1RatingValueUnits
Power Sup ply and All In put/Out put Pins-0.3 to +4.0V
Non-Operating Case Tem per ature-50 to +100oC
Soldering Tem per ature (10 seconds)250oCCharacteristicSymNotesMinimumTypicalMaximumUnits
Operating Frequency RangefO403.35403.65MHz
Frequency Drift, -10 to 45 oC, 2.2 to 3.7 Vdc±100ppm
Modulation TypeOOK/ASK
OOK Data Rate30kbps
ASK Data Rate115.2kbps
Receiver Performance, High Sensitivity Mode
Sensitivity, 2.4 kbps, 10-3 BER, AM Test Method1-109dBm
Sensitivity, 2.4 kbps, 10-3 BER, Pulse Test Method1-103dBm
Cur
rent, 2.4 kbps (RPR = 330 K)23.0mA
Sen
sitivity, 19.2 kbps, 10-3 BER, AM Test Method1-105dBm
Sensitivity, 19.2 kbps, 10-3 BER, Pulse Test Method1-99dBm
Current, 19.2 kbps (RPR = 330 K)23.1mA
Sensitivity, 115.2 kbps, 10-3 BER, AM Test Method1-101dBm
Sensitivity, 115.2 kbps, 10-3 BER, Pulse Test Method1-95dBm
Current, 115.2 kbps3.8mA
Receiver Performance, Low Current Mode
Sensitivity, 2.4 kbps, 10-3 BER, AM Test Method1-104dBm
Sensitivity, 2.4 kbps, 10-3 BER, Pulse Test Method1-98dBm
Current, 2.4 kbps (RPR = 1100 K)21.8mA
Receiver Out-of-Band Rejection, ±5% fOR±5%380dBElectrical Char ac ter is tics (typical values given for 3.0 Vdc power supply, 25 oC)Absolute Max imum Ratings• Designed for Short-Range Wireless Med ical Data Communications
• Sup ports RF Data Transmission Rates Up to 115.2 kbps
• 3 V, Low Cur rent Operation plus Sleep Mode TR3005
403.50 MHz
Hybrid
TransceiverThe TR3005 ul tra-miniature hy brid trans ceiver is ideal for short-range wireless med ical data ap -
plications where robust operation, small size, low power consumption and low cost are required.
The TR3005 em ploys RFM’s amplifier-sequenced hybrid (ASH) architecture to achieve this
unique blend of characteristics. All crit ical RF functions are con tained in the hy brid, sim pli fy ing
and speed ing design-in. The re ceiver sec tion of the TR3005 is sensitive and stable. A wide dy -
namic range log de tec tor, in combination with dig ital AGC and a com pound data slicer, pro vide
ro bust per for mance in the presence of on-channel interference or noise. Two stages of SAW fil -
tering pro vide excellent receiver out-of-band re jec tion. The transmitter includes provi sions for
both on-off keyed (OOK) and amplitude-shift keyed (ASK) modulation. The transmitter em ploys
SAW fil ter ing to suppress out put harmonics.元器件交易网www.cecb2b.com
2Electrical Char ac ter is tics (typical values given for 3.0 Vdc power supply, 25 oC)
3
4
5
6
7
9
1112131415161719ASHTransceiverPinOut
RFIO
82
10201
18
LPFADJ
RREFTHLD2AGCCAP
PKDET
BBOUT
CMPIN
RXDATA
TXMODTHLD1PRATEPWIDTHGND1
VCC1
GND2VCC2GND3
CNTRL0
CNTRL1Notes:
1. Typical sen si tiv ity data is based on a 10-3 bit er ror rate (BER), us ing DC-balanced data. There are two test meth ods commonly used to
mea
sure OOK/ASK receiver sensitivity, the “100% AM” test method and the “Pulse” test method. Sensitivity data is given for both test meth -
ods. See Ap pen dix 3.8 in the ASH Trans ceiver De signer’s Guide for the details of each test method, and for sensitivity curves for a 2.2 to
3.7 V supply voltage range at five operating temperatures. The ap pli ca tion/test circuit and com po nent val ues are shown on the next page and
in the De signer’s Guide.
2. At low data rates it is possible to adjust the ASH pulse gen er ator to trade-off some re ceiver sensitivity for lower operating cur rent. Sensitiv -
ity data and re ceiver cur rent are given at 2.4 kbps for both high sensitivity operation (RPR = 330 K) and low cur rent op er ation (RPR = 1100 K).
3. Data is given with the ASH radio matched to a 50 ohm load. Matching component values are given on the next page.
4. See Ta ble 1 on Page 8 for ad di tional information on ASH radio event timing.
CharacteristicSymNotesMinimumTypicalMaximumUnits
Transmitter Performance
Peak RF Output Power, 250 µA TXMOD CurrentPO30dBm
Peak Cur rent, 250 µA TXMOD CurrentITP37.5mA
2nd - 4th Harmonic Output3-50dBm
5th - 10th Harmonic Out puts3-55dBm
Non-harmonic Spu ri ous Outputs3-55dBm
OOK Turn On/Turn Off TimestON/tOFF412/6µs
ASK Output Rise/Fall TimestTR/tTF41.1/1.1µs
Sleep Mode CurrentIS0.7µA
Power Sup ply Volt age RangeVCC2.23.7Vdc
Power Sup ply Volt age Ripple10mVP-P
Ambient Operating Tem per atureTA-1055oC
SM-20HPackageDrawing
CD
E
F
GAB
H
DimensionmmInches
MinNomMaxMinNomMax
A9.88110.03310.135.389.395.400
B6.7316.8586.985.265.270.275
C1.7781.9302.032.070.076.080
D1.6511.7781.905.065.070.075
E0.3810.5080.635.015.020.025
F0.8891.0161.143.035.040.045
G3.1753.3023.429.0125.130.135
H1.3971.5241.651.055.060.065元器件交易网www.cecb2b.com
