Freescale Semiconductor Data Sheet: Technical DataDocument Number: MC9S08LG32Rev. 7, 8/2009Freescale reserves the right to change the detail specifications as may be required to permitimprovements in the design of its products.MC9S08LG3280-LQFPCase 917A14 mm × 14 mm64-LQFP Case 840F10 mm × 10 mm48-LQFP Case 9327 mm × 7mm Features •8-bit HCS08 Central Processor Unit (CPU)–Up to 40 MHz CPU at 5.5 V to 2.7 V across temperaturerange of –40 °C to 85 °C and –40 °C to 105 °C–HCS08 instruction set with added BGND instruction–Support for up to 32 interrupt/reset sources•On-Chip Memory–32 KB or 18 KB dual array flash; read/program/eraseover full operating voltage and temperature–1984 byte random access memory (RAM)–Security circuitry to prevent unauthorized access toRAM and flash contents•Power-Saving Modes–Two low-power stop modes (stop2 and stop3)–Reduced-power wait mode–Peripheral clock gating register can disable clocks tounused modules, thereby reducing currents–Low power on-chip crystal oscillator (XOSC) that canbe used in low-power modes to provide accurate clocksource to real time counter and LCD controller–100 μs typical wakeup time from stop3 mode•Clock Source Options–Oscillator (XOSC) — Loop-control Pierce oscillator;crystal or ceramic resonator range of 31.25 kHz to38.4kHz or 1 MHz to 16 MHz–Internal Clock Source (ICS) — Internal clock sourcemodule containing a frequency-locked-loop (FLL)controlled by internal or external reference; precisiontrimming of internal reference allows 0.2% resolutionand 2% deviation over temperature and voltage; supportsbus frequencies from 1 MHz to 20 MHz.•System Protection–COP reset with option to run from dedicated 1 kHzinternal clock or bus clock–Low-voltage warning with interrupt–Low-voltage detection with reset–Illegal opcode detection with reset–Illegal address detection with reset–Flash and RAM protection•Development Support–Single-wire background debug interface–Breakpoint capability to allow single breakpoint settingduring in-circuit debugging (plus two more breakpoints in on-chip debug module)–On-chip in-circuit emulator (ICE) debug module containing three comparators and nine trigger modes; eight deep FIFO for storing change-of-flow addresses and event-only data; debug module supports both tag and force breakpoints •Peripherals –LCD — Up to 4 × 41 or 8 × 37 LCD driver with internal charge pump.–ADC — Up to 16-channel, 12-bit resolution; 2.5 μs conversion time; automatic compare function; temperature sensor; internal bandgap reference channel; runs in stop3 and can wake up the system; fully functional from 5.5 V to 2.7 V –SCI — Full duplex non-return to zero (NRZ); LIN master extended break generation; LIN slave extended break detection; wakeup on active edge –SPI — Full-duplex or single-wire bidirectional; double-buffered transmit and receive; master or slave mode; MSB-first or LSB-first shifting –IIC — With up to 100 kbps with maximum bus loading; multi-master operation; programmable slave address; interrupt driven byte-by-byte data transfer; supports broadcast mode and 10-bit addressing –TPMx — One 6 channel and one 2 channel; selectable input capture, output compare, or buffered edge or center-aligned PWM on each channel –MTIM — 8-bit counter with match register; four clock sources with prescaler dividers; can be used for periodic wakeup –RTC — 8-bit modulus counter with binary or decimal based prescaler; three clock sources including one external source; can be used for time base, calendar, or task scheduling functions –KBI — One keyboard control module capable of supporting 8 × 8 keyboard matrix –IRQ — External pin for wakeup from low-power modes •Input/Output –39, 53, or 69 GPIOs –8 KBI and 1 IRQ interrupt with selectable polarity –Hysteresis and configurable pullup device on all input pins; configurable slew rate and drive strength on all output pins.•Package Options–48-pin LQFP, 64-pin LQFP, and 80-pin LQFP MC9S08LG32 SeriesCovers: MC9S08LG32 and MC9S08LG16Table of Contents1Pin Assignments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 2Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . .102.1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102.2Parameter Classification. . . . . . . . . . . . . . . . . . . . . . . .102.3Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . .102.4Thermal Characteristics . . . . . . . . . . . . . . . . . . . . . . . .112.5ESD Protection and Latch-Up Immunity. . . . . . . . . . . .122.6DC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . .132.7Supply Current Characteristics. . . . . . . . . . . . . . . . . . .172.8External Oscillator (XOSC) Characteristics . . . . . . . . .222.9Internal Clock Source (ICS) Characteristics. . . . . . . . .242.10ADC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . .252.11AC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . .292.11.1Control Timing. . . . . . . . . . . . . . . . . . . . . . . . . .292.11.2TPM Module Timing . . . . . . . . . . . . . . . . . . . . .302.11.3SPI Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . .312.12LCD Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .342.13Flash Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .342.14EMC Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . .352.14.1Radiated Emissions. . . . . . . . . . . . . . . . . . . . . .352.14.2Conducted Transient Susceptibility . . . . . . . . . .35 3Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .383.1Device Numbering System. . . . . . . . . . . . . . . . . . . . . .39 4Package Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .394.1Mechanical Drawings . . . . . . . . . . . . . . . . . . . . . . . . . .394.1.180-pin LQFP . . . . . . . . . . . . . . . . . . . . . . . . . . .404.1.264-pin LQFP . . . . . . . . . . . . . . . . . . . . . . . . . . .434.1.348-pin LQFP . . . . . . . . . . . . . . . . . . . . . . . . . . .46 5Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 List of FiguresFigure1.MC9S08LG32 Series Block Diagram . . . . . . . . . . . . . . 3 Figure2.80-Pin LQFP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Figure3.64-Pin LQFP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Figure4.48-Pin LQFP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Figure5.T ypical Low-side Drive (sink) characteristics – High Drive (PTxDSn = 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Figure6.T ypical Low-side D rive (sink) characteristics – Low D rive (PTxDSn = 0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Figure7.T ypical High-side D rive (source) characteristics – High Drive (PTxDSn = 1). . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Figure8.T ypical High-side Drive (source) characteristics – Low Drive (PTxDSn = 0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Figure9.T ypical Run I DD for FBE Mode at 1 MHz. . . . . . . . . . . 19 Figure10.T ypical Run I DD for FBE Mode at 20 MHz. . . . . . . . . 20 Figure11.T ypical Run I DD for FEE Mode at 1 MHz. . . . . . . . . . 20 Figure12.T ypical Run I DD for FEE Mode at 20 MHz. . . . . . . . . 21 Figure13.T ypical Stop2 I DD. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Figure14.T ypical Stop3 I DD. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Figure15.T ypical Crystal or Resonator Circuit: High Range and Low Range/High Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Figure16.T ypical Crystal or Resonator Circuit: Low Range/Low Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Figure17.Internal Oscillator Deviation from Trimmed Frequency 25 Figure18.ADC Input Impedance Equivalency Diagram. . . . . . . 26 Figure19.Reset Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Figure20.IRQ/KBIPx Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Figure21.Timer External Clock . . . . . . . . . . . . . . . . . . . . . . . . . 30 Figure22.Timer Input Capture Pulse. . . . . . . . . . . . . . . . . . . . . 30 Figure23.SPI Master Timing (CPHA = 0) . . . . . . . . . . . . . . . . . 32 Figure24.SPI Master Timing (CPHA =1). . . . . . . . . . . . . . . . . . 32 Figure25.SPI Slave Timing (CPHA = 0) . . . . . . . . . . . . . . . . . . 33 Figure26.SPI Slave Timing (CPHA = 1) . . . . . . . . . . . . . . . . . . 33 Figure27.4MHz, Positive Polarity Pins 1 – 41 . . . . . . . . . . . . . 36 Figure28.4MHz, Positive Polarity Pins 42 – 80 . . . . . . . . . . . . 36 Figure29.4MHz, Negative Polarity Pins 1 – 41. . . . . . . . . . . . . 37 Figure30.4MHz, Negative Polarity Pins 42 – 80. . . . . . . . . . . . 37 Figure31.Device Number Example for Auto Parts. . . . . . . . . . . 39 Figure32.Device Number Example for IMM Parts. . . . . . . . . . . 39 Figure33.80-pin LQFP Package D rawing (Case 917A, D oc #98ASS23237W). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Figure34.64-pin LQFP Package D rawing (Case 840F, D oc #98ASS23234W). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Figure35.48-pin LQFP Package rawing (Case 932, oc #98ASH00962A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 List of TablesT able1.MC9S08LG32 Series Features by MCU and Package . 4 T able2.Pin Availability by Package Pin-Count. . . . . . . . . . . . . . 8 T able3.Parameter Classifications . . . . . . . . . . . . . . . . . . . . . . 10 T able4.Absolute Maximum Ratings. . . . . . . . . . . . . . . . . . . . . 11 T able5.Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . 11 T able6.ESD and Latch-Up Test Conditions. . . . . . . . . . . . . . . 12 T able7.ESD and Latch-Up Protection Characteristics. . . . . . . 13 T able8.DC Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 T able9. Supply Current Characteristics. . . . . . . . . . . . . . . . . . 17 T able10.Oscillator Electrical Specifications (Temperature Range =–40 °C to 105 °C Ambient) . . . . . . . . . . . . . . . . . . . . . 22 T able11.ICS Frequency Specifications (Temperature Range =–40°C to 105 °C Ambient) . . . . . . . . . . . . . . . . . . . . . 24 T able12.12-bit ADC Operating Conditions . . . . . . . . . . . . . . . . 25 T able13.12-bit AD C Characteristics (V REFH = V DDAD, V REFL= V SSAD). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 T able14.Control Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 T able15.TPM Input Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 T able16.SPI Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 T able17.LCD Electricals, 3 V Glass . . . . . . . . . . . . . . . . . . . . . 34 T able18.Flash Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . 34 T able19.Radiated Emissions, Electric Field . . . . . . . . . . . . . . . 35 T able20.Conducted Susceptibility, EFT/B. . . . . . . . . . . . . . . . . 35 T able21.Susceptibility Performance Classification . . . . . . . . . . 38 T able22.Device Numbering System . . . . . . . . . . . . . . . . . . . . . 38 T able23.Package Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . 39 T able24.Revision History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48Figure 1. MC9S08LG32 Series Block Diagram8-BIT KEYBOARD INTERRUPT (KBI )IIC MODULE (IIC )SERIAL PERIPHERAL INTERFACE (SPI )USER FLASH B USER RAM ON-CHIP ICE (ICE ) and DEBUG MODULE (DBG )(LG32 = 16K BYTES)HCS08 CORE CPUBKGD INTBKP2-CHANNEL TIMER/PWM(TPM1)HCS08 SYSTEM CONTROL RESETS AND INTERRUPTS MODES OF OPERA TION POWER MANAGEMENTIRQLVDLOW-POWER OSCILLA TORINTERNAL CLOCK Source (ICS )SERIAL COMMUNICA TIONS6-CHANNEL TIMER/PWM(TPM2)V LL3(LCD)V LL1V LL2V CAP1V CAP2LCD[44:0]V SS V DD VOLTAGE REGULATORUSER FLASH A (LG16 = 2K BYTES)LCD28/ADC5/TPMCLK /PTA7LCD27/ADC4/TPM2CH1/KBI7/PTA6LCD25/ADC2/RX2/KBI5/PTA4INTERFACE (SCI1)TxD1RxD1SSSPSCK SCLSDA MOSIMISO V SSA /V REFLV DDA /V REFH XT ALEXTALIRQKBI[7:0]P O R T ARESET LIQUID CRYST AL DISPLAY DRIVERANALOG-TO-DIGITAL CONVERTER (ADC )12-BITAD[15:0]TPM2CH[5:0]TPMCLK TPMCLKLCD24/ADC1/TX2/KBI4/PTA3LCD23/ADC0/SDA/PTA2LCD22/SCL/PTA1LCD21/PTA0(LG32 = 16K BYTES)(LG16 = 16K BYTES)LCD26/ADC3/TPM2CH0/KBI6/PTA5BKGD/MSTPM1CH[1:0]COPReal Time Counter(RTC )TMRCLKSERIAL COMMUNICA TIONSINTERFACE (SCI2)TxD2RxD2P O R T CEXTAL/PTF7XT AL/PTF6TPM2CH4/KBI1/MISO /PTF4P O R T FTPM2CH5/KBI0/SS/PTF3ADC14/IRQ/TPM1CH1/SPSCK/PTF2ADC13/TPM1CH0/RX1/PTF1ADC12/TPM2CH2/KBI3/TX1/PTF0TPM2CH3/KBI2/MOSI/PTF5SPSCK/SDA/TPM2CH1/PTI4P O R T IMOSI/TPM2CH2/PTI3MISO/TPM2CH3/PTI2TX2/TMRCLK/PTI1RX2/PTI0SS/SCL/TPM2CH0/PTI5P O R T D P O R T ELCD[40:37]/PTB[7:4]LCD[32:29]/PTB[3:0]LCD[7:0]/PTD[7:0]P O R T B LCD[15:8]/PTE[7:0]LCD[44:41]/PTG[7:4]LCD[36:33]/PTG[3:0]P O R T GADC11/TPM1CH0/KBI3/TX1/PTH5ADC10/TPM1CH1/KBI2/RX1/PTH4ADC[9:6]/KBI[7:4]/PTH[3:0]TPM2CH4/KBI1/PTH7ADC15/KBI0/TPM2CH5/PTH6P O R T H V SS2V LL3_2Available only on 80-pin packageAvailable only on 64-pin and 80-pin package */Default function out of reset /*BKGD/MS /PTC5RESET /PTC6Modulo Timer (MTIM )1984 BYTESLCD[20:16]/PTC[4:0]Pin Assignments1Pin AssignmentsThis section shows the pin assignments for the MC9S08LG32 series devices. The priority of functions on a pin is in ascending order from left to right and bottom to top. Another view of pinouts and function priority is given in Table 2.Table 1. MC9S08LG32 Series Features by MCU and PackageFeatureMC9S08LG32MC9S08LG16Flash size (bytes)32,76818,432RAM size (bytes)1984Pin quantity 8064486448ADC 16 ch 12 ch 9 ch 12 ch 9 ch LCD 8 x 374 x 418 x 294 x 338 x 214 x 258 x 294 x 338 x 214 x 25ICE + DBG yes ICS yes IIC yes IRQ yes KBI 8 pin GPIOs 6953395339RTC yes MTIM yes SCI1yes SCI2yes SPIyes TPM1 channels 2TPM2 channels 6XOSCyesPin AssignmentsFigure 2. 