一种基于DSP的音频实时处理系统作者：刘睿来源：《现代电子技术》2011年第01期摘要：声学回声消除器一直是视频会议系统不可缺少的组件。

将回声消除算法结合噪音消除和静音检测算法等，提出一种改进的实时音频处理系统方法，并在TMS320C6713B上实现，能够有效改善噪音、双工检测、非线性回声等导致自适应滤波器发散的问题。

该系统在保证正常双工通话的同时，对非线性回声的抑制有着明显的改善效果。

关键词：声学回声消除；噪音消除；静音检测；语音信号处理； DSP中图分类号：TN911-34文献标识码：A文章编号：1004-373X(2011)01-0085-03A Real-time Audio Processing System Based on DSPLIU Rui(AVCON Information Technology Co. Ltd., Shanghai 200433, China)Abstract： Acoustic echo canceller has being an indispensable component of video conferencing-time audio processing system is proposed in combination with echo cancellation, noise cancellation and voice activity detection. The system based onTMS320C6713B DSP chip, and improved the problems of noise, double-talk detection, nonlinear echo and other problems leading to divergent adaptive filter. The system can ensure normal double-talk, and has significantly improved results of non-linear echo suppression.Keywords： acoustic echo cancellation; noise cancellation; voice active detection; speech signal processing; DSP0 引言随着VOIP的广泛应用以及多媒体通信技术的发展和成熟，人们对互联网语音通信的音频品质提出了更高的体验要求。
