2SC5570

2006-11-22 1 TOSHIBA TRANSISTOR SILICON NPN TRIPLE DIFFUSED MESA TYPE

2SC5570

HORIZONTAL DEFLECTION OUTPUT FOR HIGH

RESOLUTION

DISPLAY, COLOR TV

HIGH SPEED SWITCHING APPLICATIONS

z High Voltage: VCBO = 1700 V

z Low Saturation Voltage: VCE (sat) = 3 V (Max.)

z High Speed: tf (2) = 0.1 μs (Typ.)

ABSOLUTE MAXIMUM RATINGS (Tc = 25°C)

CHARACTERISTIC SYMBOL RATING

UNIT

Collector−Base Voltage V

CBO 1700 V

Collector−Emitter Voltage V

CEO 800 V

Emitter−Base Voltage V

EBO 5 V

DC I

C 28

Collector Current

Pulse

I

CP 56 A

Base Current I

B 14 A

Collector Power Dissipation P

C 220 W

Junction Temperature T

j 150 °C

Storage Temperature Range T

stg −55~150 °C

Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the

significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even

if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum

ratings.

Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook

(“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test report

and estimated failure rate, etc).

Unit: mm

JEDEC ―

JEITA ―

TOSHIBA 2-21F2A

Weight: 9.75 g (typ.)

2SC5570

2006-11-22 2ELECTRICAL CHARACTERISTICS (Tc = 25°C)

CHARACTERISTIC SYMBOL TEST CONDITION MIN TYP. MAXUNIT

Collector Cut−off Current I

CBO V

CB = 1700 V, I

E = 0 ― ― 1 mA

Emitter Cut−off Current I

EBO V

EB = 5 V, I

C = 0 ― ― 100μA

Emitter−Base Breakdown Voltage V

(BR) CEOI

C = 10 mA, I

B = 0 800 ― ― V

h

FE (1) V

CE = 5 V, I

C = 2 A 22 ― 48

h

FE (2) V

CE = 5 V, I

C = 8 A 12.5 ― 25 DC Current Gain

h

FE (3) V

CE = 5 V, I

C = 22 A 4.5 ― 7.5 ―

Collector−Emitter Saturation Voltage V

CE (sat) I

C = 22 A, I

B = 5.5 A ― ― 3 V

Base−Emitter Saturation Voltage V

BE (sat) I

C = 22 A, I

B = 5.5 A ― 1.0 1.5 V

Transition Frequency f

T V

CE = 10 V, I

C = 0.1 A ― 2 ― MHz

Collector Output Capacitance C

ob V

CB = 10 V, I

E = 0, f = 1 MHz ― 470 ― pF

Storage Time t

stg (1) ― 2.6 3.0

Fall Time

tf (1)

I

CP = 10 A, I

B1 (end) = 1.4 A

f

H = 64 kHz

― 0.2 0.3 μs

Storage Time t

stg (2) ― 1.4 1.6 Switching Time

Fall Time

t

f (2)

I

CP = 8 A, I

B1 (end) = 1.2 A

f

H = 130 kHz

― 0.10 0.15μs

Marking

2SC5570 TOSHIBA

JAPAN Lot No.

A line indicates

lead (Pb)-free package or

lead (Pb)-free finish. Part No. (or abbreviation code)

2SC5570

2006-11-22

3

2SC5570

2006-11-22

4

2SC5570

2006-11-22

5

2SC5570

2006-11-22 6
