Performance Series IPPerformance Series IP Embedded NVR Kits 3 Megapixel Full HD IP Cameras and 4 channel embedded NVRIntroducing the new Performance Series IP embedded NVR kits from Honeywell. The kits feature 3 Megapixel Full HD IR-illuminated IP66-rated cameras, and an embedded NVR with a user-friendly set-up and configuration wizard that takes you to live video in minutes. You have a choice of a 1 or 2 TB embedded NVR (Field upgradeable up to 12TB* storage max) and 4 IP ball cameras OR 4 IP bullet cameras. These bundled kits offer the perfect economical and flexible solution for small to medium sized businesses.Fully-featured NVRs• High decoding capability for full HD viewing and recording.• View up to four channels simultaneously on your monitor.• All channels live view and play back at 1080p @ full frame rate and 3MP @ 20 frames per second.• Bidirectional audio communication for the NVR.Fully-featured Cameras• IR LEDs facilitate recording in dimly lit or nighttime scenes.• Waterproof (IP66) camera housings are perfect for outdoor installations.• C amera configurations to improve image quality and reduce image size, and to detect and respond to alarm events.• 1/3” 3MP sensor, no distortion of image in 16:9 display, 12.5% more pixel density than conventional 3MP 4:3 cameras• Easy to Use• The Quick wizard and PoE support of plug-and-play makes setup fast and easy.• P hysical installation within minutes with the help of comprehensive and easy-to-understand quick installation guides for the NVR and IP cameras.Convenient, Flexible Storage Options• Internal storage supports two HDDs up to 12 TB (6 TB each).*• S tore videos and snapshots to external storage, such as the client 's PC, over the Internet.• Store videos and snapshots to an external network storage server such as an FTP site.• Store videos and snapshots to a USB memory device.Dynamic, Accessible Monitoring• M onitor from anywhere using the mobile apps for Apple and Android smartphones, tabletcomputers, and laptops.Privacy Masking• Conceal up to 4 areas of a scene from viewing and recording.Safety Features• Configurable motion detection and camera tamper detection settings, including configurable alarm alerts, such as automatic emails (with attached video or snapshot) and automatic alerts (such as buzzers or flashing lights).• R emote configuration and firmware updating through Honeywell Viewer web client and theHoneywell Config tool. Password-protected access to the camera’s and NVR’s video and network setup.Market Opportunities• The flexible storage options of the Performance Series IP Embedded NVR plus thefully-featured IPIR cameras make this kit perfect for many security applications.Performance Series IP FeaturesImmediately Detect and Respond toEventsThe Performance Series IP NVR/Cameras can beconfigured to automatically detect and respondto events such as motion in the scene, alarminputs, a network failure and/or tampering.Automated responses include:• Sending a notification through email, FTP and/or HTTP.• Uploading still images at the time of the eventthrough email and/or FTP.• Recording a video clip of the event to the client’sPC or network-attached storage.• Enabling a visual or auditory notification (aflashing light, bell or siren).Performance Series IPNVR specifications* Actual bitrate is scene and motion dependent with H.264 stream.** Some development might be required in specific user cases to support some of these protocols in the field as naturally protocols will mature over time.Performance Series IP Camera specificationsPerformance Series IP DimensionsHED3PR3 Ball CameraBullet Camera85,4 мм113,6 мм52,6 ммHSFV-Performance-01-UK(0816)-DS-R © 2016 Honeywell International Inc.For additional information, please visit:/security/ukHoneywell Security GroupAston Fields RoadWhitehouse Industrial Estate RuncornCheshire WA7 3DL Tel************Performance Series IPOrderingNOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.HEN04122EBXHoneywell Embedded NVR EB = Ball camera Kit BB = Bullet camera Kit X = PAL Version NVR Channels 1 or 2 TB storage1080p。
PVG®网络视频管理平台5.x管理员指南地址：北京市海淀区学院路35号世宁大厦902室电话：(010) 8232 5566目录第一章PVG概述 (6)PVG是什么 (6)PVG软件组成 (7)PVG5.x新增特性 (8)开放的构架 (8)POSA构架 (8)完整的数字干线管理 (8)帧标记 (9)第二章维护PVG服务器 (10)修改PVG的IP地址 (10)方法一直接修改 (11)方法二建立连接后修改 (11)升级PVG软件 (11)查看PVG版本 (12)第三章配置方法 (13)使用PowerManager配置 (13)使用PowerShell配置 (13)第四章配置文件管理 (14)在线配置 (14)离线编辑配置文件 (14)新建本地配置文件 (14)下载配置文件 (15)打开配置文件 (15)保存和关闭配置文件 (15)上传配置文件 (16)定制自己的配置文件模板 (16)第五章对象和属性 (17)理解对象和属性 (17)对象树 (18)对象命名规则 (19)通用属性 (19)全局对象命名 (19)根对象及其属性 (20)创建、删除和重命名对象 (20)创建对象 (20)删除对象 (21)重命名对象 (21)第六章用户管理 (23)用户 (23)创建用户对象 (23)编辑用户属性 (23)用户缺省属性 (24)用户组 (24)全局用户和用户组 (24)第七章权限和级别 (26)理解权限和级别 (26)权限定义 (26)权限下载和继承 (27)级别定义 (27)权限和级别 (27)授权 (27)选择授权方案 (27)增加权限 (28)修改权限 (29)删除权限 (29)同时给多个对象授权 (30)一次登录全网漫游 (30)第八章编解码盒和A V对象 (31)编解码盒 (31)理解A V对象 (31)A V组对象 (36)创建A V组对象 (37)模拟摄像机 (37)创建模拟摄像机 (37)修改模拟摄像机 (39)数字摄像机 (39)创建数字摄像机 (39)修改数字摄像机 (40)模拟监视器 (40)创建模拟监视器 (40)修改模拟监视器 (40)数字监视器 (40)创建数字监视器 (40)修改数字监视器 (41)编码通道 (41)创建编码通道 (41)修改编码通道 (42)解码通道 (42)创建解码通道 (42)修改解编通道 (42)组播地址范围设置 (42)第九章串口对象 (44)创建串口对象 (44)第十章矩阵及其输入输出 (45)统一设备控制接口 (45)输入端口设置 (46)输出端口设置 (48)组合矩阵参数设置 (49)为什么需要组合矩阵 (49)K组合矩阵 (49)HD组合矩阵 (50)RD组合矩阵 (51)第十一章键盘及编号映射表 (53)键盘对象 (53)创建键盘对象 (53)编辑键盘属性 (53)OSD设置 (53)编号映射表 (54)理解编号映射表 (54)用户编号 (55)摄像机编号 (55)编号解析规则 (56)监视器编号 (57)编号最大长度 (58)第十二章多服务器联网 (59)分布式构架设计 (59)两种联网协议 (59)理解高级联网协议 (59)理解矩阵主机联网协议 (60)节点表和节点表下载 (60)节点上下级关系 (61)干线和路由表 (62)干线 (62)创建输入干线 (62)创建输出干线 (63)路由表和全局路由表 (63)服务器重启通知 (65)配置矩阵主机联网协议 (66)创建A T200虚拟矩阵 (66)虚拟矩阵干线输入表 (67)虚拟矩阵摄像机列表 (68)虚拟矩阵干线输出表 (69)第十三章宏和扫描序列 (71)系统启动宏 (71)监视器缺省摄像机 (71)键盘缺省监视器 (72)键盘启动宏 (72)键盘按键宏 (72)创建宏对象 (73)编辑宏属性 (74)扫描序列 (74)创建扫描序列对象 (74)编辑扫描序列属性 (75)第十四章录像管理 (76)录像类型划分 (76)录像参数配置 (76)录像工作时间表 (77)第十五章报警管理 (79)报警设备 (79)报警输入对象 (80)报警输出对象 (80)报警联动计划 (81)第十六章电子地图管理 (83)第十七章广域网的配置 (85)理解广域网配置 (85)DDNS设置 (85)第十八章日志管理 (86)附录一宏语言 (87)概述 (87)基本函数 (87)例子 (89)例1 简单例子 (89)例2 复杂例子 (90)附录二典型模型及参考配置 (92)单PVG模型 ......................................................................... 错误！未定义书签。
