国产不锈钢焊带埋弧堆焊工艺性能研究发布时间：2022-11-01T01:56:39.820Z 来源：《科学与技术》2022年第13期作者：李潇[导读] 对SA-508 Gr.3 Cl.1 钢上进行的0.5mm×30mm 国产不锈钢带极埋弧堆焊工艺试验研究，分析影响堆焊层成型的因素，最终确定了最佳参数，实现了国产焊带EQ309L（首层）+EQ308L（两层）带极埋弧堆焊，堆焊层成型美观，表面光滑，堆焊层厚度约4mm。

李潇中国第一重型机械股份公司摘要：对SA-508 Gr.3 Cl.1 钢上进行的0.5mm×30mm 国产不锈钢带极埋弧堆焊工艺试验研究，分析影响堆焊层成型的因素，最终确定了最佳参数，实现了国产焊带EQ309L（首层）+EQ308L（两层）带极埋弧堆焊，堆焊层成型美观，表面光滑，堆焊层厚度约4mm。

同时，对堆焊层熔敷金属进行化学成分、力学性能和耐蚀性能等检测，验证了该焊带的使用能保证堆焊层力学性能和耐蚀性要求，可用于产品堆焊。

关键词：国产不锈钢焊带；埋弧堆焊；反应堆压力容器；前言核反应堆压力容器工作在高压、高温、含硼酸水介质和放射性辐照的环境下，为减少腐蚀产物放射源项，整个内表面需堆焊奥氏体不锈钢耐蚀层[1]。

带极埋弧堆焊具有热熔敷率高，焊道宽且成形美观等优点，在核反应堆压力容器内壁大面积堆焊中广泛应用。

目前，我国核反应堆压力容器内壁大面积带极堆焊用不锈钢焊带大多数靠从日本、原西德、瑞典、荷兰和美国等国进口[2]，因此加强对国产焊带的研究和应用势在必行。

本文选用某公司生产的0.5mm×30mm不锈钢焊带进行堆焊工艺试验，制定合理的堆焊工艺参数，验证该焊带的使用能否保证堆焊层力学性能和耐蚀性要求。

1 试验材料及方法1.1试验材料图1为不锈钢焊带埋弧堆焊工艺试验，堆焊母材采用SA-508 Gr.3 Cl.1钢锻件，尺寸为80mm×300mm×600mm，焊材采用规格0.5mm×30mm，EQ309L和EQ308L的焊带及与之相配的焊剂。

