N9010AK-1CM N9010AK-DVR N9010AK-EA3KeysightEXA X-Series Signal AnalyzerN9010A10 Hz to 3.6, 7.0, 13.6, 26.5, 32, or 44 GHzData SheetThis data sheet is a summary of the specifications and conditions for EXA signal analyzers. For the complete specifications guide, visit: /find/exa_specifications Balance the Challenges Whether you’re focused on time-to-market, time-to-volume, or cost of test, your choice of economy class signal analyzer should help you save both time and money. That’s the idea that drives the Keysight EXA signal analyzer—and it’s the fastest way to maximize throughputon the production line. From measurement speed to code compatibility, it makes every millisecond count and helps reduce your overall cost of test.Table of ContentsDefinitions and Conditions (3)Frequency and Time Specifications (4)Amplitude Accuracy and Range Specifications (6)Dynamic Range Specifications (9)PowerSuite Measurement Specifications (16)General Specifications (17)Inputs and Outputs (18)I/Q Analyzer (20)Related Literature (21)Get More InformationThis EXA signal analyzer data sheet is a summary of thespecifications and conditions for N9010A EXA signal analyzers, which are available in the EXA Signal Analyzer Specification Guide (N9010-90025).For ordering information, refer to the EXA Signal Analyzer Configuration Guide (5989-6531EN).Definitions and ConditionsSpecifications describe the performance of parameters covered by the product warranty and apply to the full temperature range of 0 to 55 °C 1, unless otherwise noted.95th percentile values indicate the breadth of the population (approx. 2 σ) of perfor-mance tolerances expected to be met in 95 percent of the cases with a 95 percent confidence, for any ambient temperature in the range of 20 to 30 °C. In addition to the statistical observations of a sample of instruments, these values include the effects of the uncertainties of external calibration references. These values are not warranted. These values are updated occasionally if a significant change in the statistically observed behavior of production instruments is observed.Typical describes additional product performance information that is not covered by the product warranty. It is performance beyond specifications that 80 percent of the units exhibit with a 95 percent confidence level over the temperature range 20 to 30 °C. Typical performance does not include measurement uncertainty. Nominal values indicate expected performance, or describe product performance that is useful in the application of the product, but are not covered by the product warranty.The analyzer will meet its specifications when: –It is within its calibration cycle–Under auto couple control, except when Auto Sweep Time Rules = Accy –Signal frequencies < 10 MHz, with DC coupling applied–The analyzer has been stored at an ambient temperature within the allowed operating range for at least two hours before being turned on; if it had previously been stored at a temperature range inside the allowed storage range, but outside the allowed operating range –The analyzer has been turned on at least 30 minutes with Auto Align set to normal, or, if Auto Align is set to off or partial, alignments must have been run recently enough to prevent an Alert message; if the Alert condition is changed from Time and Temperature to one of the disabled duration choices, the analyzer may fail to meet specifications without informing the user For the complete specifications guide, visit:/find/exa_specifications1. For earlier instruments (Serial number prefix < MY/SG/US5052), the full temperature ranges from 5 to 50 °C.Frequency and Time SpecificationsRange0 Hz (zero span), 10 Hz to maximum frequency of instrument Resolution 2 HzAccuracy Swept FFT ± (0.25 % x span + horizontal resolution)± (0.10 % x span + horizontal resolution)1. When used with external frequency reference 1 pulse-per-second (PPS), such as the J7203A atomic frequency reference (AFR), the reference track-ing accuracy needs to be taken into account for calculation of the overall frequency accuracy. Refer to the EXA signal analyzer specifications guide (part number: N9010-90025) for more details.rate6 ms (167/s) 5 ms (200/s)Remote measurement and LAN transferrateMarker peak search 5 ms 1.5 msCenter frequency tune and transfer (RF)22 ms20 msCenter frequency tune and transfer (μW)49 ms47 msMeasurement/mode switching75 ms39 ms1. Analysis bandwidth is the instantaneous bandwidth available around a center frequency over which the input signal can be digitized for furtheranalysis or processing in the time, frequency, or modulation domain.2. Sweep points = 101.Amplitude Accuracy and Range Specifications0.1 to 1 dB/division in 0.1 dB steps1 to 20 dB/division in 1 dB steps (10 display divisions) Linear scale10 divisionsScale units dBm, dBmV, dBμV, dBmA, dBμA, V, W, A(Option 532, 544) 3.5 to 8.4 GHz± 0.67 dB nominal8.4 to 26.5 GHz± 0.80 dB nominal26.4 to 44 GHz± 0.80 dB nominal1. DC coupling required to meet specifications below 50 MHz. With AC coupling, specifications apply at frequencies of 50 MHz and higher. Statisticalobservations at 10 MHz with AC coupling show that most instruments meet the DC-coupled specifications, however, a small percentage of instruments are expected to have errors exceeding 0.5 dB at 10 MHz at the temperature extreme. The effect at 20 to 50 MHz is negligible but notwarranted.Option P03100 kHz to 3.6 GHzOption P07100 kHz to 7 GHzOption P13100 kHz to 13.6 GHzOption P26100 kHz to 26.5 GHzOption P32100 kHz to 32 GHzOption P44100 kHz to 44 GHzGain100 kHz to 3.6 GHz+20 dB nominal3.6 to 7.0 GHz+35 dB nominal> 7 GHz+40 dB nominalNoise figure100 kHz to 3.6 GHz8 to 12 dB nominal (proportional to frequency)3.6 to 8.4 GHz9 dB nominal8.4 to 13.6 GHz10 dB nominal> 13.6 GHz DANL + 176.24 dB nominalDynamic Range Specifications(Option 503, 507, 513, 526)10 MHz to 2.1 GHz–148 dBm–150 dBm2.1 to3.6 GHz–147 dBm–149 dBm3.6 to 7.0 GHz–147 dBm–149 dBm7.0 to 13.6 GHz–143 dBm–147 dBm13.6 to 17.1 GHz–137 dBm–142 dBm17.1 to 22 GHz–137 dBm–142 dBm22 to 26.5 GHz–134 dBm–140 dBmPreamp on, RF/MW (Option 503, 507, 513, 526)10 MHz to 2.1 GHz–161 dBm –163 dBm2.1 to3.6 GHz–160 dBm–162 dBm3.6 to 7.0 GHz–160 dBm–162 dBm 7.0 to 13.6 GHz– 160 dBm–163 dBm 13.5 to 17.1 GHz–157 dBm–160 dBm 17.0 to 20.0 GHz–155 dBm–159 dBm 20.0 to 26.5 GHz–150 dBm–156 dBmMillimeter-wave (Option 532, 544)9 kHz to 1 MHz ––130 dBm 1 MHz to 1.2 GHz–152 dBm–155 dBm1.2 to2.1 GHz–151 dBm–154 dBm2.1 to3.6 GHz–149 dBm–152 dBm3.5 to4.2 GHz –144 dBm–147 dBm4.2 to 8.4 GHz–145 dBm–150 dBm 8.3 to 13.6 GHz–147 dBm–150 dBm 13.5 to 20 GHz –145 dBm–148 dBm 20 to 26.5 GHz –142 dBm–145 dBm 26.4 to 34 GHz –140 dBm–144 dBm 34.4 to 44 GHz –135 dBm–140 dBmMid-Band 0 (1.8 GHz)–157 dBm–169 dBmMid-Band 1 (5.9 GHz)–152 dBm–166 dBmMid-Band 2 (10.95 GHz)–154 dBm–165 dBmMid-Band 3 (15.3 GHz)–153 dBm–164 dBmMid-Band 4 (21.75 GHz)–148 dBm–164 dBmMid-Band 5 (30.4 GHz)–145 dBm–160 dBmMid-Band 6 (42.7 GHz)–142 dBm–154 dBm1. When Option B40, DP2, or MPB is installed some aspects of the analyzer performance change. Please refer to the EXA specifications guide for moredetails.Spurious responsesResidual responses (input terminated and 0 dB attenuation)200 kHz to 8.4 GHz (swept) –100 dBm Zero span or FFT or other –100 dBm nominalFirst RF order(f ≥ 10 MHz from carrier)–10 dBm–80 dBc + 20log(N 1) Including IF feedthrough, LO harmonic mixingresponsesHigher RF order(f ≥ 10 MHz from carrier)–40 dBm–80 dBc + 20log(N 1) Including higher order mixer responsesCarrier frequency > 26.5 GHzFirst RF order(f ≥ 10 MHz from carrier)–30 dBm–90 dBc nominalHigher RF order(f ≥ 10 MHz from carrier)–30 dBm–90 dBc nominal 1. N is the LO multiplication factor.