Product Highlights• Varifocal lens, dome camera with 36-112° horizontal FoV • Intelligent motion indexing with search engine• Built-in motion analytics like Motion Search, Motion Recap, and Motion Heatmaps• In-camera machine learning capability for intelligent object detection• No special software or browser plugins required• Cloud-augmented edge storage minimizes physical infrastructure • Meraki dashboard simplifies operation• Secure, encrypted control architecture and storage• Secure boot and signed firmware backed by hardware security chip• Granular user access controls• Integrated 802.11ac wireless for easy upgrades from analog • IR illumination up to 30m or 98ft• Suitable for deployments of all sizes, 1-10,000+ camerasThe Meraki MV22 series, part of the MV smart camera family, brings physical security and advanced analytics together in a dome form factor suitable for a variety of deployments. The built-in powerful processor and innovative edge architecture minimizephysical infrastructure and software requirements. MV22 smart cameras ensure physical safety and security while providing business intelligence, all in a refreshingly simple package.OVERVIEWAs with the rest of the MV lineup, the MV22 series places high-endurance storage locally on the camera, removing the Network Video Recorder (NVR) and Video Management System (VMS) from the equation. Not only does this drastically simplify both installation and scaling, but it also eliminates a major network security vulnerability in IT infrastructure.MV22 series cameras are equipped with an industry-leading processor, and have a 4MP sensor for recording in up to 1080P. The processor powers advanced analytics capabilities thatpreviously required specialized software and heavy-duty hardware. Harnessing the power of machine learning for computer vision,MV22 can do real-time object detection, classification, and tracking. This compelling insight lays the foundation for more effective and efficient processes, like journey pathing, and safe working practices.MV22 cameras are varifocal dome cameras, capable of up to 3x optical zoom. The adjustable field of view provides flexibility to cover wide areas for context, or focus up close to get details of smaller scenes. This, combined with an attractive industrial design and easy installation makes it a natural fit for a variety of indoor applications.MV22: SECURITY AND ANALYTICSMV22 Cloud-ManagedSmart CamerasCamera1/3” 4MP (2688x1520) progressive CMOS image sensor256GB high endurance solid state storage (MV22)512GB high endurance solid state storage (MV22X)3-9mm focal lengthf/1.2-2.3 apertureField of view: Horizontal 36-112°, Vertical 20-57°, Diagonal 42° - 138°Lens adjustment range: Tilt: 65°, Rotation: +/- 90°, Pan: 354°1/30s to 1/32,000s shutter speedMinimum illumination 0.18 Lux (standard recording) and 0.01 Lux (night mode)Built-in IR illuminators, effective up to 30m (98ft)Video1080p HD video recording (1920x1080) with H.264 encoding up to 20fps (MV22)4MP recording with H.264 encoding up to 15fps (MV22X)Cloud augmented edge storage (locally stored video with metadata in the cloud) Optimized retention settings (scheduling and motion-based) for variable retention Up to 90 days (MV22X) 24/7 continuous video storage per camera*Direct live streaming with no client software (native browser playback)**Stream video anywhere with automatic cloud proxyHigh dynamic range (HDR)Audio recording supported with built-in microphoneNetworking and Wireless1x 10/100/1000 Base-T Ethernet (RJ45)DSCP traffic markingSupported frequence bands (country-specific restrictions apply):2.4 GHz 802.11b/g/n radio2.412 - 2.484 GHz5 GHz 802.11a/n/ac radio5.150 - 5.250 GHz (UNII-1)5.250 - 5.350 GHz (UNII-2)5.470 - 5.600, 5.660 - 5.725 GHz (UNII-2e)5.725 - 5.825 GHz (UNII-3)1x1 with one spatial streamMU-MIMO support20 and 40 MHz channels (802.11n)20, 40, and 80 MHz channels (802.11ac)Up to 256 QAM on both 2.4 GHz and 5 GHz bandsIntegrated omni-directional antennas (4.4 dBi gain at 2.4 GHz, 6.3 dBi gain at 5 GHz) 2.4 GHz Bluetooth Low Energy (BLE) radio PowerPower consumption 12.95W maximum via 802.3af PoEEnvironmentTemperature: 0°C - 40°C (32°F - 104°F)Data and Network SecurityFull disk encryption (AES 256-bit)Automatically purchased and provisioned TLS certificates (publicly-signed) Management encryption and two-factor authenticationWireless security:WPA, WPA2-PSK, WPA2-Enterprise with 802.1X EAP-TTLSTKIP and AES encryptionPhysical CharacteristicsDimensions 149mm x 97mm (diameter x height)Weight 706gFemale RJ45 Ethernet connectorMulticolor, multifunction status LEDReset buttonWarrantyWarranty 5 year hardware warranty with advanced replacementOrdering InformationMV22-HW: Varifocal Indoor Dome Camera with 256GB StorageMV22X-HW: Varifocal Indoor Dome Camera with 512GB StorageLIC-MV-XYR: Meraki MV Enterprise License (X = 1, 3, 5, 7, 10 years)MA-INJ-4-XX: Meraki 802.3at Power over Ethernet injector (XX = US, EU, UK, or AU) MA-PWR-MV-LV: Low voltage 12VDC/24VAC input PoE injector for MV camerasIn The BoxQuick start & installation guideMV camera hardwareWall mounting kitNote: Each Meraki camera requires a license to operate* Storage duration dependent on encoding settings and camera storage model.** Browser support for H.264 decoding required.MV22 Camera SpecificationsCiscoSystems,Inc.|500TerryA.FrancoisBlvd,SanFrancisco,CA94158|(415)432-1000|****************2v 1.0。
AN137138MP ISP New Camera PortingRev. 0 — 24 August 2022Application note8MP ISP New Camera Porting 1Building ISP module, drivers, and librariesTo run a camera sensor on the i.MX 8MP board, build the ISP module, drivers, andlibraries (including <cam>.ko, <cam>.so, and <cam>.drv) for your sensor. In addition,get the camera calibration files (.xml), dewarp calibration files (.json), and sensor-configuration files (.cfg) ready to set correct ISP parameters and stream mode.1.If you use NXP supported sensors (such as OS08A20), get the drivers and librariesfrom "yocto imx-isp" and "yocto vvcam" after you build the whole ISP module.2.Find detailed instructions for writing code or building new drivers and libraries in"iMX8MP_CAMERA_DISPLAY_GUIDE.pdf", available at the NXP website. Togenerate sensor-calibration files, calibrate the new camera sensor in a lab and thengenerate the ".xml" files using the camera calibration tool and the ".json" files usingthe dewarp calibration tool. Sensor-configuration files can be easily created by editingNote: If you use a flat len sensor and decide not to calibrate the new dewarpconfiguration files, bypass the ISP's dewarp feature. Use the dewarp configuration files ofother sensors with the same resolution and set the "dewarp bypass" parameter to "true".Figure 1. Bypass parameter2Building the ISP moduleTo build the ISP module, get the correct versions of toolchain, linux kernel, "yocto imx-isp" and "yocto vvcam" on your local machine.8MP ISP New Camera Porting2.1Creating the i.MX Yocto SDK and installing the toolchain1.2.3.4.image-full-armv8a-imx8mp-lpddr4-evk-toolchain-5.15-kirkstone.sh" file.5.The toolchain path is "/opt/my-tool-chain-path".2.2Building the NXP kernel1.Download the correct version of the NXP kernel from https:///external/imx/linux-imx.2.Note: The build path of the Linux kernel should be the path of the "build_v8" folder.3Building the "yocto imx-isp" (details are in "build-all-isp.sh")1.folder.8MP ISP New Camera Porting 2.4Building "yocto vvcam" (details are in "build-all-vvcam.sh")1.Download the correct version of "yocto vvcam" from https:///external/imx/isp-vvcam.In Yocto, "vvcam" is in the "build-wayland-8mp/tmp/work/imx8mpevk-poky-linux/kernel-module-isp-vvcam" folder.2.Build "vvcam" using the following command (you can also use the "build-all-5Copying useful files listed below to a build-out directoryKernel:•".dtb" files (build_v8/arch/arm64/boot/dts/freescale/imx8mp-evk-*.dtb)•Image (build_v8/arch/arm64/boot/Image)•"imx-media-dev.ko" (build_v8/drivers/stagging/media/imx/imx-media-dev.ko)Imx-isp:•Libraries (isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/lib/*.so*)8MP ISP New Camera Porting •Sensor-related files (e.g. "isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/OS08a20.