IS31AP2005
2.95W MONO FILTER-LESS CLASS-D AUDIO POWER AMPLIFIER
GENERAL DESCRIPTION The IS31AP2005 is a high efficiency, 2.95W mono class-D audio power amplifier. A low noise, filter-less PWM architecture eliminates the output filter, reducing external component count, system cost, and simplifying design. Operating in a single 5V supply, IS31AP2005 is capable of driving 4Ω speaker load at a continuous average output of 2.95W with 10% THD+N. The IS31AP2005 has high efficiency with speaker load compared to a typical class AB amplifier. In cellular handsets, the earpiece, speaker phone, and melody ringer can each be driven by the IS31AP2005. The gain of IS31AP2005 is externally configurable which allows independent gain control from multiple sources by summing signals from each function. The IS31AP2005 is available in DFN and MSOP packages. APPLICATIONS Wireless or cellular handsets and PDAs Portable DVD player Notebook PC Portable radio Educational toys USB speakers Portable gaming TYPICAL APPLICATION CIRCUIT FEATURES JULY 2011 5V supply at THD = 10% -2.95W into 4Ω (Typ.) -1.70W into 8Ω (Typ.) Efficiency at 5V: -83% at 400mW with a 4Ω speaker -89% at 400mW with an 8Ω speaker Optimized PWM output stage eliminates LC output filter Fully differential design reduces RF rectification and eliminates bypass capacitor Integrated pop-and-click suppression circuitry 3mm × 3mm DFN-8 and MSOP-8 package RoHS compliant and 100% lead(Pb)-free
ORDERING INFORMATION INDUSTRIAL RANGE: -40°C TO +85°C Order Part No. IS31AP2005-DLS2-TR IS31AP2005-SLS2-TR Package DFN-8, Lead-free MSOP-8, Lead-free QTY/Reel 2500 2500
Integrated Silicon Solution, Inc. – Rev. A, 07/06/2011
2
芯天下--/
IS31AP2005
PIN CONFIGURATION Package Pin Configuration (Top view)
Integrated Silicon Solution, Inc. – Rev. A, 07/06/2011
1
芯天下--/
IS31AP2005
Figure 2
Typical IS31AP2005 Application Schematic with Single-ended Input
Integrated Silicon Solution, Inc. – Rev. A, 07/06/2011
4
芯天下--/
IS31AP2005
ABSOLUTE MAXIMUM RATINGS (NOTE 1) Supply voltage, VDD Voltage at any input pin Junction temperature, TJMAX Storage temperature range, Tstg ESD susceptibility Lead temperature 1,6 mm (1/16 inch) from case for 10s Thermal resistance θJA (DFN) -0.3V ~ +6.0V -0.3V ~ VDD+0.3V -40°C ~ +150°C -65°C ~ +150°C 6kV 260°C 47°C/W
Figure 1 Typical IS31AP2005 Application Schematic with Differential Input Copyright © 2011 Integrated Silicon Solution, Inc. All rights reserved. ISSI reserves the right to make changes to this specification and its products at any time without notice. ISSI assumes no liability arising out of the application or use of any information, products or services described herein. Customers are advised to obtain the latest version of this device specification before relying on any published information and before placing orders for products. Integrated Silicon Solution, Inc. does not recommend the use of any of its products in life support applications where the failure or malfunction of the product can reasonably be expected to cause failure of the life support system or to significantly affect its safety or effectiveness. Products are not authorized for use in such applications unless Integrated Silicon Solution, Inc. receives written assurance to its satisfaction, that: a.) the risk of injury or damage has been minimized; b.) the user assume all such risks; and c.) potential liability of Integrated Silicon Solution, Inc is adequately protected under the circumstances
DFN-8
MSOP-8
PIN DESCRIPTION DFN-8 1 2 3 4 5 6 7 8 MSOP-8 1 2 3 4 5 6 7 8 No Pin I/O Description Shutdown terminal, active low logic. No internal connection. Positive differential input. Negative differential input. Positive BTL output. Power supply. High-current ground. Negative BTL output. Connect to GND.
SDB
NC IN+ INOUT+ VDD GND OUTThermal Pad
I I I O O -Fra bibliotekIntegrated Silicon Solution, Inc. – Rev. A, 07/06/2011
3
芯天下--/
IS31AP2005
RECOMMENDED OPERATING CONDITIONS Parameter Supply voltage, VDD High-level input voltage, VIH Low-level input voltage, VIL Input resistor, RI Common mode input voltage range, VIC Operating free-air temperature, TA ELECTRICAL CHARACTERISTICS TA = 25°C (Note 2) Symbol Parameter | VOS | |IIH | | IIL | IQ ISD fsw Gain Output offset voltage (measured differentially) High-level input current Low-level input current Quiescent current Shutdown current Switching frequency Condition VI = 0V, AV = 2V/V, VDD = 2.7V ~ 5.5V VDD = 5.5V, VI = 5.8V VDD = 5.5V, VI = -0.3V VDD = 5.5V, no load VDD = 2.7V, no load VSHUTDOWN = 0.4V, VDD = 2.7V ~ 5.5V VDD = 2.7V ~ 5.5V VDD = 2.7V ~ 5.5V, RI = 150kΩ 250 2 2.6 1.2 1 Min. Typ. 10 35 2 Max. Unit mV μA μA mA μA kHz V/V Min. 2.7 Max. 5.5 VDD 0.4 VDD-0.8 85 Unit V V V kΩ V °C