80-Pin LQFPNOTEV REFH /V REFL are internally connected to V DDA /V SSA .1234567891011121314151617181920212223242526272829303132333435363738394080-Pin LQFPP T E 0/L C D 8P T E 1/L C D 9P T E 2/L C D 10P T E 3/L C D 11P T E 4/L C D 12P T E 5/L C D 13P T G 0/L C D 33P T G 1/L C D 34P T G 4/L C D 41P T G 5/L C D 42P T G 6/L C D 43P T G 7/L C D 44V L L 3_2V S S 2P T E 6/L C D 14P T E 7/L C D 15P T C 0/L C D 16P T C 1/L C D 17P T C 2/L C D 18P T C 3/L C D 19PTD7/LCD7PTD6/LCD6PTD5/LCD5PTD4/LCD4PTD3/LCD3PTD2/LCD2PTB3/LCD32PTB2/LCD31PTB7/LCD40PTB6/LCD39PTB5/LCD38PTB4/LCD37PTB1/LCD30PTB0/LCD29PTD1/LCD1PTD0/LCD0V CAP1V CAP2V LL1V LL2V L L 3P T F 5/M O S I /K B I 2/T P M 2C H 3P T F 4/M I S O /K B I 1/T P M 2C H 4P T I 5/T P M 2C H 0/S C L /S S P T I 4/T P M 2C H 1/S D A /S P S C K P T I 3/T P M 2C H 2/M O S I P T I 2/T P M 2C H 3/M I S O P T I 1/T M R C L K /T X 2P T I 0/R X 2P T H 7/K B I 1/T P M 2C H 4V S SV D DP T F 7/E X T A L P T F 6/X T A L V D D A /V R E F HV S S A /V R E F LP T H 6/T P M 2C H 5/K B I 0/A D C 15P T F 2/S P S C K /T P M 1C H 1/I R Q /A D C 14P T F 1/R X 1/T P M 1C H 0/A D C 13P T F 0/T X 1/K B I 3/T P M 2C H 2/A D C 126059585756555453525150494847464544434241PTC4/LCD20PT A0/LCD21PTG2/LCD35PTG3/LCD36PT A1/SCL/LCD22PT A2/SDA/ADC0/LCD23PT A3/KBI4/TX2/ADC1/LCD24PT A4/KBI5/RX2/ADC2/LCD25PT A5/KBI6/TPM2CH0/ADC3/LCD26PT A6/KBI7/TPM2CH1/ADC4/LCD27PT A7/TPMCLK/ADC5/LCD28PTC5/BKGD/MS PTH0/KBI4/ADC6PTH1/KBI5/ADC7PTH2KBI6/ADC8PTH3/KBI7/ADC9PTH4/RX1/KBI2/TPM1CH1/ADC10PTH5/TX1/KBI3/TPM1CH0/ADC118079787776757473727170696867666564636261Pin AssignmentsFigure 3. 64-Pin LQFPNOTEV REFH /V REFL are internally connected to V DDA /V SSA .123456789101112131415161718192021222324252627282930313264-Pin LQFPP T E 0/L C D 8P T E 1/L C D 9P T E 2/L C D 10P T E 3/L C D 11P T E 4/L C D 12P T E 5/L C D 13P T G 0/L C D 33P T G 1/L C D 34V L L 3_2V S S 2P T E 6/L C D 14P T E 7/L C D 15P T C 0/L C D 16P T C 1/L C D 17P T C 2/L C D 18P T C 3/L C D 19PTD7/LCD7PTD6/LCD6PTD5/LCD5PTD4/LCD4PTD3/LCD3PTD2/LCD2PTB3/LCD32PTB2/LCD31PTB1/LCD30PTB0/LCD29PTD1/LCD1PTD0/LCD0V CAP1V CAP2V LL1V LL2V L L 3P T F 5/M O S I /K B I 2/T P M 2C H 3P T F 4/M I S O /K B I 1/T P M 2C H 4P T I 5/T P M 2C H 0/S C L /S S P T I 4/T P M 2C H 1/S D A /S P S C K P T H 7/K B I 1/T P M 2C H 4V S SV D DP T F 7/E X T A L P T F 6/X T A L V D D A /V R E F HV S S A /V R E F LP T H 6/T P M 2C H 5/K B I 0/A D C 15P T F 2/S P S C K /T P M 1C H 1/I R Q /A D C 14P T F 1/R X 1/T P M 1C H 0/A D C 13P T F 0/T X 1/K B I 3/T P M 2C H 2/A D C 124847464544434241403938373635343364636261605958575655545352515049PTC4/LCD20PT A0/LCD21PTG2/LCD35PTG3/LCD36PT A1/SCL/LCD22PT A2/SDA/ADC0/LCD23PT A3/KBI4/TX2/ADC1/LCD24PT A4/KBI5/RX2/ADC2/LCD25PT A5/KBI6/TPM2CH0/ADC3/LCD26PT A6/KBI7/TPM2CH1/ADC4/LCD27PT A7/TPMCLK/ADC5/LCD28PTC5/BKGD/MS PTC6/RESETPTH4/RX1/KBI2/TPM1CH1/ADC10PTH5/TX1/KBI3/TPM1CH0/ADC11PTF3/SS/KBI0/TPM2CH5Pin AssignmentsFigure 4. 48-Pin LQFPNOTEV REFH /V REFL are internally connected to V DDA /V SSA .PTD0/LCD012345678PTD3/LCD3V D D A /V R E F HP T F 6/X T A LV D DV S S P T F 4/M I S O /K B I 1/T P M 2C H 4P T F 5/M O S I /K B I 2/T P M 2C H 3PT A7/TPMCLK/ADC5/LCD28PTC6/RESETP T C 2/L C D 18P T E 7/L C D 15P T C 0/L C D 16P T C 1/L C D 173130292827261415171819373839132425364891011V CAP112V LL2V S S A /V R E F L20P T F 2/S P S C K S /T P M 1C H 1/I R Q /A D C 1421P T F 1/R X 1/T P M 1C H 0/A D C 132223PTC5/BKGD/MS P T E 6/L C D 1440P T E 5/L C D 1341P T E 4/L C D 1242P T E 3/L C D 1143PTD2/LCD2V CAP2V LL132333435P T E 1/L C D 9474645P T E 2/L C D 1044PTD5/LCD5PTD4/LCD4V L L 3PTF3/SS/KBI0/TPM2CH5P T C 3/L C D 1948-Pin LQFPPTD1/LCD1PTD7/LCD7PTD6/LCD6PT A1/SCL/LCD22PT A2/SDA/ADC0/LCD23PT A3/KBI4/TX2/ADC1/LCD24PT A4/KBI5/RX2/ADC2/LCD25PT A6/KBI7/TPM2CH1/ADC4/LCD27PT A5/KBI6/TPM2CH0/ADC3/LCD26PTC4/LCD20PTA0/LCD21P T E 0/L C D 8P T F 0/T X 1/K B I 3/T P M 2C H 2/A D C 1216P T F 7/E X T A LPin AssignmentsTable2. Pin Availability by Package Pin-CountPackages<-- Lowest Priority --> Highest 806448Port Pin Alt 1Alt 2Alt 3Alt 4 111PTD7LCD7———222PTD6LCD6———333PTD5LCD5———444PTD4LCD4———555PTD3LCD3———666PTD2LCD2———77—PTB3LCD32———88—PTB2LCD31———9——PTB7LCD40———10——PTB6LCD39———11——PTB5LCD38———12——PTB4LCD37———139—PTB1LCD30———1410—PTB0LCD29———15117PTD1LCD1———16128PTD0LCD0———17139V CAP1————181410V CAP2————191511V LL1————201612V LL2————211713V LL3————221814PTF5MOSI KBI2TPM2CH3—231915PTF4MISO KBI1TPM2CH4—2420—PTI5TPM2CH0SCL SS—2521—PTI4TPM2CH1SDA SPSCK—26——PTI3TPM2CH2MOSI——27——PTI2TPM2CH3MISO——28——PTI1TMRCLK TX2——29——PTI0RX2———3022—PTH7KBI1TPM2CH4——312316V SS————322417V DD————332518PTF7EXT AL———342619PTF6XT AL———352720V DDA V REFH———362821V SSA V REFL———3729—PTH6TPM2CH5KBI0ADC15—383022PTF2SPSCK TPM1CH1IRQ ADC14Pin Assignments Table2. Pin Availability by Package Pin-Count (continued)Packages<-- Lowest Priority --> Highest806448Port Pin Alt 1Alt 2Alt 3Alt 4 393123PTF1RX1TPM1CH0ADC13—403224PTF0TX1KBI3TPM2CH2ADC12 413325PTF3SS KBI0TPM2CH5—4234—PTH5TX1KBI3TPM1CH0ADC11 4335—PTH4RX1KBI2TPM1CH1ADC10 44——PTH3KBI7ADC9——45——PTH2KBI6ADC8——46——PTH1KBI5ADC7——47——PTH0KBI4ADC6——483626PTC6RESET———493727PTC5BKGD/MS———503828PT A7TPMCLK ADC5LCD28—513929PT A6KBI7TPM2CH1ADC4LCD27 524030PT A5KBI6TPM2CH0ADC3LCD26 534131PT A4KBI5RX2ADC2LCD25 544232PT A3KBI4TX2ADC1LCD24 554333PT A2SDA ADC0LCD23—564434PT A1SCL LCD22——5745—PTG3LCD36———5846—PTG2LCD35———594735PT A0LCD21———604836PTC4LCD20———614937PTC3LCD19———625038PTC2LCD18———635139PTC1LCD17———645240PTC0LCD16———655341PTE7LCD15———665442PTE6LCD14———6755—V SS2————6856—V LL3_2————69——PTG7LCD44———70——PTG6LCD43———71——PTG5LCD42———72——PTG4LCD41———7357—PTG1LCD34———7458—PTG0LCD33———755943PTE5LCD13———766044PTE4LCD12———Electrical Characteristics2Electrical Characteristics2.1IntroductionThis section contains electrical and timing specifications for the MC9S08LG32 series of microcontrollers available at the time of publication.2.2Parameter ClassificationThe electrical parameters shown in this supplement are guaranteed by various methods. To give the customer a betterunderstanding the following classification is used and the parameters are tagged accordingly in the tables where appropriate:NOTEThe classification is shown in the column labeled “C” in the parameter tables where appropriate.2.3Absolute Maximum RatingsAbsolute maximum ratings are stress ratings only, and functional operation at the maxima is not guaranteed. Stress beyond the limits specified in Table 4 may affect device reliability or cause permanent damage to the device. For functional operating conditions, refer to the remaining tables in this section.This device contains circuitry that protects against damage due to high static voltage or electrical fields. However, it is advised that normal precautions should be taken to avoid application of any voltages higher than maximum-rated voltages to this high-impedance circuit. Reliability of operation is enhanced if unused inputs are tied to an appropriate logic voltage level (for instance, either V SS or V DD ) or the programmable pull-up resistor associated with the pin is enabled.776145PTE3LCD11———786246PTE2LCD10———796347PTE1LCD9———806448PTE0LCD8———Table 3. Parameter ClassificationsP Those parameters are guaranteed during production testing on each individual device.CThose parameters are achieved by the design characterization by measuring a statistically relevant sample size across process variations.T Those parameters are achieved by design characterization on a small sample size from typical devices under typical conditions unless otherwise noted. All values shown in the typical column are within this category.DThose parameters are derived mainly from simulations.Table 2. Pin Availability by Package Pin-Count (continued)Packages<-- Lowest Priority --> Highest806448Port Pin Alt 1Alt 2Alt 3Alt 4Electrical Characteristics2.4Thermal CharacteristicsThis section provides information about operating temperature range, power dissipation, and package thermal resistance. Power dissipation on I/O pins is usually small compared to the power dissipation in on-chip logic and voltage regulator circuits, and it is user-determined rather than being controlled by the MCU design. To take P I/O into account in power calculations, determine the difference between actual pin voltage and V SS or V DD and multiply by the pin current for each I/O pin. Except in cases of unusually high pin current (heavy loads), the difference between pin voltage and V SS or V DD will be very small.The average chip-junction temperature (T J ) in °C can be obtained from:T J = T A + (P D × θJA )Eqn.1Table 4. Absolute Maximum RatingsRatingSymbol Value Unit Supply voltageV DD –0.3 to +5.8V Maximum current into V DD I DD 120mA Digital input voltageV In –0.3 to V DD +0.3V Instantaneous maximum currentSingle pin limit (applies to all port pins)1,2,31Input must be current limited to the value specified. To determine the value of the required current-limiting resistor, calculate resistance values for positive (V DD ) and negative (V SS ) clamp voltages and use the largest of the two resistance values.2All functional non-supply pins are internally clamped to V SS and V DD .3Power supply must maintain regulation within operating V DD range during instantaneous and operating maximum current conditions. If positive injection current (V In > V DD ) is greater than I DD , the injection current may flow out of V DD and could result in an external power supply going out of regulation. Ensure that the external V DD load will shunt current greater than maximum injection current, this will be of greater risk when the MCU is not consuming power. For instance, If no system clock is present, or if the clock rate is very low (which would reduce overall power consumption).I D ±25±2mA Storage temperature rangeT stg–55 to 150°CTable 5. Thermal CharacteristicsRatingSymbol Value Unit Operating temperature range (packaged)T A T L to T H –40 to +105°C Maximum junction temperature T J125°CThermal resistance Single-layer board 80-pin LQFP 64-pin LQFP 48-pin LQFP θJA617180°C/WThermal resistance Four-layer board80-pin LQFP 64-pin LQFP 48-pin LQFPθJA485256°C/WElectrical Characteristicswhere:T A = Ambient temperature, °CθJA = Package thermal resistance, junction-to-ambient, °C/WP D = P int + P I/OP int = I DD× V DD, Watts — chip internal powerP I/O = Power dissipation on input and output pins — user determinedFor most applications, P I/O<< P int and can be neglected. An approximate relationship between P D and T J (if P I/O is neglected) is:P D = K ÷ (T J + 273 °C)Eqn.2 Solving Equation1 and Equation2 for K gives:K = P D× (T A + 273 °C) + θJA× (P D)2Eqn.3 where K is a constant pertaining to the particular part. K can be determined from equation 3 by measuring P D (at equilibrium) for a known T A. Using this value of K, the values of P D and T J can be obtained by solving Equation1 and Equation2 iteratively for any value of T A.2.5ESD Protection and Latch-Up ImmunityAlthough damage from electrostatic discharge (ESD) is much less common on these devices than on early CMOS circuits, normal handling precautions should be taken to avoid exposure to static discharge. Qualification tests are performed to ensure that these devices can withstand exposure to reasonable levels of static without suffering any permanent damage.All ESD testing is in conformity with AEC-Q100 Stress Test Qualification for automotive grade integrated circuits. During the device qualification, ESD stresses were performed for the human body model (HBM), the machine model (MM) and the charge device model (CDM).A device is defined as a failure if after exposure to ESD pulses the device no longer meets the device specification. Complete DC parametric and functional testing is performed per the applicable device specification at room temperature followed by hot temperature, unless instructed otherwise in the device specification.Table6. ESD and Latch-Up Test ConditionsModel Description Symbol Value UnitHuman BodyModel Series resistance R11500ΩStorage capacitance C100pF Number of pulses per pin—3—Latch-up Minimum input voltage limit—–2.5V Maximum input voltage limit—7.5VElectrical Characteristics2.6DC CharacteristicsThis section includes information about power supply requirements and I/O pin characteristics.Table 7. ESD and Latch-Up Protection CharacteristicsNo.Rating 11Parameter is achieved by design characterization on a small sample size from typical devices under typical conditions unless otherwise noted.Symbol Min Max Unit 1Human body model (HBM)V HBM 2500—V 2Charge device model (CDM)V CDM 750—V 3Latch-up current at T A = 85 °CI LAT±100—mATable 8. DC CharacteristicsNum C Characteristic Symbol Min Typ 1Max Unit 1—Operating Voltage— 2.7— 5.5V 2P Output high voltage — Low Drive (PTxDSn = 0)5 V , I Load = –2 mA 3 V , I Load = –0.6 mAV OHV DD – 0.8V DD – 0.8————VOutput high voltage — High Drive (PTxDSn = 1) V5 V , I Load = –10 mA 3 V , I Load = –3 mAV DD – 0.8V DD – 0.8————3P Output low voltage — Low Drive (PTxDSn = 0)5 V , I Load = 2 mA 3 V , I Load = 0.6 mAV OL———0.80.8VOutput low voltage — High Drive (PTxDSn = 1)5 V , I Load = 10 mA 3 V , I Load = 3 mA——0.80.84P Output high current — Max total I OH for all ports5 V 3 V I OHT——10060mA5C Output high current — Max total I OL for all ports 5 V 3 VI OLT——10060mA6P Bandgap voltage reference V BG — 1.225—V 7P Input high voltage; all digital inputs V IH 0.65 x V DD——V 8P Input low voltage; all digital inputs V IL ——0.35 x V DDV 9P Input hysteresis; all digital inputs V hys 0.06 x V DD——mV 10P Input leakage current; input only pins 2V In = V DD or V SS|I In |—0.11μA 11P High impedence (off-state) leakage currentV In = V DD or V SS|I OZ |—0.11μA 12P Internal pullup resistors 3R PU 204565k Ω13P Internal pulldown resistors 4R PD204565k Ω。

