3.5-INCH TFT-LCDTEST MONITORINSTRUCTION MANUALSpecially made for Surveillance systemPlease read the following items before use.●Dear customers, thanks for using this product, we sincerely hope our products can bring you convenience, and before start to use it, please pay attention to the following items.And please keep it after reading the safety notice.1）Forbidden to use in the high temperature environment especially not allowed in hi-temperature bathroom, the most suitable working temperature for this product is approximate 0-60℃If something breaks down, please turn off the monitor, and take out the batteries, or pull out the plug of the charger. When product leaks smoke 、exception smell or other exception matter . If continue using, it may cause fire disaster or suffer shockDon’t redo or knock down the machine (Do not open the case ), if the machine breaks down or the case gets broken. Please don’t continue using ,otherwise it may cause the fire disaster or suffer shock.2）Don’t redo、heat up、over-tweak or drag the connection wire, and please don’t put heavy object on the connection wire, otherwise it may damage the wire, and cause fire disaster or suffer shock. when wire damaged, please contact the local wholesaler to change.3）Please don’t place the product in disbalance place, otherwise it may make the machine drop to get damage.4）Please use the dominated batteries, and when fixing the batteries, please do in accordance with demonstration.Please don’t heat up 、redo or knock down the battery, please don’t drop the battery or make it get hit, please don’t place the battery in the metal container. Use the dominated charger to charge the battery. any fails from the above case may cause battery explosion or leak, thereby cause the fire disaster or body harmness.5）Please use the dominated battery or AC charger. Please don’t use it at the voltage beyond the fixed range.6）If battery leaks, and the liquid comes into your eyes、skin or clothes, please wash the position touched, if necessary, please contact the doctor or dial the emergent number.7）When plug get damaged or it’s loosen when inserted into the socket, please don’t use the AC charger, otherwise it may cause fire disaster or suffer shock.8）Clean the monitor. and when not used for a long time, please take out the batteries, or pull out the plug, otherwise it may cause fire disaster or suffer shock.9）When charging finished, please pull out the plug from the socket, otherwise fire disaster may happen.10）Keep the product away from water or other liquid, otherwise there may be danger of fire disaster or shock.In order to keep your safety, please use the adapter we supplied (Regarding the damages caused by using adapters from other supplier, we are not responsible to it).11）Don’t set the machine in the place of bared sunshine.12）In order to keep it away from damage by dropping or bumping at sharp object, Please place the machine in the place where the children can not reach,When the battery’s working time is apparently shorter than new one, please change the battery.13）The machine will get heat after long time working, it belongs to normal phenomenon.14）Please don’t place the charger in the place of much dust or intensity vibration、extreme humidity or high temperature (for example: under the bare sunshine or beside the heater )15）The available voltage for the charger is AC 110~240 V / 50/60 Hz. Plug standard is various from different environment; when purchase this product, please consult relevant department to confirm the suitable plug standard. 16）During charging, the batteries and charger will get heat, it belongs to normal phenomenon, but not malfunction. If possible, please charge the battery in aeration area.Battery and power supplyThe following items state the right way to use batteries and the way to extend its lifespan Using the batteries in incorrect way will shorten its lifespan or cause to leak、overheat、fire or explode.●Battery comes out from factory with no power. Please charge it before use. and put it into the battery box whe n don’tuse it.Battery usage notice-If leaving the battery to be idle, it will lose electricity gradually. Please charge it at 1-2 day early before use·When battery in idle status, turn off the monitor, it’s a way to extend the lifespan.·The performance will reduce when battery in low temperature environment; battery can’t work normally in cold condition. place a fully charged battery in warm place. Don’t place battery close to heater or hand-warming articles.Charging Notice·Please put the batteries into the machine,and then connect the charger well.this product adopts IC to conduct electrical source management.when fit on the battery,it will conduct auto-inspection(the red light flash 2 times),if battery goes worng,the red light flash quickly;if working normally,the LED indicator light keep red.if fully charged,the red light will go out.10 minutes more charging again it’s a way to check if the charged battery is full or not.The charge time will extend if the surrounding temperature lower than 10℃ or higher than 35℃,please don’t charge the battery in the place where temperature is higher than 40℃;it stops charging when temperature under 0 ℃.it’s not allowed to charge the fully charged battery again,and you don’t have to wait to charge until the el ectricity totally runs out.