HydrocarbonFiltration Products■Fuel Filtration Vessels and Systems■API/EI (IP) Qualified Cartridges■Filtration Cartridges■Fuel Dispensing Filtration■Fuel Condition MonitoringRefineryAirport2Multi-Product PipelineDedicated PipelineRoad TransportRefuelerDispenserACM 20Sea CargoAircraftHelicopterFuel DrumsFuel StorageFloating SuctionUnderground Storage Industrial & Marine Fuel Applications MF Racor offers 2 types of Microfilters:FP Cellulose cartridges offer 95%filtration efficiency and are available inmicron ratings of 1, 5, 10, 25, & 40,suitable for fuel and hydrocarbonapplications. FS Synthetic high efficiencymicrofilter cartridges feature a waterresistant, all synthetic media providing 99.7%+ efficiency at the stated 1, 5, 10, & 25 micron ratings complyingto API/EI (IP) 1590 2nd Edition (1 and 5 micron). Requirements may differ depending on location and contamination history.FWS Racor Hydrocarbon FWS seriesvessels use a 2 stage separationsystem. The first stage coalesces thefuel/water emulsion by means ofhigh efficiency filter media combinedwith a resin impregnated fiberglasscoalescing shell. The second stage uses a hydrophobic separator as a water drop barrier, allowing the cleandry fuel to pass. The coalesced water droplets are repelled by the hydrophobic barrier and are collected in the sump of the housing. A full range of standard and API/EI (IP) 1581 5th Edition qualified combinations are available. NOTE:A full range of industrial vessels are available for other hydrocarbon products.RHFM Racor Horizontal FuelMonitor Vessels with EI 1583cartridges will absorb free water from fuels to <15 ppm as well as providing high filtration efficiency. Monitor cartridges are qualified to EI 1583.RVFS This innovative filter vessel will accepta wide range of Microfilters, Coalescers and Separator cartridges. The vessel is particularly targeted at high volume diesel fuel deliveryterminals and fueling stations.FBO Offering a similar level of versatility asthe RVFS, these filter vessels will accept a widerange of Microfilters, Coalescers/Separatorsand Monitor cartridges. The vessel is particularly targeted at medium volume fuel delivery systems,and offers an economical solution to fuel delivery.ACM 20Parker’s renowned particle counter has been engineered and calibrated for use in fuels and allows quick, easy economical fuel condition checks for aviation and diesel fuels. A quick 2 minute testwill allow you to check contaminationlevels, trends and integrity in a far more consistent, reliable and repeatable waythan traditional clear and bright methods.Terminal PetrolStation3456789HYDROCARBON FILTER VESSELS 10FBO FILTER VESSELSMaximum Flow RatesMicrofilter 5-50 gpm 204050**20 PSID Filter Sep 5-30 gpm 122530**15 PSID Absorber5-45 gpm183545**30 PSIDMicrofilter 10-75 gpm 306075**20 PSID Filter Sep 10-40 gpm 153040**15 PSID Absorber10-70 gpm265570**30 PSID** varies with fluid,temperature,free water content and flow rate.The same flow rates apply to the FBO-10-MA and FBO-14-MA.Flow Range DieselKeroseneGasolineDelta PDelta PFBO-10Clean DryChange Flow Range DieselKeroseneGasolineDelta PDelta PFBO-14Performance SpecificationsFBO Filter AssemblyRacors’ FBO-10 and FBO-14 filter assemblies are designed to meet the toughest hydrocarbon refueling conditions and provide for ease of cartridge change outs.The FBO assembly can be used onmobile refuelers or installed in refueling cabinets. The unit can also be used for diesel fuel dispensing pumps or as a primary fuel filter/water separator for large diesel engines.The assembly features a locking ring collar, which attaches the filter housing to the aluminum die-cast filter head with four bolts. The slotted locking ring collar allows maintenance personnel to hand-loosen the four collar bolts, rotate and lower the bowl assembly for cartridge change outs. With new cartridge installed, simply raise the bowl and rotate into position on the locking ring and hand tighten evenly.The closure hardware consists of stainless steel nuts, bolts and washers with metal hand knobs for ease of maintenance – one person can easily change the filter element. No wrenches or other special tools are required. 