler 克莱斯勒Corvette 克尔维特Mercedes Mercedes [mə'sidi:z][mə'sidi:z][mə'sidi:z] Benz 梅赛德斯-奔驰Volkswagen 大众Audi 奥迪Rolls Royce 劳斯莱斯Bentley 宾利Ferrari 法拉利Maserati 玛莎拉蒂Aston Martin 阿斯顿马丁Jaguar 捷豹Porsche 保时捷Lamborghini 兰博基尼Koenigsegg 柯尼塞格Bugatti 布加迪Pagani 帕加尼Alfa Romeo 阿尔法罗密欧Volvo 沃尔沃Lotus 莲花a m n d A l t h g sb i e o f rRenault 雷诺Hyundai 现代Peugeot 标志Opel 欧宝Fiat 菲亚特Skoda 斯柯达Citroen 雪铁龙Dodge 道奇。
本科生毕业设计(论文)外文翻译外文题目:AUTOMOTIWE FINAL DRIVE译文题目:汽车主减速器学生姓名:专业:车辆工程指导教师姓名:评阅日期:AUTOMOTIWE FINAL DRIVEFINAL DRIVEA final drive is that part of a power transmission system between the drive shaft and the differential. Its function is to change the direction of the power transmitted by the drive shaft through 90 degrees to the driving axles. At the same time. it provides a fixed reduction between the speed of the drive shaft and the axle driving the wheels.The reduction or gear ratio of the final drive is determined by dividing the number of teeth on the ring gear by the number of teeth on the pinion gear. In passenger vehicles, this speed reduction varies from about 3:1 to 5:1. In trucks it varies from about 5:1 to 11:1. To calculate rear axle ratio, count the number of teeth on each gear. Then divide the number of pinion teeth into the number of ring gear teeth. For example, if the pinion gear has 10 teeth and the ring gear has 30 (30 divided by 10), the rear axle ratio would be 3:1. Manufacturers install a rear axle ratio that provides a compromise between performance and economy. The average passenger car ratio is 3.50:1.The higher axle ratio, 4.11:1 for instance, would increase acceleration and pulling power but would decrease fuel economy. The engine would have to run at a higher rpm to maintain an equal cruising speed.The lower axle ratio. 3:1, would reduce acceleration and pulling power but would increase fuel mileage. The engine would run at a lower rpm while maintaining the same speed.The major components of the final drive include the pinion gear, connected to the drive shaft, and a bevel gear or ring gear that is bolted or riveted to the differential carrier. To maintain accurate and proper alignment and tooth contact, the ring gear and differential assembly are mounted in bearings. The bevel drive pinion is supported by two tapered roller bearings, mounted in the differential carrier. This pinionshaft is straddle mounted. meaning that a bearing is located on each side of the pinion shaft teeth. Oil seals prevent the loss of lubricant from the housing where the pinion shaft and axle shafts protrude. As a mechanic, you will encounter the final drive gears in the spiral bevel and hypoid design.Spiral Bevel GearSpiral bevel gears have curved gear teeth with the pinion and ring gear on the same center line. This type of final drive is used extensively in truck and occasionally in older automobiles. This design allows for constant contact between the ring gear and pinion. It also necessitates the use of heavy grade lubricants.Hypoid GearThe hypoid gear final drive is an improvement or variation of the spiral bevel design and is commonly used in light and medium trucks and all domestic rear- wheel drive automobiles. Hypoid gears have replaced spiral bevel gears because they lower the hump in the floor of the vehicle and improve gear-meshing action. As you can see in figure 5-13, the pinion meshes with the ring gear below the center line and is at a slight angle (less than 90 degrees).Figure 5-13.—Types of final drives.This angle and the use of heavier (larger) teeth permit an increased amount of power to be transmitted while the size of the ring gear and housing remain constant. The tooth design is similar to the spiral bevel but includes some of the characteristics of the worm gear. This permits the reduced drive angle. The hypoid gear teeth have a more pronounced curve and steeper angle, resulting in larger tooth areas and more teeth to be in contact at the same time. With more than one gear tooth in contact, a hypoid design increases gear life and reduces gear noise. The wiping action of the teeth causes heavy tooth pressure that requires the use of heavy grade lubricants.Double-Reduction Final DriveIn the final drives shown in figure 5-13, there is a single fixed gear reduction. This is the only gear reduction in most automobiles and light- and some medium-duty trucks between the drive shaft and the wheels.Double-reduction final drives are used for heavy- duty trucks. With this arrangement (fig. 5-14) it is not necessary to have a large ring gear to get the necessary gear reduction. The first gear reduction is obtained through a pinion and ring gear as the single fixed gear reduction final drive. Referring to figure 5-14, notice that the secondary pinion is mounted on the primary ring gear shaft. The second gear reduction is the result of the secondary pinion which is rigidly attached to the primary ring gear, driving a large helical gear which is attached to the differential case. Double-reduction final drives may be found on military design vehicles, such as the 5-ton truck. Many commercially designed vehicles of this size use a single- or double-reduction final drive with provisions for two speeds to be incorporatedFigure 5-14.—Double-reduction final driveTwo-Speed Final DriveThe two-speed or dual-ratio final drive is used to supplement the gearing of the other drive train components and is used in vehicles with a single drive axle (fig. 5-15). The operator can select the range or speed of this axle with a button on the shifting lever of the transmission or by a lever through linkageThe two-speed final drive doubles the number of gear ratios available for driving the vehicle under various load and roadconditions. For example, a vehicle with a two-speed unit and a five-speed transmission, ten different forward speeds are available. This unit provides a gear ratio high enough to permit pulling a heavy load up steep grades and a low ratio to permit the vehicle to run at high speeds with a light load or no loadThe conventional spiral bevel pinion and ring gear drives the two-speed unit, but a planetary gear train is placed between the differential drive ring gear and the differential case. The internal gear of the planetary gear train is bolted rigidly to the bevel drive gear. A ring on which the planetary gears are pivoted is bolted to the differential case. A member, consisting of the sun gear and a dog clutch, slides on one of the axle shafts and is controlled through a button or lever accessible to the operator When in high range, the sun gear meshes with the internal teeth on the ring carrying the planetary gears and disengages the dog clutch from the left bearing adjusting ring, which is rigidly held in the differential carrier. In this position, the planetary gear train is locked together. There is no relative motion between the differential case and the gears in the planetary drive train. The differential case is driven directly by the differential ring gear, the same as in the conventional single fixed gear final drive.When shifted into low range, the sun gear is slid out of mesh with the ring carrying the planetary gears. The dog clutch makes a rigid connection with the left bearing adjusting ring. Because the sun gear is integral with the dog clutch, it is also locked to the bearing adjusting rings and remains stationary. The internal gear rotates the planetary gears around the stationary sun gear, and the differential case is driven by the ring on which the planetary gears are pivoted. This action produces the gear reduction, or low speed, of the axleDIFFERENTIAL ACTIONThe rear wheels of a vehicle do not always turn at the same speed. When the vehicle is turning or when tire diameters differ slightly, the rear wheels must rotate at different speeds.If there were a solid connection between each axle and the differential case, the tires would tend to slide, squeal, and wear whenever the operator turned the steering wheel of the vehicle. A differential is designed to prevent this problem.Driving Straight AheadWhen a vehicle is driving straight ahead, the ring gear, the differential case, the differential pinion gears, and the differential side gears turn as a unit. The two differential pinion gears do NOT rotate on the pinion shaft, because they exert equal force on the side gears. As a result, the side gears turn at the same speed as the ring gear, causing both rear wheels to turn at the same speed.Turning CornersWhen the vehicle begins to round a curve, the differential pinion gears rotate on the pinion shaft. This occurs because the pinion gears must walk around the slower turning differential side gear. Therefore, the pinion gears carry additional rotary motion to the faster turning outer wheel on the turn..Differential speed is considered to be 100 percent. The rotating action of the pinion gears carries 90 percent of this speed to the slowing mover inner wheel and sends 110 percent of the speed to the faster rotating outer wheel. This action allows the vehicle to make the turn without sliding or squealing the wheels.Figure 5-15.—Two speed final drive汽车主减速器主减速器主减速器是在传动轴和差速器之间的一个动力传动系统的组成部分。
中英文对照外文翻译文献(文档含英文原文和中文翻译)原文:The Track Vehicle Changes Direction Research Present Condition and DevelopmentTrends of The Organization1 change direction the research present condition of the organizationDifferent classification in basis method, the track vehicle changes direction organization can according to vehicle is in change direction process the power flows of deliver the way is divided into the single power flows to changedirection the organization to flow to change direction the organization with a power, and also can according to in change direction process two the sport of side trackses have no the contact but is divided into the independent type change direction the organization with bad soon the type changes direction the organization.1.1 single powers establish a certain changing direction the organization after flowing change direction the single power in organization flow to change direction the general structure in organization method is at became soon the organization, is the most simple method to constitute track vehicle change direction to spread to move.The single power flows to change direction the organization to change direction the organization most in brief, among them most in common usely change direction the clutch, single bad soon the machine, double is bad soon the machine, planet changes direction organization etc..Change direction the clutch[1,2] is all a friction that several types rub the clutch, depending the friction surface to deliver to turn the , being the separation some on changing direction the clutch laterally, can reduce or cut off that side drive a round delivers of turn the make vehicle changed direction.Change direction the size of the radius from drive a decrease for spreads to turn the measures namely the degree that clutch separate decides.Change direction the clutch is simple because of the construction, manufacturing convenience, got the extensive application on the small scaled track in inside in earlier period type tractor, bulldozer.But because its manipulate the sex bad, produce the efficiency low, can consume bigger, enlarge continuously along with the track vehicle power, change direction the application of the clutch will suffer certainly of restrict.SingleBad soon the machine changes direction the organization[2,3] can make vehicle several why the speed of the center position still keeps in change direction process the original driving the car straightly is soon, being a When the complete system in side move, change direction the radius over small, but another side track speed over high, change direction the Cape speed over big, for this reason a power for needing changing direction power very bigly, would outrunninggenerally launching machine restrict, if the pilot keep on changing direction, have a little bit the immodesty and then will make launch the machine fire, as a result can depend to slip to whet, using than the greater half path changes direction, or pole is not fair and softly break to change direction continuously with the lesser half path.Therefore this