光伏焊带生产工艺流程
光伏焊带是太阳能光伏组件的关键连接材料之一，用于组件内部电池片的连接。

下面将介绍光伏焊带的生产工艺流程。

首先，原材料准备。

生产光伏焊带的主要原材料是纯铜和银。

工厂将铜和银材料按一定比例混合后，通过熔炼成型，制成合金带料。

第二步，带料加工。

合金带料进入带材加工车间，经过一系列的减薄、粗磨、精磨等工艺步骤，使合金带料变成一定尺寸和厚度的光伏焊带。

第三步，表面处理。

光伏焊带表面经过酸洗和抛光处理，去除杂质和氧化物，使其表面光滑。

第四步，切割。

将光伏焊带切割成标准尺寸的小片，便于后续的焊接和组装。

第五步，电镀处理。

将切割好的光伏焊带放入电镀槽中进行电镀处理，通过电解作用，使银镀层均匀附着在铜带表面上。

第六步，拉伸和回火。

经过电镀处理的光伏焊带经过拉伸和回火工艺，增加其强度和韧性，使其能够承受电池片的压力，并具有较好的导电性能。

第七步，卷绕和包装。

将处理好的光伏焊带卷绕成卷，经过包装后即可入库，等待后续的生产使用。

以上就是光伏焊带的生产工艺流程。

通过以上的加工和处理，光伏焊带具备了良好的导电性能和可靠的连接性，能够有效提高太阳能光伏组件的效率和性能。

光伏焊带的生产过程需要严格控制各个环节的质量和工艺参数，并进行严格的检验和测试，以确保产品的稳定性和可靠性。

随着太阳能光伏产业的发展，光伏焊带的生产工艺也在不断改进和优化，以满足市场的需求，并不断降低成本，提高产能。

光伏组件焊带的选择和使用1.焊带的种类和特点主要有银焊带和铜焊带两种。

银焊带：具有良好的导电性和导热性，用于高效率的太阳能电池组件。

其主要特点包括：-高导电性：银具有优异的电导率，能够更好地传导电流。

-高耐腐蚀性：银焊带能够在恶劣的外部环境下保持良好的性能。

-易于加工：银焊带可以通过热压焊或亮焊接等方式与电池片进行连接。

铜焊带：铜焊带主要用于传统的太阳能电池片组件。

其主要特点包括：-优良的导电性：铜焊带具有良好的导电性能，能够实现高效的电流传输。

-良好的可塑性：铜焊带易于弯曲和加工，适合于各种不同形状的电池片。

2.焊带的选择因素在选择光伏组件焊带时，需要考虑以下因素：-组件类型：不同类型的太阳能电池片可能需要不同种类的焊带，如单晶硅、多晶硅或薄膜太阳能电池片。

-电池片尺寸：不同尺寸的电池片需要不同宽度和厚度的焊带。

-热量传导性能：对于高功率的太阳能电池组件，需要选择导热性能较好的焊带，以确保组件正常工作并有效散热。

-组件温度：一些环境下，组件可能面临高温或低温条件，需要选择耐高温或低温的焊带。

-成本：不同种类的焊带价格差异较大，需要根据实际需求和预算进行选择。

3.焊带的使用注意事项正确使用和安装焊带对于光伏组件的性能和寿命至关重要。

以下是一些使用焊带的注意事项：-温度控制：焊带的加热温度应根据焊带的类型和具体组件要求加以控制，过高或过低的温度可能会损害焊带或组件。

-压力控制：在焊接过程中，需要控制加压的力度，以确保焊带与电池片之间的良好接触，以及避免过度压力导致电池片损坏。

-清洁和保养：焊带需要保持干净且没有任何污垢，以确保良好的接触和导电性能。

同时需要定期检查和保养焊接设备和工具，以确保其正常运行。

总结起来，光伏组件焊带的选择和使用对于太阳能光伏组件的性能和寿命具有重要影响。

在选择焊带时，需要考虑组件类型、尺寸、热量传导性能、温度和成本等因素。

在使用焊带时，需要控制温度和加压力度，并保持焊带的清洁和保养。

专利名称：压力钢管加劲环焊接施工方法
专利类型：发明专利
发明人：岳强,林宇,赵伟,李锰,韩伟杰,王兴族,李婉茹申请号：CN202111250331.7
申请日：20211026
公开号：CN114054901A
公开日：
20220218
专利内容由知识产权出版社提供
摘要：本发明公开了压力钢管加劲环焊接施工方法，包括如下步骤：1)将多个加劲环瓣通过点焊焊接到压力钢管外形成加劲环；2)将1)中的点焊有加劲环的压力钢管固定于滚轮架上，并通过气体保护焊接机对点焊形成的其中一道加劲环角焊缝进行气焊；3)使压力钢管在滚轮架上转动，对剩余的加劲环角焊缝依次进行气焊；气体保护焊接机上，设置有至少一组焊接枪头同时对一道加劲环角焊缝进行气焊，一组焊接枪头中至少设置有2个焊接枪头；气焊中，每个焊接枪头的焊接条件均为：二氧化碳的气体流量为15～20L/min，焊接电压为25～30V，焊接电流为280～350A。

本发明操作容易、极大提升了焊接质量，实现了焊接自动化，节约施工成本。

申请人：中国水利水电第六工程局有限公司
地址：110179 辽宁省沈阳市浑南新区新隆街2号
国籍：CN
代理机构：北京远大卓悦知识产权代理有限公司
代理人：俞牡丹
更多信息请下载全文后查看。