合集下载

Freescale Semiconductor MC9S08QG8应用说明书

Freescale Semiconductor MC9S08QG8应用说明书

Freescale Semiconductor Application Note AN3048Rev. 1.00, 11/2005Table of Contents1Introduction The MC9S08QG8 is a small pin-count, yet feature rich, microcontroller. The properties of this MCU make it ideal for an application such as a stand-alone inter-integrated circuit (IIC) analog-to-digital converter (ADC). This document demonstrates how the MC9S08QG8 can be used as a stand-alone ADC accessed by the IIC. In this demonstration application, commands sent via IIC will select different ADC channels and set a threshold limit to be used for an alarm indicator. 1.1RequirementsTo run this demo, you need:•Two DEMO9S08QG8 demo boards•DEMO9S08QG8 Quick Start Guide (comes with demo board)•MC9S08QG8 data sheet from .•IIC driver code used in this document — available as AN3048SW.zip from .•True-Time Simulator CW3.1 with MC9S08QG8 patchUsing IIC to Read ADC Values on MC9S08QG8by Donnie GarciaApplication EngineeringMicrocontroller Division1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.1Requirements . . . . . . . . . . . . . . . . . . . . . . . . 11.2IIC Features. . . . . . . . . . . . . . . . . . . . . . . . . . 21.3Implementing IIC Communication . . . . . . . . . 21.3.1Master and Slave Initialization . . . . . . . 31.4Defining the Messaging Strategy. . . . . . . . . . 31.4.1Master-to-Slave Communication . . . . . 31.4.2Slave-to-Master Communication . . . . . 32Demonstrating the Stand-Alone ADC Application. 42.1Slave Board. . . . . . . . . . . . . . . . . . . . . . . . . . 42.2Master Board. . . . . . . . . . . . . . . . . . . . . . . . . 42.3Connecting the Demo Boards . . . . . . . . . . . . 52.4Starting the Demonstration . . . . . . . . . . . . . . 53Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6Introduction1.2IIC FeaturesThe IIC communications protocol is a standard that can be used to interface an MCU with other devices such as temperature sensors, EEPROMS, LCDs, other MCUs, and A/D or D/A devices. This protocol makes it easy to add additional devices onto an existing IIC bus because each device contains a unique slave address. All devices on the IIC bus monitor activity, but slaves only respond to messages that are addressed to them. IIC communication is accomplished through a simple two-line interface. Data is relayed through the SDA pin, and the clock is supplied by the master on the SCL pin.The MC9S08QG8 contains the standard IIC module that is in the HCS08 Family of microcontrollers. The features of this module include:•Compatibility with the IIC bus standards•Multi-master operation•Flexible baud rate generator•Interrupt-driven byte-by-byte transferThe interrupt capabilities of this peripheral provide a very important feature that allows interrupts to occur at address match, arbitration loss, and data transfers. All of these features together allow IIC communication to be handled by an interrupt service routine (ISR) that can be used for both master and slave operation.NOTEFor additional information on IIC module initialization, functionality, andregisters and control and status bits, please see the IIC chapter of theMC9S08QG8 data sheet (available from ).1.3Implementing IIC CommunicationThe IIC chapter of the MC9S08QG8 data sheet provides an “IIC Module Quick Start” figure and “Typical IIC Interrupt Routine” flow chart. These detail the most straight-forward method to implement IIC communications. Because the application described in this document uses that method, please have the IIC chapter of the MC9S08QG8 data sheet near for reference.The IIC master and slave code examples for this demonstration (AN3048SW.zip) use the documented method to create the interrupt service routine (ISR) for IIC. For example, the first decision in the “Typical IIC Interrupt Routine” flow chart is whether the device is set as a master or slave. This is accomplished in the example ISR with the code:if (IICC_MST){...} else {...}This checks the status of the MST bit in the IIC control register:•If it is set (MST = 1), the code will proceed to execute what is defined inside the curly brackets,i.e., master mode operation will be handled.•If MST is not set (MST = 0), code will execute the else statement, i.e., slave mode operation will be handled.It is important to note that not all decisions that are defined in this flow chart can be made by the status and control bits that are provided in the IIC registers. For example, when in master mode, you must know when the second-to-last byte and the last byte to be read are received. This is accomplished in the exampleIntroduction ISR by a variable, num_to_rec , which defines the number of bytes to receive. This variable is used to compare against a count variable that keeps track of the amount of data that has passed from slave tomaster. So in the example code provided, you will see that variables are used along with status and control bits to achieve the routine depicted in the IIC chapter of the MC9S08QG8 data sheet.1.3.1Master and Slave InitializationBoth master and slave can use the same ISR routine as shown in the demo code, but there is a difference in the initialization and startup sequence between these two. See the “IIC Module Quick Start” figure in the IIC chapter of the MC9S08QG8 data sheet for complete initialization sequence.As soon as the slave device is initialized, it is ready to receive IIC data. A master device must initiate communication by setting up a master transmit or a master receive. This is done in the addressing sequence because the LSB of the address is the R/W bit. So, to initiate IIC communication, the address along with the R/W bit must be written to the IIC data register by the master device.1.4Defining the Messaging StrategyThe goal of this application is to get an analog reading from a MC9S08QG8 MCU via IIC communication. The master MCU will be allowed to select the ADC channel and set a threshold value that can be used to compare against. A very important step in accomplishing this is defining the messages that will be sent and received. For this application, the following messaging strategy was used.1.4.1Master-to-Slave CommunicationTable 1 shows the messages that will pass from master to slave. All possible values are shown in the data range.1.4.2Slave-to-Master CommunicationTable 2 shows all data that will pass from slave to master. Not shown here is the address that must first pass from master to slave; all IIC communication is initiated by the master.Table 1. Master-to-Slave CommunicationByteAddress (upper 7bits) R/W(1bit)Threshold Threshold Channel Select 1234Data RangeAddress (0xFE–0x00), R/W (0x1–0x0)0x03–0x000xFF–0x000x01–0x00Description Concatenation of addressand read/write Upper byte of a 10-bit threshold Lower byte of a 10-bit threshold A/D channel to be readTable 2. Slave-to-Master CommunicationByteResult Result Alarm 123Data Range0x03-0x000xFF-0x000x01-0x00Description Upper byte of a 10-bitresult Lower byte of a 10-bit result Status of the compare to the thresholdDemonstrating the Stand-Alone ADC ApplicationWith the messaging strategy defined, software development is as simple as parsing the data that is received by the master or slave. The ISR that has been created is pre-configured to create receive arrays with the data. Both slave and master contain a receive data array that can be examined while the IIC bus is inactive. It is important to wait for the IIC bus to be inactive to ensure a valid data reading. The arrays allow easy access to the messages that have been received, and C code is used to look at individual bytes in the receive data array. For example, the Alarm byte is examined with the following code:This code accesses the Alarm byte in the receive data array using an “if”statement. The same method can be used on the other bytes in the receive array so that the application code can complete the necessary tasks.2Demonstrating the Stand-Alone ADCApplicationTo demonstrate this application, you will need to connect and configure the two MC9S08QG8 demo boards. Designate one of the boards to be the master board, and the other as the slave board.2.1Slave BoardProgram the slave code (QG_IIC_Slave.c) into the slave board. Follow the directions for programming the demo board provided by the quick start guide included with the demo board. This should guide you step-by-step through opening a project, connecting through USB, and programming a demo board. This board must be powered externally, so after you have programmed it, connect an external power supply (9V, nominally) to the power connector.2.2Master BoardThe master code should be programmed into the master board. To visualize our demonstration, we will use the True-Time Simulator interface and a visualization tool. So, after the board is programmed, we will be using the debug environment.The master board must be modified to contain pullup resistors on the SDA and SCL pins. The IIC driver code in AN3048SW.zip uses PTB6 and PTB7 as the IIC pins. This is configured in software by setting the IICPS bit in SOPT2. This is a useful feature of the MC9S08QG8 that allows the IIC pins to be switched from PTA2/PTA3 to PTB6/PTB7. For IIC communication to operate, you must connect pullups on the PTB6 and PTB7 pins.Demonstrating the Stand-Alone ADC Application 2.3Connecting the Demo BoardsAfter the pullups have been added to the PTB6 and PTB7 pins on the master board, three connections must be made, as shown in Figure 1:•PTB6, PTB7, and GND must be connected between the two boards.•GND must be connected; connect GND from J1 pin 3 to J1 pin 3 of the slave board.•PTB7 and PTB6 are J1 pins 8 and 10, respectively; connect them as shown in Figure 1.Figure 1. Connecting the Two MC9S08QG8 Demo Boards2.4Starting the Demonstration1.Turn on the slave board by moving the PWR_SEL jumpers to the VDD side.2.Press the green run arrow in the True-Time Simulator to begin the master code (see Figure 2).In the visualization tool, the LED shows the status of the ALARM indicator; the graph is a visual representation of the ADC data. You can switch between channel 1 and channel 0 by pressing the SW1 (channel 0) or SW2 (channel 1) on the master demo board:—When channel 0 is selected, the potentiometer of the slave board is being read.V ary the potentiometer to see the result on the graphical representation (Figure 2) change.—When channel 1 is selected, the photo sensor is being read.Cover the photo sensor to see the graphical representation (Figure 2) change.Master BoardSlave Board •Programmed with slave code (QG_IIC_Slave)•Must be powered externally •Uses PTB6 and PTB7 as IIC pins •Remove jumpers on LED1 and LED2•Programmed with master code (QG_IIC_Master)•Add pullup resistors on SDA and SCL pins, PTB6 and PTB7, respectively •Remove jumpers on LED1 and LED2Conclusion Figure 2. Visualization Tool in True-Time Simulator & Real-Time Debugger3ConclusionThis document and provided application code (AN3048SW.zip) demonstrate how the MC9S08QG8 is well suited for an IIC application. The provided IIC driver code and application example can be used to accelerate understanding of IIC and development time.Green ArrowConclusionHow to Reach Us: Home Page:E-mail:*********************USA/Europe or Locations Not Listed:Freescale SemiconductorTechnical Information Center, CH3701300 N. Alma School RoadChandler, Arizona 85224+1-800-521-6274 or +1-480-768-2130*********************Europe, Middle East, and Africa:Freescale Halbleiter Deutschland GmbHTechnical Information CenterSchatzbogen 781829 Muenchen, Germany+44 1296 380 456 (English)+46 8 52200080 (English)+49 89 92103 559 (German)+33 1 69 35 48 48 (French)*********************Japan:Freescale Semiconductor Japan Ltd.HeadquartersARCO Tower 15F1-8-1, Shimo-Meguro, Meguro-ku,Tokyo 153-0064Japan0120 191014 or +81 3 5437 9125***************************Asia/Pacific:Freescale Semiconductor Hong Kong Ltd.Technical Information Center2 Dai King StreetTai Po Industrial EstateTai Po, N.T., Hong Kong+800 2666 8080**************************For Literature Requests Only:Freescale Semiconductor Literature Distribution Center P.O. Box 5405Denver, Colorado 802171-800-441-2447 or 303-675-2140Fax: 303-675-2150*********************************************Information in this document is provided solely to enable system and software implementers to use Freescale Semiconductor products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits or integrated circuits based on the information in this document.Freescale Semiconductor reserves the right to make changes without further notice to any products herein. Freescale Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does Freescale Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. “Typical” parameters that may be provided in Freescale Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals”, must be validated for each customer application by customer’s technical experts. Freescale Semiconductor does not convey any license under its patent rights nor the rights of others. Freescale Semiconductor products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the Freescale Semiconductor product could create a situation where personal injury or death may occur. Should Buyer purchase or use Freescale Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that Freescale Semiconductor was negligent regarding the design or manufacture of the part. Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners.© Freescale Semiconductor, Inc. 2005. All rights reserved.。

MOTOROLA系列芯片解密

MOTOROLA系列芯片解密

MOTOROLA系列芯片解密MOTOROLA单片机具有片内FLASH，具有FLASH存储器在线编程功能和保密功能(FLASH编程/查处的电压由芯片内部电荷泵产生)，编程后FLASH位将设为0，擦除后FLASH位将为1，FLASH存储器的加密特性可以阻止未经授权的用户查看FLASH存储器中的内容。

