Involvementof C-type inactivationgating in the actions of voltage-gated K +channel inhibitorsYuk-Man Leung ⁎Graduate Institute of Neural and Cognitive Sciences,College of Life Sciences,China Medical University,91Hsueh Shih Road,Taichung 40402,Taiwan,ROCa b s t r a c ta r t i c l e i n f o Keywords:Voltage-gated K +channels BlockersC-type inactivation GatingVoltage-gated K +(Kv)channels serve multiple functions.Besides the most well known function of control-ling membrane excitability,they may also play roles in cell death and differentiation.Pharmacological activa-tors and inhibitors of Kv channels therefore offer potential therapeutic treatments for a variety of diseases.of Kv channels by classical blockers such as tetraethylammonium and 4-aminopyridine,and peptides such as scorpion toxins,are believed to result from a direct intervention or occlusion of the permeation pathway.During prolonged depolarization,most Kv channels undergo a process called slow or C-type inactivation,by which the selectivity filter destabilizes and thus limits K +flux.Increasing amount of evidence shows that there are certain compounds which inhibit Kv currents not by directly obstructing the K +conduction pathway,but by accelerating or intensifying selectivity filter destabilization once the channels open.This mode of block represents an alternative mechanism of Kv channel inhibition.Indeed,some of the classical Kv channel blockers are to some extent,or in certain circumstances,involved in hastening slow inactivation.This review begins with a brief description of structure –functions of Kv chan-nels,and then discusses the multiple mechanisms of Kv channel inhibition by classical blockers and how cer-tain compounds inhibit Kv channels by accelerating C-type inactivation.The pharmacological and therapeutic potentials of these C-type inactivation-dependent Kv channel inhibitors are discussed.©2011Elsevier Inc.All rights reserved.Contents1.Introduction .............................................1512.Voltage-gated K +channel gating and C-type inactivation........................1523.Classical blockers of voltage-gated K +channels:extracellular block ....................1534.Classical blockers of voltage-gated K +channels:intracellular block pounds whose block is dependent on C-type inactivation gating ....................1546.Pharmacological and therapeutic potentials of C-type inactivation-dependent voltage-gated K +channel inhibitors .1567.Conclusion and perspectives .......................................157Acknowledgment ..............................................157References .................................................1571.IntroductionK +channels are integral membrane proteins which provide selec-tive conduction pathways for K +flux along the electrochemical gra-dient.Their general role is to stabilize the cell membraneelectrically.Voltage-gated K +(Kv)channels open upon depolariza-tion and the K +ef flux accounts for the repolarization phase of an ac-tion potential or acts by reducing the neuronal spiking frequency (Hille,2001).Blocking Kv channels pharmacologically prolongs the duration of an action ck of expression,mutation or re-duced activities (loss-of-functions)of certain Kv channel members may lead to neuronal hyperexcitability in rodents or humans,mani-fested as neurological disorders such as ataxia and epilepsy (Browne et al.,1994;Bernard et al.,2004;Maljevic et al.,2008;Miceli et al.,2008).Besides their most well known function in dampening cellular ex-citability,convincing evidence supports the involvement of KvPharmacology &Therapeutics 133(2012)151–158Abbreviations:4-AP,4-aminopyridine;AHR,6β-acetoxy-7α-hydroxyroyleanone;AVE0118,(2′-{[2-(4-methoxy-phenyl)-acetylamino]-methyl}-biphenyl-2-carboxylic acid (2-pyridin-3-yl-ethyl)-amide);KN-93,2-[N-(2-hydroxyethyl)]-N-(4methoxyben-zenesulfonyl)amino-N-(4-chlorocinnamyl)-N-methylbenzylamine;Kv channels,voltage-gated K +channels;QA,quaternary ammoniums;TEA,tetraethylammonium.