100 LB-IN torque is highly recommended.Standard Design Features• Die-cast aluminum head • Steel filter bowl assembly •Powder-coated components •Locking ring collar, no V clamps •1 1/2" NPT Inlet and Outlet•10 bar @ 240°F max design pressure •Manual drain valve •Manual vent valveOptions• Mounting bracket • Sight glass• Pressure diff. indicator • Water ProbeApplications• Diesel fuel, aviation gas, gasoline and keroseneInstallations•Diesel fuel dispensing system •Marine fuel docks •Fuel systems on large diesel enginesUL listed versions are available as part numbers FBO-10-MA and FBO-14-MA. See bulletin 7694.1151"RVFS-2 12131415Features•Carbon steel construction; other materials available • ASME Code, Section VIII construction, stamped and certified • Zinc plated swing bolt closure • Buna-N o-ring cover seal • Hydraulic jack cover lift• Inlet and outlet permanently marked • Interior: epoxy-coated MIL-C-4556 E • Exterior: prime coated• Knife-edge cartridge mounting sealsOptional Accessories•Automatic air eliminator •Pressure relief valve•Differential pressure gauge •Sampling probes•Manual or automatic water drain valves•Sump drain line heaters •Liquid level sight glass •Water slug control valve •Pilot control valve•Rate of flow control valveIndustrial Filter/Water Separator VesselsThe RVFS Series Filter/Water Separator Vessels are for use with Racor Hydrocarbon ACP, RAC and CP Series Coalescers and SP, SS, ST, RSS and RST Series Separator Cartridges. Racor hydrocarbon RVFS Series two-stage vertical coalescer/separator housings are designed to filter solids and separate water from fuel. Using the correct combination of Racor hydrocarbon coalescer cartridges and second stage separator cartridges will provide the highest degree of water and solids removal.Applications • Diesel Fuel • Kerosene • Gasoline • Bio-Diesel Installations •Refineries •Terminals •Loading racks •Marine fuel sites •Fuel storage •Fuel pipelines Connections•Inlet and Outlet: 150# RF (ANSI) flanged •Main Drain: NPT•Vent and pressure relief connection: NPT •Differential pressure gauge/sample ports: NPTFeatures•Carbon steel construction;other materials available •ASME Code, Section VIII construction, stamped and certified •Zinc-plated swing bolt closure •Buna-N o-ring cover seal• Hydraulic jack cover lift• Inlet and outlet permanently marked •Interior: epoxy-coated MIL-C-4556E • Exterior: prime coated• Knife-edge cartridge mounting seals API/EI (IP) 1581 5th Edition Vertical and Horizontal Filter/Water Separator VesselsThe RVFS/5 Series Filter Water Separator Vessels are for use with Racor Hydrocarbon ACP and RAC Series Coalescers and SS, ST, RSS and RST Series Separator Cartridges. Racor hydrocarbon RVFS/5 Series two-stage vertical and horizontal coalescer/separator housings are designed to filter solids and separate free water from jet fuel. Using the correct combination of Racor hydrocarbon coalescer cartridges and second stage separator cartridges will provide the highest degree of water and solids removal.Applications• Jet A, Jet A1• JP4, JP5, JP8• KeroseneInstallations•Refineries•Terminals•Loading racks•Hydrant carts and refuelersConnections•Inlet and Outlet: 150# RF (ANSI) flanged•Main Drain: NPT•Vent and pressure relief connection: NPT•Differential pressure