AMI BIOS汇总

Advanced
USB Configuraion(USB装置设置)
USB Function [x USB ports] USB端口开启个数
Legacy USB support [auto] USB端口自动检测设置
USB 2.0 Controller [Enabled] USB控制器开关
DDR Reference Voltage [Auto] 内存电压设置
AGP VDDQ Voltage [1.50V] AGP设备电压设置
configure advanced CPU settings （CPU信息）
Manufacturer:xxxxxxx 品牌
configure system frequency/voitage
AI Overclock tuner 智能CPU频率设置
performance Mode 增强型模式
选项
Manual 手动设置
Standard 标准模式
Overclock 5% 步进超频
Configure System Frequency/Voltage
Power
Hardware Monitor(系统监控)
CPU Temperature [xx℃/xxx'F] CPU温度
MB Temperature [xx℃/xxx'F] 系统温度
Power Temperature [N/A] 电源温度
ICH Delayed Transaction [Enabled] ICH延时控制
MPS Revision [1.1] MPS修正
Onboard AC'97 Audio [auto] 声卡设定

最全面的AMI BIOS设置图解教程开机显卡自检测完成后，点击＜DEL键＞即可进入AMI BIOS SETUP设置界面主菜单。

进入了AMI BIOS NEW SETUP UTILITY 设定工具, 屏幕上会显示主菜单。

主菜单共提供了十二种设定功能和两种退出选择。

用户可通过方向键选择功能项目, 按键可进入子菜单。

默认设置BIOS setup程序有两种默认的设置：BIOS Setup设置和High Performance Defaults设置。

BIOS Setup Defaults设置提供了所有设备和系统的稳定但最小效能的设置。

而High Performance Defaults设置提供了最好的系统效能，但有可能导致系统不稳定。

Standard CMOS Features(标准CMOS设定)使用此菜单可对基本的系统配置进行设定。

如时间，日期等。

Advanced BIOS Features(Advanced Chipset Features(Power Management Features(PNP/PCI ConfigurationsIntegrated PeripheralsPC Health StatusFrequency/Voltage ControlSet Supervisor PasswordSet User PasswordLoad High Performance DefaultsLoad BIOS Setup DefaultsSave & Exit SetupExit Without Saving（不保存退出）放弃对CMOS的修改，然后退出Setup程序。

（保存后退出）保存对CMOS的修改，然后退出Setup程序。

（载入BIOS设定值缺省值）使用此菜单可以加载主板制造商提供的最小稳定的方式运行设置的一组默认值。

（载入高性能缺省值）使用此菜单可以加载主板制造商提供的为较高的性能优化过的BIOS设定值。

AMIBIOS模块结构详解完整版AMI BIOS模块结构详解完整版首先在讲AMI BIOS模块结构前,需要向大家说一样东西,就是逻辑地址.逻辑地址的形式如:XXXX:XXXX,其中前四位是段地址,后四位是偏移地址,比如ABCD:1234 物理地址=段地址*10H+偏移地址所以ABCD:1234的物理地址=ABCDH*10H+1234H=ACF04H 而ACF04H这个物理地址是相对于1M噶地址空间的如果你的BIOS大小是1M噶话那么物理地址就是ACF04H如果BIOS不是1M的话那么就要对物理地址进行换算好有条公式: BIOS文件在WINHEX中的地址 = BIOS文件相对于1M空间的地址- 常数,注:常数是根据每个BIOS的大小而确定的常数=(1024-你BIOS的大小(KB))*1024.比如你的BIOS是512KB的话那么常数就是常数=(1024-512)*1024=524288D=80000H所以ABCD:1234在512KB的BIOS中 BIOS文件在WINHEX中的地址就=ABCDH*10H+1234H-80000H=2CF04HOK 现在各位应该明白逻辑地址转化为物理地址的方法了用WINHEX打开AMI BIOS可以搜索到AMIBIOSC的字符串这里隐含很多秘密如下:(这个BIOS 512KB的)用WINHEX打开AMI BIOS可以搜索到AMIBIOSC的字符串这里隐含很多秘密.如下:(这个BIOS 512KB的)Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F00067FE0 00 00 00 00 00 00 00 00 08 0A 41 4D 49 42 494F ..........AMIBIO00067FF0 53 43 30 38 30 30 06 CE 21 40 BC 75 0C 00 83 E7 SC0800.?@紆..冪这里一共20H具体结构如下:0-2H 保留供将来使用3H 一般都是00 如果不是00的话发BIOS给我4-5H BIOS映像版本8H 都是08的9H 都是0A的 (AMIBIOSC08的长度)A-13H AMIBIOSC14-17H BIOS 核心版本18-1BH BIOS校验位1C-1DH 第一个模块的偏移地址1E-1FH 第一个模块的段地址由此可知在这个BIOS里面第一个模块的逻辑地址是 E783:000C 所以物理地址=E7830H+000CH-80000H=6783CH6783CH-8H就是第一个模块的地址了至于为什么要-8H 你自己看一下就知道了OK 第一个模块的地址找到了继续研究一下第一个模块的头部看看有什么秘密Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F 00067830 00 FF FF FF 98 07 00 00 F3 C3 B9 AA 10 00 1B E2 00067840 98 07 08 80 00 00 00 00 01 00 0C 00 20 35 01 00其中红色部分的14H就是模块头了单独提取出来Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F 00000000 98 07 00 00 F3 C3 B9 AA 10 00 1B E2 98 07 08 80 00000010 00 00 00 00 0-3H 模块大小4-7H 校验位8-9H 下一个模块的偏移地址A-BH 下一个模块的段地址C-DH 模块大小EH 模块IDFH 模块属性由此可知该模块的模块大小是0798H 校验位AAB9C3F3 下一个模块的地址为E21B:0010 模块ID为08从此可以得知下一个模块的位置如此类推......................直到最后一个模块Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F00000FD0 44 00 00 00 92 9F 03 15 FF FF FF FF 44 00 80 80 00000FE0 00 00 00 00 07 00 10 02 01 00 00 14 00 20 08 01 红色的就是模块头最后一个模块的模块头的8-BH都是FF FF FF FF的表示是最后一个模块了OK AMI BIOS模块机构详解到此完毕。

