TM221CE40R TM221CE40R.T h e i n f o r m a t i o n p r o v i d e d i n t h i s d o c u m e n t a t i o n c o n t a i n s g e n e r a l d e s c r i p t i o n s a n d /o r t e c h n i c a l c h a r a c t e r i s t i c s o f t h e p e r f o r m a n c e o f t h e p r o d u c t s c o n t a i n e d h e r e i n .T h i s d o c u m e n t a t i o n i s n o t i n t e n d e d a s a s u b s t i t u t e f o r a n d i s n o t t o b e u s e d f o r d e t e r m i n i n g s u i t a b i l i t y o r r e l i a b i l i t y o f t h e s e p r o d u c t s f o r s p e c i f i c u s e r a p p l i c a t i o n s .I t i s t h e d u t y o f a n y s u c h u s e r o r i n t e g r a t o r t o p e r f o r m t h e a p p r o p r i a t e a n d c o m p l e t e r i s k a n a l y s i s , e v a l u a t i o n a n d t e s t i n g o f t h e p r o d u c t s w i t h r e s p e c t t o t h e r e l e v a n t s p e c i f i c a p p l i c a t i o n o r u s e t h e r e o f .N e i t h e r S c h n e i d e r E l e c t r i c I n d u s t r i e s S A S n o r a n y o f i t s a f f i l i a t e s o r s u b s i d i a r i e s s h a l l b e r e s p o n s i b l e o r l i a b l e f o r m i s u s e o f t h e i n f o r m a t i o n c o n t a i n e d h e r e i n .Product data sheetCharacteristicsTM221CE40Rcontroller M221 40 IO relay EthernetMainRange of product Modicon M221Product or component typeLogic controller [Us] rated supply volt-age100...240 V ACDiscrete input number 24 discrete input conforming to IEC 61131-2 Type 1including 4 fast input Analogue input number 2 at input range: 0...10 V Discrete output type Relay normally open Discrete output number 16 relay Discrete output voltage 5...250 V AC 5...125 V DC Discrete output current2 AComplementaryDiscrete I/O number40Number of I/O expansion module <= 7 with <= 48 discrete output(s) for relay output Supply voltage limits 85...264 V Network frequency 50/60 Hz Inrush current<= 40 APower consumption in VA <= 70 VA at 100...240 VDiscrete input logic Sink or source (positive/negative)Discrete input voltage 24 V Discrete input voltage type DC Analogue input resolution 10 bits LSB value 10 mVConversion time1 ms per channel + 1 controller cycle time for analog input Permitted overload on inputs +/- 15 V DC for analog input permanent+/- 30 V DC for analog input with 5 min maximum Voltage state1 guaranteed >= 15 V for input Current state 1 guaranteed >= 2.5 mA for input Voltage state 0 guaranteed <= 5 V for input Current state 0 guaranteed <= 1 mA for input Discrete input current 7 mA for inputInput impedance 100 kOhm for analog input 3.4 kOhm for discrete inputResponse time10 ms turn-off operation for output 10 ms turn-on operation for output 5 µs turn-off operation for fast input 5 µs turn-on operation for fast input100 µs turn-off operation for input; I8...I15 terminal 100 µs turn-on operation for input; I8...I15 terminal 35 µs turn-off operation for input; I2...I5 terminal 35 µs turn-on operation for input; I2...I5 terminal Configurable filtering time12 ms for input 3 ms for input 0 ms for input Output voltage limits 277 V AC 125 V DC Current per output common 8 AAbsolute accuracy error+/- 1 % of full scale for analog inputElectrical durability Inductive (L/R = 7 ms) DC-13, 24 V/ 7.2 W : 300000 cyclesInductive (L/R = 7 ms) DC-13, 24 V/ 24 W : 100000 cyclesResistive DC-12, 24 V/ 16 W : 300000 cyclesResistive DC-12, 24 V / 48 W : 100000 cyclesInductive AC-14, (cos phi = 0.7) 240 V/ 72 VA : 300000 cyclesInductive AC-14, (cos phi = 0.7) 120 V/ 36 VA : 300000 cyclesInductive AC-14, (cos phi = 0.7) 240 V/ 240 VA : 100000 cyclesInductive AC-14, (cos phi = 0.7) 120 V/ 120 VA : 100000 cyclesInductive AC-15, (cos phi = 0.35) 240 V / 36 VA : 300000 cyclesInductive AC-15, (cos phi = 0.35) 120 V/ 18 VA : 300000 cyclesInductive AC-15, (cos phi = 0.35) 240 V / 120 VA : 100000 cyclesInductive AC-15, (cos phi = 0.35) 120 V/ 60 VA : 100000 cyclesResistive AC-12, 240 V/ 160 VA : 300000 cyclesResistive AC-12, 120 V / 80 VA : 300000 cyclesResistive AC-12, 240 V/ 480 VA : 100000 cyclesResistive AC-12, 120 V / 240 VA : 100000 cyclesSwitching frequency20 switching operations/minute with maximum loadMechanical durability>= 20000000 cycles for relay outputMinimum load10 mA at 5 V DC for relay outputReset time 1 sMemory capacity256 kB for