LC320EUN-SEF1_CAS_GENERAL_201208071343

LC320EUNProduct SpecificationSPECIFICATIONFOR APPROVAL() Preliminary Specification( ● ) Final SpecificationTitleBUYER MODEL GENERAL32.0” WUXGA TFT LCDSUPPLIER *MODEL SUFFIX LG Display Co., Ltd. LC320EUN SEF1 (RoHS Verified)*When you obtain standard approval, please use the above model name without suffix SIGNATURE DATEAPPROVED BY /APPROVED BYSIGNATURE DATEREVIEWED BY /PREPARED BY /Please return 1 copy for your confirmation with your signature and comments.Ver. 1.0TV Product Development Dept. LG Display Co., Ltd.0 /38LC320EUNProduct SpecificationCONTENTSNumberCOVER CONTENTS RECORD OF REVISIONS 1 2 3 3-1 3-2 3-3 3-4 3-5 3-6 4 5 6 7 7-1 7-2 7-3 8 8-1 8-2 9 9-1 9-2 9-3 9-4 9-5 9-6 9-7 Ver. 1.0 GENERAL DESCRIPTION ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTERISTICS INTERFACE CONNECTIONS SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS COLOR DATA REFERENCE POWER SEQUENCE OPTICAL SPECIFICATIONS MECHANICAL CHARACTERISTICS RELIABILITY INTERNATIONAL STANDARDS SAFETY EMC ENVIRONMENT PACKING DESIGNATION OF LOT MARK PACKING FORM PRECAUTIONS MOUNTING PRECAUTIONS OPERATING PRECAUTIONS ELECTROSTATIC DISCHARGE CONTROL PRECAUTIONS FOR STRONG LIGHT EXPOSURE STORAGE HANDLING PRECAUTIONS FOR PROTECTION FILM OPERATING GONDITION GUIDEITEMPage0 1 2 3 4 5 5 7 9 10 13 14 16 22 25 26 26 26 26 27 27 27 28 28 28 29 29 29 29 29 1 /38LC320EUNProduct SpecificationRECORD OF REVISIONSRevision No.0.0 1.0Revision DateJUL, 19, 2011 NOV, 16, 2011Page-DescriptionPreliminary Specification(First Draft) CAS Version 1.0 ReleaseVer. 1.02 /38LC320EUNProduct Specification1. General DescriptionThe LC320EUN is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED) b ac k l i g ht s ys t em . T he m a t r i x em p l o ys a - S i T h i n F i lm T r an s is t or a s t he a c t i v e e l em en t . It is a transmissive display type which is operating in the normally black mode. It has a 31.55 inch diagonally measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel array). Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes. Gray scale or the luminance of the sub-pixel color is determined with a 8-bit gray scale signal for each dot. Therefore, it can present a palette of more than 16.7Milion colors. It has been designed to apply the 8-bit 2-port LVDS interface. It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.EPI(RGB) LVDS EEPROM SDAG1Source Driver CircuitS1 S19202PortLVDS Select OPC Enable SCL LVDS 1,2 Option signalTiming ControllerLVDS Rx + OPC + DGA Integrated Control SignalsG1080TFT - LCD Panel(1920 × RGB × 1080 pixels) [Gate In Panel]CN1(51pin)ExtVBR-B +12.0VI2CPWM_OUT CN2 1~3 (4 pin) PWM_OUT 1~3 +24.0V, GND, On/OffPower Circuit BlockPower SignalsScanning Block 1 Scanning Block 2LED DriverScanning Block 3General FeaturesActive Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Viewing Angle (CR>10) Power Consumption Weight Display Mode Surface Treatment Ver. 1.0 31.55 inches(801.31mm) diagonal 727.4(H) × 429.0 (V) X 9.9 (B)/22.7 mm(D) (Typ.) 0.36375 mm x 0.36375 mm 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement 8bit, 16.7 Million colors 360 cd/m2 (Center 1point ,Typ.) Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.)) Total 37.94W(Typ.) [Logic= 6.04W, LED Driver=31.9W (ExtVbr_B=100% )] 5.4 Kg (Typ.) Transmissive mode, Normally black Hard coating(2H), Anti-glare treatment of the front polarizer (Haze < 1%) 3 /38LC320EUNProduct Specification2. Absolute Maximum RatingsThe following items are maximum values which, if exceeded, may cause faulty operation or permanent damage to the LCD module. Table 1. ABSOLUTE MAXIMUM RATINGSValue Parameter LCD Circuit Power Input Voltage Driver ON/OFF Driver Control Voltage Brightness T-Con Option Selection Voltage Operating Temperature Storage Temperature Panel Front Temperature Operating Ambient Humidity Storage Humidity EXTVBR-B VLOGIC TOP TST TSUR HOP HST 0.0 -0.3 0 -20 10 10 +3.6 +4.0 +50 +60 +68 90 90 VDC VDC °C °C °C %RH 2,3 %RH 2,3 4 VBL VOFF / VON -0.3 -0.3 + 27.0 +5.5 VDC VDC 1 Symbol Min VLCD -0.3 Max +14.0 VDC Unit NoteNote1. Ambient temperature condition (Ta = 25 ± 2 °C ) 2. Temperature and relative humidity range are shown in the figure below. Wet bulb temperature should be Max 39°C, and no condensation of water. 3. Gravity mura can be guaranteed below 40°C condition. 4. The maximum operating temperatures is based on the test condition that the surface temperature of display area is less than or equal to 68°C with LCD module alone in a temperature controlled chamber. Thermal management should be considered in final product design to prevent the surface temperature of display area from being over 68℃. The range of operating temperature may be degraded in case of improper thermal management in final product design.90% 60 60% Wet Bulb Temperature [°C] 30 20 10 0 10% 10 20 30 40 50 60 70 80 Humidity [(%)RH] 50 40 Storage40%Operation-200Dry Bulb Temperature [°C]Ver. 1.04 /38LC320EUNProduct Specification3. Electrical Specifications 3-1. Electrical CharacteristicsIt requires two power inputs. One is employed to power for the LCD circuit. The other Is used for the LED backlight and LED Driver circuit. Table 2. ELECTRICAL CHARACTERISTICSValue Parameter Circuit : Power Input Voltage Power Input Current Power Consumption Rush current VLCD ILCD PLCD IRUSH ExtVBR-B Brightness Adjust for Back Light ExtVBR-B Frequency Pulse Duty Level (PWM) High Level Low Level 5 1 40 2.5 0 10.8 12.0 503 734 6.04 50/60 13.2 654 954 7.85 5.0 100 100 80 3.6 0.8 VDC mA mA Watt A % % Hz Vdc Vdc HIGH : on duty LOW : off duty 1 2 1 3 On Duty 4 Symbol Min Typ Max Unit NoteNote 1. The specified current and power consumption are under the VLCD=12.0V, Ta=25 ± 2°C, fV=60Hz condition, and mosaic pattern(8 x 6) is displayed and fV is the frame frequency. 2. The current is specified at the maximum current pattern. 3. The duration of rush current is about 2ms and rising time of power input is 0.5ms (min.). 4. ExtVBR-B signal have to input available duty range and sequence. After Driver ON signal is applied, ExtVBR-B should be sustained from 5% to 100% more than 500ms. After that, ExtVBR-B 1% and 100% is possible For more information, please see 3-6-2. Sequence for LED Driver. 5. Ripple voltage level is recommended under ±5% of typical voltageWhite : 255 Gray Black : 0 GrayMosaic Pattern(8 x 6)Ver. 1.0 5 /38LC320EUNProduct SpecificationTable 3. ELECTRICAL CHARACTERISTICS (Continue)Values Parameter LED Driver : Power Supply Input Voltage Power Supply Input Current Power Supply Input Current (In-Rush) Power Consumption Input Voltage for Control System Signals LED : Life Time 30,000 50,000 Hrs 2 On On/Off Off VBL IBL In-rush PBL V on V off 22.8 2.5 -0.3 24.0 1.33 31.9 0.0 25.2 1.45 3 34.8 5.0 0.7 Vdc A A W Vdc Vdc 1 1 VBL = 22.8V ExtVBR-B = 100% 3 1 Symbol Min Typ Max Unit NotesNotes : 1. Electrical characteristics are determined after the unit has been ‘ON’ and stable for approximately 60 minutes at 25±2°C. The specified current and power consumption are under the typical supply Input voltage 24Vand VBR (ExtVBR-B : 100%), it is total power consumption. 