·It’a normal phenomenon that battery gets heat when charge over or after use.Battery’s lifespanIn normal temperature,users can charge battery for 300 times.when the working time of consuming its full capacity apparently decrease,users need to change the battery.Storage·If long time no use after fully charged, the battery’s perfermance will weaken.·If don’t use this machine for a long time,please take the batteries ou t,and store them in a dry place，moreover the store temperature should between 15℃ and 25℃.Please don’t place it in extremely high or low temperature area.Attention:battery usage notice-Don’t transport or store the battery together with necklace、barrette and other metal object.·Don’t throw the battery into fire to heat up.·Don’t knock down or redo the battery.·Please use the dominated charger to charge.·Deal with the batteries discarded.·Don’t drop the battery or make it suffer intense vibration.·Please keep it away from water.·Please keep its connection terminal clean.·It’s the normal phenomenon that the battery and machine get heat after long time working.Alternating Current Adapter·Please just use the adapter dominated for this machine,if use other kind of adapter may cause matters to the machine. ·AC adapter for indoor use.·Make sure that DC plug connect to the monitor firmly.·Please turn off the monitor before pull out the plug.·Don’t use it in other devices.·Don’t knock it down yourself.·Don’t place it in high temperature or humidy area.·Please don’t let it suffer intense shake·It’s a normal phenomenon that the adapter buzzs or get heat when using.·If adapter cause wireless interference,please reset the antenna.Product UseIn order to make sure of the normal working,please don’t let the machine get hit or shake.Electric interferenceThis product may cause interference to the medical and aviatic devices.before you use it in the hospital or airport,please consult the hospital the airline company.Liquid crystalIf screen suffered damage,please avoid to touch the liquid crystal.if any case of the following happens,please do as we show.·If liquid crystal gets to your skin,please clean the position with cloth,then daub some soap and then wash it.·If liquid crystal comes into your eyes, please flush the eye with water more than 15minutes,and then ask for help from doctor.·If drink the liquid crystal by mistake,please gargle with water,and drink much water to help throw up,and then consult the doctor.Debug The MachineBefore start to monitor the important spot,please adjust the machine to make sure of its normal working.we are not responsible to any damage or benefit loss caused by product’s malfunction.ClaimSpecification subject to change without notice, we have the final explaination right to do a explaination to this manual. ·The screen is made from high precise technology,still there would be brightness dot or color abnormity on screen sometimes.it’s the normal phenomenon to this kind of LCD,but not failure.·When fall acrosse wireless interference( such as magnetic field、static or circuit noise),the abnormity display may happen.AccessoryPower Charger 1pcWall mount bracket 1pc1.2V AA nickel-hydrogen battery 4pcsA V cable #1( video input) : 1pcAv cable #2 (video output): 1pcWrist strap 1 pcUsers’manual 1pcWarranty card 1pcAppearance and function illustrationMenu adjustmentBrightness Brightness adjustment: Users can change the brightness and darkness of image by adjusting the parameter according to his personal requirement. Firstly, press MENU key to enter main menu interface, and then press “▲”key or “▼”key to confirm this submenu, then press “▲”or “▼”to adjust the brightness and darkness of image. Press ESC key to exist main menu.Contrast Contrast adjustment: Users can change the contrast of image by adjusting the parameter according to his personal requirement. Firstly, press MENU key to enter main menu interface, press MENU key to select downwards(moving the yellow cursor to this submenu),and then press “▲”key or “▼”key to confirm this submenu, in the end press “▲”or “▼”to adjust the contrast of image. Press ESC key to exist main menu.Saturation Saturation adjustment: Users can change the saturation of image by adjusting the parameter according to his personal requirement. Firstly, press MENU key to enter main menu interface, press MENU key to selectdo wnwards(moving the yellow cursor to this submenu),and then press “▲”key or “▼”key to confirm this submenu, in the end, press “▲”or “▼”to adjust the saturation of image. Press ESC key to exist main menu.Sharpness Sharpness: Users can change the sharpness of image by adjusting the parameter according to his personal requirement. Firstly, press MENU key to enter main menu interface, press MENU key to select downwards(moving the yellow cursor to this submenu),and then press “▲”key or “▼”key to confirm this submenu, in the end, press “▲”or “▼”to adjust the sharpness of image. Press ESC key to exist main menu.V olume V olume adjustment: Users can change the volume of image by adjusting the parameter according to his personal requirement. Firstly, press MENU key to enter main menu interface, press MENU key to select downwards(moving the yellow cursor to this submenu),and then press “▲”key or “▼”key to confirm this submenu, then press “▲”or “▼”to adjust the volume of image. Press ESC key to exist main menu.Language English / Italian / ChineseInstallation Illustration Battery fixing1.Product fixing methodUsers have four methods to fix this product, you can choose the accessories supplied to fix according to the various situation.