kind of is single bad soon the machine change direction the organization to no longer adopt almost now.The speed that a speed for differing soon machine changing direction organization[3,4] can making track vehicle at changing direction slowly soon side track lowering is equal to the fast side track the increment, the for this reason vehicle changes direction of average speed and straightly the speed that drive same alike.But because a variety for badly soon machine can't completely system moving first side track, vehicle can't originally changing direction, and changing direction radius scope has no usage to change direction the clutch big, changing direction the going smoothly worse.While changing direction, the fast side track accelerates, therefore launching the affixture of the machine carry the ratio adoption change direction the clutch big.The double is bad soon the machine be constituted by wheel gear of change direction the organization, with change direction the clutch compare the spare parts number little, bear to whet the sex good, the life span is longer.The planet changes direction the organization[4,5] moves with the system from a planet a department the machine constitutes.The operation planet the system on the organization moves the machine can change two sides drives the round drives the dint size make vehicle changed direction.It is that type of to change direction the organization opposite in change direction the clutch change direction the organization can deliver the bigger changing direction the dint , can realize an athletic and fixed stalk wheel gear organization fall through of two free a planet for of flat-out decomposition with synthesizing, planet organization a three dollar as have the bad relating to soon; change direction the organization to much order to deliver the motive, and the internal path in organization faces the dint mutually equilibrium.But is complicated because of its construction, only industry in big power tractor, bulldozer and other heavy type vehicle last application.Single weakness thatpower change direction is obvious, vehicle only contain several fix of change direction the radius, press to rule not of change direction When the radius change direction, want to is slipped by friction a piece to whet to realize, and is hard to get the stability change direction the radius accurately; the next in order in change direction process rub a dollar piece of violent slip to whet to will bring to have fever with wear away, make spread to move the efficiency lower, especially in the big power change direction work appearance next, would exsit the bigger power lose, with the result that often need to be declined to change direction soon; moreover, the violent friction also make easy damage in organization, cause the work dependable bad, the life span lower.1.2 pairs of powerses flow to change direction the organization after launching machine, will launch the machine power be divided in to become soon with change direction two roads be juxtaposed to deliver, ising a double of powers to flow to change direction the organization.A power flows to change direction the organization will used for keeping the pushes forward of become soon the organization is different from result in leftly, the right side track speed differs of change direction the organization to be juxtaposed in spread move department, change direction the organization when the vehicle keeps the did not result in twoth the speed of side trackses are bad, while changing direction, became to flow each file of offering soon to drive the speed straightly with change direction the organization results in of two the speed of side trackses differ to remit to flow, realizing the vehicle change direction.(1)the machine type a power flow to change direction the organization to flow the foundation top that change direction the organization to appear at the earliest stage in the single power of was a machine to kept the with changed direction two powers flowed all from machinery to realized type a power to flowed to change direction the organization[3].It is this kind to change direction the organization main from two become soon box( a lord become soon the box, a cent moves a box of), the planet wheel gear organization, clutch moves with the planet organization system the machine constitutes, the single power flows to change direction in changing direction function the organization has the very bigincreasing, but it still change direction the radius is to have the class.The file is more low, getting of change direction the radius more small; the file is more high, getting of change direction the radius more big.Can't still adapt to the vehicle road in all different curvatures on the tactful track that change direction to drive with the demand, also can't expel parts of coalescences rub a piece proceeds to slip to whet to change direction and from slip to whet an a series of problem for bringing.(2)the machine liquid press type a power flows to change direction the organization machineThe type of changes direction the organization changes direction the function easily under the influence of the pilot's driver's technique, physical strength term moving the machine to wear away with the clutch, system, and bring the pilot the fatigue easily.Give or get an electric shock along with the machine the liquid press and technical development in engineering in machine in person, the machine type change direction the organization to will be eliminated on the big power tractor, bulldozer...etc. engineering vehicle necessarily.Press in the last additional liquid in system in machine the liquid of —that pump the motor presses the machine — liquid drives to press to change direction the system will get the application gradually.The machine liquid press type a power flows to change direction the organization[5,6] from launch the machine and change the deal pump, control valve, fixed amount motor, many files become soon box and empress bridges change direction to differ to move the organization constitutes.It will spread to flow from the machine that launch the machine power in many files became soon the importation stalk of the box last cent flow, all the way flow through was pressed by liquid pump- liquid press motor constitute of change direction adjust soon system; another all the way flow through many files became soon box, finally experienced star row top confluence, then was lined up by planet of some a the parts( such as planet) spread to the vehicle to spread to move the stalk top eventually.Because the liquid presses to pump to press with the liquid the motor can have no the class controls, therefore using the this type of changing direction the organization since can acquire the carAn a lot of weakness for twoth lateral speeds differing realizing having no class controling, again overcoming machine type changing direction organization.If the liquid presses the motor do not work, only coming from central spread the dynamic power flow, the vehicle makes the straight line drives; if only have the liquid that come from the power press the motor flows, the vehicle can realize to change direction radius as the zero changing direction originally; if input at the same time two road powers flow, because the liquid presses the motor can realize to have no the class controls, for this reason vehicle two side tracks drive the rotation to have soon and will barely do much more endless, can get the much more endless changes direction the radius, can immediately realize to have no the class changes direction, pilot as long as manipulate to change direction the dish turns to move the liquid presses the device, can make vehicle driven along the certain arc stablely.This kind of changes direction the organization not only have the construction good, have no the friction a piece, life span is long, the efficiency is high and work dependable, arrange simple, maintain the adjustment little and lower to can consume to wait the characteristics the outside, but also it is not a motive to pass the part or cut off all a side track in working function to the system move a the side drives a the round realizes to change direction of, but two side tracks deliver the motive always, can realizes nicely like this the motive change direction, basic ascend a safety for slippery phenomenon, being applicable to proceeding being partial to carrying pushing soil with cutting off root homework; at sloping fields changing direction can't appearing" conversing direction" phenomenon, increases vehicle that dissolves the track; because of changing direction do not cut off the motive, the average car of the for this reason vehicle does not lower soon; the track do not stop driving, breaking to the soil little, in loosenning soft soil of pass the sex good; change direction the size of the radius can control arbitrarily, increasing the flexibility of the track vehicle, change direction steady; change direction vehicle can develop with drive the high work in same function straightly; realizes easily a the root manipulates the pole to control in to back with change direction.2 change direction the pure liquid in trend(1)in development in organization press to have no the class changes direction the organization wants to realize the track vehicle changes direction the radius can control and continue to have no the class changes of change direction the function, the adoption capacity type liquid presses to pump to press with the liquid motor etc. has no the class become soon a piece is a more realistic viable method.The pure liquid presses to change direction the organization[7 9] of ~ss pass to pump of positive and negative two directions have no the class changes the deal regulates, realizing to launch the mobile dint was spread by double to move to change direction the road arrives to remit the popular star row has no the class changes of spreading and moving ratio, end realize the vehicle face or so two change direction laterally radius can continue to have no the class the variety keeps the , pass the liquid press to pump with the liquid press the motor shuts the lock( change the row that deal pump measureses for zero) to realize to change direction the zero to shut the lock axially, from but keeps to keep the stablely.Under the situation of becoming soon the organization hangs the blank on schedule to change direction, launch machine a power for sending out all to press from the liquid that change direction the road a piece deliver, can realize the vehicle change direction originally.The current liquid presses the industry level returns the hard getting the power enough and big and the good liquid in function presses a dollar an efficiency for, and the liquid presses the system low, this is the biggest obstacle that pure liquid press to have no the class change direction the technique develops.(2)the compound changes direction organization as to overcome the pure liquid presses the above blemish that change direction the organization, appearing now the small liquid in power in various adoptions press the liquid of a dollar piece presses the compound changes direction the project[7].A pump a motor project: this project is to solves the liquid press the direct and the most simple project in shortage in a power in a dollar, its function press with pure liquid to change direction same, but two sets of liquids press a piece merge to make the organization's physical volume weight bigger, the efficiency is still lower.The machine liquid presses to reunite the project: that project is adopting adouble of flowing the liquid press to change direction of at the same time, reserve a set of machines change direction the organization.Make use of the power not very of the liquid presses a dollar the piece realizes the greater half path changes direction of have no the class variety continuously; make use of the organization that machine change direction lesser half path realizes the class changes direction.This kind of change direction the organization falls through whole radius scope has no the class variety.A radius liquid presses to change direction the project: that project adoption contain two kinds of exportations soon the liquid that compare presses the motor, when the good road ascends to change direction adoption the higher exportation turns soon, native out of fix the hour then change to output with the low speed to overcome bigger changing direction the resistance.The liquid presses the liquid dint compound changes direction the project: that project presses with the liquid of the limited power a piece proceeds to have no the class changes direction, the help matches the machine accidentally at change direction the liquid press the motor dint not enough hour on time provide the help .That project although reduce the liquid press a piece efficiencies would be much lower.In fine, adopt the liquid press a dollar a point for having no class becoming soon characteristic to realizing track vehicle having no class changing direction is good choice, solving liquid pressing a dollar a power shortage then is low with the efficiency that direction is investigative.