霍尼韦尔 honeywell 2316 plus 说明书

SYSTEM 2316 用户手册前 言介绍SYSTEM2316是一种16防区可编程控制主机。

根据不同的需要，SYSTEM2316既可作为本地型主机使用，又可作为联网型主机投入运作。

具体采用何种工作模式，由编程决定。

该主机的编程方式亦很灵活：既能通过Alpha键盘或LED键盘进行编程，也可以通过指挥者2000/监察者2000软件进行遥控编程。

本手册覆盖范围本手册所介绍的是SYSTEM2316控制主机安装与编程的基本方法，有关遥控编程的内容请参见指挥者2000/监察者2000软件的用户手册。

主机安装安装SYSTEM2316应该装在便于接入交流电源、电话线和地线的位置处。

●从机箱上拆下电路板，以防止在敲击预制孔时损坏电路板。

●敲开机箱上的预制孔。

●在墙面上标出安装螺丝的孔位。

●在墙面上固定住机箱，将电缆穿过预制孔。

错误！未找到引用源。

装入电路板，注意在电路板的左下角接上地线焊片。

●再将接线片连接到机箱门下部合页处，使箱门接地。

接地为保证瞬时放电保护电路能正常工作，控制主机必须接地。

理想的地线应是电源线路、电话系统和防盗系统的公共地线，这种地线形式称为“统一接地”，保护性能最佳。

将与主机箱体相连的那根绿色导线接到接地棒、自来水管或其他接地装置上，即可实现主机箱体的接地。

主机接线备用电池☆备用电池SYSTEM2316配用的电池是12V，6.5AH密封铅酸电池(C&K1265)。

禁止使用非充电型或非密封铅酸型电池。

建议每隔3-5年更换一次备用电池。

将红色导线接到电池的正极，黑色导线接到电池的负极。

保险管F4备用电池由保险管F4（3A，3AG，速熔型）提供防反接保护。

☆交流电源端口（端子①和②）交流电源由一只16.5V AC，25-40V A，50/60HZ的变压器（UL标准2级）提供。

将变压器的初级直接接入交流供电线路，次级连接到端子①和②。

为减少压降至少应使用18AWG（直径1.02㎜）的导线进行连接。

域适都2316说明书产品简介：域适都238/2316 SUPER 是霍尼韦尔全新推出的支持电话线、网络、GPRS多网多报告或备份报告的高性价比新型8/16 防区控制主机。

该主机与IPM-23 SUPER网络通讯模块、MCM-23 SUPER无线网络（GPRS）通讯模块配合，可支持电话线、网络、GPRS无线网络等多种通讯方式，网络和电话报告可同时发送，也可互为备份。

主机支持8/16个防区并支持防区防拆功能。

作为一款网络化升级IP报警主机，238/2316 SUPER 保留了享誉中国安防市场的经典小型主机238C Plus II的全部功能和操作方法。

性能特点：多网多报、互为备份- 与IPM-23 SUPER网络通讯模块、MCM-23 SUPER无线网络（GPRS）通讯模块配合，可通过电话线或有线/无线网络与接警中心通讯，实现双报告、多报告（最多四个报告），也可互为备份。

网络通讯具心跳检查功能，系统通讯安全可靠。

远程反控-授权用户可以在任意场合，使用电脑登陆接警中心IP-Receive网络接警机的网络反控界面，对主机进行权限内的查看、遥控、编程等操作，方便用户对系统的使用和维护。

防区防拆-主机的每个防区都可设置成带防拆功能，探测器防拆开关可按要求接入对应防区，不再需要占用单独的防区。

副主码功能-拥有更改其他用户密码权限，但不可更改主码，不可以操作系统复位。

当主码和副主码密码一致时，只有主码有效。

增加防区类型-防区类型增加了2 4 小时匪警防区和2 4 小时火警防区，可发送不同的Contact ID码。

键盘内置蜂鸣器，作为故障、报警等事件提示LED键盘具备系统及防区状态LED灯况提示，ALPHA Plus II键盘具备LCD字符信息显示4路触发器输出，驱动外部继电器，可以和防区关联内置拨号器，通过电话直接报告到接警中心接收机，重拨时间与轮次可编程。