⑴Portable: APut it on your arms by using the wrist strap.(this method is usually suitable to outdoor working or or indoor camera lens adjustment in construction field)⑵ Portable: BHanging the machine at your waist.（3） Fixing on wall :Fix the machine on wall by using the wall bracket.（4）Normal MethodOpen the multi-function bracket to stand the machine on the table-board.2.OPERATION1、Put the batteries into machine according to the direction marked with “+” “-”.2、Insert the A V cable 1 (including power output cable) to the jack in position 9of the illustration. And then connect the red RCA connecter to video signal port, and the white one to audio port.3、Switch the power switch to “ON” side.4、If you need to output A V signal , insert A V cable 2 to the jack in position 10 of the illustration. Yellow cable for video output, white one for audio output.5、If powerless, you can charge it as it’s working. Conn ect the charger to position 7 of the illustration.6、When the image comes to be normal, you can adjust it by key 3、4、5 and 6.showed in the illustration.SpecificationTrouble shootingBefore calling for repair, please refer to this section to see whether you can solve it by yourself; if you need help, please contact our after sale service centre or our wholesaler.。
深圳鸿佳科技目前开发出兼容信利和统宝的3.5寸半透半反液晶屏，分辨率：640*480，带触摸屏，已经大批量生产，可按客户的要求更改FPC的规格和定制开模，并保证长期稳定供货。
3.5寸半透半反液晶屏除了可再室内正常显示外，白天可在室外阳光强烈的环境下无需点亮背光灯也可出色显示信息。
由于可将背照灯的使用率降至最低，因此还可大幅削减嵌有该模块产品的耗电量和延长背光LED灯的使用寿命，目前我司的产能可满足广大客户对3.5寸半透半反液晶屏的需求。
半反半透屏幕基本原理：半反半透的秘密就是在于半反射膜。
就像有些大楼的玻璃、一些太阳镜和汽车的贴膜。
正面是镜子（能反射阳光，提供阳光下阅读光源）。
而镜子的背面却能看穿这个镜子（为屏幕背光提供通道）。
一般屏幕按照“照明方式”分为：全透型和半透半反型全透型屏幕——屏幕背面没有反光镜，靠背光提供光源。
优点：弱光、无光下阅读能力优秀。
缺点：在户外阳光下背光亮度严重不足。
单纯依靠提高背光亮度，会急速损失电量，而且效果也非常不理想, 单纯通过提高LED灯的亮度来实现半透，这样是不可行的，只会缩短LED灯的寿命，减少电池的续航能力和增加功耗。
半反射型屏幕——就是将反射型屏幕的背面的反光镜换成镜面反光膜。
且加入全透型的背光；可以说半反半透屏幕是反射型屏幕和全透型屏幕的混血儿。
集中了两者的优点，兼具反射型屏幕在户外阳光下的优秀阅读能力，和全透型在弱光和无光下阅读的优异能力。
3.5寸半反半透屏幕的特性是：背光亮度自动适应户外环境。
户外阳光有多强，反射膜反射的背光（阳光）就有多强。
再强的户外日光亮度也不怕，环境光越强，反射的背光就越强，在户外可以完全不依赖额外背光照明设备，所以在户外比全透型屏幕要省电很多，而且阅读效果也好很多。
半反半透屏，技术成熟，但价格昂贵，国内很少有厂家有生产，除了价格因素外，还一个是因为工艺要求比较复杂，首先屏幕必须在本身材质的基础上还必须加上反射材质做一个反射膜，其次还必须同时具有发光板，这让它成为了融合反射屏与透射屏的优点，但却没有两者缺点的屏幕，在户外白天太阳下面，太阳越大，你看的越清楚，而没有太阳光的时候，你当然也看的很清楚嘛，至于晚上，那就更不用说了，一样清楚。
ITEMCONTENTSUNITLCD Type TFT/Transmissive/Normally white / Size3.5Inch Viewing Direction12:00 (without image inversion) O’ Clock Gray Scale Inversion Direction 6:00O’ Clock Number of Dots 320 x (RGB) × 240 / Driver ICBT81x / Interface TypeSPI/QSPI/ Module Memory Size 1 MB (BT81x) + 64 Mb (external flash) / Color Depth16.7M/ Pixel Arrangement RGB Vertical Stripe/ Surface Treatment Anti-glare / Clear (for CTP) / Input Voltage3.3V3.5” EVE3 SERIES LCD TFTRiTFT-35 seriesRev.1.0 2018-10-22L C D T F T M o d u l e S p e c i f i c a t i o nNote 1: RoHS, REACH SVHC compliant Note 2: LCM weight tolerance: ± 5%.CONTENTS (2)1 MODULE CLASSIFICATION INFORMATION (3)2 ASSEMBLY GUIDE - INTEGRATION (3)2.1 Mounting frame (4)3 MODULE DRAWING (4)4 ABSOLUTE MAXIMUM RATINGS (5)5 ELECTRICAL CHARACTERISTICS (5)6 BACKLIGHT CHARACTERISTICS (5)7 ELECTRO-OPTICAL CHARACTERISTICS (5)8 INTERFACE DESCRIPTION (7)9 BT8x CONTROLLER SPECIFICATIONS (8)9.1 Serial host interface (8)9.2 Block Diagram (8)9.3 Host interface SPI mode 0 (9)9.4 Backlight driver block diagram (9)10 LCD TIMING CHARACTERISTICS (9)10.1 Clock and data input time diagram (9)10.2 Parallel RGB timing table (11)11 TOUCH SCREEN PANEL SPECIFICATIONS (11)11.1 Electrical characteristics (11)11.1.1 For capacitive touch panel (11)11.1.2 For resistive touch panel (12)11.2 Mechanical characteristics (12)11.2.1 For capacitive touch panel (12)11.2.2 For resistive touch panel (13)12 INSPECTION (13)12.1 Inspection condition (13)12.2 Inspection standard (14)13 RELIABILITY TEST (17)14 LEGAL INFORMATION (18)1. BRAND RV – Riverdi2. PRODUCT TYPE T – TFT StandardF – TFT Custom3. DISPLAY SIZE 35– 3.5”4. MODEL SERIAL NO. A (A-Z)5. RESOLUTION H– 320x240 px6. INTERFACE B – TFT + Controller BT81x7. FRAME N – No FrameF – Mounting Frame8. BACKLIGHT TYPE W – LED White9. TOUCH PANEL N – No Touch PanelR – Resistive Touch Panel C – Capacitive Touch Panel10. VERSION 00(00-99)RiTFT-35-RES RVT35AHBNWR00 BT816, resistive touch panelRiTFT-35-CAP RVT35AHBNWC00 BT815, capacitive touch panelRiTFT-35-FR RVT35AHBFWN00 BT816, no touch panel, mounting frame RiTFT-35-RES-FR RVT35AHBFWR00 BT816, resistive touch panel, mounting frame RiTFT-35-CAP-FR RVT35AHBFWC00 BT815, capacitive touch panel, mounting frame2.1Mounting frameFor dimension s 3.5”, 4.3”, 5.0” and 7.0” the product with mounting frame version is available. Thanks to the four catches attached to the side, frame provides strong assembly to the surface by mounting element (like the screw, see Figure 3). The frames are specially designed to fit Riverdi products perfectly. The diameter of the mounting hole is 3.5mm.Figure 1. Mounting frameRiTFT-35 series3MODULE DRAWING `` RiTFT-35© 2018 Riverdi Page 4 of 24 RiTFT-35 seriesRiTFT-35-FR© 2018 Riverdi Page 5 of 24 RiTFT-35 seriesRiTFT-35-CAP© 2018 Riverdi Page 6 of 24 RiTFT-35-CAP-FR© 2018 Riverdi Page 7 of 24 RiTFT-35-RES© 