*" and "isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/os08a20.*")•"isp_media_server" (isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/isp_media_server)•Test files (isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/test_*)•Sensor-configuration files (isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/Sensor*_Entry.cfg)•"vvext" (isp-imx-4.2.2.18.0/appshell/build/generated/[build mode]/bin/vvext)•Dewarp configurations (isp-imx-4.2.2.18.0/dewarp/dewarp_config/*)•Scripts to run the ISP ("isp-imx-4.2.2.18.0/imx/start_isp.sh" and "isp-imx-4.2.2.18.0/imx/run.sh")Vvcam:•Sensor driver (isp-vvcam/vvcam/v4l2/sensor/os08a20/os08a20.ko)•"vvcam-dwe" (isp-vvcam/vvcam/v4l2/video/vvcam-dwe.ko)•"vvcam-isp" (isp-vvcam/vvcam/v4l2/video/vvcam-isp.ko)•"vvcam-video" (isp-vvcam/vvcam/v4l2/video/vvcam-video.ko)Note: When building the ISP SDK, keep the Linux and SDK versions the same as theYocto release.6Using SCP to remotely send the files in the build-out directory to EVKNote: "libtinyxml2.so" is required for the build. However, it may not be included inall SDK configurations. You can build this package separately if you have the Yoctoenvironment or download pre-built package from a package distribution repository (suchas ; choose "arm64" with the correct version).7Setting the environment when bootingAfter generating and copying the necessary files into a folder, the ISP folder can look likeFigure 2.8MP ISP New Camera PortingFigure 2. ISP folder8Running ISP and sensor (e.g. OS08A20) on 8MP EVK1.2.3.4.5.6.Reference: "build-all-isp.sh", "build-all-vvcam.sh"9Porting a new camera to the tuning tool1.Download the tuning server and client released by NXP.8MP ISP New Camera Porting2.To enable other sensor tuning, you do not have to rebuild "isp-imx" and "vvcam".After porting your sensor according to the porting guide and building it, you can getthe related sensor files in the "build_output_release" directory. Just push the sensor-3.10Revision history8MP ISP New Camera Porting 11Legal information11.1 DefinitionsDraft — A draft status on a document indicates that the content is still under internal review and subject to formal approval, which may resultin modifications or additions. NXP Semiconductors does not give any representations or warranties as to the accuracy or completeness of information included in a draft version of a document and shall have no liability for the consequences of use of such information.11.2 DisclaimersLimited warranty and liability — Information in this document is believed to be accurate and reliable. However, NXP Semiconductors does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. NXP Semiconductors takes no responsibility for the content in this document if provided by an information source outside of NXP Semiconductors.In no event shall NXP Semiconductors be liable for any indirect, incidental, punitive, special or consequential damages (including - without limitation -lost profits, lost savings, business interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are based on tort (including negligence), warranty, breach of contract or any other legal theory.Notwithstanding any damages that customer might incur for any reason whatsoever, NXP Semiconductors’ aggregate and cumulative liability towards customer for the products described herein shall be limited in accordance with the Terms and conditions of commercial sale of NXP Semiconductors.Right to make changes — NXP Semiconductors reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication hereof.Suitability for use — NXP Semiconductors products are not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications where failure or malfunction of an NXP Semiconductors product can reasonably be expected to result in personal injury, death or severe property or environmental damage. NXP Semiconductors and its suppliers accept no liability for inclusion and/or use of NXP Semiconductors products in such equipment or applications and therefore such inclusion and/or use is at the customer’s own risk.Applications — Applications that are described herein for any of these products are for illustrative purposes only. NXP Semiconductors makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification.Customers are responsible for the design and operation of their applications and products using NXP Semiconductors products, and NXP Semiconductors accepts no liability for any assistance with applications or customer product design. It is customer’s sole responsibility to determine whether the NXP Semiconductors product is suitable and fit for the customer’s applications and products planned, as well as for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products.NXP Semiconductors does not accept any liability related to any default, damage, costs or problem which is based on any weakness or defaultin the customer’s applications or products, or the application or use by customer’s third party customer(s). Customer is responsible for doing all necessary testing for the customer’s applications and products using NXP Semiconductors products in order to avoid a default of the applicationsand the products or of the application or use by customer’s third party customer(s). NXP does not accept any liability in this respect.Export control — This document as well as the item(s) described herein may be subject to export control regulations. Export might require a prior authorization from competent authorities.Evaluation products — This product is provided on an “as is” and “with all faults” basis for evaluation purposes only. NXP Semiconductors, its affiliates and their suppliers expressly disclaim all warranties, whether express, implied or statutory, including but not limited to the implied warranties of non-infringement, merchantability and fitness for a particular purpose. The entire risk as to the quality, or arising out of the use or performance, of this product remains with customer.In no event shall NXP Semiconductors, its affiliates or their suppliersbe liable to customer for any special, indirect, consequential, punitiveor incidental damages (including without limitation damages for loss of business, business interruption, loss of use, loss of data or information, and the like) arising out the use of or inability to use the product, whether or not based on tort (including negligence), strict liability, breach of