DIN3X3系列编码器差分信号转脉冲信号变送器主要特性:>>编码器差分信号直接输入转换成脉冲信号>>支持A、B和Z三相差分同时转换>>3路输入，3路输出，输出脉冲幅值可选>>不改变原波形频率，响应速度500KHz以上>>电源、信号输入、信号输出3000VDC三隔离>>供电电源：5V、12V、15V或24V直流单电源供电>>低成本、小体积，使用方便，可靠性高>>标准DIN35导轨式安装>>尺寸：120mm x70mm x43mm>>工业级温度范围:-45~+85℃应用：>>编码器差分信号隔离、采集及变换>>编码器差分信号转24V方波脉冲>>伺服编码器差分信号传输到PLC>>脉冲信号放大与整形>>地线干扰抑制>>电机转速监测系统>>速度测量与报警>>信号无失真变送和传输产品选型表：DIN3X3SAR–S□-P□–O□选型举例：例1：输入：编码器差分信号输入；电源：24V；输出：0-5V电平型号：DIN3X3SAR S5-P1-O1例2：输入：编码器差分信号输入；电源：12V；输出：0-24V电平型号：DIN3X3SAR S1-P2-O3例3：输入：0-5V电平；电源：24V；输出：0-24V电平型号：DIN3X3SAR S2-P1-O3例4：输入：0-5V电平；电源：12V；输出：集电极开路输出型号：DIN3X3SAR S2-P2-O4例5：输入：用户自定义；电源：24V；输出：用户自定义型号：DIN3X3SAR Su-P1-Ou通用参数参数名称测试条件最小典型值最大单位隔离电压1min15003000VDC信号输入幅值（V P-P）0.21060V 频率010500kHz 输入阻抗10kΩ输入电流5V输入0.45mA信号输出幅值（V P-P）O1:输出电平0-5V5V 频率010500kHz 电压（高电平）O1:输出电平0-5V5V 电压（低电平）00.05V 电流（高电平）25mA 电流（低电平）28mA 电压O4:集电极开路输出530V电流310mA 响应时间1500ns辅助电源电压用户自定义 3.31224VDC电流VD=12V150mA 辅助电源功耗2W 工作环境温度-4585℃贮存温度-4585℃引脚定义：引脚名称描述引脚名称描述1OUT1+信号输出1正端11GND1信号输入端地线2OUT1-信号输出1负端12GND1信号输入端地线3OUT2+信号输出2正端13NC空脚4OUT2-信号输出2负端14NC空脚5OUT3+信号输出3正端15IN3-信号输入3负端6OUT3-信号输出3负端16IN3+信号输入3正端7NC空脚17IN2-信号输入2负端8NC空脚18IN2+信号输入2正端9PW+电源正端19IN1-信号输入1负端10GND电源负端20IN1+信号输入1正端应用接线举例：例1：与三菱伺服编码器接线图外形尺寸：(单位：mm)可以安装在标准DIN35导轨上编码器Z 相脉冲接端子⑳(差动线驱动器)接端子⑲编码器A 相脉冲接端子⑱(差动线驱动器)接端子⑰编码器B 相脉冲接端子⑯(差动线驱动器)接端子⑮控制公共端注意事项:1、使用前根据装箱单，以及产品标签，仔细核对和确认产品数量、型号和规格。

机架式安防稳压电源使用说明书(10路输出)【型号】：PS-DC12V30DC2406AC2412-2U 【输入】：AC220V/50HZ 【输出】：AC24V/5A （共10组，DC12V30A 3组DC24V3组 AC24V4路独立输出） 【尺寸】：433mm*402 mm *88 mm 【净重】：16KG【电源型式】：19”标准机架式，2U ，前面板LED 电压指示 【电源功能】：每组独立状态指示灯,独立开关控制 【应用范围】：弱电系统中摄像机、高速球、探测器或红外灯等设备的电源供应，及其他探测设备 【装箱清单】：1、 2U 机架式电源1台2、 合格证1个3、 使用说明书1份4、 AC220V 电源输入线1条5、 备用保险管若干只 【面板示意图】：Front Panel( 前面板）Rear Panel （后面板）AC 220V Input Fuse按钮数字电压表CECT C T C T C T C T C T C T C T C T C T C TSwitch【输出电压调节】：DC 输出在机箱内电路板有标着VR 的正方形可调电位器，可用十字螺丝刀轻轻调节，顺时针旋转电压增高，逆时针旋转电压降低，可根据需要调节。

AC 输出出厂可根据现场，远近需要定做AC26V 或者其他规格 【产品特点】：R 型变压器可以用作所有电器的电源变压器或隔离变压器。

则于它具有效率高、体积小、体形薄、重量轻、磁漏少、发热低、生产标准化等特点，安全性能符 合世界各国安规，产品得到广泛应用。

特别是励磁电流小，空载损耗低，噪音极小，输出功率大等特点。

在摄像机、音响、精密设备或(在待命状态下需要长期通电的)电源转换器中使用有更突出的表现。

【保险规格】AC220V 输入15A输出每路独立保险(可根据需要换装保险规格，但总功率不得超出) ★特别提示：接入市电时，请特别注意人身安全注意接线端子的正确接法，防止接反不要超负荷使用本产品如遇故障，不要自行拆卸，请及时联系供应商。