⁎Tel.:+886422053366x2185;fax:+886422076853.E-mail address:ymleung@.tw .0163-7258/$–see front matter ©2011Elsevier Inc.All rights reserved.doi:10.1016/j.pharmthera.2011.10.005Contents lists available at SciVerse ScienceDirectPharmacology &Therapeuticsj o u r n a l h o m e p a ge :w ww.e l s e v i e r.c o m/l o c a t e /p ha rm t h e r achannels in cell death and differentiation of a wide variety of cells.For instance,there is an overexpression of Kv channels during apoptosis of neurons,immune cells and muscle cells(Yu et al.,1997;Yu, 2003).The massive K+efflux through over-expressed Kv channels leads to loss of intracellular K+and the reduced[K+]i results in relief of inhibition(thus activation)of pro-apoptotic caspases and nucle-ases(Hughes et al.,1997;Hughes &Cidlowski,1999).Kv channels have also been implicated in the axon development in Xenopus retinal cells,as pharmacological inhibition of Kv channels suppresses axon extension and produces a prominent effect on guidance cues (McFarlane&Pollock,2000;Pollock et al.,2005).More recently,it was found that K+efflux through Kv1.1,Kv1.4and Kv2.1was respon-sible for cAMP-stimulated neuritogenesis in mouse neuroblastoma N2A cells(Leung et al.,2011).All these evidence suggests that Kv channels are versatile molecules which have a variety of functions in addition to provision of K+efflux for repolarization.Specific Kv channel blockers are useful tools for probing the func-tional roles of Kv channels.On the other hand,Kv channel blockers may offer therapeutic opportunities by their ability to enhance cellu-lar excitability.Augmenting conductivity of demyelinated axons via inhibition of Kv channels by4-aminopyridine(4-AP)is a potential therapeutic treatment of multiple sclerosis(Judge&Bever,2006). Kv channel blockers such as4-AP and tetraethylammonium(TEA) could be employed to prevent neuronal apoptosis by suppressing ex-cessive K+efflux(Yu et al.,1997;Yu,2003;Hu et al.,2006).The po-tential of using Kv channel blockers for neuroprotection is discussed in a recent review(Leung,2010).The block of Kv channels by classical blockers(TEA and4-AP)is fast,and it is believed that these molecules directly interfere with the K+conduction pathway or even plug the channel pore.A process by which Kv channels limit K+efflux during continuous depolariza-tion is destabilization or distortion of the selectivityfilter(Hoshi et al.,1991;see Kurata&Fedida,2006for an excellent review).This has been coined slow inactivation or C-type inactivation(see next section).Increasing amount of evidence has shown that there are some compounds which do not appear to act by directly obstructing the pore;instead,they inhibit the channel by hastening or intensify-ing the destabilization of the selectivityfilter.This review begins by describing the fundamental structure-function aspects of Kv channel gatings and then recapitulates some basic understanding of the ac-tions of classical Kv channel blockers(especially TEA).The observa-tions that some classical blockers,to certain extent or under special circumstances,are involved in promoting Kv channel slow inactiva-tion are explained.The mode of actions of C-type inactivation-dependent blockers,as exemplified by several recently reported drugs,will be elaborated.Finally,the pharmacological and potential therapeutic values of C-type inactivation-dependent blockers are discussed.2.Voltage-gated K+channel gating and C-type inactivation2.1.Voltage-gated K+channel gatingBased on sequence homology,Kv channels are classified into Kv1 to Kv12subfamilies;each Kv subfamily contains multiple subtype members.Theα-subunit of Kv channel is the conducting subunit, tetramer polypeptides clustering around a central pore There are six transmembrane helices(S1–S6)The S5–S6linker is a pore-forming P-loop,orientate to constitute sensorma membrane is depolarized and S5–S6helices then undergo conformational changes,thus opening the cytoplasmic activation gate to allow K+efflux(Choe et al.,1999;Yellen,2002).On the basis of gating behaviors,Kv channels could be broadly classified