(3)the machine liquid presses the consecution has no the class changes direction the organization machine liquid presses the consecution has no the class changes direction the organization[10 21] of ~ss are in simple liquid pressing cent in machine spreading the foundation that move the principle, adopting the different machine organization parameter combine, and press with liquid a dollar the piece matches with of a kind of latest model changes direction the organization.It can guarantee at continue to have no the class output the next applied small liquid in premise that turn to press the total power in an exportation for significantly increasing vehicle in a dollar soon, and its spread to move the efficiency far far ahead pure the liquid presses to change direction theorganization spreads to move the efficiency.It represents the development direction that track vehicle change direction organization.The research develops the good machine in function liquid presses the consecution has no the class changes direction the organization, excellent turn to match the that type of turning. Construction parameter that face organization is the point lesson of the current vehicle engineering realm.履带车辆转向机构的研究现状及发展趋势1、转向机构的研究现状依据不同的分类方法,履带车辆转向机构可根据车辆在转向过程中功率流的传递方式分为单功率流转向机构和双功率流转向机构,也可根据在转向过程中两侧履带的运动有无联系而分为独立式转向机构和差速式转向机构。
Research on vehicle Control technology Using Four- wheelIndependent Steering SystemCHEN Si-zhong, SHU Jin,YANG LinJournal of Beijing Institute of Technology, 2006 ,15(1) :22~26对使用四轮独立转向系统的整车控制技术的研究陈思忠,舒进,杨林北京理工大学学报(英文版),2006,15(1):22~26对使用四轮独立转向系统的整车控制技术的研究陈思忠舒进杨林机械与车辆工程学院北京理工大学北京100086中国摘要:通过有效和独立的后轮控制来提高车辆的操控稳定性的技术已经提出。
首先,简要介绍配置四轮独立转向原型车。
然后详细地制定对四轮独立转向系统的电子控制器的整体设计。
四轮独立转向系统是在对质心零侧偏角控制策略的研究下得到的,它的建立是为了推断出分离的后轮转向角度的方程。
根据这些方程,对四轮独立转向车辆性能的仿真分析完成后,显示四轮独立转向车辆在低速的条件下可操作性大大提高,并且在高速条件下操纵稳定性增强。
最后,四轮独立转向车辆路试验证了模拟的正确性,表明了与传统的四轮的转向车辆相比,四轮独立转向不仅提高了车辆运动平稳性,也降低了转向阻力,减轻磨损轮胎。
关键词:四轮独立转向系统控制策略四轮转向系统中国图书馆分类号:U 270文件编码:A文章编号:1004-0579(2006)01-0022-05 最近几年,人们对四轮转向技术下的车辆操作稳定性研究产生了浓厚兴趣。
随着深一步的研究,四轮转向的问题变得越来越多的突出。
因为车辆转弯数学模型的推论往往是以自行车模型作为基础,这样就导致了两后轮转向角在转向时是相同的。
即使后轮转向制动器仅仅用于驱动一个拉杆联动,然而此联动的设计都是相当困难的,因为车辆瞬态转向中心引起后轮转向角连续变化。
所以,四轮独立转向系统是一个优秀的方法,他将运动平稳和四轮转向技术的优势结合起来。
(本文截取的是一篇国外学生的毕业论文中的一段论文名字是“A Comprehensive Thermal Management System Model for Hybrid Electric Vehicles”)The automotive industry is facing unprecedented challenges due to energy and environmental issues. The emission regulation is becoming strict and the price of oil is increasing. Thus, the automotive industry requires high-efficiency powertrains for automobiles to reduce fuel consumption and emissions. Among high-efficiency powertrain vehicles, Hy-brid Electric Vehicles (HEVs) are under development and in production as one potential solution to these problems. Thus, one of the most critical objectives of the HEV development is improving fuel economy. There are many ways of maximizing the fuel econo-my of a vehicle such as brake power regeneration,efficient engine operation,parasitic loss minimization,reduction of vehicle aerodynamic drag, and engine idle stop. Figure 1 compares the balance of the energy of a conventional vehicle with a hybrid electric vehicle。
外文原文:THE BRAKE BIBLEBrakes - what do they do?The simple answer: they slow you down.The complex answer: brakes are designed to slow down your vehicle but probably not by the means that you think. The common misconception is that brakes squeeze against a drum or disc, and the pressure of the squeezing action is what slows you down. This in fact is only part of the equation. Brakes are essentially a mechanism to change energy types. When you're travelling at speed, your vehicle has kinetic energy. When you apply the brakes, the pads or shoes that press against the brake drum or rotor convert that energy into thermal energy via friction. The cooling of the brakes dissipates the heat and the vehicle slows down. It's the First Law of Thermodynamics, sometimes known as the law of conservation of energy. This states that energy cannot be created nor destroyed, it can only be converted from one form to another. In the case of brakes, it is converted from kinetic energy to thermal energy.Angular force. Because of the configuration of the brake pads and rotor in a disc brake, the location of the point of contact where the friction is generated also provides a mechanical moment to resist the turning motion of the rotor.Thermodynamics, brake fade and drilled rotors.If you ride a motorbike or drive a race car, you're probably familiar with the term brake fade, used to describe what happens to brakes when they get too hot. A good example is coming downa mountain pass using your brakes rather than your engine toslow you down. As you start to come down the pass, the brakes on your vehicle heat up, slowing you down. But if you keep using them, the rotors or drums stay hot and get no chance to cool off. At some point they can't absorb any more heat so the brake pads heat up instead. In every brake pad there is the friction material that is held together with some sort of resin and once this starts to get too hot, the resin starts to vapourise, forming a gas. Because the gas can't stay between the pad and the rotor, it forms a thin layer between the two whilst trying to escape. The pads lose contact with the rotor, reducing the amount of friction and voila. Complete brake fade.The typical remedy for this would be to get the vehicle to a stop and wait for a few minutes. As the brake components cool down, their ability to absorb heat returns and the next time you use the brakes, they seem to work just fine. This type of brake fade was more common in older vehicles. Newer vehicles tend to have less outgassing from the brake pad compounds but they still suffer brake fade. So why? It's still to do with the pads getting too hot. With newer brake pad compounds, the pads transfer heat into the calipers once the rotors are too hot, and the brake fluid starts to boil forming bubbles in it. Because air is compressible (brake fluid isn't) when you step on the brakes, the air bubbles compress instead of the fluid transferring the motion to the brake calipers. Voila. Modern brake fade.So how do the engineers design brakes to reduce or eliminate brake fade? For older vehicles, you give that vapourised gas somewhere to go. For newer vehicles, you find some way to cool the rotors off more effectively. Either way you end up with cross-drilled or grooved brake rotors. While grooving the surface may reduce the specific heat capacity of the rotor, its effect is negligible in the grand scheme of things. However, under heavy braking once everything is hot and the resin is vapourising, the grooves give the gas somewhere to go, so the pad can continue to contact the rotor, allowing you to stop.The whole understanding of the conversion of energy is critical in understanding how and why brakes do what they do, and why they are designed the way they are. If you've ever watched Formula 1 racing, you'll see the front wheels have huge scoops inside the wheel pointing to the front (see the picture above). This is to duct air to the brake components to help them cool off because in F1 racing, the brakes are used viciously every few seconds and spend a lot of their time trying to stay hot. Withoutsome form of cooling assistance, the brakes would be fine for the first few corners but then would fade and become near useless by half way around the track.Rotor technology.If a brake rotor was a single cast chunk of steel, it would have terrible heat dissipation properties and leave nowhere for t he vapourised gas to go. Because of this, brake rotors are typically modified with all manner of extra design features to help them cool down as quickly as possible as well as dissapate any gas from between the pads and rotors. The diagram here shows some examples of rotor types with the various modification that can be done to them to help them create more friction, disperse more heat more quickly, and ventilate gas. From left to right.1: Basic brake rotor. 2: Grooved rotor - the grooves give more bite and thus more friction as they pass between the brake pads They also allow gas to vent from between the pads and the rotor. 3: Grooved, drilled rotor - the drilled holes again give more bite, but also allow air currents (eddies) to blow through the brake disc to assist cooling and ventilating gas. 4: Dual ventilated rotors - same as before but now with two rotors instead of one, and with vanes in between them to generate a vortex which will cool the rotors even further whilst trying to actually 'suck' any gas away from the pads.An important note about drilled rotors: Drilled rotors are typically only found (and to be used on) race cars. The drilling weakens the rotors and typically results in microfractures to the rotor. On race cars this isn't a problem - the brakes are changed after each race or weekend. But on a road car, this can eventually lead to brake rotor failure - not what you want. I only mention this because of a lot of performance suppliers will supply you with drilled rotors for street cars without mentioning this little fact.Big rotors.How does all this apply to bigger brake rotors - a common sports car upgrade? Sports cars and race bikes typically have much bigger discs or rotors than your average family car. A bigger rotor has more material in it so it can absorb more heat. More material also means a larger surface area for the pads to generate friction with, and better heat dissipation. Larger rotors also put the point of contact with the pads further away from the ax le of rotation. This provides a larger mechanical advantage to resist the turning of the rotor itself. To best illustrate how this works, imagine a spinning steel disc on an axle in front of you. If you clamped your thumbs either side of the disc close to the middle, your thumbs would heat up very quickly and you'd need to push pretty hard to generate the friction required to slow the disc down. Now imagine doing the same thing but clamping your thumbs together close to the outer rim of the disc. The disc w ill stop spinning much more quickly and your thumbs won't get as hot. That, in a nutshell explains the whole principle behind why bigger rotors = better stopping power.The different types of brake.All brakes work by friction. Friction causes heat which i s part of the kinetic energy conversion process. How they create friction is down to the various designs.Bicycle wheel brakesI thought I'd cover these because they're about the most basic type of functioning brake that you can see, watch working, and understand. The construction is very simple and out-in-the-open.A pair of rubber blocks are attached to a pair of calipers which are pivoted on the frame. When you pull the brake cable, the pads are pressed against the side or inner edge of the bicycle wheel rim. The rubber creates friction, which creates heat, which is the transfer of kinetic energy that slows you down. There's onlyreally two types of bicycle brake - those on which each brake shoe shares the same pivot point, and those with two pivot points. If you can look at a bicycle brake and not understand what's going on, the rest of this