(Option 503, 507, 513, 526)100 to 400 MHz+13 dBm+17 dBm 400 MHz to 3.6 GHz+14 dBm+18 dBm 3.6 to 13.6 GHz+14 dBm+18 dBm 13.6 to 26.5 GHz+12 dBm+16 dBmPreamp on, RF/MW (Option 503, 507, 513, 526)30 MHz to 3.6 GHz (two –45 dBm tones at preamp)3.6 to 26.5 GHz (two –50 dBm tones at preamp)0 dBm nominal–18 dBm nominalMillimeter-wave (Option 532, 544)10 to 100 MHz+12 dBm+17 dBm100 MHz to 3.95 GHz+15 dBm+19 dBm3.95 to 8.4 GHz+15 dBm+18 dBm8.3 to 13.6 GHz +15 dBm+18 dBm13.5 to 17.1 GHz+11 dBm+17 dBm17.0 to 26.5 GHz +10 dBm+17 dBm (nominal) 26.5 to 44 GHz –+13 dBm (nominal)Preamp on, millimeter-wave (Option 532, 544)30 MHz to 3.6 GHz (two –45 dBm tones at preamp) 0 dBm (nominal) 3.6 to 26.5 GHz (two –50 dBm tones at preamp)–18 dBm (nominal)Nominal dynamic range for Options 503, 507, 513 and 526Figure 1. Nominal dynamic range – Band 0, for second and third order distortion, 9 kHz to 3.6 GHzFigure 2. Nominal dynamic range – Bands 1 to 4, for second and third order distortion,3.6 GHz to 26.5 GHzPhase noise 1Offset Specification Typical RF/MW(Option 503, 507, 513, 526)Noise sidebands(20 to 30 °C, CF = 1 GHz)100 Hz –84 dBc/Hz –88 dBc/Hz 1 kHz ––98 dBc/Hz nominal 10 kHz –103 dBc/Hz –105 dBc/Hz 100 kHz –115 dBc/Hz –117 dBc/Hz 1 MHz –135 dBc/Hz –137 dBc/Hz 10 MHz––148 dBc/Hz nominal1. Apply for all the RF/MW instruments with Serial number prefix ≥ MY/SG/US5340. Those instruments ship standard with N9010A-EP3 as theidentifier. For nominal phase noise values with the RF/MW EXA at other center frequencies refer to Figure 3. For earlier instruments refer to the EXA specifications guide.Figure 3. Nominal phase noise at different center frequencies for RF/MW EXA (Option 503, 507, 513, or 526) with SN prefix >/= MY/SG/US5340 that ships standard with N9010A-EP3.Nominal phase noise at different center frequencies for RF/μW EXA with RBW selectivity curves, optimized phase noise versus offset frequencyFigure 4. Nominal phase noise at different center frequencies for millimeter-wave EXA (Option 532 or 544)Phase noise 1Offset Specification TypicalMillimeter-wave 100 Hz –84 dBc/Hz –88 dBc/Hz(Option 532, 544) 1 kHz ––101 dBc/Hz nominal Noise sidebands10 kHz –103 dBc/Hz –106 dBc/Hz (20 to 30 °C, CF = 1 GHz)100 kHz –115 dBc/Hz –116 dBc/Hz 1 MHz –135 dBc/Hz –137 dBc/Hz10 MHz––149 dBc/Hz nominal1. For nominal phase noise values with the millimeter-wave EXA (Option 532 or 544), refer to Figure 4.Nominal phase noise at different center frequencieswith RBW selectivity curves, optimized phase noise versus offset frequencyS S B p h a s e n o i s e (d B c /H z )Freq (kHz)Option MPB, microwave preselector bypass 1Frequency range N9010A-507 3.6 to 7 GHz N9010A-513 3.6 to 13.6 GHz N9010A-526 3.6 to 26.5 GHz N9010A-532 3.6 to 32 GHz N9010A-5443.6 to 44 GHz1. When Option MPB is installed and enabled, some aspects of the analyzer performance changes. Please refer to the EXA specification guide for more details.PowerSuite Measurement SpecificationsRelative dynamic range (30 kHz RBW) Absolute sensitivityRelative accuracy 74.0 dB81.0 dB typical–94.7 dBm–100.7 dBm typical ± 0.11 dB3GPP W-CDMA (2.515 MHz offset)Relative dynamic range (30 kHz RBW) Absolute sensitivityRelative accuracy 76.5 dB83.9 dB typical–94.7 dBm–100.7 dBm typical ± 0.12 dBGeneral SpecificationsThe EXA signal analyzer is supplied with a standard 3-year warrantyCalibration cycleThe recommended calibration cycle is two years; calibration services are available through Keysight service centersInputs and OutputsConnectorOutput amplitude Frequency BNC female, 50 Ω nominal≥ 0 dBm nominal10 MHz ± (10 MHz x frequency reference accuracy)Ext Ref InConnectorInput amplitude range Input frequencyFrequency lock range BNC female, 50 Ω nominal–5 to 10 dBm nominal10 MHz nominal± 5 x 10–6 of specified external reference input frequencyTrigger 1 and 2 inputs ConnectorImpedanceTrigger level range BNC female> 10 kΩ nominal –5 to 5 VTrigger 1 and 2 outputs ConnectorImpedanceLevel BNC female 50 Ω nominal 5 V TTL nominalMonitor output Connector FormatResolution VGA compatible, 15-pin mini D-SUBXGA (60 Hz vertical sync rates, non-interlaced) analog RGB 1024 x 768RangeResolution 10 to 75 MHz (user selectable) 0.5 MHzConversion gain–1 to +4 dB (nominal) plus RF frequency response BandwidthOutput at 70 MHz centerLow band or high band with preselector bypassed 1100 MHz (nominal)Preselected band Depends on RF center frequencyLower output frequencies Subject to foldingResidual output signals≤ –88 dBm (nominal)1. Option MPB installed and enabled.I/Q AnalyzerFrequencyFrequency spanStandard10 Hz to 10 MHzOption B25 (standard)10 Hz to 25 MHz10 Hz to 40 MHz0.02 ≤ f < 3.6≤ 25n/a0.6°0.14°≥ 3.6≤ 25off 1 1.9° 0.4° ≥ 3.6 (Option ≤ 526)≤ 25on 4.5° 1.2°1. Option MPB is installed and enabled.20Length (IQ sample pairs)536 MSa268 MSaLength (time units)Samples/(span x 1.28) (nominal) Sample rateAt ADC200 MSa/sIQ pairs Span x 1.28 (nominal)ADC resolution12 bits1. Option MPB is installed and enabled.Related LiteraturePublication title Publication numberEXA X-Series Signal Analyzer N9010A – Brochure5989-6527ENN9010A EXA X-Series Signal Analyzer – Configuration Guide5989-6531ENFor more information or literature resources please visit the web:Product page: /find/N9010AX-Series measurement applications: /find/X-Series_AppsX-Series signal analyzers: /find/X-Series21myKeysight/find/mykeysightA personalized view into the information most relevant to you.LAN eXtensions for Instruments puts the power of Ethernet and the Web inside your test systems. Keysight is a founding member of the LXI consortium.Three-Year Warranty/find/ThreeYearWarrantyKeysight’s commitment to superior product quality and lower total costof ownership. The only test and measurement company with three-yearwarranty standard on all instruments, worldwide.Keysight Assurance Plans/find/AssurancePlansUp to five years of protection and no budgetary surprises to ensure yourinstruments are operating to specification so you can rely on accuratemeasurements./qualityKeysight Technologies, Inc.DEKRA Certified ISO 9001:2008Quality Management SystemKeysight Channel Partners/find/channelpartnersGet the best of both worlds: Keysight’s measurement expertise and productbreadth, combined with channel partner convenience.cdma2000® is a registered certification mark of the Telecommunications IndustryAssociation. Used under license./find/exaFor more information on KeysightTechnologies’ products, applications orservices, please contact your local Keysightoffice. The complete list is available at:/find/contactusAmericasCanada(877) 894 4414Brazil55 11 3351 7010Mexico001 800 254 2440United States(800) 829 4444Asia PacificAustralia 1 800 629 485China800 810 0189Hong Kong800 938 693India 1 800 112 929Japan0120 (421) 345Korea080 769 0800Malaysia 1 800 888 848Singapore180****8100Taiwan0800 047 866Other AP Countries(65) 6375 8100Europe & Middle EastAustria0800 001122Belgium0800 58580Finland0800 523252France0805 980333Germany***********Ireland1800 832700Israel 1 809 343051Italy800 599100Luxembourg+32 800 58580Netherlands0800 0233200Russia8800 5009286Spain0800 000154Sweden0200 882255Switzerland0800 805353Opt. 1 (DE)Opt. 2 (FR)Opt. 3 (IT)United Kingdom0800 0260637For other unlisted countries:/find/contactus(BP-07-10-14)22 | Keysight | N9010A EXA X-Series Signal Analyzer - Data SheetThis information is subject to change without notice.© Keysight Technologies, 2013 – 2014Published in USA, August 29, 20145989-6529ENN9010AK-1CM N9010AK-DVR N9010AK-EA3。

