海马福美来M5作者：汪胤来源：《品位汽车风尚》2015年第05期福美来作为海马汽车旗下最重要的车型之_，在市场上销售了十几年，其最辉煌的时候，月销也曾过万，积累下了相当不错的口碑。
去年，海马汽车为了继续开发这一车系的潜力，推出了全新一代福美来，并命名为福美来M5，但由于只有一款1.6L发动机，动力方面的短板略显遗憾，那么作为压轴的的1.5T车型表现又如何呢？其实换装了涡轮增压发动机的福美来M5 1.5T版本在外观方面的变化并不大，只是在前脸设计不变的基础上，将原有的瀑布式镀铬进气格栅换为了黑色蜂窝状进气格栅，同时在尾部的标识上增加了1.5T的字样。
除此以外，新车还将轮毂换为了16寸双色旋风状五幅轮毂，虽说效果谈不上多运动，但也是在外观上形成了与1.6L自然吸气车型的明显区分。
因此在进行了微整容后，福美来M 5 1.5T依然保持了亲民的家庭风格，看上去踏实稳重，不浮夸。
补齐短板，1.5T完全超越期待。
作为这款车型的最大卖点，全新搭载的1.5T发动机无疑是最值得期待的部分。
从数据上看，福美来M5所装配的这台1.5T涡轮增压发动机虽然略逊于海马S5上的那台1.5T发动机，但最大功率也达到156ps，最大扭矩达到了220N·m，这样的表现在面对同排量的对手时，还是相当有底气的。
实际驾驶中，福美来M5的油门踏板调整的比较贼一些，不知道是否是因为想更多展现出这款发动机的爆发力而有意为之，不过由于峰值扭矩来临的比较晚一点，因此福美来M5的起步和提速过程比较线性。
为了保证更优秀的燃油经济性，6速手自一体变速器的升挡动作也相当积极，不到1800转便会进行换挡，车速在80km/h巡航时，发动机转速仅有1600转，油耗表现可想而知。
由于只是作为补充车型出现，福美来M5 1.5T的底盘与现款车型并没有区别，前麦弗逊后多连杆的结构在同级别车型里算是比较厚道，但既然定位为家轿，调校方面显然会更偏向于舒适性。
这套悬挂系统对路面的坑洼和起伏都能比较轻松的化解，避震也能够较好地吸收各种震动，但在响应速度上并不够理想，车体多余的晃动还是比较多，因此行驶质感上还是稍显廉价。
092海马汽车给我的印象一直都是适合家用的小型车，毕竟早在12年前的2012年，第一代海马福美来就已经进入市场拼杀。
因为海马汽车早期与日本马自达合作，每款车型都可以在马自达的阵营中找到相似的“兄弟”。
后来马自达转而与一汽合作，海马汽车就彻底变为一个只能依靠自身技术发展的自主品牌。
如今，海马已经成功地摆脱了马自达的影子，固化了自己的设计风格。
在参加这次试驾之前，我就已经得知了福美来M 5的设计与老款车型有着天渊之别。
虽然有这个心理准备，还是在第一次见到实车时惊讶万分。
大，是最先蹦出在我脑海里的感受。
福美来M 5的车身长度为4698mm ，比老款车型增加了141mm 。
我这么表达肯定有人觉得这141mm 并没有什么值得重视的地方，那我就再告诉你一个数据，作为B 级车标杆的BMW 3系轿车标准轴距版车型的车身长度是4624mm ，现在明白了吗？福美来M 5的车身长度已经赶超了B 级车，这不能不说是一次巨大的进步。
福美来M 5的外观变化还不仅仅局限在长度这一数据上，整体造型也向着欧系风格迈进。
上扬的腰线压缩了车窗的尺寸，这并没有让我觉得压抑反而觉得更加敦实了，因为我是忠实的欧系车拥趸。
车头的大灯组在翼子板上向后延伸，几乎占据了发动机舱一半的长度，种种细节之处的“基因突变”也没有让我觉得突兀，很合我的胃口。
改变固然是好的，外观的进化很成功，车内的设计当然也得有所改变。
中控台也向着驾驶席方向倾斜，更好地方便了驾驶时的操作。
让我觉得突兀的地方就是中控台上部分的选材，仿碳纤维材质的应用有些不合适。
因为福美来M 5并不是标榜运动的车型，采用中控台上银黑双色设计就已经足够时尚了，没必要再用碳纤维效果来装饰。
单独看双色座椅的确很不错，但加上中控台的三种材质搭配起来就显得有些凌乱，整体性不强。
4月份虽然刚刚步入春天不久，但南方早已进入了雨季，深圳也不例外。
连续一周的阴雨的确让空气又清新不少，可对于依赖阳光工作的我们却不住地挠头。