into two major types,namely,A-type K+channels and delayed rectifiers.A-type K+channels,exemplified by Kv1.4,Kv3.3 and Kv4.2,are fast-inactivating Kv channels with low activation thresholds(around−60to−40mV)(Hollerer-Beitz et al.,1999; Hille,2001;Sacco et al.,2006).These channels serve to control the spiking orfiring frequency.The fast inactivation,usually with time constants around tens of milliseconds,results from the rapid occlu-sion by the cytoplasmic N-terminus at the internal vestibule of the opened channel—“ball-and-chain mechanism”(Hoshi et al.,1990; Zagotta et al.,1990;Hoshi et al.,1991;Kurata&Fedida,2006).There-fore fast inactivation is also called N-type inactivation.Delayed recti-fiers(e.g.Kv1.2,Kv2.1,Kv3.1)have higher activation thresholds (around−30to−20mV)and inactivate very slowly,usually with time constants in the range of seconds.Such slow inactivation(also termed C-type inactivation)is generally thought to involve a localized conformational change at the channel outer pore mouth,such as a distortion or destabilization of the selectivityfilter during persistent depolarization(Hoshi et al.,1991;Kurata&Fedida,2006;Cordero-Morales et al.,2007)(see Fig.1).However,slow inactivation may also involve more global conformational change of the channel(see below).2.2.C-type inactivation gatingIn Shaker channels,the role of T449,a residue at the external pore mouth,in C-type inactivation has been studied in details.Mutation of this amino acid to arginine,lysine,alanine or glutamate accelerates C-type inactivation,while mutation to valine or tyrosine retards C-type inactivation(Lopez-Barneo et al.,1993).However,how pivotal this residue determines C-type inactivation rate is still questionable,as this site does not appear to produce similar effects in mammalian Kv1C-type inactivation(Rasmusson et al.,1995;Fedida et al.,1999).A mechanistic model was proposed in which the interaction strength(via hydrogen bonds)between residues in the selectivityfil-ter and the adjacent pore helix is crucial for C-type inactivation (Cordero-Morales et al.,2007).These authors adopted the prokaryot-ic proton-activated KcsA channel as a model.Upon extracellular acid-ification,KcsA channels open and immediately undergo C-type inactivation at a decent rate.Interaction via hydrogen bonds between E71and D80(equivalent to Shaker438and447)is important in con-trolling C-type inactivation rate.Mutating glutamate at71to several amino acids including glycine,alanine and valine strongly retards in-activation.Kv1.2WT channels inactivate very slowly.Introducing equivalent mutations in Kv1.2yields expected results.Thus,in Kv1.2,mutating Val370into Glu370greatly speeds up inactivation as this manipulation renders possible a stronger interaction with Asp379;such interaction acts like a spring to pull and collapse the se-lectivityfilter(Cordero-Morales et al.,2007).Recent evidence reveals that hydrogen bonding between D80and another amino acid,W67,is also crucial in determining the rate and extent of C-type inactivation in the KcsA channel(Cordero-Morales et al.,2011).Similarly,it was shown in the same work that W434–D447interaction and W366–D379interaction are crucial in controlling C-type inactivation in Shaker and Kv1.2,respectively.It is interesting to note that the V370–D379interaction(Fig.2)in the Kv1.2channel or the E71–D80interaction in the KcsA channel does not only control C-type inactivation(pore stability),but also af-fects K+selectivity(Chao et al.,2010;Cheng et al.,2011).In these re-ports,it was shown that weakening such interactions(thus reduced C-type inactivation)results in increased Na+permeability.Therefore, mechanisms governing C-type inactivation appear to be intimately coupled to the control of cationic selectivity.152Y.