gauge/sample ports: NPTOptional Accessories•Automatic air eliminator•Pressure relief valve•Differential pressure gauge•Sampling probes•Manual or automatic waterdrain valves•Sump drain line heaters•Liquid level sight glass•Water slug control valve•Pilot control valve•Rate of flow control valveAPI/EI (IP) 5th EditionVertical Coalescer Separators (FWS)API/EI (IP) 5th EditionHorizontal Coalescer Separators (FWS)1617Standard Housing Data and Flow Rates18crankcaseventilation, marinefilter/silencers, cabin air filtersand replacement filters.Engine CrankcaseRacor’s tried and trustedrange of Spin-On fuelfilter/water separators andthe legendary Turbine Seriesrepresent, to customers,OEMs and end users alike,the very best in fuelfiltration solutions.1920high technology markets, achieving profitableDesigns, manufactures and markets system-filtration and clarification products, providingcustomers with the best value, quality, techni-Designs, manufactures and markets rigid and21Brochure No. 7537 USA01/07 5MParker Hannifin CorporationRacor Division P .O. Box 3208Modesto, CA 95353 USA 800/344-3286209/521-7860Fax 209/529-3278/racor e-mail: racor @Argentina •+54 (3327) 44-4129Australia •+61 (2) 9 634 7777Austria •+43-2622-23501-0Belgium •+32 (67) 280900Brazil •+55-12-3955-1000Canada •1-800-272-7537Central & South America/Caribbean •1-305-470-8800Chile •+56 (2) 623-1216China •+86 (21) 6445 9339Czech Republic •+42-0-2-830-85-221Denmark •+45-0-43-56-04-00Finland •+358 (0)3 54100France •+33-0-254-740304Germany •+49-0-2131-4016-0Hong Kong •+852 (2) 428 8008Hungary •+36 (1) 252 8137India •+91-22-5613 7081 /82/83/84/85Italy •+39-02-451921Japan •+81-3-6408-3900Jordan •+(962) (6) 810679Korea Choongnam •+82-41-583-1410Korea Kyoungnam •+82-55-389-0100Korea Seoul •+82-2-559-0420Mexico •1-800-272-7537Netherlands •+31-0-541-585000New Zealand •+64 (9) 573 1523Norway •+47-64-91-1000Poland •+48-22-863-4942Singapore •+65 6261 5233South Africa •+27 (11) 9610700Spain •+34 (91) 675 7300Sweden •+46-8-5979-5000Switzerland •+41-0-22-307-7111Taiwan •+886 (2) 2298 8987Thailand •+66 2717 8140United Arab Emirates •+971-2-6788587United Kingdom •+44 (0) 1924-487000USA •1-800-272-7537Venezuela •+58-212-238-54-22Filtration Group Headquarters6035 Parkland Blvd.Cleveland,Ohio,44124-4141 USA Tel:(216) 896-3000Fax:(216) /filtrationFiltration and Separation Division Balston Products242 Neck RoadHaverhill,MA 01835-0723 USA Tel:(978) 858-0505Fax:(978) /balstonFiltration and Separation Division Finite Filter Products500 Glaspie Street P .O.Box 599Oxford,MI 48371-5132 USA Tel:(248) 628-6400Fax:(248) /finitefilterHydraulic Filter Division16810 Fulton County Road #2Metamora,OH 43540-9714 USA Tel:(419) 644-4311Fax:(419) 644-6205/hydraulicfilterProcess Advanced Filtration Division2340 Eastman Avenue Oxnard,CA 93030 USA Toll Free:(877) 784-2234Tel:(805) 604-3400Fax:(805) 604-3401/processfiltrationParker Hannifin GmbH & Co KGInselstrasse 5D-70327 Stuttgart-Wangen Germany Tel:+49 (0) 711 7071 290-10Fax:+49 (0) 711 7071 /racorRacor Division Global Headquaters3400 Finch Road P .O.Box 3208Modesto,CA 95353 USA Toll Free:(800) 344-3286Tel:(209) 521-7860Fax:(209) /racor Beaufort,SC,USA Tel:(843) 846-3200Holly Springs,MS,USA Tel:(662) 252-2656Parker Hannifin Industria e Comercio Ltda.Filtration DivisionEstrada Municipal Joel de Paula,900Eugenio de Melo,São Josédos Campos CEP 12225-390 SP Brazil Tel:+55 (12) 4009 3500Fax:+55 (12) 4009 /brParker Hannifin Shanghai Co.Ltd.280 YunQiao RoadJinQiao Export Processing Zone Shanghai 201206 China Tel:+86 21 5031 2525Fax:+86 21 5834 /chinaParker Hannifin Thailand Co.Ltd.1023 3rd Floor,TPS Building Pattanakarn RoadSuanluang,Bangkok 10250 Thailand Tel:+66 2717 8140Fax:+66 2717 /thailandParker Hannifin