安全继电器技术领域本实用新型涉及电气控制技术领域，主要是在电气安全控制系统中使用的一种安全继电器。
背景技术具有安全要求的机器中，普通的继电器或者PLC被广泛地作为控制模块，对安全功能进行监控。
从表面看来，这样的机器在一定条件下也能够保证安全性。
但是，当普通的继电器和PLC由于自身缺陷或外界原因导致功能失效时（如触点熔焊、电气短路、处理器紊乱等故障），就会丢失安全保护功能，如电气急停拍下后，由于触点熔焊在一起而不能断开，导致操作者出现人身安全事故。
对于安全继电器，由于其使用两个强制导向继电器并联及内部逻辑电路，以实现电路冗余、多样的结构；安全输出1组辅助触点，可实现自我检测和监控；安全输出3组触点可实现反馈回路；两个继电器均为强制导向继电器，其内部有导向杆，保证有一组触点熔焊时，其余触点保持0.5mm 间距，是可靠的电气元件；以上这些安全措施，保证安全继电器在本身缺陷或外部故障的情况下，依然能够保证安全功能，并且可以及时的将故障检测出来，从而在最大程度上保证了整个安全控制系统的正常运行，保护了人和机器的安全。
实用新型内容本实用新型的目的是提供一种安全继电器，用于电气安全控制系统中，并且具有以下特点：继电器触点输出3组常开触点，1组常闭辅助触点；设置连接急停按钮、安全门开关和复位按钮的接线端子；状态指示灯；为外部接触器或继电器提供反馈控制循环。
电路中带有自我监控的冗余电路；即使有一个强制导向继电器损坏，安全功能仍然有效；在每个开关周期中通过正确的断开和闭合可以自动检测继电器的安全功能。
为实现上述目的，本实用新型采用的技术方案是：（详见权利要求书）该实用新型外部需提供直流24V电源，可输出3组常开触点，为外部接触器或继电器提供反馈控制循环；1组常闭辅助触点，用以监控安全继电器安全功能是否正常。
在电气安全控制系统中使用安全继电器，连接相应接线端子后，即可实现安全回路的自我监控，且可以达到一定的电气安全等级要求。
