Automatic fire alarm system based on MCU Abstract: The paper introduced an automatic warehouse fire a1arm system based on MCU. The system was mainly made up of ATmega16, temperature sensors, smoke sensors, and EX-1 auto dialed alarm module. In the system, temperature signals were transformed to serial data, and smoke signals were transformed to voltage signals. All the data were processed by MCU. When the surveillance system checked fire in warehouse, alarm signal was turn on, meanwhile the messages were transmitted to managers through EX-1. Application of the system was convenient to deal with fire in-time, efficiently by warehouse manager.

Keywords: fire alarm transducer;smoke sensor system;ATmega16;temperature transducer;smoke sensor

I. INTRODUCTION

Automatic fire alarm control system has experienced a process from the simple to the complex and intelligence system increasingly in China. The characteristic is automatic fire detection and alarm technology has a great progress along with computing and detection technology development. At present, automatic fire alarm control system was used in bulk storage plant, shopping malls, high-level office buildings, hotels and other places. They were used in a number of collections focused on one area of intelligent alarm control method with higher levels of bus-type alarm control system, and in some residential areas and commercial buildings were installed by a single automatic fire alarm detection device. These alarm detection devices fail to report sometimes, or misinformation. Its reliability is not high because of using single sensor. Therefore, it is needed to develop a simple structure, low cost, high reliability, fast responding, automatic fire detection system.

II. GENERAL PROJECT OF THE SYSTEM

The hardware block diagram shown in Figure 1, hardware by temperature sensors, smoke sensors, signal processing module, MCU modules and automatic alarm module. Non electrical quantity that is through the sensing element sensors (smoke sensors and temperature sensors) will be on-site temperature, smoke and other non-electrical signal into an electrical signal, as well as signals for signal processing to convert

analog quantity to digital quantity. Finally, the sampled data were processed and compared with the limits by MCU system. This system can produce local and remote auto-alarm signals.

Temperature Ionization

Transducer smoke detector

signal

processing

PD0 PD1

SCM

auto alarm

module

T ephoneel

Inter f ace

…

Figure 1. Automatic fire alarm system structure

Ⅲ. THE HARDWARE COMPONENTS

A. Atmega16

The system used by the U.S. Atmel’s microcontroller ATmega16 microcontroller. ATmega16 is based on the AVR RISC architecture to enhance low-power 8-bit CMOS microcontroller. Because of its advanced instruction set and a single clock cycle instruction execution time, ATmega16 data throughput of up to 1 MIPS / MHz. Thereby mitigate the system in the power and the contradiction between the processing rate. ATmega16 has the following characteristics: 16K bytes in-system programmable Flash (with the ability to read and write at the same time, that is, RWW), 512 bytes EEPROM, 1K bytes SRAM, 32 general-purpose I / O port lines, 32 general-purpose working registers, for the JTAG boundary scan interface, support the on-chip debugging and programming, 3 has a more flexible mode of timer / counter (T / C), chip internal / external interrupts, programmable serial USART, there are initial conditions detector universal serial interface, 8-channel 10-bit with optional