contract, breach of warranty or any other theory, even if advised of the possibility of such damages.Notwithstanding any damages that customer might incur for any reason whatsoever (including without limitation, all damages referenced above and all direct or general damages), the entire liability of NXP Semiconductors,its affiliates and their suppliers and customer’s exclusive remedy for all of the foregoing shall be limited to actual damages incurred by customer based on reasonable reliance up to the greater of the amount actually paid by customer for the product or five dollars (US$5.00). The foregoing limitations, exclusions and disclaimers shall apply to the maximum extent permitted by applicable law, even if any remedy fails of its essential purpose.Translations — A non-English (translated) version of a document, including the legal information in that document, is for reference only. The English version shall prevail in case of any discrepancy between the translated and English versions.Security — Customer understands that all NXP products may be subject to unidentified vulnerabilities or may support established security standards or specifications with known limitations. Customer is responsible for the design and operation of its applications and products throughout their lifecyclesto reduce the effect of these vulnerabilities on customer’s applicationsand products. Customer’s responsibility also extends to other open and/or proprietary technologies supported by NXP products for use in customer’s applications. NXP accepts no liability for any vulnerability. Customer should regularly check security updates from NXP and follow up appropriately. Customer shall select products with security features that best meet rules, regulations, and standards of the intended application and make the ultimate design decisions regarding its products and is solely responsiblefor compliance with all legal, regulatory, and security related requirements concerning its products, regardless of any information or support that may be provided by NXP.NXP has a Product Security Incident Response Team (PSIRT) (reachableat *************) that manages the investigation, reporting, and solution release to security vulnerabilities of NXP products.11.3 TrademarksNotice: All referenced brands, product names, service names, and trademarks are the property of their respective owners.NXP — wordmark and logo are trademarks of NXP B.V.8MP ISP New Camera PortingContents1Building ISP module, drivers, and libraries (2)2Building the ISP module (2)2.1Creating the i.MX Yocto SDK and installingthe toolchain (3)2.2Building the NXP kernel (3)3Building the "yocto imx-isp" (details are in"build-all-isp.sh") (3)4Building "yocto vvcam" (details are in"build-all-vvcam.sh") (4)5Copying useful files listed below to abuild-out directory (4)6Using SCP to remotely send the files inthe build-out directory to EVK (5)7Setting the environment when booting (5)8Running ISP and sensor (e.g. OS08A20)on 8MP EVK (6)9Porting a new camera to the tuning tool (6)10Revision history (7)11Legal information (8)Please be aware that important notices concerning this document and the product(s)described herein, have been included in section 'Legal information'.。
network DynaHawk MPV-071 seriesItemImage Sensor Picture Elements Color B/WShutter Speed White BalanceLensFocal Length F numberVideo Compression H.264 + MJPEG MPEG-4 + MJPEGMJPEG + BNCH.264 + H.264 H.264 + BNCH.264MJPEG MPEG-4Image SettingBrightness Exposure Backlight Sharpness ContrastWhite Balance Digital Zoom Motion Detection Image Rotation WDR3D Noise Reduction 10x Optical Zoom, Auto FocusH.264/MJPEG/MPEG-41~ 1/10000 sec.Manual / AWB CameraMinimum Illumination 1/3" Sony Progressive CCD1280(H) x 960 (V)Simultaneous Video StreamingManualOperationAuto / Manual / Fixed Shutter / Auto Iris ModeOn/Off Flip, Mirror, and 180∘Rotate 0.04 lux @ F1.60.004 lux @ F1.6F1.6(Wide); F2.0(Tele)Lens4.95 ~ 49.5 mm Resolution Frame rate Manual Auto / Manual / Indoor / Outdoor1x ~ 16x ManualOn/OffOff / 4 Level AdjustmentOn/Off 1280x960/HD 720p/D1/VGA/QVGA/CIF/QCIF 1280x960/HD 720p/D1/VGA/QVGA/CIF/QCIF 1280x960/HD 720p/D1/VGA/QVGA/CIF/QCIF1280 x 960 @ 12.5/15 fps720p @ 25/30fpsPrivacy MaskPrivacy Mask Type *ICRAudio Two-way Audio Compression AlarmInput OutputEvent Notification Multiple LanguageInterface ProtocolPassword Levels Internet Browser User AccountConnectorsPower Ethernet Micro SD Audio AlarmAnalog Video RS-485*LED IndicatorOperating Temperature Power SourcePower Consumption Regulatory Dimension Weight* mark for optional items165 x 80 x 52.4 mm (L x W x H)Line out, Line in/Mic inUser and Administrator TCP/IP, UDP, RTP, RTSP, HTTP, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP and IGMPG.711 / G.7265V 10kΩ pull upCE, FCC, RoHS Compliant SDHC support10/100 Mbps Ethernet (RJ-45)360 g (0.80 lb)0°C ~ 40°CHumidity: 10% to 90%, no condensationPower, Link, ACT GeneralDC12V/AC24V/PoE MechanicalStereo phone jack, ∅ 3.5mm1.0 Vp-p / 75 Ω, BNC4 pins terminal block 3 pins terminal blockInternet Explorer (6.0+)Transparent, Color Auto/On/Off5HTTP, FTP, SMTPEnglish, French, German, Italian, Simplified Chinese, Russian7.2W (600 mA)D+ D-Photo relay output 300VDC/ACNetworkRJ-4520MPV-071R。
CVR视频监控厂商如何推出自主品牌CVR?2014-01-16 11:01:42 来源:CPS中安网作者:朱智力责任编辑: sudiao 【大中小】前言网络高清视频监控解决了模拟监控录像“有情节没细节”这一最重要的问题，同时也对存储等配套设施提出了挑战。
CVR（Central Video Recorder）中心级视频网络存储设备由标准的IPSAN/NAS网络存储设备，结合视频监控应用发展而来，近年来市场需求日渐强烈；海康等厂商通过收购专业存储厂商快速构筑了较强的竞争力，经常通过存储技术来提高竞争门槛；在市场竞争越来越激烈的情况下，安防视频监控厂商选择何种发展模式来推出自有CVR就成为了一个比较值得探讨的话题。
同时也介绍一下中科蓝鲸所推出的CVR平台产品和专业监控OEM专业存储合作模式。
网络高清带动存储容量爆发式增长，中高端细分市场CVR需求强烈；网络高清视频监控解决了模拟监控录像“有情节没细节”这一最重要的问题，同时也对网络、存储等配套设施提出了挑战。
随着数字高清爆发式增长，存储容量需求呈现几何级增长。
比如两百万高清网络摄像机1080P设置为6mbps码率的时候容量计算方法如下：6Mb/s÷8bit换Byte×3600秒×24小时×30天÷1024MB换GB=1898.44GB；就是说每一路1080P IPC存储30天空间就需要1898.44GB，转换为TB为1.85TB，就已经略超过1块3T盘的可用容量的2/3了。
从容量角度看小盘位存储产品（比如小于8盘位）就受到所能存储摄像机的路数很大限制，所以大盘位存储产品的市场需求越来越大，所以有不少厂商推出了8盘位NVR、16盘位NVR、24盘位NVR来应对容量需求的上升。
但光是盘位的增加其实并不能解决问题，嵌入式NVR往往不能满足应用需求；因为随着容量的增加，实际应用对性能、冗余度与可靠性、可管理可维护性等提出了更高的要求，所以业界就把目光投向了原本就具有高性能（企业级通用处理器）、高可靠（RAID磁盘冗余、网络冗余、供电冗余、风扇冗余），高可管理可维护性（标准的工业部件、标准的管理协议与接口）的IPSAN/NAS网络存储设备。
