道路与桥梁专业外文翻译中英对照

一，Careers in Civil EngineeringEngineering is a profession, which means that an engineer must have a specialized university education. Many government jurisdictions also have licensing procedures which require engineering graduates to pass an examination, similar to the examination for a lawyer, before they can actively start on their careers.土木工程是一个意味着工程师必须要经过专门的大学教育的职业。

许多政府管辖部门还有（一套）认证程序，这一程序要求工科毕业生在他们能积极地开始（从事）他们的事业之前，通过（认证）考试, 这种考试类似于律师职业里的律师考试一样。

In the university, mathematics, physics, and chemistry are heavily emphasized throughout the engineering curriculum, but particularly in the first two or three years. Mathematic is very important in all branches of engineering, so it is greatly stressed. Today, mathematics includes courses in statistics, which deals with gathering, classifying, and using numerical data, or pieces of information. An important aspect of statistical mathematics is probability, which deals with what may happen when there are different factors, or variables, that can change the results of a problem. Before the construction of a bridge is undertaken, for example, a statistical study is made of the amount of traffic the bridge will be expected to handle. In the design of the bridge, variable such as water pressure on the foundation, impact, the effects of different wind forces, and many other factors must be considered.大学里, 工科课程中着重强调数学、物理, 和化学,尤其在开始的二到三年。

道路桥梁英语词汇absolute datum 绝对基面abutment 桥台abutment pier 制动墩acceleration lane 加速车道accidental load 偶然荷载accommodation lane 专用车道acoustic barrier 隔音墙acting circles of blasting 爆破作用圈additional stake 加桩adjacent curve in one direction 同向曲线admixture 外加剂admixture 反坡安全线aerial photogrammetry 航空摄影测量aerophoto base 航摄基线aerophoto interpretation 航摄像片判读ageing 老化aggregate 集料 ( 骨料 )air hardining 气硬性alignment design ( 城市道路 ) 平面设计，线形设计alignment element 线形要素alligator cracking 路面龟裂allowable rebound deflection 容许 ( 回弹 ) 弯沉alternative line 比较线anchored bulkhead abutment 锚锭板式桥台anchored bulkhead abutment 锚锭板式挡土墙anchored retaining wall 锚杆式挡土墙anionic emulsified bitumen 阴离子乳化沥青ann l average daily traffic 年平均日交通量anti-creep heap ( 厂矿道路 ) 挡车堆anti-dizzling screen 防炫屏 ( 遮光栅 )antiskid heap ( 厂矿道路 ) 防滑堆approach span 引桥aquitard 隔水层arch bridge 拱桥arch culvert 拱涵arch ring 拱圈arterial highway 干线公路arterial road ( 厂内 ) 主干道， ( 城市 ) 主干路asphalt distributor 沥青洒布车asphalt mixing plant 沥青混合料拌和设备asphalt remixer 沥青混合料摊铺机asphalt remixer 复拌沥青混合料摊铺机asphalt sand 沥青砂asphalt sprayer 沥青洒布机asphaltic bitumen 地沥青at-grade intersection 平面交叉auxiliary lane 附加车道average consistency (of soil) 土的 ) 平均稠度average gradient 平均纵坡aximuth angle 方位角Bbalance weight retaining wall 衡重式挡土墙base course 基层base line 基线basic traffic capacity 基本通行能力beam bridge 梁桥beam level deflectometer 杠杆弯沉仪bearing 支座bearing angle 象限角bearing pile 支承桩bearing platform 承台bed course 垫层bench mark 水准点benched s grade 台口式路基bending strength 抗弯强度Benkelman beam 杠杆弯沉仪 ( 贝克曼弯沉仪 ) bent cap 盖梁berm 护坡道binder 结合料binder course 联结层bitumen 沥青bitumen ( 沥青混合料 ) 抽提仪bitumen-aggregate ratio 油石比bituminous concrete pavement 沥青混凝土混合料bituminous concrete mixture 沥青混凝土路面bituminous concrete moxture 沥青碎石混合料bituminous macadam pavement 沥青碎石路面bituminous moxture 沥青混合料bituminous pavement 沥青路面bituminous penetration pavement 沥青贯入式路面biuminous surface treatment ( 沥青 ) 表面处治blasting crater 爆破漏斗blastion for loosening rock 松动爆破blasting for throwing rock 抛掷爆破blasting procedure 土石方爆破bleeding 泛油blind ditch 盲沟blind drain 盲沟block pavement 块料路面block stone 块石blow up 拱胀boring 钻探boring log ( 道路 ) 地质柱状图boring machine 钻孔机borrow earth 借土borrow pit 取土坑boundary frame on crossing 道口限界架boundary frame on road 道路限界架boundary line of road constr tion 道路建筑限界bowstring arch bridge 系杆拱桥box culvert 箱涵branch pipe of inlet 雨水口支管branch road ( 城市 ) 支路， ( 厂内 ) 支道bridge 桥梁bridge decking 桥面系bridge deck pavement 桥面铺装bridge floor expantion and contraction installation traction installation 桥面伸缩装置bridge gerder erection equpment 架桥机bridge on slope 坡桥bridge site 桥位bridle road 驮道broken chainage 断链broken stone 碎石broken back curve 断背曲线buried abutment 埋置式桥台bus bay 公交 ( 车辆 ) 停靠站bypass 绕行公路Ccable bent tower 索塔cable saddle 索鞍cable stayed bridge 斜拉桥 ( 斜张桥 )Cableway erecting equipment 缆索吊装设备California bearing ratio (CBR) 加州承载比 (CBR)California bearing ratio tester 加州承载比 (CBR) 测定仪camber cruve 路拱曲线cantilever beam bridge 悬臂梁桥cantilever beam bridge 悬臂式挡土墙capacity of intersection 交叉口通行能力capacity of network 路网通行能力capillary water 毛细水carriage way 车行道 ( 行车道 )cast-in-place cantilever method 悬臂浇筑法cationic emulsified bitumen 阳离子乳化沥青cattle-pass 畜力车道cement concrete 水泥混凝土cemint concrete pavement 水泥混凝土混合料cement concrete pavement 水泥混凝土路面center-island 中心岛center lane 中间车道center line of raod 道路中线center line survey 中线测量center stake 中桩central reserve 分隔带channelization 渠化交通channelization island 导流岛channelized intrersection 分道转弯式交叉口chip 石屑chute 急流槽circular curve 圆曲线circular curve 环路circular test 环道试验city road 城市道路civil engineering fabric 土工织物classified highway 等级公路classified highway 等级道路clay-bound macadam 泥结碎石路面clearance 净空clearance above bridge floor 桥面净空clearce of span 桥下净空climatic zoning for highway 公路自然区划climbing lane 爬坡车道cloverleaf interchange 苜蓿叶形立体交叉coal tar 煤沥青cobble stone 卵石coefficient of scouring 冲刷系数cohesive soil 粘性土cold laid method 冷铺法cold mixing method 冷拌法cold-stretched steel bar 冷拉钢筋column pier 柱式墩combination-type road system 混合式道路系统compaction 压实compaction test 击实试验compaction test apparatus 击实仪compactness test 压实度试验composite beam bridge 联合梁桥composite pipe line 综合管道 ( 综合管廊 )compound curve 复曲线concave vertical curve 凹形竖曲线concrete joint cleaner ( 水泥混凝土 ) 路面清缝机concrete joint sealer ( 水泥混凝土 ) 路面填缝机concrete mixing plant 水泥混凝土( 混合料 ) 拌和设备concrete paver 水泥混凝土 ( 混合料 ) 摊铺机concrete pump 水泥混凝土 ( 混合料 ) 泵concrete saw ( 水泥混凝土 ) 路面锯缝机cone penetration test 触探试验conflict point 冲突点conical slope 锥坡consistency limit (of soil) ( 土的 ) 稠度界限consolidated s soil 加固地基consolidation 固结constr tion by swing 转体架桥法constr tion height of bridge 桥梁建筑高度constr tion joint 施工缝constr tion load 施工荷载constr tion survey 施工测量continuous beam bridge 连续梁桥contourline 等高线contraction joint 缩缝control point 路线控制点converging 合流convex vertining wall 凸形竖曲线corduroy road 木排道counterfout retaining wall 扶壁式挡土墙counterfort abutmen 扶壁式桥台country road 乡村道路county road 县公路 ( 县道 ) ，乡道creep 徐变critical speed 临界速度cross roads 十字形交叉cross slope 横坡cross walk 人行横道cross-sectional profile 横断面图cross-sectional survey 横断面测量crown 路拱crushed stone 碎石crushing strength 压碎值culture 地物culvert 涵洞curb 路缘石curb side strip 路侧带curve length 曲线长curve widening 平曲线加宽curved bridge 弯桥cut 挖方cut corner for sight line ( 路口 ) 截角cut-fill transition 土方调配cut-fill transition 土方调配图cutting 路堑cycle path 自行车道cycle track 自行车道Ddeceleration lane 减速车道deck bridge 上承式桥deflection angle 偏角deflection test 弯沉试验degree of compaction 压实度delay 延误density of road network 道路（网）密度depth of tunnel 隧道埋深design elevation of s grade 路基设计高程design freqncy ( 排水 ) 设计重现期design hourly volume 设计小时交通量design of evevation ( 城市道路 ) 竖向设计design of vertical alignment 纵断面设计design speed 计算行车速度 ( 设计车速 )design traffic capacity 设计通行能力design vehicle 设计车辆design water level 设计水位desiged dldvation 设计高程designed flood freqncy 设计洪水频率deslicking treatment 防滑处理Deval abrasion testion machine 狄法尔磨耗试验机（双筒式磨耗试验机）diamond interchange 菱形立体交叉differential photo 微分法测图direction angle 方向角directional interchange 定向式立体交叉diverging 分流dowel bar 传力杆drain opening 泄水口drainage by pumping station ( 立体交叉 ) 泵站排水drainage ditch 排水沟dressed stone 料石drop water 跌水dry concrtet 干硬性混凝土d tility (of bitumen) ( 沥青 ) 延度d tilometer ( 沥青 ) 延度仪dummy joint 假缝dynamic consolidation 强夯法Eeconomic speed 经济车速econnomical hauling distance 土方调配经济运距element support 构件支撑elevation 高程 ( 标高 )embankment 路堤emergency parking strip 紧急停车带emulsified bitumen 乳化沥青erecting by floating 浮运架桥法erection by longit inal pulling method 纵向拖拉法erection by protrusion 悬臂拼装法erection with cableway 缆索吊装法evaporation pond 蒸发池expansion bearing 活动支座expansive soil 膨胀土expansion joint 胀缝expressway ( 城市 ) 快速路external distance 外 ( 矢 ) 距Ffabricated bridge 装配式桥fabricated steel bridge 装拆式钢桥factories and mines road 厂矿道路factory external transportation line 对外道路factory-in road 厂内道路factory-out road 厂外道路fast lane 内侧车道faulting of slab ends 错台feeder highway 支线公路ferry 渡口fibrous concrete 纤维混凝土field of vision 视野fill 填方filled spandrel arch bridge 实腹拱桥final survey 竣工测量fineness 细度fineness modulus 细度模数fixed bearing 固定支座flare wing wall abutment 八字形桥台flared intersection 拓宽路口式交叉口flash 闪点flash point tester (open cup method) 闪点仪( 开口杯式) flexible pavement 柔性路面flexible pier 柔性墩floor system 桥面系flush curb 平缘石foot way 人行道ford 过水路面forest highway 林区公路forest road 林区道路foundation 基础free style road system 自由式道路系统free way 高速公路free-flow speed 自由车速freeze road 冻板道路freezing and thawing test 冻融试验frost boiling 翻浆frozen soil 冻土full depth asphalt pavement 全厚式沥青 ( 混凝土 ) 路面function planting 功能栽植Ggeneral scour under bridge opening 桥下一般冲刷geological section ( 道路 ) 地质剖面图geotextile 土工织物gradation 级配gradation of stone ( 路用 ) 石料等级grade change point 变坡点grade compensation 纵坡折减grade crossing 平面交叉grade length limitation 坡长限制grade of side slope 边坡坡度grade separation 简单立体交叉grade-separated junction 立体交叉graded aggregate pavement 级配路面brader 平地机grain composition 颗粒组成granular material 粒料gravel 砾石gravity pier (abutment) 重力式墩、台gravity retaining wall 重力式挡土墙green belt 绿化带gridiron road system 棋盘式道路系统ground control-point survey 地面控制点测量ground elevation 地面高程ground stereophoto grammetry 地面立体摄影测量g rd post 标柱g rd rail 护栏g rd wall 护墙gully 雨水口gutter 街沟 ( 偏沟 )gutter apron 平石gutter drainage 渠道排水Hhalf-through bridge 中承式桥hard shoulder 硬路肩hardening 硬化hardness 硬度haul road 运材道路heavy maintenance 大修hectometer stake 百米桩hedge 绿篱height of cut and fill at ceneter stake 中桩填挖高度high strength bolt 高强螺栓high type pavement 高级路面highway 公路highway landscape design 公路景观设计hill-side line 山坡线 ( 山腰线 )hilly terrain 重丘区horizontal alignment 平面线形horizontal curve 平曲线hot laid method 热铺法hot mixing method 热拌法hot stability (of bitumen) ( 沥青 ) 热稳性hydraulic computation 水力计算hydraulic computation 水硬性Iimaginary intersection point 虚交点immersed tunnelling method 沉埋法inbound traffic 入境交通incremental launching method 顶推法industrial district road 工业区道路industrial solid waste ( 路用 ) 工业废渣industrial waste base course 工业废渣基层inlet 雨水口inlet s merged culvert 半压力式涵洞inlet uns merged culvert 无压力式涵洞inorganic binder 无机结合料instrument station 测站intensity of rainstorm 暴雨强度intercepting detch 截水沟interchange 互通式立体交叉interchange woth special bicycle track 分隔式立体交叉intermediate maintenance 中修intermediate type pavement 中级路面intersection ( 平面 ) 交叉口intersection angle 交叉角，转角intersection entrance 交叉口进口intersection exit 交叉口出口intersection plan 交叉口平面图intersection point 交点intersection with widened corners 加宽转角式交叉口Jjack-in method 顶入法Kkilometer stone 里程碑Lland slide 坍方lane 车道lane-width 车道宽度lateral clear distance of curve ( 平曲线 ) 横净距lay-by 紧急停车带level of service 道路服务水平leveling course 整平层leveling survey 水准测量light-weight concrete 轻质混凝土lighting facilities of road 道路照明设施lime pile 石灰桩line development 展线linking-up road 联络线，连接道路liquid asphaltic bitumen 液体沥青liquid limit 液限living fence 绿篱load 荷载loading berm 反压护道lading combinations 荷载组合loading plate 承载板loading plate test 承载板试验local scour near pier 桥墩局部冲刷local traffic 境内交通location of line 定线location survey 定测lock bolt support with shotcrete 喷锚支护loess 黄土longit inal beam 纵梁longit inal gradient 纵坡longit inal joint 纵缝loop ramp 环形匝道。

道路路桥工程中英文对照外文翻译文献Asphalt Mixtures: ns。

Theory。

and Principles1.nsXXX industry。

XXX。

The most common n of asphalt is in the n of XXX "flexible" XXX them from those made with Portland cement。

XXX2.XXXXXX the use of aggregates。

XXX。

sand。

or gravel。

and a binder。

XXX for the pavement。

XXX。

The quality of the asphalt XXX to the performance of the pavement。

as it must be able to XXX。

3.PrinciplesXXX。

with each layer XXX layers typically include a subgrade。

a sub-base。

a base course。

and a surface course。

The subgrade is the natural soil or rock upon which the pavement is built。

while the sub-base and base courses provide nal support for the pavement。

The surface course is the layer that comes into direct contact with traffic and is XXX。

In n。

the use of XXX.The n of flexible pavement can be subdivided into high and low types。

附录一英文翻译原文AUTOMATIC DEFLECTION AND TEMPERATURE MONITORING OFA BALANCED CANTILEVER CONCRETE BRIDGEby Olivier BURDET, Ph.D.Swiss Federal Institute of Technology, Lausanne, SwitzerlandInstitute of Reinforced and Prestressed Concrete SUMMARYThere is a need for reliable monitoring systems to follow the evolution of the behavior of structures over time.Deflections and rotations are values that reflect the overall structure behavior. This paper presents an innovative approach to the measurement of long-term deformations of bridges by use of inclinometers. High precision electronic inclinometers can be used to follow effectively long-term rotations without disruption of the traffic. In addition to their accuracy, these instruments have proven to be sufficiently stable over time and reliable for field conditions. The Mentue bridges are twin 565 m long box-girder post-tensioned concrete highway bridges under construction in Switzerland. The bridges are built by the balanced cantilever method over a deep valley. The piers are 100 m high and the main span is 150 m. A centralized data acquisition system was installed in one bridge during its construction in 1997. Every minute, the system records the rotation and temperature at a number of measuring points. The simultaneous measurement of rotations and concrete temperature at several locations gives a clear idea of the movements induced by thermal conditions. The system will be used in combination with a hydrostatic leveling setup to follow the long-term behavior of the bridge. Preliminary results show that the system performs reliably and that the accuracy of the sensors is excellent.Comparison of the evolution of rotations and temperature indicate that the structure responds to changes in air temperature rather quickly.1.BACKGROUNDAll over the world, the number of structures in service keeps increasing. With the development of traffic and the increased dependence on reliable transportation, it is becoming more and more necessary to foresee and anticipate the deterioration of structures. In particular,for structures that are part of major transportation systems, rehabilitation works need to be carefully planned in order to minimize disruptions of traffic. Automatic monitoring of structures is thus rapidly developing.Long-term monitoring of bridges is an important part of this overall effort to attempt to minimize both the impact and the cost of maintenance and rehabilitation work of major structures. By knowing the rate of deterioration of a given structure, the engineer is able to anticipate and adequately define the timing of required interventions. Conversely, interventions can be delayed until the condition of the structure requires them, without reducing the overall safety of the structure.The paper presents an innovative approach to the measurement of long-term bridge deformations. The use of high precision inclinometers permits an effective, accurate and unobtrusive following of the long-term rotations. The measurements can be performed under traffic conditions. Simultaneous measurement of the temperature at several locations gives a clear idea of the movements induced by thermal conditions and those induced by creep and shrinkage. The system presented is operational since August 1997 in the Mentue bridge, currently under construction in Switzerland. The structure has a main span of 150 m and piers 100 m high.2. LONG-TERM MONITORING OF BRIDGESAs part of its research and service activities within the Swiss Federal Institute of Technology in Lausanne (EPFL), IBAP - Reinforced and Prestressed Concrete has been involved in the monitoring of long-time deformations of bridges and other structures for over twenty-five years [1, 2, 3, 4]. In the past, IBAP has developed a system for the measurement of long-term deformations using hydrostatic leveling [5, 6]. This system has been in successful service in ten bridges in Switzerland for approximately ten years [5,7]. The system is robust, reliable and sufficiently accurate, but it requires human intervention for each measurement, and is not well suited for automatic data acquisition. One additional disadvantage of this system is that it is only easily applicable to box girder bridges with an accessible box.Occasional continuous measurements over periods of 24 hours have shown that the amplitude of daily movements is significant, usually amounting to several millimeters over a couple of hours. This is exemplified in figure 1, where measurements of the twin Lutrive bridges, taken over a period of several years before and after they were strengthened by post-tensioning, areshown along with measurements performed over a period of 24 hours. The scatter observed in the data is primarily caused by thermal effects on the bridges. In the case of these box-girder bridges built by the balanced cantilever method, with a main span of 143.5 m, the amplitude of deformations on a sunny day is of the same order of magnitude than the long term deformation over several years.Instantaneous measurements, as those made by hydrostatic leveling, are not necessarily representative of the mean position of the bridge. This occurs because the position of the bridge at the time of the measurement is influenced by the temperature history over the past several hours and days. Even if every care was taken to perform the measurements early in the morning and at the same period every year, it took a relatively long time before it was realized that the retrofit performed on the Lutrive bridges in 1988 by additional post-tensioning [3, 7,11] had not had the same effect on both of them.Figure 1: Long-term deflections of the Lutrive bridges, compared to deflections measured in a 24-hour period Automatic data acquisition, allowing frequent measurements to be performed at an acceptable cost, is thus highly desirable. A study of possible solutions including laser-based leveling, fiber optics sensors and GPS-positioning was performed, with the conclusion that, provided that their long-term stability can be demonstrated, current types of electronic inclinometers are suitable for automatic measurements of rotations in existing bridges [8].3. MENTUE BRIDGESThe Mentue bridges are twin box-girder bridges that will carry the future A1 motorway from Lausanne to Bern. Each bridge, similar in design, has an overall length of approximately 565 m, and a width of 13.46 m, designed to carry two lanes of traffic and an emergency lane. The bridges cross a deep valley with steep sides (fig. 2). The balanced cantilever design results from a bridge competition. The 100 m high concrete piers were built using climbing formwork, after which the construction of the balanced cantilever started (fig. 3).4. INCLINOMETERSStarting in 1995, IBAP initiated a research project with the goal of investigating the feasibility of a measurement system using inclinometers. Preliminary results indicated that inclinometers offer several advantages for the automatic monitoring of structures. Table 1 summarizes the main properties of the inclinometers selected for this study.One interesting property of measuring a structure’s rotations, is that, for a given ratio of maximum deflection to span length, the maximum rotation is essentially independent from its static system [8]. Since maximal allowable values of about 1/1,000 for long-term deflections under permanent loads are generally accepted values worldwide, developments made for box-girder bridges with long spans, as is the case for this research, are applicable to other bridges, for instance bridges with shorter spans and other types of cross-sections. This is significant because of the need to monitor smaller spans which constitute the majority of all bridges.The selected inclinometers are of type Wyler Zerotronic ±1°[9]. Their accuracy is 1 microradian (μrad), which corresponds to a rotation of one millimeter per kilometer, a very small value. For an intermediate span of a continuous beam with a constant depth, a mid-span deflection of 1/20,000 would induce a maximum rotation of about 150 μrad, or 0.15 milliradians (mrad).One potential problem with electronic instruments is that their measurements may drift overtime. To quantify and control this problem, a mechanical device was designed allowing the inclinometers to be precisely rotated of 180° in an horizontal plane (fig. 4). The drift of each inclinometer can be very simply obtained by comparing the values obtained in the initial and rotated position with previously obtained values. So far, it has been observed that the type of inclinometer used in this project is not very sensitive to drifting.5. INSTRUMENTATION OF THE MENTUE BRIDGESBecause a number of bridges built by the balanced cantilever method have shown an unsatisfactory behavior in service [2, 7,10], it was decided to carefully monitor the evolution of the deformations of the Mentue bridges. These bridges were designed taking into consideration recent recommendations for the choice of the amount of posttensioning [7,10,13]. Monitoring starting during the construction in 1997 and will be pursued after the bridges are opened to traffic in 2001. Deflection monitoring includes topographic leveling by the highway authorities, an hydrostatic leveling system over the entire length of both bridges and a network of inclinometers in the main span of the North bridge. Data collection iscoordinated by the engineer of record, to facilitate comparison of measured values. The information gained from these observations will be used to further enhance the design criteria for that type of bridge, especially with regard to the amount of post-tensioning [7, 10, 11, 12, 13].The automatic monitoring system is driven by a data acquisition program that gathers and stores the data. This system is able to control various types of sensors simultaneously, at the present time inclinometers and thermal sensors. The computer program driving all the instrumentation offers a flexible framework, allowing the later addition of new sensors or data acquisition systems. The use of the development environment LabView [14] allowed to leverage the large user base in the field of laboratory instrumentation and data analysis. The data acquisition system runs on a rather modest computer, with an Intel 486/66 Mhz processor, 16 MB of memory and a 500 MB hard disk, running Windows NT. All sensor data are gathered once per minute and stored in compressed form on the hard disk. The system is located in the box-girder on top of pier 3 (fig. 5). It can withstand severe weather conditions and will restart itself automatically after a power outage, which happened frequently during construction.6. SENSORSFigure 5(a) shows the location of the inclinometers in the main span of the North bridge. The sensors are placed at the axis of the supports (①an d⑤), at 1/4 and 3/4 (③an d④) of the span and at 1/8 of the span for②. In the cross section, the sensors are located on the North web, at a height corresponding to the center of gravity of the section (fig.5a). The sensors are all connected by a single RS-485 cable to the central data acquisition system located in the vicinity of inclinometer ①. Monitoring of the bridge started already during its construction. Inclinometers①,②and③were installed before the span was completed. The resulting measurement were difficult to interpret, however, because of the wide variations of angles induced by the various stages of this particular method of construction.The deflected shape will be determined by integrating the measured rotations along the length of the bridge (fig.5b). Although this integration is in principle straightforward, it has been shown [8, 16] that the type of loading and possible measurement errors need to be carefully taken into account.Thermal sensors were embedded in concrete so that temperature effects could be taken into account for the adjustment of the geometry of the formwork for subsequent casts. Figure 6 shows the layout of thermal sensors in the main span. The measurement sections are located at the same sections than the inclinometers (fig. 5). All sensors were placed in the formwork before concreting and were operational as soon as the formwork was removed, which was required for the needs of the construction. In each section, seven of the nine thermal sensor (indicated in solid black in fig. 6) are now automatically measured by the central data acquisition system.7. RESULTSFigure 7 shows the results of inclinometry measurements performed from the end ofSeptember to the third week of November 1997. All inclinometers performed well during that period. Occasional interruptions of measurement, as observed for example in early October are due to interruption of power to the system during construction operations. The overall symmetry of results from inclinometers seem to indicate that the instruments drift is not significant for that time period. The maximum amplitude of bridge deflection during the observed period, estimated on the basis of the inclinometers results, is around 40 mm. More accurate values will be computed when the method of determination ofdeflections will have been further calibrated with other measurements. Several periods of increase, respectively decrease, of deflections over several days can be observed in the graph. This further illustrates the need for continuous deformation monitoring to account for such effects. The measurement period was .busy. in terms of construction, and included the following operations: the final concrete pours in that span, horizontal jacking of the bridge to compensate some pier eccentricities, as well as the stressing of the continuity post-tensioning, and the de-tensioning of the guy cables (fig. 3). As a consequence, the interpretation of these measurements is quite difficult. It is expected that further measurements, made after the completion of the bridge, will be simpler to interpret.Figure 8 shows a detail of the measurements made in November, while figure.9 shows temperature measurements at the top and bottom of the section at mid-span made during that same period. It is clear that the measured deflections correspond to changes in the temperature. The temperature at the bottom of the section follows closely variations of the air temperature(measured in the shade near the north web of the girder). On the other hand, the temperature at the top of the cross section is less subject to rapid variations. This may be due to the high elevation of the bridge above ground, and also to the fact that, during the measuring period, there was little direct sunshine on the deck. The temperature gradient between top and bottom of the cross section has a direct relationship with short-term variations. It does not, however, appear to be related to the general tendency to decrease in rotations observed in fig. 8.8. FUTURE DEVELOPMENTSFuture developments will include algorithms to reconstruct deflections from measured rotations. To enhance the accuracy of the reconstruction of deflections, a 3D finite element model of the entire structure is in preparation [15]. This model will be used to identify the influence on rotations of various phenomena, such as creep of the piers and girder, differential settlements, horizontal and vertical temperature gradients or traffic loads.Much work will be devoted to the interpretation of the data gathered in the Mentue bridge. The final part of the research project work will focus on two aspects: understanding the very complex behavior of the structure, and determining the most important parameters, to allow a simple and effective monitoring of the bridges deflections.Finally, the research report will propose guidelines for determination of deflections from measured rotations and practical recommendations for the implementation of measurement systems using inclinometers. It is expected that within the coming year new sites will be equipped with inclinometers. Experiences made by using inclinometers to measure deflections during loading tests [16, 17] have shown that the method is very flexible and competitive with other high-tech methods.As an extension to the current research project, an innovative system for the measurement of bridge joint movement is being developed. This system integrates easily with the existing monitoring system, because it also uses inclinometers, although from a slightly different type.9. CONCLUSIONSAn innovative measurement system for deformations of structures using high precision inclinometers has been developed. This system combines a high accuracy with a relatively simple implementation. Preliminary results are very encouraging and indicate that the use of inclinometers to monitor bridge deformations is a feasible and offers advantages. The system is reliable, does not obstruct construction work or traffic and is very easily installed. Simultaneous temperature measurements have confirmed the importance of temperature variations on the behavior of structural concrete bridges.10. REFERENCES[1] ANDREY D., Maintenance des ouvrages d’art: méthodologie de surveillance, PhD Dissertation Nr 679, EPFL, Lausanne, Switzerland, 1987.[2] BURDET O., Load Testing and Monitoring of Swiss Bridges, CEB Information Bulletin Nr 219, Safety and Performance Concepts, Lausanne, Switzerland, 1993.[3] BURDET O., Critères pour le choix de la quantitéde précontrainte découlant de l.observation de ponts existants, CUST-COS 96, Clermont-Ferrand, France, 1996.[4] HASSAN M., BURDET O., FAVRE R., Combination of Ultrasonic Measurements and Load Tests in Bridge Evaluation, 5th International Conference on Structural Faults and Repair, Edinburgh, Scotland, UK, 1993.[5] FAVRE R., CHARIF H., MARKEY I., Observation à long terme de la déformation des ponts, Mandat de Recherche de l’OFR 86/88, Final Report, EPFL, Lausanne, Switzerland, 1990.[6] FAVRE R., MARKEY I., Long-term Monitoring of Bridge Deformation, NATO Research Workshop, Bridge Evaluation, Repair and Rehabilitation, NATO ASI series E: vol. 187, pp. 85-100, Baltimore, USA, 1990.[7] FAVRE R., BURDET O. et al., Enseignements tirés d’essais de charge et d’observations à long terme pour l’évaluation des ponts et le choix de la précontrainte, OFR Report, 83/90, Zürich, Switzerland, 1995.[8] DAVERIO R., Mesures des déformations des ponts par un système d’inclinométrie,Rapport de maîtrise EPFL-IBAP, Lausanne, Switzerland, 1995.[9] WYLER AG., Technical specifications for Zerotronic Inclinometers, Winterthur, Switzerland, 1996.[10] FAVRE R., MARKEY I., Generalization of the Load Balancing Method, 12th FIP Congress, Prestressed Concrete in Switzerland, pp. 32-37, Washington, USA, 1994.[11] FAVRE R., BURDET O., CHARIF H., Critères pour le choix d’une précontrainte: application au cas d’un renforcement, "Colloque International Gestion des Ouvrages d’Art: Quelle Stratégie pour Maintenir et Adapter le Patrimoine, pp. 197-208, Paris, France, 1994. [12] FAVRE R., BURDET O., Wahl einer geeigneten Vorspannung, Beton- und Stahlbetonbau, Beton- und Stahlbetonbau, 92/3, 67, Germany, 1997.[13] FAVRE R., BURDET O., Choix d’une quantité appropriée de précontrain te, SIA D0 129, Zürich, Switzerland, 1996.[14] NATIONAL INSTRUMENTS, LabView User.s Manual, Austin, USA, 1996.[15] BOUBERGUIG A., ROSSIER S., FAVRE R. et al, Calcul non linéaire du béton arméet précontraint, Revue Français du Génie Civil, vol. 1 n° 3, Hermes, Paris, France, 1997. [16] FEST E., Système de mesure par inclinométrie: développement d’un algorithme de calcul des flèches, Mémoire de maîtrise de DEA, Lausanne / Paris, Switzerland / France, 1997.[17] PERREGAUX N. et al., Vertical Displacement of Bridges using the SOFO System: a Fiber Optic Monitoring Method for Structures, 12th ASCE Engineering Mechanics Conference, San Diego, USA, to be published,1998.译文平衡悬臂施工混凝土桥挠度和温度的自动监测作者Olivier BURDET博士瑞士联邦理工学院，洛桑，瑞士钢筋和预应力混凝土研究所概要：我们想要跟踪结构行为随时间的演化，需要一种可靠的监测系统。

