DIN 267-28 2009

Fasteners-

Part 28: Steel screws, bolts and studs with locking coating

technical delivery conditions

English translation of DIN 267-28:2009-09

緊固件-

第28部分：鋼螺釘，螺栓和螺柱鎖定塗層交貨技術條件

英語翻譯的DIN267-28:2009-09

Foreword

This standard has been prepared Working Committee NA

067-02-08 AA Schrauben und Muttern mit klebenden und

klemmenden Beschichtungen of the Normenausschuss

Mechanische Verbindungselemente (Fasteners Standards

Committee).

前言

這個標準由工作委員會NA 067-02-08 AA所編制Schrauben

und Muttern mit klebenden und klemmenden Beschichtungen of

the Normenausschuss Mechanische Verbindungselemente（緊固件標準委員會）。

Amendments

This standard differs from DIN 267-28:2004-01 and DIN 267-28 Corrigendum

1:2004-11 as follows:

a)corrigendum 1 has been incorporated;

b)bright-finished and coated surfaces have been added to

the scope of the standard;

c)normative references have been revised and updated;

d)examples of designation have been added; e)the scope of the standard has been extended to included

stainless and high

temperature resistant steels;

f)restrictions on the corrosion resistance properties have

been added;

修訂

本標準不同於DIN 267-28:2004-01和DIN 267-28,更正1:2004-11如下：

1.勘誤表1已被納入

2.成品的明亮度和塗層表面已經在標準中進行了規定;

3.規範性引用檔已被修改和更新

4.已經添加了指定示例;

5.標準的應用範圍已經擴大到包括不銹鋼和耐高溫鋼;

6.抗腐蝕特性的限制也被加入進去

Previous editions

以前的版本

DIN 267-28:1990-03, 2004-01

DIN 267-28 Corrigendum 1:2004-11

1 Scope

1 範圍

This standard specifies functional characteristics of locking

coatings applied on steel screws, bolts and studs (“bolts” for

short)

本標準規定了應用於鋼鐵螺釘，螺栓和螺柱（簡稱“螺栓”）上的鎖附塗料的功能特性

—with ISO metric screw thread as in DIN ISO 261,

符合DIN ISO 261規範的ISO公制螺紋

with a nominal thread diameter between 3 mm and 16 mm

(coarse-pitch),

標準螺紋直徑在3毫米和16毫米（粗牙）之間， —with a nominal thread diameter between 8 mm and 16 mm

(fine-pitch),

標準螺紋直徑在8毫米和16毫米（細牙）之間，

—assigned to property classes in accordance with DIN EN

ISO 898-1, DIN EN ISO 3506-1 and DIN 267-13,

依據DIN EN ISO 898-1, DIN EN ISO 3506-1 和DIN 267-13來劃分合適的等級, —with bright-finished and coated surfaces,

明亮的成品和塗佈表面

—for use at service temperatures ranging from -50℃to

120℃and, for special applications, up to 150℃or 200℃

工作溫度爲-50℃~ 120℃，特殊情況下可以高達到150℃或者200℃

This standard does not specify any requirements for further

machining of the thread in order to incorporate a locking device.

本標準沒有規定進一步加工螺紋的任何要求

2 Normative references

2規範性引用檔

The following references are indispensable for the

application of this document. For dated references, only the

edition cited applies. For undated references, the latest edition of

the referenced document (including any amendments) applies.

接下來的引用的應用文件是必不可少。凡是注日期的引用，只有被引用的版本才適用。凡是不注日期的引用，只有最新的引用檔版本（包括任何修改）才適用。DIN 267-13, Fasteners-Technical

delivery conditions-Part 13: Parts for bolted connections with

specific mechanical properties for use at temperatures ranging

from

-200℃to +700℃

DIN 267-13緊固件交負技術條件第13部分：螺栓零部件在-200℃~+700℃下的使用的具體的機械性能 DIN EN 20273. Fasteners-Clearance holes for bolts and

screws

DIN EN 20273. 螺栓和螺絲緊固件通孔

DIN EN ISO 898-1, Mechanical properties of fasteners made

of carbon steel and alloy steel--Part 1: Bolts, screws and studs

DIN EN ISO 898-1,碳素鋼和合金鋼制緊固件的機械性能- 第1部分：螺栓，螺釘和螺柱

DIN EN ISO 3506-1, Mechanical properties of corrosion-resistant stainless steel fasteners-Part 1: Bolts, screws and studs .

DIN EN ISO 3506-1, 耐腐蝕不銹鋼緊固件的機械性能-第1部分：螺栓，螺釘和螺柱

DIN EN ISO 4032, Hexagon nut, style 1-Product grades A and

B

DIN EN ISO 4032,六角螺母，類別1-產品等級A和B

DIN EN ISO 4753, Fasteners-Ends of parts with external ISO

metric thread

DIN EN ISO 4753, ISO公制外螺紋

DIN EN ISO 7089, Plain washers-Normal series-Product

grade A

DIN EN ISO 7089, 平墊片-標準系列-產品等級A

DIN EN ISO 8673, Hexagon nut, style 1, with metric fine-pitch

thread-Product grades A and B

DIN EN ISO 8673, 六角螺帽，類型1，公制細-牙螺紋-產品等級A和B

DIN ISO 261, ISO general purpose metric screw threads-General plan

DIN ISO 261, ISO 通用的公制螺紋-總體規劃

ISO 4017, Hexagon head screws-Product grades A and B

ISO 4017, 六角頭螺絲-產品等級A和B

3 Terms and definitions 3術語和定義

For the purposes of this document, the following terms and

definitions apply:

針對本檔的目的，接下來的術語和定義會被用到。

3.1

locking coating

防鬆塗料

adhesive coating which is designed to prevent

disengagement when the bolt is tightened. The bolt may be

coated over its whole circumference (R) or the coating applied

locally as strips or spots (F)

塗膠是為了防止當螺釘被鎖緊時螺釘鬆動。螺釘可能被塗超過它的整個周長（R）或者塗料局部的被用作帶或者點（F）

3.2

screw-in torque

旋入扭矩

M in

torque measured when a bolt is driven into a test nut

扭矩在螺釘旋入一個測試螺帽時被測量

3.3

tightening torque

鎖緊扭矩

M A

torque required to generate the required preload

扭矩要求產生必須的預緊力

3.4

loosening torque

鬆動扭矩

M out

torque measured after the breakaway point when