通过扩展网络通讯模块IPM-23 SUPER或MCM-23 SUPER，可通过网络报告到接警中心网络接警机，网络链接具心跳监测功能。

Honeywell 2316报警主机编程配置1.进入主机编程：输入012345*0#，即可进入主机编程2.退出主机编程：输入*#，即可退出主机编程3.16防区回路控制1F=回路1 20=回路2 21=回路3 22=回路4 23=回路524=回路6 25=回路7 26=回路8 49=回路9 4A=回路104B=回路11 4C=回路12 4D=回路13 4E=回路144F=回路15 50=回路164.每个防区的默认值：121 3231 F 12 13 2 3 # 323表示延时防区423表示长延时，2倍延时223表示即时防区923表示24小时防区5.触发器设置：74 02 0174：表示指令地址01：进入延时02：退出延时6.触发器时间设定：默认为：75 00 3075：表示指令地址数据位1：触发器时间---分钟(十位)数据位2：触发器时间---分钟(个位)数据位3：触发器时间---秒(十位)数据位4：触发器时间---秒(个位)常用设置为：75 02 00表示触发器时间设定为2分钟7.延时设置：默认为：2D 01 362362：表示进入延时30秒、外出延时60秒、警号持续时间5分钟2D：表示指令地址数据位1：挟持报告码数据位2：挟持报告接收机选择数据位3：进入延时1=10s 2=20s ... ... *4=140s *5=150s数据位4：外出延时1=10s 2=20s ... ... *4=140s *5=300s数据位5：警号持续时间1=2分钟2=5分钟3=10分钟4=15分钟5=30分钟常用设置为：2D 01 *2 *2 2表示：进入延时120s、外出延时120s、警号持续时间5分钟。

h o n e y w e l l报警主机说明Document serial number【UU89WT-UU98YT-UU8CB-UUUT-UUT108】2300系列报警主机Q1: 236、238、2316键盘无任何显示按键无反应A: （1）. 误将[安装员密码] [*] [69] [#]做为主机复位，主机被锁定。

请再用安装员密码（出厂设置012345） [*] [69] [#]操作一遍看结果如果仍不正常显示需找到直接供货商送修处理。

（2）. 主机的1、2端子是否有交流伏电压键盘电源端子是否有12伏直流电压如果检查伏电压不正常可能是220伏交流电源或变压器损坏，检查更换使其供电正常。

如果主机上没有直流12伏电压先检查键盘保险丝是否烧断，如烧断查明原因更换新的（236-F2 0.5A；238、2316-F3 0.75A）。

更换保险丝后仍没有直流12伏电压或电压不正常需找到直接供货商送修处理。

（3）. 对照接线图检查主机到键盘的接线是否正确如果发现错误请将接线按接线图正确连接。

Q2: 2300系列主机有防区不正常（防区LED灯亮），用键盘布防无效，不能进入布防状态。

A: 出厂设置应为常模布防，只要有防区不正常主机就不可以被布防。

常模布防定义：只有每个防区都正常时才能布防；好处：防止某防区有问题也能布防。

如果确实需要，请改为强制布防238、2316在编程第9项中第4位改为“2”，236在编程第8项中第2位改为“1”。

注意：需要慎重使用，确认有此需求：每个防区都不正常时也能布防。

Q3: 2300系列主机用键盘不能对某些防区旁路A: （1）. 是否是236主机如果是，有可能将编程第24项——防区旁路许可默认值改为不能旁路，恢复的办法是将编程第24项1-6防区需要旁路的值改为“1”。

（2）. 是否是238或2316主机如果是，第一有可能设置用户密码时选择了不能旁路的密码，改变的方法是再重新设置一个可以旁路的密码。

2300系列报警主机Q1: 236、238、2316键盘无任何显示按键无反应A: （1）. 误将[安装员密码] [*] [69] [#]做为主机复位，主机被锁定。

请再用安装员密码（出厂设置012345）[*] [69] [#]操作一遍看结果？如果仍不正常显示需找到直接供货商送修处理。

（2）. 主机的1、2端子是否有交流16.5伏电压？键盘电源端子是否有12伏直流电压？如果检查16.5伏电压不正常可能是220伏交流电源或变压器损坏，检查更换使其供电正常。