Corporation IndiaPlot EL 26,MIDC,TTC Industrial Area Mahape,Navi Mumbai 400709 India Tel:+91 22 5613 7081/82/83/84/85Fax:+91 22 2768 6618//indiaParker WorldwideSales OfficesContact Parker’s worldwide service and distribution network by calling:Parker Filtration GroupEngineering, Manufacturing & Service LocationsParker Hannifin UK Ltd.Filter Division EuropeShaw Cross Business Park Churwell ValeDewsbury,WF12 7RD EnglandTel:+44 (0) 1924 487000Fax:+44 (0) 1924 487038/eurofiltParker Hannifin Oy Filtration Division Salmentìe 260FI-31700 Urjala as.FinlandTel:+358 20 753 2500Fax:+358 20 753 2501/fidomnick hunter Filter Division Durham Road,Birtley Co.Durham,DH3 2SF EnglandTel:+44 (0) 191 410 5121Fax:+44 (0) 191 410 2532Parker Korea Ltd .777 Jung-Ri Dongtan-Myeon,Hwaseong-City Kyunggi-Do,445-813 KoreaTel:+82 31 379 2200Fax:+82 31 377 9710/koreaParker Hannifin Africa Pty Ltd.Parker Place,10 Berne Avenue,Aeroport Kempton Park,1620 South AfricaTel:+27 11 9610700Fax:+27 11 3927213/euParker Hannifin Japan Ltd 626,Totsuka- cho,Totsuka-ku Yokohama-shi,244-0003 Japan Tel:+81 45 870 1522Fax:+81 45 864 5305/japan。
TI00182C/07/EN/15.1271186403Technical InformationIndumax CLS50/CLS50DInductive conductivity sensor for standard, hazardous and high-temperature applications, analog or digital with Memosens protocolApplicationIndumax CLS50/CLS50D conductivity sensors are especially suitable for application in the chemical industry and process engineering. The six-decade measuring range and the high chemical resistance of the materials in contact with medium (PFA or PEEK) permit to use this sensor in a number of various applications, e.g.:•Concentration measurement of acids and bases•Quality monitoring of chemical products in tanks and pipes •Phase separation of product/product mixturesDigital CLS50D sensors are used with Liquiline CM44x or Liquiline CM42. Analog CLS50 sensors are used with the transmitters Liquiline CM42, Liquisys CLM223/253 or Mycom CLM153.Your benefits•High durability–High chemical resistance thanks to PFA coating–PEEK version for high temperatures up to 180˚C (356˚F)•Low risk of soiling–Dirt-repellent PFA surface –Large sensor opening •Easy installation–Can be installed in T-pieces ≥DN 80 with the outgoing diameter reduced to ≥DN 50–Total cable length up to 55m (180ft)•Wide measuring range from 2 μS/cm to 2000mS/cm •Integrated, coated Pt 100 temperature sensor, error class A •Ex approval EEx ia IIC T6/T4Indumax CLS50/CLS50D2Endress+HauserFunction and system designMeasuring principleInductive conductivity measurementA generator (1) generates an alternating magnetic field in the primary coil (2) which induces a current in the medium (3). The strength of the induced current depends on the conductivity and thus the ion concentration of the medium. The current flow in the medium generates another magnetic field in the secondary coil (4). The resulting current induced in the coil is measured by the receiver (5) and processed to determine the conductivity.Important properties•Wide measuring rangeThe sensor’s measuring range comprises six decades, from 2 μS/cm to 2000 mS/cm.•DurabilityThe materials in contact with medium (PEEK, PFA) feature a very high chemical resistance. In addition, the PEEK version is suitable for application at high temperatures (CLS50 up to 180˚C (356 ˚F) and CLS50D up to 125 ˚C (260 ˚F)).