Instruction of Solar Charge ControllerUser’s Manual12V/24V30ADear Users:Thank you for selecting our product.Please read this manual carefully before you use this product.The controller is for off-grid solar system and control thecharging and discharging of the battery.Main function is protecting battery.The intelligent charging process has been optimized for long battery life and improved system performance.Major FunctionsThe features are listed below:⏹Automatic Identification System Voltage,12V/24V autorecognition.⏹Humanized LCD displaying and double button operation ofman-machine interface.⏹Completed technical data for setup and modify.⏹High efficiency intelligent PWM3stage charging⏹The load control mode can be selected,the timer function canbe reset for street light at night.⏹Discharge capacity control⏹RS485communication interface(optional)⏹Discharge Counter of Ampere Hour⏹Working Storage Function:record the total run time of system,record timers of error during running time,record times of full charged battery.⏹Reliable over voltage protection,short circuit protection,overload protection,overcharge protection,over-discharge protection.⏹Accurate temperature compensation,correcting the chargingand discharging voltage automatically,improving the battery lifetime.⏹Roundly reverse connected protection.⏹Solar Panels,Battery,Solar Charge Controller positive polesare all connected together,adopting negative MOSFET in series control circuit.Important Safety Information⏹It is better to install the controller in the room.If installed thecontroller outside,please keep the environment dry,avoid direct sunlight.⏹The controller will be hot in process of working,please keep theenvironment ventilation,away from flammable.⏹The open circuit voltage of solar panel is too high,(especially24V and48Vsystem),please take care.⏹The battery has acidic electrolysis,please put on gogglesduring installation.If you accidentally exposed to the electrolysis,please rinse with water.⏹Please avoid reverse connection or short circuit connectionunder48V system,or the product easy to destroy.⏹The battery has huge power,prohibit any conductor shortcircuit the positive and negative pole of battery.Suggest to adding a fuse between battery and controller.(Slow motiontype,the action current of the fuse should be1.5times rated current of controller.)The suggestion of using⏹The controller could detect the temperature of environment toadjust the voltage of charging,so that the controller should be closed to battery as near as possible.⏹Recommend system current density of cables less than3A/mm2.⏹Try to use multi strand copper wire in order to connecting withthe terminal firmly.Loose power connection and/or corroded wires may result in resistive connections that melt wire insulation,burn surrounding materials or even cause fire.⏹The battery should be full charged each month.Or the batterywill be destroyed.The feature of LCD graphic symbol1.The default night display of controller:When the solar panelinput voltage have been detected by controller less than sensor identification point voltage,this graphic symbol will be light.2.The default daytime display of controller:When the solar panelinput voltage have been detected by controller more than sensor identification point voltage,this graphic symbol will be light.3.The indicator of PV array parameter:When the solar panelsdata was displaying,this graphic symbol will be light.For example the voltage of solar panel.4.The indicator of battery parameter:When the battery parameterwas displaying,this graphic symbol will be light.For example the voltage of battery,temperature of battery.5.The indicator of load parameter:When the load parameter wasdisplaying,this graphic symbol will be light.6.System Voltage:When the LCD shows different system voltage,the controller will adjust the technical data automatically.7.Numerical Display Area8.Timer Setting Function9.Switch Graphic Symbol.10.Unit Symbol Value11.Warning:When there is fault,this graphic symbol will be light.12.The indicator of Load status:Load on，Load off.13.The indicator of Output power:When the load terminal haveoutput,this graphic symbol will be light.14.The indicator of capacity of battery:When the battery was indifferent capacity,the strip-type will show.15.The indicator of charge status:When the controller is charging,the symbol will be light,float charge will be flash,no charging no display.Installation InstructionsController Fixed1)The controller should be installed well-ventilated place,avoiddirect sunlight,high temperature and do not install in location where water can enter the controller.2)Please select correct screw to fix the controller on the wall orother platform.Screw M4or M5,Screw cap diameter less than 10mm.3)Please reserve enough space between the wall and controller,to allow for cooling and cable connection.4)The mounting holes distance is180mm*70mm,diameter of thehole is5mm.Controller Connection1)All terminals are in tight status after factory,in order towell connected,please loose all terminals at first.2)The following order of connection please do not free change,orcause system voltage recognition fault.3)As figure,first connected the battery to controller correct poles.In order to avoid short circuit,please screw the cable of battery to the controller in advance,then connected to battery poles secondly.If your connection is correct,the LCD displaying will show battery voltage and other technical data.If LCD no indicate,please check the fault.The length of cable between battery and controller as shorter as possible.Suggest to30CM -100CM.●If short circuit happened on the terminals ofcontroller,it will be result in fire or explode.Pleasebe careful.(We strongly suggest to connecting afuse at the battery side1.5time of rated current of controller.)●If the battery reverse connection,the output of controller alsosame with battery polarity,please do not connect any load with controller at that time,or the load and controller will be destroyed.4)As figure,connected solar panels with controller correctly,if theconnection is successful and sunshine is full,the LCD will show solar panel and an arrow from solar panel tobattery will be light.The voltage of solar panel is very high under sunshine,high voltage can cause injury or destroy controller.As figure,connected loads with controller correctly.Under48Vsystem,the reverse connection of solar panel will be destroy the solar charge controller.In order to avoiding injury from load voltage,please close to the output of controller with buttonat first,then connected the load on the controller.The controller do not offer reverse connection protection for load,so please take care,reverse connection for load will be destroy bulb.⏹About ground connection of solar systemPlease noted,this solar charge controller designed by all positive connection,all components inside the controller are positive combined together.If your solar system needs ground connection, please let positive ground connection.Warning:For some force to ground connectedsystem,such as solar communication system,portable solar system,they are negative groundconnected,at this time please do not positive connected,or can cause short circuit.Operation and Indication⏹Main interface●The controller will have1s initialization interface after electrified,then go into main interface.●If no operation at main interface inner20s,the main interfacewill be auto exchange during voltage of battery,voltage of solar panel,load current,charge current,temperature of environment eachinterface keep3s.Long press“”more than5s at main interface,it will speed auto exchange.Loose button will stop speed.●Press“”under main interface could open or close the loadoutput。