2018 Riverdi Page 8 of 24 RiTFT-35-RES-FR© 2018 Riverdi Page 9 of 24 4ABSOLUTE MAXIMUM RATINGSPARAMETER SYMBOL MIN MAX UNITSupply Voltage for Logic VDD 0 4.0 V Supply Voltage for LED Inverter BLVDD 0 7.0 VInput Voltage for Logic VIN 0 4.0 VLED forward current (each LED) IF - 25 mA Operating Temperature T OP-20 70 °C PARAMETER SYMBOL MIN TYP MAX UNIT NOTES Supply Voltage For Module VDD 3.0 3.3 3.6 VInput Voltage for LED Inverter BLVDD 2.8 5.0 5.5 VLED Backlight Current IDD backlight- 150 187 mA BLVDD=3.3V LED Backlight Current IDD backlight- 93 117 mA BLVDD=5V Input Voltage ' H ' level V IH0.7VDD - VDD VInput Voltage ' L ' level V IL0 - 0.2VDD VInput Current I In TBD mAInput Current for module with CTP I InC TBD mAITEM SYMBOL MIN TYP MAX UNIT Voltage for LED backlight V l- 19.2 20.4 V Current for LED backlight I l- 20 25 mA LED Life Time - 30000 50000 - HrsLNote 1. Contrast Ratio(CR) is defined mathematically as below, for more information see Figure .Contrast Ratio =Average Surface Luminance with all white pixels (P1,P2,P3,P4,P5) Average Surface Luminance with all black pixels (P1,P2,P3,P4,P5)Note 2. Surface luminance is the LCD surface from the surface with all pixels displaying white. For more information, see Figure .Lv = Average Surface Luminance with all white pixels (P1, P2, P3, P4, P5)Note 3.The uniformity in surface luminance δ WHITE is determined by measuring luminance at each test position 1 through 5, and then dividing the maximum luminance of 5 points luminance by minimum luminance of 5 points luminance. For more information, see Figure .δ WHITE =Minimum Surface Luminance with all white pixels (P1,P2,P3,P4,P5) Maximum Surface Luminance with all white pixels (P1,P2,P3,P4,P5)Note 4. Response time is the time required for the display to transition from white to black (Rise Time, Tr) and from black to white (Decay Time, Tf). For additional information see FIG 1. The test equipment is Autronic-Melchers’s ConoScope series.Note 5.CIE (x, y) chromaticity, the x, y value is determined by measuring luminance at each test position 1 through 5, and then make average value.Note 6. Viewing angle is the angle at which the contrast ratio is greater than 2. For TFT module the contrast ratio is greater than 10. The angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD surface. For more information see Figure .Note 7. For viewing angle and response time testing, the testing data is based on Autronic-Melchers’s ConoScope series. Instruments for Contrast Ratio, Surface Luminance, Luminance Uniformity, CIE the test data is based on TOPCON’s BM-5 photo detector.Note 8. For TFT module, Gray scale reverse occurs in the direction of panel viewing angle.Figure 2. The definition of response timeFigure 3. Measuring method for Contrast ratio, surface luminance, Luminance uniformity, CIE (x, y) chromaticityFigure 4.The definition of viewing angle8INTERFACE DESCRIPTION9BT8x CONTROLLER SPECIFICATIONSBT8x or EVE3 (Embedded Video Engine 3) simplifies the system architecture for advanced human machine interfaces (HMIs) by providing functionality for display, audio, and touch as well as an object oriented architecture approach that extends from display creation to the rendering of the graphics.9.1Serial host interfaceFigure 5.SPI interface connection Figure 6. QSPI interface connectionSPI Interface– the SPI slave interface operates up to 30MHz.Only SPI mode 0 is supported. The SPI interface is selected by default (MODE pin is internally pulled low by 47k resistor).9.2Block DiagramFigure 7.. BT8x Block diagram9.3Host interface SPI mode 0Figure 8. SPI timing diagramFor more information about BT8x controller please go to official BT8x website.https:///Products/ICs/BT81X.html9.4Backlight driver block diagramBacklight enable signal is internally connected to BT8x Backlight control pin. This pin is controlled by two BT8x’s registers. One of them specifies the PWM output frequency, second one specifies the duty cycle. Refer to BT8x datasheet for more information.Figure 9. Backlight driver block diagram10LCD TIMING CHARACTERISTICS10.1Clock and data input time diagramFigure 10. DE mode timing diagramBT8xFigure 11. SYNC mode timing diagramFigure 12. Timing diagram10.2Parallel RGB timing tableTiming parameter (VDD=3.3V, GND=0V, Ta=25˚C)PARAMETER SYMBOL MIN TYP MAX UNIT CONDITION CLK Clock Time T clk 1/Max(F CLK) - 1/Min(F CLK) ns -11TOUCH SCREEN PANEL SPECIFICATIONS11.1Electrical characteristicsNote: Avoid operating with hard or sharp material such as a ball point pen or a mechanical pencil except a polyacetal pen (tip R0.8mm or less) or a fingerITEM VALUE UNIT REMARKMin. Typ. Max.Linearity - - 1.5 % Analog X and Y directions Terminal Resistance 200 - 900 ΩX100 - 600 ΩY11.2Mechanical characteristicsNote 1: Force test condition, Input DC 5V on X direction, Drop off Polyacetal Stylus (R0.8), until output voltage stabilize, then get the R8.0mm Silicon rubber and do finger Activation force test. Next step, 9 points.Note 2: Measurement surface area conditions, Scratch 100,000 times straight line on the film with a stylus change every 20,000 times with Force: 250gf, Speed: 60mm/sec by R0.8 polaceteal stylus.Note 3: Pitting test, Pit 1, 000, 000 times on the film with R0.8 silicon rubber with Force: 250gf and Speed: 2 times/sec.Note 1: Force test condition, Input DC 5V on X