如果主机上没有直流12伏电压先检查键盘保险丝是否烧断，如烧断查明原因更换新的（236-F2 0.5A；238、2316-F3 0.75A）。

更换保险丝后仍没有直流12伏电压或电压不正常需找到直接供货商送修处理。

（3）. 对照接线图检查主机到键盘的接线是否正确？如果发现错误请将接线按接线图正确连接。

Q2: 2300系列主机有防区不正常（防区LED灯亮），用键盘布防无效，不能进入布防状态。

A: 出厂设置应为常模布防，只要有防区不正常主机就不可以被布防。

常模布防定义：只有每个防区都正常时才能布防；好处：防止某防区有问题也能布防。

如果确实需要，请改为强制布防238、2316在编程第9项中第4位改为“2”，236在编程第8项中第2位改为“1”。

注意：需要慎重使用，确认有此需求：每个防区都不正常时也能布防。

Q3: 2300系列主机用键盘不能对某些防区旁路A: （1）. 是否是236主机？如果是，有可能将编程第24项——防区旁路许可默认值改为不能旁路，恢复的办法是将编程第24项1-6防区需要旁路的值改为“1”。

（2）. 是否是238或2316主机？如果是，第一有可能设置用户密码时选择了不能旁路的密码，改变的方法是再重新设置一个可以旁路的密码。

第二需要检查30-3F编程，它们的第二位应设为“1”,准许旁路。

Q4: 2300键盘某些防区灯与READY灯一起闪，按消除操作没有反应。

236主机编程速成一、欧阳歌谷（2021.02.01）二、 操作：旁路：密码 )取消记忆：＊１＃复位：密码＊６８＃例如：布防、撤防：１２３４＃ 旁路：１２３４ #复位：１２３４＊６８＃三、编程：1．进入编程：０１２３４５*０ # 2．退出编程：* # 3．密码部分：０１__ __ __ __ # 密码必须四位……4．通讯部分：０７１１１１１１# ０８００１０００#０９０１１１００# 5．１１１２２０ #四防区 ２０ １１１２２０ # 五防区 ２１ １１１２２０ # 六防区 ２２ １１１４２０ #1）第一防区为： 1*3111020# 手报24小时防区1*3111420#2）第二防区为： 1*4111020#手报 1*4111420# 3）第三防区为： 1*5111020#红外 1*5111320# 4）第四防区为： 20111020#红外 20111320# 5）第五防区为： 21111020# 烟感 21111420#110: 开启通讯 1：关闭通讯A 、B 、C 、D 、E 、F 分别用相应复合键代替：A ：*0B ：*1C ：*2D ：*3E ：*4F ：*56）第六防区为： 22111020#烟感 22111420#238主机编程速成一、操作：布防、撤防：密码#， 旁路：密码为右下角的键)取消记忆：*1# ，复位：密码*68#例如：布防、撤防：１２３４＃ 旁路：１２３４#复位：１２３４＊６８＃ 二、编程： １．进入编程：０１２３４５*０ #２．退出编程：* #３．密码部分：０１C １ __ __ __ __ # 密码开头必须为1，写够5位，若为4位，以*4作为1位结束；……4.００ １１__前６位__ __ # １２第7位_Ｅ００００#１4__ 前６位__ __#１5第7位Ｅ００００ # 5.防区部分：__ 3 #填入接警中心电话号码 C ：布撤防后向中心发布撤防报告9：布撤防后不向中心发布撤防报告填入遥控中心电话号码二防区2 0 １2 １ __ __ 3 # 三防区2 1 １2 １ __ __ 3 #四防区 ２2 １2 １ __ __ 3 # 五防区 ２3 １2 １ __ __ 3 # 六防区 ２4 １2 １ __ __ 3 # 七防区２5 １2 １ __ __ 3 #八防区 ２6 １2 １ __ __ 3 #2316主机编程速成一、操作：布防、撤防：密码#，旁路：密码 #(bypass 为右下角的键)取消记忆：*1# ，复位：密码*68#二、编程：1. 进入编程：０１２３４５*０ #2． 退出编程：* #3．密码部分：０１C __ __ __ __ # 5位,若少于5位,以*4作为1位结束,后填0； ……4.０Ａ ００ １4__ 前６位__ __#１5第7位Ｅ００００ #5.2.即时3.延时9.24小时 11C ：布撤防后向中心发布撤防报告 9：布撤防后不向中心发布撤防报告填入遥控中心电话号码一防区１F １2 １ __ __ 3 #二防区 2 0 １2 １ __ __ 3 # 三防区 2 1 １2 １ __ __ 3 #十防区4A １2 １ __ __ 3 #四防区 ２2 １2 １ __ __ 3 #十一防区4 B １2 １ __ __ 3 # 五防区 ２3 １2 １ __ __ 3 #十二防区4 C １2 １ __ __ 3 # 六防区 ２4 １2 １ __ __ 3 #十三防区4 D １2 １ __ __ 3 # 七防区 ２5 １2 １ __ __ 3 #十四防区4 E １2 １ __ __ 3 # 八防区 ２6 １2 １ __ __ 3 #十五防区4 F １2 １ __ __ 3 # 九防区4 9１2 １ __ __ 3 #十六防区5 0 １2 １ __ __ 3 #警声：1.脉冲声 2.稳定声2.即时3.延时 9.24小时。

