《毕业论文-基于单片机原理的烟雾传感器设计》摘要火灾已成为我国常发性和破坏性以及影响力最强的灾害之一。
随着经济和城市建设的快速发展，城市高层、地下建筑以及大型综合性建筑日益增多，火灾隐患也大大增加，火灾的数量及其造成的损失呈逐年上升趋势。
在工业和民用建筑、宾馆、酒店、图书馆、科研和商业部门，火灾烟雾报警器已成为必要的装置。
火灾报警系统对现代建筑起着极其重要的安全保障作用。
火灾报警控制器是火灾烟雾报警系统的核心。
本文对火灾烟雾报警控制器和探测器做了深入的研究，并全面阐述了火灾烟雾报警控制器和探测器硬件和软件设计。
以下是本文完成的主要工作: 1(火灾烟雾报警系统的控制器采用C8051F020单片机进行设计，所设计的控制器具有较高的性价比，还具有操作人员管理、报警信息查询、探测器管理、预报警、火警处理、通讯等功能，在控制器中采用LCD显示器进行报警系统所需各种信息显示。
2(探测器控制电路的核心采用PHILIP公司的低功耗P87LPC762单片机，它实现了对火灾信息的检测和传送;为提高系统的适应性与扩展性，进行了写码器设计。
3(控制器与探测器之间的通讯采用无线高频通讯方式进行，运用KB8825双频合成器进行了无线通讯电路设计，具有抗干扰能力强、功耗低等优点，可靠地完成了探测器与控制器之间的无线通信。
本文设计的火灾烟雾报警电路能有效地防止和减少火灾危害，解决有线火灾报警系统不能解决的问题，对保护人身安全和财产安全具有现实意义。
