说说磁珠(Ferrite Bead)第一次使用磁珠还是在实习的时候，但是看原理图发现有个元件写着”Bea d”，单位是100欧姆，用万用表测，导通，电阻约为0。
当时就很奇怪，是什么有什么用？后来问了师兄，才知道，这个是磁珠，相当于电感，通直流阻交流(不准确)。
这就是我当初对磁珠的印象。
磁珠全称为铁氧体磁珠，Ferrite Bead，简写FB。
磁珠的单位是欧姆，而不是亨特，这一点要特别注意。
因为磁珠的单位是按照它在某一频率产生的阻抗来标称的，阻抗的单位也是欧姆。
磁珠的 DATASH EET上一般会提供频率和阻抗的特性曲线图，一般以100MHz为标准，比如60 0R@100MHz，意思就是在100MHz频率的时候磁珠的阻抗相当于600欧姆。
磁珠的结构X射线下的结构(真的活像线圈)磁珠的等效模型R bead是磁珠的直流电阻；L bead是磁珠的等效电感；Cpar和Rpar是并联电容和电阻。
在低频的时候，Cpar开路，L bead短路，只有直流电阻R bead。
当频率增加的时候，阻抗(JwL bead)随着L bead的增加线性增加，阻抗(1/jwCpar)随着Cpar的减小而相反增长。
磁珠的阻抗频率曲线图上升斜率主要由电感L bead决定。
在高频到达一定频率点时，Cpar的阻抗开始起主要作用。
磁珠的阻抗开始减小。
阻抗频率曲线的斜率下降主要由磁珠的寄生电容Cpar所决定。
Rpar对抑制品质因素(Q-factor)有作用，无论如何，Rpar和Cpar的值增长过大会增加磁珠的品质因素和减小磁珠的有效带宽。
高品质因素(Q)可能导致电源输送网络瞬态频率响应不想要的抬升。
Z=R+jxZ：阻抗R：电阻X：电抗磁珠的电性参数Z(阻抗) [Z]@100MHz (ohm)磁珠的阻抗是指在电流下所有阻抗的总和，包括交流与直流部分。
阻抗的直流部分仅仅是绕线的直流电阻，交流部分包括电感电抗。
下面的公式计算了一个理想电感在正弦交流信号下的电感电抗。
【Version change history】Rev. Effective Date Changed Contents Change reasons Approved By01 / New release / Hai GuoCautionAll products listed in this specification are developed, designed and intended for use in general electronics equipment. The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or quality require especially high reliability, or whose failure, malfunction or trouble might directly cause damage to society, person, or property. Please understand that we are not responsible for any damage or liability caused by use of the products in any of the applications below. Please contact us for more details if you intend to use our products in the following applications.1.Aircraft equipment2.Aerospace equipment3.Undersea equipment4.nuclear control equipmentitary equipment6.Power plant equipment7.Medical equipment8.Transportation equipment (automobiles, trains, ships,etc.)9.Traffic signal equipment10.Disaster prevention / crime prevention equipment11.Data-processing equipment12. The application with a long term direct-current voltage difference, which is greater than 1.5V, between D+ and D- of differential lines13. Applications of similar complexity or with reliability requirements comparable to the applications listed in the above1. ScopeThis specification applies to SDMM Series of multi-layer common mode filter. 2.Product Description and Identification (Part Number) 1) DescriptionSDMM Series of multi-layer common mode filter. 2)Product Identification (Part Number) SDMM 0806 U -2 -□□□T ① ② ③ ④ ⑤ ⑥3. Electrical CharacteristicsPlease refer to Appendix A . 1) Operating and storage temperature range (individual chip without packing): -40 ~ +85℃℃ 2) Storage temperature range (packaging conditions): -10~+40 and RH 70% (Max.)℃℃Appendix A: Electrical CharacteristicsPart NumberCommon modeImpedance @ 100MHz(Ω)DC Resistance (Ω) Max.Rated Current (mA) Max.Insulation Resistance (M Ω) Min.Cutoff Frequency(typ.) (GHz) SDMM0806U-2-120T 12±5 2.5 130 100 ＞8 SDMM0806U-2-350T 35±20% 3.5 100 100 ＞6SDMM0806U-2-470T 47±20% 4.0 100 100 6 SDMM0806U-2-900T 90±20% 4.51001003.5Note: Absolute maximum long term direct-current voltage between D+ and D- of differential lines: DC 1.5VPacking ⑥TTape Carrier Package① TypeSDMMmultilayer commonmode filter② External Dimensions (L x W) (mm)08060.85×0.65Number of Lines ④-2 2 linesCommon