NETAPP FAS系列安装配置手册赞融电子上海分公司2003年11月修订控制1简介1.1说明本文简要说明了Network Appliance公司FAS系列存储产品配置过程。
本手册基于DataOntap 6.4.2P6操作系统1.2适用对象和前提本文是针对赞融电子的内部人员。
要求阅读者具有以下方面的专业能力:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP™ System Administrator’s GuideData ONTAP™ Software Setup Guide1.4术语表NFS：Network File System 网络文件系统CIFS：Common Internet File System 通用 Internet文件系统NAS：Network Attached Storage 网络附加存储WAFL：Write Anywhere File Layout 随地写入文件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使用计算机串口连接Filer背板上的Console口使用Windows附件中的超级终端建立连接，参数如下：每秒位数 9600，数据位 8，奇偶校验无，停止位 1，数据流控制无建立连接依次打开Disk Shelf和Filer电源使用setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173 Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: EnterPlease enter the IP address for Network Interface vif2 []: 165.204.224.174 Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]:Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]:Please enter the IP address for Network Interface e0 []: 165.204.224.172 Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]: Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 T he administration host is given root access to the filer's/etc files for system administration. To allow /etc root accesst o all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBK Setting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterT his system will send event messages and weekly reportst o Network Appliance Technical Support. To disable this feature,e nter "options autosupport.support.enable off" within 24 hours.E nabling Autosupport can significantly speed problem determinationa nd resolution should a problem occur on your system.F or further information on Autosupport, please see:.h ttp:///autosupport/P ress the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进行 cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCY our filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225 Please enter next WINS IP address (or return to end list) []: 163.181.3.225 Please enter next WINS IP address (or return to end list) []:C IFS requires local /etc/passwd and /etc/group files for multiprotocol.D efault passwd file will be created containing 'root', 'pcuser',a nd 'nobody'.Enter the password for root []:Retype the password:T his filer is currently licensed for CIFS only.T he filer will be configured as a NTFS_only filer. It canb e changed to a Multiprotocol filer by reissuing the CIFS setup command.T he default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterC IFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1T he filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:I t is highly recommended that you create the local administratora ccount (FAS940\administrator) for this filer. This account enablesa ccess to the filer from Windows when domain controllers are nota ccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User <administrator> addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfsA is a Windows 2000(tm) domain.I n order to create this filer's domain account, you must supply then ame and password of an administrator account with sufficient privileget o add the filer to the domain.Please enter the Windows 2000 user [Administrator@]: admin_mweizhi@Password for admin_mweizhi@:CIFS - Logged in as admin_mweizhi@.B y default, setup creates the filer account in the ActiveD irectory container named 'Computers'. Alternatively, you cani nstall the filer in an organizational unit (OU) by specifyingt he domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 established Mon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD () Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串口，用命令行方式创建卷vol create <volume name, such as ‘/vol/vol1’> [ -r <RAID Size> ] [ disks]例，创建名为vol1的卷，RAID组最大为8，包含2块盘vol create /vol/vol1 –r 8 2使用vol status –r 命令观察初始化进程通过Web界面创建卷在浏览器中输入http://IP_Address/na_admin点击FilerView，根据提示输入用户名密码从右侧窗口Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的大小8在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令行cifs shares -add <share name> <path>e.g. cifs shares add vol1 /vol/vol1通过Web界面设置Filerview CIFS Shares AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令行exportfs -o anon=0 /vol/vol1或者通过Web界面配置Filerview NFS Manage Exports Insert Line 在Path中输入/vol/vol1Permission选择rwAnonymous UID填写0点击OK3FilerView 使用介绍3.1Filer菜单3.1.1Show Status 显示Filer的整体状态，包括Filername, Model,System ID,Version, Disks, Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常用的CIFS, NFS,FCP, iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore 等，详情可参见/products/filer/或/products/filer/（中文网页）3.1.3Report 显示Filer目前配置及使用情况，如 Uptime, Network Interfaces, Disk Usage, System Configuration 等信息3.1.4Syslog Messages 这里是系统的syslog messages 信息，里面会记录系统运行时产生的一些信息，特别是一些系统的报错信息，这些信息非常重要，对于发现各种问题有很大帮助，Netapp Technical Support 也需要这些信息，最好每天都查看一下这里的信息3.1.5Use Command Line 在这里可以使用FilerView自带的telnet工具，方便你管理时使用Data Ontap系统的命令。
NETAPP FAS系列安装配置手册赞融电子上海分公司2003年11月修订控制1简介1.1说明本文简要说明了Network Appliance公司FAS系列存储产品配置过程。
本手册基于DataOntap 6.4.2P6操作系统1.2适用对象和前提本文是针对赞融电子的内部人员。
要求阅读者具有以下方面的专业能力:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP™ System Administrator’s GuideData ONTAP™ Software Setup Guide1.4术语表NFS：Network 网络文件系统CIFS：Common Internet 通用Internet文件系统NAS：Network Attached Storage 网络附加存储WAFL：Write Anywhere 随地写入文件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使用计算机串口连接Filer背板上的Console口使用Windows附件中的超级终端建立连接，参数如下：每秒位数 9600，数据位 8，奇偶校验无，停止位 1，数据流控制无建立连接依次打开Disk Shelf和Filer电源使用setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Enter Please enter the IP address for Network Interface vif2 []: 165.204.224.174Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface e0 []: 165.204.224.172Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]:Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 The administration host is given root access to the filer's/etc files for system administration. To allow /etc root accessto all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBKSetting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterThis system will send event messages and weekly reportsto Network Appliance Technical Support. To disable this feature,enter "options autosupport.support.enable off" within 24 hours.Enabling Autosupport can significantly speed problem determinationand resolution should a problem occur on your system.For further information on Autosupport, please see:.Press the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进行cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCYour filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225Please enter next WINS IP address (or return to end list) []: 163.181.3.225Please enter next WINS IP address (or return to end list) []:CIFS requires local /etc/passwd and /etc/group files for multiprotocol.Default passwd be created containing 'root', 'pcuser',and 'nobody'.Enter the password for root []:Retype the password:This filer is currently licensed for CIFS only.The filer will be configured as a NTFS_only filer. It canbe changed to a Multiprotocol filer by reissuing the CIFS setup command.The default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterCIFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1The filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:It is highly recommended that you create the local administratoraccount (FAS940\administrator) for this filer. This account enablesaccess to the filer from Windows when domain controllers are notaccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User <administrator> addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfs is a Windows 2000(tm) domain.In order to create this filer's domain account, you must supply thename and password of an administrator account with sufficient privilegeto add the filer to the domain.Please enter the Windows 2000 user []:Password for :CIFS - Logged in as .By default, setup creates the filer account in the ActiveDirectory container named 'Computers'. Alternatively, you caninstall the filer in an organizational unit (OU) by specifyingthe domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 establishedMon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD () Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串口，用命令行方式创建卷vol create <volume name, such as ‘/vol/vol1’> [ -r <RAID Size> ] [ disks] 例，创建名为vol1的卷，RAID组最大为8，包含2块盘vol create /vol/vol1 –r 8 2使用vol status –r 