以下龙人成功实现技术突破的MOTOROLA单片机型号，目前我们可针对以下单片机型号提供高效可靠的解密服务：24小时服务热线：086-0755-********E-mail：sales@68HC711XX系列68HC711E9MFN2 68HC711E9MFNE2 68HC711E9VFNE268HC711E9VFN2 68HC705C4A 68HC705C468HC705C8 68HC711E9VFN2 68HC705C8A68HC705C9 68HC705C9A 68HC70568HC705J1A 68HC705SR3 ……MC56F8XX系列MC56F8013VFAE MC56F8014VFAE MC56F8023MFAEMC56F8023VFAE MC56F8025VLD MC56F8036MFAEMC56F8036VFAE MC56F8037VLH MC56F8122VFAMC56F8122VFAE MC56F8123VFB MC56F8123VFBEMC56F8322MFA60 MC56F8322MFAE MC56F8322VFA60MC56F8322VFAE MC56F8323MFB60 MC56F8323MFBEMC56F8323VFB60 MC56F8323VFBE ……MC68HC705XX系列MC68HC11P2(2E74J) MC68HC711P2(1E53M) MC68HC705C4MC68HC705C8 MC68HC705C4A MC68HC705C8AMC68HC705C9 MC68HC705C9A MC68HC705SR3MC68HC705 MC68HC705J1A MC68HC705B16MC68HC705X16 MC68HC705B32 MC68HC705X32MC68HC705B6 MC68HC05B8 MC68HC05B16MC68HC705X16 MC68HC05B32 MC68HC05X32MC68HC705H12(0H57A) MC68HC705B16N MC68HC705B5MC68HC705J2 MC68HC705KJ1 MC68HC705P6MC68HC705P9 MC68705R3 MC68705R5MC68705U3 MC68705U5 XC68HC705P6A(CDW)MC68HC11XX系列MC68HC11A8(AB95T) MC68HC11A8(C96N) MC68HC11E9(1B60R)MC68HC11A8(D26E) MC68HC11E20(3E22B) MC68HC11E9(D82R)MC68HC11E9(E22B) MC68HC11E9(E28B) MC68HC11EA9(2D47J)MC68HC11F1(E87J) MC68HC11F1(2F37E) MC68HC11K1(2D58N)MC68HC11K4(1E62H) MC68HC11K4(OE75J) MC68HC11KA4(1E59B)MC68HC11KS4(0E57S) MC68HC11KS2(0H95B) MC68HC11KS4(0F60M)MC68HC11A0 MC68HC11A1 MC68HC11E1MC68HC11P1 ……MC68HC711XX系列MC68HC711E20(1H19S) MC68HC711E9(4K81H) MC68HC711E9(5C47M)MC68HC711K4(K59D) MC68HC711EA9(0D46J) MC68HC711PH8(0H30R)MC68S711E9(5C47M) MC68HC711KS8(1H96P) MC68HC711D3MC68HC711E20 MC68HC711E9 MC68HC711E9CFN2MC68HC711E9CFN(4.5V) MC68HC711E9CFN3 MC68HC711K4MC68HC711E9CFNE2 MC68HC711E9CFNE3 MC68HC711E9-FNMC68HC711KA2 MC68HC711KA4 MC68HC711KS2MC68HC711L6 XC68HC711D3 ……MC68HC81XX系列MC68HC811E2MP2 MC68HC811E2CP2 MC68HC811E2MC68HC811E2P2 MC68HC811E2VP2 MC68HC812A4CPVMC68HC812A4CPVE MC68HC812A4MPV ……MC68HC908XX系列MC68HC908AS60(3J74Y) MC68HC908AZ60(4J74Y) MC68HC908AZ60(2J74Y) MC68HC908AS60A(1L87J) MC68HC908AZ60A(3K85K) MC68HC908AS20(0H94K) MC68HC908AZ60(1J35D) MC68HC908AZ32(0J66D) MC68HC908AZ32(1H56A) MC68H908AZ32A(1L52H) MC68HC908AB32(3K56G) MC68HC908QT3MC68HC908QT1 MC68HC908QT2 MC68HC908QT4MC68HC908QY1 MC68HC908QY2 MC68HC908QY3MC68HC908QY4 MC68HC908JK1 MC68HC908JK3MC68HC908AP16CB MC68HC908AB32MFU MC68HC908LK24MC68HC908AB32CFU MC68HC908AP16CFA MC68HC908JK8MC68HC908AP16CFB MC68HC908AP32CB MC68HC908LK24MC68HC908AP32CFA MC68HC908AP32CFB MC68HC908AP64CBMC68HC908AP64CFA MC68HC908AP64CFB MC68HC908AP8CBMC68HC908AP8CFA MC68HC908AP8CFB MC68HC908AS32AMC68HC908BD48IB MC68HC908BD48IFB MC68HC908EY16CFAMC68HC908EY16MFA MC68HC908EY16VFA MC68HC908EY8CFAMC68HC908EY8MFA MC68HC908EY8VFA MC68HC908GP32MC68HC908GR16CFA MC68HC908GR16CFJ MC68HC908GR16MFAMC68HC908GR16MFJ MC68HC908GR16VFA MC68HC908GR4CDWMC68HC908GR16VFJ MC68HC908GR4CFA MC68HC908GR4CPMC68HC908GR4MDW MC68HC908GR4MFA MC68HC908GR4MPMC68HC908GR4VDW MC68HC908GR4VFA MC68HC908GR4VPMC68HC908GR8CDW MC68HC908GR8CFA MC68HC908GR8CPMC68HC908GR8MDW MC68HC908GR8MFA MC68HC908GR8MPMC68HC908GR8VDW MC68HC908GR8VFA MC68HC908GR8VPMC68HC908GT16 MC68HC908GT8CB MC68HC908GT8CFBMC68HC908GZ16 MC68HC908GZ32 MC68HC908GZ48MC68HC908GZ60 MC68HC908GZ8 MC68HC908JB12MC68HC908JB16 MC68HC908JK1ECDW MC68HC908JB8MC68HC908JK1CDW MC68HC908JK1CP MC68HC908JB8MC68HC908JK1ECP MC68HC908JK1EMDW MC68HC908JK1EMPMC68HC908JK1MDW MC68HC908JK1MP MC68HC908JK3CDWMC68HC908JK3CP MC68HC908JK3ECDW MC68HC908JK3ECPMC68HC908JK3EMDW MC68HC908JK3EMP MC68HC908JK3MDW MC68HC908JK3MP MC68HC908JK8 MC68HC908JK8MC68HC908JL3CDW MC68HC908JL3CFA MC68HC908JL3CPMC68HC908JL3ECDW MC68HC908JL3ECFA MC68HC908JL3ECPMC68HC908JL3EMDW MC68HC908JL3EMFA MC68HC908JL3EMP MC68HC908JL3MDW MC68HC908JL3MFA MC68HC908JL3MPMC68HC908LB8CDWE MC68HC908LB8MDWE MC68HC908LB8CPE MC68HC908LB8MPE MC68HC908LB8VDWE MC68HC908JL8MC68HC908LB8VPE MC68HC908LD60IFU MC68HC908KX8MC68HC908LD64IFU MC68HC908LJ12CFB MC68HC908KX2MC68HC908LJ12CFBE MC68HC908LJ12CFU MC68HC908LJ12CFU MC68HC908LJ12CFUE MC68HC908LJ12CPB MC68HC908LJ12CPBE MC68HC908LJ24CFQ MC68HC908LJ24CFQE MC68HC908LJ24CFU MC68HC908LJ24CFUE MC68HC908LJ24CPB MC68HC908LJ24CPBE MC68HC908LJ24CPK MC68HC908LJ24CPKE MC68HC908LK24CFQ MC68HC908LK24CFQE MC68HC908LK24CFU MC68HC908LK24CFUE MC68HC908LK24CPB MC68HC908LK24CPBE MC68HC908QB4MC68HC908LK24CPK MC68HC908LK24CPKE MC68HC908QB8MC68HC908LV8CPBE MC68HC908MR16 MC68HC908MR32MC68HC908QC16 MC68HC908QC4 MC68HC908QC8MC68HC908QT1ACFQE MC68HC908QT1AMFQE MC68HC908QF4 MC68HC908QT1AVFQE MC68HC908QT1CDW MC68HC908QL2MC68HC908QT1CFQ MC68HC908QT1CP MC68HC908QL3MC68HC908QT1MDW MC68HC908QT1MFQ MC68HC908QL4MC68HC908QT1MP MC68HC908QT1VDW MC68HC908QT1VFQMC68HC908QT1VP MC68HC908QT2ACFQE MC68HC908QT2AMFQE MC68HC908QT2AVFQE MC68HC908QT2CFQ MC68HC908QT2CDW MC68HC908QT2CP MC68HC908QT2MDW MC68HC908QT2MFQMC68HC908QT2MP MC68HC908QT2VDW MC68HC908QT2VFQMC68HC908QT4ACFQE MC68HC908QT4AMFQE MC68HC908QT2VP MC68HC908QT4AVFQE MC68HC908QT4CDW MC68HC908QT4CFQ MC68HC908QT4MDW MC68HC908QT4MFQ MC68HC908QT4CPMC68HC908QT4VDW MC68HC908QT4VFQ MC68HC908QT4MPMC68HC908QT4VP MC68HC908QY1CDT MC68HC908QY1CDWMC68HC908QY1CP MC68HC908QY1MDT MC68HC908QY1MDWMC68HC908QY1MP MC68HC908QY1VDT MC68HC908QY1VDWMC68HC908QY2CDT MC68HC908QY2CDW MC68HC908QY2CPMC68HC908QY2MDT MC68HC908QY2MDW MC68HC908QY2MPMC68HC908QY2VDT MC68HC908QY2VDW MC68HC908QY2VPMC68HC908QY4CDT MC68HC908QY4CDW MC68HC908QY4CPMC68HC908QY4MDT MC68HC908QY4MDW MC68HC908QY4MPMC68HC908QY4VDT MC68HC908QY4VDW MC68HC908QY4VPMC68HC908QY8 MC68HC908SR12 MC68HC908RF2XC68HC908MR32 ……MC68HC912XX系列MC68HC912DC128A(3K91D) MC68HC912DC128(0K50E) MC68HC912D60(0K13J) MC68HC912DG128(0K50E) MC68HC912DG128(5H55W) MC68HC912B32(9H91F) MC68HC912D60(0K75F) MC68HC912D60A(2K38K) MC68HC912D60(4F73K)MC68HC912DG128A(3K91D) MC9S12DG128B(0L85D) MC68HC912B32(4J54E) MC68HC912BC32 ……MC68HC9S12XX系列MC9S12DT128B(0L85D) MC9S12DB128B(0L85D) MC9S12A128B(0L85D)MC9S12DG256C(2K79X) MC9S12DT256C(2K79X) MC9S12DT128B(1L85D)MC9S12H128(1K78X) MC9S12DP256C(2K79X) MC9S12H256(1K78X)MC9S12DP512(1L00M) MC9S12DT128B(3L40K) ……MC68HRC908XX系列MC68HRC908JK1CDW MC68HRC908JK1CP MC68HRC908JK1ECPMC68HRC908JK1ECDW MC68HRC908JK1EMDW MC68HRC908JK1EMPMC68HRC908JK1MDW MC68HRC908JK3CDW MC68HRC908JK1MPMC68HRC908JK3CP MC68HRC908JK3ECDW MC68HRC908JK3ECPMC68HRC908JK3EMDW MC68HRC908JK3EMP MC68HRC908JK3MDWMC68HRC908JK3MP MC68HRC908JK8 MC68HRC908JL3CPMC68HRC908JL3CDW MC68HRC908JL3CFA MC68HRC908JL3ECPMC68HRC908JL3ECDW MC68HRC908JL3ECFA MC68HRC908JL3EMDWMC68HRC908JL3EMFA MC68HRC908JL3EMP MC68HRC908JL3MDWMC68HRC908JL3MFA MC68HRC908JL3MP MC68HRC908JL8MC68HSC705XX系列MC68HSC705C8A XC68HSC705C9A ……MC68S711E9XX系列MC68S711E9 ……MC908AXX系列MC908AB32CFUE