3-647000-6MTA 100, Standard Rectangular Connectors, Connector Assembly, Plug, Mating Alignment, Polarization Mating Alignment Type, Mating RetentionConnectors > Rectangular Connectors >Standard Rectangular ConnectorsMating Retention:WithMating Alignment Type:PolarizationMating Alignment:WithConnector & Housing Type:PlugConnector Product Type:Connector AssemblyFeaturesProduct Type Features Product Style Assembly ShapeRectangular Wire/Cable Type StrandedConnector Type Connector Assembly Connector Product Type Connector Assembly Connector & Housing Type Plug Connector System Wire-to-Wire Insertion Force Type Normal SealableNoConnector & Contact Terminates To Wire & CableConfiguration Features Number of Cavities 6Number of Positions 6Number of Rows1 3-647000-6 ACTIVEMTA TE Internal #:3-647000-6MTA 100, Standard Rectangular Connectors, Connector Assembly, Plug, Mating Alignment, Polarization Mating Alignment Type, Mating RetentionView on >MTA 100|Panel Gasket WithoutElectrical CharacteristicsOperating Voltage250 VACContact FeaturesContact Layout In-lineContact Type TabWire Contact Termination Area Plating Material TinContact Underplating Material NickelContact Mating Area Plating Material TinContact Retention Within Housing WithContact Current Rating (Max) 5 ATermination FeaturesTermination Method to Wire & Cable Insulation Displacement Crimp (IDC) Mechanical AttachmentPanel Mount NoContact Retention Type Within Housing Locking LancePanel Mount Feature WithoutMating Alignment WithMating Alignment Type PolarizationMating Retention WithMating Retention Type LatchConnector Mounting Type Cable Mount (Free-Hanging) Housing FeaturesHousing Color RedHousing Material Nylon 6/6Centerline (Pitch) 2.54 mm[.1 in]DimensionsWidth21.4 mm[.843 in]Height12.54 mm[.494 in]Length17.78 mm[.7 in]Wire Size.3 – .4 mm²Usage ConditionsOperating Temperature Range-55 – 105 °C[-67 – 221 °F]Operation/ApplicationShielded NoCircuit Application SignalIndustry StandardsCSA Rating CertifiedAgency/Standard CSA, ULUL Rating RecognizedCSA File Number LR 7189UL File Number E28476UL Flammability Rating UL 94V-2Packaging FeaturesPackaging Quantity125Packaging Method Bag/BoxProduct ComplianceFor compliance documentation, visit the product page on >EU RoHS Directive 2011/65/EU CompliantEU ELV Directive 2000/53/EC CompliantChina RoHS 2 Directive MIIT Order No 32, 2016No Restricted Materials Above ThresholdEU REACH Regulation (EC) No. 1907/2006Current ECHA Candidate List: JUN 2020(209)Candidate List Declared Against: JAN 2019(197)Does not contain REACH SVHCHalogen Content Low Halogen - Br, Cl, F, I < 900 ppm perhomogenous material. Also BFR/CFR/PVCFreeSolder Process Capability Not applicable for solder process capabilityProduct Compliance DisclaimerThis information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledgebased on the information they provided. This information is subject to change. The part numbers that TE has identified asEU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalentchromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to theselimits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment productswill be CE marked as required by Directive 2011/65/EU. Components may not be CE marked.Additionally, the partnumbers that TE has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenousmaterials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limitsas defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulations, TE’s information on SVHC in articles for this part number is still based on the European Chemical Agency (ECHA) ‘Guidance on requirements for substances in articles’(Version: 2, April 2011), applying the 0.1% weight on weight concentration threshold at the finished product level. TE is aware of the European Court of Justice ruling of September 10th, 2015 also known as O5A (Once An Article Always An Article) stating that, in case of ‘complex object’, the threshold for a SVHC must be applied to both the product as a whole and simultaneously to each of the articles forming part of its composition. TE has evaluated this ruling based on the new ECHA “Guidance on requirements for substances in articles” (June 2017, version 4.0) and will be updating its statements accordingly.TE Model / Part #3-640440-606P MTA100 CONN ASSY 22AWG REDTE Model / Part #643075-606P MTA100 MOLDED COVERTE Model / Part #640550-606P MTA100 COVERTE Model / Part #3-643815-606P MTA100 CONN ASSY POL RIBTE Model / Part #3-644540-606P MTA100 CONN ASSY F/T POLTE Model / Part #3-643813-606P MTA100 CONN ASSY POL RIBTE Model / Part #3-640442-606P MTA100 CONN ASSY BLUTE Model / Part #3-643814-606P MTA100 CONN ASSY POL RIBTE Model / Part #3-640441-606P MTA100 CONN ASSY WHTTE Model / Part #3-640621-606P MTA100 CONN ASSY F/T NATLTE Model / Part #3-640620-606P MTA100 CONN ASSY F/T REDTE Model / Part #640642-606P MTA100 COVER F/TTE Model / Part #3-640443-606P MTA100 CONN ASSY GRNTE Model / Part #3-643498-606P MTA100 CONN ASSY LFTE Model / Part #3-644564-606P MTA100 CONN ASSY F/T 26AWGTE Model / Part #58074-1MTA 50/100/156 MANUAL TOOL FRAMECompatible PartsTE Model / Part #58638-1MTA 100 CRIMP HEAD PRODUCTION POSTEDTE Model / Part #643077-606P MTA100 MOLDED COVER F/TTE Model / Part #3-641435-404P MTA156 CONN ASSY ORNGTE Model / Part #3-647000-404P MTA100 PSTD CONN ASSY LFTE Model / Part #3-641437-202P MTA156 PSTD CONN ASSY REDTE Model / Part #640642-606P MTA100 COVER F/TTE Model / Part #3-641437-404P MTA156 PSTD CONN ASSY REDTE Model / Part #647466-2SL156 RECPT,AUNI/PHBZ,16AWGWire-to-Board Headers & Receptacles (1192)Wire-to-Board Connector Contacts(18)Standard Rectangular Connectors (1730)PCB Connector Keying(1)PCB Connector Covers(107) TE Model / Part #3-644574-606P MTA100 CONN ASSY BLK LFTE Model / Part #643077-606P MTA100 MOLDED COVER F/TTE Model / Part #3-644563-606P MTA100 CONN ASSY F/T 24AWGTE Model / Part #3-643816-606P MTA100 CONN ASSY POL RIBAlso in the Series MTA 100Customers Also BoughtTE Model / Part #3-647000-303P MTA100 PSTD CONN ASSY LFTE Model / Part #3-647000-202P MTA100 PSTD CONN ASSY LFDocumentsProduct Drawings06P MTA100 PSTD CONN ASSY LFEnglish CAD Files3D PDF3DCustomer View ModelENG_CVM_CVM_3-647000-6_F.2d_dxf.zipEnglishCustomer View ModelENG_CVM_CVM_3-647000-6_F.3d_igs.zipEnglishCustomer View ModelENG_CVM_CVM_3-647000-6_F.3d_stp.zipEnglishBy downloading the CAD file I accept and agree to the of use.Terms and Conditions Datasheets & Catalog PagesMTA, CST-100 II, SL-156 and AMP Economy Power (EP) ConnectorsEnglishProduct Environmental ComplianceTE Material DeclarationEnglishAgency ApprovalsUL ReportEnglish。

Customizable Fail-Safe multifunctiontechnology actuator for controlling dampers in typical commercial HVAC applications.• Actuating force motor 450 N [100 lbf]• Nominal voltage AC/DC 24 V • Control MFT/programmable • Position feedback 2...10 VTechnical dataElectrical dataNominal voltageAC/DC 24 V Nominal voltage frequency 50/60 HzNominal voltage rangeAC 19.2...28.8 V / DC 21.6...28.8 V Power consumption in operation 11 W Power consumption in rest position 3 W Transformer sizing 22 VAElectrical Connection 18 GA appliance or plenum cables, 1 m, 3 m or 5 m, with or without 1/2" conduit connector Overload Protection electronic throughout full stroke Electrical Protectionactuators are double insulated Functional dataActuating force motor 450 N [100 lbf]Operating range Y 2...10 VOperating range Y note 4...20 mA w/ ZG-R01 (500 Ω, 1/4 W resistor)Input impedance100 kΩ for 2...10 V (0.1 mA), 500 Ω for 4...20 mA, 1500 Ω for PWM, On/Off and Floating point Operating range Y variable Start point 0.5...30 V End point 2.5...32 VOperating modes optional variable (VDC, on/off, floating point)Position feedback U 2...10 V Position feedback U note Max. 0.5 mA Position feedback U variable VDC variableSetting Fail-Safe Position adjustable with dial or tool 0...100% in 10% increments Bridging time (PF)2 s Bridging time (PF) variable 0...10 s Pre-charging time 5...26 sDirection of motion motor selectable with switch 0/1Direction of motion fail-safe reversible with switch Manual override external push button Stroke4" [100 mm]Running Time (Motor)150 s / 100 mm Running time motor variable 90...150 s Running time fail-safe <35 s Adaptation Setting Range off (default)Override controlMIN (minimum position) = 0%MID (intermediate position) = 50%MAX (maximum position) = 100%Noise level, motor 52 dB(A)Noise level, fail-safe61 dB(A)FootnotesDefault/ConfigurationApplicationOperationSafety dataPower source ULClass 2 Supply Degree of protection IEC/EN IP54Degree of protection NEMA/UL NEMA 2Enclosure UL Enclosure Type 2Agency Listing cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, CE acc. to 2014/30/EU Quality Standard ISO 9001UL 2043 CompliantSuitable for use in air plenums per Section 300.22(C) of the NEC and Section 602 of the IMCAmbient humidity Max. 95% RH, non-condensing Ambient temperature -22...122°F [-30...50°C]Storage temperature -40...176°F [-40...80°C]Servicingmaintenance-free Weight Weight3.3 lb [1.5 kg]MaterialsHousing material UL94-5VA*Variable when configured with MFT options.