program with 10000 instructionsData backed up256 kB built-in flash memory for backup of programsData storage equipment 2 GB SD card optionalBattery type BR2032 lithium non-rechargeable, battery life: 4 yrBackup time 1 year at 25 °C by interruption of power supplyExecution time for 1 KInstruction0.3 ms for event and periodic taskExecution time per instruction0.2 µs BooleanExct time for event task60 µs response timeClock drift<= 30 s/month at 25 °CRegulation loop Adjustable PID regulator up to 14 simultaneous loopsControl signal type Single phase signal at 100 kHz for fast input (HSC mode)Pulse/Direction signal at 100 kHz for fast input (HSC mode)A/B signal at 50 kHz for fast input (HSC mode)Counting input number 4 fast input (HSC mode) (counting frequency: 100 kHz), counting capacity: 32bitsIntegrated connection type Ethernet with connector RJ45Non isolated serial link "serial 1" with connector RJ45 and interface RS232/RS485USB port with connector mini B USB 2.0Supply Serial serial link supply at 5 V 200 mATransmission rate480 Mbit/s - communication protocol: USB1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m - communicationprotocol: RS2321.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m - communicationprotocol: RS485Communication port protocol Non isolated serial link : Modbus protocol master/slave - RTU/ASCII or SoMa-chine-NetworkUSB port : USB protocol - SoMachine-NetworkPort Ethernet10BASE-T/100BASE-TX 1 port with 100 m copper cableCommunication service DHCP clientModbus TCP serverModbus TCP clientModbus TCP slave deviceLocal signalling Ethernet network link yellow for Link (Link Status)Ethernet network activity green for ACT1 LED green for SL1 LED per channel green for I/O state1 LED red for BAT1 LED green for SD card access (SD)1 LED red for module error (ERR)1 LED green for RUN1 LED green for PWRElectrical connection Mini B USB 2.0 connector for a programming terminalConnector, 4 terminal(s) for analogue inputsTerminal block, 3 terminal(s) for connecting the 24 V DC power supplyRemovable screw terminal block for outputsRemovable screw terminal block for inputsCable length<= 30 m unshielded cable for output<= 10 m shielded cable for fast input<= 30 m unshielded cable for inputInsulation Non-insulated between analogue inputsNon-insulated between analogue input and internal logic500 V AC between output groups500 V AC between output and internal logicNon-insulated between inputs500 V AC between fast input and internal logic500 V AC between input and internal logicMarking CESensor power supply24 V DC at 250 mA supplied by the controllerMounting support Plate or panel with fixing kitTop hat type TH35-7.5 rail conforming to IEC 60715Top hat type TH35-15 rail conforming to IEC 60715Height70 mmDepth70 mmWidth160 mmProduct weight0.456 kgEnvironmentStandards EN/IEC 61131-2EN/IEC 61010-2-201Product certifications CSACULusIACS E10RCMResistance to electrostatic discharge 4 kV on contact conforming to EN/IEC 61000-4-28 kV in air conforming to EN/IEC 61000-4-2Resistance to electromagnetic fields 1 V/m ( 2 GHz...3 GHz) conforming to EN/IEC 61000-4-33 V/m ( 1.4 GHz...2 GHz) conforming to EN/IEC 61000-4-310 V/m ( 80 MHz...1 GHz) conforming to EN/IEC 61000-4-3Resistance to magnetic fields30 A/m at 50...60 Hz conforming to EN/IEC 61000-4-8Resistance to fast transients 1 kV for serial link conforming to EN/IEC 61000-4-41 kV for Ethernet line conforming to EN/IEC 61000-4-41 kV for I/O conforming to EN/IEC 61000-4-42 kV for relay output conforming to EN/IEC 61000-4-42 kV for power lines conforming to EN/IEC 61000-4-4Surge withstand 1 kV for relay output in differential mode conforming to EN/IEC 61000-4-51 kV for power lines (AC) in differential mode conforming to EN/IEC 61000-4-50.5 kV for power lines (DC) in differential mode conforming to EN/IEC 61000-4-51 kV for shielded cable in common mode conforming to EN/IEC 61000-4-51 kV for I/O in common mode conforming to EN/IEC 61000-4-52 kV for relay output in common mode conforming to EN/IEC 61000-4-52 kV for power lines (AC) in common mode conforming to EN/IEC 61000-4-51 kV for power lines (DC) in common mode conforming to EN/IEC 61000-4-5Resistance to conducted disturbances, induced by radio frequency fields 10 Vrms (spot frequency (2, 3, 4, 6.2, 8.2, 