MC908AP16CBE MC908AP32CBEMC908AP32CFAE MC908AP32CFBE MC908AP64CBEMC908AP64CFAE MC908AP64CFBE MC908AP8CBEMC908AP8CFAE MC908AP8CFBE ……MC908BXX系列MC908BD48IBE MC908BD48IFBE MC908EY16ACFJEMC908EY16ACFJE MC908EY16AKFJE MC908EY16AMFJE MC908EY16AVFJE MC908EY8ACFJE MC908EY8AKFJEMC908EY8AVFJE MC908EY8AMFJE ……MC908JL16XX系列MC908JL16CDWE MC908JL16CFJE MC908JL16CPEMC908JL16CSPE ……MC908QTXX系列MC908QT1ACDWE MC908QT1ACPE MC908QT1AMDWE MC908QT1AMPE MC908QT1AVDWE MC908QT1AVPEMC908QT2ACDWE MC908QT2ACPE MC908QT2AMDWE MC908QT2AMPE MC908QT2AVDWE MC908QT2AVPEMC908QT4ACDWE MC908QT4ACPE MC908QT4AMDWE MC908QT4AMPE MC908QT4AVDWE MC908QT4AVPEMC908QYXX系列MC908QY1ACDTE MC908QY1ACDWE MC908QY1ACPEMC908QY1AMDTE MC908QY1AMDWE MC908QY1AMPE MC908QY1AVDTE MC908QY1AVDWE MC908QY1AVPEMC908QY2ACDTE MC908QY2ACDWE MC908QY2ACPEMC908QY2AMDTE MC908QY2AMDWE MC908QY2AMPE MC908QY2AVDTE MC908QY2AVDWE MC908QY2AVPEMC908QY4ACDT MC908QY4ACDWE MC908QY4ACPEMC908QY4AMDTE MC908QY4AMDWE MC908QY4AMPE MC908QY4AVDTE MC908QY4AVDWE MC908QY4AVPEMC912D60XX系列MC912D60ACFU8 MC912D60ACPV8 MC912D60AMFU8MC912D60AMPV8 MC912D60AVFU8 MC912D60AVPV8MC912D60CCFU8 MC912D60CCPV8 MC912D60CMFU8MC912D60CMPV8 MC912D60CVFU8 MC912D60CVPV8MC912D60PCFU8 MC912D60PCPV8 MC912D60PMFU8MC912D60PMPV8 MC912D60PVFU8 MC912D60PVPV8MC912DG128XX系列MC912DG128ACPV MC912DG128AMPV MC912DG128AVPV MC912DG128CCPV MC912DG128CMPV MC912DG128CVPV MC912DG128PCPV MC912DG128PMPV MC912DG128PVPV MC912DT128XX系列MC912DT128ACPV MC912DT128AMPV MC912DT128AVPV MC912DT128CCPV MC912DT128CMPV MC912DT128CVPV MC912DT128PCPV MC912DT128PMPV MC912DT128PVPVMC9RS08KA1CPC MC9RS08KA1CSC MC9RS08KA2CPCMC9RS08KA2CSC ……MC9S08ACXX系列MC9S08AC16CFD MC9S08AC16CFDE MC9S08AC16CFG MC9S08AC16CFGE MC9S08AC16MFD MC9S08AC16MFDE MC9S08AC16MFG MC9S08AC16MFGE MC9S08AC16VFD MC9S08AC16VFDE MC9S08AC16VFG MC9S08AC16VFGE MC9S08AC32CFD MC9S08AC32CFDE MC9S08AC32CFG MC9S08AC32CFGE MC9S08AC32CFU MC9S08AC32CFUE MC9S08AC32CPU MC9S08AC32CPUE MC9S08AC32MFD MC9S08AC32MFDE MC9S08AC32MFG MC9S08AC32MFGE MC9S08AC32MFU MC9S08AC32MFUE MC9S08AC32MPU MC9S08AC32MPUE MC9S08AC32VFD MC9S08AC32VFDE MC9S08AC32VFG MC9S08AC32VFGE MC9S08AC32VFU MC9S08AC32VFUE MC9S08AC32VPU MC9S08AC32VPUE MC9S08AC48CFD MC9S08AC48CFDE MC9S08AC48CFG MC9S08AC48CFGE MC9S08AC48CFU MC9S08AC48CFUE MC9S08AC48CPU MC9S08AC48CPUE MC9S08AC48MFD MC9S08AC48MFDE MC9S08AC48MFG MC9S08AC48MFGE MC9S08AC48MFU MC9S08AC48MFUE MC9S08AC48MPU MC9S08AC48MPUE MC9S08AC48VFD MC9S08AC48VFDE MC9S08AC48VFG MC9S08AC48VFGE MC9S08AC48VFU MC9S08AC48VFUE MC9S08AC48VPU MC9S08AC48VPUE MC9S08AC60CFD MC9S08AC60CFDE MC9S08AC60CFG MC9S08AC60CFGE MC9S08AC60CFU MC9S08AC60CFUE MC9S08AC60CPU MC9S08AC60CPUE MC9S08AC60MFD MC9S08AC60MFDE MC9S08AC60MFG MC9S08AC60MFGE MC9S08AC60MFU MC9S08AC60MFUE MC9S08AC60MPU MC9S08AC60MPUE MC9S08AC60VFD MC9S08AC60VFDE MC9S08AC60VFG MC9S08AC60VFGE MC9S08AC60VFU MC9S08AC60VFUE MC9S08AC60VPU MC9S08AC60VPUE MC9S08AC8CFD MC9S08AC8CFDE MC9S08AC8CFGMC9S08AC8CFGE MC9S08AC8MFD MC9S08AC8MFDEMC9S08AC8MFG MC9S08AC8MFGE MC9S08AC8VFDMC9S08AC8VFDE MC9S08AC8VFG MC9S08AC8VFGEMC9S08AWXX系列MC9S08AW16CFD MC9S08AW16CFDE MC9S08AW16CFG MC9S08AW16CFGE MC9S08AW16CFU MC9S08AW16CFUE MC9S08AW16CPU MC9S08AW16CPUE MC9S08AW16MFD MC9S08AW16MFDE MC9S08AW16MFG MC9S08AW16MFGE MC9S08AW16MFU MC9S08AW16MFUE MC9S08AW16MPUMC9S08AW16VFUE MC9S08AW16VPU MC9S08AW16VPUE MC9S08AW32CFD MC9S08AW32CFDE MC9S08AW32CFG MC9S08AW32CFGE MC9S08AW32CFU MC9S08AW32CFUE MC9S08AW32CPU MC9S08AW32CPUE MC9S08AW32MFD MC9S08AW32MFDE MC9S08AW32MFG MC9S08AW32MFGE MC9S08AW32MFU MC9S08AW32MFUE MC9S08AW32MPU MC9S08AW32MPUE MC9S08AW32VFD MC9S08AW32VFDE MC9S08AW32VFG MC9S08AW32VFGE MC9S08AW32VFU MC9S08AW32VFUE MC9S08AW32VPU MC9S08AW32VPUE MC9S08AW48CFD MC9S08AW48CFDE MC9S08AW48CFG MC9S08AW48CFGE MC9S08AW48CFU MC9S08AW48CFUE MC9S08AW48CPU MC9S08AW48CPUE MC9S08AW48MFD MC9S08AW48MFDE MC9S08AW48MFG MC9S08AW48MFGE MC9S08AW48MFU MC9S08AW48MFUE MC9S08AW48MPU MC9S08AW48MPUE MC9S08AW48VFD MC9S08AW48VFDE MC9S08AW48VFG MC9S08AW48VFGE MC9S08AW48VFU MC9S08AW48VFUE MC9S08AW48VPU MC9S08AW48VPUE MC9S08AW60CFD MC9S08AW60CFDE MC9S08AW60CFG MC9S08AW60CFGE MC9S08AW60CFU MC9S08AW60CFUE MC9S08AW60CPU MC9S08AW60CPUE MC9S08AW60MFD MC9S08AW60MFDE MC9S08AW60MFG MC9S08AW60MFGE MC9S08AW60MFU MC9S08AW60MFUE MC9S08AW60MPU MC9S08AW60MPUE MC9S08AW60VFD MC9S08AW60VFDE MC9S08AW60VFG MC9S08AW60VFGE MC9S08AW60VFU MC9S08AW60VFUE MC9S08AW60VPU MC9S08AW60VPUEMC9S08GBXX系列MC9S08GB32ACFU MC9S08GB32ACFUE MC9S08GB32CFU MC9S08GB32CFUE MC9S08GB60ACFU MC9S08GB60ACFUE MC9S08GB60CFU MC9S08GB60CFUE ……MC9S08GTXX系列MC9S08GT16ACB MC9S08GT16ACFB MC9S08GT16ACFC MC9S08GT16ACFCE MC9S08GT16ACFD MC9S08GT16AMB MC9S08GT16AMFB MC9S08GT16AMFC MC9S08GT16AMFCE MC9S08GT16AMFD MC9S08GT16CB MC9S08GT16CBEMC9S08GT16CFB MC9S08GT16CFBE MC9S08GT16CFDMC9S08GT16CFDE MC9S08GT32ACFB MC9S08GT32ACFBE MC9S08GT32ACFD MC9S08GT32ACFDE MC9S08GT32CB MC9S08GT32CBE MC9S08GT32CFB MC9S08GT32CFBEMC9S08GT32CFD MC9S08GT32CFDE MC9S08GT60ACFB MC9S08GT60ACFB MC9S08GT60ACFD MC9S08GT60ACFDE MC9S08GT60CB MC9S08GT60CBE MC9S08GT60CFBMC9S08GT8ACFCE MC9S08GT8ACFD MC9S08GT8AMB MC9S08GT8AMFB MC9S08GT8AMFC MC9S08GT8AMFCE MC9S08GT8AMFD ……MC9S08JMXX系列MC9S08JM16CGT MC9S08JM16CGTE MC9S08JM16CLD MC9S08JM16CLDE MC9S08JM16MGT MC9S08JM16MGTE MC9S08JM16MLD MC9S08JM16MLDE MC9S08JM16VGT MC9S08JM16VGTE MC9S08JM16VLD MC9S08JM16VLDE MC9S08JM32CGT MC9S08JM32CGTE MC9S08JM32CLD MC9S08JM32CLDE MC9S08JM32CLH MC9S08JM32CLHE MC9S08JM32CQH MC9S08JM32CQHE MC9S08JM32MGT MC9S08JM32MGTE MC9S08JM32MLD MC9S08JM32MLDE MC9S08JM32MLH MC9S08JM32MLHE MC9S08JM32MQH MC9S08JM32MQHE MC9S08JM32VGT MC9S08JM32VGTE MC9S08JM32VLD MC9S08JM32VLDE MC9S08JM32VLH MC9S08JM32VLHE MC9S08JM32VQH MC9S08JM32VQHE MC9S08JM60CGTE MC9S08JM60CLDE MC9S08JM60CLHE MC9S08JM60CQHE MC9S08JM8CGT MC9S08JM8CGTE MC9S08JM8CLD MC9S08JM8CLDE MC9S08JM8MGTMC9S08JM8MGTE MC9S08JM8MLD MC9S08JM8MLDEMC9S08JM8VGT MC9S08JM8VGTE MC9S08JM8VLDMC9S08JM8VLDE ……MC9S08QAXX系列MC9S08QA2CDN MC9S08QA2CDNE MC9S08QA2CFQMC9S08QA2CFQE MC9S08QA2CPA MC9S08QA2CPAEMC9S08QA2MDN MC9S08QA2MDNE MC9S08QA2MFQMC9S08QA2MFQE MC9S08QA2MPA MC9S08QA2MPAE MC9S08QA2VDN MC9S08QA2VDNE MC9S08QA2VFQMC9S08QA2VFQE MC9S08QA2VPA MC9S08QA4CDNMC9S08QA4CDNE MC9S08QA4CFQ MC9S08QA4CFQE MC9S08QA4CPA MC9S08QA4CPAE MC9S08QA4MDNMC9S08QA4MDNE MC9S08QA4MFQ MC9S08QA4MFQE MC9S08QA4MPA MC9S08QA4MPAE MC9S08QA4VDNMC9S08QA4VDNE MC9S08QA4VFQ MC9S08QA4VFQEMC9S08QA4VPA MC9S08QA4VPA E ……MC9S08QDXX系列MC9S08QD2CPC MC9S08QD2CSC MC9S08QD2MPCMC9S08QD2MSC MC9S08QD2VPC MC9S08QD2VSCMC9S08QD4CPC MC9S08QD4CSC MC9S08QD4MPCMC9S08QD4MSC MC9S08QD4VPC MC9S08QD4VSCMC9S08QG4CDNE MC9S08QG4CDTE MC9S08QG4CFFE MC9S08QG4CFQE MC9S08QG4CPAE MC9S08QG8CDNE MC9S08QG8CDTE