†Rated Impulse Voltage 800V, Type of action 1.AA, Control Pollution Degree 3Product featuresDefault parameters for 2 to 10 VDC applications of the AHK..-MFT actuator are assigned during manufacturing. If required, custom versions of the actuator can be ordered. The parameters are variable and can be changed by three means: Factory pre-set or custom configuration, set by the customer using PC-Tool software or the handheld ZTH US.For fail-safe, modulating control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. A feedback signal is provided for position indication.The AHKX24-MFT-100 provides a 4 inch linear stroke. The stroke of the gear rack can be adjusted on both sides in increments of 0.8 inches [20mm] with the mechanical end stops.When reaching the damper or actuator end position the actuator automatically stops. The gear can be manually disengaged by pressing the button located on the actuator cover. The AHKX24-MFT actuator uses a brushless DC motor controlled by an Application Specific Integrated Circuit (ASIC). The ASIC monitors and controls the actuator rotation and provides a digital rotation sensing (DRS) function to prevent damage to the actuator in a stall condition. Powerconsumption is reduced in a holding mode. The actuator is electronically protected against overload. The anti-rotation strap supplied with the actuator will prevent lateral movement.Fail-Safe IndicationLED status indicator lights sequence:Yellow off / Green on: operation ok, no faultsYellow off / Green blinking: fail-safe mechanism is active Yellow on / Green off: fault is detectedYellow off / Green off: not in operation / capacitors charging Yellow on / Green on: adaption runningYellow blinking / Green on: communication with programming toolTypical specificationBridging timeFactory settings Modulating control, electrical fail-safe damper actuators shall be electronic type with integratedlinear stroking arm. Actuators must provide modulating control in response to a control inputfrom an electronic controller or positioner. Actuators shall have brushless DC motor technology and be protected from overload at all angles of rotation. Actuators shall have reversing switchand manual override on the cover. Run time shall be constant and independent of torque. A 2 to10 VDC feedback signal shall be provided for position feedback. Actuators shall be cULus listed, have a 5-year warranty, and be manufactured under ISO 9001 International Quality Control Standards. Actuators shall be as manufactured by Belimo.Power failures can be bridged up to a maximum of 10 s.In the event of a power failure, the actuator will remain stationary in accordance with the setbridging time. If the power failure is greater than the set bridging time, the actuator will moveinto the selected fail-safe position.The bridging time set at the factory is 2 s. It can be modified on site in operation by means ofthe Belimo service tool MFT-P.Settings: The rotary knob must not be set to the "PROG FAIL-SAFE" position!For retroactive adjustments of the bridging time with the Belimo service tool MFT-P or with theZTH EU adjustment and diagnostic device only the values need to be entered.Default parameters for 2 to 10 VDC applications of the AHK..-MFT actuator are assigned during manufacturing. If required, custom versions of the actuator can be ordered. The parameters are variable and can be changed by three means: Factory pre-set or custom configuration, set by the customer using PC-Tool software or the handheld ZTH US.AccessoriesElectrical accessories Description TypeDC Voltage Input Rescaling Module IRM-100Convert Pulse Width Modulated Signal to a 2...10 V Signal for BelimoProportional ActuatorsPTA-250Positioner for wall mounting SGA24Positioner for front-panel mounting SGF24Cable conduit connector 1/2"TF-CC USGateway MP to BACnet MS/TP UK24BACGateway MP to LonWorks UK24LONGateway MP to Modbus RTU UK24MODResistor, 500 Ω, 1/4" wire resistor with 6" pigtail wires ZG-R01Resistor kit, 50% voltage divider ZG-R02Transformer, AC 120 V to AC 24 V, 40 VA ZG-X40Battery backup system, for non-spring return models NSV24 USBattery, 12 V, 1.2 Ah (two required)NSV-BAT Mechanical accessories Description TypeBall joint suitable for damper crank arm KH8 / KH10, Multipack 10 pcs.KG10ABall joint suitable for damper crank arm KH8, Multipack 10 pcs.KG6Ball joint suitable for damper crank arm KH8, Multipack 10 pcs.KG8Push rod for KG6 & KG8 ball joints (36” L, 5/16” diameter).SH8Rotary support, for linear actuator, for compensation of transverse forces Z-DS13/8”-16 shaft clevis for AHK/AH.Z-KSCBracket for AHK/AH/LH linear actuators.ZG-119Tools Description TypeBelimo PC-Tool, Software for adjustments and diagnostics MFT-PSignal simulator, Power supply AC 120 V PS-100Connecting cable 16 ft [5 m], A: RJ11 6/4 ZTH EU, B: 6-pin for connection toservice socketZK1-GENConnecting cable 16 ft [5 m], A: RJ11 6/4 ZTH EU, B: free wire end forconnection to MP/PP terminalZK2-GENConnecting cable 10 ft [3 m], A: RJ11 6/4 ZTH EU, B: 3-pin Weidmüller andsupply connectionZK4-GENService Tool, with ZIP-USB function, for programmable andcommunicative Belimo actuators, VAV controller and HVAC performancedevicesZTH USElectrical installationWarning! Live electrical components!During installation, testing, servicing and troubleshooting of this product, it may be necessaryto work with live electrical components. Have a qualified licensed electrician or other individualwho has been properly trained in handling live electrical components perform these tasks.Failure to follow all electrical safety precautions when exposed to live electrical componentscould result in death or serious injury.Meets cULus requirements without the need of an electrical ground connection.Actuators with appliance cables are numbered.Provide overload protection and disconnect as required.Actuators may also be powered by DC 24 V.Only connect common to negative (-) leg of control circuits.A 500 Ω resistor (ZG-R01) converts the 4...20 mA control signal to 2...10 V.Control signal may be pulsed from either the Hot (Source) or Common (Sink) 24 V line.For triac sink the Common connection from the actuator must be connected to the Hotconnection of the controller. Position feedback cannot be used with a triac sink controller; theactuator internal common reference is not compatible.Actuators may be connected in parallel if not mechanically linked. Power consumption andinput impedance must be observed.IN4004 or IN4007 diode. (IN4007 supplied, Belimo part number 40155).VDC/mA ControlWiring diagramsOn/OffFloating Point VDC/mA ControlPWM Control Override ControlDimensions。