12.6, 16.5, 18.8, 22, 25 MHz)) con-forming to Marine specification (LR, ABS, DNV, GL)3 Vrms (0.1...80 MHz) conforming to Marine specification (LR, ABS, DNV, GL) 10 Vrms (0.15...80 MHz) conforming to EN/IEC 61000-4-6Electromagnetic emission Radiated emissions conforming to EN/IEC 55011 class A 10 m, 230 MHz (1)GHz : 47 dBμV/m QPRadiated emissions conforming to EN/IEC 55011 class A 10 m, 30...230 MHz :40 dBμV/m QPConducted emissions conforming to EN/IEC 55011 power lines, 1.5...30 MHz : 63dBμV/m QPConducted emissions conforming to EN/IEC 55011 power lines, 150 kHz...1.5MHz : 79...63 dBμV/m QPConducted emissions conforming to EN/IEC 55011 power lines, 10...150 kHz :120...69 dBµV/m QPConducted emissions conforming to EN/IEC 55011 power lines (AC), 0.5 (300)MHz : 73 dBμV/m QP/60 dBμV/m AVConducted emissions conforming to EN/IEC 55011 power lines (AC), 0.15...0.5MHz : 79 dBμV/m QP/66 dBμV/m AVImmunity to microbreaks10 msAmbient air temperature for operation-10...35 °C for vertical installation-10...55 °C for horizontal installationAmbient air temperature for storage-25...70 °CRelative humidity10...95 % without condensation in storage10...95 % without condensation in operationIP degree of protection IP20 with protective cover in placePollution degree<= 2Operating altitude0...2000 mStorage altitude0...3000 mVibration resistance 3 gn (vibration frequency: 8.4...150 Hz) on panel mounting3.5 mm (vibration frequency: 5...8.4 Hz) on panel mounting3 gn (vibration frequency: 8.4...150 Hz) on symmetrical rail3.5 mm (vibration frequency: 5...8.4 Hz) on symmetrical rail Shock resistance10 gn (test wave duration:11 ms)Product data sheetTM221CE40R Dimensions DrawingsDimensionsProduct data sheetMounting and ClearanceTM221CE40RMounting on a RailDirect Mounting on a Panel Surface(1)Install a mounting stripMounting Hole LayoutMountingCorrect Mounting PositionAcceptable Mounting PositionIncorrect Mounting PositionClearanceProduct data sheetConnections and SchemaTM221CE40RDigital InputsWiring Diagram (Positive Logic)(*)Type T fuseWiring Diagram (Negative Logic)(*)Type T fuseConnection of the Fast InputsRelay OutputsPositive Logic (Sink)(*)Type T fuse(1)The COM0, COM1, COM2 and COM3 terminals are not connected internally.(2)To improve the life time of the contacts, and to protect from potential inductive load damage, you must connect a free wheeling diode in parallel to each inductive DC load or an RC snubber in parallel of each inductive AC loadNegative Logic (Source)(*)Type T fuse(1)The COM0, COM1, COM2 and COM3 terminals are not connected internally.(2)To improve the life time of the contacts, and to protect from potential inductive load damage, you must connect a free wheeling diode in parallel to each inductive DC load or an RC snubber in parallel of each inductive AC loadAnalog InputsThe (-) poles are connected internally.Ethernet ConnectionUSB Mini-B ConnectionSL1 ConnectionSL1N.C.: not connectedProduct data sheet Performance Curves TM221CE40RDerating CurvesEmbedded Digital Inputs (No Cartridge)X :Ambient temperature Y :Input simultaneous ON ratioEmbedded Digital Inputs (with Cartridge)X :Ambient temperature Y :Input simultaneous ON ratioTM221CE40R TM221CE40R.。
INSTRUMENTSDESIGN FEATURESTeledyne Hastings Instruments (THI) prod-ucts represent over 55 years of experience in the design and manufacture of mass flow products. The 300 Series is a culmination of this experience with patented technologies that make these the finest flowmeters and controllers available today.The THI Mass Flow 300 Series products are designed to accurately measure mass flow without corrections or compensations for gas pressure and temperature. They are accurate to better than ±1.0% of full scale. THI mass flow instruments do not require any periodic maintenance under normal operating conditions with clean gases. No damage will occur from the use of moder-ate overpressures (~500 psi) or overflows. Instruments are normally calibrated with the appropriate standard calibration gas (air), then a gas conversion factor (GCF) is used to adjust the output for the intended gas. Special calibrations for other gases, such as oxygen, helium and argon, are available upon special order.The 300 Series products contain a number of features that set them