……检查发现……
1. 航后：检查发现左后航行灯不亮。
AF ：checked and found L AFT NAV light not on.
2.右前轮销磨损超标R nose wheel worn out of limits.
3. 检查发现2号ATC故障。No.2 ATC fault.
4.左外刹车组件指示销磨损超标。
L outboard brake ASSY indicating pin worn out of limits.
5.左主起落架一液压管漏油超标。
a hydraulic tube of L MLG leakage out of limits.
6. 13B座位小桌板不能收起,无法保持在收上位。
seat 13B tray table could not be stowed and could not leave at stow
position.
更换（件）……，检查 / 测试正常
1. 过站：更换右前轮，检查正常。
TR：Replaced R nose wheel，check OK.
2. 更换2号ATC收发机后，测试正常。检查正常。
replaced No.2 ATC transceiver，test OK. check OK.
4. 更换左外刹车组件，增压检查正常。Replaced L outboard brake
ASSY，pressurization check OK.
5. 更换左发右点火导线 Replaced L engine R ignition lead，
6. 更换前起落架减振支柱充气活门，地面检查无渗漏。Replaced
nose gear shock strut charging valve，no leakage in GND check.
7. 更换左发17号风扇叶片，地面检查正常。拆下：M/W31162，
装上M/W30966。
Replaced L engine No.17 fan blade，GND check OK. part off：
M/W31162， part on：M/W30966
8. 更换APU起动机，启动APU工作正常。
Replaced APU starter，APU start OK.
9. 按照MCC要求，为了满足运输病人/残疾人要求，临时拆下第
3排ABC座位。座椅随机放在前货舱.
According to MCC, for the requirement of patient/handicapped
operation, remove seats A/B/C. The seats stored in FWD cargo in this
flight.
参考/按……更换……（件），测试……
1. 根据工卡XXXX，更换电子/电气冷却供气风扇气滤，
Per job card XXXX，replaced E/E cooling fan air filter，
2.更换左后航行灯灯泡，通电测试正常。
replaced L AFT NAV light bulb，power-on test was OK.
3. 按工卡XXXX，更新FMC导航数据库。
Per job card XXXX，updated FMC NAV database.
4. 参考AMM32-31-00，更换液压管，测试无渗漏。
Ref toX，replaced hydraulic tube，no leakage found in test.5.更换时控件电瓶，安装固定测试工作正常。
replaced battery，test for installation OK.
6. 根据波音标准线路施工手册SWPM20-10-11安装导线,检查测试
正常。Refer to SWPM20-10-11 for wire installation procedures, check
and test ok.
7. 根据波音标准线路施工手册SWPM20-10-19分离导线,检查测试
正常。Refer to SWPM20-10-19 for wire separation procedures, check
and test ok.
检查发现…故障，按…保留，…号/类别，同意放行
1. 过站发现前服务话筒失效，按MEL23-20保留，保留号
XXX。TR found FWD attendant microphone malfunction，deferred
referring to MEL23-30，No. XXX.
2. 按MEL34-36保留，C类，同意放行。
Per MEL34-36 defer ,category C，released.
3. 按航线维护手册，操纵测试正常，渗油量符合放行标准，同意
放行。
Per AMM，control test OK，leakage within limits，released.
4. 拔出P6面板上XX跳开关，并在上面安装固定卡子，挂好
“INOP”标牌后按MEL XXXX放行。Pulled the circuit breaker XX in the P6 panel, installed a collar and a
“INOP” label on circuit breaker XX, dispatched referring to
MELXXXX.
按…，更换…件，测试正常，撤消 / 关闭…保留
1.，撤消XXXDD/FC。rescind DD/FCXXX.
2. 更新FMC导航数据库，通电测试工作正常，右HWAS地图方
式正常，并关闭MEL保留。
Update FMC NAV database，power-on test OK，R HWAS map
OK，closed MEL defer item.
3. 清洁并重装左GPS天线，地面测试正常，撤消XXXXX页上的
XXXXXX保留。
Cleaned and reinstalled L GPS antenna，GND test OK，rescinded
defer XXXXXX on page XXXXX.
1. 雷达罩和右发进气道口有鸟击痕迹。Checked and found bird
strike on radiome and R engine air inlet.
2. 地面检查雷达罩和右发进气道正常，右发风扇叶片正常，涵道
正常。GND check found radidme & R engine normal，engine fan
blades & bypass normal.
……（件）不工作 / 故障 / 故障灯亮
1. 左发右点火器不工作。L engine R igniter INOP.
2. 右HWAS地图显示故障。R HWAS map display fault.
3. 巡航过程左右管道压力相差过大。
Much difference between L & R duct pressure during cruising4. 设备冷却系统供气正常位不工作。Equipment cooling system
supply air INOP on NORM position.
5. 第二部应答机“ATC FAIL”灯亮。No.2 transponder “ATC FAIL
”light on.6. 空中气象雷达失效。Weather radar failed in flight.
7. 副翼操纵作动筒漏油。Aileron control actuator leaked fluid.
8. 自动驾驶B通道无法接通。Autopilot channel B couldn’t engage.
9. 空调流量小，制冷效果差。Small air-conditioning flow，poor
cooling.
发 现 故 障 原 因
1. 航后发现前起落架镜面太低，结果发现是充气活门锁不死漏气
所致。AF：found nose gear mirror too low，checked and found
charging valve could’t lock ,leaked air.
2. 航后发现左外主轮扎伤见线。AF：checked and found L outboard
main wheel punctured out of limits
3. 过站发现右外主轮磨损见线。TR： checked and found R
outboard gear worn out of limits .
为判断…故障/因为航材缺件，对串…件，测试…
1. 与B-2652飞机对串磁带放像机，通电测试正常。Exchange tape
reproducer with A/C B-2652，power-on test normal.
2. 为判断B-2652自动刹车故障，将P2-2面板与B-2650对串，通
电测试正常。Troubleshooting for auto brake fault of A/C B-
2652，robbed P2-2 from A/C B-2650，power-on test OK.
3. 由于航材缺件，为判断故障，左右发对串引气调节器，试车检
查右发引气压力正常。Due to lacking of parts，for
troubleshooting，interchanged bleed air regulator of R engine with L
engine，running-up test normal.
4. 根据非例行工卡，将APU滑油量传感器与B-2652飞机对串，
测试正常。Refer to NRC，exchanged APU oil QTY sensor with A/C
B-2652，test OK.
更换……件，试车检查……
1. 更换右发引气调节器，试车正常，左右压力一致。Replaced R
engine bleed air regulator，running-up test OK，pressure the same.
1. 清洗设备冷却供气低流量传感器及插头，测试正常。Cleaned
equipment cooling supply air low flow sensor & plug，test OK.
2. 地面对DFCS做系统测试正常，清洁MCP板后插头，测试B通
道正常。GND test for DFCS OK，cleaned MCP aft plug，test for
channel B OK.
3. 地面对ATC通电测试工作正常。Ground power-on test for ATC
OK.
1. 接生产调度通知，B-2652飞机起落次数多/少记2个，现已更正。
Production notified two cycles reduced/ added on A/C B-2652.