•Low risk of soilingThanks to its large opening, the sensor is not susceptible to soiling. The PFA version requires even less cleaning thanks to its dirt-repellent surface.Advantages of digital sensors with Memosens protocol (CLS50D only)Digital sensors are able to store the following system data in the sensor:•Manufacturing data –Serial number –Order code–Date of manufacture •Calibration data –Calibration date –Cell constant–Change in cell constant –Number of calibrations–Serial number of the transmitter used for the last calibration •Application data–Temperature application range –Conductivity application range –Date of first commissioning –Maximum temperature value–Operating hours at high temperaturesInductive conductivity measurement 12345Generator Primary coilCurrent flow in the medium Secondary coil ReceiverBenefits of inductive conductivity measurement •No electrodes, therefore no polarization•Accurate measurement in media or solutions with a high soiling degree and a tendency to deposition •Complete galvanic separation of measurement and mediumIndumax CLS50/CLS50DMeasuring system CLS50DA complete measuring system comprises:•a CLS50D conductivity sensor with fixed cable•a transmitter, e.g. Liquiline CM44xOptional:•Weather protection cover for the field installation of the transmitter•Assembly for sensor installation in tanks or in pipework, e.g. CLA111Example of a measuring system1Transmitter Liquiline CM44x2Weather protection cover3Pipe socket for flange DN50 PN/64Sensor CLS50D, flange version DN50 PN/6, fixed cable with M12 plugEndress+Hauser3Indumax CLS50/CLS50D4Endress+HauserCLS50A complete measuring system comprises:•a CLS50 conductivity sensor with fixed cable •a transmitter, e.g. Liquiline CM42Optional:•Weather protection cover for the field installation of the transmitter •Assembly for sensor installation in tanks or in pipework, e.g. CLA111Example of a measuring system 1Indumax CLS502Liquiline CM42 transmitter 3Weather protection cover 4Pipework 5Pipe socketInputMeasured variable•Conductivity •Temperature Cell constant k = 1.98 cm –1Measuring frequency 2 kHzMeasuring rangeTemperature measurementCLS50DPt 1000 (class A acc. to IEC 60751)CLS50Pt 100 (class A acc. to IEC 60751)Conductivity: 2 μS/cm to 2000 mS/cm (uncompensated)Temperature:–20 to +180 ˚C (-4 to +350 ˚F)Indumax CLS50/CLS50DEndress+Hauser 5WiringCable specificationThe sensor is supplied with a fixed cable. The connection to the transmitter can be extended using the CYK81 (CLS50D) or the CLK5 (CLS50) special measuring cable.Please note that the residual coupling increases when the cable is extended.Performance characteristicsMaximum measured error•-20 to 100 ˚C (-4 to 212 ˚F):±(5 μS/cm + 0.5 % of the measured value)•> 100 ˚C (212˚F):±(10 μS/cm + 0.5 % of the measured value)Temperature response time•PEEK versions:approx. 7 min •PFA versions:approx. 11minInstallation conditionsInstallation positionInstall the sensor in such a way that the sensor opening is oriented in the flow direction of the medium. The sensor head must be completely immersed in the medium.a0007035Installation position of the sensor 1Flow direction of medium2Minimum water level in the pipe aSensor distance from the pipe wallCYK81 for cable extension for CLS50D –max. total cable length: 100 m (330 ft)CLK5 for cable extension for CLS50–max. total cable length: 55 m (180 ft)Indumax CLS50/CLS50D6Endress+HauserInstallation factorIn narrow installation conditions, the conductivity measurement is affected by the pipe walls. This effect is compensated by the so-called installation factor. The transmitter corrects the cell constant by multiplication with the installation factor.The value of the installation factor depends on the diameter and the conductivity of the pipe as well as the sensor’s distance from the wall.If the distance from the wall is sufficient (a > 15mm (0.59"), from DN 80), it is not necessary to consider the installation factor (f = 1.00).If the distance from the wall is smaller, the installation factor increases in case of electrically insulating pipes (f >1) and decreases in case of