功率因数调整电费对照表
表一：
无功/有功比值 功率因数
cosφ 调整电费％
0.90 0.85 0.80
0.0000～0.1003 1.00 -0.75 -1.10 -1.30
0.1004～0.1751 0.99 -0.75 -1.10 -1.30
0.1752～0.2279 0.98 -0.75 -1.10 -1.30
0.2280～0.2717 0.97 -0.75 -1.10 -1.30
0.2718～0.3105 0.96 -0.75 -1.10 -1.30
0.3106～0.3461 0.95 -0.75 -1.10 -1.30
0.3462～0.3793 0.94 -0.60 -1.10 -1.30
0.3794～0.4107 0.93 -0.45 -0.95 -1.30
0.4108～0.4409 0.92 -0.30 -0.80 -1.30
0.4410～0.4700 0.91 -0.15 -0.65
-1.15
0.4701～0.4983 0.90 0.00 -0.50 -1.00
0.4984～0.5260 0.89 +0.50 -0.40 -0.90
0.5261～0.5532 0.88 +1.00 -0.30 -0.80
0.5533～0.5800 0.87 +1.50 -0.20 -0.70
0.5801～0.6065 0.86 +2.00 -0.10 -0.60
0.6066～0.6328 0.85 +2.50 0.00 -0.50
0.6329～0.6589 0.84 +3.00 +0.50 -0.40
0.6590～0.6850 0.83 +3.50 +1.00 -0.30
0.6851～0.7109 0.82 +4.00 +1.50 -0.20
0.7110～0.7369 0.81 +4.50 +2.00 -0.10
0.7370～0.7630 0.80 +5.00 +2.50 0.00
0.7631～0.7891 0.79 +5.50 +3.00 +0.50
0.7892～0.8154 0.78 +6.00 +3.50 +1.00
0.8155～0.8418 0.77 +6.50 +4.00 +1.50
0.8419～0.8685 0.76 +7.00 +4.50 +2.00
0.8686～0.8953 0.75 +7.50 +5.00 +2.50
表二：
无功/有功比值 功率因数
cosφ 调整电费％
0.90 0.85 0.80
0.8954～0.9225 0.74 +8.00 +5.50 +3.00
0.9226～0.9499 0.73 +8.50 +6.00 +3.50
0.9500～0.9777 0.72 +9.00 +6.50 +4.00
0.9778～1.0059 0.71 +9.50 +7.00 +4.50
1.0060～1.0345 0.70 +10.00 +7.50 +5.00
1.0346～1.0635 0.68 +11.00 +8.00 +5.50
1.0636～1.0930 0.68 +12.00 +8.50 +6.00
1.0931～1.1230 0.67 +13.00 +9.00 +6.50
1.1231～1.1536 0.66 +14.00 +9.50 +7.00
1.1537～1.1847 0.65 +15.00 +10.00 +7.50
1.1848～1.2165 0.64 +17.00 +11.00 +8.00
1.2166～1.2489 0.63 +19.00 +12.00 +8.50
1.2490～1.2821 0.62 +21.00 +13.00 +9.00
1.2822～1.3160 0.61 +23.00 +14.00 +9.50
1.3161～1.3507 0.60 +25.00 +15.00 +10.00
1.3508～1.3863 0.59 +27.00 +17.00 +11.00
1.3864～1.4228 0.58 +29.00 +19.00 +12.00
1.4229～1.4603 0.57 +31.00 +21.00 +13.00
1.4604～1.4988 0.56 +33.00 +23.00 +14.00
1.4989～1.5384 0.55 +35.00 +25.00 +15.00
1.5385～1.5791 0.54 +37.00 +27.00 +17.00
1.5792～1.6211 0.53 +39.00 +29.00 +19.00
1.6212～1.6644 0.52 +41.00 +31.00 +21.00
1.6645～1.7091 0.51 +43.00 +33.00 +23.00
1.7092～1.7553 0.50 +45.00 +35.00 +25.00
1.7554～1.8031 0.49 +47.00 +37.00 +27.00
表三：
无功/有功比值 功率因数
cosφ 调整电费％
0.90 0.85 0.80
1.8032～1.8526 0.48 +49.00 +39.00 +29.00