MC9S08QG8CFFE MC9S08QG8CFQE MC9S08QG8CPBE ……MC9S08RCXX系列MC9S08RC16CFG MC9S08RC16CFJ MC9S08RC16FG MC9S08RC16FJ MC9S08RC32CFG MC9S08RC32CFJMC9S08RC32FG MC9S08RC32FJ MC9S08RC60CFGMC9S08RC60CFJ MC9S08RC60FG MC9S08RC60FJMC9S08RC8CFG MC9S08RC8CFJ MC9S08RC8FGMC9S08RC8FJ ……MC9S08RDXX系列MC9S08RD16CDW MC9S08RD16CFG MC9S08RD16CFJ MC9S08RD16CP MC9S08RD16DW MC9S08RD16FGMC9S08RD16FJ MC9S08RD16P MC9S08RD32CDWMC9S08RD32CFG MC9S08RD32CFJ MC9S08RD32CP MC9S08RD32DW MC9S08RD32FG MC9S08RD32FJMC9S08RD32P MC9S08RD60CDW MC9S08RD60CFG MC9S08RD60CFJ MC9S08RD60CP MC9S08RD60DWMC9S08RD60FG MC9S08RD60FJ MC9S08RD60PMC9S08RD8CDW MC9S08RD8CFG MC9S08RD8CFJMC9S08RD8CP MC9S08RD8DW MC9S08RD8FGMC9S08RD8FJ MC9S08RD8P ……MC9S08REXX系列MC9S08RE16CFG MC9S08RE16CFJ MC9S08RE16FJMC9S08RE32CFG MC9S08RE32CFJ MC9S08RE32FG MC9S08RE32FJ MC9S08RE60CFG MC9S08RE60CFJMC9S08RE60FG MC9S08RE60FJ MC9S08RE8CFGMC9S08RE8CFJ MC9S08RE8FG MC9S08RE8FJMC9S08RGXX系列MC9S08RG32CFG MC9S08RG32CFJ MC9S08RG32FG MC9S08RG32FJ MC9S08RG60CFG MC9S08RG60CFJ MC9S08RG60FG MC9S08RG60FJ ……MC9S08SGXX系列单片机解密MC9S08SG4CSC MC9S08SG4MSC MC9S08SG4MTGMC9S08SG4VSC MC9S08SG4VTG MC9S08SG8CSCMC9S08SG8CTG MC9S08SG8MSC MC9S08SG8MTGMC9S08SG8VSC MC9S08SG8VTG ……MC9S08SH4CSC MC9S08SH4CTG MC9S08SH4MSCMC9S08SH4MTG MC9S08SH4VSC MC9S08SH4VTGMC9S08SH8CTG MC9S08SH8MSC MC9S08SH8MTGMC9S08SH8VSC MC9S08SH8VTG ……MC9S12AXX系列MC9S12A128BCFU MC9S12A128BCPV MC9S12A128BMFU MC9S12A128BMPV MC9S12A128BVFU MC9S12A128BVPV MC9S12A128CFU MC9S12A128CPV MC9S12A128MFUMC9S12A128VFU MC9S12A128MPV MC9S12A128VPVMC9S12A256BCFU MC9S12A256BCPV MC9S12A256BMFU MC9S12A256BMPV MC9S12A256BVFU MC9S12A256BVPV MC9S12A256CFU MC9S12A256CPV MC9S12A256MFUMC9S12A256MPV MC9S12A256VFU MC9S12A256VPVMC9S12A64CFU MC9S12A64CPV MC9S12A64FMC9S12A64MFU MC9S12A64MPV MC9S12A64PVMC9S12A64VFU MC9S12A64VPV ……MC9S12BXX系列MC9S12B128CFU MC9S12B128CPV MC9S12B128MFUMC9S12B128MPV MC9S12B128VFU MC9S12B128VPVMC9S12B64CFU MC9S12B64CPV MC9S12B64MFUMC9S12B64MPV MC9S12B64VFU MC9S12B64VPVMC9S12CXX系列MC9S12C128CFA MC9S12C128CFU MC9S12C128CPBMC9S12C128MFA MC9S12C128MFU MC9S12C128MPB MC9S12C128VFA MC9S12C128VFU MC9S12C128VPBMC9S12C32CFA16 MC9S12C32CFA25 MC9S12C32CFU16 MC9S12C32CFU25 MC9S12C32CPB16 MC9S12C32CPB25 MC9S12C32MFA16 MC9S12C32MFA25 MC9S12C32MFU16 MC9S12C32MFU25 MC9S12C32MPB16 MC9S12C32MPB25 MC9S12C32VFA16 MC9S12C32VFA25 MC9S12C32VFU16 MC9S12C32VFU25 MC9S12C32VPB16 MC9S12C32VPB25 MC9S12C64CFA MC9S12C64CFU MC9S12C64CPBMC9S12C64MFA MC9S12C64MFU MC9S12C64MPBMC9S12C64VFA MC9S12C64VFU MC9S12C64VPBMC9S12C96CFA MC9S12C96CFU MC9S12C96CPBMC9S12C96MFA MC9S12C96MFU MC9S12C96MPBMC9S12C96VFA MC9S12C96VFU MC9S12C96VPBMC9S12D64XX系列MC9S12D64CFU MC9S12D64CPV MC9S12D64FUMC9S12D64MFU MC9S12D64MPV MC9S12D64PVMC9S12D64VFU MC9S12D64VPV ……MC9S12DBXX系列MC9S12DB128BCPV MC9S12DB128BVPV MC9S12DB128BMPV MC9S12DB128MPV MC9S12DB128VPV ……MC9S12DBXX系列MC9S12DB128BCPV MC9S12DB128BVPV MC9S12DB128BMPV MC9S12DB128MPV MC9S12DB128VPV ……MC9S12DGXX系列MC9S12DG128BCFU MC9S12DG128BCPV MC9S12DG128BMFU MC9S12DG128BMPV C9S12DG128BVFU MC9S12DG128BVPV MC9S12DG128CFU MC9S12DG128CPV MC9S12DG128ECFUMC9S12DG128ECPV MC9S12DG128EMFU MC9S12DG128EMPV MC9S12DG128EVFU MC9S12DG128EVPV MC9S12DG128MFU MC9S12DG128MPV MC9S12DG128VFU MC9S12DG128VPVMC9S12DG256BCFU MC9S12DG256BCPV MC9S12DG256BMFU MC9S12DG256BMPV MC9S12DG256BVFU MC9S12DG256BVPV MC9S12DG256CCFU MC9S12DG256CCPV MC9S12DG256CFU MC9S12DG256CMFU MC9S12DG256CMPV MC9S12DG256CPV MC9S12DG256CVFU MC9S12DG256CVPV MC9S12DG256MFU MC9S12DG256MPV MC9S12DG256VFU MC9S12DG256VPVMC9S12DJXX系列MC9S12DJ128BCFU MC9S12DJ128BCPV MC9S12DJ128BMFU MC9S12DJ128BMPV MC9S12DJ128BVFU MC9S12DJ128BVPV MC9S12DJ128CFU MC9S12DJ128CPV MC9S12DJ128ECFUMC9S12DJ128ECPV MC9S12DJ128EMFU MC9S12DJ128EMPV MC9S12DJ128EVFU MC9S12DJ128EVPV MC9S12DJ128MFUMC9S12DJ128MPV MC9S12DJ128VFU MC9S12DJ128VPVMC9S12DJ256BCFU MC9S12DJ256BCPV MC9S12DJ256BMFU MC9S12DJ256BMPV MC9S12DJ256BVFU MC9S12DJ256BVPV MC9S12DJ256CCFU MC9S12DJ256CCPV MC9S12DJ256CFUMC9S12DJ256CMFU MC9S12DJ256CMPV MC9S12DJ256CPVMC9S12DJ256CVFU MC9S12DJ256CVPV MC9S12DJ256MFUMC9S12DJ256MPV MC9S12DJ256VFU MC9S12DJ256VPVMC9S12DJ64CFU MC9S12DJ64CPV MC9S12DJ64FUMC9S12DJ64MFU MC9S12DJ64MPV MC9S12DJ64PVMC9S12DJ64VFU MC9S12DJ64VPV ……MC9S12DPXX系列MC9S12DP256BCPV MC9S12DP256BMPV MC9S12DP256BVPV MC9S12DP256CCPV MC9S12DP256CMPV MC9S12DP256CVPVMC9S12DP256BCPV MC9S12DP256BMPV MC9S12DP256BVPV MC9S12DP256CCPV MC9S12DP256CMPV MC9S12DP256CVPVMC9S12DTXX系列MC9S12DT128BCPV MC9S12DT128BMPV MC9S12DT128BVPV MC9S12DT128CPV MC9S12DT128ECPV MC9S12DT128EMPVMC9S12DT128EVPV MC9S12DT128MPV MC9S12DT128VPVMC9S12DT256BCPV MC9S12DT256BMPV MC9S12DT256BVPV MC9S12DT256CCPV MC9S12DT256CFU MC9S12DT256CMPV MC9S12DT256CPV MC9S12DT256CVPV MC9S12DT256MFUMC9S12DT256MPV MC9S12DT256VFU MC9S12DT256VPVMC9S12EXX系列MC9S12E128CFU MC9S12E128CFUE MC9S12E128CPVMC9S12E128CPVE MC9S12E128MFU MC9S12E128MFUEMC9S12E128MPV MC9S12E128MPVE MC9S12E128VFUMC9S12E128VFUE MC9S12E128VPV MC9S12E128VPVEMC9S12E256CFU MC9S12E256CFUE MC9S12E256CPVMC9S12E256CPVE MC9S12E256MFU MC9S12E256MFUEMC9S12E256MPV MC9S12E256MPVE MC9S12E256VFUMC9S12E256VFU MC9S12E256VPV MC9S12E256VPVEMC9S12E32CFU MC9S12E32CFUE MC9S12E32MFUMC9S12E32MFUE MC9S12E32VFU MC9S12E32VFUEMC9S12E64CFU MC9S12E64CFUE MC9S12E64CPVMC9S12E64CPVE MC9S12E64MFU MC9S12E64MFUEMC9S12E64VPV MC9S12E64MPV MC9S12E64MPVEMC9S12E64VFU MC9S12E64VFUE MC9S12E64VPVEMC9S12GCXX系列MC9S12GC128CFA MC9S12GC128CPB MC9S12GC128MFAMC9S12GC128MFU MC9S12GC128MPB MC9S12GC128VFAMC9S12GC128VFU MC9S12GC128VPB MC9S12GC16CFAMC9S12GC16CFU MC9S12GC16CPB MC9S12GC16MFAMC9S12GC16MFU MC9S12GC16MPB MC9S12GC16VFAMC9S12GC16VFU MC9S12GC16VPB MC9S12GC32CFAMC9S12GC32CFU MC9S12GC32CPB MC9S12GC32MFAMC9S12GC32MFU MC9S12GC32MPB MC9S12GC32VFAMC9S12GC32VFU MC9S12GC32VPB MC9S12GC64CFAMC9S12GC64CFU MC9S12GC64CPB MC9S12GC64MFAMC9S12GC64MFU MC9S12GC64MPB MC9S12GC64VFAMC9S12GC64VFU MC9S12GC64VPB MC9S12GC96CFAMC9S12GC96CFU MC9S12GC96CPB MC9S12GC96MFAMC9S12GC96MFU MC9S12GC96MPB MC9S12GC96VFAMC9S12GC96VFU MC9S12GC96VPB ……MC9S12HN64CAA MC9S12HN64CAL MC9S12HN64CFUMC9S12HN64CPV MC9S12HN64MAA MC9S12HN64MAL MC9S12HN64MFU MC9S12HN64MPV MC9S12HN64VAA MC9S12HN64VAL MC9S12HN64VFU MC9S12HN64VPVMC9S12HZXX系列MC9S12HZ128CAA MC9S12HZ128CAL MC9S12HZ128CFU MC9S12HZ128CPV MC9S12HZ128MAA MC9S12HZ128MAL MC9S12HZ128MFU MC9S12HZ128MPV MC9S12HZ128VAA MC9S12HZ128VAL MC9S12HZ128VFU MC9S12HZ128VPV MC9S12HZ256CAA MC9S12HZ256CAL MC9S12HZ256CFU MC9S12HZ256CPV MC9S12HZ256MAA MC9S12HZ256MAL MC9S12HZ256MFU MC9S12HZ256MPV MC9S12HZ256VAA MC9S12HZ256VAL MC9S12HZ256VFU MC9S12HZ256VPV MC9S12HZ64CAA MC9S12HZ64CAL MC9S12HZ64CFUMC9S12HZ64CPV MC9S12HZ64MAA MC9S12HZ64MALMC9S12HZ64MFU MC9S12HZ64MPV MC9S12HZ64VAAMC9S12HZ64VAL