electrically conductive pipes (f <1).The installation factor can be measured using calibration solutions or it can be approximately determined from the following diagram.a0005441Relationship between installation factor f and distance from wall a1Electrically conductive pipe wall 2Insulating pipe wallAir setCLS50To compensate residual coupling in the cable and between the two sensor coils, you must perform a zero calibration in air ("air set") before installing the sensor.For further information, refer to the Operating Instructions of your transmitter.CLS50DThe digital sensor is already adjusted at the factory, an on-side compensation is not necessary.Indumax CLS50/CLS50DEndress+Hauser 7Installation of sensors with flangeThe sensor is suitable for installation in T-pieces ≥DN 80 with the outgoing diameter reduced to ≥DN 50.WARNING!LeakagesDanger of injuries by leaking medium►Tighten the nut with a torque of 20 Nm.►To avoid leakages, regularly check the tightness of the nut.Flange, not in contact with mediumFlange, in contact with mediumFixed flange, not in contact with medium (order option "process connection": 5, 6, 7)123Flange (stainless steel)NutSealing disk (GYLON)45O-ring SensorFixed flange, in contact with medium (order option "process connection": 3, 4)12Flange (stainless steel)Nut 34O-ring SensorIndumax CLS50/CLS50D8Endress+HauserLap-joint flange, not in contact with mediumInstallation of sensor assemblyEnvironmentAmbient temperature rangeCLS50D–10 to +60 ˚C (+10 to +140 ˚F)CLS50–10 to +70 ˚C (+10 to +160 ˚F)Storage temperature –20 to +80 ˚C (-4 to +180 ˚F)Ingress protectionIP 68 / NEMA 6 (installed with original sealing)Lap-joint flange, not in contact with medium (order option "process connection": A, B, C)123Lap-joint flange (PP-GF)Nut (stainless steel)Flange (PVDF)45O-ring SensorInstallation of sensor with assembly12CLA111 with suspension bracket CLA111 with flange connection 34CLA140 with flange connection CYA611Indumax CLS50/CLS50DEndress+Hauser 9ProcessProcess temperatureCLS50DCLS50Process pressure max. 20 bar (290 psi), acc. to the sensor version, see pressure-temperature diagramPressure-temperature diagramWithout flangeDN50, ANSI 2"JIS PVDF lap-joint flange Sensor CLS50D-*1/2CLS50D-*3/4/5/6/8CLS50D-*7CLS50D-*A/B/C PEEK –20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)PFA–20 to 110 °C (-4 to 230 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)Without flangeDN50, ANSI 2"JIS PVDF lap-joint flange Sensor CLS50-*1/2CLS50-*3/4/5/6/8CLS50-*7CLS50-*A/B/C PEEK –20 to 180 °C (-4 to 360 °F)–20 to 180 °C (-4 to 360 °F)–20 to 180 °C (-4 to 360 °F)–20 to 125 °C (-4 to 260 °F)PFA–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)–20 to 125 °C (-4 to 260 °F)Pressure-temperature-diagram of CLS50D 1PEEK sensor, without flange2PFA sensor, without flange (blue line)3PEEK or PFA sensor, with DN50/ANSI 2" flange (red line)4PEEK or PFA sensor, with JIS flange5PEEK or PFA sensor, with lap-joint flange PVDF (green line)Indumax CLS50/CLS50D10Endress+HauserMechanical constructionSensor dimensionsPressure-temperature-diagram of CLS501PEEK sensor, without flange2PFA sensor, without flange or with DN50/ANSI 2" flange (blue line)3PEEK sensor, with DN50/ANSI 2" flange (red line)4PFA sensor, with JIS flange (black line)5PEEK or PFA sensor, with lap-joint flange PVDF (green line)6PEEK sensor, with JIS flange (grey line)Dimensions of sensor version with G ¾ thread *Dimensions of PEEK versionDimensions of sensor version with NPT 1" threadIndumax CLS50/CLS50DEndress+Hauser 11Flange dimensionsFlange dimensions 1Lap-joint flange (PP-GF)2Fixed flange (stainless steel)Weight approx. 