佳能20系列固件升级图文说明
现对佳能20系列机器升级固件进行图文说明,首先把在电脑上安装20系列机器驱动,装好后请用USB打印线把机器及电脑进行连接,测试下是否连接成功。
成功后请在机器面板上按设置/注册按键(见下图)
然后选择到系统管理设置(见下图)
按OK键,出现系统管理员ID及密码窗口,输入ID及密码(如图)
出现上面窗口后请按登陆/注销键
这样就会进系统管理设置界面,再找到更新固件一栏,如下图
按OK键,提示以下内容:
再按OK键,提示以下屏幕
好,到这个屏为止,机器面板上操作全完成了,再让我们到电脑上解压升级包(固件升包请到群共享文件中下载),双击打开,直到出现下图
全点下一步,在升级期间,切记不要断开USB数据线及机器电源,还有机器上面板任一键不要按,也就是说机器上按键不要按,一按就会升级失败!
上图是电脑屏幕上显示的过程,下图就是升级成功屏显。
当电脑屏显以上字样时,机器上就会出现
这样的字样,恭喜你升级成功了。
这样请把机器重新关机,再开就全部完成了!
注:以上为池州佳联版权,只限群内共享,请勿外传。
