Vol.54 N o.4 Apr. 2021凝固冷却速率对2507超级双相不锈钢微观组织的演变及耐蚀性能的影响沈楚，邹德宁，赵洁，陈阳(西安建筑科技大学冶金工程学院，陕西西安710055)[摘要]为探究凝固冷却速率对2507超级双相不锈钢微观组织与耐蚀性能的影响，采用光学显微镜（0M)和 扫描电子显微镜（S E M)研究了不同凝固冷却速率2507超级双相不锈钢的微观组织演变规律，并结合Image-P r o图像分析软件与铁素体分析仪，确定了各不同凝固冷速试样组织中的各相含量，得到了凝固冷却速率对c t相析出的 影响规律及(T相的析出机理。
再采用动电位极化法与交流阻抗谱法研究了各不同凝固冷却速率2507超级双相不 锈钢的耐蚀性能。
结果表明：试样组织中的（T析出相含量随着凝固冷却速率的降低而增加，试样的耐蚀性能随着 凝固冷却速度的降低而减弱。
[关键词]2507超级双相不锈钢；凝固冷却速率；<7析出相；微观组织；耐蚀性能[中图分类号]T G506.7+1 [文献标识码]A[文章编号]100卜1560(2021)04-0074-06Effect of Solidification Cooling Rate on the Microstructure Evolution andCorrosion Resistance of 2507 Super Duplex Stainless SteelS H F.N C h u,Z O U De-ning, Z H A O Jie, C H E N Y a n g(School of Metallurgy and Engineering, X i*a n University of Architecture and Technology, X i'a n 710055, China)Abstract：For exploring the influence of solidification cooling rate on the microstructure evolution and corrosion resistance of 2507 super duplex stainless steel, the law of the microstructure evolution of 2507super duplex stainless steel with different solidification cooling rates was investigated by optical microscope (O M)and scanning electron microscope (S E M). T h e contents of each phase in the samples with different solidification cooling rates were determined by Image-Pro image analysis software and ferrite analyzer, and the effect of solidification rate on the precipitation of a phase and the precipitation m e c h a n i s m of a phase were obtained. Furthermore, the corrosion resistance properties of 2507 super duplex stainless steel with different solidification and cooling rates were investigated by potentiodynamic polarization and electrochemical impedance spectroscopy. Results showed that the content of a phase in the samples structure increased with the decrease of solidification cooling rate, and the corrosion resistance of the samples weakened with the decrease of solidification ccxjling rate.Key words：2507 super duplex stainless steel；solidification cooling rate；a p h ase；microstructure；corrosion resistance〇前言2507超级双相不锈钢是超低碳并具有较高合金含 量的一种高性能不锈钢，它兼具有铁素体不锈钢和奥 氏体不锈钢的优点，而其中最为突出的是它具有比普 通双相不锈钢更优异的耐腐蚀性能。
第43卷第1期50 2021 年 1 月上海金属SHANGHAI METALS Vol. 43 , No. 1January , 2020热轧后冷却速度和卷取温度对汽车用低合金高强钢板中析出物的影响王畅"2于洋"2王林"2张亮亮李振2陈瑾2(•首钢技术研究院，匕京100043； 2.绿色可循环应铁流程北京市重点实验室，北京100043；3.首首股份公司迁安钢铁公司，河北迁安064404)【摘要】采用Gleeble-3500热模拟试验机研究了层流冷却速度和卷取温度对汽车用低合 金高强钢板热轧过程中析出行为的影响。
结果表明：热轧过程中钢中析出物主要为多边形Nb (C,N)和细小NbC ；随着热轧后层冷速度的增大，析出物尺寸减小、长大速度减慢，其密度从 200个/p m 2减少到了 50个/p m 2。
试样热轧后层冷至400 C 的卷取过程中，由于析出驱动力不足，析出物的数量骤减，其密度从250个/ p m 2减小到了 25个/ p m 2。
控制热轧过程中析出物的 尺寸和数量并尽量减少含Nb 析出物的数量，有利于连续退火后得到细小均匀的组织，产生细晶强化和析出强化的双重强化效果。
【关键词】 低合金高强钢 第二相 析出 铌 层冷速度 卷取温度Effect of Cooling Rate and Coiling Temperature after Hot- rolling onPrecipitates in Low- alloy High- strength Steel for AutomobileWANG Chang 1'2 YU Yang 1'2 WANG Lin 1'2 ZHANG Liangliang 1，LI Zhen 2 CHEN Jin 2(1. Shougang Research Institute of Technology , Beijing 100043 , China ; 2. Beijing Key Laboratory ofGreen Recyclable Process for Iron and Steel Production Technology , Beijing 100043 , China ;作者简介:王畅，女，硕士，高级工程师，主要从事热轧及冷轧产品表面质量控制工作,E-mail ： ustb 0321033@3. Qian'an Iron and Steel Company of Shougang Co. , Ltd. , Qian'an Hebei 064404, China )【Abstract 】 Effect of laminar cooling rates and coiling temperatures after hot-rolling on precipitating behavior of low-alloy high-strength steel plate for automobile was investigated by aGleeble- 3500 thermal simulation test machine. The results showed that phases precipitated during hot-rolling were predominantly polygonal Nb (C,N ) and fine NbC , and as the laminar cooling rateafter hot- rolling increased , the precipitates became finer and grew more slowly , with their number density decreasing from 200 per p m 2 to 50 per p m 2. The precipitates in the sample undergoing hot-rolling and laminar cooling to 400 C followed by coiling decreased drastically in amount ，with their number density decreasing from 250 per p m 2 to 25 per p m 2, because of insufficient precipitation driving force. The control of both amount and size of the phases precipitated during hot- rolling and minimizing the amount of niobium- containing precipitates will help to obtain fine and uniform structureand to develop double strengthening effects of fine-grained strengthening and precipitationstrengthening after continuous annealing .【Key Words ] low-alloy high-strength steel , second phase , precipitation , niobium , laminar cooling rate ，coiling temperature第1期王畅等:热轧后冷却速度和卷取温度对汽车用低合金高强钢板中析出物的影响51为了满足减重节能的需要,汽车零部件越来越多地采用高强度钢板制造。