direction, drop off Polyacetal Stylus (R0.8), until output voltage stabilize, then get the R8.0mm Silicon rubber and do finger Activation force test. Next step, 9 points.ITEM VALUE UNIT REMARKMin. Typ. Max.12INSPECTIONStandard acceptance/rejection criteria for TFT module.12.1Inspection conditionAmbient conditions:•Temperature: 25±°C•Humidity: (60±10) %RH•Illumination: Single fluorescent lamp non-directive (300 to 700 lux)Viewing distance:35±5cm between inspector bare eye and LCD.Viewing Angle:U/D: 45°/45°, L/R 45°/45°12.2Inspection standard Item Criterion Black spots, whitespots, light leakage,Foreign Particle(round Type)D=(x+y)2*Spots density: 10 mmSize < 5”Average Diameter Qualified QtyD < 0.2 mm Ignored0.2 mm < D < 0.3 mm 30.3 mm < D < 0.5 mm 20.5 mm < D 0Size >= 5”Average Diameter Qualified Qty D<0.2 mm Ignored0.2 mm < D < 0.3 mm 40.3 mm < D < 0.5 mm 20.5 mm < D 0Clear spotsSize >= 5”Average Diameter Qualified Qty D<0.2 mmIgnored 0.2 mm < D < 0.3 mm 4 0.3 mm < D < 0.5 mm 2 0.5 mm < D*Spots density: 10 mm Size < 5”Average Diameter Qualified Qty D < 0.2 mmIgnored 0.2 mm < D < 0.3 mm 3 0.3 mm < D < 0.5 mm 2 0.5 mm < D 0Polarizer bubblesSize < 5”Average Diameter Qualified Qty D < 0.2 mmIgnored 0.2 mm < D < 0.5 mm 3 0.5 mm < D < 1 mm 2 1 mm < D 0 Total Q’ty 3Size >= 5”Average Diameter Qualified Qty D<0.25 mmIgnored 0.25 mm < D < 0.5 mm 3 0.5 mm < D 0Electrical Dot DefectSize < 5”itemQualified Qty Black do defect 4 Bright dot defect 2 Total Dot 5Size >= 5”itemQualified Qty Black do defect 5 Bright dot defect 2 Total Dot 5Touch panel spotSize < 5”Average Diameter Qualified QtyD < 0.2 mm Ignored0.2 mm < D < 0.4 mm 50.4 mm < D < 0.5 mm 213RELIABILITY TESTNO. TEST ITEM TEST CONDITION REMARKS1 High Temperature Storage 80±2°C/240hours Note 22 Low Temperature Storage -30±2°C/240hours Note 1,2Note 1: Without water condensation.Note 2:The function test shall be conducted after 2 hours storage at the room temperature and humidity after removed from the test chamber.14LEGAL INFORMATIONRiverdi makes no warranty, either expressed or implied with respect to any product, and specifically disclaims all other warranties, including, without limitation, warranties for merchantability, non-infringement and fitness for any particular purpose. Information about device are the property of Riverdi and may be the subject of patents pending or granted. It is not allowed to copy or disclosed this document without prior written permission.Riverdi endeavors to ensure that the all contained information in this document are correct but does not accept liability for any error or omission. Riverdi products are in developing process and published information may be not up to date. Riverdi reserves the right to update and makes changes to Specifications or written material without prior notice at any time. It is important to check the current position with Riverdi.Images and graphics used in this document are only for illustrative the purpose. All images and graphics are possible to be displayed on the range products of Riverdi, however the quality may vary. Riverdi is no liable to the buyer or to any third part for any indirect, incidental, special, consequential, punitive or exemplary damages (including without limitation lost profits, lost savings, or loss of business opportunity) relating to any product, service provided or to be provided by Riverdi, or the use or inability to use the same, even if Riverdi has been advised of the possibility of such damages.Riverdi products are not fault tolerant nor designed, manufactured or intended for use or resale as on line control equipment in hazardous environments requiring fail – safe performance, such as in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control, direct life support machines or weapons systems in which the failure of the product could lead directly to death, personal injury or severe physical or environmental damage (‘High Risk Activities’). Riverdi and its suppliers specifically disclaim any expressed or implied warranty of fitness for High Risk Activities. Using Riverdi products and devices in 'High Risk Activities' and in any other application is entirely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold harmless Riverdi from any and all damages, claims or expenses resulting from such use. No licenses are conveyed, implicitly or otherwise, under any Riverdi intellectual property rights.。
广州大彩光电科技有限公司版权所有版本记录销售与服务广州大彩光电科技有限公司电话：************-601传真：************Email：*************（咨询和支持服务）网站：地址：广州黄埔区（科学城）玉树华新园C栋3楼网络零售官方旗舰店：https://目录1. 硬件介绍 (1)1.1产品外观 (1)1.2硬件配置 (1)1.3调试工具 (2)2. 产品规格 (3)3. 产品尺寸 (5)4. 引脚定义 (6)5. 可靠性测试 (7)5.1ESD测试 (7)5.1.1执行标准 (7)5.1.2测试环境 (7)5.1.3测试数据 (8)5.2高低温老化测试 (8)5.2.1测试环境 (8)5.2.2测试数据 (9)5.3群脉冲测试 (9)5.3.1执行标准 (9)5.3.2测试环境 (9)5.3.3测试数据 (9)5.4辐射测试 (10)5.4.1执行标准 (10)5.4.2测试环境 (10)5.4.3测试数据 (10)6. 型号定义 (12)7. RS232与TTL电平转换 (13)8. 协议配置 (14)9. LUA脚本配置 (15)10. 包装与物理尺寸 (16)11. 产品架构 (17)12. 开发软件 (18)12.1什么是虚拟串口屏 (18)12.2Keil与虚拟串口屏绑定调试 (19)13. 开发文档 (20)14. 免责声明 (21)1. 硬件介绍本章节主要介绍产品的一些外观参考图、硬件配置图和调试所需工具。
1.1 产品外观以下为该尺寸不同型号的外观参考图，如图1-1、图1-2所示。
注：未涉及关键结构工艺修改或布局大调整，仅产品工艺或可靠性方面的变更迭代，公司不予对外发起变更，具体以收到的实物为准。
图1-1 3.5寸电阻触摸参考图图1-2 3.5寸无触摸参考图1.2 硬件配置以下为该尺寸产品硬件配置参考图，以电阻屏举例说明，如图1-3所示。
图1-3硬件配置图销售咨询：************-601Email:*************1.3 调试工具以下为该产品调试工具参考图，以电阻屏举例说明，如图1-4所示。