•Class 1 (active energy)•Class 2 (reactive energy)•Accuracy ±0.5 F .S. (current/voltage)•Power analyzer•Display of instantaneous variables: 3x3 digit •Display of energies: 8+1 digit•System variables and phase measurements: W, W dmd ,var, VA, VA dmd ,PF , V , A, An, A dmd ,Hz •A max ,A dmd max ,W dmd max indication•Energy measurements: kWh and kvarh •Hour counter (5+2 DGT)•TRMS meas. of distorted sine waves (voltages/currents)•Galvanically insulated measuring inputs •Profibus DP-V0 serial port •Alarms (visual only) V LN ,An •Power supply: 90 to 260VAC/DCProduct Description3-phase power analyzer with built-in programming key-pad. Particularly recom-mended for displaying the main electrical variables.Housing for panel mounting,(front) protection degree IP65and Profibus DP communica-tion port.Energy Management Power AnalyzerType WM14-96 “Profibus DP”Type SelectionPower supply H:90 to 260VAC/DCRange codes AV5:380/660V L-L /5(6)AAC VL-N: 185 V to 460 V VL-L: 320 V to 800 VAV6:120/208V L-L /5(6)AACVL-N: 45 V to 145 V VL-L: 78 V to 250 VPhase current: 0.03A to 6A Neutral current: 0.09 to 6AOptions DG:Profibus DP + galvanic insu l ated measuring inputsSystem 3:1-2-3-phase,balanced/unbalanced load,with or without neutralInput specifications•Protection degree (front):IP65•Front dimensions: 96x96mmWM14-96Input specifications (cont.)DataDynamic (reading only)System, phase variables and energiesBaud-rateUp to 6Mbit/s (mainlydepending on the length of the wiring and on the number of instruments belonging to the network)Profibus T ype DP-V0enable only for data reading Connectionsmax distance (1200m @ 9.6kbit/s, 100m @ 6Mbit/s) according to IEC61158, 9-pole connector and 10 screw terminals block.Addresses 1 to 125, key-pad selectable ProtocolProfibus DP-V0Profibus DP Serial Port SpecificationsSoftware functionsAuxiliary power supply90 to 260 VAC/DCPower consumptionAC: 4.5 VA DC: 4WPower Supply SpecificationsWM14-96General SpecificationsDisplay variables in 3-phase systems (in a 3-phase system with neutral)MSD: most significant digitLSD: least significant digitWM14-96Display pages (cont.)1) Example of kWh visualization:This example is showing 15 933 453.7 kWh2) Example of kvarh visualization:This example is showing 3 553 944.9 kvarhFigure ASine wave, undistorted Fundamental content 100%Harmonic content 0%A rms =1.1107 | A |Figure BSine wave, indented Fundamental content 10...100%Harmonic content 0...90%Frequency spectrum: 3rd to 16th harmonic Additional error: <1% FS Figure CSine wave, distorted Fundamental content 70...90%Harmonic content 10...30%Frequency spectrum: 3rd to 16th harmonic Additional error: <0.5% FSWaveform of the signals that can be measuredInsulation between inputs and outputsNOTE: In case of fault of first insulation the current from the measuring inputs to the ground is lower than 2 mA.WM14-96Energy metering Where:i = considered phase (L1, L2 or L3)P =active power Q =reactive powert 1,t 2=starting and ending time points of consumption recording n = time unit∆t = time interval between two successive power consumptionsn 1,n 2=starting and ending discrete time points of consumption recordingUsed calculation formulasInstantaneous apparent powerInstantaneous reactive powerSystem variablesEquivalent 3-phase voltage3-phase reactive powerPhase variablesInstantaneous effective voltageInstantaneous active powerInstantaneous power factor3-phase active power3-phase apparent power3-phase power factorNeutral currentAn = A L1 +A L2 +A L3AccuracykWh ,accuracy (RDG) depending on the currentError6A (Imax)6A (Imax)5A (In)5A (In)0.25A (0.05In)0.5A (0.1In)0.10A (0.02In)0.25A (0.05In)0%Class 1 accuracy limits (Active energy)5(6A) Start-up current: 30mA kvarh ,accuracy (RDG) depending on the currentError0%Class 2 accuracy limits (Reactive energy) 5(6A) Start-up current: 30mAPF=1PF=L0.5or C0.86A (Imax)6A (Imax)5A (In)5A (In)0.25A (0.05In)0.5A (0.1In)0.1A (0.02In)0.25A (0.05In)sin ϕ=1sin ϕ=0.5+1.5%+1%PF=1PF=L0.5or C0.8+2.5%+2%+1.5%+1%+1%-1%+2.5%+2%WM14-96Wiring diagramsProfibus port Wiring diagramsTerminate the first WM14 and the l ast WM14 by means of the screw termina l s T1, T2, T3. Use a two po l e shie l ded cab l e,about the connection l ength (from the first to the last instrument)refer to “TAB1”.Terminate the first WM14 positioning the dip-switch in ON on the “Con P” connector and the l ast WM14 by connecting T1, T2, e a two pol e shiel -ded cab l e, about the connection l ength (from the first to the l ast instrument) refer to “TAB1”.NOTE: the direct connection isnot allowed.WM14-961.Key-padT o program the configuration parameters and the display of the variables.Key to enter programming and confirm selections;Keys to:-programme values;-select functions;-display measuring pages.2.DisplayLED-type with alphanumeric indications to:-display configuration parameters;-display all the measured variables.LLSFront Panel DescriptionDimensions and Panel Cut-out96mm91mm61.4mm 15.4mm96m m96mm(*) The mandatory signals have to be made available by the user.64.4mmProfibus port Wiring diagrams (cont.)。

FEATURES•Engineered for professional live sound:Rugged all-in-one wireless system for singers andpresenters.•State-of-the-art live sound featuring Sennheiser‘s renowned e 835, e 845, e 865, e 935, e 945 capsuleson a lightweight aluminium transmitter with integrated mute switch*sold separately•True diversity half-rack receiver in a full-metal housing with intuitive LCD display for full control•Easy and flexible wireless synchronization between transmitter and receiver via infrared•Fast frequency allocation for up to 12 receivers via new linking functionality•Up to 20 compatible channels•Up to 42 MHz bandwidth with 1680 selectable frequen-cies, fully tunable in a stable UHF range •Transmission Range: up to 100 meters / 300 feet •High RF output power (up to 30 mW) depending on country regulations DELIVERY INCLUDES•EM 100 G4 true diversity receiver•SKM 100 G4-S handheld transmitter•MMD 835-1 microphone head (sold separately)•MMD 845-1 microphone head (sold separately)•MME 865-1 microphone head (sold separately)•GA 3 rackmount set•MZQ 1 microphone clamp•power supply• 2 AA batteries• 2 rod antennas•RJ 10 cable•quick guide•safety guide•manufacturer declaration sheet •frequency supplement sheetVersatile wireless systems for those who sing, speak or play instruments with up to 42 MHz tuning bandwidth in a stable UHF range and fast, simultaneous setup of up to 12 linked systems.State-of-the-art live sound featuring Sennheiser‘s renowned e 835, e 845 and e 865 capsules *sold separately on a lightweight aluminum transmitter with integrated mute switch.*capsule sold separatelySPECIFICATIONS EM 100 G4RF characteristics Modulation Wideband FMFrequency rangesA1: 470 - 516 MHzA: 516 - 558 MHzAS: 520 - 558 MHz G: 566 - 608 MHz GB: 606 - 648 MHz B: 626 - 668 MHz C: 734 - 776 MHz D: 780 - 822 MHz E: 823 - 865 MHz JB: 806 - 810 MHz K+: 925 - 937.5 MHz 1G8: 1785 - 1800 MHzReceiving frequenciesMax. 1680 receivingfrequencies, adjustable in 25 k Hz st eps20 frequency banks, each with up to 12 factory-preset channels, no intermodula-tion1 frequency bank with up to 12 programmable channelsSwitching bandwidth up to 42 MHz Nominal/peak deviation ±24 kHz / ±48 kHz Receiver principleTrue diversitySensitivity (with HDX, peak deviation)< 2.5 µV for 52 dBA eff S/N Adjacent channel selection Typically ≥ 65 dB Intermodulation attenua-tion Typically ≥ 65 dB Blocking≥ 70 dBSquelchlow: 5 dBµV middle: 15 dBµV high: 25 dBµV Pilot tone squelch Can be switched off Antenna inputs 2 BNC socketsAF characteristics Compander system Sennheiser HDXEQ presets (switchable, act on line and monitor outputs)Preset 1: Flat Preset 2:Low Cut (-3 dB at 180 Hz)Preset 3:Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)Preset 4: High Boost(+6 dB at 10 kHz)Signal-to-noise ratio (1 mV, peak deviation)≥ 110 dBA Total harmonic distortion (THD)≤ 0.9 %AF output voltage (at peak deviation, 1 kHz AF) 6.3 mm jack socket (unbalanced): +12 dBu XLR socket(balanced): +18 dBu Setting range “AF Out”48 dB (3 dB steps)Overall device Temperature range -10 °C to +55 °C Power supply 12 V DC Current consumption 300 mADimensions Approx. 190 x 212 x 43 mm WeightApprox. 