IP CAMERA V-CAM DATASHEETSpecifications:Operation System: La test H.264 Baseline ProfileImage Sensor: 1.0 MP HD CMOS SensorCore Chipset: Latest DSP ChipsetResolution: 720 HD images, resolution upto 1280*720P, 1.0MPResolution Variable: 720P (1280*720), VGA (640*360), QVGA (320*180)Frame Rate: 1~30fpsMin.Illumination: color: 1.5 Lux, W/B: 0 Lux with IR LED ONIR Distance: Dual IR cut fillter with auto switch, 2 pcs high-powered ceramic IR LEDs, night vision at 20 Meters.S/N Ratio: ≥ 38dbCMOS Features: support auto balance, contrast and background light compensation. Lens/visual Angel: 3.6mm megapixel lens @F14/74°System security: Account, password two level user authentication.ONVIF Protocol: supportM obile phone monitor: support megapixel HD mobile phone monitor, dedicated IPHONE and Android software.(Software version required iOS7.0, Android 3.0 and above)Local storage: support maximum 128Gb TF card, 24 hours recording. (storeage capacity of above 32GB requires FAT32 formatting.)Audio Compression: G.711AAudio Input: 1CH Buitin 38db microphoneAudio Output: Built-in two speakers (8Ω1W)PTZ Control: Pan 355 & Tilt 120PTZ Pre-set: 5 pointsVideo Management: Recording mode: manual recording, schedule cording and alarm reco rding.Video storage: TF card Max: 128GB, NVR (support Onvif), Local client software. Network interface: 10Mbps/100Mbps self adaptive RJ45 interfaceProtocol: TCP/IP, HTTP/TCP,UDP, SMTP, DHCP, DNS, DDNS, NTP, UPnP, P2P. WiFi: WiFi 802.11b/g/nSystem Configuration: iOS 7.0, Android 3.0 and above.Material: cartoon robot/engineering plasticsWorking Condition: Indoor.Power Supply: DC5V 2AWorking Temperature: -10℃~50℃Working Humidity: ≤95% RHDimensions: 104 L* 102W* 117H (MM)Weight: N.W: 300g, G.W: 680gDimensions: 200L*150W*115H (mm)Installation method: Mounted on wall or put it on the table.。
Advanced software for maximized efficiencyEmpower operator workflows and feed information efficiently with our latestPaperStream IP scanner driver and integrated software. With a few simple setting configura-tions, Automatic Profile Selection allows documents to undergo image processing appropriate to each document format.Operators no longer need to sort documents manually since the driver works with Paper-Stream Capture to link document formats to specific saving destinations. Image process-ing functionalities are also enhanced with Advanced Cleanup Technology providing strong character recognition and image cleanup functionalities for better OCR accuracy. All these functionalities work together to offer a wider variety of batch scanning features and assist operator workflows.Organized paper output for clean and fast workflowsNot only do we ensure that paper is fed through smoothly but also that output is made in neat stacks. The improved Stacking Control function and Elevator Stacker allow operators to quickly gather documents after scanning so that operators can quickly move on to the next batch, and scan multiple batches in shorter times.Stress-free usability with an operator-friendly designThe fi-7900 is designed to make the operator experience easy. Operators can scan directly from the scanner with the job-registration function, and complete various operations on the easily-accessible operator panel and LCD status display. Ease of use also applies to routine maintenance of the scanner. The fi-7900’s LED lights make cleaning dust, debris, and ink residue build-up from the glass simply easy and stress-free.The fi-7900 scans A4 landscape documents at high speeds of 140 ppm/280 ipm (200/300 dpi). It is capable of scanning up to A3 sized portrait documents and can load up to 500 sheets at a time.Accurate feeding to maximize productivity Our production scanners are designed to build productive workflows. In addition to our reliable feeding, the fi-7900 comes with a variety of functionalities that make feeding performance even better. Finish scanning faster without the need to make any rescans, using the all-new Automatic SeparationControl function. This new function automati-cally calibrates torque on the brake rollers and guarantees that documents go through one at a time. The fi-7900 now also comes with the fi Series signature Skew Reducer function providing independent separator rollers to ensure skewed documents do notaffect documents to follow.Advanced productivity for high-volume scanningDatasheetFUJITSU Image Scanner fi-7900Datasheet FUJITSU Image Scanner fi-7900TrademarksISIS is a trademark of Open Text. Microsoft, Windows, and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Any other products or company names appearing in this document are the trademarks or registered trademarks of the respective companies.Safety PrecautionsBe sure to carefully read all safety precautions prior to using this product and use this device as instructed. Do not place this device in wet, moist, steamy, dusty or oily areas. Using this product under such conditions may result in electrical shock, fire or damage to this product. Be sure to limit the use of this product to listed power ratings.ENERGY STAR®PFU Limited, a Fujitsu company, has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR® is a registered trademark of the United States.Specifications are subject to change without notice. Visit your local Fujitsu website for more information.*1 Actual scanning speeds are affected by data transmission and software processing times. *2 Indicated speeds are from using JPEG compression. *3 Indicated speeds are from using TIFF CCITT Group 4 compression.*4 When scanning in high resolutions (500 dpi or above), scanning may be rejected depending on scanning mode, document size, memory size, and application program. Selectable maximum density may vary depending on the length of the scanned document. *5 Limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi).*6 Documents between 431.8 mm (17 in.) and 863 mm (34 in.) in length are limited to 400 dpi. Documents between 863 mm and 3,175 mm (125 in.) in length are limited to 300 dpi. *7 Maximum capacity depends on paper weight and may vary. *8 Numbers are calculated using scanning speeds and typical hours of scanner use, and are not meant to guarantee daily volume or unit durability. *9 With the ADF hopper closed. *10 Requires PaperStream IP 2.2.0 or earlier. *11 Functions equivalent to those offered by PaperStream IP may not be available with the WIA Driver. *12 Software can be downloaded from the website designated in the Setup DVD-ROM.Datasheet FUJITSU Image Scanner fi-79004,000,000 printed characters or 6 months after opening the bagPrint Cartridge CA00050-0262Brake RollerPA03575-K013Every 600,000 sheets or one yearSeparator Roller PA03800-K012 Every 600,000 sheets or one year Pick Roller PA03575-K011 Every 600,000 sheets or one year ConsumablesPA43404-A695 PaperStream Capture Pro optional license PaperStream Capture Pro Scan Station (MV)PA03575-D203 Back-side printing on document Post Imprinter (FI-680PRB) PA03575-D201 Front-side printing on document Post Imprinter (FI-680PRF) OptionsAC cable, USB cable, Setup DVD-ROMMulti image output, Automatic color detection, Blank page detection, Static threshold, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Cropping, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Character extraction, Background pattern removal, Automatic profile selectionPaperStream IP driver (TWAIN/TWAIN x64/ISIS), WIA Driver *¹¹, PaperStream Capture, 2D Barcode forPaperStream *¹², Software Operation Panel, Error Recovery Guide, Scanner Central AdminWindows® 10, Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008*¹⁰Included Items