page is going to cause you a bit of a headache.Drum brakes - single leading edgeThe next, more complicated type of brake is a drum brake.The concept here is simple. Two semicircular brake shoes sit inside a spinning drum which is attached to the wheel. When you apply the brakes, the shoes are expanded outwards to press against the inside of the drum. This creates friction, which creates he at, which transfers kinetic energy, which slows you down. The example below shows a simple model. The actuator in this case is the blue elliptical object. As that is twisted, it forces against the brake shoes and in turn forces them to expand outwards. The return spring is what pulls the shoes back away from the surface of the brake drum when the brakes are released. See the later section for more information on actuator types.The "single leading edge" refers to the number of parts of the brake shoe which actually contact the spinning drum. Because the brake shoe pivots at one end, simple geometry means that the entire brake pad cannot contact the brake drum. The leading edge is the term given to the part of the brake pad which does contact the drum, and in the case of a single leading edge system, it's the part of the pad closest to the actuator. This diagram (right) shows what happens as the brakes are applied. The shoes are pressed outwards and the part of the brake pad which first contacts the drum is the leading edge. The action of the drum spinning actually helps to draw the brake pad outwards because of friction, which causes the brakes to "bite". The trailing edge of the brakeshoe makes virtually no contact with the drum at all. This simple geometry explains why it's really difficult to stop a vehicle rolling backwards if it's equipped only with single leading edge drum brakes. As the drum spins backwards, the leading edge of the shoe becomes the trailing edge and thus doesn't bite.Drum brakes - double leading edgeThe drawbacks of the single leading edge style of drum brake can be eliminated by adding a second return spring and turning the pivot point into a second actuator. Now when the brakes are applied, the shoes are pressed outwards at two points. So each brake pad now has one leading and one trailing edge. Because there are two brake shoes, there are two brake pads, which means there are two leading edges. Hence the name double leading edge.Disc brakesSome background. Disc brakes were invented in 1902 and patented by Birmingham car maker Frederick William Lanchester. His original design had two discs which pressed against each other to generate friction and slow his car down. It wasn't until 1949 that disc brakes appeared on a production car though. The obscure American car builder Crosley made a vehicle called the Hotshot which used the more familiar brake rotor and calipers that we all know and love today. His original design was a bit crap though - the brakes lasted less than a year each. Finally in 1954 Citroën launched the way-ahead-of-its-time DS which had the first modern incarnation of disc brakes along with other nifty stuff like self-levelling suspension, semi-automatic gearbox, active headlights and composite body panels. (all things which were re-introduced as "new" by car makers in the 90's).Disc brakes are an order of magnitude better at stopping vehicles than drum brakes, which is why you'll find disc brakes on the front of almost every car and motorbike built today. Sportier vehicles with higher speeds need better brakes to slow them down, so you'll likely see disc brakes on the rear of those too.译文:制动器制动器:它们的作用?简单的说:它会使你的汽车慢下来。
Locomotive 机车freight wagon货车passenger coach 客车multiple units动车组metro car 地铁车辆light rail轻轨railway service cars 铁路服务车Rail铁轨standard gauge标准轨距narrow gauge, broad gauge窄轨,宽轨Trackbed 道床Sleeper,枕木Crosstie 枕木 Ballast, subballast,道砟,底部道砟fastener紧固件Turnout道岔Derail(derailment)脱轨Crossing 平交道口colliery: 煤矿quarry:采石场flanged steel wheels:有凸缘钢轮copper ore:铜矿speak of:谈到,提及backbone:骨干bulk freight:散装货物mass commutation traffic: 大规模通勤运输short haul: 短途运输Merchandise traffic:货物运输Depreciation:(反-appreciation),减值,折旧,贬值Settling:沉降,沉积bulk freight:散装货物Subgrade: 地基,路基Soil stratum: 地层Embankment:堤坝Trim off:修剪Organic topsoil: 有机表层土Civil engineering: 土木工程Earthwork: 土方,土方工程Gravity wall:重力墙Drainage: 排水系统,排水装置Real estate:房地产,不动产Crane:起重机Tamper:捣固机Trolley:台车,手推车,电车Headway:进展,向目标前进Chapter 2 The TrainCoach, carriage,客车Monorail单轨Refrigerator wagon冷藏车High-speed railways高速铁路Maglev磁悬浮Open-topped wagon敞顶车Cog railway嵌齿铁路Rubber-tired underground橡胶轮地铁Siding旁轨,支线Freight train货运列车Passenger train旅客列车Heavy freight重载货运Sleeping car卧铺车Dining car餐车Run-around track调车线Inter-city train城际列车Local train管内列车,慢车Elctric traction电力牵引Stopper慢车Double-decked passenger train双层旅客列车Motor car (trailer car)动力车(拖车)Container集装箱车Tanker罐车Driving cab司机室TOFC平板拖车Box wagon棚车Coupler车钩Maintenance of way 道路维护Long-distance train长途列车Channel Tunnel海峡隧道parcel: package 包裹Travelling post offices:移动邮局Centrifugal force:离心力pram:婴儿车Wheelchair:轮椅Conurbation:有卫星城市的大都市elevated structure :高架结构Accelerate (decelerate): 加速(减速)Tram, trolley, streetcar:有轨电车Flexibility:机动,灵活Low loder:低架拖车Sneak into:偷偷地摸进Stow away:偷乘,搭白车Fatality:disasterKit:工具包,装备earn one‘s keep:值得雇用, 挣饭吃Show up:揭露,露出Dead end terminal:闭塞终端Buffer stop:止冲器Crossover:转辙轨Locomotive escape:机车折返Phase out:逐步淘汰,逐步停止Intensive service:auxiliary equipment:辅助设备, 备用设备, 附属设备Heavy maintenance:大修Whilst:时时,同时,whilePush-pull:推挽Interval service:Keep at forefront of:保持在……最前沿train loading:列车运载量Train capacity:列车运载能力Density of passengers:乘客密度Load factor:上座率Patronage:保护,光顾,赞助High degree of standardisation:高度标准化Headstock, end sill, pilot:end beamBellmouth:钟形口,喇叭口Line up:整队,排列Semipermanent coupler:半永久车钩Be bolted together:螺栓连接Cushioning:减震,缓冲Uncoupling:解钩,拆开(反,coupling)Buckeye, Knuckle and Janney coupler: 詹式车钩Coupler knuckle (jaw):钩舌Coupler head:钩头Hinge pin:折页销Fully automatic coupler:全自动车钩Disengage:脱离pneumatical:风力的,空气的Keep in good working order:保持正常运转状态Drawgear:牵引装置Bolt:螺栓Pedal:踏板Funicular: 索道Coupler alignment bar:车钩调直杆Pushbutton:按钮Shock absorber:减震器Multicore cable:多芯电缆Chapter 7 Railway Cars(1)Baggage行列车Coach客车Combine合造车Dome圆顶车 Lounge游乐车Dinner餐车Observation瞭望车Sleeper, sleeping car, Pullman卧铺车RPO铁路邮政车Housing car封闭车Autorack, auto carrier汽车运输车Boxcar, or van棚车Refrigerator car, reefer冷藏车Stock car牲畜车Open top car敞车Gondola敞车 Hopper漏斗车Ballast car砟车Flat car平车Depressed-center flat car凹底平车 Piggyback car背负式车Schnabel car钳夹车Tank car罐车Caboose守车Snow plow除雪犁Dynamometer car动力检测(试验)车Encompasss: 包围,环绕,构成,包括Listed in alphabetic order: 按字母顺序排列lining:衬里,衬套,内层,lined withContamination:污染,玷污Corrosive action:腐蚀作用Stainless steel:不锈钢Glass enamel:玻璃釉彩,搪瓷Pocket for stake: 柱插口Tie-down point:栓柱Manual brake equipment: 手制动Air brake equipment: 空气制动primary underframe: 主车架,主底架Cumbersome : 笨重的Intermodal shipping: 联合运输Tonnage:吨位log:木材,原木Lumber:木材Slope down:向下斜Scrap metal: 金属屑,废金属Aggregate:粒料,总计,聚集Wood chip:木屑,木片Drop end:落端门Shovel:铲Perishable freight:易腐货物spoiling: 变坏,损毁Insulation:绝缘层,保温层Keep out:Cooling system:冷却系统Cold brine:冷盐水Waterproof:防水的Airtight:密封的,气密的Warehouse:仓库,库房Breakage:破坏,破损Barrel:桶Drum:鼓型圆桶safety valve:安全阀Chapter 8 Railway Cars(2)For more information see/wiki/Passenger_car_(rail)Tilting train摆式列车Head-end equipment车端设备Branch line支线Air-conditioned hard seat car空调硬座车seating capacity定员Length between truck pivot centers车辆定距tare weight空重Clearance 间隙Wheelbase轴距Gauge轨距Constructional speed构造速度Wheel diameter车轮直径Stanhope:轻便马车en route:在途中Streamlined:流线型的Ornate:装饰的, 华丽的, (文体)绚丽的to date:到此为止Aluminum steel:铝钢,含铝钢evolve into:发展[进化]成Fluted:有凹槽的Conveyance:运输Row upon row:一排排,一行行carry-on:手提行李,手提的Aisle:走廊Partitioned into:分割,分隔开efficiency apartment:有小厨房和卫生设备的小套公寓房间,公寓小套间Interior:内部Galley:厨房Recede:后退,倒退,变得模糊Fell out of use: 开始不用,渐废Vantage:优势,有利情况Roofline:屋顶轮廓线Dumbwaiter:楼上楼下送饭菜的小升降机,可移动的上菜架或上菜桌Aluminum of high strength alloy:高强度铝合金pane:长方块, 尤指窗格, 窗格玻璃, 边, 面,方框Vestibule:门廊, 前厅Chapter 9 BogieRide comfort乘坐舒适性Irregularity轨道不平顺Wheel tread车轮踏面Suspension悬挂系统Tread gradient踏面锥度Flange轮缘Running performance运行品质Articulated bogies铰接式转向架Lower center of gravity低重心Swing hanger摇枕吊Bolster bogie摇枕转向架Bolsterless bogie无摇枕转向架Wheelset hunting轮对蛇行Anti-yaw damper抗蛇行减震器Suspension gear悬挂装置JR日本铁路Bogie frame构架Lateral damper横向减震器Traction transfer device牵引装置 Brake equipment制动装置Axle bearing and axle box轴箱轴承及轴箱Axle spring轴箱弹簧Brake disk制动盘Traction motor牵引电机Gear box齿轮箱,减速箱Wheelset轮对Traction force牵引力Air spring, air bag空气弹簧Side beam侧梁Coil spring圆弹簧Cross beam横梁Press welding压力焊Bearing轴承Support rigidity支撑刚度Pedestal swing spring type导框式定位Play,游间,游隙,摆动量Leaf spring板弹簧 IS typeIS拉板式定位Bending strength弯曲强度Unsprung mass(weight)Non-sprung mass簧下质量Axle beam type转臂式定位Cylindrical roller bearing圆柱滚子轴承Ball bearing球轴承Overhaul大修Nose suspension device轴悬,臂式悬挂装置Cardan driving device 万向轴驱动Torque converter变扭器Wheel tread brake踏面制动Disc brake盘型制动Brake shoe闸瓦Frictional heat摩擦热Brake pad制动闸片Motor braking动力制动Quill drive 空心轴驱动 Hollow shaft空心轴Gearwheel, driven gear从动齿轮Pinion, driving gear主动齿轮Electric locomotive电力机车Rail head轨头Reprofile镟修Wheel/rail interface轮轨关系Lubricant润滑物Flatted wheel车轮擦伤 Bogie transom转向架横梁Brake cylinder制动缸Parking brake停车制动 Heavy duty brake重载制动Frame mounted motor架悬式电机Lifting lug吊耳Gearbox齿轮箱Compressed air压缩空气WSP(wheel slide protection)车轮防滑装置Speed sensor速度传感器Pendulum (titling) bogie摆式转向架Service life使用寿命Design concept设计理念Running speed运行速度Maximum speed最大速度Lateral force横向力Transition curve过渡曲线Circular curve圆曲线Self-steering bogie自导向转向架Running stability 运行平稳性Forced steering bogie迫导向转向架Obscurity:隐蔽,偏僻,含糊Abrasion:磨耗In terms of:according toIn comparison to: 对比Be sensitive to:对……敏感Rotational resistance: 回转阻尼Harmonic:谐波, 和声, 谐函数Isolate …from…:隔离Be commercialized for: 商业化,商品化Welding technology: 焊接技术General structure:一般结构Rolled steel:钢材,轧制钢Seamless steel pipe: 无缝钢管Critical component:关键部件Corrugated wheel: 波形辐板车轮Susceptible to:易受影响的Mass imbalance:动量不平衡Resonance:共振Put into service:投入运营,交付使用Right angle cardan driving device:直角万向轴驱动装置Impede:stopForged steel:锻钢Porcupine:豪猪Rubber bushed links:用橡胶衬里的连杆Gearwheel:大齿轮In relation to: with regard to,关于,涉及,与……比较Degree of coning:锥度Squealing noise:尖啸Flange or rail greasing:轮缘或轨道油脂Slippage: 滑动Weled steel box format:焊接箱型结构Press against: 压向Neutral section:分相区Leading bogie:导向架Chapter 10 Vehicle SuspensionVehicle suspension车辆悬挂系统Cushion system缓冲系统Laminated steel spring板弹簧Axle load轴重Carrying load载重 Spring hanger弹簧吊Spring lank弹簧托板Swing link吊杆Side frame侧架,侧梁Side bearer (bearing)旁承Center bearing下心盘Equalizer bar suspension均衡梁式悬挂系统Commonwealth bogie均衡梁式转向架Levelling valve高度调节阀Solid rubber suspension pack橡胶堆悬挂系统Parlance:idiom,谈话,说法,用法Take the form of leaf steel spring: 采用板弹簧型式Securing strap:保护带,安全带Be left out for simplicity: 为简便起见,不显示(去掉)……End on:从一端看,从端面看,一端向前地Rivete:铆钉,固定Side view:侧视图Simplified diagram:简图Sideways movement:侧面运动Reversal:逆转Durability:耐久性, 耐用性; 坚固Axle box yoke:轴箱轭Rubber Chevron:V型橡胶Boarding and alighting:上车,落下Intermittent gentle hissing:断断续续的轻微的咝咝声Alight from:走下来,下车Chapter 11 BrakingKinetic energy动能Air brakes or pneumatic brakes空气制动Brake pipe列车管,制动管Compressor空气压缩机Main reservoir主风缸Driver’s brake valve司机阀Equalising reservoir均衡风缸Feed valve给气阀;进给阀Angle cock截断塞门,折角塞门Hose橡胶软管(制动软管)Auxiliary reservoir辅助风缸Triple valve三通阀Brake cylinder制动缸Brake block闸瓦Relay valve延迟阀Fail safe 失效安全F riction material摩擦材料Composition material复合材料Brake rigging制动装置 Rate of application制动倍率Slide valve滑阀Graduating valve递动阀,节制阀Regulating valve调整阀,调节阀Propagation rate制动波速Distributor分配阀Diaphragm,膜片Throttle节流阀slack action列车冲动E-P brake电空制动Dynamic braking动力制动Rheostatic braking电阻制动Regenerative braking再生制动Psi:Pounds per square inch磅/平方英尺Replenished:补充Trigger:打开,激发,引起Distributor:分配阀Sophisticated:复杂的Choke:阻气门Inshot:跃升装置; 跃升time lapse:时滞, 时延Elusive:令人困惑的; 油滑的; 难记忆的Spur:踢马剌, 剌激物, 刺激Essential ingredient:关键因素Thyristor:闸流晶体管; 半导体开关元件; 可控硅; 硅可控整流器Circuitry:电路, 线路Resistor:电阻器Power electronic:电力电子Chapter 12 Depots and WorkshopsSliding door滑动门,塞拉门Routine examination常规检查Consumable易损易耗件Maintenance regime维修体制Existing railway既有铁路Maintenance management维修管理Interchangeability互换性Operating pattern运行模式Converging聚集,会合Marshalling编组Electrified railway电气化铁路current collection equipment吸流装置Audit审计Performance indicator绩效指标maintenance standard维修标准Common sense: 常识Revisit:再访, 重游, 重临Draw on:戴上, 吸收, 利用, 引诱, 向...