PA/V A SOLUTIONSVARIODYN D1Digital Public Address andVoice Alarm System2 | Voice Alarm is increasingly important in the safe management of buildings. A voice message informs occupants exactly what to do in an emergency and it is a long established fact that people respond more quickly and are more likely to take the correct action during an evacuation if voice messages are used instead of tone sounders.THE ROLE OF VOICE ALARM• Clear directions to people in the building• Live messages giving exactinstructions to people whoare not familiar with the surroundings • Customised pre-recordedmessages (available inmultiple languages)• Up to 20 minutes shorter response time to fire alarm• Serial Interface toHoneywell fire panels for EVAC guidance and time-controlled evacuation • High-end non-emergency features such asequalizing, automatic volume control and multi-channel announcements as well as backgroundmusic • Alarm cancellation and manual evacuation override controlBENEFITS | 3PUBLIC ADDRESS -MORE THAN VOICE ALARMVoice Alarm systems are more frequently used as public address and entertainment systems than only as automatic evacuation system inpublic buildings with a high number of visitors.• Paging and evacuation with zone-dependent messages • Integration with airport/train station managementsystems• Multiple channel/zone music broadcasting • Sport/concert hall and stadium sound systemintegration • Time-scheduled announcements• Touch screen operation panels• Operation from intuitive computer management systems • High quality background music for high class shopping experienceFEATURES PUBLIC ADDRESS PROVIDES ADDITIONALL Y:4 |Selecting, designing and commissioning a PA/VA system can be challenging. At Honeywell we have a team of experts that will help you build the most suitable system for your building.The first step is to decide exactly what type of PA/VA system you will need. This will largely depend on the size and functional complexity of your building.The following two types of systems are available that start from small ‘Compact Solution’ packages suitable for single storey buildings such as shops and offices and move up to a custommade ‘Modular System’ that will consist of a number of distributed systems linked together for large structures such as exhibition fairgrounds and airports.VOICE ALARMCOMPETENCE FOR YOU• Controlling and indicating equipment certified to EN 54-16 and EN 54-4• Complete range of EN 54-24 certified loudspeakers • Flexible systems that supports both simple and the most complex communication needs • High quality digital audio matrix• Intuitive touchscreen Graphical User Interface that manages the entire system • Phased evacuation scenarios • Situation, location & evacuation phasedependent voice messages • Exact guidance regarding evacuation routes• Freely configurableevacuation scenarios with logical dependencies • Dedicated Honeywelldesign and project supportSYSTEMS KEY FEATURES |5 LEISURE COMPLEXES SCHOOLS SMALL HOTELS OFFICESTHE COMPACT SOLUTION:COMPRIO D1An easy-to-install PA/VA system.Suitable for small to medium buildingswith up to 24 loudspeaker zones.APPLICATIONS• Leisure complexes• Supermarkets• Schools• Hotels• OfficesBENEFITS• Amplifier with build-in PSU available• ‘Off the Shelf’ Package• Installation within two hours• Only 8 HU rack space incl. amplifier,charger and batteries• Ensured compliance to ENstandards• Complete solution for up to 24zones• max. 2000 W output powerexpandable with additional DOM/AMPs6 | Our PA/VA systems can be distributed and networked together to deliver the most comprehensive and powerful solution for a wide range of applications. Suitable for mid to large and complex sites.THE MODULAR SOLUTION V ARIODYN D1• Industrial facilities • Universities• Airports and transport hubs • Stadiums• Exhibition halls and fairgrounds • Mega Shopping Malls • Large Office buildingsAPPLICATIONS• Scalable and modular to adapt to constant changes and demands• Supports a large number of evacuation and/or paging zones • Manages complicated evacuation strategies in the event of an emergency • IP connectivity tolink multiple nodes (VARIODYN D1 DOM)BENEFITS• Up to 120 announcements at the same time• Pre-recording and playbackof messages• Secured data link to various Honeywell Fire Alarm Systems• Decentralized and redundant system architecture• Interface to BuildingManagement Systems (e.g. Honeywell EBI)• Redundant network and Call Stations linksComputer Management Station (PAMMI)Decentralized | 7STADIUMS AIRPORTS SHOPPING MALLS RAILWAY STATIONSCUSTOMISED CONTROLThe PAMMI (Public Announcement Man Machine Interface) software provides monitoring and control of the Honeywell Voice Alarm System via a graphical user interface on a Microsoft Windows® based personal computer.PERFECT SYMBIOSIS VOICE ALARM AND FIRE ALARMAREA BY AREA, TARGETED AND ORDERL Y:EVACUATION PROCEDURE EXAMPLE AT THE AIRPORT• There is a short-circuit in the baggage sortingarea on the 1st sub-level,section B of the airport. • The fire detector detects the formation of smokeand transmits theinformation to the firealarm control panel.