手机屏幕尺寸和分辨率一览表VGA系列：VGA、QVGA、WVGA、HVGA名词解释及区别：深圳鸿佳科技股份有限公司专注于工业类、手持设备和医疗、军工、通讯、车载等工控产品液晶显示屏（LCD）、液晶显示模组（LCM）的研发、生产和销售.......续VGA后，逐渐诞生出QVGA、WVGA、HVGA分辨率产品，这分辨率都手机参数里随处可见，下面是VGA、QVGA、WVGA、HVGA分名词解释及区别：VGA即“Video Graphics Array”。
是IBM在1987年随PS／2机一起推出的一种视频传输标准，具有分辨率高、显示速率快、颜色丰富等优点，在彩色显示器领域得到了广泛的应用。
VGA最早指的是显示器640X480。
VGA的英文全称是Video GraphicArray，也叫显示绘图阵列。
多普达手机中S900C+就是典型的QVGA即"Quarter VGA"。
中VGA的四分之一尺寸，亦即在液晶屏幕（LCD）上输出的分辨率是240×320像素。
QVGA支持屏幕旋转，可以开发出相应的程序，以显示旋转90°、180°、270°屏幕位置。
由HandEra公司发布。
多用于手持/移动设备。
WVGA即“Wide VGA”。
其分辩率为800×480象素。
是扩大了VGA（640×480)的分辨率。
应用于PDA和手机等，因为很多网页的宽度都是800，所以WVGA的屏幕会更加适和于浏览网页，可以说是未来手持设备的分辨率的大趋势。
HVGA即“Half-size VGA”。
是VGA的一半,分辨率为(480*320),(3:2宽高比)，它是用于各种各样的PDA设备，首先是2002年的索尼Clie PEG - NR70，黑莓手机也有HVGA的,iPhone也是HVGA 设备。
全球第一款Google手机，T-Mobile G1配备有3.2英寸HVGA（320×480像素）分辨率的全触控式屏幕：手机屏幕VGA QVGA HVGA WVGA区别，一般手机液晶屏幕都是TFT材质，VGA WVGA QVGA HVGE XGA只是表示屏幕分辨率只，是个代号和材质没关系。
关于五代线、六代线与七代线高鸿锦李军北京清华液晶技术工程研究中心这两年中国液晶行业取得了突破性进展。
上广电、京东方先后建成TFT-LCD 5代线并正式投产。
今年江苏昆山5代线又在紧锣密鼓地建设。
据报道上广电、京东方这条线的成品率和产品质量都已达到很不错的水平，产品已经出口国外。
应该说，从技术和管理组织层面上讲，上广电、京东方的工作是一流的，无可非议的。
无疑是取得了了不起的成绩。
但是去年以来世界TFT产品市场出现供过于求的问题，产品价格急剧下跌，造成大批企业亏损。
上广电、京东方也难以幸免，今年上半年这两家企业都不同程度的亏损。
这就引来行业内外广泛议论，5代线该不该上？今后往那儿去？本文试图就这些问题谈谈我们个人的初浅看法。
一、5、6、7代线间的差异下表给出五、六、七各代生产线上比较典型的生产线玻璃规格、以及相应的投资规模。
由于生产线的经济效益直接取决于玻璃尺寸的面积，因此比较各代生产线玻璃尺寸面积是比较其生产效益的非常有效的手段。
五代线、六代线与七代线的比较五代线六代线七代线典型尺寸（mm） 1100*1300 1500*1850 1870*2200面积（mm2） 1,430,000 2,775,000 3,916,000面积比 1 1.94 2.73投资 12亿美元或100亿人民币 20亿美元或160亿人民币 30亿美元或250亿人民币从2002年起，日本、韩国、中国（包括大陆和台湾）投入巨资建设5代及5代以上TFT-LCD生产线。
据不完全统计,已有的或正在建设的5代线12条，6代线4条，7代线4条。
8代也有2条列入议事日程。
关于5、6、7代之间技术上的差别，现在有关公司很少披露，业内一般认为单从阵列、制盒等通用工艺技术而言不应该有太大的差别，只是代数越高，对质量控制要求越高，对净化环境要求越高，否则成品率将有影响。
如果说不同代数之间有技术差别的话，不如更确切地说是最终产品的技术差别。
5、6、7代之间阵列制作大同小异，但是不同最终产品，产品性能指标要求不同，相应地液晶排列模式不同，所用液晶材料和成盒工序的工艺路线也就不同。
手机屏幕尺寸和分辨率一览表屏幕尺寸分辨率代号像素密度备注（英寸）2.8640x480VGA286PPI3.2480x320HVGA167PPI3.3854x480WVGA297PPI3.5480x320HVGA165PPI3.5800x480WVGA267PPI3.5854x480WVGA280PPI3.5960x640DVGA326PPI苹果iphone43.7800x480WVGA252PPI3.7960x540qHD298PPI4.0800x480WVGA233PPI4.0854x480WVGA245PPI4.0960x540qHD275PPI4.01136x640HD330PPI苹果iphone54.2960x540qHD262PPI4.3 800x480WVGA217PPI4.3 960x640qHD268PPI4.3 960x540qHD256PPI4.3 1280x720HD342PPI4.5 960*540qHD245PPI4.5 1280x720HD326PPI4.5 1920x1080FHD490PPI4.7 1920x1080FHD490PPI4.81280x720HD306PPI5.0480x800WVGA186PPI1024x768XGA256PPI5.01280*720294PPI5.05.01920x1080FHD207PPI5.31280x800 WXGA285PPI5.3960x540qHD207PPI6.0854×480163PPI6.01280 X 720 245PPI6.02560×1600498ppi7.0800x480128PPI7.01024*600169PPI7.01280*800216PPI9.71024x768XGA132ppi9.72048x1536264PPI101200X600170ppi102560x1600299ppiVGA系列：VGA、QVGA、WVGA、HVGA名词解释及区别：深圳鸿佳科技股份有限公司专注于工业类、手持设备和医疗、军工、通讯、车载等工控产品液晶显示屏（LCD）、液晶显示模组（LCM）的研发、生产和销售.......续VGA后，逐渐诞生出QVGA、WVGA、HVGA分辨率产品，这分辨率都手机参数里随处可见，下面是VGA、QVGA、WVGA、HVGA分名词解释及区别：VGA即“Video Graphics Array”。
ft3519规格摘要：一、引言二、ft3519 的规格概述1.产品尺寸2.显示器参数3.硬件配置4.电池续航能力5.摄像头性能6.接口与连接能力三、ft3519 在行业中的应用1.工业自动化2.医疗设备3.智能家居4.交通运输四、ft3519 的优缺点分析1.优点2.缺点五、结论正文：【引言】随着科技的飞速发展，各种规格的嵌入式设备应运而生，以满足不同行业和领域的需求。
ft3519 是一款备受关注的嵌入式设备，具有高性能、多功能、易扩展等特点。
本文将对ft3519 的规格进行详细介绍，并探讨其在行业中的应用及优缺点。
【ft3519 的规格概述】ft3519 采用了紧凑的设计，尺寸适中，便于安装和携带。
其显示器参数表现出色，无论是分辨率还是屏幕尺寸，都能满足大部分应用场景的需求。
硬件配置方面，ft3519 搭载了高性能的处理器，可确保设备稳定运行。
电池续航能力是ft3519 的一大亮点，长效续航能力使得设备在断电情况下依然可以正常工作。
摄像头性能优越，可提供高清晰度的视频画面。
此外，ft3519 具备丰富的接口与连接能力，可轻松与其他设备或网络连接。
【ft3519 在行业中的应用】ft3519 在多个行业中都有着广泛的应用。
在工业自动化领域，ft3519 可以作为监控和控制设备，提高生产效率。
在医疗设备领域，ft3519 可以作为诊断和治疗工具，提高医疗服务质量。
在智能家居领域，ft3519 可以作为智能控制中心，实现家庭设备的联动。
在交通运输领域，ft3519 可以作为监控和导航设备，提高交通安全性。
【ft3519 的优缺点分析】ft3519 的优点包括高性能、多功能、易扩展等。
这些优点使得ft3519 在各种应用场景中都能发挥出良好的性能。
然而，ft3519 也存在一定的缺点，如价格较高、软件兼容性有待提高等。
这些缺点在很大程度上限制了ft3519 在某些领域的应用。
【结论】综上所述，ft3519 作为一款嵌入式设备，具有较高的性能和广泛的应用领域。
In/On-Cell/OGS屏幕全面解析深圳鸿佳科技专注于中小尺寸TFT液晶显示屏、LCD液晶显示模块、触摸屏的研发、设计、生产和销售。
产品涵盖了TN、HTN、STN、FSTN、TFT、OLED、触摸屏等系列；其中TFT液晶屏主要有：1.77寸、2.0寸、2.0寸横屏、2.2寸、2.4寸、2.8寸、3.2寸、3.5寸、3.97寸、4.3寸、5寸、5.6寸、7寸、9.7寸、10.1寸等；黑白液晶屏主要有：字符、图形、中文字库等标准或非标准模块。
产品广泛应用于仪器仪表、医疗设备、电力设备、通讯设备、家用电器、工业控制、消费电子、POS 机、手持设备等多个领域。
关于屏幕概念的炒作，从之前的IPS、AMOLED、SLCD的面板之争，到现在清一色标榜自己是OGS全贴合屏幕，如何如何轻薄、透光、图像“浮现”在屏幕上，苹果则貌似更为“高端”，传出了In-cell/On-cell的概念。
煮机做这期关于OGS/In-Cell/On-Cell屏幕的科普，力求通俗易懂，望以最简单的方式让大家了解真相。
要彻底了解In-Cell/On-Cell/OGS等等屏幕，就得先知道屏幕的基本结构组成。
从上到下，屏幕的基本结构分为三层，保护玻璃（最上面橙黄色标注了Cover glass的部分），触控层（图中一点点淡蓝色虚线，标注了X、Y的部分)，显示面板。
保护玻璃没什么好说的，康宁大猩猩玻璃就是。
触控层的话，就是由ITO触控薄膜和ITO玻璃基板组成。
显示面板可细分的程度高，这里只大致排列下：从上到下，分别是上玻璃基板（粉红色标注了Color filiter的区域，即彩色滤光基板），液晶层（蓝条），下玻璃基板（粉红色标注了Array的区域，即薄膜电晶体基板）。
最后，还需要指出的是，保护玻璃/触控层与显示面板之间，一般贴合技术会形成一层空气（即图中标注了Bonding的金黄色区域），如果采用全贴合技术去除这层空气，屏幕反光会大大减少，点亮屏幕时就显得更为通透，熄屏时更加黑沉，没有灰白的观感。
正面/FRONT背面/REAR HTM-TFT035A-EZUI-RTPHTM-TFT035A-EZUI-RTP.1The biggest features of EzUILet series modules are easy to use,rich functions,andusers can be simple and ers can use the interface development tool software (EzUITool)for human-computer interface design,editing,control configuration,response setting,etc.,the tool software generated resources files download to EzUILet series modules,can achieve the required human-computer interface design,without the user microcontroller or other controller programming control.In order to meet users with special requirements,the EzUILet series module also retains most display control instructions (similar to the MzTH series module),so that users can be able to control the module display more freely EzUILet 035is one of the EzUI series serial port intelligent display module,witha 3.5-inch (diagonal)color