ami bios 设置全程图解（AMI BIOS settings throughout thediagram）Main (system settings)System time system time settingsSystem date date setAMIBIOS BIOS informationProcessor CPU InformationSystem memory memory informationAdvanced (advanced settings)Set the jumperfree cunflguratfon CPU memory parametersSet the CPU configuration CPUChipset chip setOnboard Devices Configuration integrated hardware device set The PCIpnp PCI setting deviceUSB Configuration USB device setInstant Music Configuration start free music setConfigure system frequency/voitageAI Overclock tuner CPU intelligent frequency settingPerformance Mode enhanced modeloptionSet manual ManualStandard standard modeOverclock 5% step overclockingConfigure System Frequency/VoltageCPU External Frequency {MHz} [xxxx] CPU FSB setDRAM Frequency [Auto] memory frequency settingsAGP/PCI Frequency {MHz} [Auto]AGP/PCI frequency setting equipmentCPU VCore Voltage [Auto] CPU core voltage settingsDDR Reference Voltage [Auto] memory voltage settingsAGP VDDQ Voltage [1.50V] AGP voltage equipment setConfigure advanced CPU settings (CPU)Manufacturer:xxxxxxx brandBrand String:xxxxxxx CPU informationFrequency: the CPU running at xxxxxxMHzFSB Speed: xxxxxxMHz CPU front busCache L1:xxxxxxxxxKB cacheCache L2:xxxxxxxxxKB two level cacheCache L3:xxxxxxxxxKB three level cacheMax CPUUID Value Limit [Disabld] CPU switchCPU Enhanced C1 Cintrol [auto] enhanced control switchCPU Internal Thermal Control [auto] CPU internal temperature control switchHyper Threading Technology [Enabled] CPU hyperthreaded switchAdvanced (Advanced chipset setup)Advanced Chipset SettingsConfigure DRAM Timing by SPD [Enablde] SDRAM clock setMemory Acceleration Mode [auto] memory acceleration controlDRAM Idle Timer [auto] memory free controlDRAM Refresh Rate [auto] memory update controlGraphic Adapter Priority [AGP/PCI] AGP/PCI priority settingsGraphics Aperture Size [xxxxMB] AGP graphics card memory settingsSpread Spectrum enhanced [Enabled] spectraICH Delayed Transaction [Enabled] ICH delay controlMPS Revision [1.1] MPS correctionOnboard AC'97 Audio [auto] sound card set板载LAN [启用]网卡设定板载网卡启动ROM ROM开关网卡[禁用]串行端口地址[ 3F8 / IRQ4 COM1序列地址]串行端口地址[ 2F8 / IrQ3型] COM2序列地址并行端口地址[禁用]井口序列地址板载游戏/ MIDI端口[禁用]游戏摇杆接口设定先进的先进的PCI / PNP设置（PCI设备设置）即插即用的O / S的[没有] PCI端口系统识别控制PCI延迟定时器[XX] PCI延时设置分配IRQ的PCI VGA [是]显卡中断位置设置PCI IRQ调色板窥探[禁用]特殊非标准显卡设置PCO IDE总线主控[启用] PCI IDE装置控制读写先进的USB（USB装置设置）配置USB功能的USB端口的USB端口开启个数[×]usb支持USB端口自动检测设置[汽车]USB 2控制器的USB控制器开关[启用]USB 2控制器模式[将] USB传输模式USB海量存储设备的配置大型存储装置设定功率（系统电源管理）挂起模式[汽车]系统省电设置reppost视频S3恢复[没有]唤醒系统时是否显示VGA画面支持ACPI 2 [没有] acpi2.0支持设置ACPI APIC支持[启用]是否增加ACPI APIC到rsdt清单、APM配置高级电源设置硬件监测上的系统监控功率APM的配置（高级电源设置）电源管理/ APM [启用]是否开启电源进阶管理与功能视频省电模式[禁用]是否在视频停止后进入省电模式硬盘电源关闭模式[禁用]是否在硬盘停转后进入省电模式暂停时间[禁用]进入省电模式的时间油门慢时钟率××%系统进入省电模式的运行速度[ ]电源键模式[开关]按关机键是进入休眠模式还是关机在交流电源的损失[关机]断电后再开启恢复断电前状态恢复电由RTC报警[禁用]自动定时唤醒设置电源由外部调制解调器[禁用]远程唤醒设置电源的PCI设备的PCI设备唤醒设置[禁用] 在PS / 2键盘[禁用]键盘唤醒设置功率在PS / 2鼠标[禁用]鼠标唤醒设置功率功率硬件监控（系统监控）CPU温度[ XX℃/ xxx'f ] CPU温度MB温度[ XX℃/ xxx'f ]系统温度功率温度[ / ]电源温度风扇速度调整Q-FAN控制[禁用]CPU风扇转速xxxxrpm CPU风扇转速[ ]机箱风扇转速[ / ]机箱风扇转速电源风扇转速[ / ]电源风扇转速Vcore电压[性质]电压监控3.3V电压[性质]电压监控5V电压[性质]电压监控[性质]电压监控12V电压靴子启动设置（启动选单）启动设备优先级启动装置顺序可移动驱动器移动装置顺序光盘驱动器光驱启动顺序启动设置配置启动选项设定安全安全性选项启动启动设备优先级（启动设备顺序）第一启动设备[3M迈拓]第一启动盘第二启动设备[禁用]第二启动盘启动设置启动项（启动选项设置）快速启动[启用]快速启动设置全屏标志[启用]开机画面设置插件ROM BIOS显示模式[力]附件装置软件显示模式Num Lock小键盘锁定设置启动[上]PS / 2鼠标支持[汽车] PS / 2鼠标开关击键速度键盘反映频率设置[快速]启动OS / 2 [不] OS / 2系统设置等待“F1”如果错误[启用]错误信息提示设置点击“删除”消息显示[启用]按下del指示提示设置中断19捕获[禁用] PCI内键程序启动设置启动安全设置（系统安全设定）dupervlsor系统管理员密码设定更改密码引导扇区病毒保护[禁用]防病毒保护开关出口退出选项（退出BIOS程序设置）退出并保存更改退出并保存设置退出和放弃改变退出而放弃设置Discard Changes give up set but not quit the BIOS programLoad Setup Defaults according to factory settings((((A.Main (standard set)This menu is available on the basic system configuration settings. Such as time, date etc.amongPrimary/Secondary IDE Master/Slave is a device from the main IDE.If your motherboard supports SATA interface will haveThird/Fourth IDE Mastert or more, they are all inside the computer management cases of IDE driving device, such as a hard disk, CD-ROM etc.! Because each motherboard is different, so this is not a detailed explanation of the set, but the general users do not have to use the default settings, the general can, if there are special requirements, it is recommended that users control instructions that are set up in the forum, or separate questions!System InformationThis is the basic hardware information display system, not what good (Figure 3)Understand the basic settings after entering the advanced settings!Two.Advanced (advanced settings) as shown in figure 4:Here is the core of Bios is set, the novice must be carefully set, because of the direct relationship between the stability of the system and the safety of the hardware, do not blindly set!1. we first see is the "JumperFree Configuration" (different brands of the motherboard may be different, there may be no longer) here can set some parameters of CPU, for the love of friends here is the main overclocking! (Figure)You can see a "AI Overclock Tumer" option, in which there are some options, as shown above, the "Manual" as the key, you will see the following chart selection:For CPU overclocking enthusiasts these things should be well known, CPU (CPU External Frequency) the FSB set is one of the key of overclocking, CPU frequency (i.e. within we usually said P4 3.0G frequency) is multiplied by the value of frequency and frequency, such as a 3.0G CPU in the FSB is 200 time of his frequency is 15 (200MHz*15 = 3000MHz). The range can be set for general FSB 100MHz to 400MHz, but the real 300 CPU are not many, so do not blindly set high FSB, a general setting range is about 100-250 about users set to have a little bit of heightening patient, it is best to 1MHz step, plus a little bit, to to prevent excessive one-time system cannot be used normally oreven damage CPU!Memory frequency setting (DRAM Frequency) using this set of installed memory clock, set the options: 200MHz, 266MHz, 333MHz, 400MHz, Auto.AGP/PCI (AGP/PCI Frequency), the frequency setting operation frequency of this project can modify the AGP/PCI equipment, in order to obtain better system performance and overclocking performance, setting value: [Auto], [66.66/33.33],[72.73/36.36]. But please set the appropriate user, if improper setting may cause AGP/PCI equipment can not be used normally!Needless to say the voltage setting,Is the working voltage setting device, recommended for most users do not easily modify, so as to prevent damage to the unit because the voltage is not correct! Is the user to modify must not blindly, to step the way a little bit of pressure, the maximum value should not exceed 0.3V.2. CPU Configuration (CPU) of this project can let you know the related index of CPU and change CPU.Here you can get all kinds of information CPU, because this is the latest ASUS Bios program, so it increased the number of new CPU information, such as the three level cache, and adds to the enhanced options Intel64 CPU! But these projects for the general CPU is not what meaning! Some of the options here basically don't change, but here is the most meaningful option is the last Hyper Threading Technology option, which isswitched on P4 CPU hyper threading, hyper threading CPU with P4 user should know that some programs can not well support hyper threading technology, and sometimes even lead to crashes, such as the Internet WinXP SP1 IE P4 hyperthreaded users have frequent crashes the CPU occupancy rate of 100%, this is because it cannot fully support hyper threading technology (but as long as the update to the SP2 update or upgrade the system without this problem.) then we can close the hyper threading technology CPU, as long as the value of the can be set to Disabled! But this will not be able to fully play the performance of P4 hyper threading CPU!3. Chipset (Advanced chipset features) using this menu you can modify the chipset registers, the performance optimization system.Configure SDRAM Timing bySetting determines whether the SDRAM clock is set by reading the memory module of SPD (SerialPresence Detect) EEPROM content. According to the SPD set to Enabled will automatically set the project, if you have the option not to Disabled, will appear the following items: SDRAM CAS# Latency, DRAM RAS Precharge, DRAM RAS to CAS Delay DRAM, precharge Delay and DRAM Burst Length. If you are not familiar with these settings do not modify the chip group.SDRAM CAS# Latency (SDRAM CAS# delay)Control and accept the start delay time after read command in SDRAM (in clock cycles). Set value: 2, 2.5, 3 (clocks). Thesmaller the value of the more powerful performance! But the relative decline of stability!DRAM RAS Precharge (Precharge command delay)The project control when SDREM sends a Precharge command, how much time will no longer send command. Set value: 4, 3, 2 (clocks)RAS to CAS Delay (delay RAS to CAS)When DRAM refresh after all ranks to separate addressing. This setting allows you to decide from RAS (row address filtering) conversion to CAS (column address filtering) delay time. A smaller clock cycle will make DRAM performance faster. Set value: 4, 3, 2 (clocks)DRAM precharge Delay (pulse cycle)This setting is used to control for SDRAM clock cycle using SDRAM parameters! Set value: 8, 7, 6, 5 (clocks)SDRAM Burst Length (SDRAM access burst length)This setting allows you to set the length of the size of the outbreak of DRAM access. The outbreak is characterized in that the DRAM forecast their location of each memory access technology in the first address. Using this feature, you must define the burst length, is the beginning of the actual length of the pulse burst. At the same time allows the internal address counter can correctly generate the next address location. Thelarger the size of memory more quickly. Setting: 4, 8 (clocks).AGP Aperture Size (AGP memory allocation)This system is used to control the number of memory can be allocated to the AGP display card. The aperture is used for graphics memory address space of a part of the PCI memory address range. Enter the aperture within the scope of the master clock cycle will be translated directly to AGP. Setting: 4MB, 8MB, 16MB, 32MB, 64MB, 128MB, and MB 256.4.OnBoard Devices Configuration (integrated equipment set)Here are some options to manage a variety of integrated motherboard hardware facilities, users basically do not change the settings! This is no longer so paralepsis! Such as the need to change, please check the motherboard manual!5.PCI Pnp (plug and play device settings)Here is the setting plug project advanced settings and PCI, users do not need to change any item, you can keep the default. In this set, incorrect values will lead to damage to the system!B Configuration (USB device)USB port device settings, everyone can understand, no need to say more! Only the transmission mode which has a FullSpeed and HiSpeed, if we USB2.0 it is set to HiSpeed, FullSpeed is a simulation of high speed transmission, no HiSpeed fast!Three.Power (power management settings) figure:In front of four without what good talk, because the motherboard brand is different, so there may be some users do not have the above options, including APM Configuration (advanced power setting) and Hardware Monitor (monitoring system) two options.1. APM Configuration (advanced power setting)2.Hardware Monitor (monitoring system)Four.Boot (boot device)This menu is to change the system boot device and related settings, are more important in Bios.1. Boot Device Priority (boot device)This project is set to start when the system starts the memory order, such as we have to start from the CD-ROM during installation of the operating system, we must take the 1st Device Priority is set to become your CD-ROM, figure is arranged on the hard disk, so when the system boots the first startup is hard, if not to suggest that you start from the CD-ROM. The first startup settings become hard disk, other startup items set to Disable, this system will start relatively quickly, because the system not to search for other redundant hardware device!TwoBoot Settings Configuration (startup options)Here are some of the startup project settings system! It is convenient for users to better habits and improve the system performance.1. QuickBoot (quick start set)This project can set whether the computer self-test function at startup, and to accelerate the speed of system, if set to "Disable" system will be in the implementation of all self boot time, but it will start slowing down! The general setting is Enabled"2. Full Screen Logo (fulllogo display settings)Here is the set whether to open the boot Logo settings, if you don't want to boot Logo can be set to Disable"3. Add On ROM Display Mode (accessory software display)This project is the accessory device software allows you to set the display mode, the general is set to "Force BIOS" on it.4. Bootup NunLock (keypad lock switch)Is to set the boot is automatically opened on the keypad NumLock. General settings for On5. PS/2 Mouse SupportSet whether the PS/2 mouse support function of this project. Can be set to AUTO.6. Typematic Rate (keyboard settings reflect the frequency)This is to let you choose the keyboard to reflect the speed of frequency options, usually set to "fast"7. Boot To OS/2 (OS/2 system)This project allows you to choose whether to activate the OS/2 operating system compatibility mode, generally set to No"8. Wait For "F1" If Error (ErrorMessage)This project is set if an error occurs when the system starts to display press the "F1" button to confirm to continue the boot, usually set to "Enabled"9. Hit "DEL" Messgae Display (press DEL prompt)This option is displayed by pressing the Del key to enter Bios setup tips at boot time, if you choose "Disable" will not see this article at the beginning of the sentence "Press DEL to Run Steup, Presss TAB to display BIOS Post Message" message, usually set to "Enabled"10. Interrupt 19 Capture (PCI built in program startup settings)When the card comes with software you use PCI when you set thisto "Enabled"3. Security (safety performance options)1.Change Supervisor Password (administrator password)The administrator password set, when setting the password after several options, including a "User Password" option, which is the user password settings, like the Windows user password, they can be set into a variety of different access rights (Use Access Level), whichNo Access users to store Bios settingsView Only users can only view Bios settings cannot change settingsLimited allows the user to change the settingsFull Access users can change Bios settingsThere are several common optionsClear User Password clear password更改密码密码检查2。