命令观察初始化进程通过Web界面创建卷在浏览器中输入点击，根据提示输入用户名密码从右侧窗口Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的大小8 在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令行cifs shares -add <share name> <path> e.g. cifs shares add vol1 /vol/vol1通过Web界面设置→CIFS→Shares→AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令行exportfs -o anon=0 /vol/vol1或者通过Web界面配置→NFS→Manage Exports→Insert Line 在Path中输入/vol/vol1Permission选择rwAnonymous UID填写0点击OK3使用介绍3.1Filer菜单3.1.1Show Status 显示Filer的整体状态，包括, Model, System ID,Version, Disks,Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常用的CIFS, NFS, FCP,iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore等，详情可参见或（中文网页）3.1.3Report 显示Filer目前配置及使用情况，如Uptime, Network Interfaces, DiskUsage, System Configuration 等信息3.1.4Syslog Messages 这里是系统的syslog messages 信息，里面会记录系统运行时产生的一些信息，特别是一些系统的报错信息，这些信息非常重要，对于发现各种问题有很大帮助，Netapp Technical Support 也需要这些信息，最好每天都查看一下这里的信息3.1.5Use Command Line 在这里可以使用自带的telnet 工具，方便你管理时使用Data Ontap系统的命令。
NetApp存储介绍美国网域存储技术有限公司北京代表处2005年8月24日NetApp 存储产品自从2001年美国911事件之后，逐渐受到越来越多的客户追捧，其原因何在呢？本文将对NetApp公司作一个全面的介绍，并对NetApp的产品以及其“简便、高效、可靠”三大显著特点作一个全面详细的介绍。
一、公司介绍美国网域存储技术有限公司的英文全称是Network Appliance，简称为NetApp。
其成立于1992年，是一家美国加州硅谷地区的高科技专业存储公司。
成立之初，其取名就前瞻性地预示了存储的发展趋势：以网络化（Network）为核心，以专具化（Appliance）为理念。
根据Gartner的调查研究，我们知道数据的管理成本远高于相应的存储购买成本。
NetApp的宗旨就是提供革新的存储解决方案以降低企业数据管理的成本和复杂性。
为此，NetApp公司在成立初始，便积极推动存储技术的革新和发展，比如NDMP协议、CIFS协议目前已分别成为磁带备份和NAS必须支持的技术。
该公司的许多存储技术一直被许多存储厂商学习跟进，不过部分技术目前还是保持着领先的优势，比如能够防范任意两块磁盘任意时间点故障的RAID-DP技术，目前还是许多厂商未能掌握的技术。
NetApp公司的产品特点可以简单的总结为“简便、高效、可靠”。
因此，公司的财务状况一直健康地发展。
从上市以后开始，每季度都以70%的速度进行增长，直至2000年互联网泡沫破灭带动全球经济下滑，才出现了唯一的下挫。
但是正所谓“塞翁失马，焉知非福”。
互联网泡沫的破灭和全球经济下滑，及紧接着的“911”事件使得人们有了两点重要的认识：1、数据一定要有保护；2、一分钱要掰成两半花。
因此，采用NetApp存储解决方案的价值优势得以充分体现，从而使得NetApp公司的业绩迅速地重新回到了高速上升的通道。
许多客户充分认识到了NetApp公司“简便、高效、可靠”以及最优整体拥有成本（TCO）的特点，在近四年里迅速成为NetApp的巨型客户，比如Oracle公司，从原来只有少量的NetApp产品变成目前光Austin 数据中心就拥有2.5PB（2500TB）的客户；摩根斯坦利（Mogan Stanley）也由原来并非NetApp的客户迅速成为NetApp的PB级俱乐部成员之一。
NetApp FAS系列基本操作配置目录App存储系统 (3)2.系统基本操作维护指南 (5)2.1. 存储初始化配置 (5)2.2. 进入管理界面 (7)2.3. 系统基本信息 (8)2.4. 系统LOG信息 (9)2.5. 配置Autosupport (10)2.6. 设置时区、时间和日期 (10)2.7. 杂项设置 (11)2.8. 停机及重新启动 (12)2.9. 管理创建AGGR及卷 (13)2.10. 管理及创建Qtree (15)2.11. 磁盘配额 (16)2.12. SnapShot的配置和管理 (18)2.13. CIFS的相关信息 (20)2.14. CIFS共享 (23)2.15. ISCSI配置 (25)2.16. FC SAN配置 (29)2.17. 网络端口的管理 (32)2.18. 其他网络参数 (33)2.19. 更改root用户密码 (35)2.20. 系统实时状态监控 (35)附录一：磁盘更换步骤 (37)附录二：时间同步服务器的设置 (38)App存储系统NetApp 系统为各种不同平台上的用户提供了对全部企业数据的无缝访问。
NetApp全系列光纤网络存储系统在文件访问方面支持NFS 和CIFS，在块存储访问方面支持FCP 和iSCSI，确保您可以非常方便地将NetApp 存储系统集成到NAS 或SAN 环境中，并且保护原来的信息。
NetApp 的设计为专用访问环境中的应用程序服务器和服务器集群以及多用户环境中的用户提供了经过优化和整合的高性能数据访问方式。
NetApp 存储系统提供了经过实践考验的、超过99.998% 的数据可用性，减少了代价高昂的停机时间（无论是计划内的还是计划外的），最大限度地保障了对关键数据的访问。
它们在一个简单、易用的环境中实现了数据的可管理性、可扩展性、互操作性和可用性，从而降低了您的总拥有成本，加强了竞争优势。
NetApp系列产品具备真正的“统一引擎”功能，使您可以同时支持文件级和块级数据访问—而以前需要有多个系统才能完成这些过程。
NetApp-FAS系列安装配置说明NETAPP FAS系列安装配置⼿册赞融电⼦上海分公司2003年11⽉修订控制1简介1.1说明本⽂简要说明了Network Appliance公司FAS系列存储产品配置过程。
本⼿册基于DataOntap 6.4.2P6操作系统1.2适⽤对象和前提本⽂是针对赞融电⼦的内部⼈员。
要求阅读者具有以下⽅⾯的专业能⼒:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP? System Administrator’s GuideData ONTAP? Software Setup Guide1.4术语表NFS：Network ⽹络⽂件系统CIFS：Common Internet 通⽤Internet⽂件系统NAS：Network Attached Storage ⽹络附加存储WAFL：Write Anywhere 随地写⼊⽂件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使⽤计算机串⼝连接Filer背板上的Console⼝使⽤Windows附件中的超级终端建⽴连接，参数如下：每秒位数 9600，数据位 8，奇偶校验⽆，停⽌位 1，数据流控制⽆建⽴连接依次打开Disk Shelf和Filer电源使⽤setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Enter Please enter the IP address for Network Interface vif2 []: 165.204.224.174Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface e0 []: 165.204.224.172Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]:Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 The administration host is given root access to the filer's/etc files for system administration. To allow /etc root accessto all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBKSetting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0 Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: /doc/13ed3844f58a6529647d27284b73f242336c3134.html You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterThis system will send event messages and weekly reportsto Network