TFT,display,320480dot matrix,16-bit color depth;16M bytes inside the module with resource memory.The module needs 5V DC power supply,the external interface is serial UART (TTL level),interface or SPI interface,simple interface and easy interface operation with various MCU..EzUILet series and EzUI series:EzUILet series modules are derived from EzUI series modules and also belong to EzUI series modules;relative to EzUI series modules,EzUILet series simplifies some controls,and changes the module USB device interface to virtual serial port,resource files are written differently from the original EzUI series;EzUILet series modules also reduce the capacity of resource memory more reasonable and more reliable.The naming of the GUI controls in the EzUILet series modules still uses the EzUI series module naming.UART,serial interface (TTL level)or SPI interface mode,interface mode and UART wave rate are configured in the resource file;Support TF card offline resource file download,support USB interface resource file burning,support online synchronous debugging;Standard version module built-in 16M bytes size resource memory,28K bytes dynamic RAM area;Vertical /horizontal screen display,as determined by the resource file configuration;Resistance to the touch screen selection;The module interior comes with 610,816,1020,1632point ASCII code west text library;Support basic drawing instructions (drawing points,lines,rectangle,circle,string display,bitmap display,etc.);resource memory supportsmultiple attribute configuration,control message response can beconfigured;Support bitmap button control,a variety of attribute configuration,control message response can be configured;Support numerical controls(integer,floating point number can be),a variety of attribute configuration,support numerical input;Support string control(both in English),a variety of attribute configuration;Support the pop-up drop-down check box control,the control message response can be configurable;Support the waveform control,allowing up to four waveform lines in the same ID number control;Support progress bar control,control message response is configurable,support superposition display value/string control;Support the bitmap animation control,and the control message response isconfigurable.1HTM-TFT035A-EZUI-RTP.2The basic parameters of the EzUILet035module are listed as follows:project specifications unit Note that Displays thenumber of dotarrays320×RG B×480Do ts Screen display LCD size.53(Diagonal line)inchTouch thepanelA 3.5-inch electricresistance screenoutlinedimension57×98×8.0m m Excluding modulepinsDynamicdisplay area48.96×73.44m mLike elementcompositiona-Si TFTLCD pattern65K TFT The16-bit colordepthbe in apoor lightwhite LEDModule powersupply5VExtreme electrical appliance characteristics:parameter symbolminimum maximum unitservice voltage VD D0.37Vinput voltage V in-0.3Vdd+0.3Voperatingtemperature rangeTopr-2070℃storagetemperatureT str-3080℃operating characteristic of electrical apparatus:parameter symbolcondition minimum typicalcasemaximumunit working voltage V dd－ 4.25 5.6VinputvoltageHigh Level V ih—0.8Vdd V dd VLow Level V ilV ss0.2Vdd Module operating current:(5V power supply,operating temperature of25°C) parameter symbo condition minimu typica maximu unit产品经可靠性测试后，仅保证功能正常，无任何致命缺陷（不显示、线路缺陷、显示异reliability test,the product only guarantee functiondefect(non-display,line defect,abormal display etc).。
YS35C006YS35C006 液晶显示模组规格书SPECIFICATIONRevision ：0.1YS35C006This module uses ROHS materialCUSTOMER:Approved by:Approved by:深圳鸿佳科技股份有限公司深圳雅顺光电科技有限公司 Version: 0. Version: 0. Version: 0.1 1 1 20 20 20113-8-01YS35C006YS35C006 液晶显示模组规格书Revision RecordRev Nodate DescriptionV0.1 2013-08-1Preliminary Specification Release深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书CONTENTS1.General Description2.Genreal Features3. Block Diagram4.Pin Description5.Absolute Maximum Ratings6. Electrical Specification 6.1 DC Characteristics6.2 back blight circuit characteristics7. Optical Specification7.1 LCD optical Characteristics 7.2 Measurement system 8.Application Circuit 9.Initial Code10．Reliability and inspection standard 10.1 Environment test(reliability test) 10.2 Ultraviolet radiation irradiation test 10.3 Mechanical test10.4 Electron magnetic compatibility 11．Inspection standard12.Caution and handing precaution 13.Installation in assembly13.1 ESD(electro-static discharge) prevention 13.2 Dust and stain prevention13.3 Installing lcd module to the enclosure 13.4 Mechanical forces 13.5 Operation14 .Transportation and storage 15.Outline dimensionWritten by Checked by Approved byJAMESALLAN ROY深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书1. General DescriptionThe YS35C006-A model is a color TFT LCM.thismodule has a 3.5 inch diagonally measured active area with HFVGA(320 horizontal by 480 vertical pixel array).each pixel is divided into red,green,blue dots which are arranged in vertical stripe and this module can display 262K colors.2.General FeatureItemMain DisplayRemark Display Mode Normally white,Transmissive LCD Viewing direction 12:00 o ′clockDriving method a-si TFT active matrix Input signals8 Bit CPU interfaceOutside dimensions 55.04mm(W)х83.15mm(H)х2.6mm(D) Active Atea48.96mm(W)х73.44mm(H) Number of Pixels (320xRGB)х480 pixels Pixel Pitch0.15mm(W)х0.15mm(H) Pixel Arrangment RGB vertical stripes WeightTBD3. Block DiagramＩＣDriver IC ILI9488 ＩＬＩ９４８１深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书4.Pin DescriptionNo.SymbolDescription1 D7 Data bus2 D6 Data bus3 D5 Data bus4 D4 Data bus5 D3 Data bus6 D2 Data bus7 D1 Data bus8 D0 Data bus9 GND Ground10 RESET Reset signal,active low 11 CS Chip select signal12 RS Command/data select signal13 WR Write signal 14 RD Read signal 15 GND Ground16 VCC Power supply,3.3V 17 LED-K3 Backlight cathode 18 LED-K2 Backlight cathode 19 LED-K1 Backlight cathode 20LED-ABacklight anode深圳鸿佳科技股份有限公司深圳雅顺光电科技有限公司 Version: 0. Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101 YS35C006YS35C006 液晶显示模组规格书5．Absolute Maximum RatingsTa=25±5℃,Vss ＝GND=0Item Symbol Ratings UnitCondition Operating power V DD －0.3～4.6 V Operating temperature T OPR －20～70 Storage temperatureT STR－30～80℃No condensation6. Electrical Specification6.1 DC CharacteristicsV SS =0V ，V DD =2.85±0.05V ，T OPR =-20～70℃Item Symbol Conditio nMin. Typ. Max. UnitSupply power V DD 2.8 3.0 3.3 Input high voltage V IH 0.8V DD － V DD Input low voltage V IL 0 － 0.2V DD Output high voltage V 0H 0.8V DD － － Output low voltage V 0L － － 0.2V DD V Logic current consumption I DD － 4.5 6 mA Current consumption duringstandby mode Is－50－uA6.2 Backlight Circuit Characteristics(6 LEDs parallel connection):ItemSymbol Min Typ. Max. Unit Condition Operating voltage V LED 2.9 3.2 3.5 V I LED =90 mAOperating current I LED － 90 － mA - Back blight luminance40004500－cd/m 2I =90 mA深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书7. Optical SpecificationOptical characteritics are determind after the unit has been on and stable for approximately 30 minutes dark environment at 25℃.the value specified are at an approximate distance 500mm from the lcd surface at a viewing angle and θ equal to 07.1 LCD Optical CharacteristicsTa=25℃parameter Symbol Condition MinTyp Max Unit Φ= 90°- 60 - Φ= 270°- 65 - Φ= 0°- 65 - Viewing Angle Φ= 180°θ Cr ＞10- 45 - deg Contrast ratio Cr - 350 -Respone time Tr+Tf - 25 - msSurface Luminance Lv θ=0Φ=0- 290 - Cd/m2X 0.608 0.628 0.648REDY 0.307 0.327 0.347 X 0.267 0.287 0.307GREEN Y0.542 0.562 0.582 X 0.116 0.136 0.156BLUEY 0.106 0.126 0.146 X 0.283 0.303 0.323CIE(x,y) chromaticty WHITEY θ=0 Φ=0 0.312 0.332 0.3527.2Measurement system (1)LCD Viewing Angle深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书5viewing angle is the angle at which the contrast ratio is greater than 10.the angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the lcd surface.(2) Response timeResponse time is the time required for the display to transition from white to black (Rising time, Tr) and from black to white (Falling time, Tf).for additional information(3)Contrast Ratio(CR)Contrast Ratio(CR) is defined mathematically as:Surface Luminance with all white pixels Contrast Ratio=Surface Luminance with all black pixelsSurface luminance is the center point across the lcd surface 500mm from the surface with all pixels displaying white. 深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书8. Application CircuitPlease consult our technical department for detail information.9. Initial CodePlease consult our technical department for detail information.10．Reliability and inspection standard10.1 Environment test(reliability test)Samples OK before testingTest item Test conditionHigh temperature storage 80℃，240 hr Low temperature storage -30℃，240 hr High temperature operation 70℃，160 hr Low temperature operation -20℃，160 hr High temperature and highhumidity operation40℃，93 %RH ，160 hrThermal shock -30℃ 25℃ 80℃ 25℃（30min ） (5min) (30min) (5min)20 cycleAfter completing the reliability tests.leave the samples under the room temperature and for the following inspection items:① No clearly visible defects or deterioration of display quality allowed. ② No function-related abnormalities.③ Connected parts still connecting tightly.④ Display characteristics fulfil initial value ，contrast ratio should be an least 30% of initial value. 深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书10.2 Ultraviolet radiation irradiation testAfter Samples irradiated by ultraviolet tradiation,have no deterioration of display quality10.3 Mechanical test 1)Vibration testTest item Test contentIn mobile telephone Reference mobile phone test standardfrequence/acceleration30Hz/2.5m/s 2 direction X 、Y 、Z 3 direction Vibration test （ packed ）time30min respectivelyAfter completing the vibration tests,the samples have No function-related abnormalities orstructure distortion .2) Shock testPeak accelationm/s2Pulseholding time msShock wave30011Half sine wave or back peak sawtoohwave or trapeziform waveAfter completing the shock tests,the samples have No function-related abnormalities or structure distortion .3)packing part drop testTest item Test contentheight 80cm Drop mode Freedom dropdrop （packed in a box ）Drop part1 corner/3 arris/6 face,1timerespectivelyAfter completing the packing part drop tests,the samples have no function-related深圳鸿佳科技股份有限公司Version: 0. Version: 0.1 1 1 20 20 20131313--8-0101YS35C006YS35C006 液晶显示模组规格书10.4 Electron magnetic compatibility Electrostatic withstanding voltageAfter air contact discharge （voltage ：±8KV ）and contact discharge directly （voltage:±4KV ）test ，the samples display ok ,and have no flicker 、white screen 、black screen 、blue screen etc.abnormity display.。
