华为ETS3125i用户手册

ETS3125i解锁指导书解锁指导1.关机后，拔出SIM卡：2.开机，进入待机界面：3.输入###1111#进入工程模式：4.进入工程模式的最后一个菜单，即解锁菜单：5.进入解锁菜单后，要求输入NCK码（华为按客户需要将NCK码提供给定制要货客户）：6.输入正确的NCK码后，点确认，即可进入。

7.选择机卡互锁中第三个选项：PINLOCK（选择reset重置）。

重置后机器自动关机，8.再插入默认PIN码(默认为1234)的SIM卡开机，就可以重新绑定.（如果用户旧卡需要使用PUK码，把sim卡pin码重置为1234）F317解锁指导书解锁指导9.关机后，拔出SIM卡：10.开机，进入待机界面：11.输入###1111# 再按下拨号键进入工程模式：12.进入工程模式的选择NCK：13.进入菜单后，要求输入NCK码（IMEI号对应的一组16位数字）：14.输入正确的NCK码后，点确认，即可进入。

15.选择机卡互锁中第三个选项：PINLOCK reset。

重置后机器自动关机，16.关机，再插入PIN码默认为1234的SIM卡重新开机即可。

（如果用户使用原SIM卡，需要将SIM卡的PIN码重置为1234）F316解锁指导书解锁指导17.关机后，拔出SIM卡：18.开机，进入待机界面：19.输入#*#433*#01#进入工程模式20.选择第4项：PINLock reset21.要求输入NCK码（IMEI号对应的一组16位数字）：22.输入正确的NCK码后，点确认，机器自动关机重启，机器解锁完毕。

23.关机，再插入PIN码默认为1234的SIM卡重新开机即可。

（如果用户使用原SIM卡，需要将SIM卡的PIN码重置为1234）。