Image Processing FunctionsIncluded Software / Drivers32 kg (70 lb)Supported Operating SystemWeight460 x 430 x 310 mm (18.1 x 16.9 x 12.2 in.)Dimensions *⁹(Width x Depth x Height)ENERGY STAR®, RoHSEnvironmental Compliance 20 to 80% (non-condensing)Relative Humidity5 to 35 °C (41 to 95 °F)Temperature Operating Environment Less than 0.3 WAuto Standby (Off) Mode 3.2 W or less Sleep Mode200 W or less Operating Mode Power Consumption AC 100 to 240 V ± 10%Power Requirements USB 2.0 / USB 1.1InterfaceLag detection Paper Protection Overlap detection (Ultrasonic sensor),Length detection Multifeed Detection 120,000 sheetsExpected Daily Volume *⁸500 sheets (A4 80 g/m² or Letter 20 lb)ADF Capacity *⁷41 to 209 g/m² (11 to 56 lb)20 to 209 g/m² (5.4 to 56 lb)A4 to A5 SizeLess than A5 Size / Over A4 Size Paper Weight (Thickness)5,588 mm (220 in.)Long Page Scanning *₆52 x 74 mm (2 x 3 in.)Minimum304.8 x 431.8 mm (12 x 17 in.)Maximum Document Size White / Black (selectable)Background Colors Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit Output Format 50 to 600 dpi (adjustable by 1 dpi increments)1,200 dpi (driver)*⁵Output Resolution *⁴(Color / Grayscale / Monochrome)600 dpiOptical ResolutionWhite LED Array x 4 (front x 2, back x 2)Light Source Color CCD x 2 (front x 1, back x 1)Image Sensor Type Simplex: 105 ppm (200/300 dpi)Duplex: 210 ipm (200/300 dpi)Scanning Speed *¹ (A4 Portrait)(Color *²/Grayscale *²/Monochrome *³)Simplex: 140 ppm (200/300 dpi)Duplex: 280 ipm (200/300 dpi)Scanning Speed *¹ (A4 Landscape)(Color *²/Grayscale *²/Monochrome *³)ADF (Automatic Document Feeder) / Manual Feed, DuplexScanner TypeTechnical InformationContactIndonesiaPT Fujitsu Indonesia Tel: +62 21 570 9330 *********************.com/id/scannersMalaysiaFujitsu (Malaysia) Sdn Bhd Tel: +603 8230 4188*********************.com/my/scannersPhilippinesFujitsu Philippines, Inc. Tel: +63 2 841 8488 ***************.com/ph/scannersSingaporeFujitsu Asia Pte Ltd Tel: +65 6512 7555******************.com/sg/scannersThailandFujitsu (Thailand) Co., Ltd. Tel: +66 2 302 1500 ***************.com/th/en/scannersVietnamFujitsu Vietnam Limited Tel: + 84 4 2220 3113 ****************.com/vn/en/scanners。
Premium H.264 IP Camera MPV-223 SeriesNoise Reduction3D Image SettingmicroSDHC 32GB support4 Pin Terminal Block4 Pin Terminal Block 1.0 Vp-p / 75 Ω, BNC MechanicalWorking Distanceup to 25 m 850 nm 23 (TBD)-10°C ~ 50°C (14° ~ 122° F)w/ Heater & Fan, Powered by DC 12V: -30°C ~ 50°C (-22° ~ 122° F) /w/ Heater & Fan, Powered by AC 24V: -35°C ~ 50°C (-31° ~ 122° F)DC 12V / AC 24V / PoERJ-45, 10/100 Mbps EthernetIPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS,User and AdministratorHTTPS / IP Filter / IEEE 802.1xPower / Link / ACT 3 Pin Terminal BlockRJ-45H.264- Full HD 1080P / SXGA/ HD 720P / XGA / SVGA / D1 / VGA / CIF MJPEG- Full HD 1080P / SXGA/ HD 720P / XGA / SVGA / D1 / VGA / CIFManual Shutter Speed OperationMultiple LanguagesBacklight Compensation White Balance Wide Dynamic Range Privacy Mask Brightness White Balance H.264 / MJPEGF1.2 (Wide); F2.1 (Tele)Lens LensFocal Length F Number Iris ControlItem CameraImage Sensor Sony Progressive CMOS 1920(H) x 1080(V)Effective Pixels 1 ~ 1/10000 sec.Manual / AWB / ATW 3x Optical Zoom, Auto Focus3.0 ~ 9.0 mmAuto / ManualManual P Iris/DC Iris ColorAuto / On / Off / SmartOn / Off Support On / Off On / Off Manual Auto / Manual Manual Manual Product specification and availibility are subject to change without notice.System: 5 W(Heater: +6 W, Fan: +1 W, Built-in IR Illuminator: +3 W)IP66CE / FCC / RoHSIndoor: ∅ 151 x 130 mm (∅ 5.9 x 5.1 in.)Outdoor: ∅ 170 x 210 mm (∅ 6.7 x 8.3 in.)Indoor: 800 g (1.8 lb)Outdoor: 1300 g ( 2.9 lb)Dimension Power Source Power Consumption 1 SetPhoto Relay Output 300V DC/ACHTTP / FTP / SMTP English / French / German / Italian / Korean / Simplified Chinese /Internet Explore (6.0+) / Chrome / Firefox / SafariOn / Off Line out, Line in G.711 / G.7261 Set5V 10kΩ pull upOn / Off On / Off Dual Streams H.264 + MJPEG / H.264 + H.264Number of LEDs10% ~ 90%, No CondensationSecurityInputOutputAlarmEvent Notification 20User Account Motion Detection Privacy Mask Type Exposure Sharpness Contrast Saturation AudioNetwork InterfaceICR*Tampering Alarm Two-way Audio CompressionHueDigital ZoomVideo Compression Video Streaming Video Resolution Protocol Micro SDSupported Web Browser Wheatherproof Standard Weight Password Levels WavelengthLED IndicatorAlarm Power *Built-in IR Illuminator Ethernet Analog Video AudioConnectorsRegulatoryOperating Temperature GeneralHumidityMPV-223-3X。
200萬寬動態防暴紅外半球美佳威迪欧型号Camera传感器有效像素Color B/W快门速度白平衡Lens镜头手动变焦/ 电动变焦FOV (16:9 resolution)Operation压缩格式H.264MJPEG图像参数亮度曝光锐利度对比度音频音频白平衡饱和度彩度背光补偿数字放大宽动态3D 降噪移动侦测隐私遮挡隐私遮挡模式红外滤光片遮挡报警音频双向语音压缩报警输入输出事件通知多国语言Network界面通讯协议管理权限安全性浏览器用户帐户Mechanical有效距离波长Led 数量端口电源网络Micro SD 声音报警输入/输出模拟输出LED 指示灯General工作温度电源功耗防护等级安规认证Indoor Outdoor Indoor Outdoor0.02 lux 开 / 关手动手动开 / 关MPV-W2 -BSimultaneous H.264 1080p (25/30 fps) + MJPEG D1 (25/30 fps)Simultaneous H.264 1080p (25/30 fps) + H.264 D1 (25/30 fps)Full HD 1080p/SXGA/HD 720p/XGA/SVGA/D1/VGA/CIF Full HD 1080p/SXGA/HD 720p/XGA/SVGA/D1/VGA/CIF1/2.7" Progressive Scan CMOSH.264/MJPEG1920(H) x 1080(V)1~ 1/10000 sec.RJ-45HTTPS, IP Filter, IEEE 802.1X5V 10kΩ pull up24Line out, Line in/mic inHTTP, FTP, SMTPPhoto Relay Output 300VDC/AC3 pins terminal block重量0.8 kg (1.8 lbs)1.3 kg( 2.9 lbs)CE, FCC, RoHS Compliant 尺寸IP66 170 x 210 mm (∅6.7 x 8.3 inches)151 x 130 mm (∅5.9 x 5.1 inches)DC12V/AC24V/PoE分辨率850nm 20红外Led 灯10/100Mbps Ethernet (RJ-45)User and Administrator 自动 / 手动up to 25m 开 / 关开 / 关 -10°C ~ 50°C (14° ~ 122° F)选购增热片与风扇机种并搭配 DC12V/AC24V: -35°C ~ 50°C (-31° ~ 122° F)1.0 Vp-p / 75 Ω, BNC 最低照度0.2 luxPower, Link, ACT103.5ﾟ(W) ~ 34.3ﾟ(T)F1.2 / f = 3-9 mm English, French, German, Italian, Korean, Simplified Chinese, Russian自动/开/关/智能Manual / AWB / ATW Color手动开 / 关自动 / 手动支持手动开 / 关* mark for optional items视频串流G.711/G.726Internet Explorer (6.0+), Chrome, Firefox, SafariIPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP,SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIFmicroSDHC 32GB support 4 pins terminal block 4 pins terminal block System: 5W(Heater: +6W, Fan: +1W, Built-in IR Illuminator: +3W, Motorized Lens: +3.6W)。