提取, 招来, 临近Rectify:矫正, 调整Progressively adverse effect on:日益增加的反作用Morale:士气,民心Upholstery:室内装潢Clomatic condition:天气条件Of equal importanceChore:家务杂事Contractual:契约的Good access to components:零部件的易接近性Superfluous:多余的, 过剩的, 过量的Watertight:不漏水的, 水密的Thwarted:反对; 阻挠, 挫败, 妨碍Overlook:俯瞰, 耸出, 远眺, 没注意到Refitting:整修, 改装premise:房产; 房屋Planning stage:计划阶段Termini:目的地, 界标,terminus 的复数Converging:集中,收敛,会聚Proximity:接近, 亲近Jack:插孔, 插座, 起重器, 千斤顶, 男人Inspection pit:检查坑Walkway:走道, 人行道Wheel turning facility:车轮加工设备Constructed wash roadDe-icing arrangement:防止结冰, 装以除冰装置, 除冰Fire alarm:火灾报警Chapter 13 Developing Maglev TrainsMagnetic field磁场Maglev磁悬浮Propulsion推进Levitation 悬浮Guidance导向Attractive force吸引力Ferromagnetic 电磁铁的Magnetic repulsion磁力推进Superconducting magnet超导磁体Linear motor线性电机Magnetizing rail磁化轨道Payload weight负载Dynamic load动载荷Electrodynamic suspension, EDS电力悬浮Electromagnetic suspension, EMS电磁悬浮No consensus exists on:Levitate: (使)轻轻浮起, (使)飘浮空中Cryogenics:低温学Linear synchronous motor: LSM同步直线电机Linear induction motor:LIM直线感应电机Gas turbine:燃气涡轮Turboprop:涡轮螺旋桨发动机Concurrently:同时发生的事件,并发的, 协作的, 一致的Availability crisis:Metropolitan:大城市Turbulence:骚乱, 动荡, (液体或气体的)紊乱HSGT,high-speed Ground Transportation ACT:FRA: Federal Railroad Administration 联邦铁路管理局[美]Chapter 14 Power Supply of Electric TractionPower supply供电 Electric traction system电力牵引系统 Overhead wire接触网Power transmission电力传输Third rail第三轨Collector受流器Pantograph受电弓 Return circuit回路 Substation配电站Earthing protection接地保护Signalling circuit信号电路Catenary接触网Dropper吊线Electric arc电弧Mast柱子Booster transformer, BT吸流变流器Return wire回流线Track magnet轨道磁铁Neutral section分相区Communication cable通信线缆Pigtail引线Diaper:尿布In parallel with:与...平行, 与...同时, 与...并联Microprocessor: 微处理器Grip with:掌握,理解Electrolysis: 电解Insulated:绝缘的,insulation, insulatorManhole: (锅炉, 下水道供人出入检修用的)人孔, 检修孔At one’s peril:由某人自担风险Take precautions to do:采取防范措施Aggravate:使恶化, 加重Stitching:用U字钉钉箱, 缝纫Sag:松弛, 下陷, 下垂, (物价)下跌, 漂流Evacuate:疏散, 撤出, 排泄Visual intrusion:视觉障碍,妨碍Chapter 15 The Light Rail Transition CBI英国工业联合会Urban transport policy城市交通政策Urban sprawl城市扩张Light rail轻轨Road transport路面交通Steep gradient大坡道sharp curve小半径曲线Criteria标准Congested urban area:拥挤的城市区域House of Commons Transport Committee:上议院交通委员会Congested:拥挤的Pedestrians:步行者Cyclists:骑脚踏车的人Public transport user;公共交通使用者Motorists:乘汽车者AMA:Association of Metropolitan AuthoritiesIntractable:难处理的Down-marketed:价廉质次的, 低档市场的Park and ride:停车换乘Pollutant:污染物质Resurgence:复苏Overambitious:野心太大的Tyne:泰恩河Underutilized:为充分利用的Newcastle:纽卡斯尔。
Unit 1 Automo bileBasicssparewheel备胎lubric ate 润滑(名词是lub ricat ion)gearbo x 变速箱frame车架transm issio n 变速器hood 发动机罩(=bonnet)→ deckli d = trunkl id 行李箱盖chassi s ['ʃæsi] 底盘cranks haft曲轴carbur etor[,kɑːbjʊ'retə] 化油器sparkplug 火花塞clutch离合器drives haft传动轴drivetrain传动链petrol eum [pə'trolɪəm] 石油propan e 丙烷gasoho l 酒精混合燃料Unit 2 Bodiesbracke t 支架labyri nth ['læbərɪnθ]迷宫cross-member横梁interp ositi on 干涉steeri ng wheel方向盘three-box car 三厢车hinge铰链bumper保险杠windsh ield挡风玻璃windsh ieldwiper雨刮器interi or trim 内饰instru mentpanel= dashbo ard 仪表盘safety belt 安全带unibod y 承载式车身rubber bush 橡胶衬套vibrat ion 振动ancill ary 辅助的stress应力fender翼子板curb weight整备质量intake duct 进气道fatigu e 疲劳demist除雾loudsp eaker扬声器Unit 3 Engine ssprock et 链齿轮cylind er 汽缸connec tingrod 连杆valve气门camsha ft 凸轮轴lifter挺杆rocker arm 摇臂valvetrain配气机构Unit 4 Fuel System clamp夹具fuel rail 油轨intake manifo ld 进气歧管exhaus t manifo ld 排气歧管thrott le 节气门squirt喷射hothou se 温室Unit 5 Electr ic System circui t 电路coil 线圈igniti on 点火altern ator发电机ammete r 安培计voltag e regula tor 稳压器insula tion绝缘distri butor分电器transi stor晶体管fuse 保险relay继电器headli ghts大灯dome light顶灯fog lamp 雾灯dash 仪表板haloge n 卤素filame nt 灯丝LED(LightEmitti ng Diodes)发光二极管Unit 6 Coolin g and Lubric ating System s wear 磨损contam inati on 污染coolan t 冷却液radiat or 散热器thermo stat节温器grill格栅,进风口centri fugal force离心力centri petal force向心力boilin g point沸点overfl ow tube 溢流管wax 蜡oil filter机油滤清器oil pan 油底壳oil galler ies 油孔sealin g 密封nozzle喷嘴meshin g gear 啮合齿轮bearin g 轴承horsep ower马力Unit 7 Exhaus t and Emissi on Contro l System header pipe 集气管three-way cataly tic conver ter 三元催化转化器cataly st 催化剂muffle r 消音器hanger挂钩heat shield隔热板heavy-duty 耐用的,重负荷的fume 烟hydroc arbon碳氢化合物evapor ate 蒸发(名词后缀是-ion)additi ve 添加剂coupli ng 连接器gasket垫圈odorle ss 无味的positi ve crankc ase ventil ation曲轴箱强制通风grove沟槽oil dipsti ck 油尺vacuum valve真空阀charco al canist er 活性炭阀idle speed怠速EGR(Exhaus t Gas Recirc ulati on)废气再循环platin um 铂pallad ium 钯rhodiu m 铑cerami c 陶瓷的honeyc omb 蜂窝状Unit 8 Suspen sionSystem, Steeri ng System and BrakeSystem passen ger cars/vehicl es 乘用车commer cialcars/vehicl es 商用车bump 路面凸起alignm ent 校准steeri ng knuckl e 转向节swivel旋转spring弹簧(sprite雪碧)ball joint球型接头shockabsorb er = damper减震器bounce谈起bushin g 衬套non-indepe ndent suspen sion非独立悬架recirc ulati ng call steeri ng system s 循环球式转向器rack-and-pinion steeri ng system s 齿轮齿条式转向器lorry货车(也有卡车的意思)worm gear 涡轮蜗杆机构steeri ng linkag e 转向连杆steeri ng column柱pitman arm 转向摇臂trackrod 转向横拉杆idlerarm 随动臂sleeve衬套master cylind er 制动主缸lever杠杆brakebooste r 制动助力器engine compar tment发动机舱housin g 外壳,壳体malfun ction故障,失灵cable线缆calipe r 卡钳brakepads 摩擦片hub 轮毂squeez e 压缩brakeshoe 制动蹄Unit 9 DriveTrains and Axlesdriveaxles驱动桥MT(Manual Transm issio n)手动变速器AT(Automa tic Transm issio n)自动变速器CVT(Contin uousl y Variab le Transm issio n)无级变速器statio nary静态的releas e bearin g 分离轴承clutch fork 离合器拨叉pressu re plate压盘tensio n 张力hydrau lic circui t 液压回路throw-out bearin g = releas e bearin g 分离轴承torque conver ter 液力变矩器fricti on 摩擦synchr onize r 同步器shiftlinkag e 换挡连杆机构stator导轮planet gears行星齿轮planet gear carrie r 行星架ring gear 齿圈slip yoke 滑动叉differ entia l 差速器axle housin g 桥壳unspru ng weight簧下质量sprung weight簧上质量Unit 10 Safety, Securi ty and Naviga tionSystem s occupa nt = passen ger乘员buckle安全带插扣impact碰撞regula tory法规nylon尼龙stiffn ess 刚度abrasi on 磨损kineti c 运动学的inerti a 惯性trigge r 触发器resist er 电阻GPS(Global Positi oning System)全球定位系统补充:assemb ly line装配线stabil izerbar横向稳定杆cylind er block气缸体cast iron/alumin ium 铸铁/铝turboc harge涡轮增压superc harge机械增压exhaus t pipe 排气管displa cemen t排量compre ssion ratio压缩比valveoverla p 气门重叠thrust washer止推垫圈ductil e iron 球墨铸铁consta nt veloci ty joint等速万向节SUV(SportUtilit y Vehicl e)运动型多功能车常见品牌:Toyota丰田Honda本田Nissan日产Mazda马自达Lexus雷克萨斯Suzuki铃木Mitsub ishi三菱Genera l Motors通用Cadill ac 凯迪拉克Lincol n 林肯Ford 福特Chrysl er 克莱斯勒Corvet te 克尔维特Merced es [mə'sidi:z] Benz梅赛德斯-奔驰Volksw agen大众Audi 奥迪RollsRoyce劳斯莱斯Bentle y 宾利Ferrar i 法拉利Masera ti 玛莎拉蒂AstonMartin阿斯顿马丁Jaguar捷豹Porsch e 保时捷Lambor ghini兰博基尼Koenig segg柯尼塞格Bugatt i 布加迪Pagani帕加尼Alfa Romeo阿尔法罗密欧Volvo沃尔沃Lotus莲花Renaul t 雷诺Hyunda i 现代Peugeo t 标志Opel 欧宝Fiat 菲亚特Skoda斯柯达Citroe n 雪铁龙Dodge道奇。
TransmissionsTransmissions have to compromise on either ride comfort or efficiency, but a new approach to the dog engagement gearbox could improve both.With tightening emissions regulations, carmakers are not just confining their efforts to improving combustion and after-treatment. Many are finding that modern engines are so advanced that the benefits of some engine technologies are small compared to the huge development costs involved.It's important to look at the whole vehicle in order to improve emissions. As the second most expensive piece of kit in the car, the transmission is the logical next place to look.Of all transmission technologies, the manual gearbox is the most efficient; around 96percent of the energy that is put in comes out of the other end. But not everyone can drive one or wants to. Because you have to dip the clutch pedal, it's less comfortable to drive in heavy traffic. It makes the driver tired and the torque interruptions' head-nod effect on passengers can be wearing.The driver's clutch control and corresponding torque interruptions are also the manual's weak point. When accelerating up through the gearbox, each up-shift requires the driver to cut the torque momentarily by lifting the gas pedal and dipping the clutch. It may just take a second to complete the operation, but during this time the vehicle is losing speed and acceleration.At the opposite and of the spectrum is the traditional automatic. Its shift quality is good thanks to its torque converter, but efficiency is relatively poor despite recent advances. Because of this ,a lot of the current research is trying to find an efficient alternative to the conventional automatic.The main technologies are continuously variable transmissions (CVTs); dual clutch transmissions(DCTs) and automated manual transmissions(AMTs).They all offer different benefits over the conventional planetary automatic.The CVT uses a belt chain or toroidal shaped dish drive to vary an infinite number of gear ratios. It has improved efficiency and cost when compared to conventional automatics.Its advantage comes from its simplicitu. It consists of very few components; usually a rubber or metal-link belt; a hydraulically operated driving pulley, a mechanical torque-sensing driving pulley, microprocessors and some sensors.The transmissions works by varying the distance between the faces of the two main pulleys.The pulleys have V-shaped grooves in which the connecting belt rides. One side of the pulley is fixed axially; the other side moves, actuated by hydraulics.When actuatec, the cylinder can increase or reduce the amount of space between the two sides of the pulley. This allows the belt to ride lower or higher along the walls of the pulley, depending on driving conditions. This changes the gear ratio. A torodial-type design works in a similar way but runs on discs and power-rollers.The "stepless" nature of its design is CVT's biggest draw for automotive engineers. Because of this, a CVT can work to keep the engine in its optimum power range, thereby increasing efficiency and mileage. A CVT can convert every point on theengine's operating curve to a corresponding point on its own operating curve.The transmission is most popular with Japanese carmakers and Japanese supplier JATCO is a major producer. But in the US and Europe driving styles are different. Uptake has been slow despite Audi and other manufacturers having offered CVT otions on their ranges.The DCT is, in effect, two manual gearboxes coupled together. Gear shifts are made by switching from one clutch on one gearbox to another clutch on the other. The shift quality is equal to a conventional automatic, but slip, fluid drag and lydraulic losses in the system result in only slightly improved efficiency and acceleration over the conventional planetary automatic. Developing the control strategy is costly too."Recent advances in conventional automatic technology have weakened the argument to develop and set up production for CVT or DCT." says Bill Martin, managing director of transmission firm zeroshift. "Some carmakers have cancelled DCT projects because of the cost."The cheapest way to build an automatic is with an AMT. AMTs use actuators to replace the clutch pedal and gear stick of a conventional manual. They keep the high efficiency and acceleration of a manual gearbox, but the shift quality on some models is lacking. Torque interruptions and the head-nod effect are the most common complaint.so what is the alternative? There are always new ideas in transmissions, but Zeroshift says that its technology has efficiency benefits over a manual, delivering fuel economy improvements to city driving. Shift quality can also be equal to that of a refined automatic.Zeroshift's approach is an upgrade to the AMT. The synchromesh is replaced with an advanced dog enqaqement system.Dog engagement has been used for many years in motor sport to allow fast shifts. Conventional dog boxes are unsuitable for road use as the large spaces between the drive lugs or "dogs" create backlash, an uncomfortable shunt caused by the sudden change in torque direction.Zeroshift's technology solves this problem by adding a second set of drive dogs. It has also made each of the two sets of dogs only capable of transmitting torque in one or other opposing directions. "By controlling the engagement and disengagement of the two sets you can shift into the new gear befor disengaging the previous gear, "says Martin. "The shift quality is smoother than a typical modern six-speed automatic luxury car."The shift is instant and the torque is not interrupted.This philosophy is used for both up and down shifts."In conventional AMT there is an emissions spike during a shift due to the need to back off and reintroduce throttle, this