桥梁bridge公路干道highway工程工程学engineering公路工程highway engineering路基roadbase路面pavement构造物建造构成制造construct施工（名）construction试验室laboratory现场检测field test（名）试验检验（不）进行试验experiment 试验检测测量test质量上流社会的quality合格，取得资格qualify材料material沥青柏油以沥青铺（一般指沥青路）asphalt 沥青（指原材料）bitumen沥青的bituminous沥青混合料bituminous mixture混凝土concrete钢筋混凝土RC (reinforced concrete)信誉信用贷款credit进度快慢tempo计划plan评定evaluation检查（名）检验inspection标准水准规格标准的合格的standard技术性的工业的technical技术技巧技术的工艺的专门的technic水泥cement碎石路碎石路macadam砂砾碎石砂砾层gravel钢筋reinforcing steel bar或reinfored steel石石头石场石的石制的stone检查员inspector测量（名）measuring测量（及）检测（及）勘测测绘（名）survey 设备仪器装置device申请application铺路工人paver经理manager加强reinforce（被加强的reinforced ）sign 签字署名通知list 表名册目录列举tabulation 制表列表表格mapping 绘图制图camera 照相机photo 照片给。

拍照拍照lime 石灰petrol 汽油diesel-oil 柴油planer 计划者planed 有计划的根据计划的pile 柱桩把桩打入用桩支撑weld 焊接焊牢焊接点welder 焊接者焊工laborer 劳动者劳工辅助工manpower 人力劳动力人力资源雇佣使用利用employ职业租用受雇employment项目条款item关税税款税impostresign 放弃辞去辞职document 公文文件证件time limit from project 工期weighbridge 地磅台秤transbit 经纬仪mention 提到说起表扬career 职业经历skill 技术技能trade 行业商业owe 欠债organization 组织机构团体traffic 交通交往通行交易买卖spend 预算花钱浪费interest 股息股份兴趣cost 费用成本花费wage 薪水报酬earning 工资收入利润cash 现金现款把...兑现tax 税负担向...纳税deficit 赤字不足额业主owner（北美用）、employer（英语国用）发展商（房屋等业主）client 或developer承包商contractor总承包商prime contractor或general contractor 分承包商nominated contractor专业承包商specialist contractor咨询公司consulting firm 或consultants咨询工程师consulting engineer建筑师architect建筑工程经理constraction manager项目经理program manager材料供应商supplier建筑经济学contraction economics亚洲开发银行asian development bank世界银行集团world bank group学会institute协会association组织结构organizational styucture基础设施infrastructure环境environment质量管理体系qulity management system 质量方针quality policy质量目标quality objective职能，函数，职务function计量的metrological鉴定qualification评审review效率efficiency验证verification顾客,消费者customer过程process产品product项目,预计的，计划的project程序procedure特性characteristic记录record检验inspection文件document信息information能力capabitily 满意satisfaction投标邀请书invitation for bids公开招标unlimited competitive open biding 投标者须知instruction to bidders银行保函bank guarantee担保公司security company支付保函payment guarantee资质说明statement of qualification单位成本cost per unit成本计划cost plan成本价price cost业主要求client´s requirements投标书tender 或bid 或proposal 合同条件condition of contract合同协议书agreement图纸drawings工程量表bill of quantities投标保证bid security保价offer开标tender 或bid评标bid evaluation施工项目work items总价合同lump sum contract专题报告subjective report审核audit 审核员auditor测量控制measurement control测量设备measureing equipment技术专家technical expert习惯，惯例custom选择selection确定，决定definition合格conformity不合格nonconformity缺陷defect预防措施preventive action纠正措施corrective action返工rework降级regrade返修repair报废serap让步concession放行release。

Unit 1 Highway Introduction公路简介(1) Road classification道路分类Road路,道路,公路, highway公路;干道, freeway高速公路;高速干道, expressway高速公路, street街,街道,(2) Road concept道路概念Road layout道路布局,planning 城市规划,土地规划, spacing 间隔, network网状物;网状系统, location位置;场所,所在地, terrain 地形;地势, drainage排水系统,排水设备;下水道, survey 测量,勘测,测绘(3) Road structure道路结构Alignment线型surface面,表面, subgrade路基,地基curvature弯曲, (几何)曲率, gradient 坡度,倾斜度, ditch沟;壕沟,水道,渠道, turnout产量,产额,4) Materials材料Gravel 砂砾,碎石,石子dirt污物;烂泥;灰尘,泥土, soil土,泥土,土壤, asphalt沥青;柏油, cement水泥, concrete 混凝土的, 具体的Rubble毛石，块石, flag薄层，薄层砂岩, stone石,石头,石块, slab石板，厚板,平板;厚片, grout薄泥浆;水泥浆,石灰浆lime石灰, cement水泥,胶结材料Bottom layer底层/intermediate layer中间层/upper layer上层/top layer顶层The Empire帝国/ the Dark Ages黑暗时代/ the Middle Ages中世纪Topograph地形图/topography地形;地形学;地形测量学/topographic地形(学)上的Turnpike收费公路/toll system收费系统/ETC –Electronic Toll Collection电子收费3. Highway types公路类型Freeway高速公路;高速干道: freeway/expressway高速公路Controlled access highway控制进入高速公路Conventional highway传统的公路Highway公路;干道: arterial highway干线公路/bypass旁道,旁路/divided highway双向分隔行驶的公路;双向之间有分车带的公路/through street通过街/through highway通过公路Parkway停车道Scenic highway风景公路Street街,街道: Cul-de-Sac street小路尽头的街道/dead end street尽头街道/frontage street正街/local street地方街道Road路,道路,公路: frontage road街面道路/local road地方道路/toll road 收费道路(bridge桥,桥梁, tunnel隧道,地道)1. Technical termsCross section横断面/ Profile 纵断面(图),剖面(图)/Plan view平面视图Longitudinal section/ Transverse section 纵/横截面Lane/ Multilane/ Multiple lanes行车/多通道/多车道Roadway巷道Through traffic/ Local traffic/ Traffic island通过交通/交通/交通岛MedianRoadbed/ curb/ shoulder路基/ 路边,(人行道旁的)镶边石,边栏/肩Right-of-way 公路用地Surface course表面过程/ Wearing course磨损过程/ Basecourse基层/Flexible pavement柔性路面/ Rigid pavement刚性路面Cohesion凝聚力/ cohesive有粘着力的;凝聚性的;有结合力的Roadbase基层/ Subbase基层Crack/ Break/ Stress/ Distress裂纹/打破/压力/痛苦,窘迫的Modulus of elasticity弹性模量2. Main points1 Geometric Cross Section on Highway几何截面的公路上1.1 Lane巷1.2 Median位数1.3 Outer separation外部分离1.4 Roadbed路基1.5 Roadside路边1.6 Roadway巷1.7 Shoulder肩1.8 Travel way旅行方式Unit 4 Asphalt and Mix Asphalt沥青和沥青混合Technical termsMix/ mixture/ compound混合/混合物/复合Petroleum石油/ crude oil原油/ gasoline汽油/ diesel柴油/ gas可燃气;煤气;沼气/ petrol汽油Bitumen沥青/ bituminous 沥青的;含沥青的/ pitch搭(帐篷);扎(营)/asphalt沥青/ asphaltum沥青/ tar焦油;柏油,沥青Hydrocarbon碳氢化合物/ hydrau液Destructive distillation破坏性蒸馏Disulfate硫酸盐Emulsify乳化/ emulsion乳胶;乳状液/Dilute稀释/ diluents稀释剂/solvent有溶解力的/ cutter stock刀具的库存Oxygen氧,氧气/ oxidize使氧化/ oxidation 氧化(作用)/ oxidization 氧化/ dioxide二氧化物/ hydrogen氢/ sulphur硫磺Waterproof不透水的,防水的Acid/ alkalis/ salt/ alcohol酸/碱/盐/酒精Liquid/ fluid/ liquor/ liquefy液/液/液/液化Semi-solid半固态/ hard-brittle solid硬脆性固体/ water-thin liquidBinder粘结剂,捆缚(或包扎)用具;绳索,带子/ sticky粘的;涂有粘胶物质的;泥泞的/ viscous粘的/ adhesive粘的;粘着的;有粘性的/ viscosity粘质;粘性Hard-surface硬地/ hard-face硬面/ hard-surfaced road坚硬的路Tack coat粘结层Cut-back asphalt稀释沥青Penetration. 针入度Versatility多样化的/ flexibility易曲性;适应性,灵活性;弹性/ durability耐久性/ ability能力;能耐/ capacity 容量, 能力,才能,接受能力,理解力/ compactability紧/Rigidity 坚硬;严格;刚直;死板/ strength强度;(酒等的)浓度/ hardness硬性;硬度/ elastic 有弹性的,有弹力的/ rigid坚硬的;坚固的;不易弯曲的/ modules of elasticity弹性模数/Cold temperature cracking低温开裂/ warm temperature rutting高温车辙Performance 履行;实行;完成,演出/ grade等级;级别;阶段/ Performance Grading性能分级(PG)Aggregate使聚集Bin (贮藏谷物等的)箱子,容器,仓/ dryer干燥剂,催干剂/ pug mill练泥机/ drum鼓状物;圆桶/ tank (贮水,油,气等的)柜,罐,箱,槽latex乳汁;乳胶sulphur extended asphalt硫磺沥青混合料sulphur dioxide二氧化硫hydrogen sulphide硫化氢1. Technical termsStability 稳定,稳定性/ stabilize 使稳定,使稳固/availability有效;有益;可利用性/ available 可利用的,可得到的/Sense 感觉;意识;观念/ sensitivity敏感性;感受性Solubility 可溶性, 溶解度/ soluble 可溶解的/ solution溶解,解答;解决(办法); /Rutting车辙/ rust锈,铁锈;(脑子等的)迟钝;(能力等的)荒废/ tar焦油;柏油,沥青Roadstone石马路By-product副产品/ coke 焦,焦炭,焦煤/ coal gas 煤气/ kerosene煤油,火油Residue 残余,剩余,滤渣,残余物/ residual残留的;剩余的/ remain剩下,余留strengthen 加强;增强;巩固/ strength 力,力量, 强度/ deformation 毁坏;变形/ deform 使变形/ reform 改革,革新,改良elastic有弹性的,有弹力的/elasticity 弹性;弹力/plastic可塑的,塑性的/plasticity 可塑性;适应性;柔软性/chipping碎屑permanent永久的,永恒的;永远的, 固定性的;常在的/ temporary 临时的;暂时的,一时的poise使平衡;使平稳/ Dyne达因/ Newton 牛顿stiffness劲度/ stiff 硬的,僵直的,僵硬的/ stress压力;紧张;应力/ strain拉紧;拖紧;伸张/ fatigue疲劳,劳累Deduce演绎,推论/ deduction 扣除,减除,推论;演绎(法/ composition 构成;构图;成分penetration test渗透测试/ softening point test软化点试验/ ring and ball test环和球试验internal diameter 内部直径/ external diameter外部直径sample样品,样本;例子,实例/ water bath水浴arbitrary反复无常的,任性多变的;独断的,专制的/ pragmatic 实际的;实干的/ pragmatism 实用主义/fluidity 流动性;流状;易变(性)/ segregate分离/ susceptibility敏感性/ susceptible 敏感的, rheology流变学/ rheological 流变rolled asphalt碾压沥青synthetic polymer 合成聚合物/ additive附加的epoxy resin环氧树脂impart to传授/ deter威慑住,吓住;使断念/ deterrent 威慑的;遏制的container terminal集装箱码头/ airfield apron机场停机坪Unit 5 Cement and Concrete水泥和混凝土A. Technical termsCement水泥,胶结材料/ chalk粉笔/ matrix矩阵Cementitious 水泥Calcium钙/ calciferous钙/Lime石灰/ limestone石灰石Silica 硅土,二氧化硅/ silicate硅酸盐Aluminium铝/ alumina氧化铝/ aluminate铝sinter烧结coarse clinker粗水泥熟料calcium aluminate 铝酸钙/ calcium silicate硅酸钙hydrate水合物/ cure治疗/Work工作/ workable 可使用的,可运转的/ workability可使用性Shrinkage收缩/ swell膨胀/ swellable膨胀/ swellability溶胀strain拉紧;拖紧;伸张grout薄泥浆;水泥浆constituent组织/ ingredient成分/ component组成Thermal热的;热量的/ thermal coefficient of expansion热膨胀热系数Compressive strength抗压强度/ tensile strength拉伸强度Compressive压缩/ tensile 拉伸Reinforce加固/ reinforcing bar钢筋/ reinforced concrete钢筋混凝土Stiffness劲度Vulnerable脆弱的Efflorescence 风化/ weather天气/ weathering气候Column 柱/ volume体积/Pressure vessel压力容器1. Technical termsPrestress预应力Crew船员Contract 合同/ contractor承包商Resident engineer驻地工程师Inspector检查员Structural member结构构件Steel strand钢绞线Bridge girder桥主梁Pier cap墩帽Deck slab甲板Pretensioning先张法/ post-tensioning后张法Precast预制/ cast -in-place就地浇Box girder箱梁Predetermined stress预定压力Stretch拉伸/ relax 放松/ shorten 缩短/ induce诱导Duct 输送管;导管/ conduit导水管,导管/ pipe管,导管,输送管/ tube 管;筒/ canal管,道/ vessel 容器Anchor 锚/ Anchorage锚具corrosion腐蚀;侵入rebar钢筋/ reel卷轴tarpaulin 防水油布condense压缩/ condensation冷凝require要求/ requisite必要/ prerequisite不可缺的;事先需要的uniform 制服/ uniformity统一vary使多样化/ various不同的;各种各样的,形形色色的/ variable / variationcamber deflection 上弯翘起挠度creep蠕变Standard Specification 标准规范/ Sampling Guide取样指南Couple一双（对）/ coupler联结器Stir搅拌/ stirrup镫筋,箍筋/Web网络/ flange凸缘/ rib肋,肋骨/ side form形式Flimsy脆弱的Galvanize strip steel 镀锌带钢/ sheet steel钢片Weld焊接;熔接;锻接，使结合/ seam 缝;接缝,缝合处,接合口;裂缝Helical螺旋/helically螺旋形的/ helicopter直升飞机Contra-flexure反向弯曲/ parabolic curve抛物曲线Uplift隆起的Wobble摆动/ twist扭转;扭弯;旋转/ spall破碎Case事实，实例，案件/ Encase装箱Increment增加;增加量;增额Slack松弛的,不紧的;不严的Pressure gauge压力表/ load cell负载单元/ stretcher担架/ dynamometer动力计;力量计;握力计Dead end 尽头;困境/ stressing end强调结束Elongation measurement伸长测量法Spliced strand拼接链Tendon筋腱、预应力钢索、钢筋束Inject注射/ eject 逐出,轰出；喷射,吐出/ injection /ejectionVent通风孔,排气孔/ slut邋遢女子/ inlet valve入口阀Unit 6 Measuring Technology and Equipment测量技术及设备A. Technical termsSurvey测量/ surveyor测量员Horizontal/vertical/plumb/slope/ plan/plane垂直/水平/垂直/倾斜/计划/飞机Elevation高程Odometer 测距仪Circumference 圆周;周长/ circle圆/ circulate流通；传播/ circular 圆Tape带子,线带Tacheometry 视距测量Stadia 视距Theodolite /transit 经纬仪Rod 测杆、标尺Telescope望远镜Topographic survey地形测量Topographic mapping地形测绘Hydrographic mapping水文图Electronic distance measurement(EDM)电子距离测量Terrain地形;地势Electromagnetic电磁(体)的Velocity/speed速度/速度Band传送带；带,细绳Infrared/ ultraviolet 红外/紫外Module/ modulate模块/调节Passive/ active/ positive/ negative 被动/主动/积极/消极Perpendicular/ parallel 垂直/平行Clinometer / abney 测斜仪/水准仪Sextant六分仪/ sexagesimal 六十分数Compass界线;周围,圆规Protractor 量角器Unit 8 The Subgrade Design and Construction Technology路基设计与施工技术A. Technical termsUppermost / top soil 最上面/土壤Embankment / excavation路堤/挖掘Fill / cut填充/切割Foundation建立,创办；基础;基本原则Organic / inorganic / organ / organization有机/无机/机关/组织Imported soil / borrow sources进口/借用来源Dense / density / condense密/密度/凝结Moisture content含水量Classification分类;分级Differ / different / difference / differentiate不同的/不同/不同/分化Cobble / gravel / sand / silt / clay卵石/砾/砂/泥/粘土Fine grained soil细粒土Dry mass / dry matter干质量／干物质Semi-weathered半风化In-situ在原处;在原位置Infer推断Resilient modulus 回弹模量Manual 手的;手工的;用手操作的；体力的Backcalculate 反演计算Overlay覆盖;铺在...上面;镀；压倒Prototype原型;标准;模范Frost冰冻/ thaw融化,融解/ heave举起,拉起, /Guide / guidance / guideline指导/指南/指导方针Expansive soil 膨胀土Bentonitic shale 膨胀土页岩Soil modifier土壤改良剂Culvert阴沟;地下电缆管道；涵洞桥Form / formulate / formulation / formula形式/制定/公式化；规划;构想/公式Title——Highway Subgrade Construction公路路基施工1. Technical termsExcavation挖掘;开凿Borrow pit借土坑Sidestep回避Borrow ditch借沟Dispose / disposal处理/处置Surplus material剩余材料Approach接近,靠近Conforming / nonconforming material合格/不合格材料Top soil / superficial coatTurf 草皮土壤/表层stake mark危险标记subgrade edge路基边缘top of slope / foot of slope顶坡/坡脚berm 便道peg 桩facility 设施silt 泥沙,淤泥/ scour 冲刷permeable有渗透性的;可穿过的/ torrent 急流earthwork 土方量over-excavation挖blast 爆炸,爆破/ fetch soil 取土transverse 横向的;横断的;横切的/ longitudinal excavation纵向开挖hauling牵引backfill 回填self-dumper 自卸车segment / segmental部分；线段side wall侧壁rock filling填石/ borrow filling 借方填筑compaction machine压实机/ rolling passes碾压cut off切断;中断provided 以...为条件;假如(that)bench长凳;长椅；法官席;法官;法庭tamp / tamper 夯具Unit 9 Pavement Design and Construction Technology 路面设计与施工技术A. Technical termsSkid / skidding 打滑/集材/拖曳Free-draining自由排水Standing water站在水Imported/treated material进口/处理材料Platform平台,台Bound/unbound material绑定/绑定材料Bitumen-based material沥青基材料Unbound granular material松散颗粒材料Ingress入口Regular / Regularity /regulate定期/规律/调节Permeable / impermeable / permeability 渗透/渗透/渗透impermeability不渗透性Texture组织,结构,质地Tolerance忍耐,忍耐力；宽容,宽大Deep-seated 根深蒂固/由来已久/顽固的Remedy / remedial / diagnose药物/治疗/诊断Propagate / Propagation / propaganda路床面宣传/传播/宣传Formation 形态,结构Deem 认为Clear-cut 轮廓鲜明的/ 清晰的/ 皆伐Onset 开始Design life设计寿命Roadwork道路工程Discount折扣;打折扣1. Technical termsMacadam碎石Impetus 动力/推动Rubble瓦砾Avenue / street / road 路/街/路Stone Matrix Asphalt (SMA) 沥青玛蹄脂碎石混合料Sprayer喷雾器Gritting machine 铺砂机Mixing plant搅拌设备Spreader散布者；(涂奶油用的)奶油刀Paver摊铺机Roller 滚动物;滚柱;滚筒;滚轴Road binder道路粘合剂Guss asphalt/concrete 摊铺地沥青/混凝土Stone quarry 采石场Wear and tear磨损Unit 10 Highway Alignment Design 公路线形设计A. Technical termsHorizontal/vertical alignment水平/垂直对齐Configuration. 结构;表面配置Safe operating speed安全操作速度Sight distance视距Highway capacity / traffic volume公路容量/交通量tangent正切;切线Superelevation 超高Rate of grade change速度等级变化Horizontal/vertical curve 水平/垂直曲线criteria(判断、批评的)标准,准则,尺度simple circular curve简单的圆曲线spiral transition curve 螺旋缓和曲线compound curve 复合曲线sharp curve锐曲线sharp/slight curvature 急剧的；锋利的;尖的/轻微弯曲swept path扫路centerline. 中线runoff决赛;终投票outline外形;轮廓minimum curve radii最小曲线半径long / length / lengthen长/长度/延长reverse curve 反向曲线superelevation transition超高过渡providing / provided (that) 假如…urban / suburban / rural城市/郊区/农村stopping/passing sight distance停止/超车视距multiple decision point多个决策点sight line瞄准线middle ordinate 中距/正矢no-passing zone禁区1. Technical termsGrade line分数线Crest/sag vertical curve嵴/凹形竖曲线Auxiliary lane辅助车道Maximum/minimum grade最高/最低等级Detrimental有害的warp使变形;使弯曲;Standpoint观点Climbing lane爬坡车道Offset补偿;抵消Ramp exit gore匝道出口高尔Headlight beam前照灯光束Encroach侵犯Ponding water积水Water table地下水位Pavement box路面盒Prism棱柱(体),角柱(体)Balance point平衡点Unit 14 Bridge Introduction 桥梁简介A. Technical termsPipeline / cycle track / pedestrian管道/周期轨道/行人Superstructure / substructure上层建筑/结构Single storey building单层建筑物Handrail扶手/ guardstone守护石Bearing 关系,关联；举止,风度;体态Plan view平面视图Pier墩,墩/abutment桥墩;桥基;桥台；毗邻;接界处/wingwall翼墙/approach接近,靠近/apron 裙板Rivetment 固结Masonry石造工程;石造建筑Retaining wall挡土墙Subsoil / Earthfill地基/填土Well foundation 井筒基础Footpath小径,(乡间)小路Parapet wall 栏杆、女儿墙Topple 倾覆Buckle 受弯屈服Arch bridge 拱桥/Three Gorge三峡/ span墩距;跨度slab bridge / 板桥T-beam T梁bow string girder bridge 弓弦梁桥suspension bridge吊桥Cable-stayed bridge斜拉桥steel bridge桥梁钢rainbow bridge彩虹桥Niagara river 尼亚加拉河Shutter百叶窗;活动遮板Head room头部空间Tie beam系梁Thrust用力推；刺；插;塞;挤出(路)Arch rib 拱肋Suspender / stay吊带/保持Tower塔;塔楼;高楼Orthotropic deck正交异性桥面Continuous girder连续梁Three-dimensional三维Stiffening girder加劲梁Transverse/longitudinal/radial bracing横向/纵向/径向支撑Moment of inertia转动惯量Truss bridge桁架桥Rigid frame bridge刚构桥Axial force轴向力Portal frame门架Clearance清除,清扫;出空；空地;空隙Spandrel braced arch 腹拱、肩拱Trussed arch桁架拱桥1. Technical termsInclement恶劣的Investigation / FBI调查/调查局Reconnaissance侦察;勘察;事先考查Feasibility可行性;可能性Right angle直角Erosion侵蚀;腐蚀Whirl / cross current / scour旋转/交叉电流/冲刷render给予,提供；使得,使成为inerodable strata地层High Flood Level(HFL)高水位Discharge排出(液体,气体等)；允许...离开;释放;解雇Waterway航道Pier thickness桥墩厚度High flood大洪水Current meter电流表Velocity rod流速杆Free board自由板Catchment area汇水盆地,汇水区域Watershed转折点;关键时刻；流域Boring 钻孔、钻探Rainfall降雨,下雨;降雨量Span墩距;跨度Culvert涵洞桥Ordinary Flood Level(OFL)普通洪水水位Low Water Level(LWL)低水位Afflux 雍水Head room头部空间Viaduct 高架桥Trestled bent栈桥弯曲Causeway 漫水桥Submersible潜水Cross-drainage横向排水Temporary/ permanent bridge临时/永久性桥Deck/through/semi-through bridge上/下/中承式桥Formation 建造、路床面Pony小马；小型的东西Headway进展Vertical lift bridge 垂直升降桥Bascule bridge开合式桥Swing bridge 旋开式桥Box/pipe/arch culvert盒/管/拱涵Cast iron铸铁;生铁Bearing capacity承载能力Earth cushion地垫Unit 15 Bridge Superstructure桥梁上部结构A. Technical termsWeight limit重量限制supplier供应者Span Arrangement跨径布置Bridge Project Manager大桥项目经理Redundant多余的,过剩的specification 规格;明细单;详细计划书Fracture critical骨折的关键Collapse倒塌；崩溃,瓦解Ability / Inability能力/能力Bolt螺栓stringer纵梁;纵桁span / single-span / multi-span跨度/单跨/连栋continuous spans连续跨越steel/concrete superstructure bridge钢筋混凝土桥梁rolled beam 辊压梁cover plate盖板welded plate girder焊接板梁box girder 箱梁truss扎,捆,缚,绑；用构架支撑cable stayed斜拉tied arch 系杆拱桥vertical/inclined web垂直/斜腹板top/bottom flange plate顶部/底部法兰盘hollow rectangular/trapezoidal section空心的矩形/梯形截面aesthetics美学torsional resistance扭阻力curved bridge曲线桥stringer / floor beam斯特林格/地板梁top/bottom chord顶部/底部和弦vertical/diagonal member垂直/斜成员lateral/sway bracing侧/斜撑axial load/force轴向载荷/力量concrete deck / steel girder混凝土桥面/钢大梁Box beam箱梁Strongback定位板Fabricate / fabrication / fabricator制造/生产/制造Balanced cantilever平衡悬臂Strain gage应变计Homogeneity / non-homogeneity 均匀/非均匀性Erratic 不定、无规律的Deflection偏斜;偏向;挠曲;偏度;挠度Mid-span / middle span / side span跨中/ 中跨/ 边跨Yield出产;结出(果实);产生(效果,收益等)Non-linearity非线性的Prescribe规定,指定Limiting strain极限应变flexure弯曲;弯曲部分,曲率neutral axis中性轴centroid距心lever arm杠杆臂resultant compression/tension/force/load由此产生的压缩/拉伸/ /载荷equivalent stress block等效应力块investigation / FBI调查/调查局under-reinforced / over-reinforced少筋/ 超筋stress intensity应力强度product产品,产物;产量;出产nomenclature学术用语;术语表Unit 16 Bridge Substructure桥梁下部结构A. Technical termsCap-and column type pier柱式墩帽Strut 支撑、加固T-type pierT型Hammerhead pier锤头码头Taper逐渐减少;逐渐变弱Rectangular/oval column矩形或椭圆柱Wall type pier墙式墩Strut and tie model拉压杆模型footing(稳固的)地位;基础single column/multi-column单/多列concentrated load集中荷载wall abutment墙台caisson 沉箱gutter 槽stepped/terraced wall configuration加强/梯田壁配置stub abutment直式桥台integral abutment整体式桥台wingwall 翼墙bridge seat 桥座backwall 背墙stem柄,把,杆approach slab 搭板contour轮廓;轮廓线；外形;结构1. Technical termsSpread footing扩展基础Cofferdam 围堰Negative skin friction / downdrag force负摩/下拉荷载力Friction pile摩擦桩End bearing pile端承桩Drilled caisson钻孔灌注Constructibility可构成性Embedment嵌入Casing箱;盒Confinement curbing约束控制Wire mesh basket 网笼Gabion 枝条筐streambed河床Unit 20 ——Construction Management and Cost Estimate 施工组织与概预算A. Technical termsSchedule 进度表Event / task / action /activity活动/任务/行动/活动Ultimate disposition 最后安排Expense / expenditure / cost费用/费用/成本Recast重铸Uncertainty不确定;不确信;易变;不可靠Production rate / productivity生产效率/生产力Gantt chart / bar chart甘特图表/图表Superimpose叠加Critical Path Method (CPM)关键路径法Critical task关键任务Logic diagram逻辑图Superintendent监督人,监管者Activity-on-the-arrow (AOA)活动箭Activity-on-the-node (AON)节点活动Dummy activity 虚拟工序Early start time / late start time开始时间早/晚开始时间Early finish time / late finish time最早完成时间/最晚完成时间Double line / bold line / color highlighted line / dash line双行线/颜色/大胆突出线/虚线Float / total float / free float 浮动/总时差/自由浮动interfering float 时差Preceding activity / succeeding activity前面的活动/后继活动Title——Construction Cost Estimate 建筑成本预算1. Technical termsBreakdown故障,损坏,崩溃;破裂Parameter / parametric参数/参数Direct/indirect cost直接/间接成本Finance / budget财务/预算Craftman钱包Scheme / schematic计划/方案Unit cost/price单位成本/价格Lump sum总金额Site visit网站访问Checklist核对用的清单Take-off脱下;移去；起飞；休假Overhead / profit / bond费用/利润/债券Escalation / contingence升级/偶然Shift 转移;替换,推卸Craft行业,职业Ownership and operating cost所有权和经营成本Dozer / bulldozer推土机/推土机Vendor 卖主Tax税;税金Markup 售价Similarity / dissimilarity相似/相异Unit 21 Tendering and Contract 投标与合同A. Technical termsTender敏感的,嫩的;柔软的；温柔的,体贴的Bid / bidder招标投标Agreement同意,一致；协定,协议Bond结合力;联结,联系Insurance保险;保险契约Makeup补足；编造；组成Owner / architect / designer / supplier / party业主/建筑师/设计师/供应商/派对Public agency / private company公共部门/私营公司Responsibility职责,任务;义务,负担General/special/technical provision一般/特殊/技术discretion判断力;辨别力；谨慎,考虑周到addenda补遗;追加；附加物Title——Types of construction contracts and bonds建筑合同和担保的类型1. Technical termsNegotiation / renegotiation协商/谈判Arctic / Antarctic北极/南极Cost plus a fixed fee成本加固定费用Cost plus a percentage成本加百分比Incentive刺激;鼓励;动机Thrifty 节约Innovation革新,改革,创新Compensate补偿,赔偿;酬报Procure 获得、实施Popular / popularity / population流行/流行/人口Recoup 收回surety / obligee担保/债权人forfeiture 没收、罚金penal / penalty刑法/处罚underwrite / constraint认购/约束default 违约option选择;选择权;选择自由lien 扣留权、留置权。