• The fire alarm system simultaneously initiatesalarms to the securityservices and the voicealarm system.• The security inspectorassesses the situation viathe video camera installedon-site and then activatesa stored a nnouncementto the personnel with thepush of a button.• Due to the increasingformation of smoke,the fire alarm systemautomatically closes thefire door in the affectedarea.Synergies arise through digital coupling of the fire alarm system with the voice alarm system, thus facilitating an orderly, area-specific evacuation during emergencies: If a fire is detected by the connected fire detectors and then received by the fire alarm control panel, this automatically activates the voice alarm system. The endangered areas are then selected automatically and informed via the PA/VA system, while at the same time the fire alarm control panel activates fire protection systems, for example, fire doors, air-conditioning and ventilating systems, elevator controls or smoke dampers.The combination of voice alarm and fire alarm technology not only offers functional advantages, there are economical advantages as well: PA/VA reduces the total EVAC time significantly, a PA/VA system is not much more expensive than standard sounders, while it adds valuable support by increasing productivity of building occupants.8 | | 9VARIODYN D1 AND COMPRIO PA/VA SYSTEM DIAGRAM Thanks to its modular construction and the varioussystem components, the VARIODYN D1 system can easily DCS Digital Call Station DSCF DSC for Firefighter Fire Alarm Control PanelInterfaceDOMAMP PSUDCSF 1/12Configuration via LaptopCD playerETCSDCS PlusCentral Operating Terminal(PAMMI, WINMAG, Honeywell EBI etc)Loop Isolator ModuleAdvanced,Automatic Volume Control10 | WINMAGPLUSONE MANAGEMENT SYSTEM FOR ALLPERFORMANCE FEATURES OF THE VARIODYN D1 INTERFACE WINMAGPLUS DRIVER• System configuration readout of a VARIODYN D1 network to take it over via import files to WINMAGplus application.• Fault and status indication of the VARIODYN D1 system components: • DOM, SCU, DAL bus devices like DCS and • UIM, Amplifiers (each channel)• Audio and control contact inputs and outputsThe WINMAGplus hazard management system lets you create a scalable software solution with superb levels of integration with different sub-systems.In case of Voice Alarm system, VARIODYN D1 is connected via Ethernet/RJ45 to the same network as the WINMAGplus server. This enables the VARIODYN D1 integration with systems such as: fire alarm, fire extinguishing, smoke and heat control, escape routes, CCTV, access control, intrusion detection, emergency lighting as well as BMS and others via open protocols.• Call station function: • Microphone switched to pre-selectable or fixed targets for live-spoken announcements• Playback of pre-recorded announcements onselectable or fixed targets• Display, update and controlof: • Volume• Volume presettings (min., max., alarm)• Audio signal levels • Control contacts | 11Client Ma chinesHazardManagementVideo SystemsIntrusion Detection SystemsAccess ControlPublic Address & Voice AlarmFire AlarmFireExtinguishingFireControlsEmergency LightingBuildingManagement Systems12 | CHALLENGING PROJECTS REQUIRE BEST DESIGN AND EXPERTISEBY CEN/TS 54-32 EUROPEAN STANDARD VA SYSTEM CAN BE DESIGNED IN 2 WAYS TO ACHIEVE REQUIRED INTELLIGIBILITY: 1. Simplified, prescriptive method, requiring loudspeakers mounted every 6 meters or less.2. Detailed method, requiring in practice acoustics simulations as VA system design base regarding spacing, location, type selection, audio equalizing and proper orientation of loudspeakers.Acoustic simulations are paramount for a proper PA/VA system design in complex, tough and large areas. EN 50489 and CEN/TS 54-32 require minimum intelligibility level from installed VA systems. Installing and planning VA systems bears a risk of failure during intelligibily measurements in the handover phase. Toprevent such critical situations and underbudgeting of VA systems acoustic simulations are the only guarantee. |13EXAMPLE OF THE ACOUSTIC SIMULATION OF AN AUDITORIUM Acoustic simulation software provides to precisely and reliably assess sound pressure level (dB) and intelligibility level (STI/CIS). The software calculates the simulatedroom as a space map in 3D, enabling the user to verify the selected type, location and setting