©2000 Fairchild Semiconductor InternationalRev. A, February 2000BD136/138/140

PNP Epitaxial Silicon Transistor

Absolute Maximum Ratings TC=25°C unless otherwise noted

Electrical Characteristics TC=25°C unless otherwise noted

* Pulse Test: PW=350µs, duty Cycle=2% Pulsed

hFE ClassificntionSymbolParameterValueUnits VCBO Collector-Base Voltage : BD136 : BD138 : BD140 - 45 - 60 - 80VVV

VCEO Collector-Emitter Voltage : BD136 : BD138 : BD140 - 45 - 60 - 80VVV

VEBO Emitter-Base Voltage - 5V

IC Collector Current (DC)- 1.5A

ICP Collector Current (Pulse)- 3.0A

IB Base Current- 0.5A

PC Collector Dissipation (TC=25°C)12.5W

PC Collector Dissipation (Ta=25°C)1.25W

TJ Junction Temperature 150°C

TSTG Storage Temperature- 55 ~ 150°C

SymbolParameterTest ConditionMin.Typ.Max.UnitsVCEO(sus)* Collector-Emitter Sustaining Voltage: BD136: BD138: BD140 IC = - 30mA, IB = 0- 45- 60- 80VVV

ICBO Collector Cut-off Current VCB = - 30V, IE = 0- 0.1µA

IEBO Emitter Cut-off Current VEB = - 5V, IC = 0 - 10µA

hFE1 hFE2 hFE3* DC Current Gain VCE = - 2V, IC = - 5mA VCE = - 2V, IC = - 0.5A VCE = - 2V, IC = - 150mA 25 25 40 250

VCE(sat)* Collector-Emitter Saturation Voltage IC = - 500mA, IB = - 50mA- 0.5V

VBE(on)* Base-Emitter ON Voltage VCE = - 2V, IC = - 0.5A - 1V

Classification61016

hFE340 ~ 10063 ~ 160100 ~ 250BD136/138/140

Medium Power Linear and Switching

Applications

•Complement to BD135, BD137 and BD139 respectively

1TO-126

1. Emitter 2.Collector 3.Base元器件交易网www.cecb2b.com©2000 Fairchild Semiconductor InternationalBD136/138/140

Rev. A, February 2000Typical Characteristics

Figure 1. DC current GainFigure 2. Collector-Emitter Saturation Voltage

Figure 3. Base-Emitter VoltageFigure 4. Safe Operating Area

Figure 5. Power Derating-10-100-10000102030405060708090100VCE = -2V

hFE, DC CURRENT GAIN

IC[mA], COLLECTOR CURRENT-1E-3-0.01-0.1-1-10-0-50-100-150-200-250-300-350-400-450-500

IC = 10 IBIC = 20 IB

VCE(sat)[mV], SATURATION VOLTAGE

IC[A], COLLECTOR CURRENT

-1E-3-0.01-0.1-1-10-0.1-0.2-0.3-0.4-0.5-0.6-0.7-0.8-0.9-1.0-1.1

VBE(on)

VCE = -5VVBE(sat)

IC = 10 IB

VBE[V], BASE-EMITTER VOLTAGE

IC[A], COLLECTOR CURRENT-1-10-100-0.01-0.1-1-10

BD140BD138BD13610us

100us1msDCIC MAX. (Pulsed)IC MAX. (Continuous)

IC[A], COLLECTOR CURRENT

VCE[V], COLLECTOR-EMITTER VOLTAGE

02550751001251501750.02.55.07.510.012.515.017.520.0

PC[W], POWER DISSIPATION

TC[oC], CASE TEMPERATURE元器件交易网www.cecb2b.comPackage Demensions

©2000 Fairchild Semiconductor InternationalRev. A, February 2000BD136/138/140

Dimensions in Millimeters3.25 ±0.208.00 ±0.30

ø3.20 ±0.10

0.75 ±0.10

#10.75 ±0.10

2.28TYP[2.28±0.20]2.28TYP[2.28±0.20]1.60 ±0.1011.00 ±0.203.90 ±0.10

14.20MAX

16.10 ±0.20

13.06 ±0.301.75 ±0.20(0.50)(1.00)

0.50+0.10–0.05TO-126元器件交易网www.cecb2b.com©2000 Fairchild Semiconductor InternationalRev. E
