常用机械加工术语中英对比CNC加工流程process flow of CNC车壳来胚→雕格仔纹→3.9H巴孔→耳仔配壳位→铣按的位→粗钻按的孔→胶内罩位Blank after turning → Milling the plaid → Drilling the 3.9H cown hole → Milling the lug to fit the end piece → Milling the pusher position→ Rough drilling the pusher hol e→ movement holder position车壳来胚→壳钻面钉吼→壳钻按的孔→壳钻巴孔→精钻巴孔→圈拔避按的位→注塑出货Case blank after turning → drilling dial hole in the case → drilling pusher hole in the case → drilling crown hole in the case → fine drilling the crown hole → milling the pusher recess of basel ring → injection车壳来胚→壳雕底平→壳雕配胶位→圈锣钻石纹→镶件锣钻石纹→胶罩配壳位→雕胶罩面字印Case blank after turning → milling the case bottom → milling the position of fitting the plastic → milling the diamond texture of the ring→ milling the diamond texture of the inlay piece →milling the notch position for movement holder → milling the marking of movement holder大啤来货→壳锣底平→底件配壳位→壳底件碰焊→胶罩配壳位→胶罩锣外形→胶罩铣面Blank after stamping → milling the case bottom → milling the position of the bottom part fitting the case → soldering the case back →milling the notch for movement holder → milling the shape of the plastic holder → milling the surface of the plastic holder大啤来胚→壳锣底平→壳避位胶罩位→胶罩粗中孔→胶罩锣外形→铣胶罩配壳位→铣胶罩四角避位Blank after stamping → mi lling the case bottom → milling the notch for movement holder → drilling the middle hole of the plastic holder →milling the shape of the plastic holder → milling the plastic holder to fit the case → milling the four corner clearance of the plastic holder钻壳工艺流程Process Flow of Drilling Case大啤来货→烧焊→粗钻(2H、3H、4H)→钻耳孔→烧壳身件(分离)→钻牙孔→攻牙打批锋Q货→出货Blank after stamping →soldering → rough drilling (2H、3H、4H) →drilling lug hole → soldering case body piece → drilling screw thread hole → tapping thread , removing burrs , inspection → deliver to assembly车壳来货→粗钻(2H、3H、4H)→拔位/钻准(2H、3H、4H)→钻耳孔→钻牙孔/攻牙→锣12H米位→打批锋、Q货→出货Case blank after turning →rough drilling (2H、3H、4H) → crown recess /drilling (2H、3H、4H) → drill ing lug hole → drilling screw thread hole/tapping thread → milling notch at 12H → removing burrs, inspection → deliver to assembly大啤来货→ Q胚确认→粗钻3H→粗磨打油→烧焊过炉→拔位/ 3H→钻耳孔配带→打批锋、Q货→出货Blank after stamping→Checking blank →rough drilling (3H) →rough polishing →soldering bracelet →crown recess(3H) → drilling lug hole for matching bracelet → removing burrs, inspection →deliver to assembly大啤来货→粗钻(2H、3H、4H、)→粗钻(8H、 9H、 10H)→钻耳孔→钻牙孔→精钻(2H、 3H、 4H 、8H、 9H、 10H)→攻牙→打批锋、Q货→出货Blank after stamping →rough drilling (2H、3H、4H) →rough drilling (8H、 9H、 10H)→dril ling lug hole → drilling screw thread hole →fine drilling(2H、 3H、 4H 、8H、 9H、 10H)→tapping thread →removing burrs, inspection → deliver to assemblyCNC来货→精钻3H→钻耳孔配带→锣腰线→钻石位Blank after CNC →fine drilling stem hole(3H)→drilling lug hole for fitting bracelet →milling the case side→drilling holes for stones车壳来货→粗钻(2H 3H 4H)→拔位/钻准(2H 3H 4H)→钻耳孔配带→钻耳面钢压钉孔→打批锋Q出货→出货Case blank after turning →rough drilling (2H、 3H、 4H)→crown recess /drilling (2H、3H、4H) →drilling lug hole for fitting bracelet →drilling lug face, hole for decoration pin →removing burrs, inspection →deliver to assembly车壳工序流程Process flow of turning the case来胚→粗丝吼→粗面子口、外元面平→精车丝孔→精车面胶圈坑面平外圆→烧壳耳罩→精车牙位、胶圈坑、底平→精车面子口→车牙case blank → rough turning case inside dimension → turning the dial opening ,turning the top surface → fine turning case inside dimension → fine turning top surface outside circumference → soldering the case lug → fine turning thread area, o-ring groove, turning bottom surface →fine turning dial opening → turning thread来胚→开粗丝孔→开粗中孔→精车丝孔、胶圈坑、牙位、藏底位→开粗底圈→精车底圈→车牙→精车玻璃位面坑弹分线坑平台位case blank→ rough turning case inside dimension → rough turning the dial opening → fine turning case inside dimension, o-ring groove, thread area, hidden back area → rough turning bottom surface → fine turning bottom surface → turning thread → fine turning crystal seat, turning groove for top ring.