2. The life time (MTTF) is determined as the time which luminance of the LED is 50% compared to that of initial value at the typical LED current (ExtVBR-B :100%) on condition of continuous operating in LCM state at 25±2°C. 3. The duration of rush current is about 200ms. This duration is applied to LED on time. 4. Even though inrush current is over the specified value, there is no problem if I2T spec of fuse is satisfied.Ver. 1.06 /38LC320EUNProduct Specification 3-2. Interface ConnectionsThis LCD module employs two kinds of interface connection, 51-pin connector is used for the module electronics and 14-pin connector is used for the integral backlight system. 3-2-1. LCD Module - LCD Connector(CN1): FI-R51S-HF(manufactured by JAE) or compatible Refer to below and next Page table - Mating Connector : FI-R51HL(JAE) or compatible Table 4. MODULE CONNECTOR(CN1) PIN CONFIGURATIONNo1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26SymbolNC NC NC NC NC NC LVDS Select ExtVBR-B NC OPC Enable GND R1AN R1AP R1BN R1BP R1CN R1CP GND R1CLKN R1CLKP GND R1DN R1DP NC NC NC or GNDDescriptionNo Connection (Note 4) No Connection (Note 4) No Connection (Note 4) No Connection (Note 4) No Connection (Note 4) No Connection (Note 4) ‘H’ =JEIDA , ‘L’ or NC = VESA External PWM (from System) No Connection (Note 4) ‘H’ = Enable , ‘L’ or NC = Disable Ground FIRST LVDS Receiver Signal (A-) FIRST LVDS Receiver Signal (A+) FIRST LVDS Receiver Signal (B-) FIRST LVDS Receiver Signal (B+) FIRST LVDS Receiver Signal (C-) FIRST LVDS Receiver Signal (C+) Ground FIRST LVDS Receiver Clock Signal(-) FIRST LVDS Receiver Clock Signal(+) Ground FIRST LVDS Receiver Signal (D-) FIRST LVDS Receiver Signal (D+) No connection No connection No Connection or GroundNo27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 -SymbolNC R2AN R2AP R2BN R2BP R2CN R2CP GND R2CLKN R2CLKP GND R2DN R2DP NC NC NC or GND NC or GND GND GND GND NC VLCD VLCD VLCD VLCD No connectionDescriptionSECOND LVDS Receiver Signal (A-) SECOND LVDS Receiver Signal (A+) SECOND LVDS Receiver Signal (B-) SECOND LVDS Receiver Signal (B+) SECOND LVDS Receiver Signal (C-) SECOND LVDS Receiver Signal (C+) Ground SECOND LVDS Receiver Clock Signal(-) SECOND LVDS Receiver Clock Signal(+) Ground SECOND LVDS Receiver Signal (D-) SECOND LVDS Receiver Signal (D+) No connection No connection No Connection or Ground No Connection or Ground Ground Ground Ground No connection Power Supply +12.0V Power Supply +12.0V Power Supply +12.0V Power Supply +12.0V -Note1. All GND(ground) pins should be connected together to the LCD module’s metal frame. 2. All VLCD (power input) pins should be connected together. 3. All Input levels of LVDS signals are based on the EIA 644 Standard. 4. #1~#6 & #9 NC (No Connection): These pins are used only for LGD (Do not connect) 5. Specific pins(pin No. #10) are used for OPC function of the LCD module. If not used, these pins are no connection. (Please see the Appendix VI for more information.) 6. Specific pin No. #44 is used for “No signal detection” of system signal interface. It should be GND for NSB(No Signal Black) during the system interface signal is not. If this pin is “H”, LCD Module displays AGP(Auto Generation Pattern).Ver. 1.07 /38LC320EUNProduct Specification3-2-2. Backlight Module Master -LED Driver Connector : 20022WR - H14B2(Yeonho) or compatible - Mating Connector : 20022HS - 14B2 or compatible Table 5-1. LED DRIVER CONNECTOR PIN CONFIGURATION Pin No 1 2 3 4 5 6 7 8 9 10 11 12 13 14 SymbolVBL VBL VBL VBL VBL GND GND GND GND GND Status VON/OFF NC NCDescriptionPower Supply +24.0V Power Supply +24.0V Power Supply +24.0V Power Supply +24.0V Power Supply +24.0V Backlight Ground Backlight Ground Backlight Ground Backlight Ground Backlight Ground Back Light Status Backlight ON/OFF control Don’t care Don’t careNote12Notes :1. GND should be connected to the LCD module’s metal frame. 