ANSYS Workbench 12.1官方中文培训教程

  • 格式：pdf
  • 大小：609.70 KB
  • 文档页数：14
ly 2009 Inventory #002666
Workshop 3 - Results
• You can also plot contours at specific frequencies. • Click RMB on the solution object and >Insert> Stress, Strain, or Deformation
– set the scoping to all faces on the beam – set the Spatial Resolution to Use Maximum – set the Orientation to Y Axis
Training Manual
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
• The Beam (3 m x 0.5 m x 25 mm) is made of Steel.
Constrain (Fix) Both Ends
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-2
July 2009 Inventory #002666
WS3-7
July 2009 Inventory #002666
Workshop 3 - Environment
– – – – – –
Training Manual
• In the Harmonic Response branch, apply one force to one edge.
There are two edges imprinted on the beam face. Switch to Edge selection mode as necessary and >Insert>Force. Use LMB and drag over surface to highlight to pick the applicable edge. Click “Apply” in the Details window In Details, change the “Defined By” to “Components” (i.e., XYZ). Enter 250 for “Y”. Leave Phase Angle = 0
Training Manual
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-5
July 2009 Inventory #002666
Workshop 3 – Modal Results
• Solve the Modal analysis. • Create some Mode Shape Results to review the results.
– note that modes 1 and 2 fall between 0 and 50 Hz
Training Manual
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-6
July 2009 Inventory #002666
WS3-4
July 2009 Inventory #002666
Workshop 3 - Environment
• Constrain both ends of the Beam.
– – – – – Click on the Modal Branch and >Insert>Fixed Support. Switch to edge selection mode as necessary Use LMB to pick the two applicable edges. Hold <CTRL> to add to your selections Click “Apply” in the Details window
Workshop 3 - Preprocessing
Training Manual
• Drag and drop the Fixed Support from the Modal branch to the Harmonic Response branch.
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
• Edit the Model cell to open the Mechanical application.
– verify that the material assignment is Structural Steel
Training Manual
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-9
July 2009 Inventory #002666
Workshop 3 – Harmonic Response Solution
Training Manual
• Edit the Analysis Settings.
– – – – set the Range Minimum to 0 Hz set the Range Maximum to 50 Hz set the Solution Intervals to 50 set the Constant Damping Ratio to 2%
• Solve the Harmonic analysis.
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-10
July 2009 Inventory #002666
Workshop 3 – Results
• Insert a Deformation Frequency Response.
Training Manual
Contours at a specific Frequency
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-12
July 2009 Inventory #002666
Workshop 3 – Results
Workshop 3 – Project Schematic
• From the project schematic, insert a new Modal system.
– we will first look at the natural frequencies and mode shapes of the system
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-8
July 2009 Inventory #002666
Workshop 3 - Environment
• Apply another force to the other edge.
• Import the Geometry file
– beam.agdb
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-3
July 2009 Inventory #002666
Workshop 3 - Preprocessing
Workshop 3 - Goals
Training Manual
• Our goal is to determine the harmonic response of a fixed-fixed beam under the influence of two harmonic forces.
– The forces represent rotating machines mounted at the “one-third” points along the beam. – The machines rotate at 300 to 1800 RPM.
Training Manual
– set Y Component to 250 N – leave Phase Angle = 0 – We will investigate the results as the phase angle between these loads changes.
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
– This will insert the result object(s) – Step thru the Details for each and specify the Geometry and other details. – It is necessary to specify a specific frequency and phase angle.
– set the Phase Angle to 180° – resolve the Harmonic Response
Training Manual
ANSYS, Inc. Proprietary © 2009 ANSYS, Inc. All rights reserved.
WS3-14
July 2009 Inventory #002666