main‎（系统基本‎设置）s‎y stem‎time‎系统时间‎设置sy‎s tem ‎d ate ‎系统日期设‎置AMI‎B IOS ‎B IOS信‎息Pro‎c esso‎r cpu‎信息sy‎s tem ‎m emor‎y内存信‎息‎a dvan‎c ed（进‎阶设置）‎j umpe‎r free‎cunf‎l gura‎t fon ‎C PU内存‎参数设定‎C PU c‎o nfig‎u rati‎o n CP‎U设定c‎h ipse‎t芯片组‎设定on‎b oard‎Devi‎c es C‎o nfig‎u rati‎o n 集成‎硬件装置设‎定PCI‎p np P‎C I装置设‎定USB‎Conf‎i gura‎t ion ‎U SB装置‎设定In‎s tant‎Musi‎c Con‎f igur‎a tion‎免开机音‎乐播放设定‎c‎o nfig‎u re s‎y stem‎freq‎u ency‎/voit‎a geA‎I Ove‎r cloc‎k tun‎e r 智能‎C PU频率‎设置pe‎r form‎a nce ‎M ode ‎增强型模式‎选项M‎a nual‎手动设置‎Stan‎d ard ‎标准模式‎O verc‎l ock ‎5% 步进‎超频‎Conf‎i gure‎Syst‎e m Fr‎e quen‎c y/Vo‎l tage‎CPU ‎E xter‎n al F‎r eque‎n cy {‎M Hz} ‎[xxxx‎] CPU‎外频设置‎D RAM ‎F requ‎e ncy ‎‎‎ [‎A uto]‎内存频率‎设置AG‎P/PCI‎Freq‎u ency‎{MHz‎}‎ [Au‎t o]AG‎P/PCI‎设备频率设‎置CPU‎VCor‎e Vol‎t age ‎‎‎[Aut‎o] CP‎U核心电压‎设置DD‎R Ref‎e renc‎e Vol‎t age ‎‎ [Au‎t o] 内‎存电压设置‎AGP ‎V DDQ ‎V olta‎g e ‎‎‎[1.50‎V] AG‎P设备电压‎设置‎conf‎i gure‎adva‎n ced ‎C PU s‎e ttin‎g s （C‎P U信息）‎Manu‎f actu‎r er:x‎x xxxx‎x品牌‎B rand‎Stri‎n g:xx‎x xxxx‎CPU型‎号信息F‎r eque‎n cy :‎x xxxx‎x MHz ‎C PU运行‎主频FS‎B Spe‎e d :x‎x xxxx‎M Hz C‎P U 前端‎总线C‎a che ‎L1:xx‎x xxxx‎x xKB ‎一级缓存‎C ache‎L2:x‎x xxxx‎x xxKB‎二级缓存‎Cach‎e L3:‎x xxxx‎x xxxK‎B三级缓‎存Ma‎x CPU‎U ID V‎a lue ‎L imit‎‎ [Di‎s abld‎] CPU‎开关En‎h ance‎d C1 ‎C intr‎o l ‎‎ [au‎t o] 增‎强型CPU‎控制开关‎C PU I‎n tern‎a l Th‎e rmal‎Cont‎r ol [‎a uto]‎CPU内‎部温控开关‎Hype‎r Thr‎e adin‎g Tec‎h nolo‎g y ‎[Enab‎l ed] ‎C PU超线‎程开关‎Adva‎n ced（‎高级芯片组‎设置）A‎d vanc‎e d Ch‎i pset‎Sett‎i ngs‎Conf‎i gure‎DRAM‎Timi‎n g by‎SPD ‎[Enab‎l de] ‎S DRAM‎的时钟设置‎Memo‎r y Ac‎c eler‎a tion‎Mode‎‎[auto‎]内存加‎速控制D‎R AM I‎d le T‎i mer ‎‎‎ [a‎u to] ‎内存空闲控‎制DRA‎M Ref‎r esh ‎R ate ‎‎‎[aut‎o] 内存‎更新控制‎Grap‎h ic A‎d apte‎r Pri‎o rity‎‎[AGP/‎P CI] ‎A GP/P‎C I优先设‎定Gra‎p hics‎Aper‎t ure ‎S ize ‎‎[xxx‎x MB] ‎A GP显卡‎内存设置‎S prea‎d Spe‎c trum‎‎‎ [‎E nabl‎e d] 增‎强光谱‎I CH D‎e laye‎d Tra‎n sact‎i on ‎ [‎E nabl‎e d] I‎C H延时控‎制MP‎S Rev‎i sion‎‎‎‎ [1.‎1] MP‎S修正‎Onbo‎a rd A‎C'97 ‎A udio‎‎‎[auto‎]声卡设‎定Onb‎o ard ‎L AN ‎‎‎‎[Ena‎b led]‎网卡设定‎Onbo‎a rd L‎A N Bo‎o t RO‎M‎‎[Disa‎b led]‎网卡RO‎M开关‎S eria‎l por‎t1 Ad‎d ress‎‎ [‎3F8/I‎R Q4] ‎C OM1序‎列地址S‎e rial‎port‎2 Add‎r ess ‎‎ [2‎F8/IR‎Q3] C‎O M2序列‎地址Pa‎r alle‎l Por‎t Add‎r ess ‎‎ [Di‎s able‎d] 井口‎序列地址‎O nBoa‎r d Ga‎m e/MI‎D I po‎r t ‎ [‎D isab‎l ed] ‎游戏摇杆接‎口设定‎Adv‎a nced‎Adva‎n ced ‎P CI/P‎n P se‎t ting‎s(PCI‎设备设置）‎plu‎g and‎play‎o/s ‎‎‎[NO]‎PCI端‎口系统识别‎控制PC‎I Lat‎e ncy ‎T imer‎‎‎ [xx‎] PCI‎延时设置‎A lloc‎a te I‎R Q to‎PCI ‎V GA ‎ [‎Y es] ‎P CI显卡‎I RQ中断‎位置设置‎P alet‎t e Sn‎o opin‎g‎‎ [‎D isab‎l ed] ‎特殊非标准‎显卡设置‎P CO I‎D E Bu‎s Mast‎e r ‎‎ [‎E nabl‎e d] P‎C I读写I‎D E装置控‎制A‎d vanc‎e dUS‎B Con‎f igur‎a ion(‎U SB装置‎设置)‎U SB F‎u ncti‎o n ‎‎‎ [‎x USB‎port‎s] US‎B端口开启‎个数Le‎g acy ‎U SB s‎u ppor‎t‎‎ [au‎t o] U‎S B端口自‎动检测设置‎USB ‎2.0 C‎o ntro‎l ler ‎‎‎[Enab‎l ed] ‎U SB控制‎器开关U‎S B 2.‎0 Con‎t roll‎e r Mo‎d e ‎ [H‎I Spee‎d] US‎B传输模式‎USB‎Mass‎Stor‎a ge D‎e vice‎Conf‎i gura‎t ion ‎大型存储装‎置设定‎Pow‎e r(系统‎电源管理)‎Susp‎e nd M‎o de ‎‎‎‎[Auto‎]系统省‎电设置R‎e ppos‎t Vid‎e o on‎S3 R‎e sume‎ [n‎o] 唤醒‎系统时是否‎显示VGA‎画面AC‎P I 2.‎0 Sup‎p ort ‎‎‎ [no‎] ACP‎I2.0支‎持设置A‎C PI A‎P IC s‎u ppor‎t‎‎ [E‎n able‎d] 是否‎增加ACP‎I API‎C到RSD‎T清单、‎APM ‎C onfi‎g urat‎i on 高‎级电源设置‎Hard‎w are ‎M onlt‎o r 系统‎监控‎Powe‎rAPM‎Conf‎i gura‎t ion(‎高级电源设‎置）P‎o wer ‎M anag‎e mcnt‎/APM ‎‎ [E‎n able‎d] 是否‎开启电源进‎阶管理AM‎P功能V‎i deo ‎P ower‎Down‎Mode‎‎ [D‎i sabl‎e d] 是‎否在视频停‎止后进入省‎电模式H‎a rd D‎i sk P‎o wer ‎D own ‎M ode ‎ [D‎i sabl‎e d] 是‎否在硬盘停‎转后进入省‎电模式S‎u spen‎d Tim‎e Out‎‎‎ [D‎i sabl‎e d] 进‎入省电模式‎的时间T‎h rott‎l e Sl‎o w Cl‎o ck R‎a tio ‎ [x‎x%] 系‎统进入省电‎模式的运行‎速度P‎o wer ‎B utti‎n Mod‎e‎‎ [O‎n/OFF‎]按关机‎键是进入休‎眠模式还是‎关机Re‎s tore‎on A‎C Pow‎e r Lo‎s s ‎ [Po‎w er O‎F F] 断‎电后再开启‎恢复断电前‎状态P‎o wer ‎O n By‎RTC ‎A larm‎‎ [D‎i sabl‎e d] 自‎动定时唤醒‎设置Po‎w er O‎n By ‎E xter‎n al M‎o dems‎ [Di‎s able‎d] 远程‎唤醒设置‎P ower‎On B‎y PCI‎Devi‎c es ‎ [‎D isab‎l ed] ‎P CI设备‎唤醒设置‎P ower‎On P‎S/2 K‎e yboa‎r d ‎ [‎D isab‎l ed] ‎键盘唤醒设‎置Pow‎e r On‎PS/2‎Mous‎e‎‎[Dis‎a bled‎]鼠标唤‎醒设置‎Powe‎rHar‎d ware‎Moni‎t or(系‎统监控)‎CPU ‎T empe‎r atur‎e‎‎‎[xx℃/‎x xx'F‎] CPU‎温度MB‎Temp‎e ratu‎r e ‎‎‎ [xx‎℃/xxx‎'F] 系‎统温度P‎o wer ‎T empe‎r atur‎e‎‎ [N‎/A] 电‎源温度‎Q-Fan‎Cont‎r ol ‎‎‎ [‎D isab‎l ed] ‎风扇速度调‎整CP‎U Fan‎Spee‎d‎‎‎ [xx‎x xRPM‎] CPU‎风扇转速‎C hass‎i s Fa‎n Spe‎e d ‎‎ [‎N/A] ‎机箱风扇转‎速Pow‎e r Fa‎n Spe‎e d ‎‎‎[N/A‎]电源风‎扇转速‎V CORE‎Volt‎a ge ‎‎‎ [‎x xxV]‎电压监控‎3.3V‎Volt‎a ge ‎‎‎‎[xxxV‎]电压监‎控5V ‎V olta‎g e ‎‎‎‎[xxx‎V] 电压‎监控12‎V Vol‎t age ‎‎‎‎ [xx‎x V] 电‎压监控‎boot‎Boot‎sett‎i ngs(‎启动选单)‎Boo‎t Dev‎i ce P‎r iori‎t y 启动‎装置顺序‎R emov‎a ble ‎D rive‎s移动装‎置顺序C‎D ROM ‎D rive‎s光驱启‎动顺序‎B oot ‎S etti‎n gs C‎o nfig‎u rati‎o n 启动‎选项设定‎S ecur‎i ty 安‎全性选项‎Boo‎tBOO‎T Dev‎i ce P‎r iori‎t y(启动‎设备顺序)‎1st‎Boot‎Devi‎c e ‎‎‎[3M-‎M axto‎r] 第一‎启动盘2‎s t Bo‎o t De‎v ice ‎‎‎ [D‎i sabl‎e d] 第‎二启动盘Bo‎o tBo‎o t Se‎t ting‎s Con‎f igur‎a tion‎(启动选项‎设置)‎Q uick‎Boot‎‎‎‎ [‎E nabl‎e d] 快‎速启动设置‎Full‎Scre‎e n Lo‎g o ‎‎‎[Enab‎l ed] ‎开机画面设‎置Add‎O n RO‎M Dis‎p lay ‎M ode ‎‎[for‎c e BI‎O S] 附‎件装置软件‎显示模式‎B ootu‎p Num‎-Lock‎‎‎ [‎O n] 小‎键盘锁定设‎置PS/‎2 Mou‎s e Su‎p port‎‎‎[aut‎o] PS‎/2鼠标开‎关Typ‎e mati‎c Rat‎e‎‎‎[Fas‎t] 键盘‎反映频率设‎置Boo‎t To ‎O S/2 ‎‎‎‎[NO]‎OS/2‎系统设置‎W ait ‎F or "‎F1" I‎f Err‎o r ‎ [‎E nabl‎e d] 错‎误信息提示‎设置Hi‎t "DE‎L" Me‎s sage‎Disp‎l ay ‎ [En‎a bled‎]按下D‎E L指示提‎示设置I‎n terr‎u pt 1‎9 Cap‎t ure ‎‎ [D‎i sabl‎e d] P‎C I内键程‎序启动设置‎B‎o otS‎e curi‎t y Se‎t ting‎s(系统安‎全设定)‎Chan‎g e Du‎p ervl‎s or P‎a sswo‎r d 系统‎管理员密码‎设定Bo‎o t Se‎c tor ‎V irus‎Prot‎e ctio‎n [Di‎s able‎d] 防病‎毒保护开关‎Ex‎i tEx‎i t Op‎t ions‎(退出BI‎O S程序设‎置)E‎x it &‎Save‎Chan‎g es 退‎出并保存设‎置Exi‎t & D‎i scar‎d Cha‎n ges ‎退出而放弃‎设置Di‎s card‎Chan‎g es 放‎弃设置但是‎不退出BI‎O S程序‎L oad ‎S etup‎Defa‎u lts ‎预读出厂设‎置(((‎(‎‎‎一．Ma‎i n(标准‎设定)‎此菜单可‎对基本的系‎统配置进行‎设定。

