氨气报警说明

进入菜单密码2967
Event Menu 事件菜单
Action Menu 活动菜单Actions are comprised of two parameters: 活动菜单包含两个项目
Indicates which component is responsible for the action to be taken 显示哪个组件负责应采取的措施Tx (transmitter) 变送器Re (Relay/Ann unciator) 继电器Ctrl (Controller) 控制器Relay Indicates which of thre e possible outputs will be activated when the event is tr ue; 继电器显示哪个三个可能的输出将被激活当事件是真实的; #XX (activates the c omponent’s #xx relay), 激活XX号继电器Buzzer (activates the compon ent’s audible alarm) 激活蜂鸣器ALL (activates the relays and audible alarms) 激活全部继电器和蜂鸣器
Delays Menu 继电器菜单
This option allows Before and After settings that will delay the activati on or deactiva tion of an action to be programmed. 这个选项允许之前和之后的设置,将延迟激活或失活的行动被编程。

Before Delays the action for the specified length of time. If the conditi on persists bey ond this delay, the defined action is executed. Before表示达到浓度后多久开始报警
After The time to wait after an event has returned to normal before ret urning action output to normal state. The after delay also offers a Latch option, described below. A fter表示浓度低于报警值后多久消除报警
Latch Mode 表示报警后不自动消除，只能手动消除
Conditions 条件
all: includes all transmitters in the group 所有仪表全部达到报警值me
an: includes the average concentration for the group’s transmitters 所有仪表的平均读数达到报警值max: includes the group’s maximum conc entration 所有仪表中最高读数达到报警值min: includes the group’s m inimum concentration 所有仪表中最低读数达到报警值1/4: includes at least a quarter of the group’s transmitters that meets set conditions 仪表总数的1/4达到报警值(例如：总共16台，4台达到报警值即启动事件) 1/3: includes at least a third of the group’s transmitters that meets set conditions 仪表总数的1/3达到报警值1/2: includes at least half of the group’s transmitters that meets set conditions 仪表总数的一半达到报警值2/3: includes at least two thirds of the group’s transmitters that m eets set conditions 仪表总数的2/3达到报警值3/4: includes at least thre e quarters of the group’s transmitters that meets set conditi ons仪表总
数的3/4达到报警值1 or +: at least one or more than one of the grou p’s transmitters that meets set condit ions 一台或以上仪表达到报警值
--- No operator 无设置= Equal to 等于<= Equal to or smaller than
小于等于< Smaller than 小于>= Equal to or larger than 大于等于> Larger than 大于!= Not equal to 不等于Max When the maximum val ue is reached, an action is triggered. It will not be deacti vated until le vels fall below minimum value 超过最大值Min When concentrations f all below minimum value, an action is triggered. It will n ot be deactiv ated until concentrations rise above set maximum value 低于最小值
GrAll: Includes all transmitters (see note) 包含所有变送器Gr_ _ _: In cludes only the devices in the specified group (see note) 包含特定组的设备Tx000: Includes only the specified transmitter (connected to the c ontroller) 针对特定地址的设备Clock: Includes only information gathe red between the specified times. Selecting cloc k sets a condition that i s applied only between the start and end time frame. It is poss ible to s et one condition screen to specific parameters and the second to clock, which means that the specified condition will trigger an event only if it occurs during the se t time period. 根据时间Fault: Bases trigger on maintenance alarm, communication failure or device failure 故障启动Alrm A: If the chosen device or group has an Alarm A or Alarm 1, an event will be tri ggered. 一级报警启动Alrm B: If the chosen device
or group has an Alarm B or Alarm 2, an event will be tri ggered 二级报警启动Alrm C: If the chosen device or group has an Alarm C, an e vent will be triggered. 三级报警启动
Status 状态Enable 启动，Disable 关闭，Erase 删除（慎用）。