1.8527～1.9038 0.47 +51.00 +41.00 +31.00
1.9039～1.9571 0.46 +53.00 +43.00 +33.00
1.9572～2.0124 0.45 +55.00 +45.00 +35.00
2.0125～2.0699 0.44 +57.00 +47.00 +37.00
2.0700～2.1298 0.43 +59.00 +49.00 +39.00
2.1299～2.1923 0.42 +61.00 +51.00 +41.00
2.1924～2.2575 0.41 +63.00 +53.00 +43.00
2.2576～2.3257 0.40 +65.00 +55.00 +45.00
2.3258～2.3971 0.39 +67.00 +57.00 +47.00
2.3972～2.4720 0.38 +69.00 +59.00 +49.00
2.4721～2.5507 0.37 +71.00 +61.00 +51.00
2.5508～2.6334 0.36 +73.00 +63.00 +53.00
2.6335～2.7205 0.35 +75.00 +65.00 +55.00
2.7206～2.8158 0.34 +77.00 +67.00 +57.00
2.8126～2.9098 0.33 +79.00 +69.00 +59.00
2.9099～3.0129 0.32 +81.00 +71.00 +61.00
3.0130～3.1224 0.31 +83.00 +73.00 +63.00
3.1225～3.2389 0.30 +85.00 +75.00 +65.00
3.2390～3.3632 0.29 +87.00 +77.00 +67.00
3.3633～3.4961 0.28 +89.00 +79.00 +69.00
3.4962～3.6386 0.27 +91.00 +81.00 +71.00
3.6387～3.7919 0.26 +93.00 +83.00 +73.00
3.7920～3.9572 0.25 +95.00 +85.00 +75.00
3.9573～4.1361 0.24 +97.00 +87.00 +77.00
4.1362～4.3304 0.23 +99.00 +89.00 +79.00
表四：
无功/有功比值 功率因数
cosφ 调整电费％
0.90 0.85 0.80
4.3305～4.5423 0.22 +101.00 +91.00 +81.00
4.5424～4.7744 0.21 +103.00 +93.00 +83.00
4.7745～5.0297 0.20 +105.00 +95.00 +85.00
5.0298～5.3121 0.19 +107.00 +97.00 +87.00
5.3122～5.6261 0.18 +109.00 +99.00 +89.00
5.6262～5.9775 0.17 +111.00 +101.00 +91.00
5.9776～6.3736 0.16 +113.00 +103.00 +93.00
6.3737～6.8236 0.15 +115.00 +105.00 +95.00
6.8237～7.3395 0.14 +117.00 +107.00 +97.00
7.3396～7.9372 0.13 +119.00 +109.00 +99.00
7.9373～8.6379 0.12 +121.00 +111.00 +101.00
8.6380～9.4711 0.11 +123.00 +113.00 +103.00
9.4712～10.4787 0.10 +125.00 +115.00 +105.00
10.4788～11.7221 0.09 +127.00 +117.00 +107.00
11.7222～13.2957 0.08 +129.00 +119.00 +109.00
13.2958～15.3520 0.07 +131.00 +121.00 +111.00
15.3521～18.1542 0.06 +133.00 +123.00 +113.00
18.1543～22.1997 0.05 +135.00 +125.00 +115.00
22.1998～28.5539 0.04 +137.00 +127.00 +117.00
28.5540～39.9874 0.03 139.00 +129.00 +119.00
39.9875～66.6591 0.02 +141.00 +131.00 +121.00
66.6592～199.9975 0.01 +143.00 +133.00 +123.00
199.9976～∞ 0.00 +145.00 +135.00 +125.00
42L6型功率因数表B.C两接线桩，分别接电源的B.C相.*I.I接电源的A相电流，*I为电流的进线端，I为电流的出线端。当线路上出现无功时，表头指针将从零刻度向滞后刻度盘摆动（向上）。当电容器过补偿时,表头指针将会向超前刻度盘摆动（向下）。如果电流端进出线接反，将出现显示不准确。
