PG150 THRU PG1510
GLASS PASSIVATED JUNCTION PLASTIC RECTIFIER
VOLTAGE - 50 to 1000 Volts CURRENT - 1.5 AmperesFEATURESl Plastic package has Underwriters Laboratory
Flammability Classification 94V-O utilizing
Flame Retardant Epoxy Molding Compoundl 1.5 ampere operation at TA=55¢J with no thermal runaway
l Exceeds environmental standards of MIL-S-19500/228l Glass passivated junction
MECHANICAL DATA
Case: Molded plastic , DO-15Terminals: Axial leads, solderable per MIL-STD-202,
Method 208Polarity: Color band denotes cathode
Mounting Position: AnyWeight: 0.015 ounce, 0.4 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICSRatings at 25¢J ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.For capacitive load, derate current by 20%.PG150PG151PG152PG154PG156PG158PG1510
UNITSMaximum Recurrent Peak Reverse Voltage501002004006008001000VMaximum RMS Voltage3570140280420560700VMaximum DC Blocking Voltage501002004006008001000VMaximum Average Forward RectifiedCurrent .375"(9.5mm) Lead Length atTA=55¢J1.5A
Peak Forward Surge Current 8.3ms singlehalf sine-wave superimposed on rated load(JEDEC method)50A
Maximum Forward Voltage at 1.5A1.1VMaximum Reverse Current Ta=25¢Jat Rated DC Blocking Voltage Ta=100¢J5.050£gA£gATypical Junction capacitance (Note 1)25PFTypical Thermal Resistance (Note 2) R£KJA45.0¢J/WOperating and Storage Temperature RangeTA-55 TO +150¢J
NOTES:
1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC.2. Thermal Resistance from Junction to Ambient and from junction to lead at 0.375"(9.5mm) lead length P.C.B
mounted.DO-15元器件交易网www.cecb2b.comRATING AND CHARACTERISTIC CURVES
PG150 THRU PG1510
10
1.0
0.1
.010 .2 .4 .6 .8 1.0 1.2TJ = 25¢J
INSTANTANEOUS FORWARD VOLTAGE, VOLTS50
40
30
20
10
01 2 4 6 8 10 20 40 60 80 100
NUMBER OF CYCLES AT 60Hz
Fig. 1-TYPICAL FORWARD CHARACTERISTICSFig. 2-PEAK FORWARD SURGE CURRENT
1.50
1.25
1.00
.75
.50
.25
025 50
75 100 125 150 175SINGLE PHASEHALF WAVE 60HzRESISTIVE ORINDUCTIVELOAD .375" 9.5mmLEAD LENGTHS
AMBIENT TEMPERATURE, ¢J 100
10
11 4 10 100TJ = 25¢J
REVERSE VOLTAGE, VOLTS
Fig. 3-FORWARD CURRENT DERATING CURVEFig. 4-TYPICAL JUNCTION CAPACITANCEINSTANTANEOUS FORWARD CURRENT,
AMPERES
PEAK FORWARD SURGE CURRENT,
AMPERES
AVERAGE FORWARD RECTIFIED
CURRENT, AMPERES
CAPACITANCE - pF元器件交易网www.cecb2b.com