is eliminated by going seamless, "says Martin. "This also reduces fuel consumption."It is a relative newcomer to the transmission sector, but the firm says that it is already attracting the attention of major European and US carmakers. The big draw is as a low-cost alternative to DCT, says Martin.Because the manual gearbox architecture is largely maintained, production costs and complexity are not greater than for a conventional AMT. Development of the controlsside is also considerably cheaper. Music to the ears of engineers trying to cut emissions and costs."Most of the carmakers have seen the system at least once," says Martion. "Some signed us immediately. Some have said not yet. None have said no. "That may be the clearest sign yet that when it comes to powertrain developments, carmakers are starting to focus on the transmission.HOW ZWROSHIFT WORKSThe hardware consists of two sets of bullets. mounted and actuated on two independent bullet rings. both sets of bullets run on the common hub, which is attached to the shaft with splines.Each bullet has a special profile. On one side they have an angled face for engagement. These are diagonally opposed, allowing the bullet to have a drive function for one gear and an overrun function for the other gear. The engagement faces taper backwards slightly to ensure the bullet latches onto the engaged gear under load.the opposite corners have a ramp, which pushes the bullet out of the previous gear once the new gear has been engaged.In neutral both bullet rings are positioned midway between the ratios. To select first gear, the bullets are moved into mesh with the engagement dogs.The bullets are actuated via shift forks conected to the shift actuators.The driving bullets lock first gear to the output shaft and transfer torque from the gearwheel onto the output shaft. The first gear overrun bullets are also moved into gear to lock the wheel to the output shaft in the opposite direction. This transfrs torque from the gearwheel onto the output shaft when the throttle closes and the engine overruns. This eliminates the backlash you'd expect from a dog engagement gearbox.To shift up with an open throttle, first gear's overrun bullets are unloaded and move in to engage second gear. This is followed by the previous driving ring which becomes unloaded when second gear is taken up.If the bullet is stopped from engaging fully-dog-face to dog-face-the second gear wheel opens an engagement window due to the relative speed difference. With the bullet pushed against the engagement dog compliance between the fork and actuator allows the stored energyto fire the bullet into the window.The first gear overrun bullets have now become the second gear drive bullets. As second gear takes over, the load is removed from the first gear drive bullets. These bullets are now no longer held by their retention angie and can be either moved out of gear by actuators or pushed out of gear by contact with the ramp face of the bullet.The first gear drive bullets then move across into engagement with second gear. In second gear, the roles of the bullets are reversed.Audi RoadjetAudi plans to add comfort, luxury and practicality without increasing emissionsThe Roadjet concept, first shown at Detroit in January 2006,indicates a number of technical directions that Audi going to take in the coming year. The firm is focusing on interior design, powertrain, chassis, electronics and safety innovations.These new directions will help Audi strengthen its position in the sub-luxury market that it previously had to itself. Audi has two main tactics to attract new customers in the US. It is breaking into the sports utility vehicle(SUV)and compact utility vehicle(CUV)markets.It also introduces new luxury and lifestyle features to strengthen its position in the US; sales there still lag behind those of BMW, Lexus and Mercedes-Benz. The recently launched Q7 off-road luxury vehicle is a late bid to capitalise on the SUV boom.In Europe, the carmaker's technical innovations such as aluminium construction, four-wheel-drive, and novel powertrain technologies have been successful. But if Audi wants to increase its US market share, it needs to innovate in those areas valued by American customers: comfort, luxury and practicality.Audi's designers have focused on this in the interior. They have devised a new wrap-around instrument panel shape to replace the more functional design in existing models. They have expanded the vehicle's multi-media interface (MMI)control system, used for cruise control, suspension, climate and entertainment separate controls. Combined with an upgraded climate system, occupants can set their own individual climate settings.Soft, warm, earthy colours are used in the Roadjet to create a feeling of well-being. The concept uses high quality functional materials: the upholstery is fine leather; the floor is neoprene. The space between the rear seats can house a range of optional equipment: the show car featured an espresso coffee machine. Storage boxes and baby carriers are more realistic alternatives.To enhance practicality, the rear seats slide backwards and forwards diagonally to increase shoulder and leg-room or rear load space. When the rear seats are in their most forward position, an oblique-facing child seat can be used behind the seats.Roadjet's load bay features an eletrically extending load floor to ease loading, offering unmerous lashing points to secure luggage items. The sliding seats and extending load floor are very likely to enter production on Audi's Q5 and A4 models.To heighten the sense of luxury, the concept uses a costly 1,000W Bang & Olufsen sound system with 14-speakers.This incorporates a "digital voice support" function that uses microphones and the car's speakers to pick up and amplify passengers' voices to ensure clear conversation even at high speeds.In a bid to improve road safety, convenience and traffic management, carmakers are working to common standards to develop a new in-car system to talk to other cars and roadside wireless olcal area networks. In traffic jams, bad weather or accident situations, cars send information to emergency services, other cars and traffic computers. The Roadjet concept featres previews such a system.The weight of all the new electronics and luxury equipment in this segment, combined with customers' growing demand for power is having a negative effect onexhaust emissions and fuel consumption. Audi is looking at sophisticated technical solutions to balance the equation.Roadjet's 3.2-litre gasoline direct injection engine is based on an existing engine but features a new fixed intake manifold with an integral vacuum reservoir to increase its output. This is combined with a two-stage cam operated variable valve lit technology to increase output.Despite the sports car performance, the Roadjet's overall fuel consumption is slightly lower than the current A4 Quattro 3.2FSI.The valve train technology, due to enter production later in 2006,lets the engine perform economically and smoothly during normal driving, switching automatically to more responsive, more powerful characteristics when the driver demands.Roadjet also has the first Audi application of speeddependent variable ratio dynamic steering for a stable highspeed motorway ride but with enhanced control on twisty country roads. Electronically-controlled variable rate dampers automatically adjust from soft and comfortable to firm and sporty to enhance safety and handling.Audi's engineers have electronically linked all of these systems to create three driver-selectable programmes: dynamic, comfort and sport. Each programme adjusts the dampers, steering, gearbox and engine eletronics to give different driving experiences.Roadjet's body styling marks a new direction for the carmaker.At 1.55m high with a wheelbase 4.7m long and 2.85m wide, the concept is roomy. The firm has used a combination of sharp feature lines and careully-sculpted concave-section doors to disguise the height. While the trademark LED tail lights are likely to enter production unchanged, steerable xenon gas discharge lights will replace the LEDs in the headlamps.Around the end of 2007 Audi will launch the Q5 CUV, based on the next A4 platform. Smaller and lighter than the Q7,it will be well placed to compete in the profitable CUV segment in the US. The Roadjet previews elements of the interior and exterior styling of this model.The Q5 will need to be more rugged to match the outdoor lifestyle image of the CUVsegment. At the same time, for the European market, the Roadjet's sharp style previews the next A4 model range, which may produce a new hatchback body in 2007 to join the conventional saloon and Avant estate. The dashboard and other new interior refinements are likely to spread across the rest of the Audi range over the next 24 months.变速器变速箱通常不得不在舒适性和效率之间做出选择,但一种新型的“犬牙啮合式”变速箱可以同时改善这两种性能。
外文原文McPherson model of the independent suspension McPherson front suspension in the car on the other is the breadth of application of the hoisting second to none. To the big BMW M3, Porsche 911 such high-performance cars, small Fiat STILO, Ford FOCUS, even before China's Hafei van Maifuxunshi hoisting and are based on the design. What is the reason in the end allow the hoisting of the McPherson such wide application This so commonly used hoisted in the end what characteristics it » We start with the design of structural understanding from the bar. Diagram below is a typical example of the hoisting of the McPhersonConstruction of theⅠ-1:Figure Ⅰ -1 McPherson hoisted chartMcPherson usually hoisted by two basic components: A pillar of shock absorbers and fonts care arm. The reason is because it is the pillar of shock absorber damping is also available in addition to supporting the role of the whole body, his structure is compact, the shock absorber damping and spring together to form a movement from top to bottom can slip column; under A boom is usually entrusted the design fonts, for the wheelsto provide some of the lateral support and direction to bear all the stress before and after. The weight of the entire body and vehicle movement to bear all the wheels on the impact of these two components * commitment. So McPherson one of the greatest features of the design is simple, simple structure will bring direct benefits of the two that is: the hoisting of light weight and small space. We know that the car belongs to the hoisting of moving parts, moving parts the light, then hoisted response rate of speed and resilience will be sooner, so the hoisting of the shock absorption capacity of more strong and reduce the quality of the hoisting of spring also means reducing the quality, then in Body weight certain circumstances, the comfort is also better. Space on the direct benefits of the designer is in store layout engine under greater engine and the engine can be placed arbitrary manner. In medium-sized car engine can be put aside large, small car in the medium can also lay down their engines, so that all the matching engine more flexible.We allKnow, the BMW inline six-cylinder engine is designed, in the pursuit of sport, the layout of its center of gravity in the front axle, so the engine to use up a lot of warehouse space of the engine, then the choice of a simple structure, the hoisting of the small space It is by design is important. McPherson suspended from the upward journey, that is, in the event to roll, wheel angle, will automatically increase, so that tires can better integrate with the road, the vehicle to provide greater lateral force, to improve the Control limit. Have excellent control and responsiveness coupled with the tight structure, it is clear on a BMW designers before hoisting the preferred option. For small cars and mini-cars, as far as possible in a small engine stores make room layout engine becomes even more important, so they have no choice but to select McPherson hoisted Moreover, if a reasonable match, McPherson Whether manipulation and comfort are very good. That so much has been hoisted at the merits of McPherson, the talk about the shortcomings. It is also precisely because McPherson is too simple structure, causing the hoisting of the stiffness limited. As McPherson hoisted only * care arm and shock absorber to withstand a strong pillar of the wheel impact, it is easier in geometry deformation. This deformation of the driving experience, isthat motorists will obviously feel the stability of poor body. Whether turning roll or brake nod phenomenon, are very obvious. Of course, the designers also like a lot of ways to solve the problem of instability. We have often heard that the horizontal Wending Gan, the anti-roll bars, balance, etc.-are used to increase the hoisting of Mai Fu's geometric stiffness and lateral stability of the components.However,Wen Dinggan optical increase by improving the performance is limited,the use of Wending Gan design can improve the stability of certain extent,geometry and suspension stiffness. If in order to fundamentally solve these problems, we must change the hoisting of the geometric shapes, and then multi-link double-rocker hoisted on behalf of the hoisting of a high-performance. McPherson addition to the hoisting of stability and rigidity in regard to inferior to multi-link, on the durability and multi-link can not be hoisted at par. As McPherson hoisted pillars need to bear the shock absorber of the horizontal, from top to bottom at the same time a campaign to reduce the purpose of vibration, shock absorber supporting bar the friction is very uneven, shock absorber oil seal to wear a hydraulic oil Damping effect of reducing leakage.中文译文麦弗逊式独立悬架的模式图麦弗逊在汽车前悬挂上的应用之广是其他悬挂无法比拟的。