一、AMI BIOS详解－－Main篇说明：以下内容图片部分为本人参照自己的映泰G31E-M7主板拍摄，具体到不同的主板以及AMI BIOS版本的不同，排列顺利以及具体内容或有区别，但大多数内容应该相差不大。

具体的文字说明部分除了自行整理编撰外同时参考收集了网上的相关资料，其中或有错误，仅供参考。

一、Main1、Main－System Time说明：设定系统时间（下图）。

2、Main－System Date说明：设定系统日期（下图）。

3、Main－Floppy A选项：None/720K/1.2M/1.44M/2.88M说明：本项对软驱进行设置，可以根据软驱具体情况进行设置。

除了一些特殊应用外，基本上已经不再使用，所以一般选择None.（下图）。

4、Main－IDE Configuration－ATA/IDE Configuration（IDE接口设置）选项：Disabled 关闭IDE接口Compatible IDE兼容模式Enhanced 增强IDE模式说明：本项对IDE口进行设置，选择不同的选项，会影响到Legacy IDE Channels（预留IDE 通道）。

5、Main－IDE Configuration－Legacy IDE Channels（预留IDE通道）选项：SATA Only仅使用SATA接口，可以使用4个SATA接口，最多连接4个SATA硬盘PATA Pri,SATA SecIDE做主通道连接两个PATA设备，SATA做副通道，只能使用SATA2和SATA4连接2个SATA硬盘SATA Pri,PATA SecSATA做主通道，只能使用SATA1和SATA3连接2个SATA硬盘，IDE1做副通道连接两个PATA设备PATA Only仅使用IDE接口，不使用SATA接口。

说明：当上一项“ATA/IDE Configuration”选择“Compatible”（IDE兼容模式）时，会出现本项。

51-0100-001107-00111111-101094-0viper-F: Dataexpert (型号不详)
51-0100-001437-00101111-101094-P54C586-H: 厂商不详（芯片组为: UMC82C891)
51-0100-008003-00111111-071595-i430HX-5: QDI P5i430HX-T2 BIOS
(= MBD-P5MB) (UMC I/O)
51-0000-001223-00111111-101094-82430FX-H: Acer/AOpen Ap5c/p 95108-1x 48.87101.001
尽管本人已经尽了最大努力来确保下面信息的可靠，但是在下面的ＢＩＯＳ号码中仍然难免会有疏漏。
您如果发现文中的任何错误，请和我联系，以免更多的人因此而受损失。
您如果发现本文中没有提到的BIOS号码，请您将主板的型号、厂商和BIOS号码等资料告知本站，以让更多的朋友受益。
在以下的列表中，如果您不能有十分确定您的主板的ＢＩＯＳ号码的的话，那么请到所有的类似主板的公司网站点去看一下；观察并比较主板的图片、手册和各项特征，以便确定到底那种主板和您的主板一样。
51-0101-005727-00111111-071595-AMIS727-R: AMI Atlas PCI II
51-0101-006389-00111111-071595-I430TX-2SMTX007-H: Supermicro P5MMS98
51-0109-005721-00111111-101094-AMIS721-P: 厂商不详（Atlas Pentium PCI/ISA, 型号721)
51-0100-000000-10111-072594-0571822-H: TMC PCI54PL

3.1.3 最新AMI BIOS 详解采用最新的AMI（American Megatrends Inc.）BIOS。

支持Windows即插即用。

设置界面如下：图3-14 BIOS基本信息配置图BIOS Setup Utility按键功能如下所示（设置界面的右下角）：→←：选择画面↑↓：选择项目Enter：选择+ / -/space：更改选项。

F7：恢复用户默认F8：保存为用户默认F9：加载优化默认值F10：保存并退出设置ECS：退出（或者返回主界面）BIOS Setup Utility提示：1）主板默认BIOS设置适用于大多数情况下最佳性能。

不建议在BIOS中设置和更改默认值。

2）在本手册中，默认值括在括号中。

带有三角标记为子菜单项。

（1）BIOS设置实用程序(Main)此选项会显示系统的基本信息。

自动显示系统BIOS版本、建立日期、处理器、内存、系统日期等信息。

系统日期（System Date）和时间（System Time）：在计算机上显示当前的日期和时间。

如果运行Windows操作系统，每当更改Windows的日期和时间，这些项目都将自动更新。

（2）BIOS设置实用程序（Advanced）图3-15 BIOS高级设置图高级设置包括四个子项目：杂项、高级芯片组配置、集成的外围设备和电脑健康状态。

杂项（Miscellaneous）：高级芯片组配置（Advanced Chipset Configuration）集成的外围设备（Integrated Peripherals）电脑健康状态（PC Health Status ）图3-16 Miscellaneous设置画面：说明：主板支持4个SATA通道，每个通道允许安装一个SATA设备，SATA端口1〜2/5〜6。

Clock to All DIMM/PCI/PCIE [Disabled] ：启用或禁用所有DIMM / PCIE时钟Spread Spectrum [Enabled] ：启用或禁用扩频。

AMIBIOS模块结构详解1. MRC（Memory Reference Code）模块：MRC模块用于初始化系统内存，包括内存控制器和DRAM（动态随机存取存储器）等。

它负责检测和配置物理内存、对内存控制器进行初始化、设置DRAM速度和时序等。

MRC模块是AMI BIOS中非常关键的一个模块，它对于内存的初始化和配置具有很大的影响。

2. PEI（Pre-EFI Initialization）模块：PEI模块是一个较早的初始化模块，用于初始化一些比较基础的硬件设备，如CPU、北桥、SMBus （系统管理总线）等。

PEI模块还负责创建全局PEI阶段数据和内存映射，为后续阶段的初始化工作做准备。

3. DXE（Driver Execution Environment）模块：DXE模块负责在EFI（可扩展固件接口）环境下运行，它是EFI生态系统中很重要的一个模块。

DXE模块用于加载和执行UEFI驱动程序和UEFI应用程序，提供了访问硬件、文件系统和网络等功能的接口。

DXE模块还负责进行一些其他的初始化和配置工作，如设备的枚举和初始化、事件和任务的管理等。

4. BDS（Boot Device Selection）模块：BDS模块是一个选择启动设备的模块，它用于根据用户的配置选择合适的启动设备，并加载并启动操作系统。

BDS模块还负责处理用户的键盘输入、显示启动菜单等交互工作。

除了以上主要的模块之外，AMI BIOS还包含一些其他的模块，如SMM （System Management Mode）模块、SMM调度器模块、ACPI（高级配置和电源接口）模块等。

这些模块在AMI BIOS中起到了相应的作用，用于实现一些特定的功能和管理。

总的来说，AMIBIOS模块结构的主要目标是实现对硬件设备的初始化和配置、提供固件接口给操作系统使用、管理和处理一些系统事件和任务、提供一些交互操作接口等。

这些模块协同工作，使得计算机系统能够正常启动和运行。

在AMI的BIOS主界面里，各主选项解释！在AMI的BIOS主界面里，各主选项解释！2010-01-10 20:32第一选项：Standard CMOS Setup（标准CMOS设定）第二选项：Advanced BIOS Features（高级BIOS功能）【注释】本大项目中分为以下小项：Adanced Settings（高级设置）------------------------------------------------------------------------------------------------------------------WARNING:Setting Wrong Values In Below Sections may cause system to malfunction（警告：下面的小节中设置错误的值可能会导致系统出现故障）CPU Configuration（CPU配置）IDE Configuration（IDE配置）Onboard Devices Configuration（板载设备配置）Keyboard Select（键盘选择）BIOS Boot Block Protection Disabled（BIOS启动街区保护禁用）ACPI APIC Supprt Enabled（符合ACPI APIC 的支持启动）第三选项：Advanced Chipset Features(高级芯片组功能）第四选项：Boot Configuration Features(启动配置功能）第五选项：Power Management Features（电源管理功能）第六选项：Pnp /PCI Configuration（即插即用 /PCI配置）第七选项：BIOS Security Features（BIOS安全功能）第八选项：PC Health Status（电脑健康状况）第九选项：Load Optimal Defaults（加载最优默认）。

BIOS设置图解教程之AMI篇目前主板上常见的BIOS主要为AMI与AWARD两个系列.对于很多初学者来说，BIOS设置是一件非常头疼的事情，面对着满屏的English，实在是无从下手。

实际上，BIOS设置并不是特别神秘的事情，但是为什么初学者却会如此头疼呢。

根据归纳，总结出了几点原因，希望初学者能够避免被这些因素所左右。

● 听别人说操作BIOS很危险在这里，笔者不否认操作BIOS有一定的风险，BIOS是Basic Input Output System的缩写，乃基本输入/输出系统的意思，也就是计算机里最基础的引导系统，如果BIOS设置错误，硬件将会不正常工作。

● 一看到全英文界面就没信心很多菜鸟一看到满屏的英文，就完全没有了设置的信心，根本不愿意仔细去看其中的内容，这样自然也不会去深入研究了。

但实际上，BIOS里很多设置项目英语都非常简单，在学校里英语不是特别差的人，都基本上能领会其大意，实在不懂得也不必去调试，毕竟BIOS里经常修改的也就那么几个项目。

所以，当你进入BIOS之后，千万不要被其中满屏的英文所吓倒，这样才能慢慢的学会调教BIOS。

● 习惯于求助别人帮忙菜鸟和高手在初期是没有区别的，但是菜鸟在遇到问题的时候，求助于别人帮忙搞定，而高手却喜欢自己去查询资料。

设置BIOS也是一样，很多人用过10年电脑，都还不知道怎么在BIOS 设置光驱为首个引导设备，导致连操作系统都还不会安装。

很显然，10年之后，他仍然是一只菜鸟。

而喜欢研究的高手，想必在用电脑半年时间内，就会熟悉安装各种操作系统，调试最基本的BIOS。

百度、Google都是解决问题的好帮手●什么是BIOS？BIOS是英文"Basic Input Output System"的缩略语，直译过来后中文名称就是"基本输入输出系统"。

