SpecificationsController MCTRL660OverviewMCTRL660 is the latest independent master controller of NovaStar,Features1) It has adopted an innovative design to implement smartneeds of display rental service to the maximum extent. 8) HDMI/DVI Input.9) HDMI/DVI Output. 10) HDMI/external audio input.11) 12bit/10bit/8bit HD video source.12) Resolution supported: 2048×1152，1920×1200，2560×960. 13) R esolution supported: 1440 × 900 , (12 bit/10 bit). 14) C ascading supported. 15) V ideo format: RGB, YCrCb4:2:2, YCrCb4:4:4.configuration and the screen configuration can be completed within 30 seconds.2)It has adopted Nova G4 engine, which makes the screen stable and flicker free without scanning lines. The images become exquisite andbring a good sense of depth. 3) It supports Nova's new-generation pixel-by-pixel calibration technology which is fast and efficient. 4) It c an implement white balance calibration and color gamut mapping based on different features of LEDs used by displays to ensure restoration of true colors.5)It is the only control system supporting the input of 12-bit high-definition multimedia interface (HDMI) and high-bandwidth digital content protection (HDCP) in China.6)It supports screen configuration at any time without a computer. 7)It supports manual adjustment of screen brightness, which is convenient and efficient. These features have satisfied the specialwhich is mainly applied for display rental service. It supports screen configuration at any time without a computer.DimensionsUnit: mmAppearancea r rangement of interface can be slightly adjusted to enhanceuser’s experience. Please in kind prevail.XI'ANXI'ANNOVASTARTECHCO.,LTD.FCC CautionAny Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operatethe equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radiocommunications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.。
欢迎您选用西安诺瓦电子科技有限公司（以下简称诺瓦科技）的产品，如果本文档为您了解和使用产品带来帮助和便利，我们深感欣慰。
我们在编写文档时力求精确可靠，随时可能对内容进行修改或变更，恕不另行通知。
如果您在使用中遇到任何问题，或者有好的建议，请按照文档提供的联系方式联系我们。
对您在使用中遇到的问题，我们会尽力给予支持，对您提出的建议，我们衷心感谢并会尽快评估采纳。
版权本文档版权归诺瓦科技所有，未经本公司书面许可，任何单位或个人不得以任何形式对文本内容进行复制、摘录等，违者必究。
商标是诺瓦科技的注册商标。
安全声明为避免可能的危险，请按规定使用此设备。
插座应当装在设备的附近，而且应当便于触及到。
如出现损坏，非专业人士请勿擅自打开维修，请及时与本公司售后联系。
高压危险：本产品的工作电压为100～240V AC。
接地：本产品通过电源的地线与大地相连，请确保接地导体的良好接地。
电磁干扰：设备应远离磁铁、马达及变压器。
防潮：请将设备置于干燥、干净的环境中。
如有液体浸入，请立即拔掉电源插头。
远离易燃易爆危险物品。
禁止液体、金属碎片浸入机器内部，以免引起安全事故。
1外观说明 1前面板 1 后面板 12信号连接 33产品尺寸 44操作动作说明 45主界面 56菜单操作 6第一步输入模式设置 6 第二步输入分辨率设置 6 第三步快捷点屏 7 第四步亮度调节 7 屏体配置 8 画面控制 8 高级设置 9 通讯设置 11 语言设置 117技术规格 128常见问题与注意事项 131 外观说明①：开机键。
短按开机，开机后长按 4~5 秒关机②：USB 接口，仅连接 U 盘（不可接电脑）③：操作屏幕④：旋钮，按下旋钮表示进入或输入确定，旋转旋钮表示选择或参数调节⑤：BACK，退回上层菜单后面板DP 1.2DP 1.2 接口，支持 HDCP 1.3HDMI 2.0HDMI 2.0 接口，支持 HDCP 1.4 和 HDCP 2.2 DUAL DVI-D1/D2双链路 DVI 接口1~1616 路 Neutrik 千兆网口输出OPT1~44 路光纤输出OPT1 对应网口 1~8，OPT2 对应网口 9~16 OPT3 为 OPT1 的备份，OPT4 为 OPT2 的备份ETHERNET控制接口USB IN: 级联输入或与 PC 连接； OUT：级联下一台IN Genlock 同步信号，保证大屏显示画面和外部Genlock 源同步，Genlock 类型：BlackburstLOOP Genlock 的环出端口AC 100-240V ～ 50/60HZ交流电源接口注意：A 型 USB 接口（扁口）禁止直接与控制计算机连接。
SpecificationsController MCTRL660 OverviewMCTRL660 is the latest independent master controller of NovaStar, which is mainly applied for display rental service.It supports screen configuration at any time without a computer.Features1)It has adopted an innovative design to implement smartconfiguration and the screen configuration can be completed within30 seconds.2) It has adopted Nova G4 engine, which makes the screen stable andflicker free without scanning lines. The images become exquisite andbring a good sense of depth.3) It supports Nova's new-generation pixel-by-pixel calibrationtechnology which is fast and efficient.4) It c an implement white balance calibration and color gamutmapping based on different features of LEDs used by displays toensure restoration of true colors.5) It is the only control system supporting the input of 12-bithigh-definition multimedia interface (HDMI) and high-bandwidthdigital content protection (HDCP) in China.6) It supports screen configuration at any time without a computer.7) It supports manual adjustment of screen brightness, which isconvenient and efficient. These features have satisfied the specialneeds of display rental service to the maximum extent.8)HDMI/DVI Input.9)HDMI/DVI Output.10)HDMI/external audio input.11)12bit/10bit/8bit HD video source.12)Resolution supported: 2048×1152，1920×1200，2560×960.13) R esolution supported: 1440 ×900 , (12 bit/10 bit).14) C ascading supported.15) V ideo format: RGB, YCrCb4:2:2, YCrCb4:4:4.DimensionsUnit: mmAppearancearrangement of interface can be slightly adjusted to enhanceuser’s experience. Please in kind prevail.XI'ANSpecificaFCCXI'ANNOVASTARTECHCO.,LTD.difications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmfulinterference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radiocommunications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will berequired to correct the interference at his own expense.。