Appliance Technical Support. To disable this feature,enter "options autosupport.support.enable off" within 24 hours.Enabling Autosupport can significantly speed problem determinationand resolution should a problem occur on your system.For further information on Autosupport, please see:.Press the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进⾏cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCYour filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225Please enter next WINS IP address (or return to end list) []: 163.181.3.225Please enter next WINS IP address (or return to end list) []:CIFS requires local /etc/passwd and /etc/group files for multiprotocol.Default passwd be created containing 'root', 'pcuser',and 'nobody'.Enter the password for root []:Retype the password:This filer is currently licensed for CIFS only.The filer will be configured as a NTFS_only filer. It canbe changed to a Multiprotocol filer by reissuing the CIFS setup command.The default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterCIFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1The filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:/doc/13ed3844f58a6529647d27284b73f242336c3134.html It is highly recommended that you create the local administratoraccount (FAS940\administrator) for this filer. This account enablesaccess to the filer from Windows when domain controllers are notaccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfs/doc/13ed3844f58a6529647d27284b73f242336c3134.html is a Windows 2000(tm) domain.In order to create this filer's domain account, you must supply thename and password of an administrator account with sufficient privilegeto add the filer to the /doc/13ed3844f58a6529647d27284b73f242336c3134.html domain.Please enter the Windows 2000 user []:Password for :CIFS - Logged in as .By default, setup creates the filer account in the ActiveDirectory container named 'Computers'. Alternatively, you caninstall the filer in an organizational unit (OU) by specifyingthe domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 establishedMon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD (/doc/13ed3844f58a6529647d27284b73f242336c3134.html ) Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串⼝，⽤命令⾏⽅式创建卷vol create [ -r ] [ disks] 例，创建名为vol1的卷，RAID组最⼤为8，包含2块盘vol create /vol/vol1 –r 8 2使⽤vol status –r 命令观察初始化进程通过Web界⾯创建卷在浏览器中输⼊点击，根据提⽰输⼊⽤户名密码从右侧窗⼝Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的⼤⼩8 在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令⾏cifs shares -add e.g. cifs shares add vol1 /vol/vol1通过Web界⾯设置→CIFS→Shares→AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令⾏exportfs -o anon=0 /vol/vol1或者通过Web界⾯配置→NFS→Manage Exports→Insert Line 在Path中输⼊/vol/vol1 Permission选择rwAnonymous UID填写0点击OK3使⽤介绍3.1Filer菜单3.1.1Show Status 显⽰Filer的整体状态，包括, Model, System ID,Version, Disks, Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常⽤的CIFS, NFS, FCP,iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore等，详情可参见或（中⽂⽹页）3.1.3Report 显⽰Filer⽬前配置及使⽤情况，如Uptime, Network Interfaces, DiskUsage, System Configuration 等信息3.1.4Syslog Messages 这⾥是系统的syslog messages 信息，⾥⾯会记录系统运⾏时产⽣的⼀些信息，特别是⼀些系统的报错信息，这些信息⾮常重要，对于发现各种问题有很⼤帮助，Netapp Technical Support 也需要这些信息，最好每天都查看⼀下这⾥的信息3.1.5Use Command Line 在这⾥可以使⽤⾃带的telnet ⼯具，⽅便你管理时使⽤Data Ontap系统的命令。
Dat sheetNetApp FAS2200 SeriesMake the smart decision about how you manage your resources, time, and money.Start RightMore powerful systems start under $8,000.Keep It SimpleMake the most of limited resources.Grow SmartHave the flexibility to adapt to the growing needs of your business.The ChallengeExplosive data growthWhether you are responsible for agrowing midsize business or a remoteor branch office of a larger organization,you are challenged more than ever byshrinking budgets, overextended staff,and the need to do more with less. Thesechallenges, coupled with the increasingcomplexity of your Windows®, VMware®,or server virtualization environment, canquickly eat into your budget and affectthe productivity of your organization.The SolutionStart rightAre you managing server andapplication sprawl on a shoestringbudget? The NetApp FAS2200 seriesis not only affordable, but