中英文对照外文翻译(文档含英文原文和中文翻译)Bridge research in EuropeA brief outline is given of the development of the European Union, together with the research platform in Europe. The special case of post-tensioned bridges in the UK is discussed. In order to illustrate the type of European research being undertaken, an example is given from the University of Edinburgh portfolio: relating to the identification of voids in post-tensioned concrete bridges using digital impulse radar.IntroductionThe challenge in any research arena is to harness the findings of different research groups to identify a coherent mass of data, which enables research and practice to be better focused. A particular challenge exists with respect to Europe where language barriers are inevitably very significant. The European Community was formed in the 1960s based upon a political will within continental Europe to avoid the European civil wars, which developed into World War 2 from 1939 to 1945. The strong political motivation formed the original community of which Britain was not a member. Many of the continental countries saw Britain’s interest as being purelyeconomic. The 1970s saw Britain joining what was then the European Economic Community (EEC) and the 1990s has seen the widening of the community to a European Union, EU, with certain political goals together with the objective of a common European currency.Notwithstanding these financial and political developments, civil engineering and bridge engineering in particular have found great difficulty in forming any kind of common thread. Indeed the educational systems for University training are quite different between Britain and the European continental countries. The formation of the EU funding schemes —e.g. Socrates, Brite Euram and other programs have helped significantly. The Socrates scheme is based upon the exchange of students between Universities in different member states. The Brite Euram scheme has involved technical research grants given to consortia of academics and industrial partners within a number of the states— a Brite Euram bid would normally be led by an industrialist.In terms of dissemination of knowledge, two quite different strands appear to have emerged. The UK and the USA have concentrated primarily upon disseminating basic research in refereed journal publications: ASCE, ICE and other journals. Whereas the continental Europeans have frequently disseminated basic research at conferences where the circulation of the proceedings is restricted.Additionally, language barriers have proved to be very difficult to break down. In countries where English is a strong second language there has been enthusiastic participation in international conferences based within continental Europe —e.g. Germany, Italy, Belgium, The Netherlands and Switzerland. However, countries where English is not a strong second language have been hesitant participants }—e.g. France.European researchExamples of research relating to bridges in Europe can be divided into three types of structure:Masonry arch bridgesBritain has the largest stock of masonry arch bridges. In certain regions of the UK up to 60% of the road bridges are historic stone masonry arch bridges originally constructed for horse drawn traffic. This is less common in other parts of Europe as many of these bridges were destroyed during World War 2.Concrete bridgesA large stock of concrete bridges was constructed during the 1950s, 1960s and 1970s. At the time, these structures were seen as maintenance free. Europe also has a large number of post-tensioned concrete bridges with steel tendon ducts preventing radar inspection. This is a particular problem in France and the UK.Steel bridgesSteel bridges went out of fashion in the UK due to their need for maintenance as perceived in the 1960s and 1970s. However, they have been used for long span and rail bridges, and they are now returning to fashion for motorway widening schemes in the UK.Research activity in EuropeIt gives an indication certain areas of expertise and work being undertaken in Europe, but is by no means exhaustive.In order to illustrate the type of European research being undertaken, an example is given from the University of Edinburgh portfolio. The example relates to the identification of voids in post-tensioned concrete bridges, using digital impulse radar.Post-tensioned concrete rail bridge analysisOve Arup and Partners carried out an inspection and assessment of the superstructure of a 160 m long post-tensioned, segmental railway bridge in Manchester to determine its load-carrying capacity prior to a transfer of ownership, for use in the Metrolink light rail system..Particular attention was paid to the integrity of its post-tensioned steel elements. Physical inspection, non-destructive radar testing and other exploratory methods were used to investigate for possible weaknesses in the bridge.Since the sudden collapse of Ynys-y-Gwas Bridge in Wales, UK in 1985, there has been concern about the long-term integrity of segmental, post-tensioned concrete bridges which may b e prone to ‘brittle’ failure without warning. The corrosion protection of the post-tensioned steel cables, where they pass through joints between the segments, has been identified as a major factor affecting the long-term durability and consequent strength of this type of bridge. The identification of voids in grouted tendon ducts at vulnerable positions is recognized as an important step in the detection of such corrosion.Description of bridgeGeneral arrangementBesses o’ th’ Barn Bridge is a 160 m long, three span, segmental, post-tensionedconcrete railway bridge built in 1969. The main span of 90 m crosses over both the M62 motorway and A665 Bury to Prestwick Road. Minimum headroom is 5.18 m from the A665 and the M62 is cleared by approx 12.5 m.The superstructure consists of a central hollow trapezoidal concrete box section 6.7 m high and 4 m wide. The majority of the south and central spans are constructed using 1.27 m long pre-cast concrete trapezoidal box units, post-tensioned together. This box section supports the in site concrete transverse cantilever slabs at bottom flange level, which carry the rail tracks and ballast.The center and south span sections are of post-tensioned construction. These post-tensioned sections have five types of pre-stressing:1. Longitudinal tendons in grouted ducts within the top and bottom flanges.2. Longitudinal internal draped tendons located alongside the webs. These are deflected at internal diaphragm positions and are encased in in site concrete.3. Longitudinal macalloy bars in the transverse cantilever slabs in the central span .4. Vertical macalloy bars in the 229 mm wide webs to enhance shear capacity.5. Transverse macalloy bars through the bottom flange to support the transverse cantilever slabs.Segmental constructionThe pre-cast segmental system of construction used for the south and center span sections was an alternative method proposed by the contractor. Current thinking suggests that such a form of construction can lead to ‘brittle’ failure of the ent ire structure without warning due to corrosion of tendons across a construction joint，The original design concept had been for in site concrete construction.Inspection and assessmentInspectionInspection work was undertaken in a number of phases and was linked with the testing required for the structure. The initial inspections recorded a number of visible problems including:Defective waterproofing on the exposed surface of the top flange.Water trapped in the internal space of the hollow box with depths up to 300 mm.Various drainage problems at joints and abutments.Longitudinal cracking of the exposed soffit of the central span.Longitudinal cracking on sides of the top flange of the pre-stressed sections.Widespread sapling on some in site concrete surfaces with exposed rusting reinforcement.AssessmentThe subject of an earlier paper, the objectives of the assessment were:Estimate the present load-carrying capacity.Identify any structural deficiencies in the original design.Determine reasons for existing problems identified by the inspection.Conclusion to the inspection and assessmentFollowing the inspection and the analytical assessment one major element of doubt still existed. This concerned the condition of the embedded pre-stressing wires, strands, cables or bars. For the purpose of structural analysis these elements、had been assumed to be sound. However, due to the very high forces involved,、a risk to the structure, caused by corrosion to these primary elements, was identified.The initial recommendations which completed the first phase of the assessment were:1. Carry out detailed material testing to determine the condition of hidden structural elements, in particularthe grouted post-tensioned steel cables.2. Conduct concrete durability tests.3. Undertake repairs to defective waterproofing and surface defects in concrete.Testing proceduresNon-destructi v e radar testingDuring the first phase investigation at a joint between pre-cast deck segments the observation of a void in a post-tensioned cable duct gave rise to serious concern about corrosion and the integrity of the pre-stress. However, the extent of this problem was extremely difficult to determine. The bridge contains 93 joints with an average of 24 cables passing through each joint, i.e. there were approx. 2200 positions where investigations could be carried out. A typical section through such a joint is that the 24 draped tendons within the spine did not give rise to concern because these were protected by in site concrete poured without joints after the cables had been stressed.As it was clearly impractical to consider physically exposing all tendon/joint intersections, radar was used to investigate a large numbers of tendons and hence locate duct voids within a modest timescale. It was fortunate that the corrugated steel ducts around the tendons were discontinuous through the joints which allowed theradar to detect the tendons and voids. The problem, however, was still highly complex due to the high density of other steel elements which could interfere with the radar signals and the fact that the area of interest was at most 102 mm wide and embedded between 150 mm and 800 mm deep in thick concrete slabs.Trial radar investigations.Three companies were invited to visit the bridge and conduct a trial investigation. One company decided not to proceed. The remaining two were given 2 weeks to mobilize, test and report. Their results were then compared with physical explorations.To make the comparisons, observation holes were drilled vertically downwards into the ducts at a selection of 10 locations which included several where voids were predicted and several where the ducts were predicted to be fully grouted. A 25-mm diameter hole was required in order to facilitate use of the chosen horoscope. The results from the University of Edinburgh yielded an accuracy of around 60%.Main radar sur v ey, horoscope verification of v oids.Having completed a radar survey of the total structure, a baroscopic was then used to investigate all predicted voids and in more than 60% of cases this gave a clear confirmation of the radar findings. In several other cases some evidence of honeycombing in the in site stitch concrete above the duct was found.When viewing voids through the baroscopic, however, it proved impossible to determine their actual size or how far they extended along the tendon ducts although they only appeared to occupy less than the top 25% of the duct diameter. Most of these voids, in fact, were smaller than the diameter of the flexible baroscopic being used (approximately 9 mm) and were seen between the horizontal top surface of the grout and the curved upper limit of the duct. In a very few cases the tops of the pre-stressing strands were visible above the grout but no sign of any trapped water was seen. It was not possible, using the baroscopic, to see whether those cables were corroded.Digital radar testingThe test method involved exciting the joints using radio frequency radar antenna: 1 GHz, 900 MHz and 500 MHz. The highest frequency gives the highest resolution but has shallow depth penetration in the concrete. The lowest frequency gives the greatest depth penetration but yields lower resolution.The data collected on the radar sweeps were recorded on a GSSI SIR System 10.This system involves radar pulsing and recording. The data from the antenna is transformed from an analogue signal to a digital signal using a 16-bit analogue digital converter giving a very high resolution for subsequent data processing. The data is displayed on site on a high-resolution color monitor. Following visual inspection it is then stored digitally on a 2.3-gigabyte tape for subsequent analysis and signal processing. The tape first of all records a ‘header’ noting the digital radar settings together with the trace number prior to recording the actual data. When the data is played back, one is able to clearly identify all the relevant settings —making for accurate and reliable data reproduction.At particular locations along the traces, the trace was marked using a marker switch on the recording unit or the antenna.All the digital records were subsequently downloaded at the University’s NDT laboratory on to a micro-computer.（The raw data prior to processing consumed 35 megabytes of digital data.）Post-processing was undertaken using sophisticated signal processing software. Techniques available for the analysis include changing the color transform and changing the scales from linear to a skewed distribution in order to highlight、突出certain features. Also, the color transforms could be changed to highlight phase changes. In addition to these color transform facilities, sophisticated horizontal and vertical filtering procedures are available. Using a large screen monitor it is possible to display in split screens the raw data and the transformed processed data. Thus one is able to get an accurate indication of the processing which has taken place. The computer screen displays the time domain calibrations of the reflected signals on the vertical axis.A further facility of the software was the ability to display the individual radar pulses as time domain wiggle plots. This was a particularly valuable feature when looking at individual records in the vicinity of the tendons.Interpretation of findingsA full analysis of findings is given elsewhere, Essentially the digitized radar plots were transformed to color line scans and where double phase shifts were identified in the joints, then voiding was diagnosed.Conclusions1. An outline of the bridge research platform in Europe is given.2. The use of impulse radar has contributed considerably to the level of confidence in the assessment of the Besses o’ th’ Barn Rail Bridge.3. The radar investigations revealed extensive voiding within the post-tensioned cable ducts. However, no sign of corrosion on the stressing wires had been found except for the very first investigation.欧洲桥梁研究欧洲联盟共同的研究平台诞生于欧洲联盟。

Aabsolute datum 绝对基面abutment 桥台abutment pier 制动墩acceleration lane 加速车道accidental load 偶然荷载accommodation lane 专用车道acoustic barrier 隔音墙acting circles of blasting 爆破作用圈additional stake 加桩adjacent curve in one direction 同向曲线admixture 外加剂admixture 反坡安全线aerial photogrammetry 航空摄影测量aerophoto base 航摄基线aerophoto interpretation 航摄像片判读ageing 老化aggregate 集料（骨料）air hardining 气硬性alignment design ( 城市道路) 平面设计，线形设计alignment element 线形要素alligator cracking 路面龟裂allowable rebound deflection 容许( 回弹）弯沉alternative line 比较线anchored bulkhead abutment 锚锭板式桥台anchored bulkhead abutment 锚锭板式挡土墙anchored retaining wall 锚杆式挡土墙anionic emulsified bitumen 阴离子乳化沥青ann l average daily traffic 年平均日交通量anti—creep heap ( 厂矿道路) 挡车堆anti-dizzling screen 防炫屏( 遮光栅)antiskid heap （厂矿道路）防滑堆approach span 引桥aquitard 隔水层arch bridge 拱桥arch culvert 拱涵arch ring 拱圈arterial highway 干线公路arterial road ( 厂内）主干道, （城市) 主干路asphalt distributor 沥青洒布车asphalt mixing plant 沥青混合料拌和设备asphalt remixer 沥青混合料摊铺机asphalt remixer 复拌沥青混合料摊铺机asphalt sand 沥青砂asphalt sprayer 沥青洒布机asphaltic bitumen 地沥青at—grade intersection 平面交叉auxiliary lane 附加车道average consistency （of soil) 土的) 平均稠度average gradient 平均纵坡aximuth angle 方位角Bbalance weight retaining wall 衡重式挡土墙base course 基层base line 基线basic traffic capacity 基本通行能力beam bridge 梁桥beam level deflectometer 杠杆弯沉仪bearing 支座bearing angle 象限角bearing pile 支承桩bearing platform 承台bed course 垫层bench mark 水准点benched s grade 台口式路基bending strength 抗弯强度Benkelman beam 杠杆弯沉仪（贝克曼弯沉仪) bent cap 盖梁berm 护坡道binder 结合料binder course 联结层bitumen 沥青bitumen （沥青混合料）抽提仪bitumen—aggregate ratio 油石比bituminous concrete pavement 沥青混凝土混合料bituminous concrete mixture 沥青混凝土路面bituminous concrete moxture 沥青碎石混合料bituminous macadam pavement 沥青碎石路面bituminous moxture 沥青混合料bituminous pavement 沥青路面bituminous penetration pavement 沥青贯入式路面biuminous surface treatment ( 沥青) 表面处治blasting crater 爆破漏斗blastion for loosening rock 松动爆破blasting for throwing rock 抛掷爆破blasting procedure 土石方爆破bleeding 泛油blind ditch 盲沟blind drain 盲沟block pavement 块料路面block stone 块石blow up 拱胀boring 钻探boring log ( 道路) 地质柱状图boring machine 钻孔机borrow earth 借土borrow pit 取土坑boundary frame on crossing 道口限界架boundary frame on road 道路限界架boundary line of road constr tion 道路建筑限界bowstring arch bridge 系杆拱桥box culvert 箱涵branch pipe of inlet 雨水口支管branch road ( 城市）支路, ( 厂内) 支道bridge 桥梁bridge decking 桥面系bridge deck pavement 桥面铺装bridge floor expantion and contraction installation traction installation 桥面伸缩装置bridge gerder erection equpment 架桥机bridge on slope 坡桥bridge site 桥位bridle road 驮道broken chainage 断链broken stone 碎石broken back curve 断背曲线buried abutment 埋置式桥台bus bay 公交( 车辆）停靠站bypass 绕行公路Ccable bent tower 索塔cable saddle 索鞍cable stayed bridge 斜拉桥( 斜张桥)Cableway erecting equipment 缆索吊装设备California bearing ratio (CBR）加州承载比(CBR) California bearing ratio tester 加州承载比(CBR）测定仪camber cruve 路拱曲线cantilever beam bridge 悬臂梁桥cantilever beam bridge 悬臂式挡土墙capacity of intersection 交叉口通行能力capacity of network 路网通行能力capillary water 毛细水carriage way 车行道（行车道）cast-in-place cantilever method 悬臂浇筑法cationic emulsified bitumen 阳离子乳化沥青cattle—pass 畜力车道cement concrete 水泥混凝土cemint concrete pavement 水泥混凝土混合料cement concrete pavement 水泥混凝土路面center-island 中心岛center lane 中间车道center line of raod 道路中线center line survey 中线测量center stake 中桩central reserve 分隔带channelization 渠化交通channelization island 导流岛channelized intrersection 分道转弯式交叉口chip 石屑chute 急流槽circular curve 圆曲线circular curve 环路circular test 环道试验city road 城市道路civil engineering fabric 土工织物classified highway 等级公路classified highway 等级道路clay—bound macadam 泥结碎石路面clearance 净空clearance above bridge floor 桥面净空clearce of span 桥下净空climatic zoning for highway 公路自然区划climbing lane 爬坡车道cloverleaf interchange 苜蓿叶形立体交叉coal tar 煤沥青cobble stone 卵石coefficient of scouring 冲刷系数cohesive soil 粘性土cold laid method 冷铺法cold mixing method 冷拌法cold—stretched steel bar 冷拉钢筋column pier 柱式墩combination-type road system 混合式道路系统compaction 压实compaction test 击实试验compaction test apparatus 击实仪compactness test 压实度试验composite beam bridge 联合梁桥composite pipe line 综合管道（综合管廊) compound curve 复曲线concave vertical curve 凹形竖曲线concrete joint cleaner ( 水泥混凝土) 路面清缝机concrete joint sealer （水泥混凝土）路面填缝机concrete mixing plant 水泥混凝土( 混合料) 拌和设备concrete paver 水泥混凝土（混合料) 摊铺机concrete pump 水泥混凝土（混合料) 泵concrete saw （水泥混凝土）路面锯缝机cone penetration test 触探试验conflict point 冲突点conical slope 锥坡consistency limit (of soil) ( 土的）稠度界限consolidated s soil 加固地基consolidation 固结constr tion by swing 转体架桥法constr tion height of bridge 桥梁建筑高度constr tion joint 施工缝constr tion load 施工荷载constr tion survey 施工测量continuous beam bridge 连续梁桥contourline 等高线contraction joint 缩缝control point 路线控制点converging 合流convex vertining wall 凸形竖曲线corduroy road 木排道counterfout retaining wall 扶壁式挡土墙counterfort abutmen 扶壁式桥台country road 乡村道路county road 县公路（县道) ，乡道creep 徐变critical speed 临界速度cross roads 十字形交叉cross slope 横坡cross walk 人行横道cross-sectional profile 横断面图cross—sectional survey 横断面测量crown 路拱crushed stone 碎石crushing strength 压碎值culture 地物culvert 涵洞curb 路缘石curb side strip 路侧带curve length 曲线长curve widening 平曲线加宽curved bridge 弯桥cut 挖方cut corner for sight line （路口）截角cut—fill transition 土方调配cut-fill transition 土方调配图cutting 路堑cycle path 自行车道cycle track 自行车道Ddeceleration lane 减速车道deck bridge 上承式桥deflection angle 偏角deflection test 弯沉试验degree of compaction 压实度delay 延误density of road network 道路（网）密度depth of tunnel 隧道埋深design elevation of s grade 路基设计高程design freqncy ( 排水) 设计重现期design hourly volume 设计小时交通量design of evevation ( 城市道路）竖向设计design of vertical alignment 纵断面设计design speed 计算行车速度( 设计车速)design traffic capacity 设计通行能力design vehicle 设计车辆design water level 设计水位desiged dldvation 设计高程designed flood freqncy 设计洪水频率deslicking treatment 防滑处理Deval abrasion testion machine 狄法尔磨耗试验机（双筒式磨耗试验机）diamond interchange 菱形立体交叉differential photo 微分法测图direction angle 方向角directional interchange 定向式立体交叉diverging 分流dowel bar 传力杆drain opening 泄水口drainage by pumping station ( 立体交叉）泵站排水drainage ditch 排水沟dressed stone 料石drop water 跌水dry concrtet 干硬性混凝土d tility （of bitumen）（沥青）延度d tilometer （沥青）延度仪dummy joint 假缝dynamic consolidation 强夯法Eeconomic speed 经济车速econnomical hauling distance 土方调配经济运距element support 构件支撑elevation 高程( 标高）embankment 路堤emergency parking strip 紧急停车带emulsified bitumen 乳化沥青erecting by floating 浮运架桥法erection by longit inal pulling method 纵向拖拉法erection by protrusion 悬臂拼装法erection with cableway 缆索吊装法evaporation pond 蒸发池expansion bearing 活动支座expansive soil 膨胀土expansion joint 胀缝expressway （城市）快速路external distance 外( 矢) 距Ffabricated bridge 装配式桥fabricated steel bridge 装拆式钢桥factories and mines road 厂矿道路factory external transportation line 对外道路factory-in road 厂内道路factory—out road 厂外道路fast lane 内侧车道faulting of slab ends 错台feeder highway 支线公路ferry 渡口fibrous concrete 纤维混凝土field of vision 视野fill 填方filled spandrel arch bridge 实腹拱桥final survey 竣工测量fineness 细度fineness modulus 细度模数fixed bearing 固定支座flare wing wall abutment 八字形桥台flared intersection 拓宽路口式交叉口flash 闪点flash point tester (open cup method) 闪点仪( 开口杯式）flexible pavement 柔性路面flexible pier 柔性墩floor system 桥面系flush curb 平缘石foot way 人行道ford 过水路面forest highway 林区公路forest road 林区道路foundation 基础free style road system 自由式道路系统free way 高速公路free—flow speed 自由车速freeze road 冻板道路freezing and thawing test 冻融试验frost boiling 翻浆frozen soil 冻土full depth asphalt pavement 全厚式沥青( 混凝土）路面function planting 功能栽植Ggeneral scour under bridge opening 桥下一般冲刷geological section ( 道路) 地质剖面图geotextile 土工织物gradation 级配gradation of stone ( 路用）石料等级grade change point 变坡点grade compensation 纵坡折减grade crossing 平面交叉grade length limitation 坡长限制grade of side slope 边坡坡度grade separation 简单立体交叉grade-separated junction 立体交叉graded aggregate pavement 级配路面brader 平地机grain composition 颗粒组成granular material 粒料gravel 砾石gravity pier （abutment) 重力式墩、台gravity retaining wall 重力式挡土墙green belt 绿化带gridiron road system 棋盘式道路系统ground control—point survey 地面控制点测量ground elevation 地面高程ground stereophoto grammetry 地面立体摄影测量g rd post 标柱g rd rail 护栏g rd wall 护墙gully 雨水口gutter 街沟( 偏沟）gutter apron 平石gutter drainage 渠道排水Hhalf-through bridge 中承式桥hard shoulder 硬路肩hardening 硬化hardness 硬度haul road 运材道路heavy maintenance 大修hectometer stake 百米桩hedge 绿篱height of cut and fill at ceneter stake 中桩填挖高度high strength bolt 高强螺栓high type pavement 高级路面highway 公路highway landscape design 公路景观设计hill-side line 山坡线( 山腰线）hilly terrain 重丘区horizontal alignment 平面线形horizontal curve 平曲线hot laid method 热铺法hot mixing method 热拌法hot stability （of bitumen) ( 沥青）热稳性hydraulic computation 水力计算hydraulic computation 水硬性Iimaginary intersection point 虚交点immersed tunnelling method 沉埋法inbound traffic 入境交通incremental launching method 顶推法industrial district road 工业区道路industrial solid waste ( 路用）工业废渣industrial waste base course 工业废渣基层inlet 雨水口inlet s merged culvert 半压力式涵洞inlet uns merged culvert 无压力式涵洞inorganic binder 无机结合料instrument station 测站intensity of rainstorm 暴雨强度intercepting detch 截水沟interchange 互通式立体交叉interchange woth special bicycle track 分隔式立体交叉intermediate maintenance 中修intermediate type pavement 中级路面intersection ( 平面) 交叉口intersection angle 交叉角，转角intersection entrance 交叉口进口intersection exit 交叉口出口intersection plan 交叉口平面图intersection point 交点intersection with widened corners 加宽转角式交叉口Jjack-in method 顶入法Kkilometer stone 里程碑Lland slide 坍方lane 车道lane-width 车道宽度lateral clear distance of curve （平曲线）横净距lay—by 紧急停车带level of service 道路服务水平leveling course 整平层leveling survey 水准测量light—weight concrete 轻质混凝土lighting facilities of road 道路照明设施lime pile 石灰桩line development 展线linking-up road 联络线，连接道路liquid asphaltic bitumen 液体沥青liquid limit 液限living fence 绿篱load 荷载loading berm 反压护道lading combinations 荷载组合loading plate 承载板loading plate test 承载板试验local scour near pier 桥墩局部冲刷local traffic 境内交通location of line 定线location survey 定测lock bolt support with shotcrete 喷锚支护loess 黄土longit inal beam 纵梁longit inal gradient 纵坡longit inal joint 纵缝loop ramp 环形匝道Los Angeles abrasion testing machine 洛杉矶磨耗试验机Mmachine （搁板式磨耗试验机）low rype pavement 低级路面main beam 主梁main bridge 主桥maintenance 养护maintenance period 大中修周期manhole 检查井marginal strip 路缘带marshall stability apparatus 马歇尔稳定度仪Marshall stability test 马歇尔试验masonry bridge 圬工桥maximum ann l hourly volume 年最大小时交通量maximum dry unit weight （标准）最大干密度maximum longit inal gradient 最大纵坡mine tunnelling method 矿山法mineral aggregate 矿料mineral powder 矿粉mini-roundabout 微形环交minimum height of fill （路基) 最小填土高度minimum longit inal gradient 最小纵坡minimum radius of horizontal curve 最小平曲线半径minimum turning radius 汽车最小转弯半径mixed traffic 混合交通mixing method 拌和法mixture 混合料model split 交通方式划分modulus of elasticity 弹性模量modulus of resilience 回弹模量modulus ratio 模量比monthly average daily traffic 月平均日交通量motor way 高速公路mountainous terrain 山岭区movable bridge 开启桥m 淤泥multiple-leg intersection 多岔交叉mational trunk highway 国家干线公路（国道) matural asphalt 天然沥青Nnatural scour 自然演变冲刷natural s soil 天然地基navigable water level 通航水位nearside lane 外侧车道net—shaped cracking 路面网裂New Austrian Tunnelling Method 新奥法Oobservation point 测点one—way ramp 单向匝道open cut method 明挖法open cut tunnel 明洞open spandrel arch bridge 空腹拱桥opencast mine road 露天矿山道路operating speed 运行速度optimum gradation 最佳级配optimum moisture content 最佳含水量optimum speed 临界速度organic binder 有机结合料origin—destination st y 起迄点调查outbound traffic 出境交通outlet s merged culvert 压力式涵洞outlet inlet main road 城市出入干道overall speed 区间速度overlay of pavement 罩面overpass grade separation 上跨铁路立体交叉overtaking lane 超车车道overtaking sight distance 超车视距Ppaper location 纸上定线paraffin content test 含蜡量试验parent soil 原状土parking lane 停车车道parking lot 停车场parking station 公交（车辆) 停靠站part out—part fill s grade 半填半挖式路基pass 垭口passing bay 错车道patrol maintenance 巡回养护paved crossing 道口铺面pavement 路面pavement depression 路面沉陷pavement recapping 路面翻修pavement slab pumping 路面板唧泥pavement spalling 路面碎裂pavement strengthening 路面补强pavement str ture layer 路面结构层pavemill 路面铣削机( 刨路机)peak hourly volume 高峰小时交通量pedestrian overcrossing 人行天桥pedestrian underpass 人行地道penetration macadam with coated chips 上拌下贯式( 沥青) chips 路面penetration method 贯入法penetration test apparatus 长杆贯入仪penetration (of bitumen）( 沥青) 针入度penetrometer （沥青) 针入度仪periodical maintenance 定期养护permafrost 多年冻土permanent load 永久荷载perviousness test 透水度试验petroleum asphaltic bitumen 石油沥青photo index 像片索引图( 镶辑复照图）photo mosaic 像片镶嵌图photogrammetry 摄影测量photographic map 影像地图pier 桥墩pile and plank retaining wall 柱板式挡土墙pile bent pier 排架桩墩pile driver 打桩机pipe culvert 管涵pipe drainage 管道排水pit test 坑探pitching method 铺砌法plain stage of slope 边坡平台plain terrain 平原区plan view （路线) 平面图plane design ( 城市道路）平面设计plane sketch ( 道路）平面示意图planimetric photo 综合法测图plant mixing method 厂拌法plasticity index 塑限plasticity index 塑性指数poisson's ratio 泊松比polished stone val石料磨光值pontoon bridge 浮桥porosity 空隙率portable pendulum tester 摆式仪possible traffic capacity 可能通行能力post-tensioning method 后张法pot holes 路面坑槽preliminary survey 初测preloading method 预压法prestressed concrete 预应力混凝土prestressed concrete bridge 预应力混凝土桥prestresed steel bar drawing jack 张拉预应力钢筋千斤顶pretensioning method 先张法prime coat 透层prod tive arterial road 生产干线prod tive branch road 生产支线profile design 纵断面设计profilometer 路面平整度测定仪proportioning of cement concrete 水泥混凝土配合比protection forest fire—proof road 护林防火道路provincial trunk highway 省干线公路（省道）Rrailroad grade crossing ( 铁路) 道口ramp 匝道rebound deflection 回弹弯沉reclaimed asphalt mixture 再生沥青混合料reclaimed bituminous pavement 再生沥青路面reconnaissance 踏勘red clay 红粘土reference stake 护桩reflection crack 反射裂缝refuge island 安全岛regulating str ture 调治构造物reinforced concrete 钢筋混凝土reinforced concrete bridge 钢筋混凝土桥reinforced concrete pavement 钢筋混凝土路面reinforced earth retaining wall 加筋土挡土墙relative moisture content （of soil）（土的）相对含水量relief road 辅道residential street 居住区道路resultant gradient 合成坡度retaining wall 挡土墙revelling of pavement 路面松散reverse curve 反向曲线reverse loop 回头曲线ridge crossing line 越岭线ridge line 山脊线right bridge 正交桥right bridge 正桥rigid frame bridge 刚构桥rigid pavement 刚性路面rigid—type base 刚性基层ring and radial road system 环形辐射式道路系统ripper 松土机riprap 抛石road 道路road alignment 道路线形road appearance 路容road area per citizen ( 城市）人均道路面积road area ratio ( 城市）道路面积率road axis 道路轴线road bed 路床road bitumen 路用沥青road condition 路况road condition survey 路况调查road crossing ( 平面) 交叉口road crossing design 交叉口设计road engineering 道路工程road feasibility st y （道路工程）可行性研究road improvement 改善工程road intersection 道路交叉( 路线交叉)road mixing method 路拌法road network 道路网road network planning 道路网规划road planting 道路绿化road project （道路工程）方案图road trough 路槽road way 路幅rock breaker 凿岩机rock filled gabion 石笼roller 压路机rolled cement concrete 碾压式水泥混凝土rolling terrain 微丘区rotary interchange 环形立体交叉rotary intersection 环形交叉roundabout 环形交叉route development 展线rout of road 道路路线route selection 选线routine maintenance 小修保养r ble 片石running speed 行驶速度rural road 郊区道路Ssaddle back 垭口safety belt 安全带safety fence 防护栅salty soil 盐渍土sand 砂sanddrain (sand pile) 砂井sand gravel 砂砾sand hazard 沙害sand mat of s grade 排水砂垫层sand patch test 铺砂试验sand pile 砂桩sand protection facilities 防沙设施sand ratio 砂率sand sweeping 回砂sand sweeping equipment 回砂机sandy soil 砂性土saturated soil 饱和土scraper 铲运机seal coat 封层secondary trunk road （厂内）次干道，（城市) 次干路seepage well 渗水井segregation 离析semi—rigid type base 半刚性基层separate facilties 分隔设施separator 分隔带sheep—foot roll 羊足压路机( 羊足碾)shelter belt 护路林shield 盾构( 盾构挖掘机)shield tunnelling method 盾构法shoulder 路肩shrinkage limit 缩限side ditch 边沟side slope 边坡side walk 人行道sieve analysis 筛分sight distance 视距sight distance of intersection 路口视距sight line 视线sight triangle 视距三角形silty soil 粉性土simple supported beam bridge 简支梁桥singl direction thrusted pier 单向推力墩single—sizeaggregat 同粒径集料siphon culvert 倒虹涵skew bridge 斜交桥skew bridge 斜桥skid road 集材道路slab bridge 板桥slab culvert 盖板涵slab staggering 错位slide 滑坡slope protection 护坡slump 坍落度snow hazard 雪害snow plough 除雪机snow protection facilities 防雪设施soft ground 软弱地基soft soil 软土softening point tester （ring ball）( 沥青) 软化点议仪method （环- 球法)softening point （of bitumen）沥青）软化点sol ility (of bitumen）（沥青）溶解度space headway 车头间距space mean speed 空间平均速度span 跨径span by span method 移动支架逐跨施工法spandrel arch 腹拱spandrel str ture 拱上结构special vehicle 特种车辆speed—change lane 变速车道splitting test 劈裂试验spot speed 点速度spreading in layers 层铺法springing 弹簧现象stabilizer 稳定土拌和机stabilized soil base course 稳定土基层stage for heating soil and broken rock 碎落台staggered junction 错位交叉stand axial loading 标准轴截steel bridge 钢筋冷墩机steel bridge 钢桥steel extension machine 钢筋拉伸机stiffness modulus 劲度stone coating test 石料裹覆试验stone crusher 碎石机stone spreader 碎石撒布机stopping sight distance 停车视距stopping tr k heap （厂矿道路) 阻车堤street 街道street drainage 街道排水street planting 街道绿化street trees 行道树strengthening layer 补强层strengthening of str ture 加固stringer 纵梁striping test for aggregate 集料剥落试验str tural approach limit of tunnel 隧道建筑限界s —high type pavement 次高级路面s grade 路基s grade drainage 路基排水s mersible bridge 漫水桥s sidence 沉陷s soil 地基s str ture 下部结构super elevation 超高super elevation runoff 超高缓和段superstr ture 上部结构supported type abutment 支撑式桥台surface course 面层surface evenness 路面平整度surface frostheave 路面冻胀surface permeameter 路面透水度测定仪surface roughness 路面粗糙度surface slipperinness 路面滑溜surface water 地表水surface—curvature apparatus 路面曲率半径测定仪surrounding rock 围岩suspension bridge 悬索桥swich—back curve 回头曲线TTintersection 丁字形交叉（T 形交叉) T—shaped rigid frame bridge 形刚构桥tack coat 粘层tangent length 切线长tar 焦油沥青technical standard of road 道路技术标准Telford 锥形块石Telford base ( 锥形）块石基层terrace 台地thermal insulation berm 保温护道thermal insulation course 隔温层thirtieth highest ann l hourly 年第30 位最大小时volume 交通量through bridge 下承式桥through traffic 过境交通tie bar 拉杆timber bridge 木桥time headway 车头时距time mean speed 时间平均速度toe of slope （边) 坡脚tongand groove joint 企口缝top of slope ( 边) 坡顶topographic feature地貌topographic map 地形图topographic survey 地形测量topography 地形township road 乡公路( 乡道）traffic assignment 交通量分配traffic capacity 通行能力traffic composition 交通组成traffic density 交通密度traffic distribution 交通分布traffic flow 交通流traffic generation 交通发生traffic island 交通岛traffic mirror 道路反光镜traffic planning 道路交通规划traffic safety device 交通安全设施traffic sq re 交通广场traffic stream 车流traffic survey 交通调查traffic volume 交通量traffic volume observation station 交通量观测站traffic volume 交通量预测traffic volume survey 交通量调查transition curve 缓和曲线transition slab at bridge head 桥头搭板transition zone of cross section 断面渐变段transition zone of curve widening 加宽缓和段transitional gradient 缓和坡段transverse beam 横梁transverse joint 横缝traverse 导线traverse survey 导线测量trencher 挖沟机triaxial test 三轴试验trip 出行trjoint 真缝trumpet interchange 喇叭形立体交叉trunk highway 干线公路truss bridge 桁架桥tunnel （道路) 隧道tunnel boring machine 隧道掘进机tunnel ling 衬砌tunnel portal 洞门tunnel support 隧道支撑turnaround loop 回车道，回车场turning point 转点two—way curved arch bridge 双曲拱桥two—way ramp 双向匝道type of dry and damp soil base 土基干湿类型UU-shaped abutment U 形桥台under-ground pipes comprehensive design 管线综合设计\underground water 地下水underground water level 地下水位underpass grade separation 下穿铁路立体交叉universal photo 全能法测图urban road 城市道路Vvalley line 沿溪线variable load 可变荷载vehicle stream 车流vehicular gap 车( 辆）间净距verge 路肩vertical alignment 纵面线形vertical curb 立缘石（侧石）vertical curve 竖曲线vertical profile map （路线）纵断面图viameter 路面平整度测定仪vibratory roller 振动压路机viscosimeter （沥青) 粘度仪viscosity (of bitumen）( 沥青) 粘( 滞) 度void ratio 孔隙比Wwashout 水毁waste 弃土waste bank 弃土堆water cement ratio 水灰比water content 含水量water level 水位water red ing agent 减水剂water stability 水稳性water—bound macadam 水结碎石路面wearing course 磨耗层weaving 交织weaving point 交织点weaving section 交织路段wheel tracking test 车辙试验width of s grade 路基宽度workability 和易性YY intersection 形交叉。

