高定向热解石墨（HOPG）是人工生长的一种石墨，其碳平面几乎完 美地沿其垂直方向堆叠，然而沿着石墨平面内，晶粒仍然存在任意 取向但非常小。
做计算 找华算
石墨的拉曼光谱
（1）结构不同，拉曼光谱不同 （2）G-band(~1580cm-1)是由碳环或长链中
的所有sp2原子对的拉伸运动产生的。 （3）缺陷和无序诱导D-band（~1360cm-1）的 产生。 （4）一般我们用D峰与G峰的强度比来衡量碳 材料的无序度。
做计算 找华算
2D-BAND
层 数 依 赖 性
激发光能量依赖性
1. e excitation
2. e-phonon scattering
3. Phonon with opposite momentum 4. E-hole recombination
做计算 找华算
石墨的拉曼光谱
不同点不同偏振方向的 拉曼光谱 （a）完美石墨晶体 （b）有缺陷的石墨
是armchair,一个是zigzag。当夹角是60°和120°时，有相同的手性。
做计算 找华算
一维碳材料--碳纳米管
碳纳米管(Carbon nanotube)是1991年才被发现的一种碳结构。 理想纳米碳管是由碳原子形成的石墨烯片层卷成的无缝、中空的管体 SWNT的直径一般为1－6 nm，最小直径大约为0.5 nm，直径大于6nm 以后特别不稳定，会发生SWNT管的塌陷，长度则可达几百纳米到几个微米 MWNT的层间距约为0.34纳米，直径在几个纳米到几十纳米，长度一般在微 米量级，最长者可达数毫米 碳纳米管中的碳原子以sp2杂化，但是由于存在一定曲率 所以其中也有一小部分碳属sp3杂化 Hundreds of species depend on how it is folded.
