收稿日期：2023-01-16基金项目：吉林省教育厅科技项目（JJKH20220100KJ ）、东北电力大学青年博士科研助推计划（BSZT02202102）资助作者简介：王彦红（1983），男，博士，副教授。
引用格式：王彦红，李浩然，李洪伟.U 型再生冷却通道内超临界航空煤油换热特性数值模拟[J].航空发动机，2023，49（4）：16-25.WANG Yanhong ，LI Ha⁃oran ，LI Hongwei.Heat transfer of supercritical aviation kerosene in a u-shaped regenerative cooling channel[J].Aeroengine ，2023，49（4）：16-25.U 型再生冷却通道内超临界航空煤油换热特性数值模拟王彦红，李浩然，李洪伟（东北电力大学能源与动力工程学院，吉林吉林132012）摘要：为了解决航空发动机的高温热防护问题，通过RNG k-ε湍流模型开展了U 型再生冷却通道内超临界压力RP-3航空煤油换热特性数值研究。
探究了进口参数、固壁热导率、壁面粗糙度对换热的影响机制。
基于流场和温度场揭示了换热特征和换热机理，通过离心力参数讨论了其作用机制，阐述了二次流对换热的影响，提出了换热关联式，其预测偏差处于±20%以内。
结果表明：上游水平通道和下游水平通道受非对称加热作用产生弱二次流，弯通道受离心力作用产生强二次流，高温区近壁流体吸热能力降低造成传热恶化，最高壁温约为935K ；离心力促使热流产生显著的周向迁移。
在高进口温度下传热恶化起始位置提前到弯通道，加剧了离心力作用，使热流迁移增强。
提高固壁热导率和壁面粗糙度，换热均增强，对离心力影响可忽略。
关键词：U 型通道；再生冷却；超临界航空煤油；换热特性；热流迁移；高温热防护；航空发动机中图分类号：V231.1文献标识码：Adoi ：10.13477/ki.aeroengine.2023.04.003Numerical Simulation on Heat Transfer Characteristics of Supercritical Aviation Kerosene in a U-shapedRegenerative Cooling ChannelWANG Yan-hong ，LI Hao-ran ，LI Hong-wei（School of Energy and Power Engineering ，Northeast Electric Power University ，Jilin Jilin 132012，China ）Abstract ：In order to solve the problem of high-temperature thermal protection of aeroengine ，numerical research on heat transfer characteristics of supercritical-pressure RP-3aviation kerosene in a U-shaped regenerative cooling channel was conducted based on the RNG k-εturbulence model.Effect mechanisms of the inlet parameters ，solid wall thermal conductivity ，and wall roughness on heat trans⁃fer were investigated.Based on the flow field and temperature field distributions ，the characteristics and mechanisms of heat transfer were revealed.The centrifugal force effect was discussed through the centrifugal force parameters.The influence of secondary flow on heat trans⁃fer was described ，and the heat transfer correlation was proposed ，with prediction deviations within ±20%.The results show that the up⁃stream horizontal section and the down-stream horizontal section generate weak secondary flow due to the asymmetric heating ，the bendsection generates strong secondary flow due to the centrifugal force ，and the heat transfer deterioration is caused by the reduced heat ab⁃sorption capacity of near-wall fluid in the high-temperature region ，and the maximum wall temperature is approximately 935K.The cen⁃trifugal force leads to a significant circumferential migration of heat flux.The starting position of heat transfer deterioration is advanced to the bend section at the high inlet temperature condition ，the centrifugal-force effect is aggravated and the heat flux migration is enhanced.With the increase of solid thermal conductivity and wall roughness ，the heat transfer is enhanced and the effect on centrifugal force can be ignored.Key words ：U-shaped channel ；regenerative cooling ；supercritical aviation kerosene ；heat transfer characteristics ；heat flux migra⁃tion ；high-temperature thermal protection ；aeroengine第49卷第4期2023年8月Vol.49No.4Aug.2023航空发动机Aeroengine0引言再生冷却是解决超声速发动机热端部件冷却问题的重要技术，其通过碳氢燃料流经燃烧室固壁内的微通道吸收机体极端热量[1]。