SD9384-EHLSpeed Dome Network Camera5MP • H.265 • 30x Optical Zoom • WDR Pro • Smart Stream III • SNV30 fps @ 2560x192030x Optical Zoom, Auto Focus360° Continuous Pan, -20° to 90° (auto flip) Tilt200M IR with Smart IRWeather-proof IP66-rated, Vandal-proof IK10 and NEMA 4X-rated Housing-40°C ~ 60°C W ide Temperature Range for Extreme Weather ConditionsEIS (Electronic Image Stabilization) for Image StabilityTrend Micro IoT SecuritySmart Tracking Advanced for Moving People with People-based Deep Learning TechnologyTechnical SpecificationsSystem InformationModel SD9384-EHLCPU Multimedia SoC (Sy stem-on-Chip) Flash8 GBRAM 2 GBCamera FeaturesImage Sensor1/2.8" Progressiv e CMOSMax. Resolution2560x1920 (5MP)Lens Ty pe30x Optical Zoom, Auto Focus Focal Length f = 4.94 ~ 148.24 mmAperture F1.3 ~ F4.6Iris Ty pe DC-irisField of View 54.1° ~ 1.9° (Horizontal) 41.2° ~ 1.4° (Vertical) 65.7° ~2.4° (Diagonal)Shutter Time 1 sec. to 1/100,000 sec.WDR T echnology WDR ProDay/Night YesRemov able IR-cut Filter YesIR Illuminators Built-in IR Illuminators up to 200 meters with Smart IR, IR LED*8Minimum Illumination ************(Color)*************(B/W)0 lux with IR illumination onPan Speed Preset speed: 450°/s Pan Range360° endlessTilt Speed Preset speed: 450°/s Tilt Range-20° to 90° (auto f lip) Preset Locations256 preset locationsPan/Tilt/Zoom Functionalities 32x digital zoom (4x on IE plug-in, 8x built in) Auto Pan modeAuto Patrol modeMechanical Auto f lipStorage Seamless Recording to MicroSD/SDHC/SDXC card and recording to network-attachedstorage (NAS)Built-in Installation Aids Remote f ocus, remote zoomVideoVideo Compression H.265, H.264, MJPEGMaximum Frame Rate 30 f ps @ 2560x1920 30 f ps @ 2560x1440 60 f ps @ 1920x1080Maximum Streams 3 v ideo streams (Up to 8 conf igurable prof iles)S/N Ratio74 dBDy namic Range120 dBVideo Streaming Adjustable resolution, quality and constant bitrate control, Smart Stream IIIImage Settings General settings: v ideo title and time stamp ov erlay, v ideo orientation (f lip, mirror),day/night settings; Illuminators: illuminators, anti-ov erexposure; Image settings: white balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curv e), def og, HLM, 3DNR, EIS, scene mode (auto, deblur); Exposure: BLC, HLC, exposure control (exposure lev el, iris adjustment, exposure time, gain control, iris mode), AE speed adjustment, WDR; Focus; Priv acy mask; Scheduled prof ile settings; Pixel calculatorAudioAudio Capability Two-way audio (Full duplex) Audio Compression G.711, G.726Audio Interf ace External line inputExternal line outputNetworkUsers Liv e v iewing f or up to 10 clientsSecurity Access list, digest authentication, HTTPS , IEEE 802.1x, password protection, secure boot, signed f irmware, Trend Micro IoT Security (brute f orce attack ev ent, cy berattack ev ent, quarantine ev ent), user access log, user account managementProtocols 802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnPInterf ace Capable of connecting 10 Base-T/100 Base-TX/1000 Base TX(RJ-45) Ethernet cable*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.ONVIF Prof ile G, S, T supported, specif ication av ailable at www.onv AI AnalyticsCompute Capability Built-in CNN acceleration moduleVision Object Analy tics Object Detection: people, v ehicle (4-wheeled, 2-wheeled); Attribute Extraction: people (gender, color, bag, hat), v ehicle (bike, bus, car, motorcy cle, truck, color); Re-Search Extraction; Path ExtractionEv ent Application Smart Tracking Adv anced (intrusion, loitering, line crossing, f ace detection) Applications Deep learning VCA (Smart tracking adv anced)Solution IntegrationVADP Package Stratocast, Trend Micro IoT Security (3-y ear f ree trial)Alarm and EventEv ent Trigger Audio detection, camera tampering detection, cy bersecurity ev ents (brute f orce attackev ent, cy berattack ev ent, quarantine ev ent), digital input, manual trigger, motion detection, periodical trigger, recording notif ication, SD card lif e expectancy, smart tracking adv anced trigger, sy stem boot, preset reachedEv ent Action Ev ent notif ication v ia audio clip, camera link, digital output, email, HTTP, FTP, NAS serv er, SD cardFile upload v ia email, HTTP, FTP, NAS serv er, SD card; trigger track, trigger patrol, mov e to presetGeneralConnectors RJ-45 cable connector f or 10/100 Mbps PoE network connection Audio line inputAudio line outputDC 48V power inputAC 24V power inputDigital input*2Digital output*1LED Indicator Sy stem power and status indicatorPower Input AC 24V, DC 48V, IEEE 802.3 bt Class 6 PoE(Simultaneous Power Redundancy Supported)Power Consumption PoE:Max. 51W/26W (IR on/of f) DC 48V:Max. 51W/26W (IR on/of f) AC 24V:Max. 51W/26W (IR on/of f)Dimensions256 x 336 mm Weight7.1 kgCertif ications EMC: CE (EN 55032 Class A, EN55035, EN50121-4), UKCA (BS EN 55032: 2015 +A11: 2020, BS EN 55035: 2017), FCC (FCC Part 15 Subpart B Class A), IC (ICES-003:2020 Issue7, Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A); Saf ety: UKCA (BS EN 62368-1:2014+A11:2017), UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471); Env ironment: IK10 (IEC 62262), IP66 (IEC 60529), NEMA (NEMA 250 Ty pe 4X); IA: BIS (IS 13252), BSMIOperating T emperature Starting T emperature:-40°C ~ 55°C (-40°F ~ 131°F) Working T emperature:-40°C ~ 60°C (-40°F ~ 140°F) (IR on)Humidity98% RH (non-condensing) Warranty36 monthsSystem RequirementsOperating Sy stem Microsof t Windows 10/8/7Mac 10.12 (Chrome only)Web Browser Chrome 58.0 or abov eInternet Explorer 10/11Other Play ers VLC: 1.1.11 or abov eIncluded AccessoriesPacking Contents Wall mount bracket, Quick installation guide, alignment sticker, screw pack, desiccant bag,waterproof accessory bag, conduit ring, terminal blockDORI (EN 62676-4 Standard)Detect (25PPM/ 8PPF)Wide: 104.1 m (341.5 f t)T ele: 2969.8 m (9743.4 f t)Observ e (63PPM/ 19PPF)Wide: 41.3 m (135.5 f t)T ele: 1178.5 m (3866.4 f t)Recognize (125PPM/ 38PPF)Wide: 20.8 m (68.2 f t)T ele: 594 m (1948.6 f t)Identif y (250PPM/ 76PPF)Wide: 10.4 m (34.1 f t)T ele: 297 m (974.3 f t)DimensionsAW-IHH-0410Industrial 2xGE 95W PoH/PoE + 2xGE SFP Switch AA-352Power Box, IP67, IK10IO Cable AO-008Combo cable f or speed domeWater Proof ConnectorAN4000Cable Gland f or IO, 8 pins, Φ1.1~1.6mmAll s pecifications are s ubject to change without notice. Copyright© VIVOTEK INC. All rights res erved. Ver. 46F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. | T: +886-2-82455282 | F: +886-2-82455532 | E: s ales @vivotek .com | W : www.vivotek .comMounting KitAM-220Wall Mount Bracket Mounting KitAM-529Mounting Adapter f or Speed DomePower Adaptor HLG-80H-4880W Single Output Switching Power Supply - 48V Power AdaptorNDR-75-4875W Single Output Industrial DIN RAIL - 48VPoE Kit AP-GIC-011A-060Indoor 1xGE 60W High Power UPoE Injector PoE KitAP-GIC-015B-095Outdoor 1xGE 95W PoH/PoE Injector with AdaptorPoE Kit AW-GEH-043A-1202xGE 95W PoH/PoE + 2xGE SFP Switch PoE KitAW-IHH-0110Industrial 1xGE 95W PoH/PoE InjectorPoE Kit Power AdaptorCompatible Accessories。
