'*华为机柜安装及接线说明1、机柜内华为设备安装'*机柜内需要安装的华为机柜配套设备包括上图中的逆变器、控制主机、蓄电池。

其中控制主机需要安装电源模块（黄浦江水中站每台主机配了2 个），如下图所示：红色框中的为电源模块，主机共有 4 个模块插槽，插上模块并通上电后，模块上的灯会亮起。

绿色框用标配的盖板把空余的插槽盖上。

2、接线（ 1）蓄电池连接：蓄电池连接使用标配的连接铁片（下图的红框），将电池串连起来。

引出线使用 4 平方以上的电线（黄浦江水中站标配有 2 根做好头的线）（ 2）蓄电池引出线：上图中的蓄电池引出线连接到控制主机最右侧的125A 空开上（两个空开任选其一），负级接空开（与空开上原来的线并在一起），正极接空开后面的接线排，如下图所示：（ 3）空调线缆：空调在门上，共需接 3 根线，门上线缆的位置如下图所示：以述线缆在出厂时，都已在门上接好，另一端已布放到机柜内的机架上。

从机架上找到对应的 3 根线缆，接到主机上（接法见下文）。

'*（ 4）空调线缆（ 1#）接入主机：上图线缆中的1#为空调主机220V 电源，接到下图空开上，注意颜色，棕色接空开，蓝色接空开旁的接线端子，黄绿色接机柜的地线端子上。

'*特别提醒：上图空开右侧的黄色挡板，其左边空开全部接强电（在我们的项目里都是220V），其右边空开全部是弱电（-48V）。

（ 5）空调线缆（ 2#）接入主机：2#线缆是空调控制线，出厂都已做好头，只需插到控制主机下图所在的位置即可。

'*（ 6）空调线缆（ 3#）接入主机：3#线缆是空调风扇电源线（-48V），从控制主机上找任意一个32A 的空开接上即可，负极接空开（与空开上原来的线并在一起），正极接空开后面的接线排，如下图所示：（ 7）逆变器电源线连接：逆变器电源线采用 6 平方以上的电缆，接在逆变器左边的接线端子上，如下图所示：线缆的另一端从控制主机上找任意一个63A 的空开接上即可，负极接空开（与空开上原来的线并在一起），正极接空开后面的接线排，如下图所示：（ 8）门控开关传感器接线机柜右上角有一个门控开关传感器，找到该传感器的线缆（已在机柜内安装好，并做好头），插到控制主机上的GATE接口上即可，如下图所示：'*（ 9）主电源接入：机柜主电源采用 2.5 平方以上的电缆，接到控制主机最左侧的空开上，火线接空开，零线接空开旁边的接线端子，地线接机柜上的地线端子，如下图所示：注意：上图空开需要把三个输入的接线端子短接在一起，正常标配应该有一个短接的铁片（如下图所示），如果找不到也可以用电线代替。