Mode Impedance ⑤ (Ω)Example Nominal Value350 35③Feature TypeUFor Ultra high speedDifferential SignalLinesTypical Electrical CharacteristicsSDMM0806U-2-120T SDMM0806U-2-350TImpedance vs. Frequency(SDMM0806U-2-120T) Impedance vs. Frequency(SDMM0806U-2-350T)Insertion loss vs. Frequency (SDMM0806U-2-120T) Insertion loss vs. Frequency (SDMM0806U-2-350T)Insertion loss vs. Frequency (SDMM0806U-2-120T) Insertion loss vs. Frequency (SDMM0806U-2-350T)SDMM0806U-2-470T SDMM0806U-2-900TImpedance vs. Frequency (SDMM0806U-2-470T) Impedance vs. Frequency (SDMM0806U-2-900T)Insertion loss vs. Frequency (SDMM0806U-2-470T) Insertion loss vs. Frequency (SDMM0806U-2-900T)Insertion loss vs. Frequency (SDMM0806U-2-470T) Insertion loss vs. Frequency (SDMM0806U-2-900T)4. Shape and Dimensions1) Dimensions: See Fig.4-1 and Table 4-1. 2) Equivalent circuit: See Fig. 4-2.3)Recommended PCB pattern for reflow soldering: See Fig. 4-3.4) Structure: See Fig. 4-4 and Fig. 4-5.Material Information: See Table 4-2.[Table 4-2]Code Part NameMaterial Name ① Ceramic Body Ceramic Powder ② Ferrite Body Ferrite Powder ③ Inner Coils(Ag) Silver Paste ④ Pull-out Electrode (Ag) Silver PasteTypeL W T SL SW P 0806 0.85±0.05 0.65±0.05 0.40±0.05 0.20+0.05/-0.10 0.27±0.05 0.50±0.05[Table 4-1] Unit: mmSW（3） （1） （4）（2）（3） （1） （2）（4）For 0806Fig. 4-2Fig. 4-3Fig.4-1①③④⑤Fig. 4-4②①AgStructure of Electro-platingBodyNiSn⑤-1 ⑤-2Fig. 4-55.Test and Measurement Procedures 5.1 Test ConditionsUnless otherwise specified, the standard atmospheric conditions for measurement/test as:a. Ambient Temperature: 20±15℃b. Relative Humidity: 65±20%c.Air Pressure: 86 kPa to 106 kPaIf any doubt on the results, measurements/tests should be made within the following limits:a. Ambient Temperature: 20±2℃b. Relative Humidity: 65±5%c. Air Pressure: 86kPa to 106 kPa 5.2 Visual Examination a. Inspection Equipment: 20× magnifier5.3 Electrical TestItems Requirements Test Methods and Remarks5.3.1 Impedance (Common Mode)Refer to Appendix ATest equipment: High Accuracy RF LCR Meter Agilent4287A/E4991A or equivalent.Common Mode Impedance is tested according to the following circuit.5.3.2 Impedance (Differential Mode)Refer to Appendix ATest equipment: High Accuracy RF LCR Meter Agilent4287A/E4991A or equivalent. Differential Mode Impedance is tested according to the following circuit.5.3.3DC ResistanceRefer to Appendix ATest equipment: High Accuracy Milliohm meter Agilent4338B/34420 or equivalent. DC Resistance is tested according to the following circuit.5.3.4Rated CurrentRefer to Appendix ATest equipment: Electric Power, Electric current meter, Thermometer.Definition of Rated Current (Ir): Ir is direct electric current as chip surface temperature rise just20 against chip initial surface temperature.℃ Rated Current is tested according to the following circuit.5.3.5 Insulation ResistanceRefer to Appendix ATest equipment: High resistance meter Agilent4339B. Withstand Voltage:2.5 times rated voltage Application time:1~5 SecondsThe charging and discharging current::Less than 1mAInsulation Resistance is tested according to the following circuit.5.3.6Insertion LossRefer to Appendix ATest equipment: S-parameter Network Analyzer AgilentE5071C or equivalent. Insertion Loss is S21mag tested according to the following circuit.5.4.10 Loading under damp heat① No visible mechanical damage. ② Impedance change: within ±20%. ③ Insulation Resistance: 100M Ω Min.