帕罗肯PA-13配电隔离器

隔离配电器的现场典型应用隔离配电器是一种与单元组合仪表及DCS，PLC等系统配套使用，为压力变送器等需要现场供电的一次仪表提供电源回路，同线测量该一次仪表输出的电源信号，经过运算、干扰抑制等处理后，变送输出隔离的单路或双路电流或电压信号。

隔离配电器提高输入、输出、电源之间的电气隔离性能。

常见的有一入一出、一入二出、一入三出、二入二出等类型，已经广泛应用于油田、石化、制造、电力、冶金等行业的自控工程之中。

隔离配电器的现场典型应用：1、解决共地、避免干扰在大型项目改造中，经常遇到不同设备之间的共地问题，这也是产生信号干扰设备之间无法正常采集和处理的原因。

此时用户需要采用一种高密度、DIN导轨安装的低成本，高性能的仪表解决这一问题行之有效的方法就是：安装一台无缘隔离器(帕罗肯科技P/PA系列-P-0133无源信号隔离器，PA-0133无源信号隔离器)，它具有无需供电，高隔离的输出通道，同时它具有价位低，高密度的安装方式，简单易行的接线方式等优势。

2、两地共享过程信号有时，用户需要在两个不同的地方同时监测一路现场信号，简单、经济的方法就是：安装一个一进两出的隔离分配器(帕罗肯PR/PG系列信号隔离分配器-PR-1127GG-D直流信号隔离分配器、PG-113/PG-114直流信号分配器《一分三、一分四》)，它不仅可以隔离地回路，电机噪音及一些电子产品所造成的干扰，而且将一路信号分配成两路至四路相同或者不同的信号，这两路信号可送到不同的两个接收设备，进行监测、记录或控制。

3、增强带负载能力有时，用户需要在回路中再加一个250欧姆的负载(PID控制器)，但是这样超过了回路负载600欧姆，现在简单经济的方法就是：安装一个地输入阻抗(100欧姆)高驱动负载能力(500欧姆)的2线制ECT，这样可以增强回路的负载能力，可以类似PID 控制器及其它扩展场合找到空间。

4、解决电源冲突问题有些回路中，用户需要将4线制变送器接到DCS上，但是DCS是给输入回路供电的，这样在变送器和DCS之间有个电源冲突的问题。