providesa more powerful platform than othersystems in its class:• “No compromise” unified storagesystems starting at under $8,000• SSD support across all FAS2200series systems• New Flash Pool technology extendsVirtual Storage Tiering to FAS2200systems: accelerate application per-formance and lower storage costs• Industry-leading efficiency featuresbuilt in at no additional cost• Use 50% less storage in virtual serverenvironments—guaranteed*Keep it simpleFree up your time, money, and people.You don’t need to be a storage expertto deploy and manage NetApp storagesystems. The NetApp FAS2200 seriesoffers a powerful range of technologiesto help increase the efficiency of yourstorage administrators:• Rapidly deploy in just minutes.• Manage via your Microsoft®Management Console, minimizingtraining costs.• Simple, automatic data movementbetween SSD and SATA disk throughFlash Pools.• Tight integration with key businessapplications enables administratorsto manage 2 to 3 times more storage.• Slash administrative overhead by upto 60% by leveraging one commonskill set for all NetApp products.• Easily tune and troubleshootvirtual server environments withOnCommand Balance.NetApp OnCommandSystem ManagerOnCommand System Manager is asimple but powerful browser-basedmanagement tool that enables admin-istrators to easily set up and manageindividual NetApp FAS2200 systems:* /guarantee• Intuitive wizard and workflow-driven interface automate common storage tasks.• Flash Pool support —view, create, and manage Flash Pool environments. • Use a single interface for SAN and NAS environments.• Use System Manager across all NetApp storage systems—unlike competitive products that manage only one class of storage.Grow smartProtect your storage investment with systems that grow with your business needs:• Get a truly unified storage architecture. • Expand capacity and add functionality quickly and easily.• Seamlessly upgrade to other NetApp systems while using the same oper-ating system and software tools.• Get built-in investment protection with the ability to convert your FAS2240 system to an external disk shelf for upgrading to larger NetApp systems. Data ONTAP Software Simplified softwareNetApp FAS2200 systems use the Data ONTAP ® storage operating system, plus a common set of powerful, easy-to-usedata management and data protection software products. The scalable, unified software of NetApp systems provides a common software environment for both NAS and SAN, from entry-level systems through the largest data center systems.With NetApp software on the FAS2200 you can:• Enable each administrator to manage two to three times more storage • Protect your critical data• Reduce disk purchases by 50% or more through a superior set of storage efficiency features • Reduce provisioning time by up to 90%• Cut test and development time in half Included standard with every FAS2200 system is a set of powerful NetApp software products that deliver highly efficient storage, simple management tools, and high performance. In addi-tion, optional Extended-Value Software products offer advanced capabilities such as instant data recovery, instant cloning, data replication, disk-to-disk backup, and application-aware backup and recovery.Choosing the Right SystemNetApp offers two systems in the FAS2200 family to help you find the balance of price, performance, and features that best fits your needs.FAS2240Equipped for higher performance or capacity needs, the FAS2240 is a good fit for:• Midsize businesses or distributed sites of larger organizations• Windows application and virtual server consolidation with multiple workloads• Customers that require higher perfor-mance, I/O flexibility, and investment protection for future growth FAS2220Geared toward value-oriented deploy-ments, the FAS2220 is a good fit for:• Midsize businesses, remote offices, and local storage• Consolidating virtualized environ-ments with one to three Windows applications or general file-serving workloads• Customers that need a powerfulsystem at a competitive priceFigure 1) You don’t need to be an expert to configure your storage with the simple, easy-to-use NetApp System Manager Console.FAS2200 SERIES OVERVIEW FAS2240-2FAS2240-4FAS2220 Form Factor2U/24 Drive4U/24 Drive2U/12 Drive Dual Controllers Yes Yes YesMaximum Raw Capacity Maximum Disk Drives 374TB144432TB144180TB60Maximum Ethernet Ports888Onboard SAS Port444NetApp Flash Pool Support Yes Yes Yes8Gb FC Support Yes*Yes*No10Gbe Support Yes*Yes*NoRemote Management Yes Yes YesStorage Protocols FCP, iSCSI, NFS, CIFS FCP, iSCSI, NFS, CIFS iSCSI, NFS, CIFS All specifications are for dual-controller, active-active configurations.