650 g (1.43 lbs)MaterialLap-joint flange PP-GF DN50 PN10ANSI 2" 150 lbs JIS 10K 50A D 165165152Ø k 125121120d 2 4 x 188 x 19 4 x 19b 181818a 787878ScrewsM16M16M16Fixed flange SS 316 L DN50 PN16ANSI 2" 300 lbs JIS 10K 50A D 165165.1155Ø k 125127120d 2 4 x 188 x 19 4 x 19b 1822.216a 272727ScrewsM16M16M16Sensor:PEEK, PFA (depending on ordered version)Sensor seal:VITON, CHEMRAZ (depending on ordered version)Process connections:G ¾:CLS50-**A: stainless steel 1.4571 (AISI 316Ti)CLS50-**B/C: PEEK GF30CLS50D-**D: stainless steel 1.4571 (AISI 316Ti)CLS50D-**B/C: PEEK GF30NPT 1":PEEK Fixed flange:stainless steel 1.4404 (AISI 316 L)Sealing disk:GYLON (ceramic-filled PTFE)Lap-joint flange:PP-GF Flange combined with lap-joint flange:PVDFIndumax CLS50/CLS50D12Endress+HauserChemical durabilityNo responsibility is taken for the correctness of this information.Ordering informationProduct pageYou can create a complete and valid order code by using the configurator on the internet product page.Enter the following address to access the product page://cls50dOnline configurator1.2.Click "Configure this product".3.The configurator opens in a separate window. You can now configure your device and receive the complete order code that applies for the device.4.Afterwards, export the order code as a PDF or Excel file. To do so, click the appropriate button at the top of the page.Medium Concentration PEEK PFA CHEMRAZ VITONSodium hydroxide solution NaOH0 to 50%20 to 100 ˚C (68to 212 ˚F)not suitable 0 to 150 ˚C (32to 302˚F)not suitable Nitric acid HNO 30 to 10 %20 to 100 ˚C (68to 212 ˚F)20 to 80 ˚C (68to 176 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)0 to 40 %20 ˚C (68 ˚F)20 to 60 ˚C (68to 140 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)Phosphoric acid H 3PO 40 to 80 %20 to 100 ˚C (68to 212 ˚F)20 to 60 ˚C (68to 140 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)Sulphuric acid H 2SO 40 to 2.5 %20 to 80 ˚C (68to 176 ˚F)20 to 100 ˚C (68to 212 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)0 to 30 %20 ˚C (68 ˚F)20 to 100 ˚C (68to 212 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)Hydrochloric acid HCl0 to 5 %20 to 100 ˚C (68to 212 ˚F)20 to 80 ˚C (68to 176 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)0 to 10 %20 to 100 ˚C (68to 212 ˚F)20 to 80 ˚C (68to 176 ˚F)0 to 150 ˚C (32to 302˚F)0 to 120˚C (32to 248˚F)Indumax CLS50/CLS50DEndress+Hauser 13Product structureThe following product structure represents the status of printing. You can create a complete and valid order code on the Internet using the configurator tool.CLS50DApprovalAA Non-hazardous areaBA ATEX II 1G Ex ia IIC T3/T4/T6BV ATEX II 3G Ex nL IIC T4/T6 + NEPSI Ex nL IIC T4/T6C2CSA IS NI Cl . I, II, III, Div. 1&2, Group A-G FB FM IS NI Cl . I, II, III, Div. 1&2, Group A-G NANEPSI Ex ia IIC T4/T6Process connectionA Lap joint flange DN 50 PN 10, PP-GFB Lap joint flange ANSI 2" 150 lbs, PP-GFC Lap joint flange JIS 10 K 50 A, PP-GF 1Thread G ¾2Thread NPT 1", PEEK3Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L)4Flange ANSI 2" 300 lbs, stainless steel 1.4404 (AISI 316 L)5Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk 6Flange ANSI 2" 300 lbs, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk 7Flange JIS 10 K 50 A, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk8Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L), welded PFA sealing plate sensorMaterial: sensor , seal, adapterB PEEK, VITON, PEEKC PEEK , CHEMZRAZ, PEEKDPFA, CHEMRAZ, stainless steel 1.4571 (AISI 316 Ti)Cable length1 3 m (9.84 ft)27 m (23 ft) 315 m (49 ft)7... m fixed cable, max. 50 m 8... ft fixed cable, max. 164 ftCable connection1Fixed cable, terminated cable cores 2Fixed cable, M12 plug CLS50D-order codeCalibration (single choice only)F1Cell constantDienstleistung (multiple choice possible)HCLABS free (LABS = paint-wetting impairment substances)TAG (multiple choice possible)1TAG, see additional specification 2Feldbus TAGIndumax CLS50/CLS50DCLS50ApprovalA Non-hazardous areaG ATEX II 1G Ex ia IIC T4/T6 GaH NEPSI Ex ia IIC T4/T6L Non-hazardous area, PWIS freeO FM IS NI Cl . I, II, III, Div. 1&2, Group A-GS CSA IS NI Cl . I, II, III, Div. 1&2, Group A-GT TIISV ATEX II 3G Ex nL IIC T4/T6 + NEPSI Ex nL IIC T4/T6Process connectionA Lap joint flange DN 50 PN 10, PVDFB Lap joint flange ANSI 2" 150 lbs, PVDFC Lap joint flange JIS 10 K 50 A, PVDF1Thread G¾2Thread NPT 1", PEEK3Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L)4Flange ANSI 2" 300 lbs, stainless steel 1.4404 (AISI 316 L)5Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk6Flange ANSI 2" 300 lbs, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk7Flange JIS 10 K 50 A, stainless steel 1.4404 (AISI 316 L), PTFE sealing disk8Flange DN 50 PN 16, stainless steel 1.4404 (AISI 316 L), welded PFA sealing plate sensorMaterial: sensor, seal, adapterA PFA, CHEMRAZ, stainless steel 1.4571 (AISI 316 Ti)B PEEK, VITON, PEEKC PEEK , CHEMZRAZ, PEEKCable length and temperature range1 5 m (16 ft) fixed cable, max. 125 ˚C (257 ˚F)210 m (32 ft) fixed cable, max. 125 ˚C (257 ˚F)320 m (65 ft) fixed cable, max. 125 ˚C (257 ˚F)4fixed cable of specific length, max. 55 m (180 ft), max. 125 ˚C (257 ˚F)5 5 m (16 ft) fixed cable, max. 180 ˚C (356 ˚F) (PEEK only, version for non-hazardous areas only)610 m (32 ft) fixed cable, max. 180 ˚C (356 ˚F) (PEEK only, version for non-hazardous areas only)CLS50-complete order codeCertificates and approvalsEx approvals CLS50D•ATEX II 1G Ex ia IIC T4/T6 GaCLS50•ATEX II 1G Ex ia IIC T4/T6 Ga•ATEX II 3G Ex nL IIC T4/T6 + NEPSI Ex nL IIC T4/T6•FM/CSA IS NI Cl. I, II, III, Div. 1 & 2; Group A - G in connection with a Liquiline CM42 or MycomCLM153 transmitter•NEPSI Ex ia IIC T4/T614Endress+HauserIndumax CLS50/CLS50DAccessoriesMeasuring cables For CLS50DCYK11 Memosens data cable•Extension cable for digital sensors with Memosens protocol•Ordering as per product structure (--> Online configurator, /cyk11)For CLS50Extension cable CLK6•For inductive conductivity sensors, for extension via the VBM junction box, sold by the meter•Order no.: 71183688Junction box VBM•For cable extension•10 terminals•Cable entries: 2 x Pg 13.5 or 2 x NPT ½"•Material: aluminum•Ingress protection: IP 65 (i NEMA 4X)•Order numbers:–cable entries Pg 13.5: 50003987–cable entries NPT ½": 51500177Assemblies Dipfit CLA111•Immersion assembly for open and closed tanks with flange DN 100•Ordering acc. to product structure, --> online configurator: /cla111•Technical Information TI00135C/07/ENDipfit CLA140•For the inductive sensors CLS50/CLS50D•Immersion assembly with flange connection for highly demanding processes•Ordering acc. to product structure, --> online configurator: /cla140•Technical Information TI00196C/07/ENImmersion assembly Dipfit CYA611•For sensor immersion in basins, open channels and tanks, PVC•Ordering acc. to product structure, --> online configurator: /cya611•Technical Information TI00166C/07/ENCalibration solutions Precision solutions, traceable to SRM (standard reference material) by NIST, for qualified calibration ofconductivity measurement systems according to ISO 9000, with temperature table•CLY11-B149.6 μS/cm (reference temperature 25 ˚C / 77 ˚F), 500 ml / 16.9 fl.ozOrder no. 50081903•CLY11-C1.406 mS/cm (reference temperature 25 ˚C / 77 ˚F), 500 ml / 16.9 fl.ozOrder no. 50081904•CLY11-D12.64 mS/cm (reference temperature 25 ˚C/ 77 ˚F), 500 ml / 16.9 fl.ozOrder no. 50081905•CLY11-E107.0 mS/cm (reference temperature 25 ˚C / 77 ˚F), 500 ml / 16.9 fl.ozOrder no. 50081906Endress+Hauser15TI00182C/07/EN/15.12 71186403FM9。