980 gCONNECTIONSC -C-TH: 748.2 757.8 MHzSPECIFICATIONSSKM 100 G4-SRF characteristicsModulation Wideband FM Frequency ranges A1: 470 - 516 MHzA: 516 - 558 MHzAS: 520 - 558 MHzG: 566 - 608 MHzGB: 606 - 648 MHzB: 626 - 668 MHzC: 734 - 776 MHzD: 780 - 822 MHzE: 823 - 865 MHzJB: 806 - 810 MHzK+: 925 - 937.5 MHz1G8: 1785 - 1800 MHz Transmission frequencies Max. 1680 receivingfrequencies, adjustable in25 k Hz st eps20 frequency banks, eachwith up to 12 factory-presetchannels, no intermodula-tion1 frequency bank with up to12 programmable channels Switching bandwidth up to 42 MHzNominal/peak deviation±24 kHz / ±48 kHz Frequency stability≤ ±15 ppmRF output power at 50 ΩMax. 30 mWPilot tone squelch Can be switched off AF characteristicsCompander system Sennheiser HDXAF frequency response80 – 18,000 HzSignal-to-noise ratio (1 mV,peak deviation)≥ 110 dBATotal harmonic distortion(THD)≤ 0.9 %Max. input voltage 3 VeffInput impedance40 kΩInput capacitance SwitchableSetting range for inputsensitivity48 dB,adjustable in 6 dB steps Overall deviceTemperature range-10 °C to +55 °CPower supply 2 AA batteries, 1.5 V orBA 2015 accupack Nominal voltage 3 V battery /2.4 V rechargeable battery Current consumption at nominal voltage:typ. 180 mAwith transmitter switchedoff: ≤ 25 µAOperating time Typically 8 h Dimensions Approx. Ø 50 x 265 mm Weight (incl. batteries)approx. 450 gC--TH: 748.2 757.8 MHzPRODUCT VARIANTSMade in Germanyew 100 G4 Base SKM-S-C-TH 748.2 to 757.8 MHz Art. no. 508976DIMENSIONS EM 100 G4DIMENSIONS SKM 100 G4-SARCHITECT‘S SPECIFICATIONA wireless RF transmission system consisting of a stationary receiver and a handheld transmitter includings a micropho-ne head.The system shall operate within twelve UHF frequency ranges, with a switching bandwidth of up to 42 MHz: 470 –516 M Hz, 516 – 558 MHz, 520 – 558 MHz, 566 – 608 M Hz, 606 – 648 MHz, 626 – 668 MHz, 734 – 776 MHz, 780 – 822 M Hz, 823 – 865 MHz, 806 – 810 MHz, 925 – 937.5 M Hz, 1785 – 1800 MHz; receiving frequencies shall be 1,680 per range and shall be tunable in 25 kHz steps. The system shall featur e 20 fix ed frequency banks with up to 12 compatible frequency presets and 1 user bank with up to 12 user programmable frequencies.The receiver shall be menu-driven with a backlit LC display showing the current frequency, frequency bank and channel number, metering of RF level, metering of AF level, lock status, pilot tone evaluation, muting function, and battery status of the associated transmitter. An auto-lock feature shall be provided to prevent settings from being accidentally altered. The receiver shall feature an integrated guitar tuner and shall provide a sound check mode.Some receiver parameters such as receiving frequency, receiver name and pilot tone setting shall be synchronizable with the associated transmitter via an integrated infrared interface.The receiver shall feature a balanced XLR-3M audio output with a maximum output of +18 dBu along with an unbalanced ¼" (6.3 mm) audio output with a maximum output of +12 dBu. The receiver shall have two DATA ports (RJ 10) to set up a multichannel system. Two BNC-type input sockets shall be provided for connecting the antennas. Nominal/peak devia-tion shall be ±24 kHz/±48 kHz. Squelch threshold shall be adjustable to three levels: Low (5 dBµV), Middle (15 dBµV) and High (25 dBµV).The receiver shall incorporate the Sennheiser HDX compander system and a defeatable pilot tone squelch. Sensitivity shall be < 2 µV for 52 dBA eff S/N with HDX engaged at peak deviation. Adjacent channel r ejection shall be ≥ 65 d B (t y-pical). Intermodulation att enuation shall be ≥ 65 d B (t ypical); blocking shall be ≥ 70 dB. Four selectable equalizer presets shall be provided: “Flat”, “Low Cut” (−3 d B at 180 Hz), “L ow Cut/High Boost” (−3 d B at 180 H z/+6 dB at 10 kHz) and “High Boost” (+6 dB at 10 k Hz). Signal-t o-noise ratio at 1 mV and peak de viation shall be ≥ 110 dB A. Total harmonic distortion (THD) shall be ≤ 0.9 %. The audio output le v el shall be adjustable within a 48 d B range in st eps of 3 dB.The receiver shall operate on 12 V power supplied from the NT 2-3 CW mains unit (for 100 – 240 V AC, 50/60 Hz). Power consumption shall be 300 mA. The receiver shall have a rugged metal housing; dimensions shall be approximately 190 x 212 x 43 mm (7.48" x 8.35" x 1.69"). Weight shall be approximately 980 grams (2.16 lbs). Operating temperature shall range from −10 °C to +55 °C (+14 °F to +131 °F).The receiver shall be the Sennheiser EM 100 G4.The radio microphone shall be menu-driven with a backlit LC display showing the current frequency, frequency bank and channel number, metering of AF level, transmission status, lock status, pilot tone transmission, muting function, and bat-tery status. An auto-lock feature shall be provided to prevent settings from being accidentally altered.The radio microphone paramet ers shall either be configurable in the associat ed receiver’s menu and synchronized with the radio microphone via an integrated infrared interface or shall be programmable in the radio microphone menu. Recei-ver parameters such as receiving frequency, receiver name and pilot tone setting shall be synchronizable with the radio microphone via an integrated infrared interface.The handheld vocal radio microphone shall be equipped with a mute switch, which shall be switchable between “AF on/ off”, “RF on/off” and “Disabled” via the user interface. Nominal/peak deviation shall be ±24 kHz/±48 kHz. Frequency stability shall be ≤ ±15 ppm. RF output pow er at 50 Ω shall be 30 m W (typical).The radio microphone shall incorporate the Sennheiser HDX compander system and a defeatable pilot tone squelch. Audio frequency response shall range from 80 – 18,000 Hz. Signal-to-noise ratio at 1 mV and peak deviation shall be ≥ 110 dBA. Total harmonic distortion (THD) shall be ≤ 0.9 %. Input sensitivity shall be adjustable within a 48 dB range in steps of 6 dB.Power shall be supplied to the radio microphone by tw o 1.5 V AA siz e batteries or by one Sennheiser BA 2015 recharge-able accupack. Nominal voltage shall be 2.4 V, current consumption shall be typical 180 mA at nominal voltage; ≤ 25 µA when radio microphone is switched off. Operating time shall be typical 8 hours. The radio microphone shall have a rugged metal housing; dimensions shall be approximately 50 mm (1.97") in diameter and 265 mm (10.43") in length. Weight inclu-ding the batteries shall be approximately 450 grams (0.99 lbs). Operating temperature shall range from −10 °C to +55 °C (+14 °F to +131 °F).A range of microphone heads shall be available for the radio microphone.The radio microphone shall be the Sennheiser SKM 100-S G4.Sennheiser electronic GmbH & Co. KG · Am Labor 1 · 30900 Wedemark · Germany · 。

ModelPower supplySpecifications •ML4803A indicatorFrequency rangeSensorCoaxial typesFor quasi-millimeter and millimeter wavesDisplayCalibration coefficient, offset value, andreference level setting Power range Range switching Range displayAccuracyAccuracy (at indicator)Zero adjustmentZero settingZero shift between each rangeCalibration oscillator Averaging RF blanking output Recorder output Remote-control Memory function AC power supply DC power supply External battery packOperating temperature SafetyDimensions and mass EMC *1100 kHz to 90 GHzFor high level: MA4701A, MA4703A, MA4705A, MA4601A, MA4603A For low level: MA4702A, MA4704A, MA4602A, MA4604AMP737A, MP738A, MP712A[ ] , MP713A[ ] (used with MA4002A Adapter)MP714A[ ], MP715A[ ], MP716A[ ], MP717A[ ] (used with MA4002B Adapter)W, dBm, or dB (REL) can be selected. 