森海塞尔pcx550说明书
处于关机状态时，右耳罩与头梁是垂直的。
将右边耳罩旋转九十度，与头梁平行，就能打开耳机了。
打开后，白色LED指示灯会闪烁。
另外，最左边的是降噪开关（红圈），接着从左往右依次是音效切换按钮（蓝圈），LED指示灯（橙圈），USB接口（绿圈），2.5mm耳机线接口（黄圈）。
红圈这里是蓝牙开关，非常小。
默认是打开的，毕竟无线耳机，还是不用线最省事。
这个是语音麦克风，通话的时候，通过这个麦克风采集说话的声音。
两侧耳罩的上下部分，都分别开有一排整齐的小孔，这个就是降噪麦克风，通过它来采集外界的噪音。
说到这里，琛哥来简单科普一下主动降噪耳机的工作原理：原理其实很容易理解，看上面这张图就能明白：降噪耳机内部设置了专门的降噪电路。
通过音频接收器（大多是麦克风）和抗噪芯片来接收和分析外界噪音的频率，并产生与其相反的频率，从而相互减弱或抵消外界噪音。
