附件1：外文资料翻译译文光电式传感器的应用与发展摘要目前,光电式传感器的应用范围越来越广,这大大促进了光电式传感器的发展。

光电式传感器结构简单而且形式多样。

它具有精度高，响应速度快，非接触等优点。

在本文中，我们分析了光电式传感器的工作原理,介绍了光电式传感器的分类,然后重点介绍了光电式传感器的应用和使用原理,分析了光电式传感器的现状和未来的发展趋势。

关键词光电式传感器，光电式传感器的应用，光电式传感器的发展1 引言光电式传感器是一种将光学元件和电子元件作为检测部分的传感器。

光电检测技术具有精度高，响应速度快，非接触式等优点。

该传感器结构简单，形式灵活多样。

因此，光电式传感器被广泛运用于控制和测试领域。

它可用于检测由于光量变化导致的非电量变化，如光强，辐射温度，气体成分等等。

它也可以通过光的传输，阻隔，反射，干扰来测量各种物理量，如物体的大小，位移，速度，温度等。

所以它是一个具有广泛应用前景的至关重要的灵敏器件。

当使用光电式传感器时，光电式传感器不直接与被测物体接触，光束质量几乎为零，在测量过程中不存在摩擦力，且在被测物体上几乎没有任何压力。

因此，光电传感器在很多应用方面都比其他传感器具有明显的优势。

然而，它的缺点是在某些应用场合中光学器件和电子设备是比较昂贵的，而且在测量过程中对环境条件的要求较高。

近年来，新型光电子器件的不断涌现为光电式传感器的进一步应用开创了新的一页尤其是CCD图像传感器的出现。

2 光电传感器的原理光电传感器是以光电器件作为转换元件的传感器。

该光电传感器的原理是把被测量的变化转换成光信号的变化，然后借助光电元件进一步将光信号转换成电信号的光电组件。

光电传感器一般由光源、光学通路和光电元件三部分组成。

光电传感器的工作过程如图1所示。

图1 光电式传感器的工作过程光电器件的作用是将光信号转换成基于光电效应的电信号。

光电效应是一种物理现象，光照射到某些物质，并导致物体电性质发生重大改变。