4-digit digital display (20% over range is equipped)Compact analog indicator is built-in (values cannot be used.)Calibration coefficient: 0 to 10 dB (accuracy: 0.01 dB)Offset value: 0 to ±99.99 dB (accuracy: 0.01 dB)Reference level: –99.99 to +99.99 dBm (accuracy: 0.01 dB)MA4701A/4703A/4705A/4601A/4603A full-scale values: –20, –10, 0, +10, +20 dBm (10 µW to 100 mW)MA4702A/4704A/4602A/4604A full-scale values: –60, –50, –40, –30, –20 dBm (1 nW to 10 µW)MP series sensors full-scale values: –20, –10, 0, +10, +20 dBm (10 µW to 100 mW)Automatic or manual (range hold) can be selected.When manual is selected, an arbitrary range can be set unrelated to input levels.Selected range (when range is held) is displayed on range lamps 1 to 5.An under range or over range is also displayed.WATT mode: ±0.5%, dBm mode: ±0.02 dBm, dB (REL) mode: ±0.02 dB Automatically performed by pressing push-button keyMA series sensors: ±0.5% of full scale (typical value) at the highest sensitivity range (range 1)MP series sensors: ±1.0% of full scale (typical value) at the highest sensitivity range (range 1)MA series sensors: ±0.2% of full scale after zero set at the highest sensitivity range MP series sensors±0.8% of full scale: Range 2 after zero set at the highest sensitivity range±0.5% of full scale: Range 3 to 5 after zero set at the highest sensitivity range 50 MHz calibration oscillator is built in. Output connector: N (J)Output power: 1.00 mW (0 dBm)Accuracy: Set to within 0.7% at factory (NIST traceable) ±1.2% worst case for one year 4 sample rates can be selected.Low-level TTL (0 to +0.25 V) in zero set modeHigh-level TTL (5 ±0.25 V) when zero set mode is cancelledDC voltage proportional to indicated value is output (1 V in full-scale display).Output impedance: 1 k Ω, Output connector: BNCGPIB is standard.Front panel functions other than the power switch can be controlled externally.SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT0, C0Up to 30 frequencies, calibration coefficient, offset value, and reference level data combinations can be stored.100 V +10–15%, 50/60 Hz, <20 VA+7 to +12 V, ≤13 VAContinuous operation with MZ5003A Battery Pack: 5 hours 0˚ to 50˚C213 (W) x 88 (H) x 250 (D) mm, ≤3 kg EN61010-1: 1993 (Installation Category ΙΙ, Pollution Degree ΙΙ)EN55011: 1991, Group 1, Class A EN50082-1: 1992*1: Electromagnetic Compatibility•Coaxial-type power sensorsAmorphous power sensorFrequency range Nominal impedanceMeasured power range Maximum input power Linearity Input connector Dimensions and massMaximum VSWRMA4701A 10 MHz to 18 GHz50 Ω–30 to +20 dBm (1 µW to 100 mW)300 mW in average±3% in only +10 to +20 dBm rangeN34 (W) x 25 (H) x 98 (L)mm, ≤200 g1.4 (10 to 30 MHz)1.18 (30 to 50 MHz)1.1 (50 MHz to 2 GHz)1.18 (2 to 12.4 GHz)1.28 (12.4 to 18 GHz)MA4703A 50 MHz to 26.5 GHzAPC-3.534 (W) x 25 (H) x 87 (L) mm, ≤200 g1.15 (50 to 100 MHz)1.10 (0.1 to 2 GHz)1.15 (2 to 12.4 GHz)1.20 (12.4 to 18 GHz)1.25 (18 to 26.5 GHz)MA4705A 50 MHz to 32 GHz1.15 (50 to 100 MHz)1.10 (0.1 to 2 GHz)1.15 (2 to 12.4 GHz)1.20 (12.4 to 18 GHz)1.25 (18 to 26.5 GHz)1.50 (26.5 to 32 GHz)MA4601A 100 kHz to 5.5 GHzN34 (W) x 25 (H) x 98 (L) mm, ≤200 g1.3 (100 to 300 kHz)1.2 (0.3 to 1 MHz)1.1 (1 MHz to 4 GHz)1.2 (4 to 5.5 GHz)MA4603A 100 kHz to 2 GHz75 ΩNC1.4 (100 to 300 kHz)1.15 (300 kHz to 2 GHz)4Dimensions and massRequired adapter typeRequired adapter typeOptional accessoriesMA4001A Range Calibrator (for indicator full-scale calibration)MA4002A Sensor Adapter for quasi-millimeter wave (for MP712A/713A/737A/738A)MA4002B Sensor Adapter for millimeter wave (for MP714A/715A/716A/717A)J0364APC-3.5 to N conversion connector (required for MP4703A/4704A/4705A)J0365NC-J•N-P conversion connector for sensitivity calibration (required for MA4603A/4604A)MP47A Attenuator for sensitivity calibration (30 dB, required for MA4602A/4604A/4702A/4704A)MP721D Fixed Attenuator (20 dB, N-type, 2 W, DC to 12.4 GHz)J0077Fixed attenuator (20 dB, N-type, 2 W, DC to 18 GHz)J0063Fixed attenuator (30 dB, N-type, 10 W, DC to 12.4 GHz)J0078Fixed attenuator (20 dB, N-type, 10 W, DC to 18 GHz)J0395Fixed attenuator (30 dB, N-type, 30 W, DC to 8.6 GHz)J0064A 7 GHz band coaxial waveguide connector (5.8 to 8.2 GHz, N-J to BRJ-7)J0064B 10 GHz band coaxial waveguide connector (10.0 to 15.0 GHz, N-J to BRJ-120)J0064C 10 GHz band coaxial waveguide connector (8.2 to 13.0 GHz, N-J to BRJ-10)J036618 GHz band coaxial waveguide connector (17.7 to 21.2 GHz, SMA-J to FUBR180)J036722 GHz band coaxial waveguide connector (18 to 26.5 GHz, APC-3.5-J to UG-5971U)J036830 GHz band coaxial waveguide connector (26.5 to 34 GHz, APC-3.5-J to UG-5991U)J0632A 18 GHz band coaxial waveguide connector (17.7 to 22 GHz, SMA-J to FUBR180)J0632B 26 GHz band coaxial waveguide connector (22 to 33 GHz, K-J to FUBR260)J0633A Conversion connector (NC-J • BNC75-J)J0633B Conversion connector (NC-J • BNC75-P)J0633C Conversion connector (NC-P • BNC75-J)J0633D Conversion connector (NC-P • BNC75-P)J0633E Conversion connector (NC-P • SP3C-J)J0633F Conversion connector (NC-J • SP3C-P)J0633G Conversion connector (NC-P • SP3C-J)J0633H Conversion connector (NC-P • SP3C-P)J0369T aper waveguide: WRJ-320 (FUBR320)/WRJ-260 (FUBR260)B0183Rack mount kit-1 (for one ML4803A)B0184Rack mount kit-2 (for two ML4803A)B0185Carrying bagB0186Protective front coverJ0370C Sensor cord, 2.5 m (for extension)J0370E Sensor cord, 5 m (for extension)J0370G Sensor cord, 10 m (for extension)MZ5003A Battery Power Supply (for DC operation)J0371DC power cord (for +7 to +12 V power supply)J0008GPIB cable, 2 mDiode power sensorModelFrequency range Nominal impedance Measured power range Maximum input power Linearity Input connector Maximum VSWR MA4702A 10 MHz to 18 GHz50 Ω–70 to –20 dBm (0.1 nW to 10 µW)200 mW in average/peak, 0 Vdc ±2% in only –30 to–20 dBm rangeN34 (W) x 25 (H) x 98 (L) mm, ≤200 g 1.4 (10 to 30 MHz)1.15 (30 MHz to 4 GHz)1.2 (4 to 8 GHz)1.3 (8 to 18 GHz)MA4704A 50 MHz to 26.5 GHzAPC-3.534 (W) x 25 (H) x 87 (L) mm, ≤200 g1.15 (50 MHz to 4 GHz)1.2 (4 to 8 GHz)1.3 (8 to 18 GHz)1.54 (18 to 26.5 GHz)MA4602A 100 kHz to 5.5 GHzN34 (W) x 25 (H) x 98 (L) mm, ≤200 g1.3 (100 to 300 kHz)1.15 (300 kHz to 3 GHz)1.2 (3 to 5.5 GHz)MA4604A 100 kHz to 2 GHz75 ΩNC1.4 (100 to 300 kHz)1.2 (300 kHz to 2 GHz)ModelMP737A 17 to 22 GHz1.6–30 to +20 dBm (1 µW to 100 mW)+22 dBm (160 mW)±3% only +10 to +20 dBm range52ø x 103L mm, ≤450 gMA4002AMP738A 21.7 to 33 GHz1.5MP712A[ ]18 to 26.5 GHz1.6MP713A[ ]26.5 to 40 GHz1.5MP714A[ ]33 to 50 GHz52ø x 78L mm, ≤700 gMA4002BFrequency range Maximum VSWR Measured power range Maximum input power Linearity error Dimensions and mass ModelMP715A[ ]40 to 60 GHz 1.4–30 to +20 dBm (1 µW to 100 mW)+22 dBm (160 mW)±3% in only +10 to +20 dBm range 52ø x 78L mm, ≤700 g (including cord)MA4002BMP716A[ ]50 to 75 GHzMP717A[ ]60 to 90 GHzFrequency range Maximum VSWR Measured power range Maximum input power Linearity error Dimensions and mass •Waveguide sensorsFor quasi-millimeter wavebandPlease select the type of flanges from the below and put its number in the mark [ ].Blank: JIS flange, 1: MIL flange, 4: UG flangeFor millimeter wavebandOrdering informationPlease specify model/order number, name, and quantity when ordering.Model/Order Main frame ML4803A Power MeterStandard accessoriesJ0370A Sensor connecting cord, 1.5 m: 1 pc J0017Power cord, 2.5 m: 1 pc F0018Fuse, 0.5 A:1 pc W0081AE ML4803A operation manual: 1 copy W0081BE ML4803A service manual:1 copySensorsMA4601A Amorphous Power Sensor (coaxial-type)MA4603A Amorphous Power Sensor (coaxial-type)MA4701A Amorphous Power Sensor (coaxial-type)MA4703A Amorphous Power Sensor (coaxial-type)MA4705A Amorphous Power Sensor (coaxial-type)MA4602A Diode Power Sensor (coaxial-type)MA4604A Diode Power Sensor (coaxial-type)MA4702A Diode Power Sensor (coaxial-type)MA4704A Diode Power Sensor (coaxial-type)MP712A[ ]Waveguide Type Sensor *1MP713A[ ]Waveguide Type Sensor *1MP714A[ ]Waveguide Type Sensor *1MP715A[ ]Waveguide Type Sensor *1MP716A[ ]Waveguide Type Sensor *1MP717A[ ]Waveguide Type Sensor *1MP737A Waveguide Type Sensor *1MP738AWaveguide Type Sensor *1Model/Order *1: Refer to the data sheet for ML4803A. Specify waveguide type when ordering.。