of loudspeakers.Voice Alarm system design for acoustically challenging areas must be based on professional, quality simulations,prepared by experienced acoustic experts.Our Technical Support Team provides expertise, experience, tools and wide portfolio of certified VA loudspeakers to assure our partners and system designers that Variodyn D1 system designs will pass acceptance tests.14 | VARIODYN D1 PRODUCT FAMIL YAll of the components of the VARIODYN D1 product family are compatible, interchangeable and optimally adapted to the customers growing needs. As varied as the requirements may be, all of the components are modular designed andcan be combined with each other quick and easy.ComprioComprio is a voice alarm system optimised for small and medium-size facilities such as schools,hotels, leisure centres and offices. It's characterised by its compact design, wide performance range and its flexibility.Digital Output Module (DOM)The Digital Output Module (DOM) is the heart of the Honeywell Voice Alarm and Public Address system. Managing either 8 or 24 zones the DOM routes up to 4 channels of audio from amplifiers to any individual zone or group of zones.Class D Power AmplifiersCombining the latest in digitalaudio technology with the integrity necessary for emergency Voice Alarm systems to satisfy the requirements of EN54 part 16.Direct Drive Power Amplifier4-channel Direct Drive Amplifier 4 x 300 W or 4 x 500 W power outputs or unit providing 4 x 125 W or 4 x 250 W power outputs with integral EN 54-4 certified battery charger.Paging Microphone DCSPlus The paging microphone allows for the selection of loudspeakerzones, and the transmission of voice announcements via programmable buttons.Ethernet Touch Call Station (ETCS)This EN 54-16 certified touch screen call station provides a user friendly, multilingual and multi-user interface support with high failure safety due to redundant transmission routes via Ethernet (PoE possible). It includes audio memory up to 27 hour and a USB stick can be connected to play audio files as well.Universal Interface Module (UIM)Interface module enables audio or control connection to third party systems such as CD players, security systems and other PA/VA or building management control systems.System Communication Unit (SCU)The System Communication Unit (SCU) is an integrated digital audio memory source able to simultaneously record and play back multiple audio data streams.PAMMI PublicAnnouncement User Interface The PAMMI software provides connection and control of the Honeywell Voice Alarm System via a graphical user interface on a Microsoft Windows ® based PC.Emergency Microphones Emergency Microphone used to select and broadcast pre-programmed alarm messages and live voice announcements during emergency situations by security operator or fire brigade commander. | 15LOUDSPEAKERSHoneywell offers loudspeakers, specially designed to meet various requirements and specifications in many project types e.g.Excellent acoustic performance to realize clear, understandable voice announcements or high quality background music.• Cost-effective types• Well designed, modern appearance• Easy for installation to reduce time, efforts and costs • Robust material to offer long lifetime•Models with ceramic terminal block and thermofuseCeiling Loudspeaker• Metal or plastic ceilingloudspeakers• Several power tappings withsimple setting• Partly dual-cone speaker toensure best audio performance • Appropriate for indoorapplications such as offices, warehouses, schools etcHorn Speaker• Clear voice messagereproduction for open and outside areas• Offers a high sound pressureand long-lasting weather resistanceSound Projector• Wide frequency response range,low distortion• Robust aluminum housing • IP65 rating• Best option for applicationssuch as corridors and railway platformsColumn Loudspeaker • Flat, directed soundpropagation, minimized reverberation• Intelligible voice and superiorsound reproduction • IP65 rating• Great choice for theme parks ,exhibition halls and any open, high-volume rooms with high reverberation time.Cabinet Loudspeaker• Simple power setting and easyinstallation• Practicable for wall mountapplication• Plastic, MDF or metal vandal-proof cabinetSpherical Loudspeaker• Where wall mount or ceilingmounting is not possible • Variable hanging height • 360° sound propagationSpecial Loudspeaker for tunnels• Specially designed and EN 54-24certified for tunnel applications • Boundary effect and loudspeakerphasing for best intelligibility inextremely difficult tunnel projectsEXTRACT FROM OUR EXTENSIVE PRODUCT OFFERINGS:00-0000 | DI | 01/ 21© 2021 Honeywell International Inc.Honeywell Building Technologies 715 Peachtree St. NE Atlanta, GA 。