Design of reinforced concrete bridgesP. Jackson Giord and PartnersThe shortest span reinforced concrete decks are built as solid slabs. These may be supported on bearings although, due to durability issues with expansion joints and bearings, it is usually preferable to cast them integral with in-situ abutments or place them as part of pre cast box culverts. As the span increases, the optimum form of construction changes to voided slab or beam and slab then box girder bridges. Open spandrel arches enable relatively long spans, more commonly built in steel or prestressed concrete, to be built efficiently in reinforced concrete. Reinforced concrete is also used for deck slabs and substructures for bridges with main elements of steel or prestressed concrete. The key design criteria and checks required by codes are the same regardless of the form of construction. These are for ultimate strength in flexure, shear and torsion and for serviceability issues including crack widths and service stresses. For elements with significant live load ratios, reinforcement fatigue may sometimes also have to be checked. IntroductionMost modern small bridges are of reinforced concrete construction and nearly all modern bridges contain some elements of reinforced concrete (RC). In this chapter, the design of reinforced concrete bridge superstructures is considered and some aspects of the design criteria for reinforced concrete, which are also relevant to other reinforced concrete substructures and reinforced concrete parts of bridges with steel or prestressed main elements, are reviewed.Some specific aspects which are most often relevant to deck slabs in bridges with prestressed or steel beams will be considered in the section on beam and slab bridges.In situ reinforced concrete construction has the great advantage of simplicity; formwork is placed, reinforcement fixed and concrete poured and the structure is then com-plete. In modern practice, precast bridge elements are usually prestressed. For smaller elements, this is because pretensioning on long line beds is a convenient method of providing the steel. For larger structures, post-tensioning provides the most convenient way of fixing manageable sized elements together. The result is that, with some exceptions which will be discussed, purely reinforced concrete bridges are usually cast in situ.In the following, the various types of RC bridge are considered and the design criteria for reinforced concrete are then reviewed.Solid slab bridgesSingle spansThe solid slab is the simplest form of reinforced concrete bridge deck. Ease of construction resulting from the sim-plicity makes this the most economic type for short span structures. Solid slabs also have good distribution properties which makes them efficient at carrying concentrated movable loads such as wheel loads for highway bridges. However, above a span of around 10m the deadweight starts to become excessive, making other forms of construction more economic.Solid slab bridges can be simply supported on bearings or built into the abutments. Until recently, bridge engineers tended to be quite pedantic about providing for expansion and even bridges as short as 9m span were often provided with bearings and expansion joints. However, bearings and expansion joints have proved to be among the most troublesome components of bridges. In particular, deterior-ation of substructures due to water leaking through expan-sion joints has been common especially in bridges carrying roads where de-icing salt is used.Recently, the fashion has changed back to designing bridges that are cast integral with theabutments or bank seats (Department of Transport, 1995). Apart from the durability advantages, this can lead to saving in the deck due to the advantage of continuity. On short span bridges with relatively high abutment walls, being able to use the deck to prop the abutments can also lead to significant savings in the abutments. However, this normally depends on being able to build the deck before backfilling behind the abutments. When assumptions about construction approach such as this are made in design, it is important that they should be properly conveyed to the contractor, normally by stating them on the drawings.A feature of the design of integral bridges which has not always been appreciated is that, because the deck is not structurally isolated from the substructure, the stress state in the deck is dependent on the soil properties. This inevitably means that the analysis is less ‘accurate’than in conventional structures. Neither the normal at-rest pressure behind abutments nor the resistance to movement is ever very accurately known. It might be argued that, because of this, designs should be done for both upper and lower bounds to soil properties. In practice, this is not generally done and the design criteria used have sufficient reserve so that this does not lead to problems.Depending on the ground conditions, span and obstacle crossed, the abutments of asingle-span bridge may be separate or may be joined to form a complete box. Such box type structures have the advantage that they can be built without piles even in very poor ground, as the bearing pressure is low. Since the box structure is likely to be lighter than the displaced fill, the net bearing pressure is often negative. This can lead to problems in made ground as the embankment either side of the box may settle much more than the box, leading to problems with vertical align-ment and damage to the surfacing or rails over the bridge.RC slab bridges are normally cast in situ. An exception is very short span shallower structures (typically up to some 6m span and 3.6m clear height) which can be most eco-nomically precast effectively complete as box culverts, leav-ing only parapets and, where required, wing walls to cast in situ. This form of construction is most commonly used for conveying watercourses under embankments but can be used for footway and cycletracks.In situ construction is very convenient for greenfield sites and for crossing routes that can be diverted. It is less con-venient for crossing under or over live routes. For the latter, spanning formwork can be used if there is sufficient headroom. However, in many cases beam bridges are more convenient and the precast beams will normally be pre-stressed. RC box type structures can, however, be installed under live traffic. They can be pushed under embankments. The issues are considered by Allenby and Ropkins (2004). A reasonable amount of fill over the box is needed to do this under live traffic. The box structure is cast adjacent to its final position and then jacked into position with anti-drag ropes preventing the foundations below and the fill above moving with it. If there is not much fill depth, it becomes impractical to push the box whilst keeping a road or rail route over the top still. A similar approach can, how-ever, be used with the box cast in advance and then jacked into place in open cut over a relatively short possession.Multiple spansIn the past, some in situ multi-span slab bridges were built which were simply supported. However, unlike in bridges built from precast beams, it is no more complicated to build a continuous bridge. Indeed, because of the absence of the troublesome and leak-prone expansion joints, it may actually be simpler. It is therefore only in exceptional circumstances (for example construction in areas subject to extreme differential settlement due to mining subsidence) thatmultiple simply supported spans are now used.Making the deck continuous or building it into the abut-ments also leads to a significant reduction in the mid-span sagging moments in the slab.The advantage of this continuity in material terms is much greater than in bridges of pre-stressed beam construction where creep redistribution effects usually more than cancel out the saving in live load moments.Various approaches are possible for the piers. Either leaf piers can be used or discrete columns. Unlike in beam bridges, the latter approach needs no separate transverse beam. The necessary increase in local transverse moment capacity can be achieved by simply providing additional transverse reinforcement in critical areas. This facility makes slab bridges particularly suitable for geometrically complicated viaducts such as arise in some interchanges in urban situations. Curved decks with varying skew angles and discrete piers in apparently random locations can readily be accommodated.Whether discrete columns or leaf piers are used, they can either be provided with bearings or built into the deck. The major limitation on the latter approach is that, if the bridge is fixed in more than one position, the pier is subject to significant moments due to the thermal expansion and contraction of the deck. Unless the piers are very tall and slender, this usually precludes using the approach for more than one or two piers in a viaduct.Voided slab bridgesAbove a span of about 10–12m, the dead weight of a solid slab bridge starts to become excessive. For narrower bridges, significant weight saving can be achieved by using relatively long transverse cantilevers giving a bridge of ‘spine beam’form as shown in Figure 1. This canextend the economic span range of this type of structure to around 16m or more. Above this span, and earlier for wider bridges, a lighter form of construction is desirable.One of the commonest ways of lightening a solid slab is to use void formers of some sort. The commonest form is circular polystyrene void formers. Although polystyrene appears to be impermeable, it is only the much more expensive closed cell form which is so. The voids should therefore be provided with drainage holes at their lower ends. It is also important to ensure that the voids and reinforcement are held firmly in position in the formwork during construction. This avoids problems that have occurred with the voids floating or with the links moving to touch the void formers, giving no cover.Provided the void diameters are not more than around 60% of the slab thickness and nominal transverse steel is provided in the flanges, the bridge can be analysed much as a solidslab. That is, without considering either the reduced transverse shear stiffness or the local bending in the flanges. Unlike the previous British code, EN 1992-2 (BSI, 2005) does not give specific guidance on voided slabs. However, some is provided in the accompanying ‘PD’pub- lished by the British Standards Institution (BSI, 2008a).The section is designed longitudinally in both flexure and shear allowing for the voids. Links should be provided and these are designed as for a flanged beam with the minimum web thickness.The shear stresses are likely to become excessive near supports, particularly if discrete piers are used. However, this problem can be avoided by simply stopping the voids off, leaving a solid section in these critical areas.If more lightening is required, larger diameter voids or square voids forming a cellular deck can be used. These do then have to be considered in analysis. The longitudinal stiff-ness to be used for a cellular deck is calculated in the normal way, treating the section as a monolithic beam.Transversely, such a structure behaves quite differently under uniform and non-uniform bending. In the former, the top and bottom flanges act compositely whereas in the latter they flex about their separate neutral axes as shown in Figure 2. This means the correct flexural inertia can be an order of magnitude greater for uniform than non-uniform bending. The behaviour can, however, be modelled in a conventional grillage model by using a shear deformable grillage. The composite flexural properties are used and the extra defor-mation under non-uniform bending is represented by calcu-lating an equivalent shear stiffness.Having obtained the moments and forces in the cellular structure, the reinforcement has to be designed. In addition to designing for the longitudinal and transverse moments on the complete section, local moments in the flanges have to be considered. These arise from the wheel loads applied to the deck slab and also from the transverse shear. This shear has to be transmitted across the voidsby flexure in the flanges, that is by the section acting like a vierendeel frame as shown in Figure 2.Voided slab bridges typically have the rather utilitarian appearance typical of bridges with the type of voided section shown in Figure 1 and with either single spans or with intermediate piers of either leaf or discrete vertical pier form. However, one of the potential great advantages of concrete is that any shape can be formed. Figure 3 shows a voided slab bridge of more imaginative appearance which carries main line rail loading. To make most efficient use of the curved soffit varying depth section, different sizes of void were used across the width.Beam and slab bridgesIn recent years, in situ beam and slab structures have been less popular than voided slab forms, while precast beams have generally been prestressed. Reinforced beam andslab structures have therefore been less common. However, there is no fundamental reason why they should not be used and there are thousands of such structures in service.One of the disadvantages of a beam and slab structure compared with a voided slab or cellular slab structure is that the distribution properties are relatively poor. In the UK at least, this is less of a disadvantage than it used to be. This is because the normal traffic load has increased with each change of the loading specification, leaving the abnormal load the same until the most recent change which could actually make it less severe for shorter spans. However, reinforced concrete beam and slab bridges do not appear to have increased in popularity as a result. They are more popular in some other countries.The relatively poor distribution properties of beam and slab bridges can be improved by providing one or more transverse beams or diaphragms within the span, rather than only at the piers. In bridges built with precast beams, forming these ‘intermediate diaphragms’is extremely inconvenient and therefore expensive so they have become unusual. However, in an in situ structure which has to be built on falsework, it makes relatively little difference and is therefore more viable.The beams for a beam and slab structure are designed for the moments and forces from the analysis. The analysis is now usually computerised in European practice, although the AASHTO (2002) code encourages the use of a basically empirical approach.Having obtained the forces, the design approach is the same as for slabs apart from the requirement for nominal links in all beams. Another factor is that if torsion is consid-ered in the analysis the links have to be designed for torsion as well as for shear. Itis, however,acceptable practiceto use torsionless analysis at least for right decks.Because the deck slab forms a large top flange, the beams of beam and slab bridges are more efficiently shaped for resisting sagging than hogging moments. It may therefore be advantageous to haunch them locally over the piers even in relatively short-span continuous bridges.The biggest variation in practice in the design of beam and slab structures is in the reinforcement of the deck slab. A similar situation arises in the deck slabs of bridgeswhere the main beams are steel or prestressed concrete and this aspect will now be considered.Conventional practice in North America was to design only for the moments induced in the deck slab by its action in spanning between the beams supporting wheel loads (the ‘local moments’). These moments were obtained from Westergaard (1930) albeit usually by way of tables given in AASHTO. British practice also uses elastic methods to obtain local moments, usuallyeither Westergaard or influ-ence charts such as Pucher (1964). However, the so-called‘global transverse moments’, the moments induced in the deck slab by its action in distributing load between the beams, are considered. These moments, obtained from the global analysis of the bridge, are added to the local moments obtained from Westergaard (1930) or similar methods. Only‘co-existent’moments (the moments induced in the same part of the deck under the same load case) are considered, and the worst global and local moments often do notcoin-cide. However, this still has a significant effect. In bridges with very close spaced beams (admittedly rarely used in North America) the UK approach can give twice the design moments of the US approach.Although the US approach may appear theoretically unsound (the global moments obviously do exist in American bridges), it has produced satisfactory designs.One reason for this is that the local strength of the deck slabs is actually much greater than conventional elastic analysis suggests. This has been extensively researched (Hewit and Batchelor, 1975; Holowka and Csagoly, 1980;Kirkpatrick et al., 1984).In Ontario (Ontario Ministry of Transportation and Communications, 1983) empirical rules have been devel-oped which enable such slabs to be designed very simply and economically. Although these were developed without major consideration of global effects, they have been shown to work well within the range of cases they apply to (Jack-son and Cope, 1990). Similar rules have been developed in Northern Ireland (Kirkpatrick et al., 1984) and elsewhere but they have not been widely accepted in Europe.Longer span structuresIn modern practice, purely reinforced structures longer than about 20m span are quite unusual; concrete bridges of this size are usually prestressed. However, there is no funda-mental reason why such structures should not be built.The longest span reinforced concrete girder bridges tend to be of box girder form. Although single cell box girders are a well-defined form of construction, there is no clear-cut distinction between a ‘multi-cellular box girder’and a voided slab. However, the voids in voided slab bridges are normally formed with polystyrene or other permanent void formers, whereas box girders are usually formed with removable formwork. The formwork can only be removed if the section is deep enough for access, which effectively means around 1.2m minimum depth. Permanent access to the voids is often provided. In older structures, this was often through manholes in the top slab. This means traffic management is required to gain access and also means there is the problem of water, and de-icing salt where this is used, leaking into the voids. It is therefore preferable to provide access from below.In a continuous girder bridge (particularly one with only two spans) the hogging moments, particularly the perma-nent load moments, over the piers are substantially greater than the sagging moments at mid-span. This, combinedwith the greater advantage of saving weight near mid-span, encourages longer span bridges to be haunched. Haunching frequently also helps with the clearance required for road, rail or river traffic under the bridge by allowing a shallower section elsewhere.The longest span and most dramatic purely reinforced concrete bridges are open spandrel arches as in the Catha-leen’s Falls Bridge shown in Figure 4. The true arch form suits reinforced concrete well as the compressive force in the arch rib increases its flexural strength. As a result, the form is quite efficient in terms of materials.Because of the physical shape of the arch and the require- ment for good ground conditions to resist the lateral thrust force from the arch, this form of construction is limited in its application. It is most suitable for crossing valleys in hilly country. The simplest way to build such a structure is on falsework. However, the falsework required is very extensive and hence relatively expensive. Because of this, such bridges are often more expensive than structurally less efficient forms, such as prestressed cantilever bridges, that can be built with less temporary works. However, they may still be economic in some circumstances, particularly in countries where the labour required to erect the falsework is relatively cheap. A further factor may be local availability of the materials in countries where the prestressing equip-ment or structural steelwork required for other bridges of this span range would have to be imported.It is also possible to devise other ways of building arches.They have been built out in segments from either end supported by tying them back with temporary stays. Another approach, which is only likely to be viable with at least three spans, is to insert temporary diagonal mem- bers so that the bridge, including the columns supporting the deck and at least main longitudinal members at deck level, can be built bay by bay behaving as a truss until it is joined up.The efficiency of arch structures, like other forms used for longer span bridges, arises because the shape is optimised for resisting the near-uniform forces arising from dead load which is the dominant load. The profile of the arch is arranged to minimise the bending moments in it. Theoretically, the optimum shape approximates to a catenary if the weight of the rib dominates or a parabola if the weight of the deck dominates but the exact shape is unlikely to be critical.Arch structures can be so efficient at carrying dead weight that applying the usual load factor for dead load actually increases live load capacity by increasing the axial force in, andhence flexural capacity of, the rib. The design code’s lesser load factor (normally 1.0) for‘relieving effects’should be applied to dead weight when this arises. However, the letter of many codes only requires this to be applied in certain cases which are defined in such a way that it does not appear to apply here. This cannot be justified philosophi-cally and the reduced factor should be used.Because the geometry is optimised for a uniform load,loading the entire span is unlikely to be the critical live load case, unlike in a simple single-span beam bridge. It will normally be necessary to plot influence lines to determine the critical case. For uniform loads, this is often loading a half-span.Arch bridges have been built in which the live load bending moments are taken primarily by the girders at deck level, enabling the arch ribs to be very slim in appear-ance. However, the more usual approach is to build the arch rib first and then build the deck structure afterwards, possibly even after the falsework has been struck so that this does not have to be designed to take the full load.The deck structure is then much like a normal viaduct supported on piers from the arch rib and the rib has to take significant moments.In the past, reinforced concrete truss structures have also been built but they are not often used in modern practice because the building costs are high due to the complexity of formwork and reinforcement.Design calculationGeometryThe shape of reinforced concrete bridges is usually decided by experience aided by typical span-to-depth ratios. The design calculations are only really used to design the reinforcement. A typical simply supported slab has a span-to-depth ratio of around 10–15 but continuous or integral bridges can be shallower. Because the concentrated live load (i.e. the wheel load) the deck has to carry does not reduce with span, the span-to-depth ratio of short span slabs tends to be towards the lower end of the range.However, deck slabs of bigger bridges often have greater span-to-depth ratios than slab bridges. This is economic because the dead weight of the slab, although an insignifi-cant part of the load on the slab, is significant to the global design of the bridge.There was a fashion for very shallow bridges in the 1960s and 1970s as they were considered to look more elegant. However, unless increasing the construction depth has major cost implications elsewhere (such as the need to raise embankments) it is likely to be more economic to use more than the minimum depth. The appearance dis-advantage on short span bridges can be resolved by good detailing of the edges. Bridge decks with short transverse cantilevers at the edges tend to look shallower than vertical sided bridges even if they are actually deeper.Having decided the dimensions of the bridge, the design calculations then serve primarily to design the reinforce-ment and the key checks will now be considered. They will be illustrated mainly by considering slab structures but most of the principles apply to all reinforced concrete. Ultimate strength in flexure and torsionReinforced concrete is normally designed for ultimate strength in flexure first. This is partly because this is usually, although not invariably, the critical design criterion.Another reason is that reinforcement can be more readily designed directly for this criterion. For other criteria, suchas crack width or service stresses, a design has to be assumed and then checked. This makes thedesign process iterative. A first estimate is required to start the iterative procedure and the ultimate strength design provides such an estimate.Although other analytical methods give better estimates of strength, elastic analysis is usually used in design. This has to be used when checking serviceability criteria. Because of this, the use of more economic analyses at the ultimate limit state (such as yield-line analysis) invariably results in other criteria (such as cracking or stress limits) becoming critical leaving little or no advantage.Concrete slabs have to resist torsion as well as flexure. However, unlike in a beam, torsion and flexure in slabs are not separate phenomena. They interact in the same way that direct and shear stresses interact in plane stress situations. They can be considered in the same way: thatis using Mohr’s circle. Theoretically, it is most efficient to use orthogonal reinforcement placed in the directions of maximum and minimum principal moments. Since there is no torsion in these directions, torsion does not then have to be considered. However, it is not often practical to do this as the principal moment directions change with both position in the slab and load case.In right slabs the torsional moments in the regions (the elements of the computer model where this is used),where the moments are maximum, are relatively small and can often be ignored. In skew slabs, in contrast, the torsions can be significant. The usual approach is to design for an increased equivalent bending moment in the reinforcement directions. Wood (1968) has published the relevant equations for orthogonal steel and Armer (1968) for skew steel. Many of the computer programs commonly used for the analysis of bridge decks have post-processors that enable them to give these corrected moments, com-monly known as ‘Wood–Armer’moments, directly. To enable them to do this, it is necessary to specify the direc-tion of the reinforcement.When the reinforcement is very highly skewed, the Wood–Armer approach leads to excessive requirements for transverse steel. When assessing existing structures, this problem can be avoided by using alternative analytical approaches. However, in design it is usually preferable to avoid the problem by avoiding the use of very highly skewed reinforcement. The disadvantage of this is that it makes the reinforcement detailing of skew slab bridges more complicated. This arises because the main steel in the edges of the slab has to run parallel with the edges. Orthogonal steel can therefore only be achieved in the centre of the bridge either by fanning out the steel or bypro-viding three layers in the edge regions. That is, one parallel to the edge in addition to the two orthogonal layers.When torsion is considered, it will be found that there is a significant requirement for top steel in the obtuse corners even of simply supported slabs. It can be shown using other analytical methods (such as yield-line or torsionless grillage analysis) that equilibrium can be satisfied without resisting these moments. The top steel is therefore not strictly necessary for ultimate strength. However, the moments are real and have caused significant cracking in older slab structures which were built without this steel. It is therefore preferable to reinforce for them. Ultimate strength in shearShear does not normally dictate the dimensions of the element. However, codes allow slabs (unlike beams) which do not have shear reinforcement and it is economically desirable to avoid shear reinforcement in these if e of links is particularly inconvenient in very shallow slabs, such as in box culverts or the deck slabs of beam and slab bridges, and many codes do not allow them to be considered effective. The shear strength rules can therefore be critical in design.。

