GS 01C21F01-02CY标准规格RE JA530A 压力变送器用于测量液体、气体或蒸汽的液位、密度与压力，然后将其转变成4~20mADC TM 的电流信号输出。
EJA530A 也可与BRAIN 手操器、TM YHC4150、CENTUMCS 、FieldMate 、HART 375互相通讯，通过它们进行设定、监控等。
ABCD可调量程的参考精度(包括从零点开始的线性、滞后性和重复性)若量程小于XX 取值：环境温度影响o 总影响量/28℃(50F )±[0.15%量程+0.15%量程上限]±0.1%量程上限/12个月稳定性±0.005%/V (21.6V~32V DC ，350Ω)供电电源影响“”功能规格MPaPsi (D1)Bar (/D3)2Kgf/cm (/D4)10~200kPa 调 零在膜盒量程的上下限范围内，零点可任意调整外部调零通过外部调零螺钉，可在测量范围内对零点进行连续调校，分辩率为0.01%，量程可通过数字表头上的量程设定开关进行现场调校。
安装位置影响与膜片面平行方向的安装位置变化不会造成零点漂移，与膜片面垂直方向旋转到90度，将会产生0.27kPa{1.1inH2O}的零漂，并可通过调零校正。
膜 盒A B C D XMP a {psi }40kPa {5.8}0.2{29}1{145}8{1160}振动影响±0.1%量程上限(5~15Hz ；4mm15~150Hz ；2g 150~2000Hz ；1g )0~200kPa量程范围量程范围量程范围量程范围量程/范围□ 1.45~290~2914.5~2900~29072.5~14500~1450720~72000~72000.1~20~21~200~205~1000~10050~5000~5000.1~20~21~200~205~1000~10050~5000~5000.1~20~20.5~100~105~500~50性能规格（以标准零点为基准调校量程，接液部分材质代码“S ”充灌液为硅油）输出“ ”2线制，4～20m A D C 输出，数字通讯，可编程设定线性或平方根输出方式，BRAIN 或HART FSK 协议加载在 4～20mA DC 的信号上。
现场条件及介质情况所提供的工业电视、DCS系统及仪表满足招标文件规定现场条件及介质情况的要求。
1、制造规范、标准及准则（1）EJA智能压力、差压变送器A．Q/CYS001-2001 EJA压力、差压变送器；B．ISO9001:2000 idt GB/T19001-2000质量管理体系标准C．GB/T 17614.1-1998 工业过程控制系统用变送器第1部分：性能评定方法。
D．GB/T 17614.2-1998 工业过程控制系统用变送器第2部分：检查和例性试验导则。
E．GB3836.1-2000 爆炸性气体环境用电气设备第1部分：通用要求。
F．GB3836.1-2000 爆炸性气体环境用电气设备第2部分：隔爆型“d”。
G．GB3836.1-2000 爆炸性气体环境用电气设备第2部分：隔爆型“d”。
H．GB3836.1-2000 爆炸性气体环境用电气设备第4部分：本质安全型“I”。
I．GB 9969.1-1998 工业产品使用说明书总则J．GB/T15464-1995 仪器仪表包装通用技术条件K．JB/T 9329-1999 仪器仪表运输,运输储存基本环境条件及试验方法L．JIS C 0920 电器设备,器具及配线材料防水试验通则（2）4、EJA压力、差压变送器技术性能要求4.1 变送器为二线制。
输出信号：4-20mA标准信号；带BRAIN协议和LCD数显；电源：24VDC。
4.2 变送器在外接负载电阻至少为500Ω时（24VDC供电），仍能正常工作。
4.3 变送器带就地数显式数字指示表,此设备是标准配置,无此表头不会影响变送器的正常工作.4.4 变送器精度高于±0.075 %。
阻尼可设置或可调。
4.5 变送器在温度变化为50℃时，漂移量不超过最大量程的0.1％。
4.6 变送器为线性输出（0~100%），在测量范围内连续可调。
量程比最小应满足100：1。
具有零位正向迁移和负向迁移。
4.7变送器能通过手操编程器进行标定、组态、诊断和维护，组态的数据保存在EPROM中。