apart from other available instruments: (1) They are inherently linear; no linearization circuitry is employed. Should recalibration in the field be desired (a calibration standard is required), the cus-tomer needs to simply set the zero and span points. (2) The output signal is linear for very large overflows and will not come back on scale when a flow an order of magnitude over the full scale flow rate is measured. (3) The instrument incorporates a remov-able/replaceable sensor module. (4) The unit has very fast settling times.Models HFM-305,HFC-307FEATURES• Range — 1000-2500 slm (Air Equivalent); Higher Flows Available • ±1.0% of Full-Scale Accuracy 1• Rapid Settling Times: HFM-305 ≤ 0.4 seconds HFC-307 ≤ 2.0 seconds • Operating Pressures to 500 PSI • NIST Traceable Calibration APPLICATIONS• Gas Blending • Research• R&D and Process Flows •Pollution MonitoringHFM-305HFC-307Teledyne Hastings Instruments reserves the right to change or modify the design of its equipment without any obligation to provide notification of change or intent to change.1See Product Manual for critical information on instrument accuracy and the use of GCFs (gas conversion factors). Stated accuracy is for nitrogen or other gas specific calibration and use with this gas only.Kalrez ® is a registered trademark of Dupont Dow Elastomers L.L.C.Swagelok ® is a registered trademark of Crawford Company.VCR ® is a registered trademark of Cajon Company.VCO ® is a registered trademark of Cajon Company.Viton ® is a registered trademark of Dupont Dow Elastomers L.L.C.DESIGN FEATURES (cont)Optional FeaturesFittings–VCR ®, VCO ®and Swagelok ®Cleaned for oxygen serviceAccessoriesPower supplies/readouts Flow totalizers Alarm set pointsInterconnecting cables*Note: After changing components, instruments require recalibration to meet accuracy specifications.Model HFM-305Model HFC-307All dimensions shown are in inches [mm].Your Customer Service RepresentativeTelephone: (757) 723-6531 Toll Free: (800) 950-2468 Fax: (757) 723-3925World Wide Web: E-mail: *********************************P.O. Box 1436Hampton, VA 23661PB 152-10/05 © Teledyne 2005 All Rights Reserved.Typical instrument ordering/options number:Model No. Circuit Output FittingsSeals Pressure CalibrationBoard TypeHFM-305010102010101Order No.OptionsCircuit Board 01 Pinout H (Standard)02 Pinout U 03 Pinout M Output01 0-5 Volts (Standard)024-20mAOrder No.OptionsFittings 01 1” VCR ®02 1” Swagelok (Standard)03 1” VCO ® Seals01 Viton (Standard)02 Kalrez ®03 Neoprene 04Buna NSelection ChartRange InformationRange _____________________________Flow Units __________________________Gas _______________________________Standard Conditions* _________________*Referenced to standard temperature and pressure (0°C and 760 Torr, respectively).Order No. OptionsPressure 01 500 psi (Standard) Calibration Type 01 NIST 5 Point (Standard)02 NIST 10 Point 03 NIST 20 Point 04 CurveTypical instrument ordering/options number:Model No. Circuit Output FittingsSeals Pressure CalibrationBoard TypeHFC-307010102010101Order No.OptionsCircuit Board 01 Pinout H (Standard)02 Pinout U 03 Pinout M Output01 0-5 Volts (Standard)02 4-20mA 03I/O 4-20mAOrder No.OptionsFittings 01 1” VCR ®02 1” Swagelok (Standard)03 1” VCO ® Seals01 Viton (Standard)02 Kalrez®03 Neoprene 04Buna NSelection ChartOrder No. OptionsPressure 01 500 psi (Standard) Calibration Type 01 NIST 5 Point (Standard)02 NIST 10 Point 03 NIST 20 Point 04 CurveRange InformationRange _____________________________Flow Units __________________________Gas _______________________________Upstream Pressure ___________________Downstream Pressure _________________Is downstream pressure dependent on flowresistance? Y/N ___________________Standard Conditions* _________________*Referenced to standard temperature and pressure (0°C and 760 Torr, respectively).。