absolute datum 绝对基面abutment 桥台abutment pier 制动墩acceleration lane 加速车道accidental load 偶然荷载accommodation lane 专用车道acoustic barrier 隔音墙acting circles of blasting 爆破作用圈additional stake 加桩adjacent curve in one direction 同向曲线admixture 外加剂admixture 反坡安全线aerial photogrammetry 航空摄影测量aerophoto base 航摄基线aerophoto interpretation 航摄像片判读ageing 老化aggregate 集料 ( 骨料 )air hardining 气硬性alignment design ( 城市道路 ) 平面设计，线形设计alignment element 线形要素alligator cracking 路面龟裂allowable rebound deflection 容许 ( 回弹 ) 弯沉alternative line 比较线anchored bulkhead abutment 锚锭板式桥台anchored bulkhead abutment 锚锭板式挡土墙anchored retaining wall 锚杆式挡土墙anionic emulsified bitumen 阴离子乳化沥青ann l average daily traffic 年平均日交通量anti-creep heap ( 厂矿道路 ) 挡车堆anti-dizzling screen 防炫屏 ( 遮光栅 )antiskid heap ( 厂矿道路 ) 防滑堆approach span 引桥aquitard 隔水层arch bridge 拱桥arch culvert 拱涵arch ring 拱圈arterial highway 干线公路arterial road ( 厂内 ) 主干道， ( 城市 ) 主干路asphalt distributor 沥青洒布车asphalt mixing plant 沥青混合料拌和设备asphalt remixer 沥青混合料摊铺机asphalt remixer 复拌沥青混合料摊铺机asphalt sand 沥青砂asphalt sprayer 沥青洒布机asphaltic bitumen 地沥青at-grade intersection 平面交叉auxiliary lane 附加车道average consistency (of soil) 土的 ) 平均稠度average gradient 平均纵坡aximuth angle 方位角Bbalance weight retaining wall 衡重式挡土墙base course 基层base line 基线basic traffic capacity 基本通行能力beam bridge 梁桥beam level deflectometer 杠杆弯沉仪bearing 支座bearing angle 象限角bearing pile 支承桩bearing platform 承台bed course 垫层bench mark 水准点benched s grade 台口式路基bending strength 抗弯强度Benkelman beam 杠杆弯沉仪 ( 贝克曼弯沉仪 ) bent cap 盖梁berm 护坡道binder 结合料binder course 联结层bitumen 沥青bitumen ( 沥青混合料 ) 抽提仪bitumen-aggregate ratio 油石比bituminous concrete pavement 沥青混凝土混合料bituminous concrete mixture 沥青混凝土路面bituminous concrete moxture 沥青碎石混合料bituminous macadam pavement 沥青碎石路面bituminous moxture 沥青混合料bituminous pavement 沥青路面bituminous penetration pavement 沥青贯入式路面biuminous surface treatment ( 沥青 ) 表面处治blasting crater 爆破漏斗blastion for loosening rock 松动爆破blasting for throwing rock 抛掷爆破blasting procedure 土石方爆破bleeding 泛油blind ditch 盲沟blind drain 盲沟block pavement 块料路面block stone 块石blow up 拱胀boring 钻探boring log ( 道路 ) 地质柱状图boring machine 钻孔机borrow earth 借土borrow pit 取土坑boundary frame on crossing 道口限界架boundary frame on road 道路限界架boundary line of road constr tion 道路建筑限界bowstring arch bridge 系杆拱桥box culvert 箱涵branch pipe of inlet 雨水口支管branch road ( 城市 ) 支路， ( 厂内 ) 支道bridge 桥梁bridge decking 桥面系bridge deck pavement 桥面铺装bridge floor expantion and contraction installation traction installation 桥面伸缩装置bridge gerder erection equpment 架桥机bridge on slope 坡桥bridge site 桥位bridle road 驮道broken chainage 断链broken stone 碎石broken back curve 断背曲线buried abutment 埋置式桥台bus bay 公交 ( 车辆 ) 停靠站bypass 绕行公路Ccable bent tower 索塔cable saddle 索鞍cable stayed bridge 斜拉桥 ( 斜张桥 )Cableway erecting equipment 缆索吊装设备California bearing ratio (CBR) 加州承载比 (CBR)California bearing ratio tester 加州承载比 (CBR) 测定仪camber cruve 路拱曲线cantilever beam bridge 悬臂梁桥cantilever beam bridge 悬臂式挡土墙capacity of intersection 交叉口通行能力capacity of network 路网通行能力capillary water 毛细水carriage way 车行道 ( 行车道 )cast-in-place cantilever method 悬臂浇筑法cationic emulsified bitumen 阳离子乳化沥青cattle-pass 畜力车道cement concrete 水泥混凝土cemint concrete pavement 水泥混凝土混合料cement concrete pavement 水泥混凝土路面center-island 中心岛center lane 中间车道center line of raod 道路中线center line survey 中线测量center stake 中桩central reserve 分隔带channelization 渠化交通channelization island 导流岛channelized intrersection 分道转弯式交叉口chip 石屑chute 急流槽circular curve 圆曲线circular curve 环路circular test 环道试验city road 城市道路civil engineering fabric 土工织物classified highway 等级公路classified highway 等级道路clay-bound macadam 泥结碎石路面clearance 净空clearance above bridge floor 桥面净空clearce of span 桥下净空climatic zoning for highway 公路自然区划climbing lane 爬坡车道cloverleaf interchange 苜蓿叶形立体交叉coal tar 煤沥青cobble stone 卵石coefficient of scouring 冲刷系数cohesive soil 粘性土cold laid method 冷铺法cold mixing method 冷拌法cold-stretched steel bar 冷拉钢筋column pier 柱式墩combination-type road system 混合式道路系统compaction 压实compaction test 击实试验compaction test apparatus 击实仪compactness test 压实度试验composite beam bridge 联合梁桥composite pipe line 综合管道 ( 综合管廊 )compound curve 复曲线concave vertical curve 凹形竖曲线concrete joint cleaner ( 水泥混凝土 ) 路面清缝机concrete joint sealer ( 水泥混凝土 ) 路面填缝机concrete mixing plant 水泥混凝土 ( 混合料 ) 拌和设备concrete paver 水泥混凝土 ( 混合料 ) 摊铺机concrete pump 水泥混凝土 ( 混合料 ) 泵concrete saw ( 水泥混凝土 ) 路面锯缝机cone penetration test 触探试验conflict point 冲突点conical slope 锥坡consistency limit (of soil) ( 土的 ) 稠度界限consolidated s soil 加固地基consolidation 固结constr tion by swing 转体架桥法constr tion height of bridge 桥梁建筑高度constr tion joint 施工缝constr tion load 施工荷载constr tion survey 施工测量continuous beam bridge 连续梁桥contourline 等高线contraction joint 缩缝control point 路线控制点converging 合流convex vertining wall 凸形竖曲线corduroy road 木排道counterfout retaining wall 扶壁式挡土墙counterfort abutmen 扶壁式桥台country road 乡村道路county road 县公路 ( 县道 ) ，乡道creep 徐变critical speed 临界速度cross roads 十字形交叉cross slope 横坡cross walk 人行横道cross-sectional profile 横断面图cross-sectional survey 横断面测量crown 路拱crushed stone 碎石crushing strength 压碎值culture 地物culvert 涵洞curb 路缘石curb side strip 路侧带curve length 曲线长curve widening 平曲线加宽curved bridge 弯桥cut 挖方cut corner for sight line ( 路口 ) 截角cut-fill transition 土方调配cut-fill transition 土方调配图cutting 路堑cycle path 自行车道cycle track 自行车道Ddeceleration lane 减速车道deck bridge 上承式桥deflection angle 偏角deflection test 弯沉试验degree of compaction 压实度delay 延误density of road network 道路（网）密度depth of tunnel 隧道埋深design elevation of s grade 路基设计高程design freqncy ( 排水 ) 设计重现期design hourly volume 设计小时交通量design of evevation ( 城市道路 ) 竖向设计design of vertical alignment 纵断面设计design speed 计算行车速度 ( 设计车速 )design traffic capacity 设计通行能力design vehicle 设计车辆design water level 设计水位desiged dldvation 设计高程designed flood freqncy 设计洪水频率deslicking treatment 防滑处理Deval abrasion testion machine 狄法尔磨耗试验机（双筒式磨耗试验机）diamond interchange 菱形立体交叉differential photo 微分法测图direction angle 方向角directional interchange 定向式立体交叉diverging 分流dowel bar 传力杆drain opening 泄水口drainage by pumping station ( 立体交叉 ) 泵站排水drainage ditch 排水沟dressed stone 料石drop water 跌水dry concrtet 干硬性混凝土d tility (of bitumen) ( 沥青 ) 延度d tilometer ( 沥青 ) 延度仪dummy joint 假缝dynamic consolidation 强夯法Eeconomic speed 经济车速econnomical hauling distance 土方调配经济运距element support 构件支撑elevation 高程 ( 标高 )embankment 路堤emergency parking strip 紧急停车带emulsified bitumen 乳化沥青erecting by floating 浮运架桥法erection by longit inal pulling method 纵向拖拉法erection by protrusion 悬臂拼装法erection with cableway 缆索吊装法evaporation pond 蒸发池expansion bearing 活动支座expansive soil 膨胀土expansion joint 胀缝expressway ( 城市 ) 快速路external distance 外 ( 矢 ) 距Ffabricated bridge 装配式桥fabricated steel bridge 装拆式钢桥factories and mines road 厂矿道路factory external transportation line 对外道路factory-in road 厂内道路factory-out road 厂外道路fast lane 内侧车道faulting of slab ends 错台feeder highway 支线公路ferry 渡口fibrous concrete 纤维混凝土field of vision 视野fill 填方filled spandrel arch bridge 实腹拱桥final survey 竣工测量fineness 细度fineness modulus 细度模数fixed bearing 固定支座flare wing wall abutment 八字形桥台flared intersection 拓宽路口式交叉口flash 闪点flash point tester (open cup method) 闪点仪 ( 开口杯式 ) flexible pavement 柔性路面flexible pier 柔性墩floor system 桥面系flush curb 平缘石foot way 人行道ford 过水路面forest highway 林区公路forest road 林区道路foundation 基础free style road system 自由式道路系统free way 高速公路free-flow speed 自由车速freeze road 冻板道路freezing and thawing test 冻融试验frost boiling 翻浆frozen soil 冻土full depth asphalt pavement 全厚式沥青 ( 混凝土 ) 路面function planting 功能栽植Ggeneral scour under bridge opening 桥下一般冲刷geological section ( 道路 ) 地质剖面图geotextile 土工织物gradation 级配gradation of stone ( 路用 ) 石料等级grade change point 变坡点grade compensation 纵坡折减grade crossing 平面交叉grade length limitation 坡长限制grade of side slope 边坡坡度grade separation 简单立体交叉grade-separated junction 立体交叉graded aggregate pavement 级配路面brader 平地机grain composition 颗粒组成granular material 粒料gravel 砾石gravity pier (abutment) 重力式墩、台gravity retaining wall 重力式挡土墙green belt 绿化带gridiron road system 棋盘式道路系统ground control-point survey 地面控制点测量ground elevation 地面高程ground stereophoto grammetry 地面立体摄影测量g rd post 标柱g rd rail 护栏g rd wall 护墙gully 雨水口gutter 街沟 ( 偏沟 )gutter apron 平石gutter drainage 渠道排水Hhalf-through bridge 中承式桥hard shoulder 硬路肩hardening 硬化hardness 硬度haul road 运材道路heavy maintenance 大修hectometer stake 百米桩hedge 绿篱height of cut and fill at ceneter stake 中桩填挖高度high strength bolt 高强螺栓high type pavement 高级路面highway 公路highway landscape design 公路景观设计hill-side line 山坡线 ( 山腰线 )hilly terrain 重丘区horizontal alignment 平面线形horizontal curve 平曲线hot laid method 热铺法hot mixing method 热拌法hot stability (of bitumen) ( 沥青 ) 热稳性hydraulic computation 水力计算hydraulic computation 水硬性Iimaginary intersection point 虚交点immersed tunnelling method 沉埋法inbound traffic 入境交通incremental launching method 顶推法industrial district road 工业区道路industrial solid waste ( 路用 ) 工业废渣industrial waste base course 工业废渣基层inlet 雨水口inlet s merged culvert 半压力式涵洞inlet uns merged culvert 无压力式涵洞inorganic binder 无机结合料instrument station 测站intensity of rainstorm 暴雨强度intercepting detch 截水沟interchange 互通式立体交叉interchange woth special bicycle track 分隔式立体交叉intermediate maintenance 中修intermediate type pavement 中级路面intersection ( 平面 ) 交叉口intersection angle 交叉角，转角intersection entrance 交叉口进口intersection exit 交叉口出口intersection plan 交叉口平面图intersection point 交点intersection with widened corners 加宽转角式交叉口Jjack-in method 顶入法Kkilometer stone 里程碑Lland slide 坍方lane 车道lane-width 车道宽度lateral clear distance of curve ( 平曲线 ) 横净距lay-by 紧急停车带level of service 道路服务水平leveling course 整平层leveling survey 水准测量light-weight concrete 轻质混凝土lighting facilities of road 道路照明设施lime pile 石灰桩line development 展线linking-up road 联络线，连接道路liquid asphaltic bitumen 液体沥青liquid limit 液限living fence 绿篱load 荷载loading berm 反压护道lading combinations 荷载组合loading plate 承载板loading plate test 承载板试验local scour near pier 桥墩局部冲刷local traffic 境内交通location of line 定线location survey 定测lock bolt support with shotcrete 喷锚支护loess 黄土longit inal beam 纵梁longit inal gradient 纵坡longit inal joint 纵缝loop ramp 环形匝道Los Angeles abrasion testing machine 洛杉矶磨耗试验机Mmachine ( 搁板式磨耗试验机 )low rype pavement 低级路面main beam 主梁main bridge 主桥maintenance 养护maintenance period 大中修周期manhole 检查井marginal strip 路缘带marshall stability apparatus 马歇尔稳定度仪Marshall stability test 马歇尔试验masonry bridge 圬工桥maximum ann l hourly volume 年最大小时交通量maximum dry unit weight ( 标准 ) 最大干密度maximum longit inal gradient 最大纵坡mine tunnelling method 矿山法mineral aggregate 矿料mineral powder 矿粉mini-roundabout 微形环交minimum height of fill ( 路基 ) 最小填土高度minimum longit inal gradient 最小纵坡minimum radius of horizontal curve 最小平曲线半径minimum turning radius 汽车最小转弯半径mixed traffic 混合交通mixing method 拌和法mixture 混合料model split 交通方式划分modulus of elasticity 弹性模量modulus of resilience 回弹模量modulus ratio 模量比monthly average daily traffic 月平均日交通量motor way 高速公路mountainous terrain 山岭区movable bridge 开启桥m 淤泥multiple-leg intersection 多岔交叉mational trunk highway 国家干线公路 ( 国道 ) matural asphalt 天然沥青Nnatural scour 自然演变冲刷natural s soil 天然地基navigable water level 通航水位nearside lane 外侧车道net-shaped cracking 路面网裂New Austrian Tunnelling Method 新奥法Oobservation point 测点one-way ramp 单向匝道open cut method 明挖法open cut tunnel 明洞open spandrel arch bridge 空腹拱桥opencast mine road 露天矿山道路operating speed 运行速度optimum gradation 最佳级配optimum moisture content 最佳含水量optimum speed 临界速度organic binder 有机结合料origin-destination st y 起迄点调查outbound traffic 出境交通outlet s merged culvert 压力式涵洞outlet inlet main road 城市出入干道overall speed 区间速度overlay of pavement 罩面overpass grade separation 上跨铁路立体交叉overtaking lane 超车车道overtaking sight distance 超车视距Ppaper location 纸上定线paraffin content test 含蜡量试验parent soil 原状土parking lane 停车车道parking lot 停车场parking station 公交 ( 车辆 ) 停靠站part out-part fill s grade 半填半挖式路基pass 垭口passing bay 错车道patrol maintenance 巡回养护paved crossing 道口铺面pavement 路面pavement depression 路面沉陷pavement recapping 路面翻修pavement slab pumping 路面板唧泥pavement spalling 路面碎裂pavement strengthening 路面补强pavement str ture layer 路面结构层pavemill 路面铣削机 ( 刨路机 )peak hourly volume 高峰小时交通量pedestrian overcrossing 人行天桥pedestrian underpass 人行地道penetration macadam with coated chips 上拌下贯式 ( 沥青 ) chips 路面penetration method 贯入法penetration test apparatus 长杆贯入仪penetration (of bitumen) ( 沥青 ) 针入度penetrometer ( 沥青 ) 针入度仪periodical maintenance 定期养护permafrost 多年冻土permanent load 永久荷载perviousness test 透水度试验petroleum asphaltic bitumen 石油沥青photo index 像片索引图 ( 镶辑复照图 )photo mosaic 像片镶嵌图photogrammetry 摄影测量photographic map 影像地图pier 桥墩pile and plank retaining wall 柱板式挡土墙pile bent pier 排架桩墩pile driver 打桩机pipe culvert 管涵pipe drainage 管道排水pit test 坑探pitching method 铺砌法plain stage of slope 边坡平台plain terrain 平原区plan view ( 路线 ) 平面图plane design ( 城市道路 ) 平面设计plane sketch ( 道路 ) 平面示意图planimetric photo 综合法测图plant mixing method 厂拌法plasticity index 塑限plasticity index 塑性指数poisson's ratio 泊松比polished stone val石料磨光值pontoon bridge 浮桥porosity 空隙率portable pendulum tester 摆式仪possible traffic capacity 可能通行能力post-tensioning method 后张法pot holes 路面坑槽preliminary survey 初测preloading method 预压法prestressed concrete 预应力混凝土prestressed concrete bridge 预应力混凝土桥prestresed steel bar drawing jack 张拉预应力钢筋千斤顶pretensioning method 先张法prime coat 透层prod tive arterial road 生产干线prod tive branch road 生产支线profile design 纵断面设计profilometer 路面平整度测定仪proportioning of cement concrete 水泥混凝土配合比protection forest fire-proof road 护林防火道路provincial trunk highway 省干线公路 ( 省道 )Rrailroad grade crossing ( 铁路 ) 道口ramp 匝道rebound deflection 回弹弯沉reclaimed asphalt mixture 再生沥青混合料reclaimed bituminous pavement 再生沥青路面reconnaissance 踏勘red clay 红粘土reference stake 护桩reflection crack 反射裂缝refuge island 安全岛regulating str ture 调治构造物reinforced concrete 钢筋混凝土reinforced concrete bridge 钢筋混凝土桥reinforced concrete pavement 钢筋混凝土路面reinforced earth retaining wall 加筋土挡土墙relative moisture content (of soil) ( 土的 ) 相对含水量relief road 辅道residential street 居住区道路resultant gradient 合成坡度retaining wall 挡土墙revelling of pavement 路面松散reverse curve 反向曲线reverse loop 回头曲线ridge crossing line 越岭线ridge line 山脊线right bridge 正交桥right bridge 正桥rigid frame bridge 刚构桥rigid pavement 刚性路面rigid-type base 刚性基层ring and radial road system 环形辐射式道路系统ripper 松土机riprap 抛石road 道路road alignment 道路线形road appearance 路容road area per citizen ( 城市 ) 人均道路面积road area ratio ( 城市 ) 道路面积率road axis 道路轴线road bed 路床road bitumen 路用沥青road condition 路况road condition survey 路况调查road crossing ( 平面 ) 交叉口road crossing design 交叉口设计road engineering 道路工程road feasibility st y ( 道路工程 ) 可行性研究road improvement 改善工程road intersection 道路交叉 ( 路线交叉 )road mixing method 路拌法road network 道路网road network planning 道路网规划road planting 道路绿化road project ( 道路工程 ) 方案图road trough 路槽road way 路幅rock breaker 凿岩机rock filled gabion 石笼roller 压路机rolled cement concrete 碾压式水泥混凝土rolling terrain 微丘区rotary interchange 环形立体交叉rotary intersection 环形交叉roundabout 环形交叉route development 展线rout of road 道路路线route selection 选线routine maintenance 小修保养r ble 片石running speed 行驶速度rural road 郊区道路Ssaddle back 垭口safety belt 安全带safety fence 防护栅salty soil 盐渍土sand 砂sanddrain (sand pile) 砂井sand gravel 砂砾sand hazard 沙害sand mat of s grade 排水砂垫层sand patch test 铺砂试验sand pile 砂桩sand protection facilities 防沙设施sand ratio 砂率sand sweeping 回砂sand sweeping equipment 回砂机sandy soil 砂性土saturated soil 饱和土scraper 铲运机seal coat 封层secondary trunk road ( 厂内 ) 次干道， ( 城市 ) 次干路seepage well 渗水井segregation 离析semi-rigid type base 半刚性基层separate facilties 分隔设施separator 分隔带sheep-foot roll 羊足压路机 ( 羊足碾 )shelter belt 护路林shield 盾构 ( 盾构挖掘机 )shield tunnelling method 盾构法shoulder 路肩shrinkage limit 缩限side ditch 边沟side slope 边坡side walk 人行道sieve analysis 筛分sight distance 视距sight distance of intersection 路口视距sight line 视线sight triangle 视距三角形silty soil 粉性土simple supported beam bridge 简支梁桥singl direction thrusted pier 单向推力墩single-sizeaggregat 同粒径集料siphon culvert 倒虹涵skew bridge 斜交桥skew bridge 斜桥skid road 集材道路slab bridge 板桥slab culvert 盖板涵slab staggering 错位slide 滑坡slope protection 护坡slump 坍落度snow hazard 雪害snow plough 除雪机snow protection facilities 防雪设施soft ground 软弱地基soft soil 软土softening point tester (ring ball) ( 沥青 ) 软化点议仪method ( 环—球法 )softening point (of bitumen) 沥青）软化点sol ility (of bitumen) ( 沥青 ) 溶解度space headway 车头间距space mean speed 空间平均速度span 跨径span by span method 移动支架逐跨施工法spandrel arch 腹拱spandrel str ture 拱上结构special vehicle 特种车辆speed-change lane 变速车道splitting test 劈裂试验spot speed 点速度spreading in layers 层铺法springing 弹簧现象stabilizer 稳定土拌和机stabilized soil base course 稳定土基层stage for heating soil and broken rock 碎落台staggered junction 错位交叉stand axial loading 标准轴截steel bridge 钢筋冷墩机steel bridge 钢桥steel extension machine 钢筋拉伸机stiffness modulus 劲度stone coating test 石料裹覆试验stone crusher 碎石机stone spreader 碎石撒布机stopping sight distance 停车视距stopping tr k heap ( 厂矿道路 ) 阻车堤street 街道street drainage 街道排水street planting 街道绿化street trees 行道树strengthening layer 补强层strengthening of str ture 加固stringer 纵梁striping test for aggregate 集料剥落试验str tural approach limit of tunnel 隧道建筑限界s -high type pavement 次高级路面s grade 路基s grade drainage 路基排水s mersible bridge 漫水桥s sidence 沉陷s soil 地基s str ture 下部结构super elevation 超高super elevation runoff 超高缓和段superstr ture 上部结构supported type abutment 支撑式桥台surface course 面层surface evenness 路面平整度surface frostheave 路面冻胀surface permeameter 路面透水度测定仪surface roughness 路面粗糙度surface slipperinness 路面滑溜surface water 地表水surface-curvature apparatus 路面曲率半径测定仪surrounding rock 围岩suspension bridge 悬索桥swich-back curve 回头曲线TTintersection 丁字形交叉 (T 形交叉 )T-shaped rigid frame bridge 形刚构桥tack coat 粘层tangent length 切线长tar 焦油沥青technical standard of road 道路技术标准Telford 锥形块石Telford base ( 锥形 ) 块石基层terrace 台地thermal insulation berm 保温护道thermal insulation course 隔温层thirtieth highest ann l hourly 年第 30 位最大小时volume 交通量through bridge 下承式桥through traffic 过境交通tie bar 拉杆timber bridge 木桥time headway 车头时距time mean speed 时间平均速度toe of slope ( 边 ) 坡脚tongand groove joint 企口缝top of slope ( 边 ) 坡顶topographic feature地貌topographic map 地形图topographic survey 地形测量topography 地形township road 乡公路 ( 乡道 )traffic assignment 交通量分配traffic capacity 通行能力traffic composition 交通组成traffic density 交通密度traffic distribution 交通分布traffic flow 交通流traffic generation 交通发生traffic island 交通岛traffic mirror 道路反光镜traffic planning 道路交通规划traffic safety device 交通安全设施traffic sq re 交通广场traffic stream 车流traffic survey 交通调查traffic volume 交通量traffic volume observation station 交通量观测站traffic volume 交通量预测traffic volume survey 交通量调查transition curve 缓和曲线transition slab at bridge head 桥头搭板transition zone of cross section 断面渐变段transition zone of curve widening 加宽缓和段transitional gradient 缓和坡段transverse beam 横梁transverse joint 横缝traverse 导线traverse survey 导线测量trencher 挖沟机triaxial test 三轴试验trip 出行trjoint 真缝trumpet interchange 喇叭形立体交叉trunk highway 干线公路truss bridge 桁架桥tunnel ( 道路 ) 隧道tunnel boring machine 隧道掘进机tunnel ling 衬砌tunnel portal 洞门tunnel support 隧道支撑turnaround loop 回车道，回车场turning point 转点two-way curved arch bridge 双曲拱桥two-way ramp 双向匝道type of dry and damp soil base 土基干湿类型UU-shaped abutment U 形桥台under-ground pipes comprehensive design 管线综合设计\underground water 地下水underground water level 地下水位underpass grade separation 下穿铁路立体交叉universal photo 全能法测图urban road 城市道路Vvalley line 沿溪线variable load 可变荷载vehicle stream 车流vehicular gap 车 ( 辆 ) 间净距verge 路肩vertical alignment 纵面线形vertical curb 立缘石 ( 侧石 )vertical curve 竖曲线vertical profile map ( 路线 ) 纵断面图viameter 路面平整度测定仪vibratory roller 振动压路机viscosimeter ( 沥青 ) 粘度仪viscosity (of bitumen) ( 沥青 ) 粘 ( 滞 ) 度void ratio 孔隙比Wwashout 水毁waste 弃土waste bank 弃土堆water cement ratio 水灰比water content 含水量water level 水位water red ing agent 减水剂water stability 水稳性water-bound macadam 水结碎石路面wearing course 磨耗层weaving 交织weaving point 交织点weaving section 交织路段wheel tracking test 车辙试验width of s grade 路基宽度workability 和易性YY intersection 形交叉。