① Temperature: 60±2.℃ ② Humidity: 90% to 95% RH. ③ Duration: 1000+12hours.④ Applied current: Rated current.⑤ The chip shall be stabilized at normal condition for 1~2 hoursbefore measuring.5.4.11Loading at high temperature (Life test) ① No visible mechanical damage. ② Impedance change: within ±20%. ③ Insulation Resistance: 100M Ω Min.① Temperature: 85±2.℃ ② Duration: 1000+12hours.③ Applied current: Rated current.④The chip shall be stabilized at normal condition for 1~2 hours before measuring.6. Packaging and Storage6.1 PackagingTape Carrier Packaging: Packaging code: T a. Tape carrier packaging are specified in attached figure Fig.6.1-1~4 b.Tape carrier packaging quantity please see the following table:Type 0806 Tape Paper Tape Quantity10Kc. Reel shall be packaged in vinyl bag.d. Maximum of 5 or 10 reels bags shall be packaged in an inner box.e.Maximum of 6 or 10 inner boxes shall be packaged in an outer case.(1)Remark: The sprocket holes are to the right as the tape is pulled toward the user.(2) Taping Dimensions (Unit: mm)Type A B P Tmax 08060.80±0.051.0±0.052.0±0.050.55Chip CavityTSunlord Business categories ：Level 0（general confidential ） Specifications for Multi-layer Common Mode Filter Page 11 of 11(3) Reel Dimensions (Unit: mm)6.2 Storage a. The solderability of the external electrode may be deteriorated if packages are stored where they are exposed to high humidity. Package must be stored at 40 or less and 70% RH or less.℃b. The solderability of the external electrode may be deteriorated if packages are stored where they are exposed to dust of harmful gas (e.g. HCl, sulfurous gas of H 2S).c. Packaging material may be deformed if package are stored where they are exposed to heat of direct sunlight.d.Solderability specified in Clause 5.4.6shall be guaranteed for 6 months from the date of delivery on condition that they are stored at the environment specified in Clause 3 .For those parts, which passed more than 6 months shall be checked solder-ability before use.7. Recommended Soldering Technologies7.1 Re-flowing Profile:△ Preheat condition: 150 ~200/60~120℃sec. △ Allowed time above 217: 60~90s ℃ec. △ Max temp: 260℃△ Max time at max temp: 10sec. △ Solder paste: Sn/3.0Ag/0.5Cu △ Allowed Reflow time: 2x max7.2 Iron Soldering Profile.△ Iron soldering power: Max.30W. △ Pre-heating: 150 / 60 sec. ℃ △ Soldering Tip temperature: 350Max.℃ △ Soldering time: 3 sec Max. △ Solder paste: Sn/3.0Ag/0.5Cu. △ Max.1 times for iron soldering. [Note: Take care not to apply the tip of the soldering iron to the terminal electrodes.]CFig.6.1.34.3±0.2mm4.0±0.1mm5.0±0.1mm3.0±0.1mmmax ＜14.4mm[Note: The reflow profile in the above table is only for qualification and is not meant to specify board assembly profiles. Actual board assembly profiles must be based on the customer's specific board design, solder paste and process, and should not exceed the parameters as the Reflow profile shows.]26015020021725℃ Tc ℃350℃。