*Based on optional dual-port 10GbE or 8Gb FC mezzanine card and single slot per controller.Global SupportSupportEdge servicesNetApp Global Support delivers high availability for your enterprise data environment and helps you optimize your storage investments. Let NetApp mitigate support issues and drive operational best practices. NetApp’s innovative, proactive support means that you’ll have fewer and less-severe support cases. But if a problem arises, our award-winning technical centers and field support staff—delivering in over 100 countries—won’t rest until it’s solved.As an industry leader in innovation, NetApp Global Support provides tools and technology to enable business continuity. AutoSupport TM, NetApp’s suite of automation tools, is delivered as a service to help you proactively manage your systems and quickly resolve issues. AutoSupport functions as a “virtual staff” to protect critical data, save time, and reduce impact on your IT resources.About NetAppNetApp creates innovative storage and data management solutions that deliver outstanding cost efficiency and accelerate business breakthroughs. Discover our passion for helping companies around the world go further, faster at .Go further, faster© 2012 NetApp, Inc. All rights reserved. No portions of this document may be reproduced without prior written consent of NetApp, Inc.Specifications are subject to change without notice. NetApp, the NetApp logo, Go further, faster, AutoSupport, Data ONTAP , FlexClone, FlexShare, FlexVol, MultiStore, NearStore, OnCommand, RAID-DP , SnapManager, SnapMirror, SnapRestore, Snapshot, and SnapVault are trademarks or registered trademarks of NetApp, Inc. in the United States and/or other countries. Microsoft, SharePoint, SQL Server, and Windows are registered trademarks and Hyper-V is a trademark of Microsoft Corporation. Oracle is a registered trademark of Oracle Corporation. SAP is a registered trademark of SAP AG. VMware is a registered trademark of VMware, Inc. All other brands or products are trademarks or registered trademarks of their respective holders and should be treated as such. DS-3318-0412FAS2200 SERIES SOFTWAREIncluded SoftwareData ONTAP Essentials:Efficiency: FlexVol ®, deduplication, compression, and thin provisioning Availability: Multipath I/O and MultiStore ®Data Protection: RAID-DP ®, Snapshot ™, NearStore ®, and Open Systems SnapVault ®Performance: FlexShare ®Management: System Manager, Operations Manager, Protection Manager, and Provision ManagerData Protocols: All supported data protocol licenses are included.Extended-Value Software (optional)Software DescriptionSnapRestore: Software to restore Snapshot copies in seconds SnapMirror: Simple, efficient, and flexible disaster recoverySnapVault: Disk-to-disk backup software for complete backups and online archives to primary or secondary storage in minutes instead of hours or days FlexClone: Instant virtual copies of databases or virtual machinesSnapManager Suite: Application and virtual machine aware backup, recovery, and cloning (for Oracle ®, Exchange, SharePoint ®, SQL Server ®, SAP ®, virtual infrastructure, and Hyper-V ™)OnCommand Balance for NetApp: Advanced analytics for physical and virtual environments Complete Bundle: All of the Extended-Value Software together in a single bundle for all-inclusive convenience (Note: OnCommand Balance is not included in the Complete Bundle option)。