中英文对照外文翻译文献(文档含英文原文和中文翻译)英文：1.1Approach for analyzing the ultimate strength of concrete filled steel tubular arch bridges with stiffening girderAbstract:A convenient approach is proposed for analyzing the ultimate load carrying capacity of concrete filled steel tubular (CFST) arch bridge with stiffening girders. A fiber model beam element is specially used to simulate the stiffening girder and CFST arch rib. The geometric nonlinearity, material nonlinearity。

influenceoftheconstruction process and the contribution of prestressing reinforcement are all taken into consideration. The accuracy of this method is validated by comparing its results with experimental results. Finally, the ultimate strength of an abnormal CFST arch bridge withstiffening girders is investigated and the effect of construction method is discussed. It is concluded that the construction process has little effect on the ultimate strength of the bridge.Key words: Ultimate strength, Concrete filled steel tubular (CFST) arch bridge, Stiffening girder, Fiber model beam element, Construction processdoi:10.1631/jzus.2007.A0682NTRODUCTIONWith the increasing applications of concrete filled steel tubular (CFST) structures in civil engi-neering in China, arch bridges have become one of the competitive styles in moderate span or long span bridges. Taking the Fuxing Bridge in Hangzhou (Zhao et al., 2004), and Wushan Bridge in Chongqing (Zhang et al., 2003), China, as representatives, the structural configuration, the span and construction scale of such bridges have surpassed those of existing CFST arch bridges in the world. Therefore, it is of great importance to enhance the theoretical level in the design of CFST arch bridges for safety and economy.he calculation of ultimate bearing capacity is a significant issue in design of CFST arch bridges. As an arch structure is primarily subjected to compres-sive forces, the ultimate strength of CFST arch bridge is determined by the stability requirement. A numberof theoretical studies were conducted in the past to investigate the stability and load-carrying capacity of CFST arch bridges. Zeng et al.(2003) studied the load capacity of CFST arch bridge using a composite beam element, involving geometric and material nonlin-earity. Zhang et al.(2006) derived a tangent stiffness matrix for spatial CFSTpole element to consider the geometric and material nonlinearities under largedisplacement by co-rotational coordinate method. Xie et al.(2005) proposed a numerical method to determine the ultimate strength of CFST arch bridges and revealed that the effect of the constitutive relation of confined concrete is not significant. Hu et al.(2006) investigated the effect of Poisson’s ratio of core concrete on the ultimate bearing capacity of a long span CFST arch bridge and found that the bearing capacity is enhanced by 10% if the Poisson’s ratio is variable. On the other hand, many experimental studies on the ultimate strength of naked CFST arch rib or CFST arch bridge model hadbeenconducted. Experimental studies on CFST arch rib under in-plane andout-of-plane loads were carried out by Chen and Chen 2000) and Chen et almetrical nonlinearity was significant for the out-of-plane strength and less significant for the in-plane strength. Cui et al.(2004) introduced a global model test of a CFST arch bridge with span of 308 m, and suggested that the influence of initial stress should be considered.The above papers mainly focused on the ultimate strength of CFST naked arch ribs or CFST arch bridges with floating deck. No attempt was made to study the ultimate strength of CFST arch bridges with stiffening girders whose nonlinear behavior and CFST arch should be simulated due to the redistribution of inner forces between arch ribs and stiffening girders. In general, stiffening girders can be classified into steel girder, PC (prestressing concrete) girder and teel-concrete combination girder. It is most difficult to simulate the nonlinear behavior of PC girder, due to the influence of prestressing reinforcement. In contrast to steel or steel-concrete combination beam, the prestressing reinforcements in PC girders not only offer strength and stiffnessdirectly, but their tension greatly affects the stiffness and distribution of the initial forces in the structure. The aims of this paper are (1) to present an elas-tic-plastic analysis of the ultimate strength of CFST arch bridge with arbitrary stiffening girders;(2) to study the ultimate load-carrying capacity of a complicated CFST arch bridge with abnormal arch ribs and PC stiffening girders; and (3) to investigate the effect of construction methods on the ultimate strength of the structure. ANALYTICAL THEORYElasto-plastic large deformation of PC girder element The elasto-plasic large deformation analysis of PC beam elements is based on the following fundamental assumptions:(1) A plane section originally normal to the neutral axis always remains a plane and normal to the neutral axis during deformation;(2) The shear deformation due to shear stress isneglected;(3)The Saint-Venant torsional principle holds in(4) The effect of shear stress on the stress-strain relationship is ignored. The cross-section of a PC box girder with onesymmetric axis is depicted in Fig.1, where, G and s denote the geometry center and the shear center re-spectively. According to the first and the third as-sumptions listed above, the displacement increments of point A(x,y) in the section can be expressed in terms of the displacement increments at the geometry center and the shear center aswhere Ktoris the coefficient factor which is related to the geometry shape of the girder cross-section.Similar to 3D elastic beam theory, the displacement increment of the girder can be expressed in terms of the nodal displacement increments asin which L denotes the element length, and z is the axial coordinate of the local coordinate system of an element. Then, the displacement vector of any section of the element can be written aswhere ∆u is the displacement vector of any section of the beam element, N is the shape function matrix and ∆ue is the displacement vector of the element node. They are respectively expressed asAccording to Eq.(2), the linear strain can be ex-pressed asin which BL is the linear strain matrix of the element Correspondingly, the nonlinear strain may be expressed aswhere BNL is the nonlinear strain matrix of the ele-mentThe stress increment ∆σ can be approximatedusing the linear strain increment aswhere D is the material property matrix. Neglecting the influence of the shear strain, D can be expressedwhere E(ε) is the tangent modulus of the material which is dependent on the strain state, and G is the elastic shearing modulus regarded as a constant. According to the principle of virtual work, we have in which σ and ∆σ are the stress vector and stress increment of the current state, q and P are the dis-tributed load and concentrated load vector, ∆q and ∆P are the increments of distributed load and concen-trated load, δ∆u and δ∆ε are the virtual displacement and virtual strain, and V isthe volume of the element. Substitute Eqs.(9), (11) and (14) into Eq.(16) and ignore the infinitesimal variable ∆σ∆εN, we have where ∆Fe is the increment of element load vectorcorresponding to ∆ue, the element displacement vec-tor. Kepand Kσare the elasto-plastic and geometric stiffness matrixes of the beam element respectively as followsThe distribution of elastic and plastic zones is non-uniform in the element, and varies during de-formation. It is very difficult to present an explicit expression of the property matrix D for the whole section. Hence, the section is divided into many subareas, as shown in Fig.2, and the fiber model is adopted to calculate the element’s stiffness matrix, i.e.Obviously, if the number of subareas is suffi-ciently large, the result of Eq.(19) will approach the exact solution. The value of Kep is calculated using numerical integration, with Di being regarded as i. To compute the geometric stiffness matrix Kσ, the normal stress should be expressed in terms of axial force and bending moment, which actually has very little contribution to the geometric stiffness, so where N is the axial force, and A is the sectional area. Prestressing reinforcement element The reinforced bars parallel to the beam axis may be regarded as fibers, whose contributions to the stiffness could be readily accounted for in Eq.(19). The contributions to the stiffness from those not par-allel to the beam and the prestressing reinforcement (PR), will however be calculated in the following section. The displacement increment of two ends of the prestressing reinforcement in Fig.3 can be expressed by Eq.(21):n which kep and kσare respectively the elasto-plastic and the geometric stiffness matrixes, ∆δis the nodal displacement vector, and ∆f is the nodal force vector of the prestressingreinforcementelement in the local coordinate system. According to Fig.4, ∆δand ∆f can be written in the form Then the stiffness matrix ep( k + k)σof the rein-accordingly. CFST arch rib, steel girder or steel-concrete girder element The fiber model mentioned above can also be used to simulate the CFST arch rib, steel stiffening girder or steel-concrete composite stiffening girder, with similar elasto-plastic stiffness matrix and stiff-ness equation. The detailed description of the deduction can be found in (Xie et al., 2005). However, for the CFST arch rib, the stress-strain relation of structure is very complex due to the com-bined influence of the confined concrete and outer steel tube. In this paper, the following stress-strain relation considering the confinement effect of the steel tube ring (Han, 2000) is adopted: where σytand σycare the yield strengths of the tension and compression sides of the steel tube respectively, βt and βc are the corresponding coefficients. Fig.5b depicted the bilinear stress-strain relationship con-The secondary modulus of the steel tube tendency of local buckling of the steel tube, is assumed to be 1% of the initial elastic modulus. Hanger element The mechanical behavior of cables such as that of hangers and tie bars, is similar to that of truss ele-ments, except that cables cannot bear compressive elasto-plastic computation theory of flexible cable considering the effect of sag was presented by (Xie eal., 1998). In most bridges, however, sag has little fect on the mechanical behavior of hangers. Hence, hangers of arch bridges are treated as elasto-plastic trusses with no compression strength, and the stiff-ness equation is expressed by Eq.(22). PROGRAM SCHEME FOR ULTIMATE BEARING CAPACITY CALCULATIOerection without brackets, and consists of many construction stages. Thus, the func-tion of simulating the construction process mustbe taken into account in the developed program for cal-culating ultimate bearing capacity, including the gradual action of load, the step-by-step formation of the structure, the influence of initial displacement and initial stress. The scheme for the program is indicated in Fig.6. The modified arc-length increment tecnique is adopted to solve the resulting nonlinear equation (Crisfield, 1981). VALIDATION OF THE METHOD FOR A PC GIRDER The accuracy of computation of the ultimate strength for CFST element has been confirmed in (Xie et al., 2005). In this paper, the precision of the present theory is checked for a PC girder by comparison with the experimental result. Fig.7 shows the cross-section and reinforcements of the girder, which spans 13 m, with 9 bundles of prestressing reinforcements and 11 branches of nonprestressing reinforced bars. The design strength of the concrete is 22.4 MPa, and those of nonprestressing reinforced bars A and B depicted in Fig.7a are 195 MPa and 280 MPa respectively of which the diameters are 12 mm and 8 mm. The prestressing reinforcement is high-strength low-rela- xation steel strand with design strength of 1860 MPa and the control force of each bundle is Nk=195 kN. More detailed information about the experiment on this PC girder is available in (Chen, 2005). Comparison of the deflection at the midspan is depicted in Fig.8, showing good consistency between he numerical simulation and experimental result. Fig.5 Stress-strain curves of steel tube (a) Yield condition; (b) Stress-strain relationship APPLICATION IN BRIDGE DESIGNThe ultimate strength of Fenghuajiang Bridge in Ningbo, Zhejiang, China is studied involving the effect of construction process to demonstrate the applicability of the present approach in bridge design. Fig.9 shows the design scheme of Fenghuajiang Bridgewhich is a girder and arch combination bridgewith central span of 138 m. The central span of the stiffening girder is made up of steel and PC composite box. The side span of the stiffening girder is made up of PC box. The abnormal CFST arch in the central span is composed of three arches, with one main archrib in the center and two secondary arch ribs. The diameter of the main arch rib is 1.8 m, and those of the other two are 1.5 m. The design strength of the concrete used in the bridge is 22.4 MPa. The arch ribs are linked with steel pipes and I-steel bearing members, forming a truss arch bridge. The main arch and the deck are connected with vertical hangers. The secondary arches and the deck are connected with inclined hangers. To take into account the effect of the construction method on the ultimate bearing capacity, it is assumed that the bridge is constructed by two kinds of methods. In Case I, there is only a construction process, the supporting frames for construction falling once after the completion of the whole bridge. In Case II, there are two construction processes, as shown in Fig.10. The first process is construction ofthe PC girder on the supporting frames. The second process is to fix the steel girder, assemble the arch rib, and tension the tie-bar and hangers to separate the steel girder from the frame. Prestressing reinforcements in the girder are properly simulated in construction stages, but the reinforced bars are not modelled due to their large number. The elasto-plastic mechanical behaviors of CFST arch ribs, hanger, bearing member, steel pipe, tie-bar, etc. are analyzed.The ultimate strength analysis process is shown in Fig.11. First,the initial stress of the established bridge is calculated under dead load and prestressing force including initial tension of the hangers, the tie and prestressing reinforcements. Then the stress and isplacement under live load are computed. At last,The out-of-plane deformation curves at the quarter points of the main arch rib are shown in Fig.14. The vertical axis denotes the load coefficient µ which does not contain the original dead load and live load exerted in Figs.11a and 11b. When 3.1≤µ≤3.2, the nonlinear behavior of the arch rib becomes obvious in the lateral direction. As shown in the figure, the buckling modes in both cases are antisymmetric out-of-plane, and the buckling load factor of the arch rib is about 4.1 considering the initial dead and live load.A comparison of the lateral and vertical deforMations at the quarter point of the main arch between two cases is shown in Fig.15, showing that the deviation of the load-displacement curves of the two cases is very small, indicating that the influence of the construction method on the stability strength is very slight. Besides, when out-of-plane buckling occurs, the bridge still has certain vertical stiffness.CONCLUSIONIn analyzing the ultimate strength of the CFST arch bridges with stiffening girders, simulating the nonlinear behavior of stiffening girders is as impor-tant as that of the CFST arch rib due to the redistribution of inner force between arch ribs and stiffening girders. In this paper, an analytical approach for estimating the ultimate bearing capacity of CFST arch bridge with stiffening girder is proposed, which takes account of the effects of material and geometric nonlinearity and the contribution of prestressing reinforcement. Based on the fiber beam element theory,the degrees of freedom of the whole structure can be reduced, making it very feasible to predict the ultimate strength of the complex structure. The accuracy of the present method was examined by comparison with the experimental results for a PC girder.To demonstrate the applicability of the present approach in bridge design, the ultimate strength of an abnormal CFST arch bridge with stiffening girder is studied considering the effect of construction process. The result shows that the construction process influences the initial internal force of the bridge significantly. But it has little effect on the ultimate strength of the bridge. Therefore, the relatively accurate stability strength can be obtained by ignoring the influence of the construction process.ReferencesChen, H.Z., 2005. Research of Calculation and Analysis of PCBox Girder Structure with Long Span. Ph.D Thesis,Zhejiang University (in Chinese).Chen, B.C., Chen, Y.J., 2000. Experimental study on me-chanic behaviors of concrete-filled steel tubular rib archunder in-plane loads. Engineering Mechanics,17(2):44-50 (in Chinese).Chen, B.C., Wei, J.G., Lin, J.Y., 2006. Experimental study on concrete filled steel tubular (single tube) arch with onerib under spatial loads. Engineering Mechanics,23(5):99-106 (in Chinese).Crisfield, M.A., 1981. A fast incremental iterative solution procedure that handles “snap through”. Computer and Structures, 13(1-3):55-62. [doi:10.1016/0045-7949(81) 90108-5]Cui, J., Sun, B.N., Lou, W.J., Yang, L.X., 2004. Model test study on concrete-filled steel tube truss arch bridge.Engineering Mechanics, 21(5):83-86 (in Chinese).e, X., Chen, H.Z., Li, H., Song, S.R., 2005. Numerical analysis of ultimate strength of concrete filled steel tu- bular arch bridges. Journal of Zhejiang University SCI-ENCE, 6A(8):859-868. [doi:10.1631/jzus.2005.A0859]Zeng, G.F., Fan, L.C., Zhang, G.Y., 2003. Load capacity analysis of concrete filled steel tube arch bridge with the composite beam element. Journal of the China RailwaySociety, 25(5):97-102 (in Chinese).Zhang, Z.A., Sun, Y., Wang, M.Q., 2003. Key technique in theerection process of the rib steel pipe truss segments forWushan Yangze River bridge. Highway, 12:26-32 (in Chinese).Zhang, Y., Shao, X.D., Cai, S.B., Hu, J.H., 2006. Spatial nonlinear finite element analysis for long-span trussedCFST arch bridge. China Journal of Highway andTransport, 19(4):65-70 (in Chinese).Zhao, L.Q., Xu, R.H., Zheng, X.Z., 2004. Overall design of thefourth Qiantangjiang River Bridge in Hangzhou. BridgeConstruction, 1:27-30 (in Chinese).翻译：分析钢管混凝土拱桥与加劲梁的极限强度的方法摘要：提出的方法是分析和研究负载承载能力的终极钢管混凝土钢管混凝土（加劲梁与钢管混凝土拱桥）。

桥梁工程中英文对照外文翻译文献(文档含英文原文和中文翻译)BRIDGE ENGINEERING AND AESTHETICSEvolvement of bridge Engineering,brief reviewAmong the early documented reviews of construction materials and structu re types are the books of Marcus Vitruvios Pollio in the first century B.C.The basic principles of statics were developed by the Greeks , and were exemplifi ed in works and applications by Leonardo da Vinci,Cardeno,and Galileo.In the fifteenth and sixteenth century, engineers seemed to be unaware of this record , and relied solely on experience and tradition for building bridges and aqueduc ts .The state of the art changed rapidly toward the end of the seventeenth cent ury when Leibnitz, Newton, and Bernoulli introduced mathematical formulatio ns. Published works by Lahire (1695)and Belidor (1792) about the theoretical a nalysis of structures provided the basis in the field of mechanics of materials .Kuzmanovic(1977) focuses on stone and wood as the first bridge-building materials. Iron was introduced during the transitional period from wood to steel .According to recent records , concrete was used in France as early as 1840 for a bridge 39 feet (12 m) long to span the Garoyne Canal at Grisoles, but r einforced concrete was not introduced in bridge construction until the beginnin g of this century . Prestressed concrete was first used in 1927.Stone bridges of the arch type (integrated superstructure and substructure) were constructed in Rome and other European cities in the middle ages . Thes e arches were half-circular , with flat arches beginning to dominate bridge wor k during the Renaissance period. This concept was markedly improved at the e nd of the eighteenth century and found structurally adequate to accommodate f uture railroad loads . In terms of analysis and use of materials , stone bridges have not changed much ,but the theoretical treatment was improved by introd ucing the pressure-line concept in the early 1670s(Lahire, 1695) . The arch the ory was documented in model tests where typical failure modes were considered (Frezier,1739).Culmann(1851) introduced the elastic center method for fixed-e nd arches, and showed that three redundant parameters can be found by the us e of three equations of coMPatibility.Wooden trusses were used in bridges during the sixteenth century when P alladio built triangular frames for bridge spans 10 feet long . This effort also f ocused on the three basic principles og bridge design : convenience(serviceabili ty) ,appearance , and endurance(strength) . several timber truss bridges were co nstructed in western Europe beginning in the 1750s with spans up to 200 feet (61m) supported on stone substructures .Significant progress was possible in t he United States and Russia during the nineteenth century ,prompted by the ne ed to cross major rivers and by an abundance of suitable timber . Favorable e conomic considerations included initial low cost and fast construction .The transition from wooden bridges to steel types probably did not begin until about 1840 ,although the first documented use of iron in bridges was the chain bridge built in 1734 across the Oder River in Prussia . The first truss completely made of iron was in 1840 in the United States , followed by Eng land in 1845 , Germany in 1853 , and Russia in 1857 . In 1840 , the first ir on arch truss bridge was built across the Erie Canal at Utica .The Impetus of AnalysisThe theory of structures ,developed mainly in the ninetheenth century,foc used on truss analysis, with the first book on bridges written in 1811. The Wa rren triangular truss was introduced in 1846 , supplemented by a method for c alculating the correcet forces .I-beams fabricated from plates became popular in England and were used in short-span bridges.In 1866, Culmann explained the principles of cantilever truss bridges, an d one year later the first cantilever bridge was built across the Main River in Hassfurt, Germany, with a center span of 425 feet (130m) . The first cantileve r bridge in the United States was built in 1875 across the Kentucky River.A most impressive railway cantilever bridge in the nineteenth century was the Fir st of Forth bridge , built between 1883 and 1893 , with span magnitudes of 1711 feet (521.5m).At about the same time , structural steel was introduced as a prime mater ial in bridge work , although its quality was often poor . Several early exampl es are the Eads bridge in St.Louis ; the Brooklyn bridge in New York ; and t he Glasgow bridge in Missouri , all completed between 1874 and 1883.Among the analytical and design progress to be mentioned are the contrib utions of Maxwell , particularly for certain statically indeterminate trusses ; the books by Cremona (1872) on graphical statics; the force method redefined by Mohr; and the works by Clapeyron who introduced the three-moment equation s.The Impetus of New MaterialsSince the beginning of the twentieth century , concrete has taken its place as one of the most useful and important structural materials . Because of the coMParative ease with which it can be molded into any desired shape , its st ructural uses are almost unlimited . Wherever Portland cement and suitable agg regates are available , it can replace other materials for certain types of structu res, such as bridge substructure and foundation elements .In addition , the introduction of reinforced concrete in multispan frames at the beginning of this century imposed new analytical requirements . Structures of a high order of redundancy could not be analyzed with the classical metho ds of the nineteenth century .The importance of joint rotation was already dem onstrated by Manderla (1880) and Bendixen (1914) , who developed relationshi ps between joint moments and angular rotations from which the unknown mom ents can be obtained ,the so called slope-deflection method .More simplification s in frame analysis were made possible by the work of Calisev (1923) , who used successive approximations to reduce the system of equations to one simpl e expression for each iteration step . This approach was further refined and int egrated by Cross (1930) in what is known as the method of moment distributi on .One of the most import important recent developments in the area of analytical procedures is the extension of design to cover the elastic-plastic range , also known as load factor or ultimate design. Plastic analysis was introduced with some practical observations by Tresca (1846) ; and was formulated by Sa int-Venant (1870) , The concept of plasticity attracted researchers and engineers after World War Ⅰ, mainly in Germany , with the center of activity shifting to England and the United States after World War Ⅱ.The probabilistic approa ch is a new design concept that is expected to replace the classical determinist ic methodology.A main step forward was the 1969 addition of the Federal Highway Adim inistration (F HWA)”Criteria for Reinforced Concrete Bridge Members “ that co vers strength and serviceability at ultimate design . This was prepared for use in conjunction with the 1969 American Association of State Highway Offficials (AASHO) Standard Specification, and was presented in a format that is readil y adaptable to the development of ultimate design specifications .According to this document , the proportioning of reinforced concrete members ( including c olumns ) may be limited by various stages of behavior : elastic , cracked , an d ultimate . Design axial loads , or design shears . Structural capacity is the r eaction phase , and all calculated modified strength values derived from theoret ical strengths are the capacity values , such as moment capacity ,axial load ca pacity ,or shear capacity .At serviceability states , investigations may also be n ecessary for deflections , maximum crack width , and fatigue .Bridge TypesA notable bridge type is the suspension bridge , with the first example bu ilt in the United States in 1796. Problems of dynamic stability were investigate d after the Tacoma bridge collapse , and this work led to significant theoretica l contributions Steinman ( 1929 ) summarizes about 250 suspension bridges bu ilt throughout the world between 1741 and 1928 .With the introduction of the interstate system and the need to provide stru ctures at grade separations , certain bridge types have taken a strong place in bridge practice. These include concrete superstructures (slab ,T-beams,concrete box girders ), steel beam and plate girders , steel box girders , composite const ruction , orthotropic plates , segmental construction , curved girders ,and cable-stayed bridges . Prefabricated members are given serious consideration , while interest in box sections remains strong .Bridge Appearance and AestheticsGrimm ( 1975 ) documents the first recorded legislative effort to control t he appearance of the built environment . This occurred in 1647 when the Cou ncil of New Amsterdam appointed three officials . In 1954 , the Supreme Cou rt of the United States held that it is within the power of the legislature to de termine that communities should be attractive as well as healthy , spacious as well as clean , and balanced as well as patrolled . The Environmental Policy Act of 1969 directs all agencies of the federal government to identify and dev elop methods and procedures to ensure that presently unquantified environmenta l amentities and values are given appropriate consideration in decision making along with economic and technical aspects .Although in many civil engineering works aesthetics has been practiced al most intuitively , particularly in the past , bridge engineers have not ignored o r neglected the aesthetic disciplines .Recent research on the subject appears to lead to a rationalized aesthetic design methodology (Grimm and Preiser , 1976 ) .Work has been done on the aesthetics of color ,light ,texture , shape , and proportions , as well as other perceptual modalities , and this direction is bot h theoretically and empirically oriented .Aesthetic control mechanisms are commonly integrated into the land-use re gulations and design standards . In addition to concern for aesthetics at the sta te level , federal concern focuses also on the effects of man-constructed enviro nment on human life , with guidelines and criteria directed toward improving quality and appearance in the design process . Good potential for the upgradin g of aesthetic quality in bridge superstructures and substructures can be seen in the evaluation structure types aimed at improving overall appearance .Lords and lording groupsThe loads to be considered in the design of substructures and bridge foun dations include loads and forces transmitted from the superstructure, and those acting directly on the substructure and foundation .AASHTO loads . Section 3 of AASHTO specifications summarizes the loa ds and forces to be considered in the design of bridges (superstructure and sub structure ) . Briefly , these are dead load ,live load , iMPact or dynamic effec t of live load , wind load , and other forces such as longitudinal forces , cent rifugal force ,thermal forces , earth pressure , buoyancy , shrinkage and long t erm creep , rib shortening , erection stresses , ice and current pressure , collisi on force , and earthquake stresses .Besides these conventional loads that are ge nerally quantified , AASHTO also recognizes indirect load effects such as fricti on at expansion bearings and stresses associated with differential settlement of bridge components .The LRFD specifications divide loads into two distinct cate gories : permanent and transient .Permanent loadsDead Load : this includes the weight DC of all bridge components , appu rtenances and utilities, wearing surface DW nd future overlays , and earth fill EV. Both AASHTO and LRFD specifications give tables summarizing the unit weights of materials commonly used in bridge work .Transient LoadsVehicular Live Load (LL) Vehicle loading for short-span bridges :considera ble effort has been made in the United States and Canada to develop a live lo ad model that can represent the highway loading more realistically than the H or the HS AASHTO models . The current AASHTO model is still the applica ble loading.桥梁工程和桥梁美学桥梁工程的发展概况早在公元前1世纪，Marcus Vitrucios Pollio 的著作中就有关于建筑材料和结构类型的记载和评述。