霍尼韦尔报警系统资料说明一、接线图1、236 plus Ⅱ2、2316 plus Ⅱ接线备注：1.警号（二芯）分正负极，红色线为正极接“BELL+”，黑色线为负极接“GND”。

2.探测器（四芯，例如：双鉴移动探测器、红外幕帘、震动探测器、等需接电源的探测设备）的供电正极接“不可关断的辅助电源”的“AUX”，负极接“不可关断的辅助电源”的“GND”;信号端不分正负但接防区的“Z”端需串接一个电阻，另一端接防区的“GND”。

3.编程键盘(三芯)的供电端“+”接“KEY+”, “_”接“GND”, 数据端“DAT”接“DATA”（数据端的负极实际是共用电源端的GDN）。

4.紧急按钮（二芯）需接常闭的两个触点，而非常开触点。

不分正负但接防区的“Z”端最好串接一个电阻（以防设备短路而烧坏主机板电路），另一端接防区的“GND”。

5.门磁（二芯）接法同紧急按钮。

6.空余防区，可接电阻（电阻一端接防区的“Z”端，一端接“GND”端），也可不接电阻。

7.移动探测器的软胶面向下安装，对着要监视的防区空间（只要检测到有人移动，LED灯就会亮，否则LED灯为灭的状态）。

8.主机箱的防拆开关引出的两根线不分正负但接防区的“Z”端最好串接一个电阻，另一端接防区的“GND”。

二、编程1.加电后，准备灯为绿色。

2.进入编程命令：按“012345*0#”，此时“准备”“布防”“服务”三灯亮，表示进入编程状态。

3.输入命令结束后按“#”结束当前项编程，继续下一项编程。

4.退出编程状态：按“*”“#”即可退出编程状态。

5.断电后在加电即可生效。

6.编程过程中，不要管指示灯的状态，只要提示音正常即可继续对下一项地址编程。

三、恢复初始值（一般用于编程混乱后使用）断电后用跳线短接“DEFAULT”的两脚不放，然后加电，大约5秒后（此时键盘灯会有变化）松开短接触点即可恢复初始值。

四、常用编程命令（以236 plus Ⅱ为例，其它型号请参考相应说明书）1.默认参数2.安装员密码编程3.用户密码编程（及布防和撤防时输入的密码）4.控制主机时间编程5.回路防区控制编程（重要）重点说明：1．某银行的探测器防区配置：1-5防区为墙面及自助机柜震动探测器，6-7防区为自助机门磁，8防区为紧急按钮，9防区为防盗门的门磁，10防区以后为红外探测器，空余防区均接了电阻。