它的全称应该是ROM－BIOS，意思是只读存储器基本输入输出系统。

其实，它是一组固化到计算机内主板上一个ROM芯片上的程序，它保存着计算机最重要的基本输入输出的程序、系统设置信息、开机上电自检程序和系统启动自举程序。

最新 AMI Bios 设置全程图解以华硕的AMI Bios为例，介绍一下AMI Bios的设置：开启计算机或重新启动计算机后，在屏幕显示如下时，按下“Del”键就可以进入Bios的设置界面。

要注意的是，如果按得太晚，计算机将会启动系统，这时只有重新启动计算机了。

大家可在开机后立刻按住Delete键直到进入Bios。

有些品牌机是按F1进入Bios 设置的，这里请大家注意！进入后，你可以用方向键移动光标选择Bios设置界面上的选项，然后按Enter 进入子菜单，用ESC键来返回主单，用PAGE UP和PAGE DOWN键或上下( ↑↓ )方向键来选择具体选项回车键确认选择，F10键保留并退出Bios设置。

接下来就正式进入Bios的设置了！首先我们会看到（如图2）一．Main(标准设定)此菜单可对基本的系统配置进行设定。

如时间，日期等。

其中 Primary/Secondary IDE Master/Slave 是从主IDE装置。

如果你的主板支持SATA接口就会有Third/Fourth IDE Mastert或者更多，他们分别管理例电脑里面各个IDE驱动装置的，如硬盘，光驱等等！因为各个主板的设置不同，所以在此就不详细解说这里的设置了，但是这些一般不用用户自己去设置，一般用默认的就可以，如果有特殊要求，建议用户自己对照说明书的说明进行设置，或者在论坛里单独提问！System Information这是显示系统基本硬件信息的，没有什么好讲（如图3）基本设置了解后就进入高级设置了！二．Advanced（进阶设置）如图4：这里就是Bios的核心设置了,新手一定要小心的设置，因为其直接关系系统的稳定和硬件的安全，千万不可以盲目乱设！1.大家先看到的是“JumperFree Configuration”（不同品牌的主板有可能不同，也可能没有）再这里可以设置CPU的一些参数，对于喜欢超频的朋友来说这里就是主攻地！(如图)大家可以看到有一个“AI Overclock Tumer”的选项，其中有一些选项，如上图，其中又以“Manual”为关键，选择后会看到如下图：对于CPU超频爱好者这些东西应该了如指掌，CPU的外频设置（CPU External Frequency）是超频的关键之一，CPU的主频（即我们平时所说的P4 3.0G等等之内的频率）是由外频和倍频相乘所得的值，比如一颗3.0G的CPU在外频为200的时候他的倍频就是15,(200MHz*15＝3000MHz)。

● CPU Configuration（CPU配置）下面我们再次返回主菜单，进入CPU配置页面：CPU配置页面里对于普通用户来说，没有太大的用处，第一项是设置CPU频率的，这在jumperFree Configuration里就已经有了，超频玩家才能用的着。

其他的几个选项用处都不大，最后一个项目是Intel有名的SpeedStep技术，如果开启此技术的话，可以实现CPU在空闲时自动降频，从而节省电能，强烈推荐笔记本用户开启此选项。

●Chipset（芯片组）由于北桥芯片的相关设置已经在Advanced菜单中的JumperFree Configuration中完成，所以这里的Chipset主要是对南桥芯片进行配置。