来胚→开粗丝孔→开粗中孔→精车丝孔、胶圈坑、藏底位、牙位、底平开粗藏圈位→精车面子口、胶圈位→精车藏圈位、面平位→车牙case blank→rough turning case inside dimension →rough turning the dial opening →fine turning case inside dimension, o-ring groove, hidden back area, thread area, rough turning the bottom surface → fine turning dial opening , o-ring area → fine turning hidden ring area, turning the top surface → turning thread来胚→开粗底子口、底平→开粗中孔→精车藏底位、子口、底平→开粗配壳位→开粗藏圈→精车配壳位→精车藏圈位倒角位case blank → rough turning caseback opening, bottom surface →rough turning dial opening → fine turning surface for hiding caseback ,bottom surface → turning position for fitting case → turning hidden ring position → fine turning position for fitting case → fine turning hidden ring area, chamfer area来胚→开粗丝孔、中孔→精车丝孔、胶圈坑、藏底位→开粗耳底→精车耳底、牙位→开粗面坑→精车玻璃位、面子口、面坑、平台→车牙case blank → rough turning case inside dimension and dial opening →fine turning case inside dimension, o-ring groove, hidden back area →rough turning case lug back→ fine turning case lug back, thread area →rough turning dial groove → fine turning crystal seat, dial opening , platform → turning thread来胚→开粗丝孔、中孔→精车丝孔、胶圈坑、牙位、藏底位、底平开粗耳底→精车耳底→精车耳面→车牙→精车玻璃、面坑、弹弓线坑case blank→ rough turning case inside dimension and dial opening →fine turning case inside dimension, o-ring groove, thread area , hidden back area, rough turning the bottom surface → fine turning case lug back→ fine turning surface of case lug → turning thread → fine turning crystal seat, turning groove for top ring.来胚→开粗孔、底平→开粗中孔→精车丝孔→开粗配圈位、精车底子口、胶圈坑、藏底位→精车面子口→精车藏圈位、胶圈位→勾坑case blank→rough turning case inside dimension,bottom surface→rough turning dial opening → fine turning case inside dimension→turning area for fitting the ring, fine turning caseback opening, o-ring groove, hidden back area → fine turning dial opening →fine turning hidden ring area, 0-ring area→ dig grooveCNC工艺流程process flow of CNCInlay来胚→开粗→精雕→雕生耳槽→试配Blank → Cutting material → Fine milling → milling the groove ofSpring bar →assembling checkingBangle来胚→碰焊→锣配壳斜位→锣配带粒→冲孔→试装配带粒Blank → sport we lding → Milling beveled area of case → Milling area for bracelet → Punching → assembling checkingBangle来胚→锣水口→钻孔→锣配壳R位→雕生耳槽→试配胶镶件Blank → Milling the burrs → Drilling → Milling radius area of case → milling t he groove of Spring bar → assembling checking with plastic inlayBangle来胚→锣水口→锣配壳R位→雕生耳槽→试装配壳效果Blank → Milling the burrs → Milling radius area of case → milling the groove of Spring bar →assembling checking with the caseBangle来胚锣水口→锣配壳位→锣制位→雕生身槽→试装配Blank →Milling the burrs → Milling area for case fitting →Milling area for pusher → milling the groove of Spring bar → assembling checking锣雕工艺流程Process flow for Millingprocess flow of bangle上下厄焊件磨光电解→碰焊（厄条焊件焊接）→整形、粗磨→钻石位孔→6H、12H厄条配壳焊接→上下厄条雕较位、锣撬刀位→钻床（钻较位扣位孔）→制扣碰焊钻孔磨光→配套入磨光精磨出货Top bangle and bottom bangle welding, electrolysis polishing → sport welding(we lding bangle) → refinding,rough polishing → Drilling hole for stones → Welding case and bangle at 6H/12H together → refinding hinge and milling notch position for case back opening → Drillpress(drilling hinge and buck le hole) → Welding,drill ing and polishing buckle → Fine polishing and pass to assembling Departmentprocess flow of bangle下厄来胚→粗磨→锣较位R→钻孔→上厄A、B来胚→粗磨→钻石位孔→钻壳孔、攻牙→碰焊过炉→配套出货Bottom bangle blank → Rough polishing → Milling rad ius area for hinge → Drilling → A and B top bangle blank→ Rou gh polishing → Drilling hole for stones → Drilling stem and tapping thread → sport welding and pass through the furnace → pass to assembling DepartmentDT樣辦DT sample裝配工序流程Assembling process flow打巴管Assembling the crown tube打按的Assembling the pusher打玻璃試水Assembling crystal and water resistant test打圈口Assembling the top-ring粘鋁圈glue the aluminium top-ring裝帶QC出貨Assembling bracelet ,QC and send to assembly 裝內影圈Assembling the concave ring裝帶制Assembling bracelet with buckle厄條裝制Assembling bangle with buckle厄條裝膠Assembling plastic into the bangle殼裝厄條Assembling case with bangle。