道路桥梁英语词汇(打印)(总25页)--本页仅作为文档封面，使用时请直接删除即可----内页可以根据需求调整合适字体及大小--Aabsolute datum 绝对基面abutment 桥台abutment pier 制动墩acceleration lane 加速车道accidental load 偶然荷载accommodation lane 专用车道acoustic barrier 隔音墙acting circles of blasting 爆破作用圈additional stake 加桩adjacent curve in one direction 同向曲线admixture 外加剂admixture 反坡安全线aerial photogrammetry 航空摄影测量aerophoto base 航摄基线aerophoto interpretation 航摄像片判读ageing 老化aggregate 集料 ( 骨料 )air hardining 气硬性alignment design ( 城市道路 ) 平面设计，线形设计alignment element 线形要素alligator cracking 路面龟裂allowable rebound deflection 容许 ( 回弹 ) 弯沉alternative line 比较线anchored bulkhead abutment 锚锭板式桥台anchored bulkhead abutment 锚锭板式挡土墙anchored retaining wall 锚杆式挡土墙anionic emulsified bitumen 阴离子乳化沥青ann l average daily traffic 年平均日交通量anti-creep heap ( 厂矿道路 ) 挡车堆anti-dizzling screen 防炫屏 ( 遮光栅 )antiskid heap ( 厂矿道路 ) 防滑堆approach span 引桥aquitard 隔水层arch bridge 拱桥arch culvert 拱涵arch ring 拱圈arterial highway 干线公路arterial road ( 厂内 ) 主干道， ( 城市 ) 主干路asphalt distributor 沥青洒布车asphalt mixing plant 沥青混合料拌和设备asphalt remixer 沥青混合料摊铺机asphalt remixer 复拌沥青混合料摊铺机asphalt sand 沥青砂asphalt sprayer 沥青洒布机asphaltic bitumen 地沥青at-grade intersection 平面交叉auxiliary lane 附加车道average consistency (of soil) 土的 ) 平均稠度average gradient 平均纵坡aximuth angle 方位角Bbalance weight retaining wall 衡重式挡土墙base course 基层base line 基线basic traffic capacity 基本通行能力beam bridge 梁桥beam level deflectometer 杠杆弯沉仪bearing 支座bearing angle 象限角bearing pile 支承桩bearing platform 承台bed course 垫层bench mark 水准点benched s grade 台口式路基bending strength 抗弯强度Benkelman beam 杠杆弯沉仪 ( 贝克曼弯沉仪 ) bent cap 盖梁berm 护坡道binder 结合料binder course 联结层bitumen 沥青bitumen ( 沥青混合料 ) 抽提仪bitumen-aggregate ratio 油石比bituminous concrete pavement 沥青混凝土混合料bituminous concrete mixture 沥青混凝土路面bituminous concrete moxture 沥青碎石混合料bituminous macadam pavement 沥青碎石路面bituminous moxture 沥青混合料bituminous pavement 沥青路面bituminous penetration pavement 沥青贯入式路面biuminous surface treatment ( 沥青 ) 表面处治blasting crater 爆破漏斗blastion for loosening rock 松动爆破blasting for throwing rock 抛掷爆破blasting procedure 土石方爆破bleeding 泛油blind ditch 盲沟blind drain 盲沟block pavement 块料路面block stone 块石blow up 拱胀boring 钻探boring log ( 道路 ) 地质柱状图boring machine 钻孔机borrow earth 借土borrow pit 取土坑boundary frame on crossing 道口限界架boundary frame on road 道路限界架boundary line of road constr tion 道路建筑限界bowstring arch bridge 系杆拱桥box culvert 箱涵branch pipe of inlet 雨水口支管branch road ( 城市 ) 支路， ( 厂内 ) 支道bridge 桥梁bridge decking 桥面系bridge deck pavement 桥面铺装bridge floor expantion and contraction installation traction installation 桥面伸缩装置bridge gerder erection equpment 架桥机bridge on slope 坡桥bridge site 桥位bridle road 驮道broken chainage 断链broken stone 碎石broken back curve 断背曲线buried abutment 埋置式桥台bus bay 公交 ( 车辆 ) 停靠站bypass 绕行公路Ccable bent tower 索塔cable saddle 索鞍cable stayed bridge 斜拉桥 ( 斜张桥 )Cableway erecting equipment 缆索吊装设备California bearing ratio (CBR) 加州承载比 (CBR) California bearing ratio tester 加州承载比 (CBR) 测定仪camber cruve 路拱曲线cantilever beam bridge 悬臂梁桥cantilever beam bridge 悬臂式挡土墙capacity of intersection 交叉口通行能力capacity of network 路网通行能力capillary water 毛细水carriage way 车行道 ( 行车道 )cast-in-place cantilever method 悬臂浇筑法cationic emulsified bitumen 阳离子乳化沥青cattle-pass 畜力车道cement concrete 水泥混凝土cemint concrete pavement 水泥混凝土混合料cement concrete pavement 水泥混凝土路面center-island 中心岛center lane 中间车道center line of raod 道路中线center line survey 中线测量center stake 中桩central reserve 分隔带channelization 渠化交通channelization island 导流岛channelized intrersection 分道转弯式交叉口chip 石屑chute 急流槽circular curve 圆曲线circular curve 环路circular test 环道试验city road 城市道路civil engineering fabric 土工织物classified highway 等级公路classified highway 等级道路clay-bound macadam 泥结碎石路面clearance 净空clearance above bridge floor 桥面净空clearce of span 桥下净空climatic zoning for highway 公路自然区划climbing lane 爬坡车道cloverleaf interchange 苜蓿叶形立体交叉coal tar 煤沥青cobble stone 卵石coefficient of scouring 冲刷系数cohesive soil 粘性土cold laid method 冷铺法cold mixing method 冷拌法cold-stretched steel bar 冷拉钢筋column pier 柱式墩combination-type road system 混合式道路系统compaction 压实compaction test 击实试验compaction test apparatus 击实仪compactness test 压实度试验composite beam bridge 联合梁桥composite pipe line 综合管道 ( 综合管廊 ) compound curve 复曲线concave vertical curve 凹形竖曲线concrete joint cleaner ( 水泥混凝土 ) 路面清缝机concrete joint sealer ( 水泥混凝土 ) 路面填缝机concrete mixing plant 水泥混凝土 ( 混合料 ) 拌和设备concrete paver 水泥混凝土 ( 混合料 ) 摊铺机concrete pump 水泥混凝土 ( 混合料 ) 泵concrete saw ( 水泥混凝土 ) 路面锯缝机cone penetration test 触探试验conflict point 冲突点conical slope 锥坡consistency limit (of soil) ( 土的 ) 稠度界限consolidated s soil 加固地基consolidation 固结constr tion by swing 转体架桥法constr tion height of bridge 桥梁建筑高度constr tion joint 施工缝constr tion load 施工荷载constr tion survey 施工测量continuous beam bridge 连续梁桥contourline 等高线contraction joint 缩缝control point 路线控制点converging 合流convex vertining wall 凸形竖曲线corduroy road 木排道counterfout retaining wall 扶壁式挡土墙counterfort abutmen 扶壁式桥台country road 乡村道路county road 县公路 ( 县道 ) ，乡道creep 徐变critical speed 临界速度cross roads 十字形交叉cross slope 横坡cross walk 人行横道cross-sectional profile 横断面图cross-sectional survey 横断面测量crown 路拱crushed stone 碎石crushing strength 压碎值culture 地物culvert 涵洞curb 路缘石curb side strip 路侧带curve length 曲线长curve widening 平曲线加宽curved bridge 弯桥cut 挖方cut corner for sight line ( 路口 ) 截角cut-fill transition 土方调配cut-fill transition 土方调配图cutting 路堑cycle path 自行车道cycle track 自行车道Ddeceleration lane 减速车道deck bridge 上承式桥deflection angle 偏角deflection test 弯沉试验degree of compaction 压实度delay 延误density of road network 道路（网）密度depth of tunnel 隧道埋深design elevation of s grade 路基设计高程design freqncy ( 排水 ) 设计重现期design hourly volume 设计小时交通量design of evevation ( 城市道路 ) 竖向设计design of vertical alignment 纵断面设计design speed 计算行车速度 ( 设计车速 ) design traffic capacity 设计通行能力design vehicle 设计车辆design water level 设计水位desiged dldvation 设计高程designed flood freqncy 设计洪水频率deslicking treatment 防滑处理Deval abrasion testion machine 狄法尔磨耗试验机（双筒式磨耗试验机）diamond interchange 菱形立体交叉differential photo 微分法测图direction angle 方向角directional interchange 定向式立体交叉diverging 分流dowel bar 传力杆drain opening 泄水口drainage by pumping station ( 立体交叉 ) 泵站排水drainage ditch 排水沟dressed stone 料石drop water 跌水dry concrtet 干硬性混凝土d tility (of bitumen) ( 沥青 ) 延度d tilometer ( 沥青 ) 延度仪dummy joint 假缝dynamic consolidation 强夯法Eeconomic speed 经济车速econnomical hauling distance 土方调配经济运距element support 构件支撑elevation 高程 ( 标高 )embankment 路堤emergency parking strip 紧急停车带emulsified bitumen 乳化沥青erecting by floating 浮运架桥法erection by longit inal pulling method 纵向拖拉法erection by protrusion 悬臂拼装法erection with cableway 缆索吊装法evaporation pond 蒸发池expansion bearing 活动支座expansive soil 膨胀土expansion joint 胀缝expressway ( 城市 ) 快速路external distance 外 ( 矢 ) 距Ffabricated bridge 装配式桥fabricated steel bridge 装拆式钢桥factories and mines road 厂矿道路factory external transportation line 对外道路factory-in road 厂内道路factory-out road 厂外道路fast lane 内侧车道faulting of slab ends 错台feeder highway 支线公路ferry 渡口fibrous concrete 纤维混凝土field of vision 视野fill 填方filled spandrel arch bridge 实腹拱桥final survey 竣工测量fineness 细度fineness modulus 细度模数fixed bearing 固定支座flare wing wall abutment 八字形桥台flared intersection 拓宽路口式交叉口flash 闪点flash point tester (open cup method) 闪点仪 ( 开口杯式 ) flexible pavement 柔性路面flexible pier 柔性墩floor system 桥面系flush curb 平缘石foot way 人行道ford 过水路面forest highway 林区公路forest road 林区道路foundation 基础free style road system 自由式道路系统free way 高速公路free-flow speed 自由车速freeze road 冻板道路freezing and thawing test 冻融试验frost boiling 翻浆frozen soil 冻土full depth asphalt pavement 全厚式沥青 ( 混凝土 ) 路面function planting 功能栽植Ggeneral scour under bridge opening 桥下一般冲刷geological section ( 道路 ) 地质剖面图geotextile 土工织物gradation 级配gradation of stone ( 路用 ) 石料等级grade change point 变坡点grade compensation 纵坡折减grade crossing 平面交叉grade length limitation 坡长限制grade of side slope 边坡坡度grade separation 简单立体交叉grade-separated junction 立体交叉graded aggregate pavement 级配路面brader 平地机grain composition 颗粒组成granular material 粒料gravel 砾石gravity pier (abutment) 重力式墩、台gravity retaining wall 重力式挡土墙green belt 绿化带gridiron road system 棋盘式道路系统ground control-point survey 地面控制点测量ground elevation 地面高程ground stereophoto grammetry 地面立体摄影测量g rd post 标柱g rd rail 护栏g rd wall 护墙gully 雨水口gutter 街沟 ( 偏沟 )gutter apron 平石gutter drainage 渠道排水Hhalf-through bridge 中承式桥hard shoulder 硬路肩hardening 硬化hardness 硬度haul road 运材道路heavy maintenance 大修hectometer stake 百米桩hedge 绿篱height of cut and fill at ceneter stake 中桩填挖高度high strength bolt 高强螺栓high type pavement 高级路面highway 公路highway landscape design 公路景观设计hill-side line 山坡线 ( 山腰线 )hilly terrain 重丘区horizontal alignment 平面线形horizontal curve 平曲线hot laid method 热铺法hot mixing method 热拌法hot stability (of bitumen) ( 沥青 ) 热稳性hydraulic computation 水力计算hydraulic computation 水硬性Iimaginary intersection point 虚交点immersed tunnelling method 沉埋法inbound traffic 入境交通incremental launching method 顶推法industrial district road 工业区道路industrial solid waste ( 路用 ) 工业废渣industrial waste base course 工业废渣基层inlet 雨水口inlet s merged culvert 半压力式涵洞inlet uns merged culvert 无压力式涵洞inorganic binder 无机结合料instrument station 测站intensity of rainstorm 暴雨强度intercepting detch 截水沟interchange 互通式立体交叉interchange woth special bicycle track 分隔式立体交叉intermediate maintenance 中修intermediate type pavement 中级路面intersection ( 平面 ) 交叉口intersection angle 交叉角，转角intersection entrance 交叉口进口intersection exit 交叉口出口intersection plan 交叉口平面图intersection point 交点intersection with widened corners 加宽转角式交叉口Jjack-in method 顶入法Kkilometer stone 里程碑Lland slide 坍方lane 车道lane-width 车道宽度lateral clear distance of curve ( 平曲线 ) 横净距lay-by 紧急停车带level of service 道路服务水平leveling course 整平层leveling survey 水准测量light-weight concrete 轻质混凝土lighting facilities of road 道路照明设施lime pile 石灰桩line development 展线linking-up road 联络线，连接道路liquid asphaltic bitumen 液体沥青liquid limit 液限living fence 绿篱load 荷载loading berm 反压护道lading combinations 荷载组合loading plate 承载板loading plate test 承载板试验local scour near pier 桥墩局部冲刷local traffic 境内交通location of line 定线location survey 定测lock bolt support with shotcrete 喷锚支护loess 黄土longit inal beam 纵梁longit inal gradient 纵坡longit inal joint 纵缝loop ramp 环形匝道Los Angeles abrasion testing machine 洛杉矶磨耗试验机Mmachine ( 搁板式磨耗试验机 )low rype pavement 低级路面main beam 主梁main bridge 主桥maintenance 养护maintenance period 大中修周期manhole 检查井marginal strip 路缘带marshall stability apparatus 马歇尔稳定度仪Marshall stability test 马歇尔试验masonry bridge 圬工桥maximum ann l hourly volume 年最大小时交通量maximum dry unit weight ( 标准 ) 最大干密度maximum longit inal gradient 最大纵坡mine tunnelling method 矿山法mineral aggregate 矿料mineral powder 矿粉mini-roundabout 微形环交minimum height of fill ( 路基 ) 最小填土高度minimum longit inal gradient 最小纵坡minimum radius of horizontal curve 最小平曲线半径minimum turning radius 汽车最小转弯半径mixed traffic 混合交通mixing method 拌和法mixture 混合料model split 交通方式划分modulus of elasticity 弹性模量modulus of resilience 回弹模量modulus ratio 模量比monthly average daily traffic 月平均日交通量motor way 高速公路mountainous terrain 山岭区movable bridge 开启桥m 淤泥multiple-leg intersection 多岔交叉mational trunk highway 国家干线公路 ( 国道 ) matural asphalt 天然沥青Nnatural scour 自然演变冲刷natural s soil 天然地基navigable water level 通航水位nearside lane 外侧车道net-shaped cracking 路面网裂New Austrian Tunnelling Method 新奥法Oobservation point 测点one-way ramp 单向匝道open cut method 明挖法open cut tunnel 明洞open spandrel arch bridge 空腹拱桥opencast mine road 露天矿山道路operating speed 运行速度optimum gradation 最佳级配optimum moisture content 最佳含水量optimum speed 临界速度organic binder 有机结合料origin-destination st y 起迄点调查outbound traffic 出境交通outlet s merged culvert 压力式涵洞outlet inlet main road 城市出入干道overall speed 区间速度overlay of pavement 罩面overpass grade separation 上跨铁路立体交叉overtaking lane 超车车道overtaking sight distance 超车视距Ppaper location 纸上定线paraffin content test 含蜡量试验parent soil 原状土parking lane 停车车道parking lot 停车场parking station 公交 ( 车辆 ) 停靠站part out-part fill s grade 半填半挖式路基pass 垭口passing bay 错车道patrol maintenance 巡回养护paved crossing 道口铺面pavement 路面pavement depression 路面沉陷pavement recapping 路面翻修pavement slab pumping 路面板唧泥pavement spalling 路面碎裂pavement strengthening 路面补强pavement str ture layer 路面结构层pavemill 路面铣削机 ( 刨路机 )peak hourly volume 高峰小时交通量pedestrian overcrossing 人行天桥pedestrian underpass 人行地道penetration macadam with coated chips 上拌下贯式 ( 沥青 ) chips 路面penetration method 贯入法penetration test apparatus 长杆贯入仪penetration (of bitumen) ( 沥青 ) 针入度penetrometer ( 沥青 ) 针入度仪periodical maintenance 定期养护permafrost 多年冻土permanent load 永久荷载perviousness test 透水度试验petroleum asphaltic bitumen 石油沥青photo index 像片索引图 ( 镶辑复照图 )photo mosaic 像片镶嵌图photogrammetry 摄影测量photographic map 影像地图pier 桥墩pile and plank retaining wall 柱板式挡土墙pile bent pier 排架桩墩pile driver 打桩机pipe culvert 管涵pipe drainage 管道排水pit test 坑探pitching method 铺砌法plain stage of slope 边坡平台plain terrain 平原区plan view ( 路线 ) 平面图plane design ( 城市道路 ) 平面设计plane sketch ( 道路 ) 平面示意图planimetric photo 综合法测图plant mixing method 厂拌法plasticity index 塑限plasticity index 塑性指数poisson's ratio 泊松比polished stone val石料磨光值pontoon bridge 浮桥porosity 空隙率portable pendulum tester 摆式仪possible traffic capacity 可能通行能力post-tensioning method 后张法pot holes 路面坑槽preliminary survey 初测preloading method 预压法prestressed concrete 预应力混凝土prestressed concrete bridge 预应力混凝土桥prestresed steel bar drawing jack 张拉预应力钢筋千斤顶pretensioning method 先张法prime coat 透层prod tive arterial road 生产干线prod tive branch road 生产支线profile design 纵断面设计profilometer 路面平整度测定仪proportioning of cement concrete 水泥混凝土配合比protection forest fire-proof road 护林防火道路provincial trunk highway 省干线公路 ( 省道 )Rrailroad grade crossing ( 铁路 ) 道口ramp 匝道rebound deflection 回弹弯沉reclaimed asphalt mixture 再生沥青混合料reclaimed bituminous pavement 再生沥青路面reconnaissance 踏勘red clay 红粘土reference stake 护桩reflection crack 反射裂缝refuge island 安全岛regulating str ture 调治构造物reinforced concrete 钢筋混凝土reinforced concrete bridge 钢筋混凝土桥reinforced concrete pavement 钢筋混凝土路面reinforced earth retaining wall 加筋土挡土墙relative moisture content (of soil) ( 土的 ) 相对含水量relief road 辅道residential street 居住区道路resultant gradient 合成坡度retaining wall 挡土墙revelling of pavement 路面松散reverse curve 反向曲线reverse loop 回头曲线ridge crossing line 越岭线ridge line 山脊线right bridge 正交桥right bridge 正桥rigid frame bridge 刚构桥rigid pavement 刚性路面rigid-type base 刚性基层ring and radial road system 环形辐射式道路系统ripper 松土机riprap 抛石road 道路road alignment 道路线形road appearance 路容road area per citizen ( 城市 ) 人均道路面积road area ratio ( 城市 ) 道路面积率road axis 道路轴线road bed 路床road bitumen 路用沥青road condition 路况road condition survey 路况调查road crossing ( 平面 ) 交叉口road crossing design 交叉口设计road engineering 道路工程road feasibility st y ( 道路工程 ) 可行性研究road improvement 改善工程road intersection 道路交叉 ( 路线交叉 )road mixing method 路拌法road network 道路网road network planning 道路网规划road planting 道路绿化road project ( 道路工程 ) 方案图road trough 路槽road way 路幅rock breaker 凿岩机rock filled gabion 石笼roller 压路机rolled cement concrete 碾压式水泥混凝土rolling terrain 微丘区rotary interchange 环形立体交叉rotary intersection 环形交叉roundabout 环形交叉route development 展线rout of road 道路路线route selection 选线routine maintenance 小修保养r ble 片石running speed 行驶速度rural road 郊区道路Ssaddle back 垭口safety belt 安全带safety fence 防护栅salty soil 盐渍土sand 砂sanddrain (sand pile) 砂井sand gravel 砂砾sand hazard 沙害sand mat of s grade 排水砂垫层sand patch test 铺砂试验sand pile 砂桩sand protection facilities 防沙设施sand ratio 砂率sand sweeping 回砂sand sweeping equipment 回砂机sandy soil 砂性土saturated soil 饱和土scraper 铲运机seal coat 封层secondary trunk road ( 厂内 ) 次干道， ( 城市 ) 次干路seepage well 渗水井segregation 离析semi-rigid type base 半刚性基层separate facilties 分隔设施separator 分隔带sheep-foot roll 羊足压路机 ( 羊足碾 )shelter belt 护路林shield 盾构 ( 盾构挖掘机 )shield tunnelling method 盾构法shoulder 路肩shrinkage limit 缩限side ditch 边沟side slope 边坡side walk 人行道sieve analysis 筛分sight distance 视距sight distance of intersection 路口视距sight line 视线sight triangle 视距三角形silty soil 粉性土simple supported beam bridge 简支梁桥singl direction thrusted pier 单向推力墩single-sizeaggregat 同粒径集料siphon culvert 倒虹涵skew bridge 斜交桥skew bridge 斜桥skid road 集材道路slab bridge 板桥slab culvert 盖板涵slab staggering 错位slide 滑坡slope protection 护坡slump 坍落度snow hazard 雪害snow plough 除雪机snow protection facilities 防雪设施soft ground 软弱地基soft soil 软土softening point tester (ring ball) ( 沥青 ) 软化点议仪method ( 环—球法 )softening point (of bitumen) 沥青）软化点sol ility (of bitumen) ( 沥青 ) 溶解度space headway 车头间距space mean speed 空间平均速度span 跨径span by span method 移动支架逐跨施工法spandrel arch 腹拱spandrel str ture 拱上结构special vehicle 特种车辆speed-change lane 变速车道splitting test 劈裂试验spot speed 点速度spreading in layers 层铺法springing 弹簧现象stabilizer 稳定土拌和机stabilized soil base course 稳定土基层stage for heating soil and broken rock 碎落台staggered junction 错位交叉stand axial loading 标准轴截steel bridge 钢筋冷墩机steel bridge 钢桥steel extension machine 钢筋拉伸机stiffness modulus 劲度stone coating test 石料裹覆试验stone crusher 碎石机stone spreader 碎石撒布机stopping sight distance 停车视距stopping tr k heap ( 厂矿道路 ) 阻车堤street 街道street drainage 街道排水street planting 街道绿化street trees 行道树strengthening layer 补强层strengthening of str ture 加固stringer 纵梁striping test for aggregate 集料剥落试验str tural approach limit of tunnel 隧道建筑限界s -high type pavement 次高级路面s grade 路基s grade drainage 路基排水s mersible bridge 漫水桥s sidence 沉陷s soil 地基s str ture 下部结构super elevation 超高super elevation runoff 超高缓和段superstr ture 上部结构supported type abutment 支撑式桥台surface course 面层surface evenness 路面平整度surface frostheave 路面冻胀surface permeameter 路面透水度测定仪surface roughness 路面粗糙度surface slipperinness 路面滑溜surface water 地表水surface-curvature apparatus 路面曲率半径测定仪surrounding rock 围岩suspension bridge 悬索桥swich-back curve 回头曲线TTintersection 丁字形交叉 (T 形交叉 )T-shaped rigid frame bridge 形刚构桥tack coat 粘层tangent length 切线长tar 焦油沥青technical standard of road 道路技术标准Telford 锥形块石Telford base ( 锥形 ) 块石基层terrace 台地thermal insulation berm 保温护道thermal insulation course 隔温层thirtieth highest ann l hourly 年第 30 位最大小时volume 交通量through bridge 下承式桥through traffic 过境交通tie bar 拉杆timber bridge 木桥time headway 车头时距time mean speed 时间平均速度toe of slope ( 边 ) 坡脚tongand groove joint 企口缝top of slope ( 边 ) 坡顶topographic feature地貌topographic map 地形图topographic survey 地形测量topography 地形township road 乡公路 ( 乡道 )traffic assignment 交通量分配traffic capacity 通行能力traffic composition 交通组成traffic density 交通密度traffic distribution 交通分布traffic flow 交通流traffic generation 交通发生traffic island 交通岛traffic mirror 道路反光镜traffic planning 道路交通规划traffic safety device 交通安全设施traffic sq re 交通广场traffic stream 车流traffic survey 交通调查traffic volume 交通量traffic volume observation station 交通量观测站traffic volume 交通量预测traffic volume survey 交通量调查transition curve 缓和曲线transition slab at bridge head 桥头搭板transition zone of cross section 断面渐变段transition zone of curve widening 加宽缓和段transitional gradient 缓和坡段transverse beam 横梁transverse joint 横缝traverse 导线traverse survey 导线测量trencher 挖沟机triaxial test 三轴试验trip 出行trjoint 真缝trumpet interchange 喇叭形立体交叉trunk highway 干线公路truss bridge 桁架桥tunnel ( 道路 ) 隧道tunnel boring machine 隧道掘进机tunnel ling 衬砌tunnel portal 洞门tunnel support 隧道支撑turnaround loop 回车道，回车场turning point 转点two-way curved arch bridge 双曲拱桥two-way ramp 双向匝道type of dry and damp soil base 土基干湿类型UU-shaped abutment U 形桥台under-ground pipes comprehensive design 管线综合设计\underground water 地下水underground water level 地下水位underpass grade separation 下穿铁路立体交叉universal photo 全能法测图urban road 城市道路Vvalley line 沿溪线variable load 可变荷载vehicle stream 车流vehicular gap 车 ( 辆 ) 间净距verge 路肩vertical alignment 纵面线形vertical curb 立缘石 ( 侧石 )vertical curve 竖曲线vertical profile map ( 路线 ) 纵断面图viameter 路面平整度测定仪vibratory roller 振动压路机viscosimeter ( 沥青 ) 粘度仪viscosity (of bitumen) ( 沥青 ) 粘 ( 滞 ) 度void ratio 孔隙比Wwashout 水毁waste 弃土waste bank 弃土堆water cement ratio 水灰比water content 含水量water level 水位water red ing agent 减水剂water stability 水稳性water-bound macadam 水结碎石路面wearing course 磨耗层weaving 交织weaving point 交织点weaving section 交织路段wheel tracking test 车辙试验width of s grade 路基宽度workability 和易性YY intersection 形交叉。

道路路桥工程中英文对照外文翻译文献中英文资料中英文资料外文翻译(文档含英文原文和中文翻译)原文：Asphalt Mixtures-Applications。

Theory and Principles1.ApplicationsXXX is the most common of its applications。

however。

and the onethat will be XXX.XXX “flexible” is used to distinguish these pavements from those made with Portland cement,which are classified as rigid pavements。

that is。

XXX it provides they key to the design approach which must be used XXX.XXX XXX down into high and low types,the type usually XXX product is used。

The low typesof pavement are made with the cutback。

or emulsion。

XXX type may have several names。

However。

XXX is similar for most low-type pavements and XXX mix。

forming the pavement.The high type of asphalt XXX中英文资料XXX grade.中英文资料Fig.·1 A modern XXX.Fig.·2 Asphalt con crete at the San Francisco XXX.They are used when high wheel loads and high volumes of traffic occur and are。

Accident Analysis and PreventionThis paper describes a project undertaken to establish a self-explaining roads (SER) design programmeon existing streets in an urban area. The methodology focussed on developing a process to identifyfunctional road categories and designs based on endemic road characteristics taken from functionalexemplars in the study area. The study area was divided into two sections, one to receive SER treatments designed to maximise visual differences between road categories, and a matched control area to remainuntreated for purposes of comparison. The SER design for local roads included increased landscaping andcommunity islands to limit forward visibility, and removal of road markings to create a visually distinctroad environment. In comparison, roads categorised as collectors received increased delineation, additionof cycle lanes, and improved amenity for pedestrians. Speed data collected 3 months after implementationshowed a significant reduction in vehicle speeds on local roads and increased homogeneity of speeds onboth local and collector roads. The objective speed data, combined with r esidents’ speed choice ratings,indicated that the project was successful in creating two discriminably different road categories.2010 Elsevier Ltd. All rights reserved.1. Introduction1.1. BackgroundChanging the visual characteristics of roads to influencedriver behaviour has come to be called the self-explaining roads(SER) approach (Theeuwes, 1998; Theeuwes and Godthelp, 1995;Rothengatter, 1999). Sometimes referred to as sustainable safety,as applied in the Netherlands, the logic behind the approach isthe use of road designs that evoke correct expectations and drivingbehaviours from road users (Wegman et al., 2005; Weller etal., 2008). The SER approach focuses on the three key principlesof functionality, homogeneity, and predictability (van Vliet andSchermers, 2000). In practice, functionality requires the creation ofa few well-defined road categories (e.g., through roads, distributorroads, and access roads) and ensuring that the use of a particularroad matches its intended function. Multifunctional roadslead to contradictory design requirements, confusion in the mindsof drivers, and incorrect expectations and inappropriate drivingbehaviour. Clearly defined road categories promote homogeneity intheir use and prevent large differences in vehicle speed, direction,and mass. Finally, predictability, or recognisability, means keepingthe road design and layout within each category as uniform as possibleand clearly differentiated from other categories so that thefunction of a road is easily recognised and will elicit the correctbehaviour from road users. The SER approach has been pursued tothe largest extent in the Netherlands and the United Kingdom but ithas also been of some interest inNewZealand. In 2004, the NationalRoad Safety Committee and the Ministry of Transport articulateda new National Speed Management Initiative which stated “Theemphas is is not just on speed limit enforcement, it includes perceptualmeasures that influence the speed that a driver feels is appropriatefor the section of road upon which they are driving–in effect the ‘selfexplainingroad”’ (New Zealand Ministry of Transport, 2004).In cognitive psychological terms, the SER approach attempts toimprove road safety via two complementary avenues. The first is toidentify and use road designs that afford desirable driver behaviour.Perceptual properties such as road markings, delineated lane width,and roadside objects can function as affordances that serve as builtininstructions and guide driver behaviour, either implicitly orexplicitly (Charlton, 2007a; Elliott et al., 2003; Weller et al., 2008).This work is more or less a direct development of work on perceptualcountermeasures, perceptual cues in the roading environmentthat imply or suggest a particular speed or lane position, eitherattentionally or perceptually (Charlton, 2004, 2007b; Godley et al.,1999).A second aspect of the SER approach is to establish mentalschemata and scripts, memory representations that will allowroad users to easily categorise the type of road on which they are.1.2. Localised speed managementThe traditional approaches to improving speed management,traffic calming and local area traffic management (LATM) havefocussed on treating specific problem locations or “black spots”in response to crash occurrences or complaints from the public(Ewing, 1999). A potential disadvantage of these approaches is thataddressing the problem with localised treatments can lead to are-emergence of the problem at another location nearby. Further,when applied inappropriately, localised approaches may addressthe problem from only one perspective, without considering theimpact on other types of road users or residents. When traffic calmingtreatments rely on physical obstacles such as speed humpsthey can be very unpopular with bothresidents and road users andcan create new problems associated with noise, maintenance, andvandalism (Martens et al., 1997).From an SER perspective, treatments that are highly localizedor idiosyncratic may do more harm than good by adding to themultiplicity of road categories and driver uncertainty, rather thanbuilding driver expectations around a few uniform road types.Instead of considering a single location in isolation, SER roaddesigns are considered within a hierarchy of road functions; e.g.,access roads, collector roads, and arterial roads. Although SERschemes may employ physical design elements used in trafficcalming schemes (e.g., road narrowing with chicanes and accesscontrols) they also employ a range of more visually oriented featuressuch as median and edge line treatments, road markings,pavement surfaces, and roadside furniture. For an effective SERscheme it is important to select the combination of features that will afford the desired driver speeds and to ensure their consistentuse to form distinct categories of road types (van der Horst andKaptein, 1998; Wegman et al., 2005).road category that would meet the three SER principles of functional use, homogeneous use, and predictable use. Herrstedt (2006)reported on the use of a standardised catalogue of treatments compiledfrom researcher and practitioner advice. Goldenbeld and vanSchagen (2007) used a survey technique to determine road characteristicsthat minimise the difference between drivers’ ratingsof preferred speed and perceived safe speed and select road featuresthat make posted speeds “credible”. Aarts and Davidse (2007)used a driving simulator to verify whether the “essential recognisabilitycharacteristics” of different road classes conformed to theexpectations of road users. Weller et al. (2008) employed a range of statistical techniques, including factor analysis and categoricalclustering to establish the road characteristics that drivers use tocategorise different road types.The practical difficulties of implementing an SER system thusbecome a matter of finding answers to a series of questions. Howdoes one create a discriminable road hierarchy for an existingroad network? What road characteristics should be manipulatedto establish category-defining road features? How can SER roadfeatures and selection methods be made relevant and appropriatefor a local context? (Roaddesigns appropriate for The Netherlandswould not be suitable in New Zealand, in spite of its name.) A surveyof national and international expert opinion in order establishcategory-defining road features for New Zealand roads revealedthat the regional character and local topography of roads oftenundercut the usefulness of any standardised catalogue of designcharacteristics (Charlton and Baas, 2006).1.4. Goals of the present projectThe project described in this paper sought to develop anddemonstrate an SER process based on retrofitting existing roadsto establish a clear multi-level road hierarchy with appropriatedesign speeds, ensuring that each level in the hierarchy possesseda different “look and feel”. Rather than transferring SER designs already in use internationally, the project attempted to develop amethod that would build on the features of roads in the local area;extending road characteristics with desirable affordances to otherroads lacking them and creating discriminable road categories inthe process. Of interest was whether such a process could producecost-effective designs and whether those designs would be effectivein creating different road user expectations and distinct speedprofiles for roads of different categories.2. MethodsThe research methodology/SER design process developed forthis project progressed through a series of five stages: (1) selectionof study area; (2) identification of the road hierarchy; (3) analysisof the road features; (4) development of a design template; and (5)implementation and evaluation of the SER treatments. Each of thestages is described in the sections that follow.2.1. Selection of study areaThe study area for this project (Pt England/Glen Innes in Auckland)was selected in consultation with a project steering groupcomprised of representatives from the Ministry of Transport, NewZealand Transport Agency, New Zealand Police, and other localtransport and urban agencies. The study area was an establishedneighbourhood contained amix of private residences, small shops,schools, and churches, and was selected, in part, because of its historyof cyclist, pedestrian and loss of controlcrashes, almost twicethe number。