不过这里我们经常调节的只有第二项，Initiate Graphic Adapter，中文意思是从什么图形卡启动。

也就是说，当我们计算机中有一块PCI显卡和一块PCI-e显卡同时存在时，到底让那一块显卡工作来引导系统。

一般来说，整合主板中这里的调节项为PCI-E/On board，也就是先从独立显卡引导还是从集成显卡引导。

● Onboard Devices Configuration（板载设备配置）此菜单里主要讲述的是一些集成在主板上的设备，包括声卡、网卡、1394控制器等设备。

有一天，你突然发现声卡消失了，或者网卡消失了，那么你就应该来BIOS里看看这里是不是被屏蔽了。

上图正在调节高保真音频，如果你没有独立声卡的话，就选择Enabled吧。

Front Panel Type讲的是前置音频的类型，可以设置成AC 97或者是HD Audio。

如果你家里没有5.1声道以上音响设备的话，建议设置成AC97，因为这样前后的音频才是独立的。

如果选择HD Audio的话，前置音频只能作为5.1声道系统中的两个小音箱。

笔者测试用的这块华硕P5K/EPU主板，由于采用P35芯片组，南桥芯片没有直接提供IDE的支持。

主板代码大全编辑: 硬件世界发表日期: 2007-03-04 15:08AMI主板代码大全（BIOS-ID）大家有不知型号的主板，就从这里面查吧，不要一一问了。

如果查不到，再问，不过，可能问了也白问。

AMI的BIOS-ID，有下面几种形式：DINT-1123-041990-K8其中，1123就是该主板的BIOS-ID041990，是BIOS的出品日期，格式是月日年另一种格式是：51-0102-zz5123-00111111-101094-AMIS123-P51表示支持CPU的类型和BIOS的容量0102，BIOS的版本号zz5123，5123就是BIOS-ID代码大全，下面的格式是：代码主板厂家主板厂家网站0394 Suk Jung Korea http://www.sukjung.co.kr1101 Sunlogix Inc.1102 Soyo Technology Co., Ltd. /1103 Tidalpower Technology Inc.1105 Autocomputer Co., Ltd. FCC ID: JR61106 Dynasty Computer Inc. /1107 Dataexpert Corp. /1108 Chaplet Systems Inc. 1109 Fair Friend Enterprise Co., Ltd. FCC ID: IQM1111 Pao-Ku International Co., Ltd. FCC ID: IDX1112 Aquarius Systems USA Inc. FCC ID: JW51113 Micro Leader Enterprises Corp.1114 Iwill Corp. /1115 Senor Science Co., Ltd. 1F, #10, Alley 19, Lane 325, Chien Kang Rd, TW1116 Chicony Electronics Co., Ltd. /1117 A-Trend Technology Co., Ltd. /1120 Unicorn Computer Corp. /1121 First International Computer Inc. /1122 Notestar (IC-book)Microstar Computer Corp (AMI)1123 Magtron Technology Co., Ltd.1124 Tekram Technology Co., Ltd. 1126 Chuntex Elelectronics, Co., Ltd. 1127 unknown Some boards from AXIOM Technology Co., Ltd. use this code1128 Chaintech Computer Co., Ltd. /1130 Pai Jung Electronic Industrial. Co., Ltd. FCC ID: I5L1131 Elitegroup Computer Co., Ltd. /1132 Dkine Enterprise Co., Ltd.1133 Seritech Enterprise Co., Ltd. FCC ID: IYD1135 Acer Incorporated /1136 Sun's Electronics Co., Ltd. FCC ID: GRK1138 Win-Win Electronic Co., Ltd. FCC ID: JQM1139 Rectron http://www.rectron.co.za/1140 Angine Ltd. Taiwan Branch (H. K.) See Protech Systems Co., Ltd. (1354) 1141 Nuseed Technology Inc.1142 Firich Enterprises Co., Ltd. /1143 CReTE Systems Inc. /1144 Vista Technology Co., Ltd.1146 Taste Corp.1147 Integrated Technology Express Inc. /1150 Achitec Corp. Ltd. /1151 Accos Enterprise Co., Ltd.1152 Top Thunder Technology Co., Ltd. FCC ID: I651154 San Li Technology Ltd. /1156 Technical House Inc. 4F, #9, Lane 235, Pao Chiao Rd, Hsin Tien, TW 1158 Hi-Com Industrial Co., Ltd.1159 Twinhead International Corp. /1161 Monterey International Corp. FCC ID: FKD1163 Softek Systems Co., Ltd.1164 unknown1165 Mercury Computer Corp.1168 RioWorks Solutions Inc. /1169 Micro-Star International Co., Ltd. /1170 Taiwan Igel Co., Ltd.1171 Shining Yuan Enterprise /1172 Giantec Technology Corp. /1175 Applied Component Technology Corp.1176 Sigma Computer Corp. 5F, #32, Lane 90, Min Chuan R, Hsin Ti, TW1177 HighTech Information System /1178 Clevo Co. /1180 Padalin International Development Corp.1181 Leo Systems Inc. (FIC) /1182 Alpha-Top Corp.1183 Mirle Automation Corp. /1184 Delta Electronics Inc. /1185 unknown1188 Quanta Computer Inc. /1190 Chips and Technologies /, ftp:///1192 Interlogic Industries /1192 ICP Electronics Inc. /1193 SerComm Corp. / Print Servers1195 GNS Technologies Inc.1196 Universal Scientific Industrial Co. /1197 Golden Way Electronic Corp. /1199 GigaByte Co., Ltd. /1201 New Tech International Co., Ltd. P. O. Box 7846, TW1203 Sunrex Technology Corp. /1204 Bestek Computer Co., Ltd. FCC ID: JZ91209 Puretek Industrial Co., Ltd. /1210 Rise Computer Inc. /1211 DFI Diamond Flower Electronic Co., Ltd. /1214 Rever Computer Inc. /1218 Elite Computer Co., Ltd. /1221 Darter Technology Inc. /1222 Domex Technology Corp. /1223 Biostar Microtech Corp. /1225 Yung Lin Technology Corp.1229 Dataworld International Corp. 6th Floor #2 Nan King East Road, Section 2 Taipei 1234 Leadman Electronics Inc. /1235 Formosa Industrial Computer Inc. /1238 Win Tech Technology Co., Ltd. /1240 Free Computer Technology Inc. /1241 Mustek Corp. /1242 Amptek Technology Co., Ltd.1244 Flytech Group International /1246 Cosmotech Computer Corp. FCC ID: KF61247 ABIT Computer Corp. /1248 Muse Technology Co., Ltd.1251 Portwell Infotech /1252 Sono Computer Co., Ltd. /1256 Lucky Star Technology Co., Ltd. /1258 Four Star International Trading Co. FCC ID: GKS1259 GVC Corp. /1260 DT Research Inc. Milpitas, CA1262 Arima Computer Corp. /1266 Modula Tech Co., Ltd. 4F, #3, Lane 538, Chung Cheng Rd, Hsin Tien, TW1270 Portwell Inc. /1271 Tidal Technologies Inc. 3F, # 7, Lane 50, Sec 3, Nan Kang Rd, TW1272 Ultima Electronics Corp. /, /1273 UFO Systems Inc. FCC ID: FNF1274 Full Yes Industrial Corp. /1275 Jackson Dai Industrial Co., Ltd.1276 Jet Way Information Co., Ltd. 1277 Tarng Bow Co., Ltd. [Bow Electronics Co Ltd.] FCC ID: IJN1281 EFA Corp. /1283 Advance Creative Computer Corp. (DTK) /1284 Lung Hwa Electronics Co., Ltd. FCC ID: DXL1286 Askey Computer Corp. /1291 Taiwan MyComp Co., Ltd. /1292 Asustek Computer Inc. /1297 DD&TT Enterprise Inc. FCC ID: H851298 Trigem Company http://www.trigem.co.kr/1299 Trigem Company Use 0898, 1098, 1298, 1299, 1499, 1598, 29991301 Taken Corp. /1304 Dual Technology Corp. /1306 Sky Computer1309 Protronic Enterprises Corp. 7F-2, 234, Sec 5, Nanking E. Rd, TW 1317 New Comm Technology Co., Ltd.1318 Unitron Inc. /1323 Inventec Corp. /1343 Holco Enterprise Co., Ltd. /1346 Snobol Industrial Corp. 8F, #361, Ta Nan Rd, TW1351 Singdak Electronic Co., Ltd.1353 J. Bond Computer Systems Corp. /1354 Protech Systems Co., Ltd. /1355 Arrgo Systems Inc. /1357 New Portwell1367 CoxsWain Technology Co. Ltd.1371 ADI Corp. /1373 Silicon Integrated Systems Corp. /1374 unknown1379 Win Technologies Co., Ltd. /1391 Aten International Co., Ltd. /1392 ACC Taiwan Inc. /1393 Plato Technology Co., Ltd. /1395 Spring1396 Tatung Science and Technology Inc. /1398 Spring Circle Computer Inc. FCC ID: F981400 Key Win Electronics1404 Alptech Logic Products Inc. /1421 Well Join Industry Co., Ltd. /1422 Labway Computer Co., Ltd. FCC ID: JV71425 Lindata Corp. / Under Construction!1437 Hsing Tech Enterprise Co., Ltd. /1440 Great Electronics Corp. FCC ID: A7P1450 Win-Lan Co.1451 Ecel Systems Corp. 8F-3, #27, Lane 135, Sec 1, Fu Hsing S. Rd, TW 1452 United Hitech Corp. (AIR) /mb-air.html 1453 Kai Mei Electronic Corp. /kaimei.co 1454 unknown1461 Hedonic Computer Co., Ltd.1462 Arche Technologies Inc. FCC ID: GVW1464 unknown1470 Flexus Computer Technology Inc. /1471 C.P. Technology Co. Ltd. /1472 Datacom Technology Co., Ltd. FCC ID: JX81473 PC Chips /1484 Mitac International Corp. /1490 Great Tek Corp. /1491 President Technology Inc.(Wang Labs) FCC ID: HZ41493 Artdex Computer Corp. FCC ID: I7G1494 Proteam Computer Corp. /1500 Foxen Co., Ltd. It was Netcon Co.,Ltd.1503 UpRight Technology Co., Ltd. FCC ID: LNE1507 Tangent Computer /1514 Wuu Lin Electronics Co., Ltd.1519 Epox Computer Co., Ltd. /1526 Eagle Computer Technology Co., Ltd. / ???1531 Force System Inc. FCC ID: GZE1540 BCM Advanced Research /1546 Golden Horse Computer Co., Ltd. 250, Chung San N. Rd, Ta Yuan Hsiang, Taipei, Taiwan 1549 CT Continental Corp. FCC ID: HCY1564 Random Technology Inc. FCC ID: JGD1576 Jetta Computer Co., Ltd. /1585 Gleem Industries Co., Ltd. 8F-1,#99, Sec 2, Chung Shan N. Rd, Taipei, Taiwan1588 Boser Technology Co., Ltd. /1593 Advantech Co., Ltd. /1594 Trigon1598 unknown1608 Consolidated Marketing Corp. CMC PowerPort1612 Datavan International Corp. /1617 Honotron Corp. FCC ID: HEI1618 Union Genius Computer Co., Ltd.1621 New Paradise Enterprise Co., Ltd. FCC ID: III1622 R.P.T. Intergroups International Ltd. /1628 Digital Equipment International Ltd.1630 Iston Computer Corp.1647 Lantic Inc. /1652 Advanced Semiconductor Engineering, Inc. /1655 Kingston Technology Inc. /1656 Storage System Inc. FCC ID: GJ5 / JP3#51, Chien Kuo 1st Rd, Hsin Chuang, Taipei, Taiwan1658 Macrotek International Corp. /1666 Cast Technology Inc. JMA ftp:///1671 Cordial Far East Corp. 8F,#109, Shuang Feng Rd, Hsin Chuang, Taipei, Taiwan1672 Lapro Corp. FCC ID: IFI1675 Advanced Scientific Corp. /1685 High Ability Computer Co., Ltd. FCC ID: ILZ1691 Gain Technology Co., Ltd. FCC ID: ITB1696 unknown1700 DSG Technology Inc. /1707 Chaining Computer and Communication Co. FCC ID: IMG1708 E-San Electronic Co., Ltd. LTD. 15F, #76, Sec 2, Tun-Hua S. Rd, Taipei, Taiwan1719 Taiwan Turbo Technology Co., Ltd. FCC ID: LGC1720 Fantas Technology Co., Ltd. FCC ID: JMM1723 NTK Computer Inc. /1727 Tripod Technology Corp.1737 Ay Ruey International Co., Ltd.1739 Jetpro Infotech Co., Ltd. 6 F, #43, Pao Tsing Str, Taipei, Taiwan1743 Mitac Inc. !!!1759 BEK-Tronic Technology 2570 Corporate Place, Suite E-108, Monterey Park CA 91754 1762 Ansoon Technology Co. 1F, #32, Sec 1, Huan Shan Rd, Nei Hu, Taipei, Taiwan1770 AOpen /1771 Toyen Computer Co., Ltd.1774 ACER Sertek Inc. /1776 Joss Technology Ltd. /1780 Acrosser Technology Co., Ltd. /(Passworded)1783 EFAR Microsystems, Inc. Taiwan branch 6F-1, #243, Fu Sheng S. Rd, SEC. 1 TW1788 Systex Corp. 12F, #51, Sec 2, Chung Ching S. Rd, Taipei, Taiwan1792 U-Board Computerize Co., Ltd. 4F, #303, Ta Kuan Rd, Sec 2, Pan Chiao, Taipei, Taiwan 1794 CMT-Taiwan, Inc.1796 J&J Technology Co., Ltd. /1800 Syzygia Computer Corp.1801 Palit Microsystems Inc. /1805 unknown1806 Interplanetary Information Co., Ltd. /1807 Expert Electronics Corp. /1810 Elechands International Co., Ltd.1815 Powertech Electronic Co., Ltd. /1820 OVIS Enterprises Co., Ltd. AMI mistake, must be OUR Enterprises Co., Ltd.1823 Inlog Micro Systems Co., Ltd.1826 TerComputer Technologies Corp.1827 Anpro Inc. 5F, #35, Sec 1, Chien Kuo Rd, Taipei, Taiwan1828 AXIOM Technology Co., Ltd. /1840 New Union H.K. Ltd.1845 PC Direct Technology Co., Ltd.1845 Proware Technology Corp.1846 Garnet International Corp. Garnet Business Machines Inc, Garnet Systems Co Ltd.1847 Brain Power Co., Ltd. 2F 12, Lane 130, Sec 3, Nan Kang Rd, Taipei, Taiwan1850 HTR Asia Pacific Inc.1853 Veridata Electronics Inc. /1856 Smart D&M Technology Co., Ltd. /1867 Lutron Electronic Enterprise Co. Ltd. /1868 Soyo Technology Co., Ltd. (H.K Office) /1879 Aeontech International Co., Ltd. Do not confuse with Aaeon Technology1881 Manufacturing Technology Resources Inc. FCC ID: KY51888 Seal International Corp.1889 Rock Technology Ltd.1906 Freedom Data Technology Co., Ltd.1914 BCOM Electronics Inc. 1917 Source Of Computer Co., Ltd.(Sourcecom Corp. ?) 