IP camera TesterIPC-8600 Series （VII Generation ）7 inch capacitive touch screen / ONVIF /SDI camera/Analog camera/ CVI camera /TVI camera/AHD /SDI camera test / WIFI /12V 2APower output / 5V 2A power bank / DC48V PoE power supply /HDMI output/Video level meter/ IP camera viewer /PTZ control /Ping test/Link test/Cable tracer /IP discovery, Auto -search the whole network segment IP / Rapid ONVIF, Auto-login and display the camera image, activate Hikvision camera quickly. Support more than 80 IP camera brands test (Hikvision, Dahua, Honeywell, Samsung etc)7 inch Touch Screen IP camera tester is for maintenance and installation of IP camera and Analogue camera ,display HD camera and analogue camera image ,PTZ control, easy to use and operate . Built in network testing tools (IP address search, PING etc), quickly check the IP camera problem. Cable scan, TDR tester, easy to check the network cable, BNC cable problem, Optical power meter, Visual fault detector function, effective to solve the optical fiber transmission problem.New IP camera tester normal working time lasts 16 hours, built in WIFI ，as well as test Wireless IP ,Analog and SDI camera ,12V 2A power output for camera ,DC48V PoE power supply,5V 2A power output(as a power bank 13000mAh),HDMI output, Audio input and output, Network bandwidth testing, OSD menu rotates in 180 angle ，OSD menu can be rotated in 180 angle by manual setting. This function is very convenient for the user to upward the downside to connect the LAN cable and do the testing.CCTV system installation and maintenanceNetwork cabling project installation and maintenanceDome camera IP camera testingVideo transmission channel testingPTZ controller1. 7 inch touch screen ，1024*600 resolution NEW2.Capacitive touch screen ,OSD menu, 3.Touch screen and key operation 4.Built-in WIFI, wireless network camera test NEW 5.AHD/CVI/TVI camera test . snapshot ,video record and playback ,zoom, NEW （*Optional ） 6. IP discovery, do not need to k now the first two digits of camera’s IP address , it can auto -scan the whole network segment IP , and auto-modify tester’s IPaddress7.Rapid ONVIF, search camera quickly, auto log in and display image from the camera, activate Hikvision camera. 8.Support 1080P camera 9. SDI camera test （*Optional ）SDI digital video surveillance testing, SDI input, support resolution as follows:1280x720P 25Hz/1280x720P 30Hz/1280x720P 50Hz/1280x720P 60Hz/1920x1080P 25Hz/1920x1080P 60H z/1920x1080I 50Hz/1920x1080I 60Hz10.Digital camera image test and video image zoom, record, screen snapshot, Photo viewer and playback 11.Currently, Support ONVIF, combine with more than 80 brand camera ,such as DAHUA,Haikang,KEDA,Samsung,HIKVISION and TIANDY camera. 12. If IP camera manufacturers can offer Video Management Software that compatible with mobile phone or tablet PC, install the Video Management Softwarein the tester enable the tester to display IP camera image by IP camera viewer.Features Application13. OSD menu rotates in 180 angle NEW14. Display real resolution of the IP camera images15. Video screen snapshot ,video recording ,files named and save, easy to find16. Support network PTZ controller (ONVIF)17. Support 1080P HD video files and MKV/MP4 media files play18. PTZ controller ,Photograph, Video record, Record playback19. Video level meter, Video PEAK lever, SYNC level, COLOR BURST measurement NEW20. Optical Power Meter, it can measure the optical power value and fiber loss *(Optional)21. Visual fault locator , to test fiber’s bending and breakage * (Optional)22. TDR cable test, test cable length and short-circuit * (Optional)23. Digital Multi-meter, Voltage, current, resistance and capacitance measuring, continuity testing, diode testing. (Optional)24. Color bar generator, analog video color bar and testing image output NEW25. POE voltage measurement, PING test ,IP address scan, port flashing etc26. PoE DC48V power output，Max power 24W NEW27. 12V /2A power output NEW28. 5V 2A power output，as the power bank NEW29. HDMI output, 1920*1080P Resolution NEW30. Audio in /out31. LED lamp, calculators, music players and other application tools32. Support customers self update software33. Lithium Ion Polymer Battery, working time lasts 16 hours“*”Sign means the function optionalModel IPC-8600【*】models optionalDisplay 7 inch Capacitive touch screen , resolution 1024（RGB）x 600Network port 10/100M auto adapt,RJ45SDI camera test(Optional) *1 channel SDI IN BNC Input ,Support resolution 720p 60fps / 1080p 60fps /1080i 60fpsTVI camera test*(Optional) *Support resolution 720p 25fps,30fps,50fps,60fps / 1080P 25fps,30fps , camera OSD menu control over coaxial cable CVI camera test(Optional) *Support resolution 720p 25fps,30fps,50fps,60fps / 1080P 25fps,30fps , camera OSD menu control over coaxial cableAHD camera test* (Optional) * Support AHD2.0, Support resolution 1080P 25fps,30fps /720p 25fps,30fps , camera OSD menu control over coaxial cableWIFI Built in WIFI，speeds150M，display wireless camera imageIP camera type ONVIF，ACTi、Dahua IPC-HFW2100P、Hikvision,DS-2CD864-E13、Samsung SNZ-5200、Tiandy TD-NC9200S2、Kodak IPC120L、Honeywell HICC-2300T、Aipu-waton IP5000-BC-13MP/IRS06-13MP、fine-Tida IPC、FSJ BY-1080Q、WEISKY IPC camera etc. Customized welcomeVideo input/output 1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt) Video Level Test: Video signals measured in IRE or mVVideo level meter PEAK video signal level, SYNC signal level, Color bar chroma level measurement Zoom Image Support Analog camera and IP camera image zoom /move Specificatio nsSnapshot,Video record andplaybackImage Screen snapshot, record ,save ,view and record and play backHDMI output 1 channel HDMI output，support 1920*1080P12V/2ApoweroutputOutput DC12V/2A power for camera5V power output 5V 2A power output，as a Power bankPoE power output 48V PoE power output，Max power 24WAudio test 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphonePTZ controlSupport RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P,Samsung, Panasonic, Lilin, Yaan, etccolor bar generatorOutput one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and blackcolor )UTP Cable tester Test UTP cable connection status and display on the screen. Read the number on the screenData monitor Captures and analyzes the command data from controlling device，also can send hexadecimalNetwork test IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP addressCable scan Search the cable by the audio signalPoE test Measurement POE switch or PSE power supply voltage and cable connection statusDigital Multi-meter (optional)* AC/DC Voltage，AC/DC current、Resistance、Capacitance、Data hold、Relative measurement、Continuity testing . Testing speed: 3 times/ seconds，Data range -6600～+6600.Optical power meter (Optional)* Calibrated Wavelength(nm) ：850/1300/1310/1490/1550/1625nm Power range(dBm) ：-70～+10dBmVisual fault locator(optional)*Test fiber’s bending and breakage ( SM and MM fiber)TDR cable test(optional) *Cable length and short circuit measurement(BNC cable, Coaxial cable, Cat5/6, telephone cable) POWERExternal powersupplyDC 12V 2ABattery Built-in 7.4V Lithium polymer battery ,6500mAhRechargeable After charging 7~8 hours, normal working time 16 hoursParameterOperation setting Capacitive touch screen, OSD menu，Chinese/EnglishAuto off 1-30 (mins)GeneralWorkingTemperature-10℃---+50℃Working Humidity 30%-90%Dimension/Weight 231mm x 172mm x 52mm / 1.26Kg。