“V”字头代码(SMD Marking Code)代码规格型号生产商封装备注V01 VN50300T Sil - n-ch enh mosfet 500V 22mAV02 VN0605T Sil - n-ch enh mosfet 60V/0.18AV04 VN45350T Sil - n-ch enh mosfet 450V 20mAV1p BFT25 Phi SOT23 npn RF 5V 6.5mA 2.3GHz V1 MRF959 Mot SC75 npn RF fT 9GHzV2 BFQ67 Tfk - npn RF fT 7.5 GHz 50mA V3 BFG67 Phi SOT143 npn RF fT 8GHz 50mAV5 BFG197 Phi SOT143 npn RF 7.5GHz 100mAV11 3SK131 Nec SOT143 dg VHF mosfetV11 3SK242 Nec SOT343 dg VHF mosfetV12 3SK131 Nec SOT143 dg VHF mosfetV12 3SK242 Nec SOT343 dg VHF mosfetV13 3SK131 Nec SOT143 dg VHF mosfetV13 ZC932 Zet SOT23 5 - 17pF hyperabrupt varicapV13 3SK242 Nec SOT343 dg VHF mosfetV14 ZC931 Zet SOT23 4 -13.5pF hyperabrupt varicapV15 ZC930 Zet SOT23 3 - 9pF hyperabrupt varicapV16 ZC934 Zet SOT23 25 - 95pF hyperabrupt varicapV17 ZC933 Zet SOT23 12 - 42pF hyperabrupt varicapV21 3SK222 Nec SOT143 dg VHF mosfet V21 3SK246 Nec SOT343 dg VHF mosfet V22 3SK222 Nec SOT143 dg VHF mosfet V22 3SK246 Nec SOT343 dg VHF mosfetV50 VP0610T Sil - p-ch enh mosfet -60V 120mAVB MSC2295-B Mot - npn RF 150MHz fT 20V VC MSC2295-C Mot - npn RF 150MHz fT 20V V87 SMV1204-87 SOT 23 CATHODE(TWIN) VA1 SMV1206-001 SOT 23 SINGLEVA3 SMV1206-004 SOT 23 CATHODE(TWIN) VB1 SMV1207-001 SOT 23 SINGLEVB3 SMV1207-004 SOT 23 CATHODE(TWIN) VC1 SMV1297-001 SOT 23 SINGLEVD1 SMV1227-001 SOT 23 SINGLEVDW SMV1203-96 SOT 23 SINGLEVE1 SMV1228-001 SOT 23 SINGLEVF1 SMV1229-001 SOT 23 SINGLEVG1 SMV1203-01 SOT 23 SINGLEVH1 SMV1203-05 SOT 23 SINGLEVJ1 SMV2022-001 SOT 23 SINGLEVJ3 SMV2022-004 SOT 23 CATHODE(TWIN) VJ9 SMV2022-003 SOT 23 ANODE (TWO)VK1 SMV2023-001 SOT 23 SINGLEVK3 SMV2023-004 SOT 23 CATHODE(TWIN) VK7 SMV2023-015 SOT 143 SPLIT PR(TWO) VK9 SMV2023-003 SOT 23 ANODE (TWO)VL1 SMV1214-001 SOT 23 SINGLEVL3 SMV1214-004 SOT 23 CATHODE(TWIN) VL9 SMV1214-003 SOT 23 ANODE (TWO) VM1 SMV1215-001 SOT 23 SINGLEVN1 SMV1224-001 SOT 23 SINGLEVP1 SMV1233-001 SOT 23 SINGLEVP3 SMV1233-004 SOT 23 CATHODE(TWIN) VP9 SMV1233-003 SOT 23 ANODE (TWO) VPB SMV1233-007 SOT 23 ANODE SINGLE VQ1 SMV1234-001 SOT 23 SINGLEVQ3 SMV1234-004 SOT 23 CATHODE(TWIN) VQ9 SMV1234-003 SOT 23 ANODE (TWO) VR1 SMV1235-001 SOT 23 SINGLEVR3 SMV1235-004 SOT 23 CATHODE(TWIN) VS1 SMV1420-001 SOT 23 SINGLEVT1 SMV1237-001 SOT 23 SINGLEVT3 SMV1237-004 SOT 23 CATHODE (TWIN) VU1 SMV1299-001 SOT 23 SINGLEVU3 SMV1299-004 SOT 23 CATHODE(TWIN) VU7 SMV1299-015 SOT 143 SPLIT PR(TWO) VV1 SMV1408-001 SOT 23 SINGLEVV3 SMV1408-004 SOT 23 CATHODE (TWIN) VW1 SMV1409-001 SOT 23 SINGLE VW3 SMV1409-004 SOT 23 CATHODE (TWIN) VX1 SMV1411-001 SOT 23 SINGLE VX3 SMV1411-004 SOT 23 CATHODE (TWIN) VY1 SMV1419-001 SOT 23 SINGLEVZ1 SMV1421-001 SOT 23 SINGLE。

Pro 6000E GenSetGasoline 6 kW 60 Hz• Onan Portable GenSet® EliteTM14 hp Overhead Valve Engine• Full-Featured Control Panel • Electric Start• Low Oil Pressure Shutdown with Indicator Light • 9-gal, 10-hr Fuel Tank • Idlematic with SwitchModels and RatingsModel Starter Hz Voltage MaxWatts Max Amps Rated Watts RatedAmpsAC Receptacles 6.0 EGHEB/38018* Electric/Recoil60120/240600050/25 550045.8/22.9 (1) Duplex 120V/15A GFI(2) Duplex 120V/30A TL (1) Duplex 120V/30A TL*CSA-approved.Ratings apply to altitudes up to 500 ft (152.4 m), 85o F (29.4oC).Derating: Power output will decrease 3.5% for each 1000 ft (305 m) above sea level and 1% for each 10oF(5.5o C) increase in ambient temperature about 85o F (29oC).Weight, Size and Sound Level• Dry Weight: 205 lb (94 kg)• Length: 29.2 in (743 mm); Width: 22.5 in (572 mm); Height: 28.0 in (711 mm) • Sound Levels- Idlematic:, 65 dB(A) at 7 m, 79 dB(A) at 1 m- Full Load, 60Hz: 79 dB(A) at 7 m, 92 dB(A) at 1 m© 2003 Cummins Power Generation Specifications subject to change without notice A-1398a (10/03)Standard Features • Onan® Elite TM 14-hp overhead valveengine• Low oil pressure shutdown• Electronic ignition• AC and DC manual reset circuitbreakers• Dual element air cleaner• Wrap-around protective cradle of 1-in steel tubing• USDA spark-arresting muffler• Vibration isolator frame mountings• Electric and recoil start• 9-gal, 10-hr fuel tank at rated load• Solid state automatic voltageregulator• Full-featured control panel• Idlematic with switch• Full-flow oil filter• VoltmeterReceptacles• 6.0 EGHEB/38018, (CSA-approved)(60 Hz)- (1) Duplex, 120V/15A GFI (AC),(NEMA 5-15R)- (2) 120V/30A Twistlock (AC),(NEMA L5-30R)- (1) 120/240V/20A Twistlock (AC)(NEMA L14-30R- (1) 12V/10A, 120W (DC)• Full-power switch• Simultaneous AC and 12 VDC• 12 VDC battery charging with cables• Battery tray (battery not included.Recommended 180 cca minimum @40o F, 300 cca @ -20o FAccessories • Two wheel dolly kit - (part #410-1166)• Twistlock plug 120 V/30 A, NEMAL5-30P (part #323-0862)• Twistlock plug 120/240 V/20 A,NEMA L14-20P (part #323-0857)Engine and Performance Detail Design: 4-cycle gasolineCylinders: 1Bore: 3.31 in (84.2 mm)Stroke: 2.76 in (70 mm)Displacement: 23.8 in3 (390 cm3)Power: 14 bhp maxCylinder liner: Cast ironValves: Overhead valve configuration.Premium valve materials, replaceableguides and seats and intake stem seals.Lubrication system: Positivedisplacement oil pump (full-pressurelubrication) with filterLube oil capacity: 1.0 qt (0.9 L) withfilterStarting system: Electric/recoilApproximate run time: 10 hr at ratedloadFuel tank capacity: 9 gal (34 L)Automatic decompression releasesystemTypical fuel consumptionGasoline, gph (Lph)No load Half load Full load60 Hz (est.) NA 0.51 (1.9) 0.92 (3.5)Alternator Detail Design: 2-pole AC alternatorExciter system: Self-excited, permanentmagnet provides instant voltage build up.Cooling: Air-cooledVoltage regulator: AutomaticNo load to full load Constant loadGenSetDetail Voltage regulationFrequency regulation ±3%±4%±2%±2%BasicDimensionsThis outline drawing is provided for general reference only and is not intended for design or installation. See installation manual and obtian outline drawing 500-2653 for more information (available from you Distributor/Dealer).Warranty Policy Onan Pro Series Portable GenSets are backed by Onan's standard three-year limited warranty, with an optional five-year extended warranty. See your local Distributor/Dealer for details.After Sale SupportGENUINE ONAN MAINTENANCE PARTS AND PRODUCTSFor your ongoing satisfaction and the dependability of your Onan genset, Onan offers a complete line of replacement and tune-up parts, oil and maintenance chemicals specifically designed for gensets. Easy to find at Onan service and parts dealers coast-to-coast, Onan Green Label TM parts are packaged for correct selection and convenient storage.EASY TO LOCATE CERTIFIED ONAN SERVICE AND PARTS DEALERS Onan has over 400 certified commercial service dealers covering most majormetropolitan areas in the U.S. and Canada. To locate Onan service dealers in your area, call 1-800-888-ONAN and request a commercial service and parts dealer directory (F-1060).Standards and TestingTested at extremes of temperature -20o F to +120o F for starting and operation.60 Hz models (120/240V only) listed by Nationwide Consumer Testing Institute, Inc. per ANSI/EGS-1 and CSA certified per electrical Bulletin 946. Tested in high humidity conditions. Tested in salt spray conditions.Tested in heavy air borne dust conditions. Field Test Program.This product meets US. EPA Phase 1 and 1995-1999 California Regulations for utility and lawn and garden equipment engines.Do not use this genset on a boat. Such use may violate U.S. Coast Guardregulations, and can result in severe personal injury or death from fire, explosion, electrocution, or carbon monoxide poisoning.Contact your Distributor/Dealer for more information:To easily locate the nearest Onan Distributor/Dealer, or for more information, contact Onan at 1-800-888-ONAN or 763-574-5000; 1400 73rd Avenue N.E., Minneapolis, MN 55432 U.S.A.;fax 763-574-5298; .Onan is a subsidiary of Cummins Engine Company. Onan is a registered trademark of Onan Corporation.Cummins is a registered trademark of Cummins Engine Company.WARNING: Backfeed to utility systems can cause electrocution or property damage. Do not connect to building electrical except through approved device and after building main breaker is opened.。