5388 N Sterling Center Drive, Westlake Village , CA http://www.sourcecom.co m/1918 Lanner Electronics Inc. /1920 Ipex ITG International Ltd.1924 Join Inc.1926 Kou Sheng Computer Co., Ltd. 2F, 19, San Chung Rd, Nan Kang, Taipei, Taiwan1927 Seahill Technology Co., Ltd. (IC-book)Spring Hill Int Ltd (AMI) /1928 Nexcom International Co., Ltd. /1929 CAM Enterprise Inc.1931 AAEON Technology Inc. /1932 Kuei Hao Industrial Co., Ltd. 2F, #89, Kang Loh Str, Neihu Taipei, Taiwan1933 ASMT Corp.1934 Silver Bally Inc.1935 Prodisti Co., Ltd.1936 Codegen Technology Co., Ltd.1937 Orientech Electronics Corp. Orient Semiconductor Electronics Ltd. ???1938 Project Information Company Ltd.1939 Arbor Technology Corp. /1940 SunTop Computer Systems Corp.1941 Funtech Entertainment Corp. FCC ID: MDP1942 Sunflower Systems Inc. FCC ID: LDT1943 Needs System Development Co., Ltd.1945 Norm Advanced Technology Corp.1947 Ten Yun Co., Ltd.1948 Beneon Corp. 4F, 246, Sec 5, Chung-Hsiao E. Rd, Taipei, Taiwan1949 National Advantages Computer Inc.1950 Mits Technology Co., Ltd.1951 Macromate Corp. /1953 Orlycon Enterprise Co., Ltd. P.O. Box 68-1366 Taipei, Taiwan1954 Chung Yu Electronics Co., Ltd. 32, Kin Men Str, Taipei, Taiwan1955 Yamashita Engineering Manufacture 203, 734 Silver Spur Rd, Rolling Hills Estate, CA 90274 1957 High Large Corp.1958 Young Micro Systems Inc 1221, Florence Avenue, Santa Fe Springs, CA 906701959 Fastfame Computer Co., Ltd. /1960 Acqutek Corp. / Uses 1823 and1618 code too.1961 Deson Trade Inc.1962 Astra Communication Corp. /1963 Dimensions Electronics Co., Ltd.1964 Micron Design Technology Ltd. 5F, #164-2, Lien Cheng Rd, Chung Ho, Taipei, Taiwan1965 Cantta Enterprises Co., Ltd.1968 Khi Way Enterprise Co., Ltd.1969 Gemlight Computer Ltd. /1970 MAT Technologies Ltd.1973 Fugu Tech Enterprise Co., Ltd. /1974 Green Taiwan Computer Co., Ltd.1975 Supertone Electronic Co., Ltd.1977 AT&T Taiwan Telecommunications1978 Winco Electronic Co., Ltd. /1980 Teryang Systems Co., Ltd.1981 Nexcom International Co., Ltd. /1982 China Semiconductor Corp. 907, Chung Cheng Rd, Chung-Ho, Taipei, Taiwan1985 Top Union Electronics Corp.1986 DMP Electronics Co., Ltd.1988 Concierge Co., Ltd.1989 Atherton Technology Co., Ltd. FCC ID: MT91990 Expen Tech Electronics Co., Ltd. 5F, 2, Alley 8, Syh Wei Lane, Chung ChengRd, Hsin Tien, T aiwan1994 Japan Cere'Bro Computers Inc. (CBR)1996 Ikon Technologies Corp. /1998 Chang Tseng Corp.2100 Kapok /2101 unknown2292 Olivetti Computer /5034 TMC Research Corp.Reason Technologies ??5721 American Megatrends6069 Ocean Technology http://www.octek.es/6081 CSS Laboratories /6105 Dolch Computer Systems /6132 Technology Power Enterprises Inc. Out of business6137 unknown6155 Some boards American Predator Corp. use this code6165 Genoa http://www.genoa.de/6181 unknown6182 Peaktron6214 Hewlett-Packard 6218 unknown used on Amptron DX81006224 unknown6247 TTC Computer Products Irving, Texas, U.S.A.6257 unknown6259 Young Micro Systems Inc 1221, Florence Avenue, Santa Fe Springs, CA 906706265 unknown6279 unknown6285 Tyan Computer Corp. /6291 unknown6326 Crystal6328 Alaris Inc (in 1996 closed m/b manufacturing)6377 Teknor industrial Computers Inc 6377 unknown6386 Pacific Information Inc Out of business ?6389 Super Micro Computer Inc. /6398 unknown used by LION6399 Mylex Corp. /6407 Elonex Plc. 6423 American Predator Corp. [APC] ftp:///bios/6455 unknown6666 CTL Corp8003 QDI (Quantum Designs Ltd.) /8005 AVT Industrial Ltd. /8021 unknown8027 unknown8028 unknown8031 Zida Technologies Ltd. /8036 unknown8045 PC Partner Ltd. (VTech) /8054 Pine Technology ftp:///pub/8078 Weal Union Development Ltd. 东西抢注：楼主先是介绍的是主板BIOS的简单的知识，然后是介绍的各主板厂商的网址，以方便大家了解市面上面的主板以及下载驱动AWARD主板代码大全（BIOS-ID）AWARD主板BIOS—ID的形式如下：xx/xx/xx-SiS-496/497-2A4IBZ1DC-00其中的2A4IBZ1DC，就是BIOS-ID2A4IB，是主板的芯片组代码Z1，就是主板的厂商代码下面是芯片组代码查询，不全，会慢慢补充：代码芯片组154I5 SiS 85C431/85C420/85C411/85C406/85C405213V0 SARC RC2016213V1 SARC RC201821480 HiNT SC9204 (Sierra), HMC82C206 [USA-9109] 214D1 HiNT SC8005 (Sierra), HMC82C206214I8 SiS 85C471214I9 SiS 85C471E214L0 VIA VT82C470214L2 VIA VT82C486A214L6 VIA VT82C486A/VT82C495/VT82C496G214W3 VD 88C898214X2 UMC UM491215UM OPTi 82C546/82C5972191? ALD 93C41321917 ALD 93C3082A41? ALD 93C4392A41? ALD 93C4882A431 Cyrix MediaGx Cx55102A432 Cyrix GXi Cx55202A433 Cyrix GXm Cx55202A434 Cyrix GXm Cx55302A496 Intel Saturn I2A498 Intel Saturn II2A499 Intel Aries2A4H2 Contaq 82C596/82C5992A4H4 Contaq 82C596/82C5992A4IB SiS 85C496/85C4972A4J6 Winbond W83C491 (SL82C491 Symphony Wagner) 2A4KA ALi M14292A4KC ALi M1439/45/312A4KD ALi M1487/M14892A4L4 VIA VT82C505/496G/4162A4L6 VIA 496G/406/5052A4O3 EFAR EC802GL, EC100G2A4R4 Forex FRX46C521A2A4UK OPTi-802G-822 (895?)2A4X5 UMC 82C881E/82C886B2A4Z0 Integrated Micro Solutions IMS8848 / IMS88492A597 Intel 82433LX / 82434LX (Mercury)2A59A Intel 82433NX / 82434NX (Neptune)2A59B Intel 82433MX / 82434MX (Ariel)2A59C Intel 82437FX / 82438FX (Triton FX)2A59F Intel 82439HX (Triton II HX)2A59G Intel 82437VX / 82438VX (Triton VX)2A59H Intel 82437VX / 82438VX (Triton VX) (illegal BIOS code) 2A59I Intel 82439TX (Triton TX)2A5G7 VLSI VL82C5942A5GB VLSI Lynx VL82C541/VL82C5432A5IA SiS 501/502/5032A5IC SiS 5501/5502/55032A5ID SiS 5511/5512/5513 5511B/5512/55132A5IE SiS 5101/5102/51032A5IF SiS 5596/55972A5IH SiS 55712A5II SiS 5581/5582 5597/55982A5IJ SiS 5120 Mobile2A5IK SiS 5591/55922A5IM SiS 5302A5KB ALi M1449/61/512A5KE ALi M1511 (Aladdin II)2A5KF ALi M1521 / M1523 (Aladdin III)2A5KI ALi M1531 / M 1543 (Aladdin IV / IV+)2A5KK ALi M1541 / M1542 (Aladdin V / V+)2A5L5 VIA ?2A5L7 VIA VT82C5702A5L9 VIA VT82C570M2A5LA VIA Apollo VP1 VT82C580VP (VXPro)2A5LC VIA Apollo VP2 VT82C590VP2A5LD VIA Apollo VPX (VXPro+)2A5LE VIA Apollo (M)VP32A5LF VIA Apollo Pro2A5LG VIA Apollo Pro+ / Pro 1332A5LH VIA Apollo (M)VP42A5R5 Forex FRX58C613/601A2A5R6 Forex FRX58C613A/602B/601B2A5T6 ACC Micro 2278/2188 (Auctor)2A5UI OPTi 82C822/596/5972A5UI OPTi 82C596/546/822A5UL OPTi 82C822/571/5722A5UM OPTi 82C822/546/5472A5UN OPTi Viper 82C556/557/558 (-M)2A5UP OPTi Viper-Max2A5X7 UMC 82C8902A5X8 UMC 8886BF/8891BF/8892BF2A5XA UMC 890C2A69H Intel 440FX2A69J Intel 440LX / 440EX2A69K Intel 440BX / 440ZX2A69L Intel 820 (Camino)2A69M Intel 810 / 810E (Whitney)2A69N Intel 440MX (Banister Mobile)2A69R Intel 815 (Solano)2A6IL SiS 56002A6IN SiS 6202A6IR SiS 630 630S 630E2A6KL ALi M1621/M1543C2A6KO ALi M1631/M1535D2A6LF VIA 691/5962A6LG VIA 693/596 or 693/686A2A6LI VIA 601/686A MVP42A6LJ VIA 694X/596B or VIA 694X/686A2A6LK VIA VT8371 (KX-133)2A9KG ALi M6117/M1521/M15232A9KL ALi M1621 (Aladdin Pro II)2A9KO ALi M1631 (Aladdin TNT2)2AG9H Intel Neptune ISA2B496 Intel Saturn I EISA2B597 Intel Mercury EISA2B59A Intel Neptune EISA2B59F Intel 430HX EISA2B69D Intel Orion EISA2C460 UNIchip U4800-VLX2C470 Hyundai HYF824812C4D2 HiNT SC8006 (Sierra), HMC82C2062C4I7 SiS 85C4612C4I8 SiS 85C471B2C4I9 SiS 85C471B/E/G2C4J6 Winbond W83C491(SL82C491 Symphony Wagner) 2C4K9 ALi M14292C4KC ALi M14392C4L2 VIA 82C486A2C4L6 VIA VT496G2C4L8 VIA VT425MV2C4O3 EFAR EC802GL, EC100G2C4S0 AMD Elan 4702C4T7 ACC Micro 2048 (Auctor)2C4UK OPTi 82C895/82C8022C4X2 UMC UM82C491/82C4932C4X6 UMC UM498F/496F [UMC 881/886]2C4Y1 Samsung KS82C8842C917 ALD 93C308-A2C9V0 SARC RC20166A450 ST Microelectronics PC Client ST86 processor6A5KP ArtX A76A61A nVIDIA nForce6A61B nVIDIA nForce26A660 ATI A36A69L Intel 820 (Camino)6A69M Intel 810 (Whitney)6A69R Intel 815 815E 815EP (Solano)6A69S Intel 850 (Tehama) / 8606A69V Intel 845 845E 845G 845GE 845GL 845PE (Brookdale)6A69W intel E7205 E75006A6IR SiS 6306A6IS SiS 730 730S6A6IT SiS 635 635T6A6IU SiS 733 7356A6IX SiS 645 645DX 6516A7I0 SiS 6486A6KT ALi MAGiK 16A6LG VIA VT82C693A VT82C694A6A6LI VIA PLE1336A6LJ VIA VT82C694XDP with MP support6A6LK VIA VT8371 (KX133)6A6LL VIA VT8605 (PM133)6A6LM VIA VT8363 (KT133 / KT133A / KT133E)6A6LN VIA VT8365 / VT8364 (KM133 / KL133 / KLE133)6A6LO VIA VT8601 (PLE133)6A6LU VIA VT8375 (KM266 / KL266)6A6LV VIA VT8366 / VT8366A / VT8367 (KT266 / KT266A / KT333) 6A6LW VIA VT8753 (P4X266 / P4X266A)6A6LY VIA VT8368 (KT400)6A6S2 AMD 7516A6S6 AMD 760 7616A6S7 AMD 762主板厂家代码含义代码主板厂家主板厂家网址A0 Aorta Systems (now AsusTek) /A1 ABIT Computer Corp. /A2 A-Trend Technology Co., Ltd. /A3 Aquarius Systems, Inc. (ASI) + BCOM Electronics Inc. /A5 AXIOM Technology Co., Ltd. /A7 AVT Industrial Ltd. /A8 AdcomAB Acer Open [AOpen] /ACAD Amaquest Computer Corp. /+ AnsonAIAJAK Advantech Co., Ltd. /+ AAEON Technology Inc. /AM Achme /AN ADI Corp /APAQAT ASK Technology Ltd. /AVAWAX Achitec /AYAZB0 Biostar Microtech Corp. /B1 BEK-Tronic Technology 2570 Corporate Place, Suite E-108, Monterey Park CA 91754 B2 Boser Technology Co., Ltd. /B3 BCM Advanced Research /B5B6BABBBK Albatron C0 MatsonicC1 Clevo Co. /C2 Chicony Electronics Co., Ltd. /C3 Chaintech Computer Co., Ltd. htttp:///C5 Chaplet Systems Inc. /Artsome/ch/ch.htmlC6C8C9 CompuTrend Systems, Inc. /CECF Flagpoint /CHCICLCQCS CSS Laboratories /+ Gainward Co., Ltd. /CUCV California Graphics USA Distribution / CWCXCZD0 DataExpert Corp. /D1 DTK Computer, Inc. (former Advance Creative Computer) / D2 DigitalD3 American Digicom Corp. /D4 Diamond Flower Electric Instrument Co. [DFI] /D7 Daewoo Telecom http://www.dwt.co.kr/, ftp://ftp.dwt.co.kr/D8 Nature Worldwide TechnologyDADBDCDDDE Dual Technology Corp. /DFDI Domex Computer Services (DTC) /DJ Darter (used by DTC too) DL Delta Electronics, Inc. E1 Elitegroup Computer Co., Ltd. /E3 EFA Corp. /E4 ESPCo (Elite Spirit Co., Ltd.) E6 Elonex PLC /E7 Expen TechE9EC ENPC Technology Corp. /+ EONtronics Corp. /EO Evalue Technology Inc. /F0 First International Computer, Inc. /F1 Flytech Group International /F2 Flexus Computer Technology Inc. /F3 Full Yes Inc. [FYI] F5 FuguTech /F8 Formosa Industrial Computing, Inc. /F9 Ford Lian International Ltd. + Red Fox Technology Co. Inc. + BravoBaby Corp. FCFD Atima FFFG Fastfame Technology Co., Ltd. /FI First International Computer, Inc. /G0 Gigabyte Technology Co., Ltd. /G1 GIT Co.G2G3 Gemlight /G4G5 GVC /G6G9 Global Circuit Technology /+ SuperTek Computer Electronics Inc. /+ C.P. Technology Co. Ltd. /GA Giantec Technology Corp. or GBGE Zaapa Mainboard (Globe Legate Co.) /H0 Hsin Tech /H2 Holco (Shuttle) /H3 HedonicH7H8H9HAHGHH HighTech Information System /HJ Sono Computer Co., Ltd. /HT Unicore (supplies only BIOS binaries !) I1I2I3 Iwill Corp. /I4 Inventa TaiwanI5 Informtech International Ltd. /I6I7 Inlog Microsystem Co Ltd /I9 ICP Acquire /IA InfinityIC Inventec Corp. /IE Industrial Technology Research Institute .tw/ IGIPITIVIZJ1 Jetway, J-Mark /J2 Jamicon Electronics http://www.jamicon.nl/J3 J-Bond /J4 Jetta /J6 Joss /J7J9JAJB Jetway, J-Mark ?JDJFK0 Kapok /K1 Kaimei Corp Now Jamicon Electronics, http://www.jamicon.nl/K9KAKBKF KINPO Electronic /KKL0L1 Lucky Star Technology Co., Ltd. /L7 Lanner Electronics Inc. /L8L9 Lucky TigerLALB Leadtek /+ Super Micro Computer, Inc. /LCLD?? Leotec M0 MatraM1M2 Taiwan MyComp [TMC] /+ Interlogic Industries /M3 Mitac /M4 Micro-Star International Co., Ltd. /M8 Mustek Corp. /M9 Micro Leader EnterprisesMDMGMH Macrotek /+ Interlogic Industries /MKMP Maxtium Computer Corp. /MQMSN0 Nexcom /+ Interlogic Industries /N3N5 NEC CorpN6NM NMC New Media Comm http://www.nmc-pe.de/NX Nexar now part of atec group (was )O0 Octek /O3O5O8OZP0P1 PC-Chips /P2P3 PalitP4 ASUStek P6 Protech /P8 AZZA Technology Inc. /P9 Powertech / No motherboards! PA EPoX Computer Co., Ltd. /PB 2-the-Max Int.PC Pine ftp:///pub/PF President (Formely Wang Labs) Now unavailablePGPHPJPK ALD Technology Ltd. /PMPN Procomp Informatics Ltd /PQPR Supergrace PS Palmax /PTPV Visionex ?PW+ Tidalpower Technology Inc /PYQ0 Quanta /Q1 QDI (Quantum Designs Ltd.) /R0 Rise Computer Inc. /R2 Rectron http://www.rectron.co.za/R3 Datavan International Corp. /R5R7R9 RSAP Technology Award mistake?RA RioWorks Solutions Inc. /S0S2 Soyo Computer Inc. /S3 Smart D&M Technology Co., Ltd. /S4S5 Holco Enterprise Co., Ltd. /S6S9 Spring CircleSA Seanix /SBSC Sukjung (Auhua Electronics Co. Ltd.) http://www.sukjung.co.kr/ SDSE SMT+ New Tech /bios.htmSGSH Luckytech Technology Co. Ltd. /+ SYE (Shining Yuan Enterprise)SISJ Sowah (H.K.) /SL WincoSM Hope Vision, SuperPower, San Li /+ Agama Technology Co., Ltd. /SN Soltek /SQSRSTSUSVSW S&D Some boards from Zaapa and A-Corp use this codeSX Supermicro ?SZT0 Twinhead /T1 Tarng Bow Co. Aeton, Leadman, Teamung, FentechT5 Tyan Computer Corp. /T6 Trigem /T7T8TB Techmedia / Tae Il Medie (Taeil) http://www.taeil.co.kr/ and TETG Tekram ftp:///THTITJ Totem Technology Co., Ltd. /TKTL Transcend Information, Inc. /TMTNTP Taiwan Commate Computer Inc. /TQTR Top Star ?TSTT T&W Electronics (CZ) Co., Ltd. /TX Eupa ComputerT sann Kuen Enterprise / or TY Aeton Technology Inc. /U0 U-Board Out of business+ Teknor Industrial Computers /U1 Universal Scientific Industrial /U2 A.I.R. /mb-air.html+ UHC United Hitech CorpU3 Umax /U4 Unicorn Computer Corp. /U5 UnicoU6 Unitron /U7U8U9 Warp Speed Ink. /UZ UMC V2V3 PC Partner Group /V5 Vision Top /V6 Vobis http://www.vobis.de/V7 YKM (Dayton Micron) /W0 WinTechnologies (Edom) /W1 Well Join Industry Co., Ltd. /W5 Winco Electronics /W6W7 Win Lan Enterprise /W8W9 Weal Union Development Ltd.WIXA ADLink Technology Inc. /X3 ACORP International /, http://207.226.164.58/X4X5 Arima Computer Corp. /XLXXY2 Yamashita Engineering Manuf., Inc. S.203, 734 Silver Spur Rd, Rolling Hills, Estate CA, 9027 4Y3Z1 Zida Technologies Ltd. /Z3 ShenZhen Zeling Industrial Co., Ltd. /。