中英术语对照公路highway 道路road 公路工程highway engineering 公路网highway network 公路网密度highway density 公路等级highway classification 公路自然区划climatic zoning for highway 公路用地highway right-of-way 高速公路freeway expressway 等级公路classified highway 辅道relief road 干线公路arterial highway 支线公路feeder highway 专用公路accommodation highway 国家干线公路国道national trunk highway 省级干线公路国道provincial trunk highway 县公路县道county road 乡公路乡道township road 辐射式公路radial highway 环形公路ring highway 绕行公路bypass 交通结构traffic structure 交通组成traffic composition 混合交通mixed traffic 交通流traffic flow 交通流理论traffic flow theory 车流vehicle stream 交通密度traffic density 车头间距space headway 车头时距time headway 车间净距vehicular gap 延误delay 地点速度spot speed 行驶速度running speed 运行速度operating speed 临界速度critical speed 平均速度average speed 计算行车速度设计车速design speed 交通量traffic volume 年平均日交通量annual average daily traffic 月平均日交通量monthly average daily traffic 年第30位最大小时交通量thirtieth highest annual hourly volume 年最大小时交通量maximum annual hourly 设计小时交通量design hourly volume 通行能力traffic capacity 基本通行能力basic traffic capacity 可能通行能力possible traffic capacity 设计通行能力design traffic capacity 道路服务水平level of service 公路交通规划traffic planning 交通调查traffic survey 交通量调查traffic volume survey 交通量观测站traffic volume observation station 起迄点调查OD 调查origin-destination study 出行trip 境内交通local traffic 过境交通through traffic 交通发生traffic generation 交通分布traffic distribution 交通分配traffic assignment 交通预测traffic prognosis 行车道carriageway 分离式行车道divided carriageway 车道lane 变速车道speed-change lane 加速车道acceleration lane 减速车道deceleration lane 爬坡车道climbing lane 停车道parking lane 错车道turn-out lane 自行车道cycle path 路侧人行道sidewalk 分隔带lane separator 中央分隔带median divider 中间带central strip 路肩shoulderverge 路缘带marginal strip 路缘石kerbcurb 侧向余宽lateral clearance 路拱cambercrown 路拱横坡crown slope 公路建筑限界clearance of highway 公路路线highway route 公路线形highway alignment 平面线形horizontal alignment 纵面线形vertical alignment 线形要素alignment elements 平曲线horizontal curve 极限最小平曲线半径limited minimum radius of horizontal curve 复曲线compound curve 反向曲线reverse curve 断背曲线broken-back curve 回头曲线switch-back curve 缓和曲线transition curve 竖曲线vertical curve 弯道加宽curve widening 加宽缓和段transition zone of curve 超高superelevation 超高缓和段superelevation runoff 纵坡longitudinal gradient 最大纵坡maximum longitudinal gradient 最小纵坡minimum longitudinal gradient 变坡点grade change point 平均纵坡average gradiant 坡长限制grade length limitation 高原纵坡拆减highland grade compensation 缓和坡段transition grading zone 合成坡度resultant gradient 视距sight distance 停车视距non-passing sight distance stopping sight distance 超车视距passing sight distance 道路交叉road intersection 道口railroad grade crossing 平面交叉at-grade intersectiongrade crossing 正交叉right-angle intersection 斜交叉skew intersection 环形交叉rotary intersection 十字形交叉quotquot T形交叉T intersection错位交叉offset intersection staggered junction Y形交叉Y intersection 立体交叉grade separation 分离式立体交叉simple grade separation separate grade crossing 互通式立体交叉interchange 苜蓿叶形立体交叉full cloverleaf interchange 部分苜蓿叶形立体交叉cloverleaf interchange 菱形立体交叉diamond interchange 定向式立体交叉directional interchange 喇叭形立体交叉three-Leg interchange 环形立体交叉rotary interchange 匝道ramp 交叉口road crossingintersection 交叉口进口intersection entrance 交叉口出口intersection exit 加铺转角式交叉口intersection with widened corners 拓宽路口式交叉口flared intersection 分道转弯式交叉口channelized intersection 渠化交通channelization 交织weaving 交织路段weaving section 合流converging 分流diverging 冲突点conflict point 交通岛traffic island 导流岛channelization island 中心岛central island 安全岛refuge island 沿线设施roadside facilities 交通安全设施traffic safety device 人行横道crosswalk 人行地道pedestrian underpass 人行天桥pedestrian overcrossing 护栏guard fence 防护栅guard fencesafety barrier 遮光栅anti-dizzling screen 应急电话emergency telephone 反光标志reflective sign 反光路钮reflective button 弯道反光镜traffic mirror 道路交通标志road traffic sign 警告标志warning sign 禁令标志regulatory sign 指示标志guide sign 指路标志information sign 辅助标志auxiliary sign 可变信息标志changeable message sign 路面标线pavement marking 防雪设施snow protection facilities 防沙设施sands protection facilities 隔音墙acoustic barrier 停车场parking area 踏勘reconnaissance 可行性研究feasibility study 线形设计highway alignment design 公路景观设计highway landscape design 选线route selection 路线控制点control point 定线location 比较线alternative line 展线line development 初测preliminary survey 定测location survey 地貌topographic feature 地物culture 地形topography 台地terrace 垭口passsaddle back 平原区plain terrain 微丘区rolling terrain 重丘区hilly terrain 山岭区mountainous terrain 沿溪线valley line 山脊线ridge line 山坡线hill-side line 越岭线ridge crossing line 土方调配cut-fill transition 土方调配图cut-fill transition program 土方调配经济运距economical hauling distance 导线traverse 导线测量traverse survey 中线center line 中线测量center line survey 施工测量construction survey 竣工测量final survey 路线平面图plan 交点intersection point 虚交点imaginary intersection point 转点turning point 转角intersection angle 方位角azimuth angle 象限角bearing 方向角direction angle 切线长tangent length 曲线长curve length 外矢距external secant 测站instrument station 测点observation point 中桩center stake 加桩additional stake 护桩reference stake 断链broken chainage 水准测量leveling survey 水准点bench mark 绝对基面absolute datum 高程elevation 地面高程ground elevation 设计高程designed elevation 路线纵断面图profile 中桩填挖高度cut and fill at center stake 地形测量topographic survey 基线base line 地形图topographic map 等高线contour line 横断面测量cross-sectional survey 横断面图cross-section 坑探pit test 钻探boring 摄影测量photogrammetry 航空摄影测量aerial photogrammetry 地面立体摄影测量ground stereophoto grammetry 地面控制点测量ground control-point survey 航摄基线aerophoto base 影像地图photographic map 像片索引图镶辑复照图photo index 航摄像片判读aerophoto interpretation 综合法测图planimatric photo 全能法测图universal photo 微分法测图differential photo 像片镶嵌图photo mosaic 路基subgrade 路堤embankment 路堑cutting 半填半挖式路基part cut-part fill subgrade 台口式路基benched subgrade 路基宽度width of subgrade 路基设计高程design elevation of subgrade 路基最小填土高度minimum height of fill 边坡side slope 边坡坡度grade of side slope 边坡顶top of slope 边坡脚toe of slope 护坡道berm 边坡平台plain stage of slope 碎落台berm at the foot of cutting slope 护坡slope protection 挡土墙retaining wall 重力式挡土墙gravity retaining wall 衡重式挡土墙balance weight retaining wall 悬臂式挡土墙cantilever retaining wall 扶壁式挡土墙counterfort retaining wall 柱板式挡土墙column-plate retaining wall 锚杆式挡土墙anchored retaining wall by tie rods 锚碇板式挡土墙anchored bulkhead retaining wall 石笼rock filled gabion 抛石riprap 路基排水subgrade drainage 边沟side ditch 截水沟intercepting ditch 排水沟drainage ditch 急流槽chute 跌水drop water 蒸发池evaporation pond 盲沟blind drain 渗水井seepage well 透水路堤permeable embankment 过水路面ford 填方fill 挖方cut 借土borrow earth 弃土waste 取土坑borrow pit 弃土堆waste bank 回填土back-filling 黄土loess 软土soft soil 淤泥mud 泥沼moor 泥炭peat 盐渍土salty soil 膨胀土expansive soil 冻土frozen soil 多年冻土permafrost 流砂quicksand 软弱地基soft ground 强夯法dynamic consolidation 预压法preloading method 反压护道loading berm 砂井sand drain 路基砂垫层sand mat of subgrade 压实compaction 压实度degree of compaction 标准最大干容重maximum dry unit weight 相对密实度relative density 毛细水capillary water土石方爆破blasting procedure 抛掷爆破blasting for throwing rock 爆破漏斗blasting crater 松动爆破blasting for loosening rock 爆破作用圈acting circles of blasting 路面pavement 弹性层状体系理论elastic multilayer theory 回弹弯沉deflection 加州承载比CBRCalifornia bearing ratioCBR 路面宽度width of pavement 路槽road trough 刚性路面rigid pavement 柔性路面flexible pavement 路面结构层pavement structure layer 面层surface course 磨耗层wearing course 联结层binder course 基层base course 垫层bed course 隔水层aquitard 隔温层thermal insulating course 封层seal coat 透层prime coat 保护层protection course 补强层strengthening layer 高级路面high type pavement 次高级路面sub-high type pavement 中级路面intermediate type pavement低级路面low type pavement 水泥混凝土路面cement concrete pavement 沥青路面bituminous pavement 沥青混凝土路面bituminous concrete pavement 沥青碎石路面bituminous macadam pavement 沥青贯入碎砾石路面bituminous penetration pavement 沥青表面处治bituminous surface treatment 块料路面block pavement 石块路面stone block pavement 泥结碎石路面clay-bound macadam pavement 水结碎石路面water-bound macadam pavement 级配路面graded aggregate pavement 稳定土基层stabilized soil base course 工业废渣基层industrial waste base course 块石基层Telford base 层铺法spreading in layers 拌和法mixing method 厂拌法plant mixing method 路拌法road mixing method 热拌法hot mixing method 冷拌法cold mixing method 热铺法hot laid method 冷铺法cold laid method 贯入法penetration method 铺砌法pitching method 缩缝contraction joint 胀缝expansion joint 真缝true joint 假缝dummy joint横缝transverse joint 纵缝longitudinal joint 施工缝construction joint 传力杆dowel bar 拉杆tie bar 路面平整度surface evenness 路面粗糙度surface roughness 路面摩擦系数friction coefficient of pavement 附着力adhesive force 水滑现象hydroplaning phenomenon 桥梁bridge 公路桥highway bridge 公铁两用桥highway and rail transit bridge 人行桥pedestrian bridge 跨线桥overpass bridge 高架桥viaduct 永久性桥permanent bridge 半永久性桥semi-permanent bridge 临时性桥temporary bridge 钢筋混凝土桥reinforced concrete bridge 预应力混凝土桥prestressed concrete bridge 钢桥steel bridge 圬工桥masonry bridge 木桥timber bridge 正交桥right bridge 斜交桥skew bridge 弯桥curved bridge 坡桥bridge on slope 斜桥skew bridge 正桥right bridge 上承式桥deck bridge 中承式桥half-through bridge 下承式桥through bridge 梁桥beam bridge 简支梁桥simple supported beam bridge 连续梁桥continuous beam bridge 悬臂梁桥cantilever beam bridge 联合梁桥composite beam bridge 板桥slab bridge 拱桥arch bridge 双曲拱桥two-way curved arch bridge 空腹拱桥open spandrel arch bridge 实腹拱桥filled spandrel arch bridge 系杆拱桥bowstring arch bridge 桁架桥truss bridge 刚构桥rigid frame bridge T形刚构桥T-shaped rigid frame bridge 连续刚构桥continuous rigid frame bridge 斜腿刚构桥rigid frame bridge with inclined legs 斜拉桥斜张桥cable stayed bridge 悬索桥suspension bridge 漫水桥submersible bridge 浮桥pontoon bridge 开启桥movable bridge 装配式桥fabricated bridge 装拆式钢桥fabricated steel bridge 涵洞culvert 管涵pipe culvert 拱涵arch culvert 箱涵box culvert 盖板涵slab culvert 无压力式涵洞non-pressure culvert 压力式涵洞pressure culvert 半压力式涵洞partial pressure culvert 倒虹吸涵siphon culvert 上部结构superstructure主梁main beam 横梁floor beam 纵梁longitudinal beam stringer 挂梁suspended beam 拱圈archring 拱上结构spandrel structure 腹拱spandrel arch 拱上侧墙spandrel wall 桥面系floor system bridge decking 桥面铺装bridge deck pavement 伸缩缝expansion and contraction joint 桥面伸缩装置bridge floor expansion and contraction installation 安全带safety belt 桥头搭板transition slab at bridge head 下部结构substructure 桥墩pier 墩身pier body 墩帽coping 盖梁bent cap 破冰体ice apron 重力式桥墩gravity pier 实体桥墩solid pier 空心桥墩hollow pier 柱式桥墩column pier 排架桩墩pile bent pier 柔性墩flexible pier 制动墩braking pier 单向推力墩single direction thrusted pier 桥台abutment 台身abutment body 前墙front wall 翼墙wing walls 台帽coping 锥坡conical slope 耳墙wing walls U形桥台U-shaped abutment 八字形桥台flare wing wall abutment 一字形桥台head wall abutment straight abutment 重力式桥台gravity abutment 埋置式桥台buried abutment 扶壁式桥台counterforted abutment 锚锭板式桥台anchored bulkhead abutment 支撑式桥台supported type abutment 地基subsoil 加固地基consolidated subsoil 天然地基natural subsoil 基础foundation 扩大基础spread foundation 沉井基础open caisson foundation 管柱基础cylindrical shaft foundation 桩基础pile foundation 桩pile 预制桩precast pile 就地灌注桩cast-in-place concrete pile 摩擦桩friction pile 支承桩bearing pile 承台bearing platform 支座bearing 固定支座fixed bearing 活动支座expansion bearing 索塔cable bent tower 索鞍cable saddle 调治构造物regulating structure 丁坝spur dike 顺坝longitudinal dam 桥位bridge site 桥梁全长total length of bridge 主桥main bridge 引桥approach span 跨径span 桥涵计算跨径computed span 桥涵净跨径clear span 矢跨比rise span ratio 计算矢高calculated rise of arch 桥下净空clearance of span 桥面净空clearance above bridge floor 桥梁建筑高度construction height of bridge 荷载load 永久荷载permanent load 可变荷载variable load 偶然荷载accidental load 荷载组合loading combinations 车辆荷载标准loading standard for design vehicle 设计荷载design load 施工荷载construction load梁beam 简支梁simple-supported beam 连续梁continuous beam 悬臂梁cantilever beam 板slab 拱arch 桁架truss 刚构rigid frame 柱column 强度strength 刚度stiffness rigidity 抗裂度crack resistance 稳定性stability 位移displacement 变形deformation挠度deflection 预拱度camber 流域catchment basin 集水面积runoff area 径流runoff 水文测验hydrological survey 河床river bed 河槽river channel 主槽main channel 边滩side shoal 河滩flood land 河床宽度bed width 河槽宽度channel width 过水断面discharge section 水位water level 最高或最低水位maximum minimumwater level 通航水位navigable water level 设计水位design water lever 水面比降water surface slope 河床比降gradient of river bed 湿周wetted perimeter 糙率coefficient of roughness 水力半径hydraulic radius 水文计算hydrological computation 设计流量designed discharge 设计流速designed flow velocity 行近流速approach velocity 洪水调查flood survey 洪水频率flood frequency 设计洪水频率designed flood frequency 潮汐河流tidal river 悬移质suspended load 推移质bed material load 水力计算hydraulic computation 水头water head 冲刷scour 桥下一般冲刷general scour under bridge 桥墩或台局部冲刷local scour near pier 自然演变冲刷natural scour 冲刷系数coefficient of scouring 淤积silting 壅水back water 流冰ice drift 先张法pretensioning method 后张法post-tensioning method 缆索吊装法erection with cableway 悬臂拼装法erection by protrusion 悬臂浇筑法cast-in-place cantilever method 移动支架逐跨施工法span by span method 纵向拖拉法erection by longitudinal pulling method 顶推法incremental launching method 转体架桥法construction by swing 浮运架桥法erecting by floating顶入法jack-in method 围堰cofferdam 护筒pile casing 隧道tunnel 洞门tunnel portal 衬砌tunnel lining 明洞open cut tunnel 围岩surrounding rock 隧道建筑限界structural approach limit of tunnels 明挖法open cut method 矿山法mine tunnelling method 盾构法shield tunnelling method 沉埋法沉管法immersed tunnel 导坑heading 隧道支撑tunnel support 构件支撑element support 喷锚支护lock bolt support with shotcrete 隧道通风tunnel ventilation 隧道照明tunnel lighting 养护maintenance 定期养护periodical maintenance 巡回养护patrol maintenance 大中修周期maintenance period小修保养routine maintenance 中修intermediate maintenance 大修heavy maintenance 改善工程road improvement 抢修emergency repair of road 加固strengthening of structure 回砂sand sweeping 罩面overlay of pavement 路面翻修pavement recapping 路面补强pavement strengthening 车辙rutting 路面搓板surface corrugation 路面网裂net-shaped cracking 路面龟裂alligator cracking 路面碎裂pavement spalling 反射裂缝reflection crack 路面坑槽pot holes 路面冻胀surface frost heave 路面沉陷pavement depression 路面滑溜surface slipperiness 露骨surface angularity 啃边edge failure 泛油bleeding 拥包upheaval 拱胀blow up 错台faulting of slab ends 错法slab staggering 滑坡slide 坍方land slide 崩塌collapse 碎落debris avalanche 沉降settlement 沉陷subsidence 泥石流mud avalanche 振动液化liquefaction 翻浆frost boiling 岩溶karst 沙害sand hazard 雪害snow hazard 水毁washout 好路率rate of good roads 养护质量综合值general rating of maintenance quality 路容road appearance 路况road condition 路况调查road condition survey 路政管理road ad.。

桥梁工程中英文对照外文翻译文献(文档含英文原文和中文翻译)BRIDGE ENGINEERING AND AESTHETICSEvolvement of bridge Engineering,brief reviewAmong the early documented reviews of construction materials and structu re types are the books of Marcus Vitruvios Pollio in the first century B.C.The basic principles of statics were developed by the Greeks , and were exemplifi ed in works and applications by Leonardo da Vinci,Cardeno,and Galileo.In the fifteenth and sixteenth century, engineers seemed to be unaware of this record , and relied solely on experience and tradition for building bridges and aqueduc ts .The state of the art changed rapidly toward the end of the seventeenth cent ury when Leibnitz, Newton, and Bernoulli introduced mathematical formulatio ns. Published works by Lahire (1695)and Belidor (1792) about the theoretical a nalysis of structures provided the basis in the field of mechanics of materials .Kuzmanovic(1977) focuses on stone and wood as the first bridge-building materials. Iron was introduced during the transitional period from wood to steel .According to recent records , concrete was used in France as early as 1840 for a bridge 39 feet (12 m) long to span the Garoyne Canal at Grisoles, but r einforced concrete was not introduced in bridge construction until the beginnin g of this century . Prestressed concrete was first used in 1927.Stone bridges of the arch type (integrated superstructure and substructure) were constructed in Rome and other European cities in the middle ages . Thes e arches were half-circular , with flat arches beginning to dominate bridge wor k during the Renaissance period. This concept was markedly improved at the e nd of the eighteenth century and found structurally adequate to accommodate f uture railroad loads . In terms of analysis and use of materials , stone bridges have not changed much ,but the theoretical treatment was improved by introd ucing the pressure-line concept in the early 1670s(Lahire, 1695) . The arch the ory was documented in model tests where typical failure modes were considered (Frezier,1739).Culmann(1851) introduced the elastic center method for fixed-e nd arches, and showed that three redundant parameters can be found by the us e of three equations of coMPatibility.Wooden trusses were used in bridges during the sixteenth century when P alladio built triangular frames for bridge spans 10 feet long . This effort also f ocused on the three basic principles og bridge design : convenience(serviceabili ty) ,appearance , and endurance(strength) . several timber truss bridges were co nstructed in western Europe beginning in the 1750s with spans up to 200 feet (61m) supported on stone substructures .Significant progress was possible in t he United States and Russia during the nineteenth century ,prompted by the ne ed to cross major rivers and by an abundance of suitable timber . Favorable e conomic considerations included initial low cost and fast construction .The transition from wooden bridges to steel types probably did not begin until about 1840 ,although the first documented use of iron in bridges was the chain bridge built in 1734 across the Oder River in Prussia . The first truss completely made of iron was in 1840 in the United States , followed by Eng land in 1845 , Germany in 1853 , and Russia in 1857 . In 1840 , the first ir on arch truss bridge was built across the Erie Canal at Utica .The Impetus of AnalysisThe theory of structures ,developed mainly in the ninetheenth century,foc used on truss analysis, with the first book on bridges written in 1811. The Wa rren triangular truss was introduced in 1846 , supplemented by a method for c alculating the correcet forces .I-beams fabricated from plates became popular in England and were used in short-span bridges.In 1866, Culmann explained the principles of cantilever truss bridges, an d one year later the first cantilever bridge was built across the Main River in Hassfurt, Germany, with a center span of 425 feet (130m) . The first cantileve r bridge in the United States was built in 1875 across the Kentucky River.A most impressive railway cantilever bridge in the nineteenth century was the Fir st of Forth bridge , built between 1883 and 1893 , with span magnitudes of 1711 feet (521.5m).At about the same time , structural steel was introduced as a prime mater ial in bridge work , although its quality was often poor . Several early exampl es are the Eads bridge in St.Louis ; the Brooklyn bridge in New York ; and t he Glasgow bridge in Missouri , all completed between 1874 and 1883.Among the analytical and design progress to be mentioned are the contrib utions of Maxwell , particularly for certain statically indeterminate trusses ; the books by Cremona (1872) on graphical statics; the force method redefined by Mohr; and the works by Clapeyron who introduced the three-moment equation s.The Impetus of New MaterialsSince the beginning of the twentieth century , concrete has taken its place as one of the most useful and important structural materials . Because of the coMParative ease with which it can be molded into any desired shape , its st ructural uses are almost unlimited . Wherever Portland cement and suitable agg regates are available , it can replace other materials for certain types of structu res, such as bridge substructure and foundation elements .In addition , the introduction of reinforced concrete in multispan frames at the beginning of this century imposed new analytical requirements . Structures of a high order of redundancy could not be analyzed with the classical metho ds of the nineteenth century .The importance of joint rotation was already dem onstrated by Manderla (1880) and Bendixen (1914) , who developed relationshi ps between joint moments and angular rotations from which the unknown mom ents can be obtained ,the so called slope-deflection method .More simplification s in frame analysis were made possible by the work of Calisev (1923) , who used successive approximations to reduce the system of equations to one simpl e expression for each iteration step . This approach was further refined and int egrated by Cross (1930) in what is known as the method of moment distributi on .One of the most import important recent developments in the area of analytical procedures is the extension of design to cover the elastic-plastic range , also known as load factor or ultimate design. Plastic analysis was introduced with some practical observations by Tresca (1846) ; and was formulated by Sa int-Venant (1870) , The concept of plasticity attracted researchers and engineers after World War Ⅰ, mainly in Germany , with the center of activity shifting to England and the United States after World War Ⅱ.The probabilistic approa ch is a new design concept that is expected to replace the classical determinist ic methodology.A main step forward was the 1969 addition of the Federal Highway Adim inistration (F HWA)”Criteria for Reinforced Concrete Bridge Members “ that co vers strength and serviceability at ultimate design . This was prepared for use in conjunction with the 1969 American Association of State Highway Offficials (AASHO) Standard Specification, and was presented in a format that is readil y adaptable to the development of ultimate design specifications .According to this document , the proportioning of reinforced concrete members ( including c olumns ) may be limited by various stages of behavior : elastic , cracked , an d ultimate . Design axial loads , or design shears . Structural capacity is the r eaction phase , and all calculated modified strength values derived from theoret ical strengths are the capacity values , such as moment capacity ,axial load ca pacity ,or shear capacity .At serviceability states , investigations may also be n ecessary for deflections , maximum crack width , and fatigue .Bridge TypesA notable bridge type is the suspension bridge , with the first example bu ilt in the United States in 1796. Problems of dynamic stability were investigate d after the Tacoma bridge collapse , and this work led to significant theoretica l contributions Steinman ( 1929 ) summarizes about 250 suspension bridges bu ilt throughout the world between 1741 and 1928 .With the introduction of the interstate system and the need to provide stru ctures at grade separations , certain bridge types have taken a strong place in bridge practice. These include concrete superstructures (slab ,T-beams,concrete box girders ), steel beam and plate girders , steel box girders , composite const ruction , orthotropic plates , segmental construction , curved girders ,and cable-stayed bridges . Prefabricated members are given serious consideration , while interest in box sections remains strong .Bridge Appearance and AestheticsGrimm ( 1975 ) documents the first recorded legislative effort to control t he appearance of the built environment . This occurred in 1647 when the Cou ncil of New Amsterdam appointed three officials . In 1954 , the Supreme Cou rt of the United States held that it is within the power of the legislature to de termine that communities should be attractive as well as healthy , spacious as well as clean , and balanced as well as patrolled . The Environmental Policy Act of 1969 directs all agencies of the federal government to identify and dev elop methods and procedures to ensure that presently unquantified environmenta l amentities and values are given appropriate consideration in decision making along with economic and technical aspects .Although in many civil engineering works aesthetics has been practiced al most intuitively , particularly in the past , bridge engineers have not ignored o r neglected the aesthetic disciplines .Recent research on the subject appears to lead to a rationalized aesthetic design methodology (Grimm and Preiser , 1976 ) .Work has been done on the aesthetics of color ,light ,texture , shape , and proportions , as well as other perceptual modalities , and this direction is bot h theoretically and empirically oriented .Aesthetic control mechanisms are commonly integrated into the land-use re gulations and design standards . In addition to concern for aesthetics at the sta te level , federal concern focuses also on the effects of man-constructed enviro nment on human life , with guidelines and criteria directed toward improving quality and appearance in the design process . Good potential for the upgradin g of aesthetic quality in bridge superstructures and substructures can be seen in the evaluation structure types aimed at improving overall appearance .Lords and lording groupsThe loads to be considered in the design of substructures and bridge foun dations include loads and forces transmitted from the superstructure, and those acting directly on the substructure and foundation .AASHTO loads . Section 3 of AASHTO specifications summarizes the loa ds and forces to be considered in the design of bridges (superstructure and sub structure ) . Briefly , these are dead load ,live load , iMPact or dynamic effec t of live load , wind load , and other forces such as longitudinal forces , cent rifugal force ,thermal forces , earth pressure , buoyancy , shrinkage and long t erm creep , rib shortening , erection stresses , ice and current pressure , collisi on force , and earthquake stresses .Besides these conventional loads that are ge nerally quantified , AASHTO also recognizes indirect load effects such as fricti on at expansion bearings and stresses associated with differential settlement of bridge components .The LRFD specifications divide loads into two distinct cate gories : permanent and transient .Permanent loadsDead Load : this includes the weight DC of all bridge components , appu rtenances and utilities, wearing surface DW nd future overlays , and earth fill EV. Both AASHTO and LRFD specifications give tables summarizing the unit weights of materials commonly used in bridge work .Transient LoadsVehicular Live Load (LL) Vehicle loading for short-span bridges :considera ble effort has been made in the United States and Canada to develop a live lo ad model that can represent the highway loading more realistically than the H or the HS AASHTO models . The current AASHTO model is still the applica ble loading.桥梁工程和桥梁美学桥梁工程的发展概况早在公元前1世纪，Marcus Vitrucios Pollio 的著作中就有关于建筑材料和结构类型的记载和评述。
