论文题目:Sol-gel在无机材料中的应用课程名称:无机合成化学专业名称:应用化学学号:1109341009姓名:高康能成绩:2014年9月29日Sol-gel在无机材料中的应用摘要:介绍了溶胶-凝胶法制备有机-无机杂化材料的原理、分类和制备方法及应用。
关键词:溶胶-凝胶法、无机材料、应用引言随着现代科技的发展,单一性能的材料已不能满足人们的需要。
目前通过两种或多种材料的功能复合,性能互补和优化,无机有机杂化材料是无机材料和有机材料在纳米尺度结合的复合材料,两相间存在强的作用力的结构。
可以克服单一的有机或无机材料的局限性。
同时在光学、力学、电学及电化学等方面呈现出许多新的特性。
因此无机有机杂化材料是材料领域的一个重要的研究方向[1-4]。
1 溶胶凝胶法的基本理论溶胶是指分散在液体中的粒子足够小(100mm)以致可以通过布朗运动保持无限期的悬浮。
凝胶是一种包含液相组分秋游内部网络结构的固体,此时的液相和故乡都呈现一种高度分散的状态。
溶胶-凝胶法一般是以金属及半金属盐作为前躯体(硅酸甲酯(TMOS)、正硅酸乙酯(TEOS)、酞酸丁酯等)在水、互溶剂三维网络结构在成胶的过程及催化剂的存在下发生水解和缩聚反应,,形成SiO2中,若引人掺杂组分,可将其包埋于三维网络结构中用溶胶一凝胶法制备的材料不仅有良好的化学性能、高的光稳定性和透过性,,同时溶胶凝胶过程还具有纯度高、均匀性强、反应条件易于控制并易于实现多种产品构型等优点溶胶-凝胶法是湿化学反应方法之一,不论所用的起始原料称为前驱物为无机盐或金属醇盐,其主要反应步骤是前驱物溶于溶剂水或有机溶剂中形成均匀的溶液,溶质与溶剂产生水解或醇解反应生成物聚集成1nm左右的粒子并组成溶胶,经蒸发干燥转变为凝胶具体过程为图溶剂化、水解反应和缩聚反应。
2 溶胶凝胶的特点溶胶一凝胶法的特点是用液体化学试剂或将粉状试剂溶于溶剂中或溶胶为原料,而不是用传统的粉状物体,反应物在液相下均匀混合并进行反应,反应生成物是稳定的溶胶体系,经放置一定时间转变为凝胶,其中含有大量液相,需借助蒸发除去液体介质,而不是机械脱水。