MC9S12HZ64VFU MC9S12HZ64VPVMC9S12KGXX系列MC9S12KG256CFU MC9S12KG256CPV MC9S12KG256MFU MC9S12KG256MPV MC9S12KG256VFU MC9S12KG256VPVMC9S12KTXX系列MC9S12KT256CPV MC9S12KT256MPV MC9S12KT256VPVMC9S12NE64XX系列MC9S12NE64CPV MC9S12NE64CPVE MC9S12NE64VTU MC9S12NE64VTUE ……MC9S12UF32XX系列MC9S12UF32PB MC9S12UF32PBE MC9S12UF32PUMC9S12XAXX系列MC9S12XA128CAA MC9S12XA128CAL MC9S12XA128CFU MC9S12XA128CPV MC9S12XA128MAA MC9S12XA128MAL MC9S12XA128MFU MC9S12XA128MPV MC9S12XA128VAA MC9S12XA128VAL MC9S12XA128VFU MC9S12XA128VPV MC9S12XA256CAA MC9S12XA256CAG MC9S12XA256CAL MC9S12XA256CFU MC9S12XA256CFV MC9S12XA256CPV MC9S12XA256MAA MC9S12XA256MAG MC9S12XA256MAL MC9S12XA256MFU MC9S12XA256MFV MC9S12XA256MPV MC9S12XA256VAA MC9S12XA256VAG MC9S12XA256VAL MC9S12XA256VFU MC9S12XA256VFV MC9S12XA256VPVMC9S12XA512CAA MC9S12XA512CAG MC9S12XA512CALMC9S12XA512CFU MC9S12XA512CFV MC9S12XA512CPVMC9S12XA512MAA MC9S12XA512MAG MC9S12XA512MALMC9S12XA512MFU MC9S12XA512MFV MC9S12XA512MPVMC9S12XA512VAA MC9S12XA512VAG MC9S12XA512VALMC9S12XA512VFU MC9S12XA512VFV MC9S12XA512VPVMC9S12XBXX系列MC9S12XB128CAA MC9S12XB128CA MC9S12XB128CFUMC9S12XB128CPV MC9S12XB128MAA MC9S12XB128MALMC9S12XB128MFU MC9S12XB128MPV MC9S12XB128VAAMC9S12XB128VAL MC9S12XB128VFU MC9S12XB128VPVMC9S12XB256CAA MC9S12XB256CAL MC9S12XB256CFUMC9S12XB256CPV MC9S12XB256MAA MC9S12XB256MALMC9S12XB256MFU MC9S12XB256MPV MC9S12XB256VAAMC9S12XB256VAL MC9S12XB256VFU MC9S12XB256VPVMC9S12XDXX系列MC9S12XD128CAA MC9S12XD128CAL MC9S12XD128CFUMC9S12XD128CPV MC9S12XD128MAA MC9S12XD128MALMC9S12XD128MPV MC9S12XD128VAA MC9S12XD128VALMC9S12XD128VFU MC9S12XD128VPV MC9S12XD256VPVMC9S12XD256CAA MC9S12XD256CAG MC9S12XD256CALMC9S12XD256CFU MC9S12XD256CFV MC9S12XD256CPVMC9S12XD256MAA MC9S12XD256MAG MC9S12XD256MALMC9S12XD256MFU MC9S12XD256MFV MC9S12XD256MPVMC9S12XD256VAA MC9S12XD256VAG MC9S12XD256VALMC9S12XD256VFU MC9S12XD256VFV MC9S12XD64VFUMC9S12XD64CAA MC9S12XD64CFU MC9S12XD64MAAMC9S12XD64MFU MC9S12XD64VAA ……MC9S12XDGXX系列MC9S12XDG128CAA MC9S12XDG128CAL MC9S12XDG128CFU MC9S12XDG128CPV MC9S12XDG128MAA MC9S12XDG128MAL MC9S12XDG128MFU MC9S12XDG128MPV MC9S12XDG128VAA MC9S12XDG128VAL MC9S12XDG128VFU MC9S12XDG128VPVMC9S12XDPXX系列MC9S12XDP512CAG MC9S12XDP512CA MC9S12XDP512CFV MC9S12XDP512CPV MC9S12XDP512MAG MC9S12XDP512MAL MC9S12XDP512MFV MC9S12XDP512MPV MC9S12XDP512VAG MC9S12XDP512VAL MC9S12XDP512VFV MC9S12XDP512VPVMC9S12XDQXX系列MC9S12XDQ256CAA MC9S12XDQ256CAG MC9S12XDQ256CALMC9S12XDQ256CFU MC9S12XDQ256CFV MC9S12XDQ256CPV MC9S12XDQ256MAA MC9S12XDQ256MAG MC9S12XDQ256MAL MC9S12XDQ256MFU MC9S12XDQ256MFV MC9S12XDQ256MPV MC9S12XDQ256VAA MC9S12XDQ256VAG MC9S12XDQ256VAL MC9S12XDQ256VFU MC9S12XDQ256VFV MC9S12XDQ256VPVMC9S12XDTXX系列MC9S12XDT256CAA MC9S12XDT256CAG MC9S12XDT256CAL MC9S12XDT256CFU MC9S12XDT256CFV MC9S12XDT256CPV MC9S12XDT256MAA MC9S12XDT256MAG MC9S12XDT256MAL MC9S12XDT256MFU MC9S12XDT256MFV MC9S12XDT256MPV MC9S12XDT256VAA MC9S12XDT256VAG MC9S12XDT256VA MC9S12XDT256VFU MC9S12XDT256VFV MC9S12XDT256VPV MC9S12XDT384CAA MC9S12XDT384CAG MC9S12XDT384CAL MC9S12XDT384CFV MC9S12XDT384CPU MC9S12XDT384CPV MC9S12XDT384MAA MC9S12XDT384MAG MC9S12XDT384MAL MC9S12XDT384MFV MC9S12XDT384MPU MC9S12XDT384MPV MC9S12XDT384VAA MC9S12XDT384VAG MC9S12XDT384VAL MC9S12XDT384VFV MC9S12XDT384VPU MC9S12XDT384VPV MC9S12XDT512CAA MC9S12XDT512CAG MC9S12XDT512CAL MC9S12XDT512CFU MC9S12XDT512CFV MC9S12XDT512CPV MC9S12XDT512MAA MC9S12XDT512MAG MC9S12XDT512MAL MC9S12XDT512MFU MC9S12XDT512MFV MC9S12XDT512MPV MC9S12XDT512VAA MC9S12XDT512VAG MC9S12XDT512VAL MC9S12XDT512VFU MC9S12XDT512VFV MC9S12XDT512VPVMC9S12XHZXX系列MC9S12XHZ256CAG MC9S12XHZ256CA MC9S12XHZ256MAG MC9S12XHZ256MAL MC9S12XHZ256VAG MC9S12XHZ256VAL MC9S12XHZ384CAG MC9S12XHZ384CAL MC9S12XHZ384MAG MC9S12XHZ384MAL MC9S12XHZ384VAG MC9S12XHZ384VAL MC9S12XHZ512CAG MC9S12XHZ512CAL MC9S12XHZ512MAG MC9S12XHZ512MAL MC9S12XHZ512VAG MC9S12XHZ512VALMCHC908JWXX系列MCHC908JW32FAE MCHC908JW32FC ……DSP56F8XX系列单片机解密(龙人)DSP56F801 DSP56F802 DSP56F803DSP56F805 DSP56F807 DSP56F827DSP56F826 ……P912XDG128XX系列P912XDG128CAA P912XDG128CAA P912XDG128CALP912XDG128CFU P912XDG128CPV P912XDG128MAAP912XDG128MAL P912XDG128MFU P912XDG128MPVP912XDG128VAA P912XDG128VAL P912XDG128VFUP912XDG128VPV ……P9RS08KAXX系列P9RS08KA1CPC P9RS08KA1CSC P9RS08KA2CPCP9RS08KA2CSC ……PC56F80XX系列PC56F8011VFAE PC56F8013VFAE PC56F8014VFAEPC68HC908XX系列PC68HC908GP32 ……PC9S12UFXX系列PC9S12UF32PB PC9S12UF32PBE PC9S12UF32PUPC9S12XFXX系列PC9S12XF128 PC9S12XF256 PC9S12XF384PC9S12XF512 ……PC9S12XHZXX系列PC9S12XHZ256CAG PC9S12XHZ256CAL PC9S12XHZ256MAG PC9S12XHZ256MAL PC9S12XHZ256VAG PC9S12XHZ256VAL PC9S12XHZ384CAG PC9S12XHZ384CAL PC9S12XHZ384MAG PC9S12XHZ384MAL PC9S12XHZ384VAG PC9S12XHZ384VAL PC9S12XHZ512CAG PC9S12XHZ512CAL PC9S12XHZ512MAG PC9S12XHZ512MAL PC9S12XHZ512VAG PC9S12XHZ512VALS9S08AWXX系列S9S08AW16ACFT S9S08AW16ACLS S9S08AW16AMFTS9S08AW16AMLS S9S08AW16AVFT S9S08AW16AVLSS9S08AW8ACFT S9S08AW8ACLS S9S08AW8AMFTS9S08AW8AMLS S9S08AW8AVFT S9S08AW8AVLS11系列motorola单片机解密：MC68HC711系列MC68HC11A8 (AB95T)、MC68HC11A8 (C96N)MC68HC11A8 (D26E)、MC68HC11E20 (3E22B)MC68HC11E9 (1B60R)、MC68HC11E9 (D82R)MC68HC11E9 (E22B)、MC68HC11E9 (E28B)MC68HC11EA9 (2D47J)、MC68HC11F1 (2F37E)MC68HC11F1 (E87J)、MC68HC11K1 (2D58N)MC68HC11K4 (1E62H)、MC68HC11K4 (OE75J)MC68HC11KA4 (1E59B)、MC68HC11KS2 (0H95B)MC68HC11KS4 (0E57S)、MC68HC11KS4 (0F60M)MC68HC711E20 (1H19S)、MC68HC711E9 (4K81H)MC68HC711E9 (5C47M)、MC68HC711EA9 (0D46J)MC68HC711K4 (K59D)、MC68HC711PH8 (0H30R)MC68S711E9 (5C47M)、XC68HC711KS8 (1H96P)MC68HC11P2 (2E74J)、XC68HC711P2 (1E53M)MC68HC705系列MC68HC705C4 (68HC705C4) MC68HC705C4A (68HC705C4A) MC68HC705C8 (68HC705C8) MC68HC705C8A (68HC705C8A) MC68HC705C9 (68HC705C9) MC68HC705C9A (68HC705C9A) MC68HC705SR3 (68HC705SR3) MC68HC705J1A (68HC705J1A) MC68HC705 (68HC705) ……MC68HC705B16 MC68HC705B32MC68HC705X16 MC68HC705X32MC68HC05B6 MC68HC05B8MC68HC05B16 MC68HC05B32MC68HC05X16 MC68HC05X32MC68HC05H12(0H57A) ……MC68HC908系列MC68HC908AZ60(2J74Y) MC68HC908AZ60(4J74Y)MC68HC908AZ60A(3K85K) MC68HC908AS60(3J74Y)MC68HC908AS60A(1L87J) MC68HC908AB32(3K56G)MC68HC08AZ60(1J35D) MC68HC08AZ32(0J66D)MC68HC08AZ32(1H56A) MC68HC08AS20(0H94K)MC68HC08AZ32A(1L52H) ……MC68HC912系列MC68HC912DC128A(3K91D) MC68HC912DC128(0K50E)MC68HC912DG128(5H55W) MC68HC912DG128A(3K91D)MC68HC912DG128(0K50E) MC68HC912D60A(2K38K)MC68HC912D60(0K75F) MC68HC912D60(0K13J)MC68HC912D60(4F73K) MC68HC912B32(4J54E)MC68HC912B32(9H91F) MC9S12DG128B(0L85DMC68HC9S12系列MC9S12DT128B(0L85D) MC9S12A128B(0L85D)MC9S12DB128B(0L85D) MC9S12DT128B(1L85D)MC9S12DG256C(2K79X) MC9S12DT256C(2K79X)MC9S12H128(1K78X) MC9S12H256(1K78X)MC9S12DP256C(2K79X) MC9S12DT128B(3L40K)MC9S12DP512(1L00M) ……【责任编辑：hailee 文章来源：】。