2. Normal : Low (under 0.7V) / Abnormal : Open 3. Each impedance of pin #12 is over 50 [KΩ] .◆ Rear view of LCM PCB 1 … <Master>Ver. 1.0 8 /381 …1414LC320EUNProduct Specification 3-3. Signal Timing SpecificationsTable 6 shows the signal timing required at the input of the LVDS transmitter. All of the interface signal timings should be satisfied with the following specification for normal operation. Table 6. TIMING TABLE (DE Only Mode)ITEM Display Period Horizontal Blank Total Display Period Vertical Blank Symbol tHV tHB tHP tVV Min 960 100 1060 1080 20 (228) 1100 (1308) Typ 960 140 1100 1080 45 (270) 1125 (1350) Max 960 240 1200 1080 69 (300) 1149 (1380) Unit tCLK tCLK tCLK Lines Note 1920 / 2 1tVBLines1TotaltVPLinesITEM DCLK Horizontal Frequency VerticalSymbol fCLK fHMin 63.00 57.3Typ 74.25 67.5Max 78.00 70Unit MHz KHzNote2 2 NTSC : 57~63Hz (PAL : 47~53Hz)fV57 (47)60 (50)63 (53)HzNote: 1. The input of HSYNC & VSYNC signal does not have an effect on normal operation (DE Only Mode). If you use spread spectrum of EMI, add some additional clock to minimum value for clock margin. 2. The performance of the electro-optical characteristics may be influenced by variance of the vertical refresh rate and the horizontal frequency ※ Timing should be set based on clock frequency.Ver. 1.09 /38LC320EUNProduct Specification 3-4. LVDS Signal Specification3-4-1. LVDS Input Signal Timing DiagramDE, Data0.7VDD 0.3VDDtCLKDCLK0.5 VDDValid data First data Invalid dataPixel 0,0 Pixel 2,0Invalid dataValid data Second data Invalid dataPixel 1,0 Pixel 3,0Invalid dataDE(Data Enable)tHV tHP 1DE(Data Enable)1080tVVtVPVer. 1.010 /38LC320EUNProduct Specification3-4-2. LVDS Input Signal Characteristics 1) DC SpecificationLVDS -LVDS+V CM # V CM = {( LVDS +) + ( LVDS - )} /2 0VV IN _ MAXV IN _ MINDescription LVDS Common mode Voltage LVDS Input Voltage Range Change in common mode Voltage 2) AC SpecificationSymbol VCM VIN ∆VCMMin 1.0 0.7 -Max 1.5 1.8 250Unit V V mVNote -Tclk LVDS ClockALVDS DatatSKEW tSKEW( F clk = 1/T clk )ATclk80%LVDS 1’st Clock LVDS 2nd / 3rd / 4th Clock20% tRFtSKEW_min tSKEW_maxDescription LVDS Differential Voltage LVDS Clock to Data Skew LVDS Clock/DATA Rising/Falling time Effective time of LVDS LVDS Clock to Clock Skew (Even to Odd) High Threshold Low ThresholdSymbol VTH VTL tSKEW tRF teff tSKEW_EOMin 100 -300 260 |±360| -Max 300 -100 |(0.25*Tclk)/7| |(0.3*Tclk)/7| |1/7* Tclk|Unit mV mV ps ps ps psNote 3 2 -Note 1. All Input levels of LVDS signals are based on the EIA 644 Standard. 2. If tRF isn’t enough, teff should be meet the range. 3. LVDS Differential Voltage is defined within teffVer. 1.0 11 /38LC320EUNProduct Specification360ps 0.5tui V+ data tuiVTH Vcm VTLVdata360ps teffV+ clktui : Unit IntervalVcmVclkVer. 1.012 /38LC320EUNProduct Specification 3-5. Color Data ReferenceThe brightness of each primary color(red,green,blue) is based on the 8bit gray scale data input for the color. The higher binary input, the brighter the color. Table 7 provides a reference for color versus data input. Table 7. COLOR DATA REFERENCEInput Color Data RED Color MSB LSB MSB GREEN LSB MSB BLUE LSBR7 R6 R5 R4 R3 R2 R1 R0Black Red (255) Green (255) 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 ... 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 ... 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 ... 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 0 1 1 0 0 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0G7 G6 G5 G4 G3 G2 G1 G00 0 1 0 0 1 0 0 0 1 1 0 1 1 1 1 0 0 1 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 ... 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 ... 0 1 0 1 0 0 0 0 1 1 0 0 1 1 0 0 1 1 0 0 ... 