EE-SY313中文资料
- 格式:pdf
- 大小:169.34 KB
- 文档页数:2
VCC = 5 V RL = 330 Ω Ta = 25°C
VOUT (EE-SX3jj) VOUT (EE-SX4jj)
Sensing Position Characteristics (Typical)
IF = 20 mA VCC = 5 V Ta = 25°C Sensing object: White paper with a reflection factor of 90%
1. Refer to the temperature rating chart if the ambient temperature exceeds 25°C. 2. The pulse width is 10 µs maximum with a frequency of 100 Hz. 3. Complete soldering within 10 seconds.
Low level output voltage V OL(V)
VCC = 5 V IF = 0 mA (20 mA)
LED current I FT (mA)
IOL = 16 mA
IFT ON (IFT OFF)
IOL = 5 mA
Ambient temperature Ta (°C)
Output current IC (mA)
Incorporates an IC chip with a built-in detector element and amplifier. Incorporates a detector element with a built-in temperature compensation circuit. Compact reflective Photomicrosensor (EE-SY310/-SY410) with a molded housing and a dust-tight cover. A wide supply voltage range: 4.5 to 16 VDC Directly connects with C-MOS and TTL. Dark ON model (EE-SY313) Light ON model (EE-SY413)
Vcc = 4.5 to 16 V, IOL = 16 mA,without incident light (EE-SY313), with incident light (EE-SY413) (see notes 1 and 2) Vcc = 16 V, RL = 1 kΩ, with incident light (EE-SY313), without incident light (EE-SY413) (see notes 1 and 2)
Condition
Vcc = 16 V VCC = 4.5 to 16 V VCC = 4.5 to 16 V
224
元器件交易网
EE-SY313/-SY413
Note: 1. “With incident light” denotes the condition whereby the light reflected by white paper with a reflection factor of 90% at a sensing distance of 4.4 mm is received by the photo IC when the forward current (IF) of the LED is 20 mA. 2. Sensing object: White paper with a reflection factor of 90% at a sensing distance of 4.4 mm. 3. Hysteresis denotes the difference in forward LED current value, expressed in percentage, calculated from the respective forward LED currents when the photo IC is turned from ON to OFF and when the photo IC is turned from OFF to ON.
EE-SY313/-SY413
4. The value of the response frequency is measured by rotating the disk as shown below.
200 mm dia.
15 mm 15 mm 15 mm
4.4 mm
5. The following illustrations show the definition of response delay time. Theplies to the EESY413.
IFT ON (IFT OFF)
Ambient temperature Ta (°C)
Forward voltage VF (V)
Supply voltage VCC (V)
LED Current vs. Ambient Temperature Characteristics (Typical)
VCC = 5 V RL = 330 Ω IFT OFF (IFT ON)
EE-SY313
EE-SY413
Forward Current vs. Collector Dissipation Temperature Rating
Forward current I F (mA)
Forward Current vs. Forward Voltage Characteristics (Typical)
Electrical and Optical Characteristics (Ta = 25°C)
Item Emitter Forward voltage Reverse current Peak emission wavelength Detector Low-level output voltage High-level output voltage Current consumption Peak spectral sensitivity wavelength LED current when output is OFF LED current when output is ON Hysteresis Response frequency Response delay time Response delay time nH f tPLH (tPHL) tPHL (tPLH) 17% typ. 50 Hz min. 3 µs typ. 20 µs typ. VCC = 4.5 to 16 V VCC = 4.5 to 16 V, IF = 20 mA, IOL = 16 mA VCC = 4.5 to 16 V, IF = 20 mA, IOL = 16 mA VCC = 4.5 to 16 V, IF = 20 mA, IOL = 16 mA Symbol VF IR λP VOL VOH ICC λP IFT Value 1.2 V typ., 1.5 V max. 0.01 µA typ., 10 µA max. 920 nm typ. 0.12 V typ., 0.4 V max. 15 V min. 3.2 mA typ., 10 mA max. 870 nm typ. 10 mA typ., 20 mA max. IF = 20 mA VR = 4 V IF = 20 mA
Response delay time t
tPHL (tPLH)
Distance d 2 (mm)
PHL ,
Operate
Release tPLH (tPHL)
Supply voltage VCC (V)
Forward current IF (mA)
Distance d1 (mm)
225
Forward current I F (mA)
LED Current vs. Supply Voltage (Typical)
Ta = 25°C R L = 1 kΩ
Ta = –30°C Ta = 25°C Ta = 70°C
LED current I FT (mA)
IFT OFF (IFT ON)
Output current Permissible output dissipation
Terminal No. A K V O G
Name Anode Cathode Power supply (Vcc) Output (OUT) Ground (GND)
Operating Storage
Soldering temperature
Forward current Reverse voltage Pulse forward current
Internal Circuit
A V O K G
Detector
Power supply voltage Output voltage
Unless otherwise specified, the tolerances are as shown below. Dimensions 3 mm max. 3 t mm v 6 6 t mm v 10 10 t mm v 18 18 t mm v 30 Tolerance ±0.3 ±0.375 ±0.45 ±0.55 ±0.65 Note: Ambient temperature
Low-level Output Voltage vs. Output Current (Typical)
Low level output voltage V OL(V)
Ta = 25°C VCC = 5 V IF = 0 mA (20 mA)