AMIBIOS汇总AMI（American Megatrends Inc.）是一家全球领先的BIOS软件和硬件开发公司。

成立于1985年，公司总部位于美国乔治亚州。

AMI BIOS是该公司开发的BIOS固件，用于控制和管理计算机硬件设备。

1.用户友好界面：AMIBIOS采用图形用户界面（GUI），使用户能够轻松地浏览和配置各种设置。

用户可以使用鼠标和键盘进行交互，进行BIOS设置的修改。

2.完善的系统配置：AMIBIOS提供了广泛的系统配置选项，如CPU频率和电压设置、内存配置、硬盘设置、视频设置等。

用户可以根据自己的需求和系统要求进行个性化调整。

3.硬件监控和调试功能：AMIBIOS具有强大的硬件监控功能，能够实时监测CPU温度、风扇转速、电压等参数，并提供相应的预警功能。

此外，AMIBIOS还提供了调试工具，方便开发人员进行硬件调试和故障排除。

4.引导管理器：AMIBIOS提供了灵活的引导管理器，可以管理和配置多个操作系统的引导顺序。

用户可以轻松地选择要启动的操作系统，并进行引导设置的修改。

5.安全功能：AMIBIOS具有多种安全功能，如密码保护、安全启动、硬盘加密等，可保护计算机免受未经授权的访问和数据泄露。

6.BIOS更新和恢复：AMIBIOS支持在线更新和恢复功能，使用户能够轻松升级BIOS固件，并在BIOS故障或损坏时进行恢复。

7.远程管理功能：AMIBIOS支持远程管理功能，允许管理员通过网络远程监控和管理计算机系统。

这对于企业IT团队来说特别有用，可以提高系统管理的效率。

8.扩展性和兼容性：AMIBIOS具有良好的扩展性和兼容性，能够支持各种类型的硬件设备和操作系统。

这使得AMIBIOS成为多个计算机制造商的首选BIOS解决方案。

总结起来，AMIBIOS具有用户友好的界面、丰富的系统配置选项、强大的硬件监控和调试功能、灵活的引导管理、安全功能、BIOS更新和恢复功能、远程管理功能以及良好的扩展性和兼容性。

3.1.3 最新AMI BIOS 详解采用最新的AMI（American Megatrends Inc.）BIOS。

支持Windows即插即用。

设置界面如下：图3-14 BIOS基本信息配置图BIOS Setup Utility按键功能如下所示（设置界面的右下角）：→←：选择画面↑↓：选择项目Enter：选择+ / -/space：更改选项。

F7：恢复用户默认F8：保存为用户默认F9：加载优化默认值F10：保存并退出设置ECS：退出（或者返回主界面）BIOS Setup Utility提示：1）主板默认BIOS设置适用于大多数情况下最佳性能。

不建议在BIOS中设置和更改默认值。

2）在本手册中，默认值括在括号中。

带有三角标记为子菜单项。

（1）BIOS设置实用程序(Main)此选项会显示系统的基本信息。

自动显示系统BIOS版本、建立日期、处理器、内存、系统日期等信息。

系统日期（System Date）和时间（System Time）：在计算机上显示当前的日期和时间。

如果运行Windows操作系统，每当更改Windows的日期和时间，这些项目都将自动更新。

（2）BIOS设置实用程序（Advanced）图3-15 BIOS高级设置图高级设置包括四个子项目：杂项、高级芯片组配置、集成的外围设备和电脑健康状态。

杂项（Miscellaneous）：高级芯片组配置（Advanced Chipset Configuration）集成的外围设备（Integrated Peripherals）电脑健康状态（PC Health Status ）图3-16 Miscellaneous设置画面：说明：主板支持4个SATA通道，每个通道允许安装一个SATA设备，SATA端口1〜2/5〜6。

Clock to All DIMM/PCI/PCIE [Disabled] ：启用或禁用所有DIMM / PCIE时钟Spread Spectrum [Enabled] ：启用或禁用扩频。

AMI BIOS设置详解文字版由于BIOS的唯一性和其在PC机架构中特殊的位置，通过恶意软件对BIOS进行未经授权的修改可能会对计算机造成明显和严重的威胁。

接下来是小编为大家收集的AMI BIOS设置详解文字版，希望能帮到大家。

AMI BIOS设置详解文字版BIOS是英文Basic Input/Output System(基本输入/输出系统)的缩写，其程序储存在主板上的 EPROM或Flash ROM 内，作用是测试装在主板上的部件能否正常工作，并提供驱动程序接口，设定系统相关配备的组态。

当你的系统配件与原CMOS参数不符合时，或CMOS 参数遗失时，或系统不稳定时，就需要进入BIOS设定程序，以重新配置正确的系统组态。

进入AMI BIOS设定程序1. 打开系统电源或重新启动系统，显示器屏幕将出现自我测试的信息;2. 当屏幕中间出现"Press to enter setup"提示时，按下键，就可以进入BIOS设定程序。

3. 以方向键移动至你要修改的选项，按下键即可进入该选项的子画面;4. 使用方向键及〈Enter〉键即可修改所选项目的值，也可用鼠标(包括PS/2鼠标)选择BIOS选项并修改。

5. 任何时候按下键即可回到上一画面;6. 在主画面下，按下键，选择“Saving Changes And Exit"即可储存你的新设定并重新启动系统。

选择“Exit Without Saving"，则会忽略你的改变而跳出设定程序。

Standard Setup(标准设定)窗口Date/Time: 显示当前的日期/时间，可修改。

Floppy Drive A，B: 设定软盘驱动器类型为None/720K/1.2M/1.44M/2.88M 。

Pri Master/Slave以及Sec Master/Slave: 此选项可设定:HDD Type(硬盘类型): Auto(自动检测)、SCSI(SCSI HDD)、CD-ROM驱动器、Floptical(LS-120大容量软驱)或是Type 1～47等IDE 设备。