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 0 1 1 0 0 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0B7 B6 B5 B4 B3 B2 B1 B00 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 ... 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 00 0 0 0 1 0 0 1 1 1 0 1 1 0 1 1 0 0 0 0Basic ColorBlue (255) Cyan Magenta Yellow White RED (000) RED (001)RED... RED (254) RED (255) GREEN (000) GREEN (001)0 0 0 0 0 0 1 00 0 0 00 0 0 00 0 0 0 ...0 0 0 00 0 0 00 0 0 00 0 0 0GREEN... GREEN (254) GREEN (255) BLUE (000) BLUE (001)0 0 1 0 0 0 0 00 0 0 00 0 0 00 0 0 0 ...0 0 0 00 0 0 00 0 0 00 0 0 1BLUE... BLUE (254) BLUE (255)0 1 0 11 11 11 11 11 11 10 1Ver. 1.013 /38LC320EUNProduct Specification3-6. Power Sequence3-6-1. LCD Driving circuit90%90% 10% T8 T2 30% T5 10%Power Supply For LCD VLCD0V10% T1Valid DataVcm : LVDS Common mode VoltageInterface Signal (Tx_clock)0V 100% T6 T3 T4User Control Signal (LVDS_select, OPC Enable, ExtVBR-B) Power for LEDT7LED ONTable 8. POWER SEQUENCEValue Parameter Min T1 T2 T3 T4 T5 T6 T7 T8 0.5 0 200 200 1.0 0.5 100 Typ Max 20 T2 ms ms ms ms s ms s ms 1 2 3 3 4 5 6 7 Unit NotesNote :1. Even though T1 is over the specified value, there is no problem if I2T spec of fuse is satisfied. 2. If T2 is satisfied with specification after removing LVDS Cable, there is no problem. 3. The T3 / T4 is recommended value, the case when failed to meet a minimum specification, abnormal display would be shown. There is no reliability problem. 4. T5 should be measured after the Module has been fully discharged between power off and on period. 5. If the on time of signals (Interface signal and user control signals) precedes the on time of Power (VLCD), it will be happened abnormal display. When T6 is NC status, T6 doesn’t need to be measured. 6. If there is no abnormal display, no problem. 7. It is recommendation specification that T8 has to be 100ms as a minimum value. ※ Please avoid floating state of interface signal at invalid period. ※ When the power supply for LCD (VLCD) is off, be sure to pull down the valid and invalid data to 0V. 14 /38Ver. 1.0LC320EUNProduct Specification3-6-2. Sequence for LED Driver Power Supply For LED Driver24V (typ.) 90% 90%VBL10% 0VT1 VON/OFFT2T3LED ONExtVBR-BT4T63-6-3. Dip condition for LED DriverT5 VBL : 24VVBL(Typ.) x 0.8 0V Table 9. Power Sequence for LED DriverParameter T1 T2 T3 T4 T5 T6 Values Min 20 500 10 0 500 Typ Max 10 Units ms ms ms ms ms ms VBL(Typ) x 0.8 2 Remarks 1Notes : 1. T1 describes rising time of 0V to 24V and this parameter does not applied at restarting time. Even though T1 is over the specified value, there is no problem if I2T spec of fuse is satisfied. 2. In T6 section, ExtVBR-B should be sustained from 5% to 100% .Ver. 1.0 15 /38LC320EUNProduct Specification4. Optical SpecificationOptical characteristics are determined after the unit has been ‘ON’ and stable in a dark environment at 25±2°C. The values are specified at 50cm from the LCD surface at a viewing angle of Φ and θ equal to 0 °. FIG. 1 shows additional information concerning the measurement equipment and method. Optical Stage(x,y) LCD Module Pritchard 880 or equivalent50cm FIG. 1 Optical Characteristic Measurement Equipment and Method Table 10. OPTICAL CHARACTERISTICSParameter Contrast Ratio Surface Luminance, white Luminance Variation Response Time Gray-to-Gray Uniformity RED GREEN BLUE WHITE Color Temperature Color Gamut x axis, right(φ=0°) Viewing Angle 2D (CR>10) x axis, left (φ=180°) y axis, up (φ=90°) y axis, down (φ=270°) 3D up + down (CT≤10%) 3D Crosstalk Gray Scale Ver. 1.0 θr θl θu θd θu (y axis) +θd (y axis) 3D C/T 89 89 89 89 11 2 5.4 Symbol CR LWH δ WHITE G to G σ G to G BW Rx Ry Gx Gy Bx By Wx Wy Typ -0.03 5P Ta= 25±2°C, VLCD=12.0V, fV=60Hz, Dclk=74.25MHz, EXTVBR-B =100% Value Min 1000 290 110 Typ 1400 360 135 6 8 0.637 0.344 0.321 0.602 0.155 0.055 0.279 0.292 10,000 68 10 % 8 8 7 16 /38 degree 6 K % Typ +0.03 1.3 9 12 ms Max cd/m2 Unit Note 1 2 3 5 4Color Coordinates [CIE1931]LC320EUNProduct SpecificationNote : 1. Contrast Ratio(CR) is defined mathematically as : Surface Luminance with all white pixels Surface Luminance with all black pixels It is measured at center 1-point. 