车辆工程专业——外文文献翻译(中英文翻译)附录Ⅰ(原文)Modern cars is not a simple means of delivery, it is already "people, cars and the environment," the combination. As a car seat directly support the user's device, the car has no small importance of the components. The main function of car seats for the driver to provide ease of manipulation, comfortable, safe and easy fatigue of the driver seat. Seat design should also meet the following five basic requirements: the seat of the rational arrangement; Second, the seat shape to meet the body's physiological function; Third, the seat should have the regulatory agencies; Fourth, the vibration characteristics of a good seat; Five seats to be very safe and reliable; eat size of the installation location is important, it directly affects the user's convenience and comfort. Seating layout should reflect the requirements of ergonomics. Driver's seat is the most crucial seats. Its basic requirement is a reasonable layout and simple operation, that is, when the drivers take on the steering wheel, joystick and pedals for good accessibility. Because differences in European, American and Asian body in some countries is very wide car seat, car seat in some countries is relatively small. As the crowd the same area, there are differences between men and women, the tall and the small differences in driver's seatmust have regulatory agencies to meet most people's body. "Most people" concept, the car body design used a two-dimensional model, which according to the height of its total population is divided into different groups: Seat size of the installation location is important, it directly affects the user's convenience and comfort. Seating layout should reflect the requirements of ergonomics. Driver's seat is the most crucial seats. Its basic requirement is a reasonable layout and simple operation, that is, when the drivers take on the steering wheel, joystick and pedals for good accessibility. Because differences in European, American and Asian body in some countries is very wide car seat, car seat in some countries is relatively small. As the crowd the same area, there are differences between men and women, the tall and the small differences in driver's seat must have regulatory agencies to meet most people's body. "Most people" concept, the car body design used a two-dimensional model, which according to the height of its total population is divided into different groups: 5[%] (all 5[%] of drivers in the short stature than or equal to this size, the remaining 95[%] taller large); 95[%] (all 95[%] of drivers in the short stature than or equal to the size of the remaining 5[%] taller large). Applied in the automotive industry in the total range of between 5[%] and 95[%], that is, including the 90[%] crowd. For example, adjustable seats and pedals designed distance between the drivers as much as possible to adapt body, where women generally take 5[%] and 95[%] of male body model.Driver's seat on the steering wheel, joystick and pedals to take the body and determines the position, posture, seating arrangement by the position and shape of the design of the decision. Drivers to take the posture is not ideal or even lead to fatigue and strain. Therefore, Japan and major European and American design of the depot location has the basic drivers seat position, head, shoulders, arms, abdomen, legs and other reference data space, can not be arbitraryCar seats from the seat, back, dorsal support, headrests and other components, they have a surface shape, seat surface and backrest should be with the body shape curve of the back curve of a relaxed state match, after the seat occupant seated surface shape and the body pressure distribution in the muscles of the crew to make the most relaxed state, to support the lumbar spine, not because of poor circulation caused numbness, fatigue easily take a long time. Through the front seat up and down, backrest angle, head up and down positions, such as the limited front and rear adjustment, can make most people are comfortable. The spring seat seat vibration performance constitute the key. Tests show that vehicle is in motion even though the floor vibration, but the action of the spring seat, the seat is still possible to get good comfort, good performance if the spring, the comfort of the car will be relatively poor. At present, most holistic seat cushion foam urethane, which uses S-shaped coil springor springs from being buried in urethane foam, has a simple structure, low cost, noise-free advantages. Low-back seats for the car, the head is an attachment on the seat. As the speed increases, its growing importance of personal safety. Car in the event of rear-end collision, the impact of cars by the force behind the rapid moment forward, the inertia occupant's head is suddenly thrown back, cervical spine to withstand the acceleration forces to the large and easily hurt. With the head supporting and reduce the space of free movement of the head can reduce the impact of the cervical spine. 1998 Volvo (Volvo) car assembly WHIPS (Whiplash Protection System) rear-end collision occurs when the headrest and backrest can be made after the occupants moved at the same time effectively prevent cervical spine injury. The current car seat has seat belts, airbags together constitute the security of the crew. The strength of their own car seat, the reliability of the connection on the body, back strength and testing requirements are the industry standard, not just to do an installation up to the line. With modern technology, car seats are equipped pneumatic devices, air pump from the engine compartment is provided inside the seat back pressure chamber 4, respectively, to achieve the protection of the Ministry of the lumbar spine. Are divided into two parts back, the angle can be adjusted to make the waist and shoulder the same time close to the back, play a security role. Have built in the back of a computer-controlled electronic oscillator, and massage healtheffects.附录Ⅱ(译文)现代轿车已经不是一个单纯的运载工具,它已经是“人、汽车与环境”的组合体。
更多汽车资料请访问中国汽车技术论坛:CHAPTER 1 AUTOMOTIVE BASICS1.1 Principal ComponentsToday's average car contains more than 15,000 separate, individual parts that must work together. These parts can grouped into four major categories: engine, body, chassis and electrical equipment.1.2 EngineThe engine acts as the power unit. The internal combustion engine is most common: this obtains its power by burning a liquid fuel inside the engine cylinder. There are two types of engine :gasoline(also called a spark-ignition engine) and diesel(also called a compression-ignition engine).Both engines are called heat engines; the burning fuel generates heat which causes the gas inside the cylinder to increase its pressure and supply power to rotate a shaft connected to the transmission.1.3 BodyAn automobile body is a sheet metal shell with windows, doors, a hood, and a trunk deck built into it. It provides a protective covering for the engine, passengers, and cargo. The body is designed to keep passengers safe and comfortable. The body styling provides an attractive, colorful, modern appearance for the vehicle.1.4 ChassisThe chassis is an assembly of those systems that are the major operating part of a vehicle. The chassis includes the transmission, suspension, steering, and brake systems.Transmission systems ― conveys the drive to the wheels. The main components are clutch, gearbox, driveshaft, final drive, and differential.Suspension― absorbs the road shocks.Steering― controls the direction of the movement.Brake― slows down the vehicle.1.5 Electrical EquipmentThe electrical system supplies electricity for the ignition, horn, lights, heater, and starter. The electricity level is maintained by a charging circuit. This circuit consists of the battery, alternator (or generator). The battery stores electricity. The alternator changes the engine's mechanical energy into electrical energy and recharges the battery.New WordsPrincipal component 主要部件category 种类,类型body 车身chassis 底盘layout 布置power unit 动力装置internal combustion engine 内燃机cylinder 汽缸gasoline 汽油spark 火花ignition 点燃,点火diesel 柴油机compression 压缩shaft 轴transmission 传动系sheet metal 金属板shell 外壳hood (发动机)罩trunk deck 行李舱盖cargo 货物styling 样式assembly 总成,装配suspension 悬挂,悬置shock 冲击steering 转向,操纵brake 刹车,制动器clutch 离合器gearbox 变速器driveshaft 传动轴final drive 主减速器,后桥differential 差速器slow down (使)慢下来,减速horn 喇叭starter 起动机charge 充电alternator 交流发电机Review Questions1.List the main parts of an automobile?2.What are the common types of a vehicle according to body styling?3.Which systems does a chassis include and what are the main functions of the chassis?4.Why are suspension systems used on vehicles?CHAPTER2 INTERNAL COMBUSTION ENGINE2.1 principle of operation2.1.1 Engine and powerEngine is used to produce power. The chemical energy in fuel is converted to heat by the burning of the fuel at a controlled rate. This process is called combustion. If engine combustion occurs with the power chamber. ,the engine is called internal combustion engine. If combustion takes place outside the cylinder, the engine is called an external combustion engine.Engine used in automobiles are internal combustion heat engines. Heat energy released in the combustion chamber raises the temperature of the combustion gases with the chamber. Theincrease in gas temperature causes the pressure of the gases to increase. The pressure developed within the combustion chamber is applied to the head of a piston to produce a usable mechanical force, which is then converted into useful mechanical power.2.1.2 Engine TermsLinking the piston by a connecting rod to a crankshaft causes the gas to rotate the shaft through half a turn. The power stroke “uses up” the gas , so means must be provided to expel the burnt gas and recharge the cylinder with a fresh petrol-air mixture :this control of gas movement is the duty of the valves ;an inlet valve allows the new mixture to enter at the right time and an exhaust valve lets out the burnt gas after the gas has done its job. Engine terms are :TDC(Top Dead Center):the position of the crank and piston when the piston is farther away from the crankshaft.BDC(Bottom Dead Center):the position of the crank and piston when the piston is nearest to the crankshaft.Stroke : the distance between BDC and TDC; stroke is controlled by the crankshaft.Bore : the internal diameter of the cylinder.Swept volume : the volume between TDC and BDC.Engine capacity : this is the swept volume of all the cylinder e.g. a four-stroke having a capacity of two liters(2000cm) has a cylinder swept volume of 50cm.Clearance volume: the volume of the space above the piston when it is at TDC. Compression ratio = (swept vol + clearance vol)\(clearance vol)Two-stroke : a power stroke every revolution of the crank.Four-stroke : a power stroke every other revolution of the crank..2.1.3 The Four-stroke Spark-ignition Engine CycleThe spark-ignition engine is an internal-combustion engine with externally supplied in ignition , which converts the energy contained in the fuel to kinetic energy.The cycle of operations is spread over four piston strokes. To complete the full cycle it takestwo revolutions of the crankshaft.The operating strokes are :This stroke introduces a mixture of atomized gasoline and air into the cylinder . The strokestarts when the piston moves downward from a position near the top of the cylinder . As thepiston moves downward, a vacuum, or low-pressure area, is created.During the intake stroke, one of the ports is opened by moving the inlet valve. The exhaustvalve remains tightly closed.Compression strokeAs the piston moves upward to compress the fuel mixture trapped in the cylinder , the valvesare closed tightly. This compression action heats the air/fuel mixture slightly and confines itwithin a small area called the combustion chamber .Power strokeJust before the piston reaches the top of its compression stroke, an electrical spark isintroduced from a spark plug screwed into the cylinder head.The spark ignites the compressed, heated mixture of fuel and air in the combustion chamberto cause rapid burning. The burning fuel produces intense heat that causes rapid expansionof the gases compressed within the cylinder . This pressure forces the piston downward. Thedownward stroke turns the crankshaft with great force.Exhaust strokeJust before the bottom of the power stroke, the exhaust valve opens. This allows the piston,as it moves upward, to push the hot, burned gases out through the open exhaust valve.Then, just before the piston reaches its highest point, the exhaust valve closes and the inletvalve opens. As the piston reaches the highest point in the cylinder , known as TDC, it startsback down again. Thus, one cycle ends and another begins immediately.2.1.4 Engine Overall MechanicsThe engine has hundreds of other parts . The major parts of engine are engine block , engineheads, pistons, connecting rods, crankshaft and valves. The other parts are joined to make systems.These systems are the fuel system, intake system, ignition system, cooling system, lubricationsystem and exhaust system. Each of these systems has a definite function. These systems willdiscussed in detail later.NEW WORDPiston 活塞Connecting rod 连杆Crankshaft 曲轴Power stoke 活塞行程Expel 排出Valve 气阀inlet(intake) valve 进气阀exhaust valve 排气阀term 术语TDC 上止点BDC 下止点Bore 缸径swept volume 有效容积engine capacity 发动机排量clearance volume 余隙容积,燃烧室容积compression ratio 压缩比revolution 旋转,转数every other 每隔一个cycle 循环spread over 分布,遍及intake stroke 进气行程compression stroke 压缩行程knock 敲缸,敲打exhaust stroke 排气行程engine block 发动机缸体lubrication 润滑2.2 Engine Block and Cylinder Head2.2.1 Engine BlockThe engine block is the basic frame of the engine. All other engine parts either fit inside it or fasten to it. It holds the cylinders, water jackets, and oil galleries. The engine block also holds the crankshaft, which fastens to the bottom of the block. The camshaft also fits inside the block, except on overhead-cam engines (OHC). In most cars, this block is made of gray iron, or an alloy (mixture) of gray iron and other metals, such as nickel or chromium. Engine blocks are castings.Some engine blocks, especially those in smaller cars, are made of cast aluminum. This metal is much lighter than iron. However, iron wears better than aluminum. Therefore, the cylinders in most aluminum engines are lined with iron or steel sleeves. These sleeves are called cylinder sleeves. Some engine blocks are made entirely of aluminum.2.2.2 Cylinder HeadThe cylinder head fastens to the top of the block, just as a roof fits over a house. The underside forms the combustion chamber with the top of the piston. The most common cylinder head types are the hemi, wedge, and semi-hemi. All three of these terms refer to the shape of the engine's combustion chamber. The cylinder head carries the valves, valve springs and the rockers on the rocker shaft, this part of the valve gear being worked by the push-rods. Sometimes the camshaft is fitted directly into the cylinder head and operates on the valves without rockers. This is called an overhead camshaft arrangement. Like the cylinder block, the head is made from either cast iron or aluminum alloy.2.2.3 GasketThe cylinder head is attached to the block with high-tensile steel studs. The joint between the block and the head must be gas-tight so that none of the burning mixture can escape. This is achieved by using cylinder head gasket. This is a sandwich gasket, i.e. a sheet of asbestos between two sheets of copper, both these materials being able to withstand the high temperature and pressures within the engine.2.2.4 Oil Pan or SumpThe oil pan is usually formed of pressed steel. The oil pan and the lower part of the cylinder block together are called the crankcase; they enclose, or encase, the crankshaft. The oil pump in the lubricating system draws oil from the oil pan and sends it to all working parts in the engine. The oil drains off and runs down into the pan. Thus, there is constant circulation of oil between the pan and the working parts of the engine.New Wordsengine block 缸体cylinder head 气缸盖fasten 使固定water jacket 水套oil gallery 油道camshaft 凸轮轴overhead-cam(OHC) 顶置凸轮gray iron 灰铸铁alloy 合金nickel 镍chromium 铬casting 铸件head cover 汽缸盖罩intake manifold 进气总管distributor 分电器oil pan 油底壳aluminum 铝be lined with 镶有cylinder sleeve 气缸套hemi 半球形wedge 楔型,楔入semi-hemi 准半球形rocker 摇臂push-rod 推杆gasket 衬垫high-tensile 高强度的stud 螺栓gas-tight 密封的asbestos 石棉crankcase 曲轴箱,曲柄箱encase 封闭,把…包起来drain off 排出,流出Review Question1.What do TDC, BDC, stroke, compression ratio and engine capacity stand for?2.How do you calculate swept volume and compression ratio?3.What controls the length of the stroke?4.List the main parts of the engine overall mechanics?5.What are the main function of the engine block?2.3 Piston Connecting Rod and Crankshaft2.3.1 Piston AssemblyThe piston is an important part of a four-stroke cycle engine. Most pistons are made from cast aluminum. The piston , through the connecting rod, transfers to the crankshaft the force create by the burning fuel mixture. This force turns the crankshaft .Thin, circular , steel bands fit into grooves around the piston to seal the bottom of the combustion chamber. These bands are called piston rings. The grooves into which they fit are called ring grooves. A piston pin fits into a round hole in the piston . The piston pin joins the piston to the connecting rod . The thick part of the piston that holds the piston is the pin boss.The piston itself , its rings and the piston pin are together called the piston assembly.2.3.2.PistonTo withstand the heat of the combustion chamber, the piston must be strong. It also must be light, since it travels at high speeds as it moves up and down inside the cylinder. The piston is hollow. It is thick at the top where it take the brunt of the heat and the expansion force. It is thin at the bottom, where there is less heat. The top part of the piston is the head , or crown . The thin part is the skirt The sections between the ring grooves are called ring lands.The piston crown may be flat , concave ,dome or recessed . In diesel engine , the combustion chamber may be formed totally or in part in the piston crown , depending on the method of injection . So they use pistons with different shapes.2.3.3Piston RingsAs Fig.2-9 shows , piston rings fit into ring grooves near the of the piston. In simplest terms, piston rings are thin, circular pieces of metal that fit into grooves in the tops of the pistons.In modern engines ,each piston has three rings. (Piston in older engines sometimes had four rings, or even five.) The ring’s outside surface presses against the cylinder walls. Rings provide the needed seal between the piston and the cylinder walls. That is, only the rings contact the cylinder walls. The top two rings are to keep the gases in the cylinder and are called compression rings. The lower one prevents the oil splashed onto the cylinder bore from entering the combustion chamber , and is called an oil ring. Chrome-face cast-iron compression rings are commonly used in automobile engines. The chrome face provide a very smooth , wear-resistant surface.During the power stoke , combustion pressure on the combustion rings is very high. It causes them to untwist . Some of the high-pressure gas gets in back of the rings. This force the ring face into full contact with the cylinder wall. The combustion pressure also holds the bottom of the ring tightly against the bottom of the ring groove. Therefore , high combustion pressure causes a tighter seal between the ring face and the cylinder wall.2.3.4 Piston PinThe piston pin holds together the piston and the connecting rod . This pin fits into the piston pin holes and into a hole in the top end of the connecting rod. The top end of is much smaller than the end that fits on the crankshaft . This small end fitsinside the bottom of the piston . The piston pinfits through one side of the piston , through thesmall end of the rod , and then through the otherside of the piston . It holds the rod firmly in place inthe center of the piston. Pins are made ofhigh-strengh steel and have a hollow center . Manypins are chrome-plated to help them wear better.2.3.3 Connecting rodThe connecting rod is made of forged high-strengthsteel . It transmits and motion from the piston to the crankpin on the crankshaft . The connecting rod little end is connected to the piston pin . A bush made from a soft metal , such as bronze , is used for this joint . The lower end of the connecting rod fits the crankshaft journal . This is called the big end . For this big-end bearing , steel-backed lead or tin shell bearing are used . These are the same as those used for the main bearings . The split of the big end is sometimes at an angle , so that it is small enough to be withdrawn through the cylinder bore . The connecting rod is made from forged alloy steel .2.3.5 CrankshaftThe crankshaft , in conjunction with the connecting rod , coverts the reciprocating motion of the piston to the rotary motion needed to drive the vehicle . It is usually made from carbon steel which is alloyed with a small proportion of nickel .The main bearing journals fit into the cylinder block and the big end journals align with the connecting rods .At the rear end of the crankshaft is attached the flywheel , and at the front end are the driving whells for the timing gears , fan , cooling water and alternator .The throw of the crankshaft , the distance between the main journal and the big end centers , controls the length of the stroke . The stroke is double the throw , and the stroke-length is the distance that the piston travels from TDC to BDC and vice versa .2.3.6 FlywheelThe flywheel is the made from carbon steel . It fit s onto the rear of the crankshaft . As well as keeping the engine rotating between power strokes it also carries the clutch , which transmits the drive to the transmission , and has the starter ring gear around its circumference . There is only one working stroke in four so a flywheel is needed to drive the crankshaft during the time that the engine is performing the non-power strokes .New Words Comprise 由。
车辆工程专业英语词汇汽车工程专业英语词汇1. Engine - 引擎2. Transmission - 变速器3. Suspension - 悬架系统4. Brake - 制动器5. Chassis - 底盘6. Exhaust - 排气系统7. Fuel injection - 燃油喷射系统8. Steering - 转向系统9. Ignition - 点火系统10. Hybrid - 混合动力11. Battery - 电池12. Alternator - 发电机13. Turbocharger - 涡轮增压器14. Radiator - 散热器15. Cylinder - 汽缸16. Piston - 活塞17. Crankshaft - 曲轴18. Camshaft - 凸轮轴19. Valve - 气门20. Timing belt - 正时皮带21. Clutch - 离合器22. Differential - 差速器23. ABS (Anti-lock Braking System) - 防抱死制动系统24. ECU (Engine Control Unit) - 发动机控制单元25. OBD (On-board Diagnostics) - 车载诊断系统26. CVT (Continuously Variable Transmission) - 连续可变传动系统27. DSG (Direct-Shift Gearbox) - 双离合器变速器28. Traction control - 牵引力控制系统29. ESC (Electronic Stability Control) - 电子稳定控制系统30. Airbag - 安全气囊。