Innovative, Modular, Dual Belt Conveyor Pallet Systems for Assembly AutomationInnovative Timing Belt Conveyor Design Industry Best Pallet Transfer System Clean Room Class 100 CertifiedFast & Simple to Use Online Configurator 2200 SERIESPALLET SYSTEMS• Conveyor Load Capacity 500 lbs non-accumulating 250 lbs accumulated• Pallet capacity of 30 to 70 lbs• Speeds up to 114 ft/min (34 m/min)2200 SERIES PRECISION MOVE PALLET SYSTEMS• Widths: 160, 240, 320, 400, and 480 mm • Lengths: Up to 24' 7" (7500mm)• Dual belt conveyors with common drive module • 25mm wide 5mm pitch timing belt conveyor • Standard or static conductive belting available • Aluminum extruded frame with universal T-Slot • Quick belt change without conveyor removal• 160mm to 480mm• Industry compatible sizes and bushing locations • Static conductive pallet skirt• Square and rectangular sizes available• Pallets are sold as kits or completed assembliesLift & LocateLift & RotateLift & Transfer90 Degree Corner90 Degree Corner & MergeCushioned Pallet Stop (Non-cushioned also available)The Benefits of a Dorner 2200 Series Precision Move Pallet SystemInnovative Offering • Timing belt conveyors provide added load capacity in a small platform • Quick belt change without the need to remove conveyor from system • Pin Tracking System provides cost effective pallet traffic management Delivers Fast • D orner sets the industry standard for rapid delivery • C onveyors and automation modules available in 20 days or less Time Saving • Dorner’s online configurator engineers simple to complex configurations in minutes. • The industry leading tool delivers a complete 3D Assembly model for instant validation of fit• Adjustable height lift from center of conveyor • Provides 200 lbs of lift capability at 90psi • Accuracy of ± 0.002"• Lift and Rotate:• Pneumatic lift from center of conveyor• Pneumatic rotation with adjustable positioning • Rotation angle: 90 to 180 degrees adjustable • Includes cushioned lift stroke • Lift and Transfer:• Changes product orientation• Uses dual strand timing belt conveyors and pneumatic lift • 70 lbs load capacitySimple Powered Corner Modules• 90 Degree Corner:• Uses pin tracking in pallet• Maintains product orientation through the turn• Includes 24VDC drive mechanism to drive the pallet around the corner• 90 Degree Corner and Merge: • Uses pin tracking in pallet• Inside guide is mounted to pneumatic cylinders to transfer pallet around corner• Straight guide with pneumatic cylinder is mounted across perpendicular conveyor to guide pallets straight through the merge area• Includes 24VDC drive mechanism to drive the pallet around the cornerAccurate Pin Tracking System• Simple and cost effective method of tracking pallets through turns• Used on 90 Degree Corner and 90 Degree Corner &Merge ModulesLift & Rotate90 Degree Corner1X SeriesThe 1X Series Line is designed for small part handling and transfers where space is a premium.1X Series Family:• Flat Belt• Aluminum Frame • Widths to 10"• Loads to 15 lbs • Speeds up to 80 fpm 2X SeriesThe 2X Series Line isengineered for smallto medium sized parts,precision applicationsand flexible layouts.2X Series Family:• Flat Belt• Cleated Belt• Modular Belt• Precision Move• SmartFlex®• Aluminum Frame• Widths to 24"• Loads to 200 lbs• Speeds up to 400 fpm• Curves• Z-Frame Elevators3X SeriesThe 3X Series Line isdesigned for mediumto heavy sized parts,precision applications,bulk handling andflexible layouts.3X Series Family:• Flat Belt• Cleated Belt• Modular Belt• Flexible Chain• Precision Move• Aluminum Frame• Widths to 60"• Loads to 1000 lbs• Speeds up to 600 fpm• Curves• Z-Frame Elevators7X SeriesThe 7X Series StainlessSteel Line is engineeredfor small to heavyproduct requiring variouslevels of sanitary designandflexible layouts.7X Series Family:AquaPruf® + AquaGard®• Flat Belt• Cleated Belt• Modular Belt• Flexible Chain•Vertical Belt Technology• Stainless Steel Frame• Widths to 52"• Loads to 750 lbs• Speeds up to 400 fpm• Curves• Z-Frame Elevators NEED SOMETHING DIFFERENT?DORNER’S ENGINEERED SOLUTIONS GROUP PROVIDES EXACTLY WHAT YOU NEEDFOR YOUR SPECIFIC APPLICATION. FROM MODIFIED STANDARD CONVEYORS TOCOMPLETE CUSTOM DESIGNS.LOOKING FOR AFTER SALE SUPPORT?DORNER’S SERVICES TEAM PROVIDES COMPLETE SUPPORT FROM REPLACEMENTPARTS TO INSTALLATION AND MAINTENANCE SERVICES.© Dorner Mfg. Corp. 2017. All Rights Reserved. Made in the U.S.A. 851-794 Rev. A 3M - JBK - 041610YEAR Warranty。