—A B B M E A SU R EM ENT & A N A LY TI C S | I NS TRUC TI O N | I N/A N A I N S T/048-EN R E V. AADS420Dissolved oxygen probeT-piece assembly and cleaningadaptor kitMeasurement made easyIntroductionThis publication details part numbers and installation procedures for the T-piece assembly (bayonet) and a cleaning adaptor kit for use with the ADS420 dissolved oxygen probe.The procedures must be carried out by a trained technician.RequirementsTable 1 Items requiredPart number Description Quantity –PTFE tape as required –Adjustable spanner1For more informationPublications for the associated sensors and transmitters are available for free download from: /measurementor by scanning this code:Search for or click on: Data SheetADS420 dissolved oxygen probe DS/ADS420-EN Operating InstructionADS420 dissolved oxygen probe OI/ADS420-EN—ADS420 dissolved oxygen probeT-piece assembly and cleaning adaptor kit2A DS420| T-PIECE A SSEM B LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A1 Health & SafetyDocument symbolsSymbols that appear in this document are explained below:Potential safety hazards2 SpecificationsMaterialT-piece body (NPT)30 % GF polypropyleneCleaning adaptor and blanking nut316 stainless steelBayonet adaptor O-ringVitonOperating process pressureMaximum: 6 bar (87 psi)*Operating process temperature range0 to 50 °C (0 to 122 °F)* Cleaning solution pressure to be 1 bar (14.5 psi) higher than process pressureA DS420| T-PIECE A SSEMB LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A33 IdentificationTable 2 T-piece assembly 3KXA494400L0012Description Part no.RDO T-piece Bayonet Assembly: NPT BayonetT-piece, RDO T-Piece Bayonet Adaptor3KXA494400L0012This instruction: T-piece assembly and cleaningadaptor kitIN/ANAINST/048-ENTable 3 RDO cleaning adaptor kit 3KXA494400L0011Description Part no.RDO Cleaning adaptor kit: RDO T-piececleaning adaptor3KXA494400L0011This instruction: T-piece assembly and cleaning adaptor kit IN/ANAINST/048-EN4 DimensionsClearanceAllow sufficient clearance for hand-mounting between theT-piece assembly install location and closest adjacent/installation surface.Dimensions in mm (in).Figure 1 Recommended clearance between T-pieceand installation surfaceT-piece assembliesReferring to Figure 2, the following T-piecemounting accessories are available:• with a bayonet sensor fitting B• with or without the optional jet wash system(blanking nut Cshown in place of cleaning adaptor)Min. 30(1.18)4A DS420| T-PIECE A SSEM B LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A…4 DimensionsBayonet T-piece assemblyFigure 2 Bayonet T-piece assembly – NPTJet wash cleaning adaptorFigure 3 Jet wash cleaning adaptorA DS 420 | T-PIECE A SSEMB LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A 55InstallationBayonet T-piece assemblyReferring to Figure 4:1 Connect the T-piece E to the process line using the 1 in NPT connectors at the threaded inlet/outlet.2 Apply PTFE tape (or similar) around the probe thread B .3 Connect the sensor C into the bayonet adaptor D and tighten it.4 Install the bayonet D into the T-piece E and twist it until the bayonet is locked in position.5 Commission the process, ensuring the T-piece/sensor assembly does not leak.Figure 4 Bayonet T-piece assembly installation – NPTCleaning adaptorReferring to Figure 5:1 Loosen the blanking nut A from the base the cleaning adaptor entry B .2 Put the EZClean cleaning adaptor C into the adaptor entry B , and tighten it with a 14 mm A/F open-ended spanner.3 Connect the push-fit connector and air supply using 6 mm OD semirigid tubing.Refer to OI/EZCLEAN-EN for instructions to configure the EZClean air blast system.4 Commission the process, ensuring the T-piece/sensor assembly does not leak.Figure 5 Jet wash cleaning adaptor6A DS420| T-PIECE A SSEM B LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A NotesA DS420| T-PIECE A SSEMB LY A N D CL E A N I N G A DA P TO R K IT | I N/A N A I NS T/048-EN R E V. A7 NotesI N /A N A I N S T /048-E N R e v . A 04.2022—We reserve the right to make technical changes or modify the contents of this document without prior notice. With regard to purchase orders, the agreed particulars shall prevail. ABB does not accept any responsibility whatsoever for potential errors or possible lack of information in this document.We reserve all rights in this document and in the subject matter and illustrations contained therein. Any reproduction, disclosure to third parties or utilization of its contents – in whole or in parts – is forbidden without prior written consent of ABB.© ABB 20223KXA494403R3101—ABB Measurement & Analytics For your local ABB contact, visit:/contactsFor more product information, visit:/measurement。