-M.Leung/Pharmacology&Therapeutics133(2012)151–158A study using solution NMR spectroscopy revealed that the selec-tivity filter of C-type inactivated KcsA channel has a higher af finity for water than K +;the latter's permeation is thus obstructed by water molecules during C-type inactivation (Imai et al.,2010).This finding is supported by a recent molecular mechanics simulation study (Boiteux &Bernèche,2011).In a report by the Perozo lab (Cuello et al.,2010),five crystal structures of the KcsA channels at different degrees of open conformations were studied.Subtle changes in the 4K +binding sites (S1–S4)in the selectivity filter were observed which may represent C-type inactivation:an initial loss of the S2binding site (S2destabilization)and a subsequent loss of the S3bind-ing site (S3destabilization).Evidence suggests that C-type inactivation may not only involve localized conformational change at the selectivity filter,but may also have a global impact on the channel conformation (Jiang et al.,2003).In this report,using N-terminal-deleted mutant of Kv1.4expressed in Xenopus oocytes,the authors showed that the internal vestibule indeed shrinks in size during C-type inactivation;the vol-ume change is similar to that which happens during activation and deactivation.3.Classical blockers ofvoltage-gated K +channels:extracellular block3.1.Occlusion of the K +conduction pathway by tetraethylammonium TEA could block extracellularly and intracellularly.Early mutagen-esis studies showed that TEA possibly binds to T449(only three amino acids external to the GYG sequence)of Shaker (Heginbotham &MacKinnon,1992).Since T449has also been found to be a residue affecting C-type inactivation (see above)and often TEA block is ac-companied by a slowing of C-type inactivation,it appears reasonable to conceive that TEA inhibits C-type inactivation (i.e.,prevents selec-tivity filter constriction)in a “foot-in-the-door ”fashion.Subsequent mutagenesis work revealed that the TEA binding site(s)are rather diffuse,since other residues at the P-loop are also responsible for TEA binding,namely,T370,T373,Y376,D378,Y380and K382of Kv2.1(Pascual et al.,1995).It was thus proposed that TEA does not bind like a tight plug;rather,TEA resides in the aqueous environment immediately outside the outer lip (Fig.1).3.2.Tetraethylammonium action may involve C-type inactivation under special circumstancesAlthough TEA block of wild type Kv channels has been considered not associative with enhancement of selectivity filter constriction,a twist in our understanding of its action comes from a report suggest-ing that TEA might hasten C-type inactivation gate closing under cer-tain circumstances.Ahern et al.(2009)showed that in the Shaker T449F mutant,inactivation rate is much reduced,as the aromatic rings of the four Phe residues repel each other.Addition of TEA,in-stead of causing the “foot-in-the-door ”effect,indeed acceleratesC-Fig.2.Molecular graphics of the Kv1.2channel.The Kv1.2channel is a tetramer of 4polypeptides.Only one monomer is shown in this diagram.Each monomer has six transmembrane domains:S1and S2(yellow),S3and S4(green),S5and S6(red).The P-loop between S5and S6is shown in purple color.Val370and Asp379are repre-sented by the small yellow sticks.intensified BATEA blockNormal conductionDCC-type inactivationC-type inactivationintensifiedFig.1.Schematic diagrams of TEA block and C-type inactivation in Kv channels.(A )Normal conduction of K +through the selectivity filter of the Kv channel.(B )TEA resides at theouter pore mouth,blocking the ef flux of K +.(C )C-type inactivation happens when the selectivity filter of the Kv channel constricts or destabilizes during prolonged depolarization,thus obstructing K +out flow.(D )A drug (purple square)binds to an extracellular domain and accelerates/intensi fies C-type inactivation.153Y.