2. Surface luminance are determined after the unit has been ‘ON’ and 1 Hour after lighting the backlight in a dark environment at 25±2°C. Surface luminance is the luminance value at center 1-point across the LCD surface 50cm from the surface with all pixels displaying white. For more information see the FIG. 2. 3. The variation in surface luminance , δ WHITE is defined as : δ WHITE(5P) = Maximum(Lon1,Lon2, Lon3, Lon4, Lon5) / Minimum(Lon1,Lon2, Lon3, Lon4, Lon5) Where Lon1 to Lon5 are the luminance with all pixels displaying white at 5 locations . For more information, see the FIG. 2. 4. Response time is the time required for the display to transit from any gray to white (Rise Time, TrR) and from any gray to black (Decay time, TrD). For additional information see the FIG. 3. ※ G to GBW Spec stands for average value of all measured points. Photo Detector : RD-80S / Field : 2 ° 5. G to G σ is Variation of Gray to Gray response time composing a picture Contrast Ratio = G to G (σ) =√Σ(Xi- u)2 NXi = Individual Data u = Data average N : The number of Data6. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD module surface. For more information, see the FIG. 4. 7. Gray scale specification Gamma Value is approximately 2.2. For more information, see the Table 11. 8. 3D performance specification is expressed by 3D luminance and 3D viewing angle. Table 11. GRAY SCALE SPECIFICATIONGray Level L0 L15 L31 L47 L63 L79 L95 L111 L127 L143 L159 L175 L191 L207 L223 L239 L255 Ver. 1.0 Luminance [%] (Typ) 0.07 0.27 1.04 2.49 4.68 7.66 11.5 16.1 21.6 28.1 35.4 43.7 53.0 63.2 74.5 86.7 100 17 /38LC320EUNProduct SpecificationMeasuring point for surface luminance & measuring point for luminance variation.H A② ①B V③④⑤A : H / 4 mm B : V / 4 mm @ H,V : Active AreaFIG. 2 5 Points for Luminance MeasureResponse time is defined as the following figure and shall be measured by switching the input signal for “Gray(N)” and “Black or White”.Tr 100 90TfOptical Response10 0 Gray(N) Gray(N) White N = 0(Black)~255(White) FIG. 3 Response Time BlackVer. 1.018 /38LC320EUNProduct SpecificationDimension of viewing angle rangeNormalEYφ = 90 ° , Upφ = 180 ° , Leftθ φφ = 0 ° , Rightφ = 270 ° , DownFIG. 4 Viewing AngleVer. 1.019 /38Product SpecificationLC320EUN4) Measurement of 3D crosstalk(i) Test image ( LB-RW, LW-RB and LB-RB ) is displayed.(ii) Right or left eyeglass are placed in front of LMS successively andluminance is measured for position 1.with rotating LMS or sample vertically.Average ofand3) Measurement of 3D luminance(i) Test image ( LW-RW ) is displayed.(ii) Left or right eyeglass are placed in front of LMS successively andluminance is measured at center 1 point where the notation for luminance measurement is “Lum(LE, LW-RW,1)” or “Lum(RE, LW-RW,1). Lum(LE, LB-RW,1) -Lum(LE, LB-RB,1)Lum(LE, LW-RB,1) -Lum(LE, LB-RB,1)Lum(RE, LW-RB,1) -Lum(RE, LB-RB,1)Lum(RE, LB-RW,1) -Lum(RE, LB-RB,1)5)Measurement of 3D Viewing Angle3D viewing angle is the angle at which the 3D crosstalk is under 10%. The angles are determined for the vertical or y axis with respect to the z axis which is normal to the LCD Ver. 1.021/38< FIG. 9. Measurement of 3D crosstalk and 3D viewing angle >LB-RWLW-RBLB-RBΦyd (down)Φyu(up)LMS(a) Test pattern image(b) Measurement of 3D viewing angle (up/down)module surface and measured for position 1. For more information , see the Fig 9y axisLCMz axisProduct SpecificationLC320EUN Table 12 provides general mechanical characteristics.5. Mechanical CharacteristicsTable 12. MECHANICAL CHARACTERISTICSItem ValueOutline Dimension Horizontal727.4 mm Vertical429.0 mm Depth9.9mmBezel AreaHorizontal705.6 mmVertical400.1 mmActive Display AreaHorizontal698.4mmVertical392.9mmWeight 5.4Kg (Typ.), 5.7 kg (Max.)Ver. 1.022/38 Note : Please refer to a mechanical drawing in terms of tolerance at the next page.Product SpecificationLC320EUN6. ReliabilityTable 13. ENVIRONMENT TEST CONDITION No.Test ItemCondition1High temperature storage test Ta= 60°C 240h 2Low temperature storage test Ta= -20°C 240h3High temperature operation test Ta= 50°C 50%RH 240h 4Low temperature operation testTa= 0°C 240h5Vibration test (non-operating)Wave form : random Vibration level : 1.0Grms Bandwidth : 10-300Hz Duration : X,Y,Z,Each direction per 10 min 6Shock test(non-operating)Shock level : 50GrmsWaveform : half sine wave, 11ms Direction :±X, ±Y, ±ZVer. 1.025/38Note : Before and after Reliability test, LCM should be operated with normal function.One time each direction 7Humidity condition Operation Ta= 40 °C ,90%RH 8Altitude operatingstorage / shipment0 -15,000 ft 0 -40,000 ftLC320EUNProduct Specification7. International Standards7-1. Safetya) UL 60065, Seventh Edition, Underwriters Laboratories Inc.Audio, Video and Similar Electronic Apparatus -Safety Requirements.b) CAN/CSA C22.2 No.60065:03, Canadian Standards Association.Audio, Video and Similar Electronic Apparatus -Safety Requirements.c) EN 60065:2002 + A11:2008, European Committee for Electrotechnical Standardization (CENELEC).Audio, Video and Similar Electronic Apparatus -Safety Requirements.d) IEC 60065:2005 + A1:2005, The International Electrotechnical Commission (IEC).Audio, Video and Similar Electronic Apparatus -Safety Requirements.(Including report of IEC60825-1:2001 clause 8 and clause 9)Notes1. Laser (LED Backlight) InformationClass 1M LED ProductIEC60825-1 : 2001Embedded LED Power (Class 1M)2. Caution: LED inside.Class 1M laser (LEDs) radiation when open.Do not open while operating.7-2. EMCa) ANSI C63.4 “American National Standard for Methods of Measurement of Radio-NoiseEmissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz.”American National Standards Institute (ANSI), 2003.b) CISPR 22 “Information technology equipment –Radio disturbance characteristics –Limit andmethods of measurement." International Special Committee on Radio Interference(CISPR), 2005.c) CISPR 13 “Sound and television broadcast receivers and associated equipment –Radio disturbancecharacteristics –Limits and method of measurement." International Special Committee on RadioInterference (CISPR), 2006.7-3. Environmenta) RoHS, Directive 2002/95/EC of the European Parliament and of the council of 27 January 2003Ver. 1.026/38Product SpecificationLC320EUN8. Packing8-1. Designation of Lot Marka) Lot MarkABCDEFGHIJKLMA,B,C : SIZE(INCH) D : YEARE : MONTHF ~ M : SERIAL NO.Note1. YEAR2. MONTHMarkYear K2020F2016G2017H2018J2019D2014E2015CBA201320122011Nov Month Oct Jun Jul Aug Sep Apr May Dec Mar Feb Jan Ver. 1.027/388-2. Packing Forma) Package quantity in one Pallet : 6 pcs b) Pallet Size : 1140 mm X 870 mm X 1161 mm.a) Package quantity in one Pallet : 4 pcs b) Pallet Size : 1200 mm X 870 mm X 1133 mm.8-2-1. PJ/GZ/NJ8-2-2. WRBMarkA678945C321b) Location of Lot MarkSerial No. is printed on the label. The label is attached to the backside of the LCD module.This is subject to change without prior notice.。