飞思卡尔8位单片机MC9S08JM60开发板实践教程共40页word资料

飞思卡尔8位单片机MC9S08JM60开发板实践教程共40页word资料

第一章搭建实验环境系统时钟设置#include "App\Include\App.h"#ifndef _MCG_C#define _MCG_C//oscillator 12MHZ 倍频为24MHZ（）先8分频后16倍频void S_MCGInit(void)/* the MCG is default set to FEI mode, it should be change to FBE mode*/MCGC2[7:6] BDIV总线频率分频因子–选择由MCGC1寄存器中CLKS位决定的时钟源的分频。

这控制总线频率。

00 编码0 –时钟1分频01 编码1 –时钟2分频（复位后默认）10 编码2 –时钟4分频11 编码3 –时钟8分频[5] RANGE频率范围选择–选择外部振荡器或者外部时钟源的频率范围。

1 选择1MHz到16MHz外部振荡器的频率范围。

（1MHz到40MHz的外部时钟电源）的高频率范围0 选择32kHz到100kHz外部振荡器的频率范围。

（32kHz到1MHz的外部时钟电源）的低频率范围[4] HGO高增益振荡器选择–控制外部振荡器操作模式。

1 配置外部振荡器为高增益运行0 配置外部振荡器为低功耗运行[3] LP低功耗选择–控制在忽略模式中FLL（或者PLL）是否为无效1 FLL（或PLL）在忽略模式（低功耗）中为无效的。

0 FLL（或PLL）在忽略模式中为无效的。

[2] EREFS外部参考时钟选择–为外部参考选择时钟源1 选择振荡器0 选择外部时钟源[1] ERCLKEN外部参考时钟使能–使能外部参考时钟作为MCGERCLK1 MCGERCLK激活0 MCGERCLK 无效[0] EREFSTEN外部参考时钟停止使能MCGC2 0b0011 0110 激发外部时钟（晶振）（没有使能）MCGC2=MCGC2_RANGE_MASK|MCGC2_HGO_MASK|MCGC2_EREFS_MASK|MCGC2_ERCLK EN_MASK;while(!MCGSC_OSCINIT);//MCGSC寄存器中OSCINIT（第1位）为1，表示由EREFS位选择的晶振被初始化。

1飞思卡尔8位单片机MC9S08JM60开发板实践教程-60页word资料

1飞思卡尔8位单片机MC9S08JM60开发板实践教程-60页word资料

第一章搭建实验环境1、实验电路板及下载器实物图片2、实验电路图本实验图包含两大部分，分别是ＣＰＵ．ＳＣＨ和实验资源．ＳＣＨ。

ＣＰＵ采用飞思卡尔８位单片机ＭＣ９Ｓ０８ＪＭ６０ＣＬＤ，（电路图介绍）图1-3实验资源部分电路图1-4ＬＣＤ串口１６０２液晶电路图1-5ＲＳ２３２接口电路图1-6数码管显示电路图1-7发光管、ａｄ转换以及按键电路图1-83、集成开发软件环境的建立１〉运行文件CW_MCU_V6_3_SE．ＥＸＥ，在电脑Ｃ盘安装飞思卡尔８位（及简化３２位）单片机集成开发环境ｃｏｄｅｗａｒｒｉｏｒ６．３版本２〉运行USBDM_4_7_0i_Win，这个程序会在c盘的程序文件夹下增加一个目录C:\Program Files\pgo\USBDM 4.7.0，在这个目录下ａ＞C:\Program Files\pgo\USBDM 4.7.0\FlashImages\JMxx下的文件USBDM_JMxxCLD_V4.sx是下载器的固件文件；ｂ＞C:\Program Files\pgo\USBDM4.7.0\USBDM_Drivers\Drivers下有下载器的usb驱动．因此在插入usb下载器，电脑提示发现新的usb硬件的时候，选择手动指定驱动安装位置到以上目录即可。

３〉运行USBDM_4_7_0i_Win之后，还会在目录：C:\Program Files\Freescale\CodeWarrior for Microcontrollers V6.3\prog\gdi下增加一些文件，从修改时间上来看，增加了6个文件，这些文件是为了在codewarrior集成开发环境下对usb下载器的调试、下载的支持。

4、Ｃ语言编程基础第二章 LED闪烁程序编写过程1、新建工程运行单片机集成开发环境codewarrior IDE出现如下界面●Create New Project ：创建一个新项目工程●Load Example Project ：加载一个示例工程●Load Previous Project ：加载以前创建过的工程●Run Getting started Tutorial：运行CodeWarrior软件帮助文档●Start Using CodeWarrior：立刻使用CodeWarrior点击Create New project按钮，以创建一个新的工程，出现选择CPU的界面如下，请选择HCS08/HCS08JM Family/MC9S08JM60，在右边的Connection窗口可以选择最后一个开源下载器HCS08 Open Source BDM。