-M.Leung /Pharmacology &Therapeutics 133(2012)151–158type inactivation.The authors suggested that there is an interaction between the cation(TEA)and theπelectrons of the Phe aromatics, so that the inactivation gate is pulled to close rapidly,resulting in a “spring-in-the-door”mechanism.To support their hypothesis,they showed that a V438A mutation,possibly producing an allosteric reor-ientation of T449F,restores the“foot-in-the-door”effect.The authors further showed that by serialfluorination of the Phe449residues of the single mutant T449F and hence drawing electrons away from the aromatics,the“spring-in-the-door”is replaced by the“foot-in-the-door”mechanism.Thus,under certain circumstances(T449F), the classical Kv channel blocker TEA may not simply act as a pore blocker,but may exert its inhibitory effect in part through promoting C-type inactivation(Ahern et al.,2009;Olcese,2009).3.3.ToxinsVarious toxins targeting Kv channels have been isolated from the venom of a diversity of animal species,such as scorpions,snakes,con-osnails,sea anemones and spiders(Mouhat et al.,2008).These peptide toxins are usually very potent and some have been shown to be specific for a particular Kv subfamily.For instance,dendrotoxins and stromatoxin-1are specific blockers for Kv1and Kv2subtypes,respec-tively(Shiau et al.,2003;Harvey&Robertson,2004).Most of the Kv-acting toxins bind extracellularly.While some(e.g.tityustoxin-Kα) have been known to have no effect on C-type inactivation(Rodrigues et al.,2003)or interfere with C-type inactivation(e.g.κ-Conotoxin PVIIA;Koch et al.,2004),there is hitherto no toxin known to block Kv channels mainly by accelerating the C-type inactivation gate.4.Classical blockers ofvoltage-gated K+channels:intracellular block4.1.Quaternary ammoniums and quinidineaction may in part involve C-type inactivationQuaternary ammoniums(QA),4-AP and quinidine could directly block Kv channels intracellularly,that is,they could block at the inter-nal cavity once the Kv channel opens.These drugs could affect C-type inactivation.In particular,part of the blocking mechanisms of QA and quinidine involves acceleration of C-type inactivation,although these two drugs achieve this via different modes of action.It is believed that K+occupies a selective site near the outer lip of the channel pore;such occupancy tends to maintain the open state of the Kv channel and prevents its C-type inactivation(Baukrowitz& Yellen,1995).It is found that upon N-type inactivation and blockade of the internal cavity by QA,the reduced K+efflux prevents the re-plenishment of this K+occupancy site.If the extracellular concentra-tion of K+is low,there is a reduced occupancy rate of this K+-selective site;and N-type inactivation and QA blockade could thus help accelerating C-type inactivation(Baukrowitz&Yellen,1996).The membrane-permeant4-AP blocks intracellularly,and prefer-entially blocks the open state of Kv channels.Thus4-AP block de-pends on the opening of the cytoplasmic activation gate(Russell et al.,1994).Once the drug gains access into the internal cavity,it can be trapped inside after the channel closes.Interestingly,C-type inac-tivation appears to have a significant effect on the conformation of the internal cavity,as it obscures the binding of4-AP into the internal cavity.This is consistent with the observation that C-type inactivation also constricts the internal cavity size(Jiang et al.,2003).That C-type inactivation and4-AP block at the internal cavity is mutually exclu-sive is further substantiated by thefinding that4-AP block could pre-vent C-type inactivation via an allosteric mechanism in Shaker (Claydon et al.,2007).Therefore,there are certain allosteric interac-tions between the slow inactivation gate and the internal vestibule.Quinidine,an anti-arrhymic drug,binds to the internal vestibule and therefore blocks Kv channels in the open state.In a Kv1.4mutant lacking N-type inactivation,quinidine has been shown to accelerate C-type inactivation by acting from the internal vestibule via an allo-steric manner,which is believed to involve orientation of the S6 (Wang et al.,2003).These studies suggest that drugs acting intracel-lularly are also able to affect the inactivation gate closing.The differ-ence between the effects of intracellular quinidine and that of internal 4-AP on C-type inactivation remains unknown.4.2.Direct internal block without involving C-type inactivationOf note,the aforementioned allosteric drug action has to be distin-guished from the effects of a few drugs known to speed up current decay not by promoting C-type inactivation,but by blocking at the internal cavity of Kv channels in an open-channel block and time-dependent manner.The classical example of this is block of Kv chan-nels by intracellular nonyltriethylammonium or TPeA,which are TEA analogs(Armstrong,1971).Block has to wait until the cytoplasmic activation gate opens:hence open-channel block.The block by these more hydrophobic drugs shows time-dependence.Internal TEA block does not display time-dependence,since TEA has a much faster off-rate and thus block by TEA happens as soon as the channel opens.More recent observations of open-channel and time-dependent block by intracellularly applied drugs include AVE0118 (2′-{[2-(4-methoxy-phenyl)-acetylamino]-methyl}-biphenyl-2-car-boxylic acid(2-pyridin-3-yl-ethyl)-amide),an anti-arrhythmic agent, and verapamil,a classical L-type Ca2+channel antagonist.AVE0118 was found to bind to at least six residues orienting toward the inter-nal vestibule,and by plugging at the internal cavity,AVE0118also slows channel deactivation(Decher et al.,2006).Block of Kv1.3inter-nal cavity by intracellularly applied TEA reduces the efficacy of verap-amil block while outer mouth pore mutations and extracellularly applied TEA fail to produce such an effect(Rauer&Grissmer,1996). These data suggest that verapamil binds to the internal cavity.pounds whose block isdependent on C-type inactivation gating5.1.HMJ-53A,rhynchophylline and6β-acetoxy-7α-hydroxyroyleanone(AHR)A variety of drugs reportedly accelerate Kv current decay,and this could be interpreted in multiple ways which include a time-dependent occlusion of the ion permeation pathway(e.g.intracellu-lar blockers such as nonyltriethylammonium,verapamil and AVE0118discussed in the previous section)or acceleration of C-type inactivation.We recently introduced several novel Kv channel blockers which inhibit Kv channels not by obstructing the pores but by enhancing the C-type inactivation gate closing.Channel inhibition is manifested as a hastened decay of currents.The inactivation time constants are often tens of milliseconds,close to those of N-type inac-tivation.These compounds include HMJ-53A(Chao et al.,2008), rhynchophylline(Chou et al.,2009)and6β-acetoxy-7α-hydroxyroy-leanone(AHR)(Leung et al.,2010).HMJ-53A is a synthetic compound which possesses inhibitory effect on platelet aggregation(Hour& Hung,2000).Rhynchophylline is an alkaloid isolated from the hook part of Uncaria rhynchophylla Miq.(Rubiaceae)and exhibits neuro-protective functions(Kang et al.,2004).AHR,isolated from Taiwania cryptomerioides,is a diterpenoid compound previously found to have anti-oxidative effects(Wang&Wu,2002).Several characteris-tics were investigated to consider if these drugs act on the inactiva-tion gate:(1)whether their blockade of Kv channels is extracellular and whether the degree of block is independent of intracellular K+ concentration,(2)whether they have significant effect on steady-state inactivation gating,and(3)their effects in C-type inactivation-defective mutants.These aspects are elaborated as follows.154Y.-M.Leung/Pharmacology&Therapeutics133(2012)151–158HMJ-53A,rhynchophylline and AHR all act extracellularly to hasten current decay and they exert no effect when dialyzed into the cell via the recording pipette (Chao et al.,2008;Chou et al.,2009;Leung et al.,2010;also see Fig.3).These data suggest that these few drugs do not act at the internal cavity,thus distinguishing their pharmacolog-ical properties from the intracellular actions of QA and quinidine,which are able to promote C-type inactivation (by different mechanisms,as mentioned above).Further,while the intracellularly acting QA and quinidine only mildly promote C-type inactivation,the effects of HMJ-53A,rhynchophylline and AHR on C-type inactivation are drastic,de-creasing inactivation time constants to around 30–100ms.What are the mechanisms of these blocks?Are these drugs directly occluding the permeation pathway,or intensifying the destabilization of the selectivity filter?If these drugs occlude the K +permeation path-way,the drug should reside immediately outside the outer pore to block K +ef flux directly;the drug and K +ions will encounter each other at the exit of the narrowest part of the ion conduction pathway.It could be reasoned that the lower the concentration of the intracellu-lar K +,the less the physical expulsion of the extracellular drug and thus the greater the block.Our experiments showed that the block by all these agents was not signi ficantly affected when intracellular K +con-centration was reduced from 140to 70mM.These results are incom-patible with the proposal that these drugs are direct pore blockers.All the three drugs caused a signi ficant left shift in steady-state in-activation curve,further supporting the notion that they effect on the inactivation gate.They all do not affect the activation kinetics.With the exception of rhynchophylline,which causes a left-shift in activa-tion curve and thus lowers the activation threshold (see below),they do not affect the voltage-dependence of activation.As mentioned,interaction between V370and Asp379in Kv1.2is important in pore stability and C-type inactivation (Cordero-Morales et al.,2007).We mutated V370into G370and this mutant in-activates signi ficantly more slowly than the WT does (Leung et al.,2010).While AHR causes a drastic acceleration of current decay in WT Kv1.2channels,its effect on current decay is much attenuated in Kv1.2V370G (Leung et al.,2010;Fig.4).This provides a strong sup-port that the effect of AHR on current decay depends on C-type inac-tivation.Given that V370is facing the internal cavity (Fig.2)and that AHR action is extracellular,it is unlikely that AHR directly binds to this residue.Instead,AHR may bind to certain extracellular domain and then accelerate C-type inactivation,which in part hinges on the V370residue.The observation that AHR has no effect on ATP-sensitive K +channels,which are devoid of C-type inactivation,fur-ther supports that AHR inhibition of Kv channels depends on C-type inactivation gating (Leung et al.,2010).5.2.2-[N-(2-hydroxyethyl)]-N-(4methoxybenzenesulfonyl)]amino-N-(4-chlorocinnamyl)-N-methylbenzylamine,dofetilide and other drugs 2-[N-(2-hydroxyethyl)]-N-(4methoxybenzenesulfonyl)]amino-N-(4-chlorocinnamyl)-N-methylbenzylamine (KN-93)is a potent inhibi-tor of Ca 2+/calmodulin-activated protein kinase II (CaMKII).KN-93,acting extracellularly but not intracellularly,was shown to enhance slow inactivation in a number of Kv channels including Kv1.2,Kv1.5,Kv2.1and Kv3.2(Ledoux et al.,1999;Rezazadeh et al.,2006).Such an action is independent of its action on CaMKII,since an inactive analog also accelerates slow inactivation.KN-93has a small effect on activa-tion gating:slight left-shift in activation curve (Rezazadeh et al.,CADIntracell. AHRB0.40.60.81.00.00.2I e o p /I p e a kTime (s)Fig.3.Extracellular,but not intracellular,application of HMJ-53A and AHR accelerates slow inactivation of Kv currents.(A )Representative traces showing outward Kv currents in N2A cells triggered by +30mV just after whole-cell con figuration was established,after 15min of 30μM HMJ-53A dialysis and 8min after bath application of 30μM HMJ-53A to the same cell.(B )The decay time constants before and after HMJ-53A treatment as observed in (A )is plotted against time.(C )Outward Kv currents were triggered by +30mV in a Kv1.2-expressing HEK293cell.Traces shown are currents just after whole-cell con figuration was established,after 10min of 50μM AHR dialysis and 3min after bath application of 50μM AHR to the same cell.(D )The ratio of end-of-pulse current/peak current (Ieop/Ipeak)as observed in (C )are plotted against time.Panels A and B are from Chao et al.(2008)Neuropharmacology 54:1128–1135.Panels C and D are from Leung et al.(2010)Cell Mol Life Sci 67:147–156.155Y.-M.Leung /Pharmacology &Therapeutics 133(2012)151–158。
